FIRESPARQL: A LLM-Based Framework for SPARQL Query

Generation over Scholarly Knowledge Graphs

Xueli Pan

, Victor de Boer

and Jacco van Ossenbruggen

Vrije Universiteit Amsterdam, De Boelelaan 1105, 1081 HV Amsterdam, The Netherlands

Keywords:

Scholarly Knowledge Graph, SPARQL Query Generation, Finetuning LLM.

Abstract:

Question answering over Scholarly Knowledge Graphs (SKGs) remains a challenging task due to the complex-

ity of scholarly content and the intricate structure of these graphs. Large Language Model (LLM) approaches

could be used to translate natural language questions (NLQs) into SPARQL queries; however, these LLM-

based approaches struggle with SPARQL query generation due to limited exposure to SKG-speciﬁc content

and the underlying schema. We identiﬁed two main types of errors in the LLM-generated SPARQL queries:

(i) structural inconsistencies, such as missing or redundant triples in the queries, and (ii) semantic inaccu-

racies, where incorrect entities or properties are shown in the queries despite a correct query structure. To

address these issues, we propose FIRESPARQL, a modular framework that supports ﬁne-tuned LLMs as a

core component, with optional context provided via retrieval-augmented generation (RAG) and a SPARQL

query correction layer. We evaluate the framework on the SciQA Benchmark using various conﬁgurations

(zero-shot, zero-shot with RAG, one-shot, ﬁne-tuning, and ﬁne-tuning with RAG) and compare the perfor-

mance with baseline and state-of-the-art approaches. We measure query accuracy using BLEU and ROUGE

metrics, and execution result accuracy using relaxed exact match(RelaxedEM), with respect to the gold stan-

dards containing the NLQs, SPARQL queries, and the results of the queries. Experimental results demonstrate

that ﬁne-tuning achieves the highest overall performance, reaching 0.90 ROUGE-L for query accuracy and

0.85 RelaxedEM for result accuracy on the test set.

1 INTRODUCTION

Question Answering (QA) over Knowledge Graphs

(KGs), which allows users to query structured data

using natural language, has gained considerable at-

tention (Huang et al., 2019; Omar et al., 2023). The

task of QA over KGs usually takes a natural language

question (NLQ) as an input and translates it into for-

mal queries, typically SPARQL, that retrieve precise

answers from the underlying KG. Previous studies in

this domain have been centered around large-scale

and encyclopedic KGs such as DBpedia, Freebase,

and Wikidata. In these generic KGs, QA systems

beneﬁt from extensive community resources, well-

documented schema, and relatively simple entity-

relation structures. Recently, the emergence of large

language models (LLMs) has inspired a growing body

of research exploring their potential to address the

task of QA over KGs (Wang et al., 2024b; Omar

https://orcid.org/0000-0002-3736-7047

https://orcid.org/0000-0001-9079-039X

https://orcid.org/0000-0002-7748-4715

et al., 2023) and benchmarked on datasets such as LC-

QuAD (Trivedi et al., 2017), QALD (Perevalov et al.,

2022), and WebQuestions (Berant et al., 2013).

However, applying these techniques to QA to

Scholarly Knowledge Graphs (SKGs) presents signif-

icant challenges due to the intricate nature of schol-

arly data and the complex structure of SKGs (Jiang

et al., 2023; Pliukhin et al., 2023; Taffa and Us-

beck, 2023). Unlike encyclopedic KGs, SKGs cap-

ture domain-speciﬁc and technical content such as re-

search contributions, research problems, methodolo-

gies, datasets, and evaluation, which are often rep-

resented in complex ontological structures. Several

studies have investigated the potential of using LLMs

for this task, exploring optimization techniques such

as zero-shot learning, few-shot learning, and ﬁne-

tuning (Taffa and Usbeck, 2023; Lehmann et al.,

2024). Despite the improvements of LLMs on the

task of QA over SKGs, LLMs face limitations when

handling KG-speciﬁc parsing due to their lack of di-

rect access to entities within the KGs and insufﬁ-

cient understanding of the ontological schema, partic-

Pan, X., de Boer, V. and van Ossenbruggen, J.

FIRESPARQL: A LLM-Based Framework for SPARQL Query Generation over Scholarly Knowledge Graphs.

DOI: 10.5220/0013774000004000

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 17th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2025) - Volume 1: KDIR, pages 123-134

123

ularly for low-resource SKGs like the Open Research

Knowledge Graph (ORKG)(Auer et al., 2023).

Insights from our pilot experiment revealed two

major categories of errors LLMs tend to make in

this task: (i) Structural inconsistencies, where gen-

erated SPARQL queries contain missing or redundant

triples, and (ii) Semantic inaccuracies, where queries

reference incorrect entities or properties, despite fol-

lowing the correct structural form. To address these

limitations, we propose FIRESPARQL, a LLM-based

modular framework for SPARQL query generation

over SKGs. At its core, FIRESPARQL supports FIne-

tuned LLMs adapted to the SKG domain and offers

relevant context provided via REtrieval-augmented

generation (RAG) and a lightweight SPARQL correc-

tion layer. These components are designed to improve

both the structural and semantic accuracy of the gen-

erated queries.

We investigate the effectiveness of this framework

using the SciQA Benchmark (Auer et al., 2023), com-

paring multiple conﬁgurations, including zero-shot,

one-shot, and ﬁne-tuned models with and without

RAG, against baselines and state-of-the-art methods.

We assess performance based on BLEU and ROUGE

scores for SPARQL query accuracy, and use a re-

laxed Exact Match metric to evaluate the execution

accuracy of the returned query results. Our ﬁndings

demonstrate that domain-speciﬁc ﬁne-tuning yields

the most consistent and robust performance, signiﬁ-

cantly enhancing both query accuracy and execution

result accuracy. Notably, the best-performance con-

ﬁguration is ﬁne-tuned LLaMA3-8B-Instruct with 15

training epochs, achieving 0.77, 0.91, 0.86, 0.90, and

0.85 on BLEU-4, ROUGE-1, ROUGE-2, ROUGE-

L, and RelaxedEM(all), respectively. However, our

experiments reveal that incorporating RAG into ei-

ther the zero-shot or ﬁne-tuned model does not yield

further improvements and can even degrade perfor-

mance.

