Design and Implementation of a Real-Time Web Infrastructure for

Student Monitoring: A Kafka-Based Plugin for Moodle

Rima Kilany Chamoun

, Wadad Wazen

and Mario Gharib

Saint-Jospeh University, Faculty of Engineering, Beirut, Lebanon

Saint-Jospeh University, CINIA, Beirut, Lebanon

Keywords: Learning Management Systems, Moodle, Apache Kafka, Real-Time Streaming, Event-Driven Architecture,

Educational Analytics, Web Infrastructure.

Abstract: Modern Learning Management Systems (LMS) require increasingly responsive and scalable infrastructures

to support real-time learning analytics. This paper presents the design and implementation of robust technical

architecture that integrates Moodle, an open-source LMS, with Apache Kafka, a distributed streaming

platform, to enable real-time student performance monitoring. The proposed solution captures high-velocity

event data from Moodle (e.g., assignment submissions, quiz attempts, forum activity) and routes it through

dynamically generated Kafka topics into a scalable pipeline, where it is processed in real time and stored in

MongoDB for downstream analysis. This infrastructure supports immediate visualization of engagement data,

threshold-triggered alerts, and seamless extensibility toward predictive analytics using Kafka Streams and

machine learning models. The system demonstrates how architectural innovations in event-driven web

applications can be applied to education, enabling data-driven interventions and advancing the capabilities of

LMS platforms beyond traditional batch-based reporting.

1 INTRODUCTION

1.1 Background and Motivation

The evolution of Learning Management Systems

(LMS) has significantly transformed digital

education, but many platforms still rely on batch-

based data processing models. Such models delay

insight generation and hinder timely responses to

students’ evolving needs. The growing demand for

responsive, web-scale educational systems highlights

the need for infrastructure capable of supporting real-

time data collection, processing, and visualization.

Event-driven architectures and stream-processing

pipelines—standard in modern web applications—

are underutilized in educational platforms.

1.2 Objective and Scope of the Study

This paper presents a technical infrastructure that

integrates Moodle (Moodle, n.d.) with Apache Kafka

to enable real-time educational data streaming.

Designed to address performance, scalability, and

https://orcid.org/0000-0002-5710-6901

extensibility challenges common in LMS

environments, the system applies architectural

patterns from modern web infrastructure—such as

decoupled messaging, real-time stream processing,

and scalable storage—to enhance the responsiveness

and effectiveness of educational platforms. The goal

is to transform Moodle from a traditional, batch-

oriented LMS into a dynamic platform for real-time

analytics that empowers educators with timely,

actionable insights.

At the core of the system, Moodle serves as the

primary source of educational data, generating events

based on student activities such as logins, quiz

submissions, and assignment completions. These

events are captured and streamed into a real-time data

pipeline, where they are categorized for further

processing and analysis. This design enables timely

monitoring of student engagement and supports

flexible analytic strategies, including both real-time

and batch-based insights.

To ensure optimal throughput and fault tolerance,

Kafka topic configurations—such as the number of

partitions and replication factors—are tuned based on

Chamoun, R. K., Wazen, W. and Gharib, M.

Design and Implementation of a Real-Time Web Infrastructure for Student Monitoring: A Kafka-Based Plugin for Moodle.

DOI: 10.5220/0013753200003985

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 21st International Conference on Web Information Systems and Technologies (WEBIST 2025), pages 205-212

ISBN: 978-989-758-772-6; ISSN: 2184-3252

205

the nature and frequency of events. General

guidelines suggest assigning more partitions to high-

frequency events (e.g., attendance or quiz

submissions) to enable parallel consumption and

faster processing, while lower-frequency or high-

impact events (e.g., late assignments or failed

quizzes) can benefit from increased replication for

reliability.

After processing, the data are stored in MongoDB

and visualized using external analytics tools.

Although both Grafana and Kibana offer robust

visualization capabilities, Grafana was selected due to

its native support for MongoDB via official and

community plugins, its flexibility in building real-

time educational dashboards, and its ease of

integration without requiring data migration to

Elasticsearch. This setup enables dynamic

dashboards and in-depth analysis of student activity.

