A Comparative Study of Multi-Model Lane Detection Methods Based

on a Unified Evaluation Framework

Shaopu Zou

School of Computer and Artificial Intelligence, Beijing Technology and Business University, Beijing, China

Keywords: Lane Detection, SCNN, PINet, LaneATT, CULane.

Abstract: Lane detection, as a crucial task in autonomous driving systems, faces the dual challenges of robustness and

accuracy in complex road environments. This study conducts a comparative analysis of three representative

deep learning models—Spatial Convolutional Neural Network (SCNN), Point Instance Network (PINet), and

LaneATT. The models are reproduced and evaluated under consistent input settings using the unified CUHK

Lane Dataset (CULane) and a standardized evaluation tool. Both quantitative metrics and visualized results

are utilized to assess each model’s detection performance across diverse driving scenarios. Experimental

results demonstrate that LaneATT achieves the best overall performance, particularly exhibiting strong

robustness in challenging conditions such as nighttime and shadowed environments. PINet excels in curved

lane detection, while SCNN maintains stable outputs in standard road settings. This study establishes a unified

evaluation framework for horizontal comparisons of lane detection models, providing a systematic basis for

performance assessment under standardized conditions. The proposed framework contributes to the

advancement of algorithmic benchmarking and offers methodological guidance for subsequent research on

model optimization and real-world deployment.

1 INTRODUCTION

With the rapid development of autonomous driving

technology, lane detection has become a crucial

component of the vehicle perception system and has

attracted increasing attention (Singal et al., 2023).

Accurate lane detection not only helps vehicles

maintain correct trajectories on the road but also plays

a vital role in Lane Keeping Assist Systems (LKAS)

and Advanced Driver Assistance Systems (ADAS)

(Waykole et al., 2021; Tian et al., 2021). However,

complex road environments—such as varying lighting

conditions, occlusions, and curved roads—still pose

significant challenges to reliable lane detection

(Sultana et al., 2023).

Traditional lane detection approaches primarily

rely on image processing techniques such as edge

detection and Hough transforms. While effective

under ideal conditions, these methods are vulnerable

to disturbances in complex environments, often

resulting in reduced detection accuracy (Huang &

Liu, 2021). In recent years, the emergence of deep

https://orcid.org/0009-0007-6134-0737

learning has introduced significant breakthroughs in

this field (Zakaria et al., 2023). Models based on

Convolutional Neural Networks (CNNs) can

automatically learn visual features from data, thus

enhancing both robustness and accuracy in lane

detection tasks (Kortli et al., 2022).

Among the various deep learning-based lane

detection methods, the Spatial Convolutional Neural

Network (SCNN) introduces spatial convolution

modules to enable information propagation across

feature maps, thereby improving the structural

modeling of lane lines (Pan et al., 2018). The Point

Instance Network (PINet) treats lane detection as a

keypoint estimation and instance segmentation task,

transforming it into a clustering problem of point

instances, which enhances performance in detecting

complex lane geometries (Ko et al., 2021). The

LaneATT combines anchor-based mechanisms with

attention modules, directly regressing lane

parameters to achieve efficient lane detection

(Tabelini et al., 2021).

Despite the strong performance demonstrated by

these models in their respective studies, differences in

Zou, S.

A Comparative Study of Multi-Model Lane Detection Methods Based on a Uniﬁed Evaluation Framework.

DOI: 10.5220/0014322600004718

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 2nd International Conference on Engineering Management, Information Technology and Intelligence (EMITI 2025), pages 123-129

ISBN: 978-989-758-792-4

123

experimental settings and evaluation criteria make it

difficult to conduct fair and direct comparisons under

the same conditions. To address this issue, this paper

reproduces and evaluates SCNN, PINet, and

LaneATT within a unified experimental environment.

All models are tested using the same dataset—CUHK

Lane Dataset (CULane) (Pan et al., 2018) — and

assessed through consistent evaluation tools and

metrics to facilitate a systematic comparison of their

detection performance across various driving

scenarios.

The remainder of this paper is organized as

follows:

Chapter 2 provides a detailed introduction to the

dataset used and the technical principles and

architectures of the three lane detection models.

Chapter 3 elaborates on the experimental setup

and evaluation metrics and presents a comparative

performance analysis and visualizations across

different scenarios.

Chapter 4 summarizes the research findings,

discusses the limitations of current methods, and

outlines potential directions for future work.