The main contributions of this paper are three-

fold: (1) We identify and systematically categorize

the common error types in LLM-generated SPARQL

queries for QA over SKGs, distinguishing between

structural inconsistencies and semantic inaccuracies.

(2) We propose FIRESPARQL, a modular frame-

work for SPARQL query generation that integrates a

core ﬁne-tuned LLM with an optional RAG module

and a lightweight SPARQL correction layer. (3) We

conduct comprehensive experiments on the SciQA

Benchmark under multiple conﬁgurations, includ-

ing zero-shot, one-shot, ﬁne-tuning, and their RAG-

augmented variants, benchmarking against baselines

and state-of-the-art methods using different model

sizes and training epochs.

All resources and codes are available in our

GitHub repository

. For reproducibility, we

have released the best-performing ﬁne-tuned

model—LLaMA-3-8B-Instruct trained for 15

epochs—on Hugging Face.

2 RELATED WORK

2.1 Traditional Methods for QA over

KGs

Before the emergence of LLMs, QA over KGs is pri-

marily addressed through knowledge graph embed-

ding(KGE), neural network modeling, and reinforce-

ment learning (RL). These methods typically relied

on modeling the structure of the KG and carefully en-

gineered the features of the KG for entity linking, re-

lation prediction, and path ranking. KGE-based ap-

proaches transform entities and relations into low-

dimensional vector spaces to support efﬁcient reason-

ing. Huang et al. (Huang et al., 2019) propose the

KEQA framework for answering the most common

types of questions by jointly recovering the question’s

head entity, predicate, and tail entity representations

in the KG embedding spaces. Graph neural networks

(GNNs) have also been leveraged to reason over the

structure of KGs. Yasunaga et al. (Yasunaga et al.,

2021) introduce QA-GNN, leveraging joint reason-

ing, where the QA context and KG are connected to

form a joint graph and mutually update their represen-

tation through GNNs. Some studies emphasized RL

to navigate the KG and identify answer paths. Hai

et al. (Cui et al., 2023) propose AR2N, an inter-

pretable reasoning method based on adversarial RL

for multi-hop KGQA, to address the issue of spuri-

ous paths. AR2N consists of an answer generator and

a path discriminator, which could effectively distin-

guish whether the reasoning chain is correct or not.

2.2 QA over Generic KGs Such as

DBpedia and Wikidata

QA over generic Knowledge Graphs (KGs), such as

DBpedia and Wikidata, has been extensively stud-

ied and serves as the foundation for many advances

in the ﬁeld. Early systems primarily focused on se-

mantic parsing and graph-based reasoning (Berant

et al., 2013; Trivedi et al., 2017). More recently,

https://github.com/sherry-pan/FIRESPARQL.git

https://huggingface.co/Sherry791/Meta-Llama-3-8B-

Instruct-ft4sciqa

KDIR 2025 - 17th International Conference on Knowledge Discovery and Information Retrieval

124

attention has shifted to neural and LLM-based ap-

proaches. Bustamante and Takeda (Bustamante and

Takeda, 2024) explore the use of entity-aware pre-

trained GPT models for SPARQL generation, show-

ing notable improvements in handling KG-speciﬁc

structures. Similarly, Hovcevar and Kenda (Hovce-

var and Kenda, 2024) integrate LLMs with KGs in

industrial settings to support natural language inter-

faces. Meyer et al. (Meyer et al., 2024) assess the

SPARQL generation capabilities of various LLMs,

pointing out both strengths and limitations in terms of

structural correctness and execution accuracy. Other

studies such as Kakalis and Kefalidis (Kakalis and

Kefalidis, 2024) focus on domain-speciﬁc extensions,

like GeoSPARQL, and propose techniques for auto-

matic URI injection. All in all, these works contribute

a rich landscape of methods for mapping natural lan-

guage questions to structured SPARQL queries across

diverse knowledge bases.

2.3 SPARQL Generation for QA over

SKGs

QA over SKGs, such as the Open Research Knowl-

edge Graph (ORKG), has gained attention due to

its potential to support scientiﬁc exploration and

knowledge discovery. Unlike generic knowledge

graphs, SKGs capture ﬁne-grained scholarly infor-

mation, which introduces additional complexity in

terms of schema diversity and domain-speciﬁc termi-

nology. With the advent of LLMs, there has been

a surge of interest in applying these models on the

task of QA over SKGs. Lehmann et al. (Lehmann

et al., 2024) conduct a comprehensive evaluation on

the effectiveness of LLMs on the SciQA benchmark,

demonstrating the models’ strengths in generating ﬂu-

ent SPARQL queries but also noting common pitfalls

such as entity disambiguation and schema misalign-

ment. Taffa and Usbeck (Taffa and Usbeck, 2023)

speciﬁcally focus on adapting LLMs to the scholarly

setting, emphasizing the need for domain-speciﬁc

prompts and training data. Meanwhile, Pliukhin et

al. (Pliukhin et al., 2023) explore ﬁne-tuning strate-

gies that improve LLM performance in one-shot sce-

narios. These studies collectively suggest that while

LLMs offer promising capabilities, their effectiveness

in the scholarly domain hinges on adaptation through

ﬁne-tuning, prompt engineering, and schema-aware

correction mechanisms.

3 ERROR TYPE ANALYSIS ON

GENERATED SPARQL

QUERIES

Despite the improvements of LLMs on QA over

SKGs, LLMs face limitations when handling KG-

speciﬁc parsing. The experimental results conducted

by Sören Auer et al.(Auer et al., 2023) showed that

only 63 out of 100 handcrafted questions could be an-

swered by ChatGPT, of which only 14 answers were

correct. To better understand why LLMs fail to gen-

erate the correct SPARQL query to a NLQ, we con-

duct a pilot experiment on using ChatGPT(GPT-4)

with a random one-shot example to generate SPARQL

queries for 30 handcrafted questions in the SciQA

benchmark datasets.

Insights from this pilot experiment revealed two

major categories of errors LLMs tend to make in this

task: semantic inaccuracies and structural inconsis-

tencies. Semantic inaccuracies occur when LLMs fail

to link the correct properties and entities in ORKG,

despite generating SPARQL queries with the correct

structure. Our observations reveal that LLMs tend to

rely on the example provided in the one-shot learn-

ing process to generate the correct structure for a cer-

tain type of question, but often struggle with linking

the correct properties and entities because LLMs do

not learn the content of the underlying KG. Structural

inconsistencies arise due to LLMs’ lack of an onto-

logical schema of the underlying KG, leading to er-

rors in query structure, such as missing or abundant

links (triples), despite correctly linking to the men-

tioned entities or properties.

