Medical Image Segmentation Analysis and Research

Xiaohan Liu

School of Integrated Circuit Science and Engineering, Tianjin University of Technology, TianJin, 300384, China

Keywords: Medical Image Segmentation, Region Segmentation, Deep Learning.

Abstract: Medical image segmentation technology, a vital part of medical imaging analysis, has made great progress in

recent years. It is extremely important for the early identification of diseases, the making of treatment plans,

and surgical planning. In the early days, traditional image segmentation methods, like those based on

threshold-based segmentation, edge-detection, and region-growing, were effective in some simple scenarios.

However, when they were faced with complex medical images, they often encountered challenges such as

difficulty in handling noise interference, blurred boundaries, and multi-target overlapping. This paper first

systematically reviews three traditional medical image segmentation techniques based on threshold, edge, and

region, and then focuses on recent deep-learning-based segmentation techniques, including U-Net, Mask R-

CNN, and DeepLab models. This paper also summarizes the current status of medical image segmentation

techniques through examples of cell and organ segmentation as well as stomach cancer segmentation. Finally,

from the aspects of deep learning model optimization and technology integration, this paper looks into the

future of medical image segmentation technology.

1 INTRODUCTION

Medical image segmentation technology is a crucial

element in medical image analysis. This holds

substantial importance in the initial detection of

diseases and the development of treatment plans

during the early stages of disease onset. Its objective

is to precisely extract target regions, such as organs,

diseased tissues, or cellular structures, from complex

medical images, thereby providing a reliable

foundation for clinical decision-making. Given the

significant differences in the segmentation of medical

images by humans, previous researchers have

conducted extensive research on medical image

segmentation methods.

Traditional image segmentation methods,

including threshold segmentation, edge detection and

region growth segmentation methods, can perform

basic image segmentation tasks in specific scenes

through underlying features like image gray value,

texture and spatial distribution. However, when

dealing with complex medical images, traditional

segmentation methods have obvious limitations.

Image features are easily disturbed by noise,

decreasing the segmentation accuracy. In multi -

https://orcid.org/0009-0001-2277-7078

target scenarios, traditional image segmentation

methods have difficulty in effectively differentiating

targets from backgrounds, particularly when target

and background features are alike, leading to subpar

segmentation results. Moreover, when the target

boundary in the image is unclear, traditional methods

are likely to produce discontinuous or incorrect

segmentation results, further undermining the

segmentation accuracy. Since many traditional

methods rely on manually setting seed points or

parameters, this not only increases the operational

complexity but also makes the segmentation results

vulnerable to subjective influence.

In recent years, deep-learning technology has

advanced rapidly, bringing revolutionary

breakthroughs in medical image segmentation. By

automatically learning multi-level features, deep-

learning methods remarkably enhance the precision

and stability of segmentation. This paper intends to

explore the applications in medical image

segmentation of U-Net, Mask R-CNN as well as

DeepLab, along with their pros and cons, by

conducting a contrastive analysis between traditional

methods and deep-learning techniques. It provides

194

Liu, X.

Medical Image Segmentation Analysis and Research.

DOI: 10.5220/0013680900004670

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 2nd International Conference on Data Science and Engineering (ICDSE 2025), pages 194-198

ISBN: 978-989-758-765-8

references for researchers in related fields and offers

ideas for further research directions.

2 THRESHOLD SEGMENTATION

Threshold segmentation ranks among the simplest

approaches in image segmentation. Its principle

entails analyzing the grayscale values of an image,

establishing a threshold, and comparing the pixels of

the image with it. Then, distinct areas are separated

according to the comparison results. Based on these,

the components of the object and the backdrop within

the picture can be recognized. A global threshold is

selected by calculating the maximal inter-class

variance within the image. The Otsu algorithm selects

the threshold by calculating the minimum intra-class

variance in addition to the maximum inter-class

variance calculation (Otsu, 1975). Calculating the

local threshold involves calculating the threshold in

different areas of the image and then calculating the

average threshold or dynamically selecting the

threshold according to the alteration of pixel gray

values. Ilhan U et al.. proposed a threshold-based

method that segmented the tumor region from the

brain MRI image by enhancing the brain MRI image

(Ilhan, 2017). Maolood et al. proposed a

segmentation method based on fuzzy entropy and

level-set thresholds that can segment diverse cancer-

related images (Maolood, 2018).

