2 RELATED WORKS
Attallah (Attallah, 2023) proposes a novel approach
for tomato leaf disease classification using image
preprocessing, transfer learning with ResNet-18,
ShuffleNet, and MobileNet, and hybrid feature
selection. Deep features are extracted, refined, and
classified using KNN and SVM, achieving 99.92%
and 99.90% accuracy with 22 and 24 features,
respectively, ensuring efficient and accurate disease
detection for improved agricultural productivity. A
small system containing two CNN models (CNN1
and CNN2) that only require 5.1 MB and 6 MB of
storage is shown by H. Ulutas and V. Aslantas
(Ulutaş, Aslantaş, et al. , 2023). Training periods are
greatly shortened, taking about 1.5 hours. The
ensemble achieves 99.60% accuracy using a dataset
of 18,160 pictures, fine-tuning, and PSO-based
optimization, allowing for the effective and timely
identification of tomato leaf diseases. A methodology
that uses the Otsu segmentation technique for image
processing and the Grey Level Co-Occurrence Matrix
(GLCM) method for feature extraction is put forth by
S. U. Rahman et al. The Support Vector Machine
(SVM) technique is used for classification, and it
achieves impressive accuracy rates. Effective tomato
leaf disease detection and diagnosis are made possible
by this combination of approaches. A. Guerrero-
Ibañez and A. Reyes-Muñoz(Ibañez, and, Muñoz,
2023) describe a CNN-based method for classifying
tomato diseases that outperforms a number of current
models, attaining 99.9% accuracy with good
precision, recall, and F1 scores. In order to improve
accuracy, precision, recall, and F1 scores, K. Roy et
al. [5] suggest a hybrid PCA Deep Net framework
that combines deep neural networks and machine
learning. It outperforms current algorithms in
identifying and categorising tomato leaf diseases,
achieving 99.25% validation accuracy after being
trained on the Plant Village dataset. A modified
InceptionResNet-V2 (MIR-V2) model using RPCA-
enhanced data and adjusted max-pool layers is
presented by P. Kaur et al. (Kaur, Harnal, et al. , 2023)
and achieves 98.92% accuracy. Precision, recall, and
F1-score are used to evaluate the system's overall
performance in plant disease detection, and it
surpasses pre-trained models. Four CNN
architectures (VGG-16, VGG-19, ResNet, and
Inception V3) were assessed by I. Ahmad et al. or the
categorisation of tomato leaf diseases. Using a self-
collected augmented field dataset of 15,216 photos
and a laboratory dataset of 2,364 images, Inception
V3 reached the best accuracy of 93.40% on the
laboratory dataset, however due to real-world
obstacles, its performance was lower on the field
dataset. Performance indicators like as F1-score,
recall, and precision demonstrated Inception V3's
greater performance in both datasets. To solve
misdiagnosis issues, S. G. Paul et al. (Paul, Biswas, et
al. , 2023) offer a method for tomato leaf disease
classification that uses a lightweight proprietary CNN
model and transfer learning-based models (VGG-16,
VGG-19). The algorithm achieved a 95.00%
accuracy and recall rate by applying data
augmentation and classifying eleven types, including
healthy leaves. The agricultural ecosystem benefited
from the implementation of the best-performing
model in web and Android applications, which
offered a comprehensive solution for early disease
identification and treatment options. Using CNN, S.
Z. Khan et al. were able to detect tomato leaf disease
in nine disease classes and one healthy class with an
average accuracy of 91.2%. This demonstrated the
system's efficacy in disease identification and
assisting with timely crop management,
outperforming pre-trained models such as VGG16,
InceptionV3, and Mobile Net. Huang et al. (Huang,
Chen, et al. , 2023) overcame complicated backdrops
by using the FC-SNDPN approach with VGG-16 for
automatic tomato leaf disease identification in
southern China. The solution outperformed
conventional CNN models and supported precision
agriculture with an accuracy of 95.40% using a
custom dataset and segmentation technique. A. Saeed
et al. (Saeed, Aziz, et al. , 2023) used pre-trained
CNNs, Inception V3 and Inception ResNet V2,
trained on a dataset of 5,225 pictures, to create a
tomato leaf disease detection system. With dropout
rates between 5% and 50%, the models' accuracy was
99.22%; Inception V3 and Inception ResNet V2
performed best at 50% and 15%, respectively. This
method has great promise for the identification of
agricultural diseases since it is successful in
differentiating between healthy and sick tomato
leaves. In order to improve feature extraction, T.
Sanida et al. (Sanida, Sideris, et al. , 2023) integrate
the first ten convolutional layers of VGG16 with
inception blocks in their deep learning system for
tomato leaf disease identification. The model pre-
trains on ImageNet and fine-tunes on a tomato leaf
dataset as part of a two-stage transfer learning
process. The training imbalance between classes is
addressed with an enhanced categorical cross-entropy
loss function. The technology outperforms other
cutting-edge methods with an accuracy of 99.23%.
Using 18,160 photos, Ulutaş and Aslantaş (Ulutaş and
Aslantaş, 2023) suggest an ensemble CNN model for
tomato leaf disease detection. They achieved 99.60%