2 DATASET AND METHODS

2.1 Dataset

This study adopts the CULane dataset, a large-scale

open dataset specifically designed for lane detection

tasks, provided by the Multimedia Laboratory of The

Chinese University of Hong Kong. The CULane

dataset covers a wide range of real-world driving

scenarios, aiming to provide a comprehensive and

challenging evaluation environment for lane

detection models.

The dataset consists of approximately 133,235

images, including around 88,880 images for training,

9,675 for validation, and 34,680 for testing. All

images are extracted from real urban driving videos,

ensuring strong practical relevance for real-world

applications.

Each image in the dataset is manually annotated

with lane markings using cubic spline curves. Even

when lane lines are occluded or not clearly visible,

annotations are inferred based on contextual

information (as shown in Figure 1). This annotation

method accurately captures the position and shape of

lane lines and supports a variety of downstream tasks

such as regression, detection, and segmentation.

Figure 1. Example of point-wise lane annotation (Picture

credit: Original)

The test set of the CULane dataset is divided into

nine representative scenarios (some of which are

illustrated in Figure 2): normal, crowded, dazzle light,

shadow, no lane, arrow, curve, crossroad, and night.

Each subset targets specific environmental

challenges, allowing for a thorough evaluation of

model generalization under diverse driving

conditions.

Figure 2. Examples of different road scenarios (Picture credit: Original)

Images in the CULane dataset have a resolution of

1640 × 590 pixels, preserving fine-grained visual

details that facilitate accurate recognition of distant or

thin lane markings.

In this study, all models are evaluated using the

official CULane data split, with identical training and

testing configurations. Inference is conducted at a

fixed input resolution, and a unified evaluation tool is

used to assess performance. The focus of this work is

on model inference and evaluation on the standard

test set without any retraining or fine-tuning, ensuring

fairness and reproducibility in the comparison.

Given its large scale, diverse scenarios, and

precise annotations, the CULane dataset serves as an

ideal benchmark for lane detection experiments and

provides a solid foundation for comparing algorithm

performance in complex real-world environments.

EMITI 2025 - International Conference on Engineering Management, Information Technology and Intelligence

124

2.2 Methods

To comprehensively compare the performance of

different lane detection methods in complex road

scenarios, this study selects three representative deep

learning models—SCNN, PINet, and LaneATT—for

experimental evaluation. These models differ in

network architecture and detection strategies,

reflecting the strengths and limitations of current

mainstream approaches from various perspectives.

2.2.1 SCNN Model

The SCNN model introduces spatial convolution

units into a traditional convolutional neural network,

based on an adapted VGG16 backbone, enabling

serialized information propagation along the spatial

dimensions of the feature maps. Specifically, SCNN

propagates features in horizontal and vertical

directions, effectively modeling the elongated and

continuous structure of lane lines.

The overall architecture of SCNN consists of a

backbone network, spatial convolution modules, and

a prediction head. The input image is first processed

through a series of convolutional layers to extract

base features. Then, spatial message passing is

performed iteratively in four directions—up, down,

left, and right—to enhance the representation of lane

continuity in the feature maps. Finally, fully

connected layers predict lane point positions along

each scanline to produce the final detection results.

This approach maintains computational efficiency

while significantly improving detection accuracy in

complex environments, making it particularly

suitable for extracting continuous lanes under

occlusions or road wear.

2.2.2 PINet Model

The PINet model adopts an instance segmentation

approach, transforming lane detection into a point-

wise instance prediction problem. It uses a stacked

hourglass network to extract multi-scale features and

then predicts each pixel’s lane instance affiliation

and its spatial offset.

The architecture consists of three main

components: a feature encoder, an instance

embedding branch, and an offset regression branch.

The encoder, typically a stacked Hourglass network,

extracts hierarchical features from the input image.

The embedding branch generates a low-dimensional

vector for each pixel, allowing pixels belonging to the

same lane to be clustered. The offset branch predicts

each pixel’s displacement relative to the centerline

of its corresponding lane. A clustering algorithm

(e.g., Mean Shift) is then used to group lane points

into complete lane instances.

This method is highly adaptable to varying

numbers and shapes of lane lines, showing strong

robustness in dense or sharply curved road

conditions.

2.2.3 LaneATT Model

The LaneATT model employs an anchor-based

regression strategy combined with attention

mechanisms, discarding traditional pixel-wise

segmentation in favor of directly regressing lane

parameters such as quadratic coefficients and

endpoints. LaneATT typically utilizes ResNet-34 as

its backbone and applies a Transformer encoder to

capture global contextual features. Anchors are

placed at predefined positions for efficient lane

parameter regression.

