A Review of Methods for Estimating Depth Based on Various

Application Scenarios

Siqi Huang

Engineering College , Shantou University, Shantou, China

Keywords: Depth Estimation, 2D Image, Stereo Image, SPIdepth, HiMODE.

Abstract: In computer vision, depth estimation is a crucial task. The task is to measure the distance between each pixel

and the camera. The accuracy and efficiency of estimation tasks have undergone a significant improvement

due to the rise of deep learning. There are many distinct application situations for depth estimation, and the

task can be broadly classified into two categories: stereo image depth estimation and 2D image depth

estimation, depending on the needs of each scenario. In this paper, HR-Depth, HybridDepth, SPIdepth in 2D

image depth estimation methods and UniFuse, NLFB, PanoFormer, OmniFusion, HiMODE in stereo image

depth estimation methods are introduced and analysed. In addition, NYU-Depth V2, KITTI in 2D image

dataset and Stanford3D, and Matterport3D in stereo image dataset are introduced in detail, and the

effectiveness of these two kinds of approaches is examined and contrasted using the widely used evaluation

indices. It is found that HybridDepth and SPIdepth perform well in 2D image depth estimation, and NLFB

and HiMODE perform better in stereo image depth estimation. Future research in depth estimation may focus

more on depth estimation studies of stereo images, because stereo images usually contain richer depth

information, which can allow for higher accuracy in depth estimation.

1 INTRODUCTION

Depth estimate becomes a crucial element as

computer vision advances from basic image

identification to intricate scene comprehension.

Using a mapping relationship from 2D picture cues to

3D depth, the objective is to extract depth cues from

the image and calculate each pixel's distance from the

camera. In order to achieve applications in different

scenes, image datasets of different scene types such

as NYU-Depth, KITTI, Stanford3D, Matterport3D,

etc., have been constructed, which have driven the

research on depth estimation. As a result, depth

estimation has found extensive use in fields like

autonomous driving, robotics, VR, AR, 3D

reconstruction, and security monitoring.

As the application scenarios become wider and

wider, the depth estimation task is gradually divided

into two different types: 2D image depth estimation

and stereo image depth estimation. Using 2D images

without direct depth information, 2D image depth

estimation seeks to determine how to create a

mapping relationship between 2D image cues and 3D

https://orcid.org/0009-0009-1920-1180

depth in order to estimate each pixel's distance from

the camera; Whereas stereo image depth estimation is

the study of how to extract effective depth cues from

images containing 360-degree scene information in

the presence of aberrations or distortions, etc., in

order to obtain depth information.

Focusing on the above two different types of

depth estimation research, this paper analyses and

summarises their research progress and current status,

collects different types of research data, and classifies

and analyses them. Finally, it provides an outlook on

the research development and application of depth

estimation.

2 METHOD

2.1 Depth Estimation Methods For 2D

Images

The Eigen team was the first to use CNN for 2D

image depth estimation in 2014, and since then,

204

Huang, S.

A Review of Methods for Estimating Depth Based on Various Application Scenarios.

DOI: 10.5220/0013681100004670

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 2nd International Conference on Data Science and Engineering (ICDSE 2025), pages 204-211

ISBN: 978-989-758-765-8

numerous researchers have improved it in various

ways based on this. Meanwhile, unsupervised deep

learning methods have emerged, such as training the

network by generating new viewpoint maps or using

left and right views and video information to solve the

depth estimation problem. Supervised means that

there is a high dependence on training data with

accurate depth labels, whereas unsupervised means

that there is no need for depth-labelled data.