The system also implements role-based access

controls, providing tailored analytics views for

instructors and managers, as detailed in Section 4.4.

This integration facilitates timely tracking of

engagement and performance metrics, supports

threshold-based alerts for proactive intervention, and

lays the foundation for future integration with

predictive machine learning models.

This study explores the end-to-end

communication architecture, demonstrating how real-

time data can be captured, processed, stored, and

visualized in a seamless, modular pipeline. By

combining Kafka’s distributed streaming capabilities

with Moodle’s LMS environment, the infrastructure

enables timely educational interventions and

contributes to the development of more personalized

and engaging learning experiences. Ultimately, this

work aims to provide a replicable model for real-time

learning analytics that supports improved student

outcomes across diverse educational contexts.

2 LITERATURE REVIEW

Extensive research has been conducted on the

integration of Learning Management Systems (LMS)

like Moodle with various data processing

technologies to enhance the monitoring and

assessment of student performance. Recent studies

emphasize the benefits of integrating Moodle LMS

with real-time data streaming platforms like Apache

Kafka to enhance student engagement. One proposed

architecture uses Apache Flume to capture student

activity logs in real time, which are then transmitted

via Kafka and processed using Apache Spark for

immediate analysis and responsive feedback

mechanisms (Chaffai, 2023). This setup enables

institutions to monitor engagement patterns and

intervene when students show signs of

disengagement. In addition to technical integration,

Moodle’s native collaborative features—such as

discussion forums and group assignments—have

been shown to increase student participation and

satisfaction, particularly in STEM education contexts

(Gamage et al., 2022), (Martin et al., 2021).

Furthermore, the use of Moodle’s learning analytics

tools allows educators to track learner progress,

detect at-risk students, and tailor interventions

accordingly (Martin et al., 2021). Recent

developments also explore the incorporation of

artificial intelligence within Moodle to personalize

learning. For instance, an AI-powered system has

been developed that uses Natural Language

Processing (NLP) to send personalized feedback and

support messages based on student behavior and

performance data (Aammou et al., 2024).

Collectively, these approaches highlight how the

synergy of real-time analytics, collaborative tools,

and AI-driven personalization within Moodle

ecosystems can significantly enhance learner

engagement and educational outcomes. On the other

hand, traditional educational methods, which often

rely on periodic assessments, do not sufficiently

capture the continuous progress or struggles of

students. By incorporating real-time data processing

systems such as Apache Kafka, these systems can

provide more dynamic and responsive educational

experiences. This approach allows for the ongoing

assessment of student engagement and

understanding, facilitating immediate academic

support where necessary. The literature reveals a

significant trend towards leveraging technology to

transform educational environments, making them

more adaptable and attuned to the needs of both

students and educators.

2.1 What are the Key Benefits of

Integrating Apache Kafka with

Moodle?

Integrating Apache Kafka with a Learning

Management System (LMS) like Moodle can

significantly enhance real-time monitoring and data

analysis in educational institutions. Kafka's robust

event streaming capabilities allow for reliable, high-

volume data exchange, which is crucial for

processing educational logs and analytics in real time

(Theofanis, Raptis, Cicconetti, & Passarella, 2024).

By optimizing Kafka's configuration, such as the

number of partitions and brokers, institutions can

WEBIST 2025 - 21st International Conference on Web Information Systems and Technologies

206

tailor the system to meet specific application

requirements, improving performance and resource

utilization (Theofanis, Raptis, Cicconetti, &

Passarella, 2024)(Han, Shang, & Wolter, 2020).