Its architecture includes a feature extraction

backbone (typically ResNet), a Transformer encoder,

and a lane regression head. The backbone encodes the

input image into intermediate features, which are then

globally modeled by the Transformer module to

capture long-range spatial dependencies. Finally, the

model performs lane regression at anchor locations to

produce fitted lane curves.

LaneATT achieves high detection accuracy while

significantly improving inference speed, making it

well-suited for real-time or large-scale deployment

scenarios.

2.2.4 Unified Experimental Setup

To ensure fairness in model comparisons, all

experiments in this study adopt the official training

and testing splits of the CULane dataset. Input images

are resized to a unified resolution across all models.

Inference is conducted under the same hardware

environment to ensure comparability in speed and

resource consumption. Results are evaluated using

consistent metrics and identical evaluation scripts.

To provide a clear overview of the differences in

model architecture and detection strategy, the key

characteristics of the three models are summarized in

Table 1. This study focuses solely on the inference

performance of the models without any retraining or

modification of the original implementations.

A Comparative Study of Multi-Model Lane Detection Methods Based on a Uniﬁed Evaluation Framework

125

Table 1. Comparison of the architectures of the three lane detection models

Model Backbone Core Module Out

ut T

e Characteristics

SCNN VGG16 Spatial convolution unit Scanline-wise point

rediction

Strong continuity, suitable for

occluded or worn lane markings

PINet Hourglass Instance embedding + offset

ression

Clustering of points

into lanes

Flexible in handling variable number

and sha

e of lane lines

LaneATT ResNet Transformer encoder +

ancho

ased re

ression

Curve parameter

ression

Fast inference, suitable for real-time

lications

3 EXPERIMENTS

3.1 Evaluation Metrics

To comprehensively evaluate the performance of

each lane detection model, this study adopts the

official evaluation metrics provided by the CULane

benchmark. The evaluation tool matches predicted

lane lines with ground truth annotations based on the

spatial overlap and calculate Precision, Recall, and F-

measure as the core performance indicators.

3.1.1 Matching Method

The evaluation tool first fits both predicted and

annotated lane lines using spline interpolation and

renders their respective width masks in the image

space. It then calculates the Intersection over Union

(IoU) between the two lines, as illustrated in Equation

(1).

IoU =

Predict ∩ GT

Predict ∪ GT

(1)

A predicted lane line is considered a successful

match if its IoU with a ground truth lane line exceeds

a threshold of 0.5. To ensure optimal matching in

multi-lane scenarios, the tool applies the Hungarian

Algorithm to compute one-to-one pairings based on

the IoU similarity matrix. This process yields global

statistics for True Positives (TP), False Positives (FP),

and False Negatives (FN) across the entire image.

3.1.2 Metric Definitions

Based on the above matching process, the final

evaluation metrics are defined as follows:

Precision: The proportion of correctly predicted

lane lines out of all lane line predictions made by the

model.

Precision =

(2)

Recall: The proportion of ground truth lane lines

that are successfully detected by the model.

Recall =

(3)

F-measure: The harmonic mean of Precision and

Recall, providing a balanced assessment of both

accuracy and completeness in lane detection.

F1 =

2 × Precision × Recall

Precision

Recall

(4)

3.2 Experimental Results and Analysis

To systematically compare the lane detection

performance of SCNN, PINet, and LaneATT under

various driving scenarios, this study evaluates each

model on the nine representative scenes defined in the

CULane dataset. For each scenario, Precision, Recall,

and F1-measure are calculated. Among them, F1-

measure is considered the primary performance

metric in this study. Table 2 presents the comparative

results of the three models across all scenarios.

Table 2. F1-measure, Precision, and Recall comparison of three models across different CULane scenarios

Scenario SCNN

PINet

LaneATT

SCNN

Precision

PINet

Precision

LaneATT

Precision

SCNN

Recall

PINet

Recall

LaneATT

Recall

Normal 0.9049 0.8985 0.9218 0.9070 0.9235 0.9384 0.9029 0.8749 0.9059

Crowd 0.6803 0.7184 0.7500 0.6922 0.8157 0.8100 0.6688 0.6418 0.6983

Hlight 0.6332 0.6458 0.6669 0.6482 0.7767 0.7455 0.6189 0.5527 0.6033

Shadow 0.6352 0.6683 0.7795 0.6340 0.8223 0.8216 0.6364 0.5629 0.7416

EMITI 2025 - International Conference on Engineering Management, Information Technology and Intelligence