2020, HR - Depth was presented in a study by

Xiaoyang Lyu et al. This approach, which focuses on

optimizing the depth estimation effect through two

methodologies, is an enhanced deep network for

high-resolution self-supervised monocular depth

estimation. On the one hand, the jump connection in

DepthNet is redesigned to add intermediate nodes to

the original encoder and decoder nodes to aggregate

features, so that the decoder can obtain high-

resolution features with richer semantic information

and thus predict the depth map boundary more

accurately; on the other hand, the feature fusion

squeeze excitation (fSE) module is proposed, which

efficiently fuses features through global average

pooling, fully-connected layers and 1×1 convolution

to efficiently fuse features and improve network

performance while reducing the number of

parameters. In addition, a lightweight network Lite -

HR - Depth based on MobileNetV3 was constructed

and knowledge distillation techniques were applied to

further improve its accuracy. The benefits of this

approach are substantial： when using Resnet-18 as

the encoder, HR-Depth performs better than any prior

state-of-the-art techniques with the fewest parameters

at both high and low resolutions; Lite - HR - Depth

contains only 3.1M parameters, yet achieves

comparable or even better performance than

Monodepth2 at high resolution; by redesigning the

jump connections and introducing the fSE module,

the accuracy of depth estimation in large gradient

region is effectively improved, and sharper edges can

be predicted; the high-resolution depth estimation is

deeply analysed, which provides theoretical basis and

practical references for subsequent studies.（Lyu、

Liu、Wang，2020）

In 2024, HybridDepth was presented in a study by

Ashkan Ganj et al. The method aims to address the

problems of scale ambiguity, hardware heterogeneity

and generalisability in depth estimation by fusing

focused stack information and single-image prior for

robust metric depth estimation. The process logic is

as follows: first, the relative depth map and the metric

depth map are generated using the single-image

relative depth estimator and the DFF metric depth

estimator, respectively; then, the relative depth map

is converted into a global-scale depth map by global

scale and displacement alignment, and a dense scale

map is constructed; finally, the global-scale depth

map is corrected using a deep-learning-based

refinement layer combined with a scale map and an

uncertainty map from the DFF module. depth map

with pixel-level scale correction to obtain the final

depth map. This method has significant advantages,

surpassing existing methods on several datasets, such

as on the DDFF12 and NYU Depth V2 datasets, with

significant improvement in metrics such as RMSE

compared to specific SOTA models; strong zero-

sample generalisation capability, with excellent

performance on the ARKitScenes and Mobile Depth

datasets; a compact model structure, with an

inference The model is compact, with inference time

of only 20ms and size of 240MB, which is more

suitable for mobile device deployment than other

models while ensuring accuracy; it effectively solves

the scale ambiguity problem of single-image depth

estimation, and the depth estimation is more accurate

and consistent under different scaling levels. （Ganj

、Su、Guo，2024）

In 2024, Mykola Lavreniuk Research introduced

SPIdepth for self-supervised monocular depth

estimation. The primary flow logic of this technique,

which aims to increase depth estimate accuracy by

fortifying the pose network, is as follows: Use

DepthNet to extract visual characteristics from a

single RGB image, then use the encoder-decoder

framework and the previously trained ConvNext to

generate the depth map; In order to align the depth

map and the reference image during view

compositing, PoseNet is utilized to estimate the

relative poses between the input and the reference

image. The Self Query Layer is used to capture the

geometric cues for depth estimation, compute the

depth intervals and generate the final depth maps

through probabilistic linear combinations; both

DepthNet and PoseNet are optimised for training, and

the interference regions are filtered by an automatic

masking strategy, which is combined with various

loss functions to improve the model performance.

The benefits are significant, demonstrating excellent

performance on datasets such as KITTI, Cityscapes

and Make3D, with accuracy surpassing many other

methods, strong generalisation ability, excellent

performance in dealing with dynamic scenes and

zero-sample evaluations, and high efficiency in

inference using only a single image, with a

lightweight model design that is easy to integrate into

various types of systems. （ Mykola Lavreniuk ，

2024）

A Review of Methods for Estimating Depth Based on Various Application Scenarios

205

2.2 Depth Estimation Methods For

Stereo Image

In 2021, UniFuse was proposed by Hualie Jiang et al.