Figure 1 shows the example of the semantic inac-

curacies and structural inconsistencies problem with

the generated SPARQL queries in our pilot study.

In the example of the semantic inaccuracies prob-

lem, ChatGPT failed to link the correct property

orkgp:P15687; instead, it linked to a wrong property

orkgp:P7101. In the example of the structural incon-

sistencies problem, the SPARQL query generated by

ChatGPT directly links Contribution to Metrics and

fails to detect the correct schema of the ORKG where

Contribution and Metric are connected via Evalua-

tion.

4 METHODOLOGY

As we mentioned in Section 3, generating executable

and semantically accurate SPARQL queries over

SKGs using LLMs remains a challenging task due to

two main types of errors: semantic inaccuracies and

FIRESPARQL: A LLM-Based Framework for SPARQL Query Generation over Scholarly Knowledge Graphs

125

Figure 1: Examples of semantic inaccuracies and structural inconsistencies problem with the generated SPARQL queries.

structural inconsistencies. To address these issues,

we propose FIRESPARQL, a modular framework de-

signed to improve both the semantic accuracy and the

structural consistency of generated SPARQL queries.

The framework consists of three core components: (1)

Fine-tuned LLMs, (2) Retrieval-Augmented Genera-

tion (RAG), and (3) SPARQL correction. The ﬁnal

SPARQL queries are evaluated at both the query accu-

racy and execution result accuracy using ground truth

comparisons. An overview of the framework and the

evaluation setup is shown in Figure 2.

4.1 Fine-Tuning

At the core of FIRESPARQL is a ﬁne-tuning module

applying Low-Rank Adaptation (LoRA) (Hu et al.,

2021) for parameter-efﬁcient ﬁne-tuning. Unlike full-

parameter ﬁne-tuning, LoRA freezes the pre-trained

model weights and injects trainable low-rank decom-

position matrices into each layer of the Transformer

architecture. This approach signiﬁcantly reduces the

number of trainable parameters required for down-

stream tasks while maintaining strong performance.

Fine-tuning LLMs has proven effective in scientiﬁc

knowledge extraction (Muralidharan et al., 2024) and

KG construction (Ghanem and Cruz, 2024; Wang

et al., 2024a).

To address structural inconsistencies in generated

SPARQL queries, often arising from a limited under-

standing of the SKG schema, we ﬁne-tune LLMs so

that the ontology and structural patterns of the under-

lying SKG are implicitly captured during ﬁne-tuning.

The ﬁne-tuning data can include the ontology de-

scriptions, RDF triples, or task-speciﬁc labeled exam-

ples. In our implementation, we use NLQ-SPARQL

query pairs as training data, which implicitly en-

code the structure and vocabulary of the target SKG.

This results in a ﬁne-tuned LLM capable of generat-

ing syntactically correct and semantically meaningful

SPARQL queries directly from natural language ques-

tions.

We further investigate the impact of training

epochs on ﬁne-tuning performance. The number of

epochs determines how many times the model iterates

over the training data, directly inﬂuencing its ability

to capture domain-speciﬁc patterns. The prompt tem-

plate for SPARQL generation is shown in Listing 1.

Listing 1: Prompt template for SPARQL generation.

The Open R es ea rc h Kn ow le dg e Gra ph (

ORK G ) is a se ma n ti c k no w l e dg e

gr a ph d es i gn ed to re pre s ent ,

comp a re , an d r et r ie ve sc ho la r l y

co n t r ib ut io n s . G ive n a n at ura l

la ng ua ge q ue st i on in Eng li sh ,

you r t a sk is to g en er a te the

co r r e sp on di n g SP A RQ L q uer y to

thi s q ue st io n . The g en er a t e d

SP ARQ L q uer y s ho uld be abl e to

qu e ry the ORKG , ge tt ing co r re ct

an swe r to the in p ut q ue st i on .

Giv e me on l y the SP AR QL query , no

ot h er tex t .

In p ut q ue s ti on : {input question}

Ou tpu t S PA RQL q uer y :

4.2 RAG

RAG (Lewis et al., 2020) has been proposed to enable

LLMs access to external and domain-speciﬁc knowl-

edge for knowledge-intensive NLP tasks, which could

be a promising way to address the issue of semantic

inaccuracies, where generated SPARQL queries fail

to link to the correct properties or entities. These in-

accuracies often stem from the model’s limited expo-

KDIR 2025 - 17th International Conference on Knowledge Discovery and Information Retrieval

126

sure to SKGs or ambiguous entity/property mentions

in the input question. Therefore, we propose an op-

tional RAG module in the framework to enhance the

model’s contextual understanding of the underlying

SKGs. Given an NLQ, relevant context is retrieved

from the SKG in the form of candidate entities, prop-

erties, or subgraphs. A prompt template then incor-

porates this contextual information alongside the in-

put question, which is passed to the ﬁnetuned LLM

to generate a more semantically accurate SPARQL

query. In our implementation, we use RAG to re-

trieve candidate properties from a curated list of dis-

tinct ORKG properties, including their URLs and la-

bels. These candidates are then incorporated as con-

textual information in the prompt template to guide

SPARQL generation.

4.3 SPARQL Corrector

Despite improvements through ﬁne-tuning and RAG,

generated SPARQL queries may still contain minor

structural or syntactic errors that hinder successful ex-

ecution. These include unnecessary text in the out-

put, missing or extra punctuation, or subtle syntax is-

sues such as missing spaces between variable names.

To address this, we introduce a lightweight SPARQL

correction layer based on LLMs. This module takes

the initially generated query and its natural language

question as input and reﬁnes it to ensure syntactic va-

lidity, which increases the likelihood of generating ex-

ecutable SPARQL queries. The cleaned queries are

then passed to the evaluation stage. The prompt we

used to clean the input SPARQL query is shown in

Listing 2.

Listing 2: Prompt for SPARQL correction.

Gi v en a qu es ti on and i t s

co r r e sp on di n g SP A RQ L query ,

th e re mi ght be er ro r s in the

qu e ry suc h as m i ss in g s pa ces

be tw e en v ar ia bl e names ,

un ne c e s s a ry r epe t iti on , etc .

