Exploring the Application Boundaries of Lightweight Multimodal

Models

Rui Wang

Faculty Information Science & Technology, Universiti Kebangsaan Malaysia, Bangi, Selangor, Malaysia

Keywords: Lightweight Model, Boundary, Artificial Intelligence.

Abstract: With the rapid development of Multimodal Large Language Models (MLLMs), models have shown

unprecedented potential in graph comprehension and generation tasks. However, current research mostly

focuses on the performance breakthroughs of giga-parameter-level models, and lacks systematic exploration

of the capability boundaries of lightweight models (with parameters less than or equal to 3B) in real-world

application scenarios. This paper systematically explores the performance boundaries of the lightweight

MLLM in different application scenarios based on the Bunny-v1_0-2B-zh open source model. By designing

a multi-dimensional evaluation framework covering core capabilities such as text comprehension, visual

reasoning, and revealing the practical application potential of the 2 billion parametric scale model.

Experiments show that the model can achieve excellent performance in resource-constrained scenarios such

as mobile device deployment, but has shortcomings in complex logical reasoning and specialized domain

knowledge. This study provides empirical evidence for the selection of applicable scenarios and optimization

direction of the lightweight model.

1 INTRODUCTION

As multimodal large language models (MLLMs)

show breakthrough performance in tasks such as text

generation and visual reasoning, their high

computational cost and deployment threshold limit

practical application scenarios. Lightweight models

provide new possibilities for resource-constrained

scenarios such as edge computing and mobile AI

through architectural optimization and knowledge

distillation techniques, which dramatically reduce the

computational requirements while maintaining the

basic capabilities (Brown et al., 2020). This study is

conducted based on the Bunny-v1_0-2B-zh model,

which was developed by the Beijing Academy of

Artificial Intelligence (BAAI), and is a lightweight

model for Chinese natural language processing tasks

(He et al., 2024), which is very suitable for

lightweight modeling research.

Existing research focuses on the model

compression technology itself, and lacks systematic

exploration of the capability boundaries of

lightweight models, which often leads to the problem

of “model selection mismatch” in practical

https://orcid.org/0009-0000-9013-0586

applications. Currently, lightweight MLLM research

is mainly promoted along two paths: based on

architectural streamlining methods, such as Meta's

LLaMA-7B, which reduces computational

complexity through the sparse attention mechanism

(Yuan et al., 2025), and achieves 83% of the

performance of a 13B model in English unimodal

tasks (Touvron et al., 2023); based on the multi-

modal adaptation method, Google's MobileViT will

be visualized to be a lightweight transformer, which

is a lightweight model with the ability of the

Transformer. Transformer lightweight and then

interfaces it with language models to achieve real-

time inference on mobile with an 8% decrease in

ImageNet accuracy (Mehta & Rastegari, 2022).

However, there are significant limitations in the

existing work, for example, most models are only

designed for unimodal or bilingual environments and

lack specialized optimization for Chinese multimodal

scenarios (Liu et al., 2023). The evaluation system is

biased towards traditional accuracy metrics and

Ignores the need for joint optimization of memory,

latency, and energy consumption in real-world

deployments (Chen et al., 2023).

476

Wang, R.

Exploring the Application Boundaries of Lightweight Multimodal Models.

DOI: 10.5220/0013699600004670

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 2nd International Conference on Data Science and Engineering (ICDSE 2025), pages 476-480

ISBN: 978-989-758-765-8

This study aims to explore the application

boundaries of the lightweight model, and focuses on

the performance exploration when the model is

actually deployed. By designing gradient complexity

test tasks (Zhang et al., 2024), the performance

degradation pattern of the model in core tasks such as

text comprehension and visual reasoning is

systematically quantified, At the same time, the time

spent on each output is collected to visualize the

model performance.

Through this study, it can provide a reference for

the optimization of lightweight models and the

deployment of actual scenarios, which is of practical

value for promoting the landing of edge intelligence.

2 RESEARCH OBJECTIVES

This study needs to evaluate the overall performance

of the lightweight multimodal language model

Bunny-v1.0-2B-zh, focusing on its performance in

text generation and image understanding tasks.

Through experiments, the applicability and capability

of the model in different tasks and scenarios are

explored to provide a clear direction for subsequent

optimization. Meanwhile, this study hopes to verify

whether the lightweight model can achieve more

accurate multimodal understanding and generation

while maintaining efficient computational

performance.