for 360° stereo depth estimation. This method aims

at fusing the features of equirect-angular projection

(ERP) or cubemap projection (CMP) to enhance the

depth estimation. The process is as follows: firstly,

the input panoramic image is subjected to ERP and

CMP respectively, and the CMP features are

reprojected to the ERP mesh through C2E; the U-Net

is used as the baseline network, and the processed

CMP features are unidirectionally fused to the ERP

features in the hopping connection of the decoding

stage, which is specifically achieved through the

designed CEE fusion module, which firstly performs

the residual modulation on the CMP features to

reduce their discontinuities, and then uses the SE

block to adaptively adjust the importance of the

channels; finally, the isometric columnar projection

depth map is output from the fused features. This is

achieved by the designed CEE fusion module, which

firstly modulates the residuals of the CMP features to

reduce their discontinuities, and then adaptively

adjusts the importance of the channels by using the

SE block; finally, the fused features output an

isometric bar-projected depth map. This approach has

several noteworthy benefits: State-of-the-art

performance is attained on the four frequently used

datasets, and the benefit is evident on the largest real

dataset Matterport3D; the CEE fusion module is

made to better fuse the two projected features and

reduce the number of parameters; the proposed one-

way fusion framework fuses the CMP features to the

ERP branch only in the decoding stage, which is more

efficient than the two-way fusion; the model

complexity is low. Low complexity, UniFuse based

on ResNet-18 has a small complexity increase but

significant performance increase compared to

BiFuse, and can maintain real-time and good

performance on MobileNetV2; strong generalization

ability, outperforms BiFuse when migrating between

different datasets, and is able to generate reasonable

depths in regions with no real depth. （Jiang、Sheng

、Zhu，2021）

In 2021, NLFB was proposed by Ilwi Yun et al. to

improve the 360 ° monocular depth estimation

method. The method consists of three main parts:

first, proposing a self-supervised learning method

using only gravity-aligned videos, which reduces the

dependence on depth data by mining the relationship

between the depths of consecutive scenes, and

constructing image, depth, and pose consistency loss

to train the model; secondly, using a jointly

supervised and self-supervised learning approach that

uses supervised learning to compensate for the

shortcomings of self-supervised learning in areas that

reflect light, for instance, and self-supervised learning

to improve the supervised learning features and

increase the model's ability to adapt to data that is not

visible; thirdly, the network can preserve global

information when reconstructing depth by creating a

non-local fusion block (NLFB), which applies non-

local operations to the features entering the fusion

block. The advantages of this method are significant:

Transformer is successfully applied to 360° depth

estimation, which outperforms previous methods on

multiple benchmark datasets and reaches the current

optimal level; the inaccuracy of supervised learning's

predictions because of data scarcity and the erratic

performance of self-supervised learning are both

successfully improved by the joint learning approach;

the non-local fusion block better preserves the global

information and improves the accuracy; the self-

supervised learning part requires only gravity-aligned

videos, which reduces the dependence on depth data

and shows advantages in the comparison with other

self-supervised learning methods. （ Yun 、 Lee 、

Rhee，2021）

In 2022, Shen et al. proposed the PanoFormer

model, which aims to solve the problem of depth

estimation of indoor 360 ° panoramic images. It

starts by designing a hierarchically structured

network architecture in which the input stems

perform the initial processing of the image, followed

by the encoder and decoder progressively extracting

and reducing the features through multiple

hierarchical stages, where the key lies in the

collaborative work of the positional embedding, PST

blocks and convolutional layers included in each

stage. In terms of feature processing, a pixel-level

patch-dividing method is innovatively adopted to

finely divide the input features and manually create

tokens, which helps the network to capture more

detailed features, differentiating it from the traditional

Vision Transformer processing. In order to cope with

the distortion problem of panoramic images, the

relative position embedding is implemented using the

Spherical Token Locating Model (STLM), which

effectively reduces the effect of distortion on depth

estimation by transforming operations between

different domains. Meanwhile, to improve the

perception of the panoramic geometric structure and

provide important information for depth estimation,

the enhanced panoramic self-attention mechanism

with token flow, which is based on the classic Vision

Transformer block, allows the final position of the

ICDSE 2025 - The International Conference on Data Science and Engineering

206

tokens to be determined by the initialization and

learnable flow during the computation of the attention

scores, token flow, and resampled features. In the

supervised part of model training, the objective

function is designed by combining the inverse Huber

(Berhu) loss and gradient loss, and the loss value is

calculated according to a specific formula, which

drives the model to be optimized continuously.