Moreover, local analytics tools, such as the JavaScript

library developed for Moodle, enable institutions to

analyze educational logs without transferring

sensitive data to third parties, thus addressing privacy

concerns (Amo, Cea, Jimenez, Gomez, & Fonseca,

2021). This local-first approach not only mitigates

risks associated with data exposure but also facilitates

the use of advanced analytics techniques, such as

clustering and visualization, to monitor student

engagement and identify at-risk students effectively

(Sáiz-Manzanares, Rodríguez-Díez, Díez-Pastor,

Rodríguez-Arribas, Marticorena-Sánchez, & Ji,

2021). Overall, the integration of Kafka with Moodle

fosters a more responsive and secure educational

environment, enhancing both data-driven decision-

making and student support.

2.2 How Does Apache Kafka Enhance

Real-Time Monitoring

Real-time analytics are pivotal in modern educational

systems, providing a framework through which data

can be utilized immediately as it is generated. The

role of these analytics is to enable educators to make

informed decisions swiftly, which is crucial for

intervening effectively in students' academic paths.

This process involves the continuous monitoring of

data points like assignment submissions, quiz

performances, and overall engagement levels within

an LMS. The integration of real-time analytics into

educational practices not only supports personalized

learning paths but also fosters an educational

environment that can adapt to the pace and style of

each student. By facilitating a more granular view of

student performance, real-time analytics help

educational institutions to maximize their resources

and enhance educational outcomes. Apache Kafka

offers several benefits for real-time monitoring and

data analysis in education-based Learning

Management Systems (LMS) like Moodle. Firstly,

Kafka's distributed and fault-tolerant architecture

ensures high reliability and scalability, which is

crucial for handling the large volumes of data

generated by user interactions in an LMS (Theofanis,

Raptis, Cicconetti, & Passarella, 2024)(Santos,

2023). This capability allows for efficient data

streaming and processing, enabling timely insights

into student engagement and performance. Moreover,

Kafka facilitates seamless integration with various

applications, enhancing the ability to analyze data in

real time and make informed decisions quickly

(Sanjana, Sinchana, Prabhu, & Sandhya, 2023). Its

support for high-throughput message processing

ensures that data can be collected and analyzed

without significant delays, which is essential for

maintaining an effective learning environment (Zhou,

Zhou, & Chen, 2024). Additionally, Kafka's ability to

trigger alerts based on specific conditions can help

educators respond promptly to student needs, thereby

improving overall educational outcomes (Santos,

2023). Overall, the implementation of Apache Kafka

in an LMS like Moodle can significantly enhance

operational efficiency and decision-making

processes.

2.3 How Does Apache Kafka Enhance

Scalability in Moodle LMS?

Implementing Apache Kafka's event-driven

architecture (EDA) can significantly enhance the

scalability and reliability of a Moodle-based Learning

Management System (LMS) for real-time monitoring

and data analysis in educational institutions. Research

indicates that EDA improves performance and

scalability in microservices by facilitating

asynchronous communication, which can lead to a

19.18% increase in response time and a 34.40%

reduction in error rates compared to traditional API-

driven architectures (Alam, Nugraha, Rohmat, &

Darmawan, 2022). Furthermore, Kafka's ability to

handle high-volume data streams with low latency

makes it suitable for real-time applications, as

demonstrated in a cloud-based architecture that

processed up to 8000 messages per second reliably

(Khriji, Benbelgacem, Cheour, El Houssaini, &

Kanoun, 2021). Additionally, optimizing database

performance through distributed systems has shown

substantial improvements in Moodle's efficiency,

with performance gains of up to 384% in course read

operations (Johan, Prakasa, Hanani, Rohman, &

Utama, 2024). Thus, integrating Kafka with Moodle

can address performance bottlenecks and enhance the

system's capacity to manage concurrent users

effectively, ensuring a robust educational

environment.

2.4 What Role Does Event-Driven

Architecture Play in Modern LMS

Infrastructures?

Event-driven architecture (EDA) has become a

pivotal model for designing scalable, responsive

Learning Management Systems (LMS) by enabling

asynchronous, decoupled processing of student-

Design and Implementation of a Real-Time Web Infrastructure for Student Monitoring: A Kafka-Based Plugin for Moodle

207

generated events such as quiz submissions, logins, or

forum activity. In contrast to monolithic or polling-

based designs, EDA allows system components to

operate independently, processing high-throughput

data streams in real time without introducing

performance bottlenecks (Kiran, 2021).

