Enhancing Design-by-Contract with Frame Speciﬁcations

Yoonsik Cheon and Benjamin Good

Department of Computer Science, The University of Texas at El Paso, El Paso, Texas, U.S.A.

Keywords:

Annotation, Design by Contract, Frame Condition, Runtime Check, Dart.

Abstract:

This paper introduces an annotation-based approach to extending Design by Contract (DbC) with support for

specifying and enforcing frame properties at runtime. Frame speciﬁcations, also known as frame conditions

or frame properties, deﬁne which parts of a program’s state may be modiﬁed during execution. Our approach

models object states as abstract tuples, ensuring that runtime checks do not introduce unintended side effects.

We implement a proof-of-concept prototype in Dart, utilizing compile-time instrumentation and runtime re-

ﬂection to accommodate optional typing. By automating contract enforcement, this approach reduces the

need for manual assertions, simpliﬁes code maintenance, and enhances clarity by separating program logic

from runtime checks. We evaluate its effectiveness in a cross-platform mobile application, comparing it to

traditional assertion-based methods.

1 INTRODUCTION

Design by Contract (DbC) is a well-established soft-

ware correctness methodology that emphasizes clear

speciﬁcations of obligations and guarantees between

software components (Meyer, 1992; Meyer, 1997;

Mitchell and McKim, 2001; Ozkaya, 2019). By em-

bedding formal contracts, such as preconditions, post-

conditions, and invariants, within the code, DbC en-

sures that software behaves as expected during execu-

tion. The fundamental premise is that the client and

provider of a method must adhere to agreed-upon con-

ditions, thereby fostering robustness and reliability.

However, while DbC effectively speciﬁes what a

method must achieve (via postconditions) and what

constraints must hold before execution (via precon-

ditions), it does not specify what parts of the pro-

gram state may change. This missing aspect, known

as frame conditions, is crucial for reasoning about

program behavior modularly (Borgida et al., 1995).

Frame conditions help ensure that methods do not

inadvertently modify unrelated state, a critical prop-

erty for maintaining system integrity—especially in

complex applications where unintended side effects

can lead to subtle and hard-to-detect errors. Indeed,

unforeseen state changes have been identiﬁed as a

root cause of serious software failures in both indus-

trial and safety-critical systems (Amusuo et al., 2022;

Gazzola et al., 2017). This highlights the importance

of making state change constraints explicit and veriﬁ-

able as part of the contract.

This paper introduces an annotation-based ap-

proach to integrating frame speciﬁcations into DbC

for runtime veriﬁcation. Our approach enables de-

velopers to specify, at the method level, which parts

of an object or program state may be modiﬁed dur-

ing execution. We model objects as tuples of abstract

state components, allowing for ﬁne-grained control

over permissible modiﬁcations without unintended

side effects. By leveraging compile-time instrumen-

tation and runtime reﬂection, our approach enforces

frame conditions dynamically, improving software re-

liability and maintainability. Additionally, we address

challenges inherent to optionally typed languages, en-

suring that our technique remains ﬂexible and appli-

cable across diverse programming environments.

For this study, we chose Dart (Bracha, 2016) as

our implementation platform due to its increasing

popularity in mobile app development and its unique

language features, such as optional typing. To the

best of our knowledge, no existing DbC framework

provides built-in support for specifying and enforc-

ing frame conditions at runtime. While prior research

has explored static analysis and veriﬁcation of frame

properties (Hatcliff and Dwyer, 2001; Leino and Nel-

son, 2002; Marche et al., 2004; Kassios, 2006; Leino

and Muller, 2006; Darvas and Leino, 2007; Hahnle

et al., 2007), our work is the ﬁrst to integrate run-

time support for frame conditions within a DbC-based

runtime checking system. A runtime-based technique

378

Cheon, Y. and Good, B.

Enhancing Design-by-Contract with Frame Speciﬁcations.

DOI: 10.5220/0013578400003964

In Proceedings of the 20th International Conference on Software Technologies (ICSOFT 2025), pages 378-385

ISBN: 978-989-758-757-3; ISSN: 2184-2833

is especially important for dynamically or optionally

typed languages like Dart, where static analysis alone

may be insufﬁcient or ineffective.