Furthermore, two panorama-specific metrics—the left-

right consistency error (LRCE) and the polar root

mean square error (P-RMSE)—are suggested in light

of the features of panoramic images. The P - RMSE

focuses on measuring the depth estimation accuracy

of the polar regions, while the LRCE is used to assess

the depth consistency of the left and right boundaries,

and together, they provide a comprehensive and

tailored evaluation criterion for panoramic depth

estimation to ensure the effectiveness and accuracy of

the model in the panoramic image depth estimation

task. （Shen、Lin、Liao，2022）

In 2022, Li et al. proposed the OmniFusion

method for 360-degree monocular depth estimation.

Given the presence of spherical distortion in 360

images affecting depth estimation, the method first

converts the ERP input images into a set of tangent

images using spherical projection, which can be used

to predict the depth map using a conventional CNN

architecture due to its lack of distortion. At the same

time, considering that the independence of tangent

image prediction of depth can cause problems, a

geometric embedding network is introduced to

combine pixel sphere coordinates with image centre

coordinates to provide geometric information, which

is fused with image features at an early stage of the

encoder to enhance depth consistency. To

compensate for the lack of overall information

brought by decomposing ERP, Transformer is used to

globally aggregate the image block features, and after

convolutional dimensionality reduction and

spreading to add positional embedding, the features

are adjusted by self-attention. In addition, let the

network predict the confidence maps, merge the

depths in a weighted average manner, and add a

regression layer to the decoder and transform the

domain. In order to enhance the quality of depth

estimation and successfully address the issue of 360-

image depth estimation, an iterative depth refinement

approach is also created to enhance the geometric

embedding based on the iteratively updated depth

information.（Li、Guo、Yan，2022）

In 2022, HiMODE was proposed by Masum Shah

Junayed et al. as an innovative method for depth

estimation of 360-degree panoramic images. The

technique, which is based on a CNN+Transformer

hybrid architecture, attempts to efficiently address the

issues of data loss and distortion in the depth

estimation of panoramic images. Architecturally, it

employs a deeply separable convolutional CNN

backbone network combined with a feature pyramid

network that is capable of extracting high-resolution

features near the edges, thereby reducing image

distortion and artefacts. The Transformer module, on

the other hand, plays an important role, with an

encoder that enhances the ability to encode depth

features by capturing the relationships between pixels

and global information in the image through self-

attention and cross-attention mechanisms; and a

spatial and temporal patch (STP) and a multi-head

self-attention (MHSA) layer in the decoder, which

can process and recover encoded features to generate

accurate depth maps. In addition, the method

introduces linear projection and positional coding,

where the feature maps extracted by the CNN are

appropriately processed to fit the input requirements

of the Transformer, and positional coding is utilised

to enhance the understanding of the image features.

By lowering the number of parameters and

computational expenses, the spatial residual block

(SRB) setting contributes to the system's increased

stability and performance. Conversely, the contextual

adjustment layer makes up for the lack of depth data

and increases the accuracy of depth estimation by

combining the feature maps that the CNN retrieved

with the depth maps that the Transformer produced.

