Dataset Watermarking Using the Discrete Wavelet Transform

Mike P. Raave

1 a

, Devris¸

Is¸ler

2,3 b

and Zekeriya Erkin

1 c

Cyber Security Group, Delft University of Technology, Van Mourik Broekmanweg, Delft, The Netherlands

IMDEA Networks Institute, Madrid, Spain

Universidad Carlos III de Madrid, Madrid, Spain

Keywords:

Watermarking, Data Ownership, Discrete Wavelet Transform.

Abstract:

In this work, we focus on watermarking time series datasets and explore one of the techniques known from

audio-watermarking, namely Discrete Wavelet Transform (DWT) based watermarking, to investigate its ef-

fectiveness. We adapt (Attari and A. Shirazi, 2018) and embed a bit stream into a time series dataset by

calculating the DWT coefﬁcients and modifying their magnitudes for embedding. Our experimental results

on two real-world datasets show good robustness against a small range of data modiﬁcation attacks but lack

capability in larger-scale attacks. We believe that our work could initiate a new research direction on dataset

watermarking using well-known techniques from signal processing.

1 INTRODUCTION

Watermarking is a well-known technique for protect-

ing data ownership upon unauthorized distribution.

Watermarking generally consists of two main algo-

rithms: 1) embedding; and 2) extraction. Embed-

ding allows an owner to embed a watermark into a

form of data using a watermarking secret (e.g., a se-

cret bit string) and produces a watermarked version

of the data without degrading the data utility signif-

icantly (e.g., minimizing the amount of distortion on

median and average). In extraction, the owner proves

its ownership of a suspected dataset, even if the data is

modiﬁed, by reconstructing, or extracting, the embed-

ded watermark. When the watermark is successfully

extracted, the owner can prove the ownership by ver-

ifying their watermark.

Watermarking has been well-studied in the con-

text of multimedia data (Malanowska et al., 2024),

database (Rani and Halder, 2022; Panah et al., 2016)

, and other type of datasets (

Is¸ler et al., 2024).

Although media watermarking, e.g. image, au-

dio, is more advanced than non-media watermarking,

there are only a few studies analyzing the implica-

tions of media watermarking on non-media real-world

datasets. For example, (Pham et al., 2017) attempt to

https://orcid.org/0009-0003-0751-3773

https://orcid.org/0000-0003-4895-8827

https://orcid.org/0000-0001-8932-4703

watermark medical time-series datasets using DWT-

based watermarking. They deploy an ML model to

retrieve a watermark formed as a binary image em-

bedded into the dataset. Due to its use case, i.e., more

effective diagnoses, the reconstruction of medical sig-

nals is vital. Therefore, their approach is not directly

applicable to other time series applications. (Mae-

sen et al., 2023), on the other hand, watermark ma-

chine learning datasets by applying singular value de-

composition based image watermarking which cause

around 0.1% accuracy loss. However, their approach

is not generic and cannot be directly applied to the

datasets such as time-series.

Considering time-series and audio data, they have

common characteristics such as both data types are a

form of frequency and are measured over time. There-

fore, in this work, we explore the idea of applying

a transform domain media watermarking algorithm,

i.e., DWT-based audio watermarking, to non-medical

time series data. Transform domain algorithms are

more robust and resistant to attacks (Guo et al., 2023;

Attari and A. Shirazi, 2018) while ensuring better im-

perceptibility compared to spatial domain algorithm,

e.g., Least Signiﬁcant Bit. In consequence, we chose

DWT-based audio watermarking (Attari and A. Shi-

razi, 2018) since it is a frequency domain watermark-

ing algorithm and makes good use of the signal char-

acteristics (Guo et al., 2023).

Our Approach. To be able to watermark a time-

series dataset that may contain multiple signals and

676

Raave, M. P.,

I¸sler, D. and Erkin, Z.

Dataset Watermarking Using the Discrete Wavelet Transform.

DOI: 10.5220/0013556300003979

In Proceedings of the 22nd International Conference on Security and Cryptography (SECRYPT 2025), pages 676-681

ISBN: 978-989-758-760-3; ISSN: 2184-7711

several covariates (which is not the case for media sig-

nals) using DWT-based audio watermarking (Attari

and A. Shirazi, 2018), we modiﬁed their algorithm

to suit the type and range of time-series data. We split

the data into frames and embed a Barker code into

each frame to counter single-range cropping attacks

and enhance performance. Afterwards, we use the

magnitude of the DWT coefﬁcients of the data to em-

bed the watermark. Additionally, we proposed new

attacks to improve the robustness of the modiﬁed al-

gorithm after careful investigation since the original

algorithm’s use-case scenario is changed.