In LMS environments like Moodle, EDA

improves scalability during peak usage (e.g., exams

or course registration) and supports responsiveness

through asynchronous event handling (Kommera,

2020). Its modular design also facilitates integration

with modern technologies—including real-time data

pipelines and machine learning—without disrupting

existing services (Malviya, Mandala, Lekkala, &

Reddy, 2025). Frameworks based on platforms such

as Apache Kafka and Flink add fault tolerance and

allow real-time analytics and alerts (Kiran, 2021),

(Kommera, 2020).

While EDA introduces complexity in event

orchestration and consistency management, these

challenges are outweighed by its adaptability, fault

resilience, and support for personalized interventions.

Our proposed architecture builds on these principles,

implementing a Kafka-based event streaming system

tailored to the evolving needs of scalable, analytics-

driven LMS infrastructures.

3 PROPOSED FRAMEWORK

3.1 Overview of the Proposed System

The proposed system is designed to harness the robust

capabilities of Apache Kafka integrated with Moodle

to facilitate a real-time student performance

monitoring framework. This system transforms the

traditional reactive educational model into a

proactive, data-driven approach. By leveraging

Kafka's efficient data ingestion and processing

capabilities alongside Moodle's widespread

educational platform, the system can provide

immediate insights into student performance and

engagement. This integration allows for the

continuous evaluation of students' activities and

academic progress, enabling educators to intervene

promptly and effectively.

3.2 Real-Time Data Pipeline: From

Kafka Ingestion to MongoDB

Storage

In our SMART plugin architecture, Apache Kafka

serves as the backbone for ingesting real-time

educational events from Moodle, such as quiz

submissions and forum posts, using the PHP-rdkafka

client (GitHub, n.d.). These events are categorized

into course-specific Kafka topics for modular

processing and fault-tolerant distribution. Once

captured, the events are stored in MongoDB, chosen

for its document-oriented structure that aligns with

Moodle’s hierarchical data. MongoDB enables fine-

grained querying and longitudinal tracking by storing

metadata like timestamps, user IDs, and activity

types. This integration supports both real-time

responsiveness and historical analysis, empowering

educators with timely insights and facilitating role-

based access to dashboards via tools like Grafana.

3.3 The Potential Integration of Kafka

Streams in the System

The current system uses Apache Kafka to collect real-

time student data, which is stored in MongoDB.

Integrating Kafka Streams would enable advanced,

real-time analytics directly on the data streams before

storage. This includes operations like windowed

aggregations, stream joins, and real-time scoring.

Such enhancements would allow the system to

generate immediate insights—including detailed

engagement trends, participation levels, and early

warning signs for at-risk students (see Figure 1). The

enriched data would then be stored in MongoDB for

deeper analysis, supporting timely and informed

educational interventions.

Figure 1: UML Component diagram of our SMART Plugin

integrating Moodle with Apache Kafka and MongoDB for

real-time data processing.

WEBIST 2025 - 21st International Conference on Web Information Systems and Technologies

208

4 IMPLEMENTATION

In this section we will detail the implementation of

the proposed architecture, as shown in the UML

deployment diagram in Figure 2. The resources used

were as follows:

- Moodle: Our smart plugin is being developed

with the latest stable version of Moodle (4.3.2+).

- Apache Kafka: Kafka cluster that includes the

Kafka Streams API (Kafka version 3.6.1).

- MongoDB: The latest stable release of MongoDB

for data storage (7.0).

- MongoDB Java Driver: Library for interacting

with MongoDB from the Kafka Streams

application

- MongoDB PHP Library for reading data from

MongoDB.

- Java Standard Library, which includes the

java.util.regex.Pattern package. This package

allows the application to subscribe to topics based

on a certain pattern, including those

corresponding to courses that have not yet been

created with their specific topics.

- Rdkafka library: php library for

producing/consuming messages.