Existing work on DbC in Dart includes Chalin’s

Dart Contracts proposal (Chalin, 2014), which intro-

duces mechanisms for specifying function and class

behavior but lacks provisions for deﬁning or en-

forcing frame properties. Our annotation-based ap-

proach addresses this gap by allowing developers to

explicitly specify frame conditions in Dart and ver-

ify them at runtime. Speciﬁcally, besides @Modifies

annotation for declaring frame conditions, our ap-

proach introduces the @State annotation, which pro-

vides an abstract representation of an object’s state to

facilitate frame checks (see Section 4.2). This con-

cept is analogous to model variables in Behavioral

Interface Speciﬁcation Languages (BISLs) (Cheon

et al., 2005), which deﬁne speciﬁcation-only vari-

ables based on concrete program variables. Further-

more, the parts parameter within the @State annota-

tion functions similarly to data groups (Leino, 1998),

allowing developers to group mutable ﬁelds under an

abstract state element for more structured and modu-

lar speciﬁcation of frame conditions.

The rest of this paper is organized as follows. Sec-

tion 2 reviews Design by Contract. Section 3 outlines

key challenges in specifying frame conditions. Sec-

tion 4 describes our annotation-based approach, in-

cluding state modeling and veriﬁcation. Section 5 de-

tails the prototype implementation. Section 6 presents

our evaluation. Section 7 concludes with a summary

and future work.

2 DESIGN BY CONTRACT

Design by Contract (DbC) is a programming method-

ology that enhances software robustness by explic-

itly deﬁning formal agreements, or “contracts,” be-

tween system components (Meyer, 1992; Mitchell

and McKim, 2001; Ozkaya and Kloukinas, 2014).

These contracts specify the mutual obligations and

guarantees of components, focusing on preconditions,

postconditions, and class invariants to ensure correct-

ness and maintainability.

At the core of DbC are preconditions and postcon-

ditions, which deﬁne the expected conditions before

and after a method’s execution, respectively. Precon-

ditions specify the constraints that must hold before a

method is invoked. If these are satisﬁed, the method

is guaranteed to fulﬁll its postconditions. Postcondi-

tions describe the expected state of the system after

execution, ensuring that the method behaves as in-

tended. Consider a simple bank account class with a

method responsible for money withdrawal. The con-

tract for this method can be expressed as follows:

@Requires(’amount > 0 && amount <= balance’)

@Ensures(’balance == balance@pre - amount’)

void withdraw(long amount) {

balance -= amount;

}

In this example, the withdraw() method includes

a precondition, denoted by the @Requires annotation,

which states that the withdrawal amount must be posi-

tive (amount > 0) and must not exceed the current bal-

ance (amount <= balance). The postcondition, indi-

cated by @Ensures, guarantees that the balance is cor-

rectly updated by deducting the withdrawn amount.

The notation balance@pre refers to the account bal-

ance before the method execution, providing a refer-

ence for validation after the method completes. By

explicitly deﬁning these expectations and guarantees,

DbC simpliﬁes debugging, maintenance, and soft-

ware evolution. Enforcing such contracts makes soft-

ware behavior more predictable and reliable, reducing

the risk of errors due to violated assumptions.

DbC also support class invariants—properties that

must always hold in an object’s stable state, typically

before and after any public method execution. In-

variants deﬁne integrity constraints such as “the bal-

ance must never be negative” and they apply across

all methods that can affect an object’s state.

While DbC enforces preconditions, postcondi-

tions, and invariants, it does not specify how state may

change during a method’s execution. This is where

frame conditions come into play. Frame conditions

deﬁne which parts of the state can change between a

method’s entry and exit, ensuring that methods do not

inadvertently modify unrelated parts of the state. For

example, in a bank account class, an invariant might

ensure the balance is never negative, whereas a frame

condition for the withdraw() method would restrict

changes to the balance ﬁeld and no other part of the

state. Invariants describe a single state, while frame

conditions relate two states: the pre-state and post-

state. Additionally, not all frame properties can be

captured as invariants, especially when expressing the

absence of side effects, which is crucial for modular

reasoning about code behavior.