Our foremost contribution is to apply an audio wa-

termarking technique based on DWT to non-media

time series datasets using two real-world datasets. We

measure the distortion in terms of data statistics in-

troduced by watermarking. Based on our experimen-

tal ﬁnding, our algorithm modiﬁes the average of the

datasets by approximately 0.5%. Hence, adjusting

the watermarking parameters, the owner can satisfy

its desired imperceptibility and robustness. Later, we

evaluate robustness against cropping, scaling, noise

addition, zero-out, and collusion attacks. Our ex-

perimental results show that our algorithm improves

robustness up to 65% data deletion for single-range

cropping attacks and up to a scaling rate of 1.5 for

scaling attacks.

2 RELATED WORK

(Attari and A. Shirazi, 2018) is an SS-based audio

watermarking approach. They watermark an audio

signal using 6

-level DWT coefﬁcients. These co-

efﬁcients are divided into frames, after which a wa-

termark bit is assigned per frame. Per coefﬁcient in

a frame, the closest Fibonacci number to its mag-

nitude is determined. Based on the bit assigned to

the frame, which contains the coefﬁcient, and the Fi-

bonacci number, the magnitude of the coefﬁcient is

changed to either the closest Fibonacci number or one

number higher in the Fibonacci sequence. To extract

the watermark, similar steps as in the embedding pro-

cess are executed frame by frame. If, within a frame,

the majority of the closest Fibonacci numbers to the

coefﬁcients correspond to even positions in the Fi-

bonacci sequence, the extracted watermark bit is 0,

otherwise, it is 1. As the bit stream is randomly gen-

erated, the algorithm is hard to break ensuring a high

level of security. They further analyze the robustness

of their algorithm against various attacks. In addi-

tion, their algorithm is suitable for various applica-

tions since the frame size can be tuned depending on

the underlying watermarking application.

(Fallahpour and Meg

ıas, 2014) propose a similar

algorithm utilizing the Fast Fourier Transform (FFT)

coefﬁcients instead of DWT coefﬁcients and gives

the possibility to tune parameters (e.g., the frequency

band of the signal used for embedding and the frame

size) depending on the required capacity and robust-

ness. As FFT coefﬁcients do not store information

about time, their algorithm is only suitable for au-

dio applications. (Pham et al., 2017) use an image

as a watermark that is scrambled through the Arnold

transformation before embedding to improve robust-

ness. The data itself is down-sampled after the 4

level DWT approximation coefﬁcients are calculated.

Afterwards, the watermark image gets embedded with

a bit of the image per data frame. For extraction, they

use an ML model built from part of the watermarked

data. This algorithm has high robustness against small

forms of cropping, noise addition, ﬁltering and re-

sampling attacks and has good imperceptibility such

that the watermarked data is still usable.

3 WATERMARKING TIME

SERIES USING DWT

Now, we present our watermarking scheme utiliz-

ing (Attari and A. Shirazi, 2018) to watermark time-

series.

3.1 Watermark Embedding

The watermark embedding algorithm, see Algorithm

1, receives the following inputs: a time-series dataset

d formalized as d = {(t

, x

)|i = 1, 2, . . . , N} where N

is the total number of observations in d, and t

is the

timestamp of the i-th observation and x

∈R is the i-th

observation’s value(s),

a bit stream as watermark w,

a reference set re f of numbers with a ﬁxed multipli-

cation rate mult, an integer containing the preferred

DWT level dwt, a frame size for the coefﬁcients f

bin

a frame size for embedding a Barker code f

Barker

and returns a watermarked version of d as denoted by

. w is randomly generated through a pseudorandom

function using a secret seed value as a high entropy

secret. d is split into smaller sections such that w is

embedded into multiple places in d to increase robust-

ness against (un)intentional modiﬁcations. Each sec-

tion n has a ﬁxed size of f

Barker

. Per section n, the data

is split into two lists, n

and n

, such that n

+ n

= n

as in (Shen et al., 2012).

The formalization can be modiﬁed as x

∈ R

where

m ≥ 1 represents the number of variables or dimensions

(univariate if m = 1, multivariate if m > 1).

Dataset Watermarking Using the Discrete Wavelet Transform

677

In n

5-bit Barker codes are embedded in each se-

quence to counter cropping attacks. The relative value

of a Barker code of length 5 has been used as consid-

ered in (Campbell, 1989) which is added to the value

at the corresponding index in n

. The imaginary val-

ues of the Barker code are added in the dataset to

make the process of extracting the watermark more

robust and effective. In order to avoid having imag-

inary values in the dataset, we use n

for the Barker

code and n

for embedding the watermark. For em-

Algorithm 1: Watermark Embedding.