Specific tasks include: comprehensively

evaluating the model performance and clarifying the

difference between the model performance under

standard tasks and extreme scenarios. Then, identify

bottlenecks and deficiencies, and identify

shortcomings in the current model design by

exploring the limitations under different parameters

and task conditions. Quantitative and qualitative

analyses are conducted through a series of

experiments to analyze model performance across

multiple tasks, including consistency, accuracy, and

variety of text generation, as well as precision and

semantic consistency of image understanding. Key

parameters affecting the quality of the model output,

such as generation length and repetition penalties, are

also identified. Finally, an application potential

exploration is conducted to validate the model's

ability to operate in practice in low-resource

computing devices. Its adaptability in multimodal

combinatorial tasks is tested and its application

scenarios in real-world deployments are explored.

3 EXPERIMENTAL

3.1 Experimental Objectives

To test the generation quality of the model for

different lengths of text output. To investigate the

effect of the repetition penalty mechanism on the

generated content. Evaluate the model's ability to

understand image content and combine it with text

generation. Test the model's performance in a specific

domain. To test the model's ability to handle non-

canonical inputs such as spelling errors, incomplete

inputs.

3.2 Introduction to the Model

This experiment uses Bunny-v1.0-2B-zh, a model

based on the bunny architecture built with the SigLIP

visual coder and the Qwen1.5-1.8B language

backbone, which accepts high-resolution images up

to 1152x1152. The compression of large-scale

datasets into high-quality core sets through data

condensation (Wu et al., 2024) techniques plays a key

role in model lightweight.

3.3 Experimental Design

3.3.1 Experiment Prep

The experiment uses Graphics Processing Unit

(GPU) to run the model, in order to reflect the

advantages of the lightweight model, and to simulate

the more demanding model deployment scenarios, the

mobile GPU RTX 4080 Laptop is used in this

experiment.

The image input uses the example_2 provided by

BAAI as the input image for most of the experiments,

which avoids errors caused by unclear images and

blind zones in model understanding. Meanwhile, the

use of officially provided images facilitates research

and comparison by other researchers. The images are

shown in Figure 1.

Exploring the Application Boundaries of Lightweight Multimodal Models

477

Figure 1: Official image example_2. (Beijing Zhiyuan

Artificial Intelligence Research Institute, 2024)

For BERT scoring in later experiments, a manual

text description of the image is needed, which is

described as follows: “A black and white cat poses

with wide-open eyes and wide-open mouth, revealing

a shocked look, with a yellow ‘HUH?’ in the middle

of the image, a humorous Internet emoticon, the cat

sits in the corner of a painted wall, and the wall in the

lower left of the image has peeling, revealing a gray

interior.”

In order to test the effect of different parameters

on the model-generated content, the input text “Please

describe the content of this image and reply in

Chinese” was fixed, and then the length restriction

experiment and the repetition penalty parameter

experiment were conducted respectively.

3.3.2 Text Length Limitation Experiment

The text length limitation parameter is increased from

10 to 500, 10 words are added each time, and each

output and output time are recorded. The data with

large differences and reference values are selected,

and finally the relevance score and accuracy score are

calculated.

Below is the formula for relevance score:

S=

a+0.5b

×4+



c×0.2





The element a is the number of element hits, b is

the number of partial descriptions, T is the total

number of elements, and c is the coherence

coefficient.

Number of element hits: the number of elements

that exactly match the standard answer (maximum 5),

Total number of elements: fixed to 5 (black and white

fur color / HUH text / cat / emoji attributes / spatial

relations), Coherence factor: paragraph articulation

score based on BERT-score (0-5).

Accuracy scoring formula:

A=5−w







⋅e







wi: error type weight (subject error w1=3.0,

fictional element w2=1.0, attribute contradiction

w3=0.5). ei: number of occurrences of the

corresponding error type. Base score: 5 points, with a

minimum of 0 points after deductions.

3.3.3 Repeat Penalty Experiment

The penalty parameter is increased from 0.5 to 2.5 by

0.1 each time, other operations are the same as the text

length limitation experiment, and finally the

repetition rate, content accuracy and semantic fluency

are calculated.

Repetition rate formula:

R =

r - a

T- a





r: repetition count, a: allowed repetitions, T: total

token number.

The accuracy score formula is the same as the text

length limitation experiment.