3 MOTIVATION AND

CHALLENGES

We aim to enhance DbC by integrating frame speci-

ﬁcations, which go beyond traditional preconditions

and postconditions to explicitly deﬁne which parts

Enhancing Design-by-Contract with Frame Speciﬁcations

379

of a system’s state can change during method exe-

cution. This added expressiveness improves contract

clarity, reduces unintended side effects, and enables

automatic runtime veriﬁcation. While DbC tradition-

ally ensures that speciﬁc conditions are satisﬁed be-

fore and after execution, it does not specify what must

remain unchanged. Frame conditions ﬁll this gap

by listing all variables that can change—known as

“and nothing else changes” (Borgida et al., 1995)—

indirectly asserting that all other variables remain the

same. By clearly stating which variables or struc-

tures may be modiﬁed, frame conditions help prevent

subtle bugs caused by unintended state modiﬁcations,

contributing to more robust and maintainable soft-

ware. They also support automated runtime checks to

verify that these constraints are upheld. If a method

violates its frame conditions, violations are detected

immediately, improving debugging and maintainabil-

ity. Overall, frame conditions strengthen DbC by pro-

viding clearer and more enforceable speciﬁcations.

Although conceptually simple, implementing run-

time frame checks involves signiﬁcant challenges.

Capturing an object’s initial state and comparing it

post-execution requires true cloning, which is non-

trivial due to reference semantics. For example, in

the withdraw() method:

void withdraw(long amount) {

var preState = captureState(this);

...

assert(ensureFrame(

preState, captureState(this)));

}

Assigning this to preState only stores a ref-

erence, not a copy. Modiﬁcations affect both, so

accurate preservation requires cloning, which many

classes lack. Without built-in support, developers

must implement custom cloning, which is error-prone

and inconsistent.

Dynamic and optional typing in modern languages

like Dart complicates frame checks further. Lacking

explicit type information hinders compile-time gener-

ation of reliable check code. For example, enforcing

immutability of unspeciﬁed ﬁelds in withdraw() be-

comes difﬁcult without clear type declarations. Frame

conditions also become complex with nested or com-

posite objects. Determining whether to clone just the

top-level object or its entire reference graph impacts

both correctness and performance. For instance, ver-

ifying that only the balance changes while the as-

sociated customer object remains untouched requires

deep cloning and precise speciﬁcation. This also in-

volves deciding between reference and value equal-

ity. Finally, runtime frame checks can introduce sig-

niﬁcant overhead. Capturing and comparing object

states—especially when dealing with deep or com-

plex structures—may impact performance, particu-

larly in systems that require high throughput. Balanc-

ing the need for rigorous frame enforcement with per-

formance considerations remains a key challenge, al-

though this issue is not addressed in the current study.

4 OUR APPROACH

We introduce custom annotations to specify frame

conditions for methods and translates these condi-

tions into runtime checks. These annotations allow

programmers to declare which elements of a pro-

gram’s state may be modiﬁed during method execu-

tion while ensuring that all other elements remain

unchanged. For example, consider the annotated

withdraw() method and its instrumented code:

@Modifies(’balance’)

void withdraw(long amount) {

var preState = state;

state.frame(’this.balance’);

...

assert(preState == state);

}

get state => State({’this’:

{’balance’: balance, ... }});

In this example, the @Modifies annotation spec-

iﬁes that only the balance ﬁeld may be modiﬁed,

while all other elements of the state must remain un-

changed. The skeletal code generated from the an-

notation shows how the annotation enables a runtime

check. Before the method executes, the current state

is captured and stored in a local variable preState.

A getter method, state, constructs a state model, or

a snapshot of the current state, consisting of name-

value pairs. The frame() method of the State frame-

work class is used to capture information about the

mutability of state elements. After the method ex-

ecution, the stored initial state (preState) is com-

pared with the ﬁnal state to ensure compliance with

the frame conditions. The overridden equality (==)

operator is used to compare only those state elements

that should not have been changed—i.e., elements not

listed in the @Modifies annotation. We can also in-

troduce class-speciﬁc state model classes along with

methods to specify and check frame conditions (see

Section 4.3). One limitation of our approach is that

intermediate state changes cannot be detected. While

this is acceptable in sequential environments, it may

be unsuitable for concurrent settings where interme-

diate changes could be observed.