Threshold-based segmentation methods are

simple in logic, fast in calculation, and can perform

real-time processing. However, when handling

complex structures, the contrast of gray values for the

target area and the background area isn't evident, and

they are prone to being interfered with by noise. At

this time, the performance of threshold-based image

segmentation will degrade, making it difficult to

adapt to multimodal image features.

3 EDGE DETECTION

Medical image analysis based on edge detection aims

to analyze the changes of gray value, texture, color

and other features in the image. In an image, when an

abrupt change occurs between pixels, the method uses

an edge detection operator to detect the image target

and tracks the contours to segment the image target.

Commonly used edge detection operators include the

Sobel operator (Sobel, 1978), the LoG operator (Marr

and Hildreth, 1980), and the Canny operator

(Canny,1986). The Sobel operator determines the

edges by calculating the gradients in the horizontal

and vertical directions, but it has difficulty in

distinguishing the subject from the background

strictly. The LoG operator is first smoothed by a

Gaussian filter and then takes the second-order

derivative to find the zero-crossing point. However,

the operator is sensitive to noise, which leads to

insufficient edge localization accuracy.

The Canny operator, based on a multi-stage

algorithm, is more complex. It can effectively detect

weak edges and suppress noise at the same time.

However, the computation procedure is intricate and

the processing time is extended. In practical image

segmentation applications, these operators can be

used to segment bone X-ray images (Lu, Tang, and

Liu, 2023). blood vessel images, and lung CT images

(Zhang, Fu, and Dai, 2019).

Segmentation based on edge detection is a method

for segmenting images that have uniform regions. If

the edge of the image is fuzzy or the image has more

details, the accuracy of the image segmentation

results will be low. In addition, since the method is

based on the change of image grayscale, the obtained

result is only the segmentation result of the image,

which is not necessarily the same as the actual

segmentation. At the same time, for some complex

medical images, such as images of richly textured soft

tissues, some important information may be lost.

4 REGIONAL GROWTH

To cluster pixels with similar characteristics together,

researchers can use several methods in the division of

medical images based on region growth. The region-

growing approach selects several seed pixels on the

picture. Subsequently, it combines the adjacent pixels

with these seed pixels based on characteristics such

as grayscale value, texture, and color, until no more

pixels satisfying the criteria are available. This

method relies on the setting of seed points and

thresholds, and is likely to cause incomplete

segmentation or over-segmentation. The region

splitting and merging approach partitions the initial

image into numerous regions. After that, it

consecutively expands or combines these regions

according to the similarity among the pixels. Once the

features of the pixels in a region exceed a threshold

set in advance, it means that there are different targets

in the region and they need to be further segmented.

This method is computationally complex and has

poor noise immunity.

The segmentation method based on region growth

can, on the one hand, establish a graph model using

Medical Image Segmentation Analysis and Research

195

local information, and then segment the images of

pulmonary arteries and veins (Jimenez-Carretero,

Bermejo-Peláez, and Nardelli, 2019). On the other

hand, this method can also accomplish the

segmentation of a brain magnetic resonance image

(MRI) by automatically choosing seed points along

with a genetic algorithm (Javadpour and

Mohammadi, 2016).

5 IMAGE SEGMENTATION

BASED ON DEEP LEARNING

Due to the limitations of the above-mentioned

medical image segmentation methods in handling

complex images, researchers developed a deep-

learning-based segmentation approach. This

approach is intended to further enhance the image

segmentation results, enabling better handling of

complex-image segmentation tasks.

5.1 U-Net

U-Net, a deep-learning-based structure for image

semantic partitioning, is of great significance in

medical image segmentation and ranks among the

most prevalently utilized image - segmentation

models (Siddique, Paheding, and ElkinIn, 2021)

order to achieve higher segmentation accuracy with a

small number of training images, Ronneberger et al.