Fluency scoring formula:

𝐹=BERTScore×5





3.4 Analysis of Experimental Results

By filtering and scoring, the table of text length

limitation experiment and the table of repetition

penalty experiment were drawn.

Table 1: Text Length Limit Experimental Data.

Word limit Relevance score (1-5) Accuracy score (0-5) Time

10 words 1.2 2.0 2m 34.9s

30 words 1.2 2.0 2m 33.7s

89 words 1.2 2.0 2m 33.5s

90 words 3.8 5.0 2m 34.5s

120 words 4.1 4.5 3m 13.1s

200 words 4.3 4.0 3m 30.3s

500 words 4.0 4.0 3m 32.4s

Unlimite

4.5 3.5 3m 24.2s

ICDSE 2025 - The International Conference on Data Science and Engineering

478

As shown in Table 1, the outputs under the limit

of 10 to 89 words are exactly the same and of poor

quality, which may be the drawback brought by the

forced restriction of the number of text output by the

model. After the length limit reaches 90, the output

quality returns to normal, and the output quality

gradually decreases when the length limit continues

to be increased. The reason for this phenomenon is

that the model deliberately matches the text length

limit, and too short a text limit leads to insufficient

generation steps to complete multiple rounds of

reasoning; too long a text limit leads to fictitious

elements in the model, which are prone to produce

erroneous details.

Compare the unrestricted output with the model's

default parameters. Its output is strongly correlated

with the image, but the accuracy is slightly worse

compared to the output with the restricted over-length

parameter, which is exactly the opposite when the

parameter is 90. In summary, the best performance

parameter is 120, below 90 is not recommended, from

90 to unlimited each has its own advantages, can be

adjusted according to the actual situation.

Table 2: Repeat Penalty Experiment Data.

Penalty coefficient

Repetition rate

(0-1)

Accuracy score

(0-5)

Semantic fluency (1-5) Time

1.0 0.62 3.5 2.4 1m 53.3s

1.2 0.24 4.0 3.9 2m 24.2s

1.5 0.18 3.0 3.2 2m 35.6s

1.7 0.15 2.0 3.0 2m 42.3s

2.0 0.15 2.0 3.0 3m 7.6s

2.5 0.15 2.0 3.0 2m 41.2s

After the experiment, the model of the repetition

penalty parameter is lower than 1.0 repeat output

meaningless content, from 1.0 normal output content,

parameter 1.2 to reach the best performance,

parameter 1.5 when the performance of the decline,

the repetition is reduced; parameter 1.7 when the

performance continues to decline, the repetition

continues to decline, the output is unchanged after the

output is greater than 1.7, it is an invalid modification.

By observing Table 2, it is concluded that the

model's repetition penalty boundary is from 1.0 to 1.7,

and the comprehensive performance is best at 1.2,

which is suitable as the default parameter; when it is

greater than 1.2, the model's content becomes

dispersed in order to avoid repetition, and the

accuracy of the description of the picture decreases,

but its creativity is richer, and it is suitable for dealing

with the creative task, therefore, the repetition penalty

parameter is recommended to be set between 1.2 and

1.5 .

3.5 Advanced Experiment

3.5.1 Special Domain Adaptation

Experiment

Following the optimal parameters derived from the

first two experiments, a special domain adaptation

experiment can be done. In this paper, take the

medical field as an example, input an X-ray chest

photo. The photo is shown in Figure 2.

Figure 2: X-ray Chest Picture. (Youlai Doctor, 2024)

Ask the question “Does this patient have steel

nails in his chest, reply in Chinese. ” Under the

repetition penalty parameter 1.2, the model

recognizes a steel nail in the patient's chest and adds

that it may be a tool for fixing the chest wall during

treatment or surgery; under parameter 1.5, the

previous output remains unchanged, but the sentence

“X-ray shows L-1023” is fictionalized at the end.

If the model is not prompted, but is simply asked, “

Do you know what is wrong with this patient?”, the

model assumes that the patient has small nodules and

masses in the lungs.

Exploring the Application Boundaries of Lightweight Multimodal Models

479

This experiment illustrates a number of points.

One is that the repetition penalty parameter 1.5 would

fudge the content and is not suited to the rigors of the

medical field; the other is that the model's image

parsing is so powerful that it is able to identify foreign

objects in the chest cavity on monochrome X-rays,

even though it requires some prompting to

identifythem as steel nails, which only shows that the

model has not been trained in the medical field. What

is certain is that lightweight models have unlimited

potential for future deployment in various domains.