126

No line 0.4351 0.4769 0.4936 0.4538 0.7399 0.6611 0.4179 0.3518 0.3939

Arrow 0.8457 0.8350 0.8840 0.8556 0.9069 0.9226 0.8360 0.7738 0.8484

Curve 0.6159 0.6361 0.6767 0.6649 0.7679 0.7950 0.5736 0.5429 0.5890

Cross 0 0 0 0 0 0 -1 -1 -1

Night 0.6559 0.6605 0.7055 0.6590 0.8301 0.7996 0.6528 0.5484 0.6311

As shown in Table 2, the three models exhibit

varying detection performance across different

driving scenarios. Overall, LaneATT consistently

achieves the highest F1-measure across all scenarios,

demonstrating superior robustness, particularly in

challenging conditions such as crowded, shadowed,

and nighttime environments. In the Normal scenario,

all three models perform well, with LaneATT slightly

outperforming SCNN and PINet.

In more complex settings—Crowd, Shadow, and

Night—LaneATT shows a substantial lead in F1 score

compared to the other two models, highlighting its

strong adaptability. While performance drops under

extreme conditions such as Hlight (dazzling light) and

No line (no visible lane markings), LaneATT still

maintains a performance edge.

Notably, in the Curve scenario, both PINet and

LaneATT demonstrate good adaptability, likely due

to their ability to handle non-linear lane structures. In

the Arrow scenario, SCNN and LaneATT achieve

higher detection accuracy, with LaneATT attaining

an F1-measure of 0.884.

It is important to note that although the CULane

dataset includes the Cross (intersection) scenario, this

subset does not provide ground truth lane annotations.

As such, the evaluation tool is only used to test model

robustness in this scene rather than actual detection

performance. Consequently, all models score zero in

this scenario—not due to poor performance, but due to

the lack of ground truth, and this subset is excluded

from the core performance comparison.

In summary, the overall model performance on

the CULane test set can be ranked as: LaneATT >

PINet > SCNN. LaneATT leverages anchor-based

regression and Transformer-driven global modeling

to achieve superior detection accuracy and robustness

across diverse scenarios. PINet, with its point-

instance detection strategy, excels in handling curved

or lane-dense environments. SCNN, while slightly

lower in overall accuracy, demonstrates stable

continuity in lane detection, particularly under

occlusion or degradation.

3.3 Visualization of Experimental

Results

To further compare the performance of the three

models across different scenarios, representative test

image samples were selected, and the prediction

results of SCNN, PINet, and LaneATT were

visualized on the same images. Figure 3 presents a

comparison between the predicted lane lines and the

ground truth, where green lines represent the

annotated lanes and red lines indicate the predicted

outputs from each model.

Figure 3. Visualization comparison of lane detection by the three models in typical scenarios (Picture credit: Original)

A Comparative Study of Multi-Model Lane Detection Methods Based on a Uniﬁed Evaluation Framework

127

As illustrated in Figure 3, the performance of

different models varies significantly under complex

scenarios. In the Normal scenario, all three models

are able to accurately detect lane lines, with

predictions closely matching the ground truth.

LaneATT, in particular, demonstrates smoother

fitting at lane curvature points, reflecting superior

detail recovery capabilities. In the Crowd scenario, all

three models successfully detect the primary lane

lines with minimal prediction error, showcasing good

robustness.

In contrast, in the Shadow scenario, where

lighting conditions change drastically, the models

show noticeable differences. SCNN exhibits

significant deviations and broken lines in its

predictions, leading to reduced accuracy. PINet

detects only two lane lines, but they align well with

the ground truth. LaneATT successfully identifies all

lane lines with predictions almost fully overlapping

the annotations, demonstrating the best overall

performance in this setting.

Under the Night scenario, both LaneATT and

PINet maintain high detection accuracy, whereas

SCNN shows missed detections under low-light

conditions, failing to identify the rightmost lane line

and exhibiting a notable performance drop.

In conclusion, the visual results further support

the quantitative findings presented in Section 3.2.

LaneATT demonstrates stronger robustness and

generalization in complex scenarios, with more stable

and accurate predictions. PINet maintains high

localization accuracy in curved or partially occluded

environments. SCNN, while stable in scenarios with

clear lane continuity, exhibits limited performance

under strong environmental interference.

4 CONCLUSIONS

This study focused on the task of lane detection by

selecting three representative deep learning models—

SCNN, PINet, and LaneATT — for systematic

reproduction and performance comparison under a

unified dataset (CULane) and evaluation framework.

By standardizing the input-output settings, evaluation

metrics, and visualization analysis, the aim was to

explore the detection effectiveness of these models

under various driving scenarios and provide an

empirical foundation for future research.