- Security Protocols: Software to manage secure

communications, like SSL/TLS for HTTPS

connections.

- Programming Languages and Frameworks: PHP

(version 8.1) for Moodle plugin development,

Java for Kafka Streams, and any other languages

necessary for custom development.

Figure 2: UML Deployment Diagram of the Moodle-Kafka

Architecture.

4.1 Data Ingestion from Moodle

Data ingestion is handled by custom event handlers

within the SMART plugin, defined in observer.php

and registered via Moodle’s Events API. These

handlers respond to key student activities—such as

quiz submissions, forum posts, attendance logging,

and assignment uploads—by extracting relevant

metadata (e.g., user ID, course ID, timestamps) using

$event->get_data(), parsing the payload via

parse_event_data(), and serializing the result into

JSON using json_encode(). The structured message is

then streamed to Apache Kafka using the php-rdkafka

client (GitHub, n.d.). Each event is routed to a

designated Kafka Topic based on its type (e.g.,

quiz_submissions, forum_posts, assignments_

submitted). When a new course is created, the plugin

initializes corresponding topics (e.g., quizzes,

absences) to prepare for incoming events. For time-

sensitive activities like quizzes and assignments,

Moodle’s task manager schedules ad hoc checks for

non-submissions post-deadline.

Performance tuning identified that using three

Kafka partitions with a replication factor of two

ensured optimal throughput and low latency for high-

volume topics like quiz failures and attendance, while

single-partition topics sufficed for lower-frequency

events like late assignment tracking. These settings

were validated through simulated testing with up to

200 concurrent Moodle users during peak activity.

To ensure compliance with educational data

regulations, the system incorporates anonymization

protocols and adheres to GDPR and FERPA

standards (European Union, 2016), safeguarding

student privacy while supporting real-time

monitoring.

4.2 Data Storage with MongoDB

After real-time processing (or directly from the Kafka

producer in the current implementation), the data is

ingested into MongoDB, which serves as the central

repository for storing all processed student data. Each

document represents an event or processed data point,

including fields like student ID, activity type,

timestamp, and relevant metrics. Collections are

organized by activity type (e.g., quiz_results,

forum_interactions) to align with Kafka topics.

Indexes on key fields optimize query performance for

generating reports and alerts. MongoDB is deployed

as a replica set with configurations prioritizing

availability and partition tolerance—using

writeConcern: {w: "majority", j: true, wtimeout:

5000}, readPreference: "secondaryPreferred", and

readConcern: "available". This setup ensures

responsive dashboards while accepting eventual

consistency for non-critical analytics. For critical

operations, stronger consistency is enforced using

readConcern: "majority" and readPreference:

"primary", balancing performance with data integrity

(MongoDB Inc., 2024).

Design and Implementation of a Real-Time Web Infrastructure for Student Monitoring: A Kafka-Based Plugin for Moodle

209

4.3 Implementation of Event Handlers

and a Kafka Producer Within the

Moodle Plugin

The core of the real-time data ingestion process lies

in the custom Moodle plugin, which integrates event

handlers and a Kafka producer using PHP-rdkafka.

Each event handler is designed to listen to specific

Moodle events, using the Moodle Events API

(Moodle Docs, n.d.), such as when a student submits

an assignment, completes a quiz, or posts in a forum.

Upon capturing an event, the handler extracts relevant

information (e.g., student ID, activity details,

timestamps) and formats it into a JSON message.

This message is then passed to the Kafka

producer, which is configured to connect to the Kafka

cluster. The producer serializes the JSON message

using the librdkafka library, ensuring that the data is

compact and efficiently transmitted over the network.

The message is then published to the appropriate

Kafka topic, where it becomes available for real-time

processing or direct storage in MongoDB.

The plugin’s architecture is designed to handle

high throughput, ensuring that even during peak

usage times, all student interactions are captured and

processed without delay. This is achieved through

careful optimization of the event handlers and the

Kafka producer’s configuration, including tuning

parameters such as batch sizes, linger time, and

compression settings to balance performance and

resource utilization.