ICSOFT 2025 - 20th International Conference on Software Technologies

380

4.1 State and Object Models

Frame condition checks compare a program’s state

before and after method execution to verify compli-

ance with speciﬁed constraints. The pre-state cap-

tures the program state before execution; the post-

state, after. A frame condition declares which parts

of the pre-state may change—implicitly asserting that

the rest must remain unchanged. In our approach,

the pre-state acts as a pattern against which the post-

state is matched. Mutable parts are explicitly marked,

and runtime checks conﬁrm the post-state conforms to

this pattern. The State class constructs abstract state

snapshots, with its frame() method marking mutable

ﬁelds, ensuring side-effect-free runtime check.

A program state includes snapshots of all acces-

sible objects within a method’s scope: the receiver

(this), parameters, and global references. While

the receiver’s state can often be generated at com-

pile time (refer to Section 4.3), dynamic or optional

typing may require constructing states for parame-

ters and globals at runtime. We model a program

state as a mapping from variable names to object

states. For example, in a board game method such as

placeStone(Player player, int x, int y), the rel-

evant program state might include (see Section 6):

{this : this, player : player, x : 10, y : 12}

Objects such as boards or players may have nested

structures. A program state captures top-level objects,

while sub-objects represent nested states. Each object

state maps ﬁeld names to values or other object states,

forming a hierarchical model. For example, a Game

object with a Board and two Player objects (one of

whom has the turn) appears in Figure 1.

[0: ,1: ]

{name: ‘Black’}

{

board: , players: , turn: }

{name: ‘White’}

Figure 1: An object with nested structures.

The pre-state model serves two main purposes:

(a) identifying which ﬁelds may be modiﬁed and (b)

preserving the values of ﬁelds that must remain un-

changed. To indicate that a ﬁeld is mutable, we use a

wildcard object (* to represent any value, which sim-

pliﬁes the post-state comparison.

{board : board, players : players, turn : ∗}

In this example, the pre-state model—augmented

with frame conditions—allows changes to turn, while

requiring board and players to remain unchanged.

4.2 Custom Annotations

We introduce custom annotations to specify frame

conditions. The primary one, @Modifies, declares

which parts of the program state a method may mod-

ify. All other state parts are implicitly required to re-

main unchanged. State parts are referenced using ﬁeld

notation, with comma-separated entries:

@Modifies(’this.places[x][y]’)

void placeStone(Player player, int x, int y)

As explained, we model objects abstractly as

name-value maps: { f

: v

, . . . , f

: v

}. Names iden-

tify observable parts of an object’s state. For exam-

ple, this.places[x][y] accesses a speciﬁc element

in a nested list. In Dart, object ﬁelds can also be ac-

cessed through user-deﬁned getters and query meth-

ods. Our approach supports referencing such methods

in @Modifies, making frame conditions applicable re-

gardless of how the state is accessed.

@Modifies(’this.getPlace(x,y)’)

void placeStone(Player player, int x, int y)

4.2.1 Composite Objects

Objects often have nested structure. We use path

expressions like x.y.z to refer to subcomponents.

To improve expressiveness, we may allow limited

wildcards—e.g., x.p* for all ﬁelds of x starting with

p. Future work may explore the beneﬁts of such pat-

terns.

4.2.2 Collections

Collections—arrays, lists, sets, maps—are accessed

using index notation (e.g., a[10]), which maps to get-

ter/setter methods. Dart uses lists for arrays, mak-

ing both interchangeable. To reference collection el-

ements in frame conditions, we allow: (a) speciﬁc el-

ements: a[1, 10, size], (b) ranges: a[1..10], and

to cover insertions and deletions, capturing dynamic

updates.

4.2.3 State Annotations

At runtime, a frame condition ensures that all framed

state parts remain unchanged:

∀x • x ∈ State

pre

∧ x ∈ Framed ⇒ x

post

≡ x

pre

In practice, the relevant objects are those acces-

sible in the pre-state, such as this and parameters.

Deep references via nested calls are harder to track

Enhancing Design-by-Contract with Frame Speciﬁcations

381

and often irrelevant. To manage this, we provide

annotations to include or exclude speciﬁc state ele-

ments: (a) explicit state such as public ﬁelds are in-

cluded by default and (b) implicit state such as getters

and observer methods must be explicitly annotated.