developed a U-Net model suitable for biomedical

image segmentation under the influence of the full

convolutional network (FCN)(Ronneberger, Fischer,

and Brox, 2015). The encoder-decoder model was

proposed by Long et al(Long, Shelhamer, Darrell,

2015). U - Net's fundamental structure is composed

of two components. One is the contraction

path(encoder), which extracts high-level features

from the image while reducing the amount of data by

implementing downsampling on the feature map. The

other part is the expansion path (decoder), which

gradually recovers the extracted feature information

to a resolution close to the original image size through

upsampling. In addition, U-Net uses skip connections

to directly connect the feature maps of the encoder

and decoder, by combining high-level global features

while preserving local features, thus effectively

improving the accuracy of image segmentation. U-

Net's unique U-shaped symmetric architecture

extracts high-level semantic features with the help of

contraction paths and preserves low-level detail

features with the help of expansion paths, so as to

achieve the organic integration of the two and

effectively restore the image resolution. With this

characteristic, U-Net enjoys a remarkable edge in

medical image segmentation and has emerged as one

of the crucial approaches in this domain.

U-Net can perform end-to-end training. This

implies that during the training process, it can directly

learn from the inputted medical images and generate

the corresponding segmentation outcomes. This

learning approach enables U-Net to adapt to different

types of medical images and segmentation tasks,

including neuronal structure segmentation, cell

segmentation, heart segmentation (Antonelli, Reinke,

Bakas, and Farahani, 2022), and lung CT image

segmentation (Chen, 2023). Building on the evolution

of the U-Net model, researchers have derived a

diverse range of variants. For example, the 3D U-Net

model is applicable to stereoscopic data segmentation

(Çiçek, Abdulkadir, and Lienkamp, 2016). The

Attention U-Net can focus on the segmentation of a

particular thing and is not affected by background and

other factors. U-Net++ is a further enhancement of U-

Net. Besides cell segmentation, it can also segment

organs like brain tumors (Micallef, Seychell, Bajada,

2021). U-Net3+ fuses features of different scales

through full-scale jump connections, resulting in

higher segmentation accuracy.

5.2 Mask R-CNN

Unlike semantic segmentation, instance segmentation

adds labels to each target object after detecting the

target type, and a representative model in instance

segmentation is the Mask R-CNN model. Ren et al. 's

Faster R-CNN model is an algorithm for target

detection(Ren, He, Girshick, 2016). He et al 's Mask

R-CNN model improves the Faster R-CNN model

from two aspects (He, Gkioxari, Dollár, 2017): (1) To

attain precise image segmentation, Mask R - CNN

adds a mask branch in parallel to predict the region of

interest (RoI). (2) In the Mask R - CNN model, the

RoIPool layer is substituted with the RoLAlign layer

since the rounding operation of the RoIPool layer can

result in image positioning deviation. While

performing object detection, pixel-level image

segmentation is carried out, which allows Mask R-

CNN to segment accurately in scenarios with blurred

object boundaries and complex shapes.

When performing image segmentation with Mask

R-CNN, the input image is initially pre-processed

through clipping and other operations, and then the

feature map is obtained through the neural

convolutional network, multiple anchor points are set

for the feature map and candidate RoI is obtained.

Binary classification and bounding box regression are

ICDSE 2025 - The International Conference on Data Science and Engineering

196

performed on the regional suggestion network (RPN)

for these ROIs. The filtered RoI undergoes

classification, bounding box regression, and mask

generation through the RoIAlign operation.

For multi-organ segmentation, Shu et al. 's

improved Mask R-CNN model accurately segmented

seven major organs, including the heart, lung, liver,

and kidney, in the same image(Shu, Nian, Yu, 2020).

In the segmentation of bone and soft tissue images,

Felfeliyan, B et al(Felfeliyan, Hareendranathan,

Kuntze, 2022) improved the Mask R-CNN model by

adjusting the loss function, enabling it to accurately

segment multiple parts such as shoulder, elbow, and

wrist in MSI MRI images. This not only achieves

good results in the field of multi-organ segmentation

but also has excellent performance in the

segmentation of specific tissues and parts, further

expanding the application range of the Mask R-CNN

model in medical image segmentation.

Mask R-CNN can be applied to the prediction and

segmentation of diseased areas in medical images and

provides a solid foundation for subsequent algorithm

improvement. For example, the 3D Mask R-CNN

algorithm can improve the accuracy of brain tumor

image segmentation(Jeong, Kahn, Liu, 2020).