Pl eas e c lea n the S P AR QL a nd r etu rn

onl y the c le a ne d SP ARQ L ( no

ex pl a n a t i on ) :

qu es ti on : {Natural language question}

qu e ry : {Generated SPARQL query}

5 EXPERIMENTS

5.1 Datasets

We conduct experiments on the SciQA benchmark

dataset, a recently released resource designed to

evaluate question answering systems over scholarly

knowledge graphs (Auer et al., 2023). SciQA pro-

vides a diverse set of natural language questions

aligned with the Open Research Knowledge Graph

(ORKG). SciQA contains 100 handcrafted natural

language questions (HQs) with paraphrases, corre-

sponding SPARQL queries with their results. In ad-

dition, a set of 2465 questions (AQs) has been semi-

automatically derived from eight question templates.

The RDF data dump is also released on Zenodo

to-

gether with the benchmark.

We choose SciQA because the underlying KG

for this dataset, the ORKG, is built for representing

and querying the semantic content of research papers,

not just their metadata. Unlike DBLP, which mainly

provides bibliographic metadata such as citation and

authorship information, ORKG captures ﬁne-grained

scientiﬁc statements in a machine-readable format,

enabling fact-based, content-level question answer-

ing. ORKG goes beyond citation networks and au-

thorship details to represent ﬁne-grained scientiﬁc

claims, methodologies, comparisons, and ﬁndings.

This semantic depth enables fact-centric and content-

level QA, making SciQA a more suitable benchmark

for evaluating systems that aim to reason about scien-

tiﬁc knowledge.

5.2 Baselines and the State of the Art

As a baseline, we adopt a zero-shot setting in which

the model generates SPARQL queries without any

task-speciﬁc ﬁne-tuning or example guidance. This

setup evaluates the model’s out-of-the-box ability to

understand the task and map natural language ques-

tions to structured SPARQL queries. For the state-of-

the-art comparison, we implement the one-shot ap-

proach in which the model is provided with the most

semantically similar question from the training set,

along with its corresponding SPARQL query, as an

in-context demonstration. The most similar example

is identiﬁed by computing cosine similarity between

the input question and all training questions using

Sentence-BERT embeddings. To ﬁnd the most sim-

ilar question from the training set, Sentence-BERT

is better than vanilla BERT because it produces sen-

tence embeddings optimized for semantic similarity.

https://zenodo.org/records/7744048

FIRESPARQL: A LLM-Based Framework for SPARQL Query Generation over Scholarly Knowledge Graphs

127

NLQ

Prompt template

RAG

SKG

Candidate

properties and

entities

Fine-tuned LLM

NLQ-SPARQL

Pairs [1]

Ontology

Fine-tuning

SKG

LoRA

Final SPARQL

Retrieved

relevant

context

SPARQL Queries

LLM

SPARQL corrector

Vanilla LLM

Ground truth

SPARQL queries

Eval 1: SPARQL

generation performance

Evaluation

Answers to the

generated SPARQL

queries

SKG

Ground truth answers

Eval 2: SAPRQL Execution

performance

FIRESPARQL framework

Figure 2: FIRESPARQL framework (yellow boxes) and evaluation setup (grey boxes).

This conﬁguration has shown strong performance in

recent studies by helping the model better understand

the tasks (Lehmann et al., 2024; Liu et al., 2022).

5.3 Implementation

We ﬁne-tuned two instruction-tuned models, Llama

3.2-3B Instruct and Llama 3-8B Instruct, using 1,795

NLQ-SPARQL pairs from the SciQA training set.

The models were trained under various epoch conﬁg-

urations (3, 5, 7, 10, 15, and 20) to analyze perfor-

mance across training durations. All ﬁne-tuning ex-

periments were conducted on a single NVIDIA H100

GPU. We used DeepSeek-R1-Distill-Llama-70B as

the underlying model for the RAG component. All

SPARQL queries are executed over the ORKG data

dump released together with the benchmark on Zen-

odo using Qlever (Bast and Buchhold, 2017)

The execution times for ﬁne-tuning the two Llama

models across different numbers of epochs are sum-

marized in Table 3 in the Appendix.

5.4 Evaluation Metrics

We employ a combination of string-based and

execution-based evaluation metrics to assess the qual-

ity of the generated SPARQL queries. Similar to other

research, we use BLEU-4 and ROUGE scores, which

measure token-level and n-gram overlaps, to evalu-

ate the similarity between generated queries and the

ground-truth queries. These metrics provide insights

into how closely the structure and content of the gen-

erated queries align with the reference queries. Ad-

ditionally, we assess the execution performance of

the generated SPARQL queries using two variants of

Relaxed Exact Match (RelaxedEM): success and all.

The RelaxedEM(success) metric considers only those

queries that were syntactically valid, successfully ex-

ecuted against the ORKG RDF dump, and returned

non-empty results. In contrast, the RelaxedEM(all)

metric evaluates the correctness of the query results

across the entire test set, including queries that may

have failed or returned empty results.

Unlike the original Exact Match, which is very

strict, our Relaxed Exact Match incorporates several

preprocessing steps. First, we remove variable names

from the returned results to avoid penalizing differ-

KDIR 2025 - 17th International Conference on Knowledge Discovery and Information Retrieval

128

ences that do not affect semantics. Second, we split

the results line by line and eliminate duplicate lines

to normalize the output structure. Finally, we com-

pare the set of lines in the results using exact match-

ing. The metric RelaxedEM provides a more toler-

ant and realistic evaluation of query execution per-

formance in scholarly knowledge graph settings. The

above-mentioned dual evaluation approach allows us

to comprehensively analyze both the syntactic qual-

ity and the practical effectiveness of the generated

SPARQL queries.

5.5 Results

Table 1 shows the results of different metrics on

different strategies, different models, and different

epochs. Figure 3 shows the results of different metrics

with different epochs for LoRA ﬁne-tuning. All the

scores are the average scores of three runs. The stan-

dard deviation of BLEU-4, ROUGE scores, Relaxe-

dEM(success), and RelaxedEM(all) across different

model variants (e.g., zero-shot, one-shot, ﬁne-tuning,

and RAG) and training epochs is consistently low

(std < 0.0265), indicating stable performance across

all three runs. Therefore, we use the average scores

as a reliable and representative summary of model ef-

fectiveness. In the next section, we discuss the main

takeaways from these results.