Figure 3: UML Sequence Diagram of the Moodle-Kafka

Architecture.

4.4 User Interaction

The system provides educators with role-based, user-

friendly interfaces for real-time access to student

performance data. Instructors interact with

customized Moodle dashboards enhanced by the

SMART plugin, which retrieves course-specific

data—such as attendance, quiz scores, and

participation—from MongoDB. These dashboards

support configurable alerts, allowing educators to

define threshold-based triggers for significant events,

such as missed assignments or low engagement.

Figure 4 shows the SMART plugin interface used to

set monitoring parameters and alert conditions

tailored to specific course contexts.

At the institutional level, managers access broader

analytics via Grafana dashboards, which visualize

aggregated data across multiple courses and

departments. Data flow from Moodle’s event system

through Apache Kafka to MongoDB is illustrated in

Figure 3, showcasing the real-time pipeline

architecture. The reporting interface combines data

from Moodle (student names, identifiers) and

MongoDB (engagement metrics), presenting it in

sortable HTML tables for intuitive exploration. This

dual-interface design ensures that both instructors and

administrators have timely access to actionable

insights, aligned with their respective roles and

responsibilities.

Figure 4: SMART Plugin Configuration panel.

5 RESULTS AND DISCUSSION

The proposed system demonstrates robust real-time

monitoring capabilities by integrating Apache Kafka

and MongoDB to capture, process, and visualize

student engagement data as it occurs. In a simulated

deployment reflecting a university with 1,200

students and approximately 3,600 hourly interactions,

the SMART plugin streamed events via php-rdkafka

to Kafka and stored them in MongoDB. The Kafka

cluster—configured with 3 partitions and a

replication factor of 2—maintained stable throughput

with average end-to-end latency below 80

milliseconds and no data loss, validating its suitability

for small-to-medium-scale institutions and its

scalability in line with Kafka’s capacity to handle tens

of thousands of events per second (Theofanis, Raptis,

Cicconetti, & Passarella, 2024)(Han, Shang, &

Wolter, 2020). The system facilitates timely

pedagogical interventions by alerting instructors

when students fall behind, and its real-time

dashboards—illustrated in Table 1—enable

WEBIST 2025 - 21st International Conference on Web Information Systems and Technologies

210

personalized learning by presenting metrics such as

missed assignments, absences, and quiz failures.

These analytics empower educators to provide

tailored support based on student-specific activity

patterns, thereby enhancing engagement and

improving learning outcomes. Moreover, the

infrastructure supports institutional decision-making

through the continuous analysis of performance

trends, informing curriculum adjustments, resource

allocation, and the design of targeted academic

programs. Technical integration challenges—such as

configuring Kafka for reliable message streaming,

designing scalable MongoDB schemas, and resolving

compatibility between Moodle (PHP) and Kafka

(Java)—were mitigated through Docker-based

containerization and fine-tuned Kafka connector

settings. While the system is fully functional in

controlled test environments, future work will involve

benchmarking its performance with live student

cohorts at institutional scale.

Table 1: Sample Monitoring Output Report from Moodle.

ID Name

Total

Assignme

nts Misse

Total

Quizzes

Misse

Total

Abse

nces

Total

Quizzes

Fails

10 John Doe 8 2 8 0

11 Jane Roe 1 0 1 0

6 CONCLUSIONS AND FUTURE

WORK

The SMART plugin shows how integrating Apache

Kafka with Moodle enables real-time monitoring and

improved student performance assessment within

LMS environments. This scalable and responsive

infrastructure facilitates timely educational

interventions and supports personalized learning.

Additionally, the modular framework is designed for

extensibility, paving the way for future integration of

tools like Kafka Streams and predictive machine

learning models.

The following table compares our smart Moodle-

Kafka plugin to native Moodle reporting tools.

Table 2: Moodle Kafka Plugin features vs Native Moodle

Reporting.