The advantages of HiMODE include the following:

firstly, it achieves excellent performance on multiple

datasets and is able to estimate the depth map

accurately, especially in recovering surface details

and processing complex scenes. Second, the

technique is very flexible, robust to the size of the

input image, and can be used and trained on datasets

of various sizes. In addition, HiMODE's hybrid

architecture combines the advantages of CNN and

Transformer to provide an effective solution for depth

estimation of 360-degree panoramic images with a

wide range of applications. （

Junayed 、

Sadeghzadeh、Islam，2022）

3 EXPERIMENTS

3.1 Datasets

NYU-Depth V2 is a classical dataset focusing on

indoor scene understanding, with simultaneous

acquisition of colour (RGB) images and depth

(distance) information by Microsoft Kinect sensors,

A Review of Methods for Estimating Depth Based on Various Application Scenarios

207

containing 1449 pairs of densely annotated RGB and

depth images (with each object annotated with a

category and an individual number), as well as 464

diversified indoor scenes (e.g., home, office) from 3

cities ) of more than 400,000 frames of raw,

unlabelled video from three cities. The dataset is

divided into three parts: Labeled (preprocessed

labelled data with complete depth information), Raw

(raw sensor data), and a supporting toolkit, which is

widely used to train models for depth estimation,

semantic segmentation, 3D reconstruction, etc., and

is an important research foundation for robotics,

AR/VR, and other fields.

KITTI is a reputable dataset in the field of

automated driving that was jointly launched by the

Toyota Technological Institute (TTI) and the

Karlsruhe Institute of Technology (KIT) in Germany.

It contains rich data gathered by a range of sensors

(such as RGB cameras, stereo cameras, and 3D

LIDAR) in real traffic scenarios, covering complex

environments like cities and villages.Although its raw

data does not provide fine annotations for semantic

segmentation (e.g., pixel-level classification), the

researchers manually annotated some of the images

for different tasks (e.g., road detection, object

recognition) involving categories such as roads,

vehicles, pedestrians, and sky. This dataset has

become a core test benchmark for autonomous

driving algorithm development (e.g., environment

perception, depth estimation, visual localisation) due

to its realistic scenarios and diverse data.

The Stanford3D dataset is an important 3D

computer vision dataset, which is mainly collected

from indoor environments, covering several different

scenes such as offices, bedrooms, and so on. The

dataset contains rich data content, including a large

number of 3D models in the form of triangular

meshes, accompanied by information such as

materials and colours, and the corresponding RGB

images and depth images. At the same time, the

dataset also provides detailed annotation information,

including object category annotation, geometric

annotation (e.g., 3D coordinates, dimensions, shapes,

etc.) and semantic annotation (e.g., object functions,

uses, etc.). These annotation information provides

important support for tasks such as 3D model

reconstruction, object recognition and classification,

and scene understanding and interaction, making the

Stanford3D dataset widely valuable for research and

uses in the domain of computer vision.

A sizable RGB-D dataset for interior scene

comprehension is called Matterport3D. 10,800

panoramic views of 90 actual building-scale sceneries

made up of 194,400 RGB-D photos are included. A

residential building with several rooms and floors that

are labeled with surface configurations, camera

postures, and semantic segmentation makes up each

scene.

3.2 Evaluation Metrics

Indicators of the error or departure of a prediction

from the actual value include Absolute Relative Error

(Abs Rel), Squared Relative Error (Sq Rel), Root

Mean Square Error (RMSE), and Threshold Precision

Indicators (δ < 1.25, δ < 1.25², δ < 1.25³); Abs

Rel is the average of the absolute values of the relative

errors between the true and predicted values; the

lower the value, the better the model performs and the

closer the prediction is to the true value; The average

of the squares of the relative errors between the true

value and the anticipated value is known as Sq Rel.

The model performs better and the forecast result is

closer to the true value when the value is less. Sq Rel

is the average of the squares of the relative errors

between the predicted value and the true value, and

again the smaller the value, the better the model

performance; RMSE calculates the difference

between the predicted value and the true value, and

seeks for the average of the squares of the difference

and then opens the square root, and the smaller the

value is, the closer the predicted result is to the true

value, and the better the model prediction ability is;

and Threshold Precision is a metric that quantifies

how much the actual depth value deviates from the

projected depth value. The percentage of pixels in a

certain threshold range is the ratio of the predicted

depth value to the true depth value; the higher the

ratio, the more accurately the depth estimate is made

under the associated threshold value.