Data: d, f

bin

, f

Barker

, dwt,re f , w

Result: d

1 foreach List n from d with size f

Barker

2 n

= [1, . . . , 1]

Barker

;

3 n

= n −n

;

4 n

[1] = 1 +

√

−1;

5 n

[3] = 1 −

√

−1;

6 c

= ComputeDW T (n

, dwt);

7 for List y in c

with size f

bin

8 f rameNr = the current iteration of the

loop.;

9 w

bit

= w[ f rameNr];

10 for Coefﬁcient c in y do

11 k =

f indPositionClosestNumber(re f , c);

12 if k mod 2 ≡ w

bit

then

13 c = re f [k];

14 end

15 else

16 c = re f [k + 1];

17 end

18 end

19 end

20 n

′

= ComputeIDW T (c

);

21 n = n

+ n

′

;

22 end

23 d

= CombineAll(n);

bedding the watermark in n

, a dwt

-level DWT is

ﬁrst applied to n

and the resulting DWT approxi-

mation coefﬁcients are divided into frames f of size

bin

. Each frame is assigned a bit out of w by calcu-

lating the index of the bit in w: l = ⌊

index o f f

⌋+ 1,

where i represents the index of the coefﬁcient in the

list of approximation coefﬁcients. For each coefﬁ-

cient c, the k

number in re f is found that is closest

to the magnitude of c. To embed the bit, the con-

dition k mod 2 ≡ w[l] is checked. If the condition

is true, the magnitude is changed to the k

number

in re f . If not, it is changed to the (k + 1)

number

in re f . After all coefﬁcients are considered, the in-

verse DWT is applied and n

is merged with the mod-

iﬁed version of n

to get the watermarked data d

Finally, all the sections are concatenated to form d

and {f

bin

, f

Barker

, dwt,re f , w} are securely stored as

watermark secrets.

A few steps in the original algorithm are modi-

ﬁed to improve the performance. First, splitting the

data into lists with size f

Barker

and dividing those lists

n into n

and n

is an improvement to accommodate

the embedding of a 5-bit Barker code in n

to counter

single-range cropping attacks. Second, this algorithm

has no variable values which are optimal for all cases

compared to the original. Thus, the user/owner can

determine the way the variable re f is created and what

the value of f

bin

, f

Barker

and dwt is. The results of

changing these variables can be seen in Section 4.

Algorithm 2: Watermark Extraction.

Data: d

, f

bin

, f

Barker

, dwt,re f

Result: w

′

1 w

′

= [];

2 startIndex = detectBarkerCode(d

, f

Barker

);

3 Take a sub-list with the ﬁrst f

Barker

values

from startIndex as n;

4 n

= [1, . . . , 1]

Barker

;

5 n

= n −n

;

6 c

= ComputeDW T (n

, dwt);

7 for List y in c

with size f

bin

8 for Coefﬁcient c in y do

9 k = f indPositionClosestNumber(re f ,

c);

10 Store k mod 2;

11 if majority-k-values≡0 then

12 w

′

.add(0);

13 end

14 else

15 w

′

.add(1);

16 end

17 end

18 end

19 return w

′

;

3.2 Watermark Extraction

The ﬁrst step in watermark extraction, see Algo-

rithm 2, is to detect the start point of extracting

the watermark from a suspected dataset d

using

⟨f

bin

, f

Barker

, dwt, re f ⟩. The detection is achieved by

ﬁnding the embedded Barker codes at the start of each

section, which are the added imaginary values to the

data. When the start of a section has been found, a list

n is stored from the start index with the next f

Barker

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

678

values. This list is split into sections n

and n

, such

that n

+ n

= n. A dwt

-level DWT is applied to

and the resulting DWT approximation coefﬁcients

are divided into frames with size f

bin

. Each frame y

is used for a form of majority voting to ﬁnd the wa-

termark bit embedded. Hence, for each coefﬁcient

c in a frame, the k

number is found in re f closest

to the magnitude of c. Each k connected to each c

is stored. If the values of k are more often odd than

even per frame, the watermark bit is 1; otherwise, it

is 0. Therefore, the algorithm always uses odd-sized

frames to prevent ambiguity. Once all frames have

been considered, the watermark w

′

is extracted from

the sequence. If w

′

is equal to the input watermark w,

the watermark is successfully detected.