Feature

Moodle Native

Reports

SMART Kafka Plugin

Real-Time Monitoring

✗ ✔

Dynamic Event Topic

Creation

✗ ✔

Stream Processing Pipeline

✗ ✔ (Kafka-compatible)

Custom Threshold-Based

Alerts

✗

✔

Extensible for Future ML

Models

✗

✔

Scalable with High User

Volume

Limited

✔

(Kafka partitioned topics)

Immediate Intervention

Support

✗

✔

6.1 Implications and Contributions

This work tackles the broader challenge of integrating

real-time analytics into Learning Management

Systems (LMS) to support timely, data-driven

educational interventions. It demonstrates how

technologies like Apache Kafka and MongoDB can

be adapted to educational contexts through modular,

event-driven architectures. Key contributions

include:

A scalable infrastructure connecting Moodle

with Kafka for real-time ingestion, dynamic topic

management, and low-latency streaming, with future

support for Kafka Streams and machine learning.

The SMART plugin, which extends Moodle with

real-time dashboards and alerting features, enabling

educators to respond proactively to live student data.

A roadmap for predictive modeling, using

historical and streaming data to identify academic

risks and support personalized learning.

A bridge between educational practice and

scalable web infrastructure, showing how modern

data engineering can be embedded into open-source

LMS platforms with minimal disruption.

Beyond the technical proof-of-concept, the

architecture is generalizable to other platforms,

promoting broader adoption of responsive, analytics-

driven instruction. Future empirical studies will

assess the impact of real-time alerts and predictive

models on learning outcomes across diverse

academic settings.

6.2 Future Work

Future work will include empirical evaluation of the

system’s usability and its effect on educational

outcomes, focusing on how real-time feedback

influences both student engagement and instructor

decision-making. The next development phase

involves integrating Kafka Streams and machine

learning to transition from monitoring to predictive

analytics. Historical data from MongoDB will be

used for training models, with features engineered to

capture student behavior patterns. Algorithms such as

decision trees and neural networks will be applied to

predict dropout risk and academic performance.

These models will be embedded into the Kafka

Streams pipeline for real-time inference, generating

alerts for at-risk students. The system will support

Design and Implementation of a Real-Time Web Infrastructure for Student Monitoring: A Kafka-Based Plugin for Moodle

211

continuous learning through periodic model

retraining. Predictions and alerts will be stored in

MongoDB and visualized through real-time

dashboards in Moodle.

ACKNOWLEDGEMENTS

The authors would like to thank Karim Issa and Omar

Metlej for their major contribution to the project. The

authors also acknowledge the use of OpenAI

ChatGPT, for assistance with summarizing content

and refining the language during the preparation of

this paper.

REFERENCES

Aammou et al., “Smart agent-based educational system

using NLP for personalized feedback in Moodle LMS,”

*Br. J. Educ. Technol. Syst.*, vol. 12, no. 1, 2024.

[Online]. Available: https://www.brajets.com/index

.php/brajets/article/view/1723

Alam, R., F. Nugraha, G. Rohmat, and I. Darmawan,

“Event-driven architecture to improve performance and

scalability in microservices-based systems,” in *Proc.

IEEE ICADEIS*, 2022, doi: 10.1109/ICADEIS

56544.2022.10037390.

Amo, D., S. Cea, N. M. Jimenez, P. Gomez, and D.

Fonseca, “A privacy-oriented local web learning

analytics JavaScript library with a configurable schema

to analyze any edtech log: Moodle’s case study,”

Sustainability, vol.13, no.9, 2021, doi:10.3390/su1309

5085.

Chaffai, A.; “Real-time analysis of students’ activities on

an e-learning platform based on Apache Spark,”

*Academia.edu*, 2023. [Online]. Available:

https://www.academia.edu/109325203

European Union, “Regulation (EU) 2016/679 (General

Data Protection Regulation),” *Off. J. Eur. Union*,

2016. [Online]. Available: https://eur-lex.europa.eu/

legal-content/EN/TXT/?uri=celex:32016R0679

Gamage et al., “The impact of Moodle LMS integration on

group discussions to support collaborative learning,”

*ResearchGate*, 2022. [Online]. Available: https://

www.researchgate.net/publication/382848020

GitHub, “php-rdkafka.” [Online]. Available: https://github.

com/arnaud-lb/php-rdkafka

Han, W., Z. Shang, and K. Wolter, “Learning to reliably

deliver streaming data with Apache Kafka,” in *Proc.