6 DISCUSSION

In this section, we present the key experimental ﬁnd-

ings and outline the limitations and directions for fu-

ture work.

6.1 Discussion on the Results

Our experimental ﬁndings provide several key in-

sights into the effectiveness of the FIRESPARQL

framework and the performance of different strategies

for SPARQL query generation with different epoch

settings and different model sizes.

6.1.1 Fine-Tuning Performance

As shown in Table 1, ﬁne-tuning LLMs on

NLQ–SPARQL pairs leads to signiﬁcant improve-

ments over both the zero-shot baseline and the one-

shot state-of-the-art methods. The highest perfor-

mance is achieved by the ﬁne-tuned LLaMA-3-8B-

Instruct model trained for 15 epochs, attaining scores

of 0.77 (BLEU-4), 0.91 (ROUGE-1), 0.86 (ROUGE-

2), 0.90 (ROUGE-L), and 0.85 (RelaxedEM on all test

cases). These results indicate that, across both query-

level (BLEU, ROUGE) and execution-level (Relaxe-

dEM) evaluations, SPARQL queries generated by

ﬁnetuned models are not only more accurate but also

structurally well-formed and executable. This high-

lights the effectiveness of supervised adaptation for

learning the ontology and structure of the underlying

SKG during training.

6.1.2 Model Size Impact

As shown in Fig 3, LLaMA-3-8B-Instruct consis-

tently outperforms LLaMA-3.2-3B-Instruct after ﬁne-

tuning across all evaluation metrics. This demon-

strates that larger model capacity enhances the abil-

ity to internalize domain-speciﬁc patterns from train-

ing data, including the structure and semantics of the

target SKG. Interestingly, the trend reverses in the

one-shot setting: LLaMA-3.2-3B-Instruct performs

better than the 8B variant on most metrics, except

for RelaxedEM(success), as shown in Table 1. This

performance gap might be attributed to the fact that

LLaMA-3.2-3B-Instruct was released after LLaMA-

3-8B-Instruct and incorporates pruning and distilla-

tion techniques, which were speciﬁcally applied to the

1B and 3B variants (lla, ). These techniques help to

preserve performance while signiﬁcantly improving

efﬁciency, making the LLaMA-3.2-3B-Instruct model

capable of strong instruction-following performance

on resource-constrained devices. As a result, despite

its smaller size, LLaMA-3.2-3B-Instruct may beneﬁt

from a more reﬁned architecture and training strate-

gies, allowing it to better leverage in-context exam-

ples in one-shot settings compared to the larger, but

earlier, 8B model.

6.1.3 RAG Performance

As shown in Table 1, the score of RelaxedEM(all)

drops from 0.85 to 0.29 when incorporating RAG

into the ﬁne-tuned LLaMA-3-8B-Instruct trained for

15 epochs, which does not lead to additional perfor-

mance gains, and it even degrades the task perfor-

mance. This decline can be attributed to the noisy

or misaligned nature of the retrieved context, such

as incorrect or irrelevant property suggestions from

the ORKG, which may introduce confusion instead

of providing useful guidance since we don’t have a

context checker to validate whether the context is rel-

evant or not. Prior studies (Jin et al., 2024; Joren et al.,

2024) have similarly observed that low-quality RAG

context can conﬂict with the knowledge already en-

coded in ﬁne-tuned models, ultimately leading to re-

duced task performance.

FIRESPARQL: A LLM-Based Framework for SPARQL Query Generation over Scholarly Knowledge Graphs

129

Table 1: BLEU, ROUGE and RelaxedEM scores with different strategies, different models and different epochs.

Strategy Model Epoch BLEU-4 ROUGE-1 ROUGE-2 ROUGE-L

RelaxedEM

(success)

RelaxedEM

(all)

llama-3.2-3b-Instruct - 0.03 0.36 0.18 0.35 0.00 0.00

zero-shot (baseline)

llama-3-8b-Instruct - 0.03 0.39 0.18 0.38 0.00 0.00

llama-3.2-3b-Instruct - 0.03 0.36 0.18 0.36 0.00 0.00

zero-shot_rag

llama-3-8b-Instruct - 0.03 0.36 0.18 0.38 0.00 0.00

llama-3.2-3b-Instruct - 0.58 0.81 0.73 0.78 0.78 0.40

one-shot (SOTA)

llama-3-8b-Instruct - 0.38 0.61 0.50 0.59 0.89 0.29

llama-3.2-3b-Instruct-lora_

deepseekr1-distill-llama-70b

20 0.32 0.63 0.51 0.60 0.42 0.06

ft_rag

llama3-8b-Instruct-lora_

deepseekr1-disttill-llama-70b

15 0.58 0.81 0.72 0.77 0.85 0.29

3 0.67 0.86 0.79 0.83 0.88 0.53

5 0.62 0.83 0.75 0.79 0.71 0.36

7 0.52 0.77 0.67 0.73 0.79 0.27

10 0.56 0.79 0.70 0.76 0.70 0.22

15 0.60 0.81 0.73 0.78 0.88 0.40

llama-3.2-3b-Instruct-lora

20 0.70 0.86 0.79 0.84 0.80 0.54

3 0.75 0.90 0.84 0.88 0.99 0.79

5 0.74 0.90 0.85 0.87 0.98 0.73

7 0.70 0.87 0.80 0.84 0.96 0.69

10 0.71 0.88 0.81 0.85 0.94 0.69

15 0.77 0.91 0.86 0.90 0.98 0.85

llama-3-8b-Instruct-lora

20 0.74 0.89 0.84 0.88 0.99 0.82

Figure 3: Average BLEU-4, ROUGE-L and RelaxedEM scores with different epochs on different ﬁne-tuned models.

6.1.4 One-Shot Performance

As shown in Table 1, the one-shot setting, us-

ing the most similar example from the training set,

achieved strong performance, second only to the ﬁne-

tuned models. Speciﬁcally, the one-shot approach

reached scores of 0.58 (BLEU-4), 0.81 (ROUGE-

1), 0.73 (ROUGE-2), 0.78 (ROUGE-L), and 0.40

(RelaxedEM(all)) on LLaMA-3.2-3B-Instruct model.