The main change to the extraction algorithm com-

pared to the original is the added step to detect the

Barker code at the start of a section. Since exist-

ing methods offered no clear way to embed and de-

tect Barker codes, we used complex values, which re-

main hidden when the data is visualized. Addition-

ally, the algorithm only analyzes the ﬁrst section from

the starting point, as it offers the highest likelihood

of correct watermark retrieval, especially when the

dataset has been modiﬁed or resized.

4 EXPERIMENTAL SETUP AND

RESULTS

4.1 Setup

Our experimental results are produced on a standard

laptop machine with an Intel(R) Core(TM) i7-9750H

CPU at 2.6GHz with 16.00 GB RAM. We use two

datasets from (Brownlee, 2020): 1) minimal temper-

ature dataset; and 2) sunspots dataset. The sunspots

dataset and the minimal temperature dataset consist of

2800 entries and 3600 entries, respectively. In terms

of the statistics of the datasets, the sunspots dataset

has an average value of 51.3. The minimal tempera-

ture dataset has an average value of 11.2. For our ex-

periments, we evaluate our approach using two main

metrics: 1) imperceptibility; and 2) robustness.

Imperceptibility. As a common practice (Agrawal

and Kiernan, 2002) , we evaluate the imperceptibil-

ity by analyzing the effect of the watermark on each

dataset by measuring the relative changes of the fol-

lowing metrics: 1) the average of the dataset; and 2)

the average absolute change of values.

Robustness. We evaluate the robustness of our ap-

proach against ﬁve attacks: 1) cropping; 2) noise ad-

dition; 3) scaling; 4) zero-out attacks; and 5) collu-

sion attacks. These particular attacks have been cho-

Table 1: Imperceptibility results of the test datasets.

Input Min temp (%) Sunspots (%)

bin

dwt mult avg diff value

chg

avg diff value

chg

11 1 1.2 0.5 8.9 0.7 11.9

11 3 1.2 0.4 8.8 0.6 11.9

11 5 1.2 0.8 8.9 1.0 19.4

11 3 1.4 1.0 16.1 2.3 22.7

15 1 1.2 0.5 8.9 0.7 11.9

sen since we focus on formatted datasets. As a re-

sult, these datasets would be most vulnerable to stan-

dard data modiﬁcation attacks as the ones mentioned

above. In the original algorithm (Attari and A. Shi-

razi, 2018), there are results for a form of cropping

and random noise addition attack which we can com-

pare with this algorithm. For the other three attacks

there are no results to compare with from the orig-

inal algorithm as these attacks are more typical for

time series data compared to audio data. Regarding

the value of f

Barker

, it was found that the smaller the

value is, the more perceptible the watermark will be

as a change in DWT values in a small piece of data

has a larger effect on the resulting value than with a

larger value of f

Barker

. The larger the value is, the less

robust the watermark is as a smaller part of the data

needs to be modiﬁed for the watermark to be irretriev-

able. The only constraint for f

Barker

is that the value

must be smaller or equal to the size of the dataset.

However, we have run all tests with f

Barker

= 600, as

this provided good imperceptibility and did not have

any negative effects on the robustness of the algorithm

compared to lower values of f

Barker

4.2 Results

We discuss the experimental results based on the

aforementioned setting and metrics. We run our ex-

periments 100 times per instance and take the mean

of total computations.

4.2.1 Imperceptibility

We present the complete results of imperceptibility

experiments in Table 1 and brieﬂy discuss the results

due to limited space. The complete results can be

found in the full version (Raave et al., 2024).

Effect of f

bin

. Our results show that when we increase

bin

, the effect on the statistics of the datasets are not

signiﬁcant as the average difference and average value

do not change for both datasets. Thus, our approach

does not distort data drastically.

Effect of dwt. When dwt is increased, we can see

in the results that the relative difference in the av-

Dataset Watermarking Using the Discrete Wavelet Transform

679

erage value and the average change per value in the

dataset increases noticeably when dwt = 5 for all

three datasets. Between dwt = 1 and dwt = 3 each

dataset does not show signiﬁcant differences, which

shows that both values should achieve the best possi-

ble results when chosen in the algorithm.

Effect of mult. When mult is increased, all of the re-

sulting values increase with a signiﬁcant factor. This

effect can be observed in both datasets.