Experimental results reveal significant

differences in overall performance and detailed

behavior among the three models. LaneATT achieved

the highest F1 scores across all scenarios,

demonstrating superior robustness and generalization

capabilities, particularly in complex environments

such as nighttime, crowded traffic, and variable

lighting conditions. PINet performed well in handling

curved roads and lane-dense scenes, making it

suitable for recognizing structurally complex lane

patterns. While SCNN maintained stable detection in

standard scenarios with good lane continuity, its

performance declined under more challenging

conditions. The visual analyses further confirmed

these quantitative findings, showcasing the prediction

differences on specific test images.

Despite the comprehensive comparative analysis

conducted in this study, some limitations remain.

First, the evaluation focused solely on the inference

stage without including the full training process.

Second, only the CULane dataset was used, lacking

cross-dataset generalization analysis. Third, practical

deployment factors such as detection speed and

resource consumption were not addressed.

Future research can be extended in several

directions: further optimizing model architectures to

improve adaptability in complex scenes; expanding

evaluation to include diverse urban environments and

varying weather conditions; incorporating

lightweight network designs to enhance inference

efficiency and promote real-world deployment in

autonomous driving systems; and exploring multi-

task learning approaches to integrate lane detection

with other perception tasks.

This study holds practical relevance and reference

value. On the one hand, reproducing and comparing

typical models within a unified evaluation

framework, clarifies the applicability and strengths of

current mainstream lane detection methods under

different scenarios, providing a basis for industrial

model selection. On the other hand, the standardized

comparison procedure and multi-perspective

visualization analysis proposed in this work serve as

an experimental paradigm and evaluation reference

for future model improvements and academic studies.

REFERENCES

Singal, G., Singhal, H., Kushwaha, R., Veeramsetty, V.,

Badal, T., & Lamba, S. (2023). RoadWay: lane

detection for autonomous driving vehicles via deep

learning. Multimedia Tools and Applications, 82(4),

4965-4978.

Waykole, S., Shiwakoti, N., & Stasinopoulos, P. (2021).

Review on Lane Detection and Tracking Algorithms of

Advanced Driver Assistance

System. Sustainability, 13(20), 11417.

Tian, J., Liu, S., Zhong, X., & Zeng, J. (2021). LSD-based

adaptive lane detection and tracking for ADAS in

EMITI 2025 - International Conference on Engineering Management, Information Technology and Intelligence

128

structured road environment. Soft Computing, 25(7),

5709-5722.

Sultana, S., Ahmed, B., Paul, M., Islam, M. R., & Ahmad,

S. (2023). Vision-based robust lane detection and

tracking in challenging conditions. IEEE Access, 11,

67938-67955.

Huang, Q., & Liu, J. (2021). Practical limitations of lane

detection algorithm based on Hough transform in

challenging scenarios. International Journal of

Advanced Robotic Systems, 18(2).

Zakaria, N. J., Shapiai, M. I., Abd Ghani, R., Yassin, M. N.

M., Ibrahim, M. Z., & Wahid, N. (2023). Lane detection

in autonomous vehicles: A systematic review. IEEE

access, 11, 3729-3765.

Kortli, Y., Gabsi, S., Voon, L. F. L. Y., Jridi, M.,

Merzougui, M., & Atri, M. (2022). Deep embedded

hybrid CNN – LSTM network for lane detection on

NVIDIA Jetson Xavier NX. Knowledge-based systems,

240, 107941.

Pan, X., Shi, J., Luo, P., Wang, X., & Tang, X. (2018).

Spatial as Deep: Spatial CNN for Traffic Scene

Understanding. Proceedings of the AAAI Conference

on Artificial Intelligence, 32(1).

https://doi.org/10.1609/aaai.v32i1.12301

Ko, Y., Lee, Y., Azam, S., Munir, F., Jeon, M., & Pedrycz,

W. (2021). Key points estimation and point instance

segmentation approach for lane detection. IEEE

Transactions on Intelligent Transportation

Systems, 23(7), 8949-8958.

Tabelini, L., Berriel, R., Paixao, T. M., Badue, C., De

Souza, A. F., & Oliveira-Santos, T. (2021). Keep your

eyes on the lane: Real-time attention-guided lane

detection. In Proceedings of the IEEE/CVF conference

on computer vision and pattern recognition (pp. 294-

302).

A Comparative Study of Multi-Model Lane Detection Methods Based on a Uniﬁed Evaluation Framework

129