Compared to the best-performing ﬁne-tuned model,

the one-shot approach achieved comparable perfor-

mance on query accuracy. However, in terms of

execution accuracy, it lagged behind, with a Re-

laxedEM(all) score of 0.40, substantially lower than

the 0.85 achieved by the ﬁne-tuned LLaMA-3-8B-

Instruct model. These results suggest that while ﬁne-

tuning remains essential for maximizing execution ac-

curacy, one-shot learning provides a simple yet effec-

tive alternative in scenarios where high-quality ﬁne-

tuning datasets are unavailable.

KDIR 2025 - 17th International Conference on Knowledge Discovery and Information Retrieval

130

6.1.5 SPARQL Corrector Performance

The integration of a SPARQL corrector layer sig-

niﬁcantly improved the syntactic validity and exe-

cution accuracy of queries generated by the ﬁne-

tuned LLaMA models. As illustrated by the ex-

amples provided in the Appendix, the raw out-

puts often contained structural and formatting errors,

such as missing whitespace between keywords (e.g.,

SELECT ?model?model_lbl). This issue leads to

syntax errors and failed executions when submitted to

the QLever endpoint. The corrector layer effectively

resolved these inconsistencies by standardizing spac-

ing, punctuation, and query structure—ensuring com-

pliance with SPARQL syntax. This post-processing

step is particularly valuable in handling complex

query patterns involving nested clauses and aggrega-

tion. Consequently, we observed a notable improve-

ment in the execution success rate and semantic align-

ment with the reference queries. These results un-

derscore the importance of incorporating lightweight

correction mechanisms alongside ﬁne-tuned models

for reliable SPARQL query construction.

6.1.6 Training Epoch Sensitivity

As shown in Figure 3, the number of ﬁne-tuning

epochs has a signiﬁcant impact on all metrics for both

LLaMA-3.2-3B-Instruct and LLaMA-3-8B-Instruct

models. First, both models start with high scores on

all metrics at epoch 3 and then slightly decline dur-

ing the early training phases (epochs 3–7), suggesting

that the models may require sufﬁcient training time to

properly internalize the SKG-speciﬁc structures and

semantics. Second, the training dynamics reveal an

upward trend in performance from 7 epochs onward,

with the best performance at 20 epochs for the 3B

model and 15 epochs for the 8B model. This indicates

that larger models tend to converge faster and exhibit

stronger generalization early on, while smaller mod-

els require more epochs to achieve competitive per-

formance.

6.1.7 Performance on HQs and AQs

The execution results in Table 2 reveal a clear

performance gap between handcrafted questions

(HQs) and auto-generated questions (AQs) on

query execution accuracy. For AQs, the best-

performing ﬁne-tuned model achieves very strong

performance, with 438 queries falling into the

success-execution_non-empty_exact-match_1

category, indicating successful execution, non-empty

results, and perfect alignment with the ground-truth

answers. In contrast, none of the HQs achieved this

Table 2: Query execution results on HQs and AQs across

three runs with the best-performed ﬁne-tuned model.

#HQ #AQ Total

test set 21 492 513

sucess-execution_non-empty_exact-match_1 0 438 438

sucess-execution_non-empty_exact-match_0 5.67 5.00 10.67

sucess-execution_empty 14.67 34.00 48.67

fail-execution-syntax-error 0.67 15.00 15.67

level of exact matching. Instead, most generated

queries for HQs either produced empty results despite

being syntactically valid (14.67 on average across

three runs) or only partially overlapped with the

ground-truth anwsers (5.67). A small number of the

generated queries for HQs (0.67) also failed due to

syntax errors. These ﬁndings suggest that while the

model generalizes effectively to the more uniform,

template-based structure of AQs, it faces signiﬁcant

challenges when dealing with the semantic richness

of HQs. In particular, the large proportion of empty

results for HQs highlights their susceptibility to

semantic inaccuracies: even when the generated

queries are structurally sound, the model often fails

to correctly identify or link the intended entities

and properties, resulting empty answers. This

reinforces the earlier observation by Sören Auer et

al.(Auer et al., 2023) that HQs pose a more realistic

and demanding test of model robustness, exposing

limitations that remain hidden when evaluating solely

on synthetic, template-driven data.

6.2 Error Analysis on Failed SPARQL

Queries

We further analyzed the generated SPARQL queries

that either failed to execute or returned empty results,

by comparing them with the corresponding ground

truth queries. Under the best-performing conﬁgu-

ration—using the ﬁne-tuned LLaMA3-8B-Instruct

model trained for 15 epochs—448 out of 513 gener-

ated SPARQL queries were executed successfully via

QLever without any syntax errors and returned mean-

ingful results. Meanwhile, 14 queries failed due to

syntax errors, and 51 queries were executed success-

fully but returned empty results.

To better understand the causes of failure, we ex-

amined the error messages for the 14 syntactically in-

valid queries and inspected the queries that returned

empty results. Our analysis revealed that 11 out of

the 14 syntactically invalid queries shared the same

error message:

Invalid SPARQL query: Variable ?metric

is selected but not aggregated. All

non-aggregated variables must be part

of the GROUP BY clause. Note: The

GROUP BY in this query is implicit

because an aggregate expression was

FIRESPARQL: A LLM-Based Framework for SPARQL Query Generation over Scholarly Knowledge Graphs

131

used in the SELECT clause.

This indicates that these queries included aggregate

functions (e.g., MAX(?value)) in the SELECT clause

but did not include the non-aggregated variables (e.g.,

?metric, ?metric_lbl) in a GROUP BY clause. In

SPARQL 1.1, such usage is invalid unless all non-

aggregated variables are explicitly grouped. This re-

ﬂects a lack of adherence to SPARQL’s syntax rules

around aggregation and grouping.

The remaining 3 queries failed with the following

error:

Invalid SPARQL query: Token ’SELECT’:

mismatched input ’SELECT’ expecting

’}’.

This indicates that the queries contained improperly

structured subqueries. Speciﬁcally, full SELECT state-

ments nested directly inside a WHERE clause without

being enclosed in curly braces ({}). SPARQL re-

quires subqueries to be syntactically isolated within

their own scope using curly braces. These errors

likely stem from incorrect handling of nested query

structures during generation.