Supported annotations include: (a) @State.includes

and @State.excludes to control what counts as state

and (b) @State(’name’, ’expression’) to deﬁne cus-

tom state elements. For example, if player stats are

fetched externally:

@State(’stat’, ’getStat(player)’)

@Modifies(’getPlace(x,y), stat.moves’)

void placeStone(Player player, int x, int y)

Annotations can also deﬁne abstract state prop-

erties that encapsulate multiple ﬁelds into a single

logical unit. For example, a player’s full name—

composed of ﬁrst, middle, and last name ﬁelds—can

be treated as one abstract state called name. This

abstraction simpliﬁes frame conditions by allowing

related ﬁelds to be referenced collectively—for in-

stance, referring to name instead of listing each indi-

vidual component.

@State(’name’, ’"$_first $_middle $_last"’,

parts: ’_first, _middle, _last’)

@Modifies(’name’)

void changeName( ...)

4.3 Translation to Runtime Checks

We translate frame conditions into runtime checks

through a combination of compile-time instrumen-

tation and runtime reﬂection. This hybrid approach

accommodates Dart’s optional typing system, where

types may be implicit or only known at runtime. At

compile time, methods annotated with frame condi-

tions are identiﬁed, and instrumented code is inserted

to enforce checks. These checks capture the method’s

initial state and verify it afterward against the spec-

iﬁed frame constraints. When static type informa-

tion is available (e.g., for the receiver this), it guides

the generation of efﬁcient code to access the object’s

state. Otherwise, the code relies on reﬂection to infer

and access the structure dynamically.

Instrumentation performs four key steps: (a) iden-

tify accessible objects by determining which objects

the method can access (receiver, parameters, rele-

vant globals), using scope analysis and annotations,

(b) capture pre-state by recording the initial state of

all identiﬁed objects, (c) apply frame constraints by

marking which parts of the state are allowed to change

based on the annotation, and (d) verify post-state by

comparing the ﬁnal state with the initial state to en-

sure only allowed changes occurred.

Consider a method annotated with a frame condi-

tion:

@Modifies(’board.getPlace(x,y),

currentPlayer’)

void placeStone(int x, int y)

This method modiﬁes only a speciﬁc board posi-

tion and the current player. The instrumented code

might look like:

void placeStone(int x, int y) {

// capture the pre-state.

State preState = State({’this’:

{’board’: board, ’players’: players}});

assert(preState.capture({’x’:x, ’y’:y})));

// augment with frame condition.

assert(preState.frame(

’this.board.getPlace(x,y),’

’this.currentPlayer’));

// execute original code

// verify the post-state.

assert(preState == State(...)

..capture({’x’: x, ’y’: y}));

}

The code begins by capturing the pre-state using

a State object, which stores the initial values of rel-

evant objects. A call to preState.capture() extends

this snapshot to include parameters x and y, although

this is technically unnecessary for value types like

int in Dart. This capture occurs within an assert

statement to avoid runtime overhead in production.

Frame conditions are then applied to identify mutable

elements—in this case, this.board.getPlace(x, y)

and this.currentPlayer—which are marked using

wildcard objects. These wildcards, handled by the

frame() method, signal permissible changes (see Sec-

tion 5). After executing the method body, the instru-

mented code captures the post-state and asserts that

only allowed modiﬁcations occurred, using the over-

riden == operation.

4.3.1 Object Comparison and Equality

To detect changes in object states, we compare pre-

and post-state values using a customizable equality

mechanism. Dart supports both reference equality

(identical()) and value equality (==), and our sys-

tem allows developers to choose the method for each

ﬁeld or object via annotations:

ICSOFT 2025 - 20th International Conference on Software Technologies

382

@State(’currentPlayer’, ’_currentPlayer’,

equality=identity)

final Player _currentPlayer;

The equality parameter accepts built-in compar-

isons (==, identical()) or custom functions. Devel-

opers can also specify defaults at the class or appli-

cation level. The equality choice affects how object

states are captured: (a) reference equality stores only

object identities, (b) value equality requires shallow

or deep copies, and (c) custom equality may need tai-

lored cloning, which can also be annotated. Snap-

shots for comparison may be captured eagerly (dur-

ing pre-state initialization) or lazily (when applying

frame constraints), optimizing storage. Choosing a

default comparison is also important. Although many

developers expect value equality, reference equality is

faster and avoids object copying. Since Dart treats all

values as objects, capturing everything as value state

would be costly. We thus default to reference equality,

allowing overrides as needed.