ICDSE 2025 - The International Conference on Data Science and Engineering

208

3.3 Experiment Data

Table 1: Experimental data on depth estimation methods for 2D images

Dataset Method Abs Rel RMSE

NYU-Depth V2 HybridDepth 0.026 0.128 0.988 1.000 1.000

Metric3Dv2 0.047 0.183 0.989 0.998 1.000

Marigold 0.055 0.224 0.964 0.991 0.998

Depth

Anything

0.056 0.206 0.984 0.998 1.000

UniDepth 0.058 0.201 0.984 0.997 0.999

KITTI Monodepth2 0.115 4.701 0.879 0.961 0.982

PackNrt-SfM 0.107 4.538 0.889 0.962 0.981

HR-Depth 0.104 4.410 0.894 0.966 0.984

GEDepth 0.048 2.044 0.976 0.997 0.999

EVP 0.048 2.015 0.980 0.998 1.000

SQLdepth 0.043 1.698 0.983 0.998 0.999

LightedDepth 0.041 1.748 0.989 0.998 0.999

SPIDepth 0.029 1.394 0.990 0.999 1.000

As shown in table 1, the minimum values of Abs Rel

and RMSE under different datasets are marked in

bold, and the maximum value of threshold accuracy

index is marked in bold, which shows that the current

2D image depth estimation methods of HybridDepth

and SPIDepth have better performance, and the

model prediction accuracy is higher.

Table 2: Experimental data on depth estimation methods for stereo images

Dataset Method Abs Rel Sq Rel RMSE

Stanford3D HoHoNet 0.0901 0.0593 0.4132 0.9047 0.9762 0.9933

Omnide

th 0.1009 0.0522 0.3835 0.9114 0.9855 0.9958

Bifuse 0.1214 0.1019 0.5396 0.8568 0.9599 0.9880

SvS

n 0.1003 0.0492 0.3614 0.9096 0.9822 0.9949

NLFB 0.0649 0.0240 0.2776 0.9665 0.9948 0.9983

PanoForme

0.0405 - 0.3083 0.9394 0.9838 0.9941

UniFuse 0.1114 - 0.3691 0.8711 0.9664 0.9882

OmniFusion 0.0950 0.0491 0.3474 0.8988 0.9769 0.9924

HiMODE 0.0532 0.0207 0.2619 0.9711 0.9965 0.9989

Matterport3D SvSyn 0.1063 0.0599 0.4062 0.8984 0.9773 0.9934

Omnidepth 0.1136 0.0671 0.4438 0.8795 0.9795 0.9950

HoHoNet 0.0671 0.0417 0.3416 0.9415 0.9838 0.9942

Bifuse 0.1330 0.1359 0.6277 0.8381 0.9444 0.9815

NLFB 0.0700 0.0287 0.3032 0.9599 0.9938 0.9982

PanoForme

- - 0.3635 0.9184 0.9804 0.9916

UniFuse 0.1063 - 0.4941 0.8897 0.9623 0.9831

OmniFusion 0.0900 0.0552 0.4261 0.9189 0.9797 0.9931

HiMODE 0.0658 0.0245 0.3067 0.9608 0.9940 0.9985

As shown in table 2, the minimum values of Abs Rel,

Sq Rel, RMSE under different datasets are boldly

marked, and the maximum value of the threshold

accuracy index is boldly marked, which indicates that

HiMODE, NLFB, and PanoFormer have performed

better than other stereo image depth estimation

techniques in recent years, and that the model

prediction accuracy is higher.

A Review of Methods for Estimating Depth Based on Various Application Scenarios

209

4 DISCUSSION

Both 2D image depth estimation and stereo image

depth estimation have their own shortcomings. 2D

image depth estimation has difficulties in data

acquisition and annotation, the model has limited

performance in dealing with complex scenes, lighting

changes and object occlusion, and feature extraction

is insufficient with high model complexity and

computational cost. Future research directions

include data enhancement, model optimisation, and

application scenario expansion, such as synthetic

data, innovative neural network structure, and fusion

of multimodal information. Stereo image depth

estimation, on the other hand, is more complex in data

acquisition and processing, and the model has

challenges in edge and detail capture, global and local

information fusion, and special scene processing, as

well as high model complexity and computational

cost. Future research can be carried out by optimising

the dataset, improving the model structure, fusing

multi-scale and multi-modal information, and

improving the real-time performance for better

application in augmented reality, virtual reality,

intelligent robotics and autonomous driving.