In fact, a researcher has already trained a lightweight

model for the gaming domain, called

VideoGameBunny (VGB), based on the Bunny

model architecture, using game screenshots as a

training set, and its performance is also excellent

(Taesiri & Bezemer, 2024).

3.5.2 Abnormal Input Robustness

This final experiment challenges the model's Chinese

language processing capabilities, with anomalous

input consisting of missing key prepositions,

homophone substitutions, mixing of non-literal

symbols, mixing of Chinese and English, and

extremely long single sentences without punctuation.

The model is able to handle most of the abnormal

inputs correctly, but only outputs English when

English is used to request Chinese responses. When

the model is not prompted to reply in Chinese, the

model is likely to reply in English, which indicates

that although the model has been optimized for

Chinese, English is still a higher priority.

4 CONCLUSIONS

Based on BAAI's Bunny-v1_0-2B-zh model, this

paper explores the application boundaries of this

lightweight model through stepwise parameter

tuning. This experiment has been designed in a

targeted way, without using public datasets for large-

scale testing, and the experimental data may have

some errors; the experiments in this paper are only

tested using the Bunny-v1_0-2B-zh model, which

cannot represent other lightweight models, and the

experimental results are for reference only. As a

model with only 2 billion parameters, the Bunny-

v1_0-2B-zh model is smaller than general lightweight

models, but it shows amazing performance. It not

only outputs results in an average of 2 minutes and 30

seconds on mobile devices, but is also able to show

image recognition capabilities that are not inferior to

those of larger models, which gives it application

potential in a wide range of domains , and bodes very

well for the development of lightweight models. This

paper provides a reference for the optimization and

deployment of lightweight models in the future, and

contributes to the promotion of lightweight

development of AI.

REFERENCES

Beijing Zhiyuan Artificial Intelligence Research Institute.

2024. Bunny-v1_0-2B-zh. Retrieved April 1, 2025,

from https://huggingface.co/BAAI/Bunny-v1_0-2B-

zh/tree/main/images

Brown, T. B., Mann, B., Ryder, N., et al. 2020. Language

models are few-shot learners. Advances in Neural

Information Processing Systems, 33, 1877–1901.

Chen, W., Li, M., Zhou, Y., et al. 2023. EcoMLM: A

holistic efficiency evaluation framework for

lightweight multimodal models. In Proceedings of the

2023 ACM International Conference on Mobile

Systems, Applications, and Services (MobiSys) (pp. 1–

15).

He, M., Liu, Y., Wu, B., et al. 2024. Efficient multimodal

learning from data-centric perspective. arXiv preprint

arXiv:2402.11530.

Liu, Y., Chen, Z., Wang, Y., et al. 2023. CPM-M3:

Multilingual multimodal pre-training with curriculum

learning. In Proceedings of the 61st Annual Meeting of

the Association for Computational Linguistics (ACL)

(pp. 10234–10248).

Mehta, S., & Rastegari, M. 2022. MobileViT: Light-weight,

general-purpose, and mobile-friendly vision

transformer. In Proceedings of the 10th International

Conference on Learning Representations (ICLR).

Taesiri, M. R., & Bezemer, C.-P. 2024. VideoGameBunny:

Towards vision assistants for video games. arXiv

preprint arXiv:2407.15295.

Touvron, H., Lavril, T., Izacard, G., et al. 2023. LLaMA:

Open and efficient foundation language models. arXiv

preprint arXiv:2302.13971.

Wu, X., Zhang, B., Deng, Z., et al. 2024. Vision-language

dataset distillation. arXiv preprint

arXiv:2308.07545v4.

Yuan, J., Gao, H., Dai, D., et al. 2025. Native sparse

attention: Hardware-aligned and natively trainable

sparse attention. arXiv preprint arXiv:2502.11089v2.

Youlai Doctor. 2024. Sternum fracture (33). Retrieved

April 1, 2025, from

https://www.youlai.cn/dise/imagedetail/343_72859.ht

Zhang, Y., Liu, Z., Wang, X., et al. 2024. Gradient

complexity profiling: A systematic approach to

lightweight model capability boundary analysis. IEEE

Transactions on Pattern Analysis and Machine

Intelligence, 46(3), 1452–1467.

ICDSE 2025 - The International Conference on Data Science and Engineering

480