These ﬁndings highlight the current limitations of

ﬁne-tuned LLMs in capturing the formal syntactic

constraints of the SPARQL query language, particu-

larly in scenarios involving nested subqueries and ag-

gregation functions. As a potential extension to our

approach, prompt engineering techniques that include

explicit syntax error examples or constraint reminders

could be incorporated during SPARQL generation to

encourage the model to produce syntactically valid

SPARQL, especially for complex constructs like ag-

gregation and subqueries.

6.3 Limitations and Future Work

While FIRESPARQL demonstrates strong perfor-

mance in generating SPARQL queries over the

ORKG, several limitations remain, which also high-

light directions for future research: Our current exper-

iments are limited to a single domain-speciﬁc bench-

mark, SciQA, which is built on top of the ORKG. To

assess the generalizability of our approach, it is cru-

cial to evaluate FIRESPARQL on a broader range of

benchmarks across different domains and knowledge

graphs. This would help determine whether the ob-

served improvements are transferable or highly task-

speciﬁc. Although our framework includes an op-

tional RAG module, its effectiveness is currently hin-

dered by the quality of the retrieved context. In many

cases, irrelevant or incorrect candidate properties are

introduced, leading to performance degradation. Fu-

ture work should focus on developing more accurate

and semantically aware retrieval mechanisms that can

provide high-quality, contextually relevant informa-

tion—such as topological subgraphs or query tem-

plates—without introducing noise. FIRESPARQL re-

lies on supervised ﬁne-tuning using NLQ–SPARQL

pairs, which may not always be available. In fu-

ture work, we aim to explore alternative data for ﬁne-

tuning LLMs such as synthetic training data or lever-

aging weak supervision from ontology or subgraphs.

7 CONCLUSION

In this paper, we introduced FIRESPARQL, a mod-

ular framework for SPARQL query generation over

SKGs. By systematically analyzing common error

types, structural inconsistencies, and semantic inac-

curacies, we designed a three-module architecture

comprising ﬁne-tuned LLMs for SPARQL genera-

tion, optional RAG for providing relevant context,

and a lightweight SPARQL correction layer. Our em-

pirical evaluation on the SciQA benchmark demon-

strates that domain-speciﬁc ﬁne-tuning, especially us-

ing LoRA for efﬁcient parameter updates, signiﬁ-

cantly improves both the syntactic quality and exe-

cution accuracy of generated SPARQL queries. No-

tably, our best-performing conﬁguration, based on

the LLaMA-3-8B-Instruct model ﬁne-tuned for 15

epochs, achieves state-of-the-art results across all

evaluation metrics, including BLEU, ROUGE, and re-

laxed exact match (RelaxedEM). While RAG does not

enhance performance in the presence of ﬁne-tuning,

this points to the importance of high-quality context

retrieval. Importantly, our results also reveal a sub-

stantial performance gap between auto-generated and

handcrafted questions, underscoring the difﬁculty of

adapting LLMs to the semantic complexity and vari-

ability for handcrafted questions. FIRESPARQL of-

fers a reproducible and conﬁgurable framework that

can be adapted based on resource availability, paving

the way for more robust, interpretable, and scalable

QA systems over SKGs.

REFERENCES

Llama 3.2: Revolutionizing edge ai and vision with open,

customizable models. https://ai.meta.com/blog/llama-

3-2-connect-2024-vision-edge-mobile-devices/. Ac-

cessed: 2025-05-26.

Auer, S., Barone, D. A. C., Bartz, C., Cortes, E., Jaradeh,

M. Y., Karras, O., Koubarakis, M., Mouromtsev, D. I.,

Pliukhin, D., Radyush, D., Shilin, I., Stocker, M., and

Tsalapati, E. (2023). The sciqa scientiﬁc question an-

swering benchmark for scholarly knowledge. Scien-

tiﬁc Reports, 13.

KDIR 2025 - 17th International Conference on Knowledge Discovery and Information Retrieval

132

Bast, H. and Buchhold, B. (2017). Qlever: A query engine

for efﬁcient sparql+ text search. In Proceedings of the

2017 ACM on Conference on Information and Knowl-

edge Management, pages 647–656.

Berant, J., Chou, A., Frostig, R., and Liang, P. (2013).

Semantic parsing on freebase from question-answer

pairs. In Proceedings of the 2013 conference on em-

pirical methods in natural language processing, pages

1533–1544.

Bustamante, D. and Takeda, H. (2024). Sparql generation

with entity pre-trained gpt for kg question answering.

arXiv preprint arXiv:2402.00969.

Cui, H., Peng, T., Han, R., Han, J., and Liu, L. (2023). Path-

based multi-hop reasoning over knowledge graph

for answering questions via adversarial reinforcement

learning. Knowledge-Based Systems, 276:110760.

Ghanem, H. and Cruz, C. (2024). Fine-Tuning vs. Prompt-

ing: Evaluating the Knowledge Graph Construction

with LLMs. In CEUR Workshop Proceedings, volume

3747 of TEXT2KG-DQMLKG-24 ( TEXT2KG 2024

and DQMLKG 2024 ) 3rd International workshop one

knowledge graph generation from text. Data Qual-

ity meets Machine Learning and Knowledge Graphs

2024, page 7, Hersonissos, Greece.

Hovcevar, D. and Kenda, K. (2024). Integrating Knowledge

Graphs and Large Language Models for Querying in

an Industrial Environment. PhD thesis, Bachelor’s

Thesis. University of Ljubljana, Faculty of Computer,

Information.

Hu, E. J., Shen, Y., Wallis, P., Allen-Zhu, Z., Li, Y., Wang,

S., Wang, L., and Chen, W. (2021). Lora: Low-rank

adaptation of large language models. arXiv preprint

arXiv:2106.09685.

Huang, X., Zhang, J., Li, D., and Li, P. (2019). Knowledge

graph embedding based question answering. In Pro-

ceedings of the twelfth ACM international conference

on web search and data mining, pages 105–113.

Jiang, L., Yan, X., and Usbeck, R. (2023). A struc-

ture and content prompt-based method for knowledge

graph question answering over scholarly data. In

QALD/SemREC@ ISWC.

Jin, B., Yoon, J., Han, J., and Arik, S. O. (2024). Long-

context llms meet rag: Overcoming challenges for

long inputs in rag. arXiv preprint arXiv:2410.05983.