5 CONCLUSION

A crucial task in computer vision, depth estimation

measures the distance between each pixel in an image

and the camera. This information is vital for many

applications, including robotics, automatic driving,

VR, AR, 3D reconstruction, security monitoring, and

more. It also has significant research implications.

The accuracy and efficiency of depth estimation have

improved significantly with the advent of deep

learning, and it is currently primarily separated into

two categories: stereo image depth estimation and 2D

image depth estimation. In 2D image depth

estimation, HR-Depth optimises depth estimation by

redesigning jump connections and introducing fSE

modules, HybridDepth fuses focused stack

information and single-image a priori to solve scale

ambiguity, and SPIdepth strengthens the pose

network to improve accuracy, which have shown

excellent performance on multiple datasets. In stereo

image depth estimation, UniFuse fuses different

projection features, NLFB combines self-supervised

learning with non-local fusion blocks, PanoFormer

adopts innovative network architectures and

strategies to deal with distortion, OmniFusion solves

the problem of spherical distortion by using spherical

projection and Transformer, and HiMODE reduces

distortion by using a hybrid architecture of CNN+

Transformer. Transformer hybrid architecture to

reduce distortion and data loss, each of these

approaches has its own advantages in depth

estimation of complex scenes. However, at present,

2D image depth estimation suffers from the problems

of difficult data acquisition and annotation, limited

ability of the model to deal with complex scenes,

insufficient feature extraction, and high model

complexity and high computational cost, etc. Stereo

image depth estimation also faces the challenges of

data acquisition and processing, edge detail capture,

global and local information fusion, special scene

response, and model complexity and computational

cost. In the future, depth estimation research can be

carried out in various aspects, such as at the data level,

solving data-related problems by synthesising data

and optimizing datasets; at the model level,

innovating neural network structures, simplifying

models, and fusing multi-scale and multi-modal

information; at the application level, further

expanding to augmented reality, virtual reality,

intelligent robotics, and automated driving scenarios,

and improving real-time and accuracy, in order to

promote the depth estimation technology to a wider

range of fields. estimation technology to be widely

used and developed in more fields. Meanwhile, since

stereo images usually contain richer depth

information, such methods may become more and

more popular in the research of depth estimation.

REFERENCES

Cheng, B., Yu, Y., Zhang, L., et al., 2024. Depth estimation

of self-supervised monocular dynamic scene based on

deep learning. Journal of Remote Sensing, 28(9).

Ganji, A., Su, H., Guo, T., 2024. HybridDepth: Robust

Metric Depth Fusion by Leveraging Depth from Focus

and Single-Image Priors. arXiv preprint

arXiv:2407.18443.

Godard, C., Mac Aodha, O., Firman, M., et al., 2019.

Digging into self-supervised monocular depth

estimation. In Proceedings of the IEEE/CVF

International Conference on Computer Vision,

pp.3828-3838.

Guizilini, V., Ambrus, R., Pillai, S., et al., 2019. Packnet-

sfm: 3d packing for self-supervised monocular depth

estimation. arXiv preprint arXiv:1905.02693.

Hu, M., Yin, W., Zhang, C., et al., 2024. Metric3d v2: A

versatile monocular geometric foundation model for

zero-shot metric depth and surface normal estimation.

IEEE Transactions on Pattern Analysis and Machine

Intelligence.

Jiang, H., Sheng, Z., Zhu, S., et al., 2021. Unifuse:

Unidirectional fusion for 360 panorama depth

ICDSE 2025 - The International Conference on Data Science and Engineering

210

estimation. IEEE Robotics and Automation Letters,

6(2), pp.1519-1526.

Junayed, M.S., Sadeghzadeh, A., Islam, M.B., et al., 2022.