IEEE/IFIP DSN*, 2020, doi:10.1109/DSN48063.2020.

00068.

Johan, E., W. Prakasa, A. Hanani, F. Rohman, and S. N.

Utama, “Improving Moodle performance using

HAProxy and MariaDB Galera Cluster,” *Appl. Inf.

Syst. Manag*, vol. 7, no. 1, 2024, doi: 10.15408/

aism.v7i1.34871.

Khriji, S., Y. Benbelgacem, R. Cheour, D. El Houssaini,

and O. Kanoun, “Design and implementation of a

cloud-based event-driven architecture for real-time data

processing in wireless sensor networks,” *J. Super

comput*, 2021, doi: 10.1007/s11227-021-03955-6.

Kiran, V. N. S., “Event-Driven architecture: Building res-

ponsive and scalable systems,” *Int. J. Sci. Res.*, vol.

10, no. 7, 2021, doi: 10.21275/sr24716231109.

Kommera, A. R., “The power of event-driven architecture:

Enabling real-time systems and scalable solutions,”

*Turk. J. Comput. Math. Educ.*, vol. 11, no. 1, 2020,

doi: 10.61841/turcomat.v11i1.14928.

Malviya, R. K., V. Mandala, S. Lekkala, and M. S. Reddy,

“Event-riven integration in multi-cloud and hybrid

architectures: Ensuring data consistency and

performance,” *SSRN*, 2025, doi:10.2139/ssrn.508

0809.

Martin et al., T. K. “Learning analytics in STEM education:

The role of Moodle tools for monitoring engagement,”

*Int. J. STEM Educ.*, vol. 8, no. 12, 2021. [Online].

Available: https://link.springer.com/article/10.1186/

s40 594-021-00323-x

Moodle, “Moodle Learning Platform.” [Online]. Available:

https://docs.moodle.org/

Moodle Docs, “Events API.” [Online]. Available:

https://docs.moodle.org/dev/Events_API

MongoDB Inc., “Read and Write Concerns,” MongoDB

Manual, 2024. [Online]. Available: https://www.

mongodb.com/docs/manual/core/replica-set-read-write

-concerns

Sáiz-Manzanares, M. C., J. J. Rodríguez-Díez, J. F. Díez-

Pastor, S. Rodríguez-Arribas, R. Marticorena-Sánchez,

and Y. P. Ji, “Monitoring of student learning in learning

management systems: An application of educational

data mining techniques,” *Appl. Sci.*, 2021, doi:

10.3390/app11062677.

Sanjana, N., R. Sinchana, V. Prabhu, and S. Sandhya,

“Real-time event streaming for financial enterprise

systems with Kafka,” in *Proc. IEEE AsianCon*, 2023,

doi: 10.1109/ASIANCON58793.2023.10270532.

Santos, J. L., “Streamlining enterprise data processing,

reporting and real-time alerting using Apache Kafka,”

in *Proc. IEEE ISDFS*, 2023, doi: 10.1109

/ISDFS58141.2023.10131800.

Theofanis, P., C. Raptis, C. Cicconetti, and A. Passarella,

“Efficient topic partitioning of Apache Kafka for high-

reliability real-time data streaming applications,”

*Future Gener. Comput. Syst.*, 2024, doi:

10.1016/j.future.2023.12.028.

Zhou, Z., L. Zhou, and Z. Chen, “A distributed real-time

monitoring scheme for air pressure stream data based

on Kafka,” *Appl. Sci.*, vol. 14, no. 12, 2024, doi:

10.3390/app14124967.

WEBIST 2025 - 21st International Conference on Web Information Systems and Technologies

212