5.3 DeepLab

When the DeepLab model processes an image, it first

preprocesses the image to ensure consistent data

distribution. Next, it extracts features from the image

by means of a deep convolutional network, which is

the core part of the DeepLab model. Subsequently,

the DeepLab model introduces dilated convolution to

expand the receptive field, improve the image-

segmentation accuracy, and maintain the resolution

simultaneously. After that, the model introduces

Spatial Pyramid Pooling (SPP) to perform pooling

operations on the feature maps, further enhancing its

performance. Finally, the model optimizes the

segmentation-target boundary according to the

similarity between pixels by using the fully-

connected conditional random field (CRF). After

undergoing the above-mentioned processing, the

DeepLab model outputs an image of the same size as

the input image. Each pixel in the image is assigned a

category label to indicate the semantic category it

belongs to.

Overall, these techniques have enabled DeepLab

to achieve remarkable results in semantic

segmentation. This success has drawn numerous

researchers to extend DeepLab's applications to

diverse fields. Among them, the medical-image

analysis field, due to its unique value and challenges,

has become an important area that many researchers

focus on and actively explore for applications.

DeepLab improves performance of semantic

segmentation by integrating various techniques. In

the field of medical image analysis, Wang et al.

proposed a model based on the DeepLab v3+ network

structure to precisely recognize gastric cancer images

and segment the cancerous areas(Wang, Liu,2021).

DeepLab v3+ network architecture optimizes the use

of dilated convolution, enabling it to merge multi-

scale features and improve segmentation capabilities

for complex scenes. The model proposed based on

this structure has significantly advanced the

segmentation of gastric-cancer images and also

promoted the growth of convolutional neural

networks in the medical field.

6 CONCLUSIONS

Medical image segmentation technology, as an

important computer - assisted diagnostic technology,

has become a crucial and essential technology in

medical image analysis and exerts a significant

influence in the fields of disease diagnosis, treatment

planning and medical research. Traditional

segmentation methods, depending on image features

and algorithm logic, can quickly complete the

segmentation task when the image features are

obvious or the scene is relatively simple. However, as

the complexity of medical images grows, traditional

segmentation methods are gradually failing to satisfy

the requirements of modern medicine. Meanwhile,

deep-learning-based segmentation technology can

effectively compensate for the deficiencies of

traditional methods when segmenting complex

medical images.

Nowadays, in the realm of medical image

segmentation, besides common segmentation

methods, there are also multimodal image fusion,

multiscale fusion and deep learning combined with

traditional processing techniques. These methods can

better obtain to capture complex information.

Although the segmentation technology of medical

images has made notable progress, it still faces some

challenges. For example, deep learning models

necessitate numerous training models, model

robustness is insufficient, and the evaluation of image

segmentation results varies from person to person.

In the future, medical image segmentation technology

may develop in terms of ongoing optimization and

refinement of deep learning models and combination

with other technologies, so as to obtain more

comprehensive pathological characteristics and

Medical Image Segmentation Analysis and Research

197

expand different application scenarios. This will

further improve the accuracy, robustness, and

application value of medical image segmentation and

provide strong support for precision medicine and

personalized treatment.

REFERENCES

Antonelli, M., Reinke, A., Bakas, S., Farahani, K., Kopp-

Schneider, A., Landman, B. A., ... & Cardoso, M. J.,

2022. The medical segmentation decathlon. Nature

Communications, 13(1), 4128.

Canny, J., 1986. A computational approach to edge

detection. IEEE Transactions on Pattern Analysis and

Machine Intelligence, (6), 679-698.

Chen, Z., 2023. Medical Image Segmentation Based on U-

Net. In Journal of Physics: Conference Series (Vol.

2547, No. 1, p. 012010). IOP Publishing.

Çiçek, Ö., Abdulkadir, A., Lienkamp, S. S., Brox, T., &

Ronneberger, O., 2016. 3D U-Net: learning dense

volumetric segmentation from sparse annotation. In

Medical Image Computing and Computer-Assisted

Intervention–MICCAI 2016: 19th International

Conference, Athens, Greece, October 17-21, 2016,

Proceedings, Part II 19 (pp. 424-432). Springer

International Publishing.

Felfeliyan, B., Hareendranathan, A., Kuntze, G., Jaremko,

J. L., & Ronsky, J. L., 2022. Improved-Mask R-CNN:

Towards an accurate generic MSK MRI instance

segmentation platform (data from the Osteoarthritis

Initiative). Computerized Medical Imaging and

Graphics, 97, 102056.