HiMODE: A hybrid monocular omnidirectional depth

estimation model. In Proceedings of the IEEE/CVF

Conference on Computer Vision and Pattern

Recognition, pp.5212-5221.

Ke, B., Obukhov, A., Huang, S., et al., 2024. Repurposing

diffusion-based image generators for monocular depth

estimation. In Proceedings of the IEEE/CVF

Conference on Computer Vision and Pattern

Recognition, pp.9492-9502.

Lavreniuk, M., 2024. SPIdepth: Strengthened Pose

Information for Self-supervised Monocular Depth

Estimation. arXiv preprint arXiv:2404.12501.

Lavreniuk, M., Bhat, S.F., Müller, M., et al., 2023. Evp:

Enhanced visual perception using inverse multi-

attentive feature refinement and regularized image-text

alignment. arXiv preprint arXiv:2312.08548.

Li, Y., Guo, Y., Yan, Z., et al., 2022. Omnifusion: 360

monocular depth estimation via geometry-aware

fusion. In Proceedings of the IEEE/CVF Conference on

Computer Vision and Pattern Recognition, pp.2801-

2810.

Lyu, X., Liu, L., Wang, M., et al., 2021. Hr-depth: High

resolution self-supervised monocular depth estimation.

In Proceedings of the AAAI Conference on Artificial

Intelligence, 35(3), pp.2294-2301.

Piccinelli, L., Yang, Y.H., Sakaridis, C., et al., 2024.

UniDepth: Universal monocular metric depth

estimation. In Proceedings of the IEEE/CVF

Conference on Computer Vision and Pattern

Recognition, pp.10106-10116.

Shen, Z., Lin, C., Liao, K., et al., 2022. PanoFormer:

Panorama transformer for indoor 360 ∘ depth

estimation. In European Conference on Computer

Vision, Cham: Springer Nature Switzerland, pp.195-

211.

Sun, C., Sun, M., Chen, H.T., 2021. Hohonet: 360 indoor

holistic understanding with latent horizontal features. In

Proceedings of the IEEE/CVF Conference on

Computer Vision and Pattern Recognition, pp.2573-

2582.

Wang, F.E., Yeh, Y.H., Sun, M., et al., 2020. Bifuse:

Monocular 360 depth estimation via bi-projection

fusion. In Proceedings of the IEEE/CVF Conference on

Computer Vision and Pattern Recognition, pp.462-471.

Wang, Y., Liang, Y., Xu, H., et al., 2024. Sqldepth:

Generalizable self-supervised fine-structured

monocular depth estimation. In Proceedings of the

AAAI Conference on Artificial Intelligence, 38(6),

pp.5713-5721.

Yang, L., Kang, B., Huang, Z., et al., 2024. Depth anything:

Unleashing the power of large-scale unlabeled data. In

Proceedings of the IEEE/CVF Conference on

Computer Vision and Pattern Recognition, pp.10371-

10381.

Yang, X., Ma, Z., Ji, Z., et al., 2023. Gedepth: Ground

embedding for monocular depth estimation. In

Proceedings of the IEEE/CVF International Conference

on Computer Vision, pp.12719-12727.

Yun, I., Lee, H.J., Rhee, C.E., 2022. Improving 360

monocular depth estimation via non-local dense

prediction transformer and joint supervised and self-

supervised learning. In Proceedings of the AAAI

Conference on Artificial Intelligence, 36(3), pp.3224-

3233.

Zioulis, N., Karakottas, A., Zarpalas, D., et al., 2019.

Spherical view synthesis for self-supervised 360 depth

estimation. In 2019 International Conference on 3D

Vision (3DV), IEEE, pp.690-699.

Zhu, S., Liu, X., 2023. LightedDepth: Video depth

estimation in light of limited inference view angles. In

Proceedings of the IEEE/CVF Conference on

Computer Vision and Pattern Recognition, pp.5003-

5012.

A Review of Methods for Estimating Depth Based on Various Application Scenarios

211