Joren, H., Zhang, J., Ferng, C.-S., Juan, D.-C., Taly, A.,

and Rashtchian, C. (2024). Sufﬁcient context: A new

lens on retrieval augmented generation systems. arXiv

preprint arXiv:2411.06037.

Kakalis, E.-P. D. and Kefalidis, S.-A. (2024). Advancing

geosparql query generation on yago2geo: Leverag-

ing large language models and automated uri injection

from natural language questions.

Lehmann, J., Meloni, A., Motta, E., Osborne, F., Recu-

pero, D. R., Salatino, A. A., and Vahdati, S. (2024).

Large language models for scientiﬁc question answer-

ing: An extensive analysis of the sciqa benchmark.

In The Semantic Web: 21st International Conference,

ESWC 2024, Hersonissos, Crete, Greece, May 26–30,

2024, Proceedings, Part I, page 199–217. Springer-

Verlag.

Lewis, P., Perez, E., Piktus, A., Petroni, F., Karpukhin, V.,

Goyal, N., Küttler, H., Lewis, M., Yih, W.-t., Rock-

täschel, T., et al. (2020). Retrieval-augmented gen-

eration for knowledge-intensive nlp tasks. Advances

in neural information processing systems, 33:9459–

9474.

Liu, J., Shen, D., Zhang, Y., Dolan, W. B., Carin, L., and

Chen, W. (2022). What makes good in-context ex-

amples for gpt-3? In Proceedings of Deep Learn-

ing Inside Out (DeeLIO 2022): The 3rd Workshop

on Knowledge Extraction and Integration for Deep

Learning Architectures, pages 100–114.

Meyer, L.-P., Frey, J., Brei, F., and Arndt, N. (2024). As-

sessing sparql capabilities of large language models.

arXiv preprint arXiv:2409.05925.

Muralidharan, B., Beadles, H., Marzban, R., and Muppa-

raju, K. S. (2024). Knowledge ai: Fine-tuning nlp

models for facilitating scientiﬁc knowledge extraction

and understanding.

Omar, R., Mangukiya, O., Kalnis, P., and Mansour, E.

(2023). Chatgpt versus traditional question answer-

ing for knowledge graphs: Current status and future

directions towards knowledge graph chatbots. arXiv

preprint arXiv:2302.06466.

Perevalov, A., Diefenbach, D., Usbeck, R., and Both, A.

(2022). Qald-9-plus: A multilingual dataset for ques-

tion answering over dbpedia and wikidata translated

by native speakers. In 2022 IEEE 16th International

Conference on Semantic Computing (ICSC), pages

229–234. IEEE.

Pliukhin, D., Radyush, D., Kovriguina, L., and Mouromt-

sev, D. (2023). Improving subgraph extraction algori-

htms for one-shot sparql query generation with large

language models. In QALD/SemREC@ ISWC.

Taffa, T. A. and Usbeck, R. (2023). Leveraging llms in

scholarly knowledge graph question answering. In

QALD/SemREC@ ISWC.

Trivedi, P., Maheshwari, G., Dubey, M., and Lehmann, J.

(2017). Lc-quad: A corpus for complex question

answering over knowledge graphs. In The Semantic

Web–ISWC 2017: 16th International Semantic Web

Conference, Vienna, Austria, October 21-25, 2017,

Proceedings, Part II 16, pages 210–218. Springer.

Wang, J., Chang, Y., Li, Z., An, N., Ma, Q., Hei, L., Luo,

H., Lu, Y., and Ren, F. (2024a). Techgpt-2.0: A large

language model project to solve the task of knowledge

graph construction.

Wang, Y., Lipka, N., Rossi, R. A., Siu, A., Zhang, R., and

Derr, T. (2024b). Knowledge graph prompting for

multi-document question answering. In Proceedings

of the AAAI Conference on Artiﬁcial Intelligence, vol-

ume 38, pages 19206–19214.

Yasunaga, M., Ren, H., Bosselut, A., Liang, P., and

Leskovec, J. (2021). Qa-gnn: Reasoning with lan-

guage models and knowledge graphs for question an-

swering. arXiv preprint arXiv:2104.06378.

FIRESPARQL: A LLM-Based Framework for SPARQL Query Generation over Scholarly Knowledge Graphs

133

APPENDIX

Table 3: Epoch-wise ﬁne-tuning runtime of llama models

using a single NVIDIA H100 GPU.

model epochs running time(hh:mm:ss)

lama-3.2-3b-Instruct

3 00:09:18

5 00:14:49

7 00:23:33

10 00:32:42

15 00:37:41

20 00:57:45

lama-3-8b-Instruct

3 00:10:46

5 00:16:53

7 00:26:35

10 00:38:04

15 00:55:21

20 01:14:11

Listing 3: The example of generated SPARQL query before

the SPARQL corrector.

SE LEC T ? mo del ? mo d el _ lbl

WH E RE {

? d at as et a

or k gc :

Da ta s et ;

rdf s : la bel

da ta s et _

lbl .

FI LTE R ( str (? d at ase t _ lbl ) = "

FTD da ta s et ")

? be nc hm ar k or k gp : HAS _

DA TA S ET ? d at ase t ;

or k gp : HAS _

EV AL UA TI ON

? e val .

? p ape r or k gp : HAS _

BE NC HM AR K ? b en ch ma r k .

OP TI ON AL {? p ape r ork gp :

HAS _ M O DEL ? m ode l .

? m ode l rdfs :

la b el

mo d el _ lbl .}

} <| e o t _ id | >

Listing 4: The example of generated SPARQL query after

the SPARQL corrector.

SE LEC T ? m o del ? mo del _ l b l

WH E RE {

? d at as et a ork gc : D at as et ;

rdf s : la bel ? da ta set _ lbl .

FI LTE R ( str (? d at ase t _ lbl ) = " FTD

da ta s et ")

? be nc hm ar k o rkg p : HAS _ D AT A SE T ?

da ta s et ;

or k gp : HAS _ EV AL UA TI ON ?

eva l .

? p ape r o rkg p : H AS _ B E NC HM AR K ?

be nc hm ar k .

OP TI ON AL {

? p ape r o rkg p : H AS _ MOD EL ? m ode l .

? m ode l r d fs : l a bel ? mo del _ l b l .

}

KDIR 2025 - 17th International Conference on Knowledge Discovery and Information Retrieval

134