5 IMPLEMENTATION

We developed a proof-of-concept prototype for frame

annotations in Dart, targeting cross-platform mobile

apps. Dart was chosen for its platform reach and lan-

guage features like optional typing, which pose both

challenges and opportunities for design-by-contract

(DbC) and frame conditions. The prototype currently

supports basic annotations such as @Modifies and

@State. Our implementation leverages several public

Dart packages: (a) source_gen for automating code

generation from frame annotations via custom gener-

ators, (b) build for orchestrating generator execution

during compilation, and (c) analyzer for performing

static code analysis.

A key challenge was Dart’s optional typing. We

addressed this with a hybrid approach that combines

compile-time instrumentation and runtime reﬂection.

When type information is available, the tool infers ob-

ject structures and generates optimized code. Other-

wise, it falls back on runtime inspection. For example,

given known type information, the tool generates:

State preState = State({’this’:

{’board’: board, ...}});

The structure of this is inferred at compile time.

Its ﬁelds (e.g., board) are included as name-value

pairs. If deeper abstraction is needed at runtime, re-

ﬂection can construct nested state models.

To enforce frame conditions, we compare the ﬁnal

program state against the initial snapshot (preState).

To facilitate this comparison, ﬁelds marked mutable

in the initial state are replaced with wildcards using

the frame() method of the State class, which ap-

plies transformations via reﬂection. For example, for

the @Modifies(’this.board.getPlace(x,y)’) clause,

the following code is generated:

preState.frame(’this.board.getPlace(x,y)’);

This method traverses the preState state, locating

the speciﬁed path and replacing it with a wildcard. If

intermediate objects like board are not already mod-

eled as states, they are dynamically converted:

’board’: State({’getPlace(x,y)’: *, ...})

This ensures only declared changes are allowed,

and any undeclared mutations can be detected. If a

composite object isn’t pre-modeled, its state is built at

runtime to preserve consistency and isolation of side

effects. At the core is the State class, which captures

and compares program states. It supports composite

structures, applies wildcard logic for mutable ﬁelds,

and veriﬁes frame compliance.

For production, all instrumented code is encapsu-

lated within assert statements. Dart removes these in

release mode (--release), ensuring no runtime over-

head. Tree-shaking further eliminates unused code,

resulting in efﬁcient builds.

Figure 2: Screenshot of Omok game.

6 PRELIMINARY EVALUATION

To evaluate the effectiveness of our annotation-based

approach, we conducted a small case study using a

Dart/Flutter implementation of Omok (also known

as Gomoku), a two-player strategy game played on

a 15 × 15 grid (see Figure 2). Players take turns

placing stones in an attempt to form an unbroken

line of ﬁve—vertically, horizontally, or diagonally.

We compared our approach to a previously proposed

assertion-based method (Cheon et al., 2024), in which

frame speciﬁcations are manually encoded as exe-

cutable assertions within the source code to enable

runtime checks.

Enhancing Design-by-Contract with Frame Speciﬁcations

383

The game logic was encapsulated in three main

classes—Board, Player, and Game—totaling 256

source lines of code (SLOC). These classes deﬁned

21 methods. To compare the annotation and asser-

tion approaches, we speciﬁed frame properties for all

methods, even though full coverage is uncommon in

practice. Manually adding frame assertions increased

code size by 59% to 408 SLOC, while the annotation-

based version required only 284 SLOC—an 11% in-

crease (see Table 1).

Table 1: Size complexities.

SLOC Increase (%)

Base code 256 N/A

Assertion 408 59

Annotation 284 11

These results show that annotations signiﬁcantly

reduce the overhead of specifying frame properties,

making the code more concise and maintainable. The

declarative style eliminates much of the boilerplate re-

quired by manual assertions.

Below is an excerpt of the Game class using our

annotation-based approach to specify which parts of

the state may be modiﬁed:

class Game {

@State(’board’)

final Board _board; // other fields ...