He, K., Gkioxari, G., Dollár, P., & Girshick, R., 2017. Mask

R-CNN. In Proceedings of the IEEE International

Conference on Computer Vision (pp. 2961-2969).

Ilhan, U., & Ilhan, A., 2017. Brain tumor segmentation

based on a new threshold approach. Procedia Computer

Science, 120, 580-587.

Javadpour, A., & Mohammadi, A., 2016. Improving brain

magnetic resonance image (MRI) segmentation via a

novel algorithm based on genetic and regional growth.

Journal of Biomedical Physics & Engineering, 6(2), 95.

Jeong, J., Lei, Y., Kahn, S., Liu, T., Curran, W. J., Shu, H.

K., ... & Yang, X., 2020. Brain tumor segmentation

using 3D Mask R-CNN for dynamic susceptibility

contrast enhanced perfusion imaging. Physics in

Medicine & Biology, 65(18), 185009.

Jimenez-Carretero, D., Bermejo-Peláez, D., Nardelli, P.,

Fraga, P., Fraile, E., Estépar, R. S. J., & Ledesma-

Carbayo, M. J., 2019. A graph-cut approach for

pulmonary artery-vein segmentation in noncontrast CT

images. Medical Image Analysis, 52, 144-159.

Long, J., Shelhamer, E., & Darrell, T., 2015. Fully

convolutional networks for semantic segmentation. In

Proceedings of the IEEE Conference on Computer

Vision and Pattern Recognition (pp. 3431-3440).

Lu, F., Tang, C., Liu, T., Zhang, Z., & Li, L., 2023. Multi-

attention segmentation networks combined with the

Sobel operator for medical images. Sensors, 23(5),

2546.

Maolood, I. Y., Al-Salhi, Y. E. A., & Lu, S., 2018.

Thresholding for medical image segmentation for

cancer using fuzzy entropy with level set algorithm.

Open Medicine, 13(1), 374-383.

Marr, D., & Hildreth, E., 1980. Theory of edge detection.

Proceedings of the Royal Society of London. Series B.

Biological Sciences, 207(1167), 187-217.

Micallef, N., Seychell, D., & Bajada, C. J., 2021. Exploring

the U-Net++ model for automatic brain tumor

segmentation. IEEE Access, 9, 125523-125539.

Otsu, N., 1975. A threshold selection method from gray-

level histograms. Automatica, 11(285-296), 23-27.

Ren, S., He, K., Girshick, R., & Sun, J., 2016. Faster R-

CNN: Towards real-time object detection with region

proposal networks. IEEE Transactions on Pattern

Analysis and Machine Intelligence, 39(6), 1137-1149.

Ronneberger, O., Fischer, P., & Brox, T., 2015. U-Net:

Convolutional networks for biomedical image

segmentation. In Medical Image Computing and

Computer-Assisted Intervention–MICCAI 2015: 18th

International Conference, Munich, Germany, October

5-9, 2015, Proceedings, Part III 18 (pp. 234-241).

Springer International Publishing.

Siddique, N., Paheding, S., Elkin, C. P., & Devabhaktuni,

V., 2021. U-Net and its variants for medical image

segmentation: A review of theory and applications.

IEEE Access, 9, 82031-82057.

Shu, J. H., Nian, F. D., Yu, M. H., & Li, X., 2020. An

improved Mask R-CNN model for multiorgan

segmentation. Mathematical Problems in Engineering,

2020(1), 8351725.

Sobel, I., 1978. Neighborhood coding of binary images for

fast contour following and general binary array

processing. Computer Graphics and Image Processing,

8(1), 127-135.

Wang, J., & Liu, X., 2021. Medical image recognition and

segmentation of pathological slices of gastric cancer

based on Deeplab v3+ neural network. Computer

Methods and Programs in Biomedicine, 207, 106210.

Zhang, Z., Fu, H., Dai, H., Shen, J., Pang, Y., & Shao, L.,

2019. ET-Net: A generic edge-attention guidance

network for medical image segmentation. In Medical

Image Computing and Computer Assisted

Intervention–MICCAI 2019: 22nd International

Conference, Shenzhen, China, October 13–17, 2019,

Proceedings, Part I 22 (pp. 442-450). Springer

International Publishing.

ICDSE 2025 - The International Conference on Data Science and Engineering

198