@Modifies(’this.* except players’)

void newGame() { ... }

@modifiesNothing

Player get currentPlayer => _currentPlayer;

@Modifies(’currentPlayer’)

Player changePlayerTurn() { ... }

@Modifies(’players[1]’)

set opponentPlayer(Player opponent) { ... }

@Modifies(’board.places[x][y],

board.winRow, currentPlayer’)

Outcome makeMove(int x, int y) { ... }

// other methods ...

}

In this example, the newGame() method modiﬁes

all ﬁelds except players. The @modifiesNothing

shorthand is used for the read-only currentPlayer

getter. Given that a majority of methods (57% in

our prior study (Cheon et al., 2024)) are observers,

this annotation simpliﬁes speciﬁcations while im-

proving clarity. Methods like changePlayerTurn()

and opponentPlayer() illustrate how annotations

can precisely limit modiﬁcations to speciﬁc ﬁelds,

including individual elements (e.g., players[1]).

The makeMove() method demonstrates ﬁne-grained

speciﬁcation by allowing updates to only relevant

board state components—places[x][y], winRow—

and currentPlayer. Composite objects such as

board are treated abstractly, referencing only select

internal state elements rather than the entire object.

Although our preliminary evaluation focused only

on code size, the results demonstrate that annotations

offer a practical and scalable approach for specifying

and enforcing frame properties in Dart. By reducing

source lines of code and decoupling frame speciﬁca-

tions from method bodies, annotations improve code

maintainability. This is particularly advantageous in

optionally typed languages like Dart, where annota-

tions provide a ﬂexible mechanism for modeling state

and mutability. When embedded directly in the code-

base, frame annotations promote systematic manage-

ment of state changes, thereby enhancing code clarity

and minimizing unintended side effects.

Despite these beneﬁts, several open challenges re-

main. One issue involves modeling state using get-

ters, which is often necessary when dealing with en-

capsulated internal state—especially in third-party li-

braries or cloud-backed objects. However, using mul-

tiple getters to represent related aspects of state can

lead to redundancy or ambiguity. A promising direc-

tion is to group related getters into uniﬁed state ab-

stractions, simplifying frame conditions and improv-

ing readability. Another challenge lies in handling

call-by-value semantics. In Dart, primitive types like

int are passed by value, and any modiﬁcations within

a method are local. However, reference types still al-

low mutation of the underlying object, which can re-

sult in visible side effects outside the method scope.

Frame speciﬁcations must therefore distinguish be-

tween changes to parameter references and mutations

to the objects they reference. Additional complex-

ity stems from the distinction between reference and

value models. Frame conditions must clarify whether

a reference itself (e.g., a ﬁeld like board) may be

reassigned, or whether only its internal state (e.g.,

places and winRow) may be modiﬁed. This distinc-

tion is crucial for accurately expressing permissible

state changes and maintaining consistent behavior.

Inheritance further complicates the speciﬁcation

of frame properties. It raises design questions such

as whether subclasses should only extend the abstract

state deﬁned by their superclasses or be allowed to

modify inherited state components. Similarly, when

overriding methods, should subclasses be required to

specify frame conditions that are at least as restric-

tive as those in the superclass? Balancing extensibil-

ICSOFT 2025 - 20th International Conference on Software Technologies

384

ity with contract integrity is essential for safe and pre-

dictable object-oriented design.

7 CONCLUSION

We presented an annotation-based approach for in-

tegrating frame properties into Design by Contract

(DbC) in Dart, with a focus on runtime veriﬁcation. A

key contribution of our approach is the use of an ab-

stract representation of object states, modeled as tu-

ples, to ensure that runtime checks do not introduce

unintended side effects. This abstraction maintains

a clean separation between program logic and state

management. Additionally, our method supports both

statically and dynamically typed languages, enabling

optional typing through a hybrid of compile-time and

runtime mechanisms. By adding frame conditions in

annotations, our approach can reduce code complex-

ity, enhance maintainability, and simplifyes the veri-

ﬁcation process.

As part of future work, we plan to evaluate our

technique on larger and more complex codebases to

better assess its effectiveness, scalability, and broader

impact on veriﬁcation and validation, beyond just re-

ducing code size. We also intend to explore how well

the approach extends to key object-oriented features

such as inheritance, method overriding, and polymor-

phism to ensure its robustness in diverse design con-

texts. Finally, we aim to reﬁne our prototype into a

practical and user-friendly tool to support developers

in writing safer, more maintainable code.

REFERENCES

Amusuo, P. C., Sharma, A., Rao, S. R., Vincent, A., and

Davis, J. C. (2022). Reﬂections on software failure

analysis. In ACM Joint European Software Engineer-

ing Conference and Symposium on the Foundations

of Software Engineering (ESEC/FSE), pages 1615–

1620, Singapore.

Borgida, A., Mylopoulos, J., and Reiter, R. (1995). On

the frame problem in procedure speciﬁcations. IEEE

Transactions on Software Engineering, 21(10):785–

798.

Bracha, G. (2016). The Dart Programming Language.

Addison-Wesley.

Chalin, P. (2014). Ensuring that your Dart will hit the

mark: An introduction to Dart contracts. In Interna-

tional Conference on Information Reuse and Integra-

tion, pages 369–377, San Francisco, CA.

Cheon, Y., Leavens, G. T., Sitaraman, M., and Edwards, S.

(2005). Model variables: Cleanly supporting abstrac-

tion in design by contract. Software: Practice and

Experience, 35(6):583–599.

Cheon, Y., Liu, B., and Rubio-Medrano, C. (2024). As-

serting frame properties. In International Conference

on Software Technologies (ICSOFT 2024), pages 145–

152, Dijon, France.

Darvas, A. and Leino, K. R. M. (2007). Practical reasoning

about invocations and implementations of pure meth-

ods. In International Conference on Fundamental Ap-

proaches to Software Engineering, pages 336–351.

Gazzola, L., Mariani, L., Pastore, F., and Pezze, M. (2017).

An exploratory study of ﬁeld failures. In IEEE In-

ternational Symposium on Software Reliability Engi-

neering (ISSRE), pages 67–77.

Hahnle, R., Schmitt, P. H., and Beckert, B. (2007). Veriﬁca-

tion of Object-oriented Software: The Key Approach.

Springer.

Hatcliff, J. and Dwyer, M. (2001). Using the Bandera tool

set to model-check properties of concurrent java soft-

ware. In CONCUR 2001–Concurrency Theory: In-

ternational Conference, pages 39–58, Aalborg, Den-

mark.

Kassios, I. T. (2006). Dynamic frames: Support for fram-

ing, dependencies and sharing without restrictions. In

FM 2006: Formal Methods: 14th International Sym-

posium on Formal Methods, pages 268–283, Hamil-

ton, Canada.

Leino, K. R. M. (1998). Data groups: Specifying the modi-

ﬁcation of extended state. In ACM SIGPLAN Confer-

ence on Object-Oriented Programming, Systems, Lan-

guages, and Applications, pages 144–153.

Leino, K. R. M. and Muller, P. (2006). A veriﬁcation

methodology for model ﬁelds. In Programming Lan-

guages and Systems: 15th European Symposium on

Programming, pages 115–130, Vienna, Austria.

Leino, K. R. M. and Nelson, G. (2002). Data abstraction and

information hiding. ACM Transactions on Program-

ming Languages and Systems (TOPLAS), 24(5):491–

553.

Marche, C., Paulin-Mohring, C., and Urbain, X. (2004).

The Krakatoa tool for certiﬁcation of Java/JavaCard

programs annotated in JML. Journal of Logic and Al-

gebraic Programming, 58(1-2):89–106.

Meyer, B. (1992). Applying ’design by contract’. IEEE

Computer, 25(10):40–51.

Meyer, B. (1997). Object-Oriented Software Construction.

Prentice Hall, Upper Saddle River, NJ, 2nd edition.

Mitchell, R. and McKim, J. (2001). Design by Contract, by

Example. Addison-Wesley, Boston, MA.

Ozkaya, M. (2019). Teaching design-by-contract for the

modeling and implementation of software systems.

In International Conference on Software Technologies

(ICSOFT), pages 499–507.

Ozkaya, M. and Kloukinas, C. (2014). Design-by-contract

for reusable components and realizable architectures.

In ACM SIGSOFT Symposium on Component-Based

Software Engineering (CBSE ’14), pages 129–138.

Enhancing Design-by-Contract with Frame Speciﬁcations

385