4.2.2 Robustness

For the baseline for our robustness analysis, we chose

the following values: f

bin

= 11, dwt = 1 and mult =

1.2, as those values gave the most consistently good

results regarding watermark extraction and provided

a good trade-off between imperceptibility and robust-

ness. However, optimizing these parameters is an in-

triguing open problem as we did not include more val-

ues of f

bin

, dwt, and mult, since the detection rate of

the watermark would drop below a 100% when the

values deviated too far from the set baseline. For ro-

bustness, the following data modiﬁcation attacks have

been chosen to focus on: cropping, noise addition,

scaling, zero-out, collusion attacks. These attacks

were tested with 10%, 30% and 50% of the dataset

being modiﬁed. These modiﬁcations were done on

randomly chosen indexes. Higher than 50% modiﬁ-

cation led to a conversion of a Bit Error Rate (BER)

of 50%. As the algorithm only considers zeros and

ones as watermarks, it cannot be distinguished from

that point whether the algorithm randomly guesses,

as the correct guess for a watermark bit is 50%, or the

algorithm makes more mistakes for a different reason.

Below we discuss the results per attack.

Table 2: Robustness results of the real world datasets.

Min temp (%) Sunspots (%)

Crop

Edit

Insert

Zero

Crop

Edit

Insert

Zero

10 35 10 45 10 35 15 40 15

30 50 45 50 40 50 40 50 40

50 50 50 50 45 50 50 50 50

Cropping Attack. Two types of cropping attacks were

considered: removing a continuous range of data and

randomly deleting samples. To resist these, the al-

gorithm uses Barker codes for synchronization. By

choosing a frame size f

Barker

, the watermark is em-

bedded in each frame, increasing the chance of recov-

ery. A value of f

Barker

= 600 (for datasets of ∼3000

entries) offers a good balance between robustness and

imperceptibility. With this setup, up to 65% of the

data can be removed in one continuous block, and

the watermark is still fully recoverable. However, the

method is less effective against random deletion. As

shown in Table 2, removing 10% of samples at ran-

dom results in a BER of 35%, only slightly better than

random guessing (50%).

Random Noise Addition Attack. For adding noise to

the data, two variants of this attack are chosen to test

with: editing the existing values and inserting new en-

tries into the dataset. For editing existing values the

edited values were restricted to be within the range of

10% of the current value so that it is less perceptible

to others that the data is modiﬁed as shown by Table

2. Table 2 shows that for both datasets, the BER is

relatively low when 10% of the data is modiﬁed. For

larger-scaled attacks, it is more vulnerable.

For inserting values, they were chosen in a similar

way as for editing. The results of these tests can be

found in Table 2. In the table, it can be seen that for

both datasets, the watermark cannot be retrieved reli-

ably anymore. For 10% data modiﬁcation, the BER

is lower than when one would guess the watermark

bits, but not signiﬁcantly lower such that one could

still use the watermarked data in a practical setting.

Zero-Out Attack. A zero-out attack entails that a per-

centage of the data is changed to have a value of zero.

Therefore it is similar to a cropping attack, but the

dataset does not shrink in size in this case. Table 2

shows the results of the experiments. As shown by

Table 2, we observe that for 10% of the datasets be-

ing modiﬁed, the algorithm has a BER of 15%. With

larger-scaled zero-out attacks, this algorithm proves

to be more vulnerable.

Scaling Attack. A scaling attack entails that the data

is being scaled with a certain factor. The results of

this attack being successful were fully dependent on

the value of mult. The tests have been run with multi-

ple values of mult, but 1.6 seemed to give the best re-

sults. We found in our results that for positive scaling

values, the algorithm provides strong robustness up to

50% scaling with a resulting BER of 0%. When the

data is negatively scaled, the algorithm seems to ﬂip

all bits which results in a BER of 100%. When testing

with lower values of mult, the maximal scaling rate

which still resulted in a BER of 0% detection went

down to about 10% positive scaling. When compar-

ing these results to a medical time series watermark

in (Pham et al., 2017) and the audio algorithm (Attari

and A. Shirazi, 2018), our algorithm provides more

robustness in positive scaling, while being less robust

against negative scaling (see our full version (Raave

et al., 2024) for more details).

Collusion Attack. In a collusion attack, an attacker

has access to two or more differently watermarked

versions of the same dataset and attempts to remove

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

680

or obscure the watermarks. This attack assumes a

stronger adversary than other types. To test our mod-

iﬁed algorithm’s robustness, we generated two ver-

sions of the same dataset with different watermarks

and parameters (e.g., f

Barker

, dwt, mult). Our results

show that recovering the watermark or parameters is

difﬁcult, as each one affects the data in a random,

uncorrelated way. Additionally, the use of a high-

entropy secret in generating w prevents the watermark

from being guessed. We will explore more advanced

collusion scenarios involving multiple copies.

5 DISCUSSION

Our imperceptibility tests show that changing f

bin

and

DWT level has minimal impact on output quality, sug-

gesting that a ﬁxed DWT level is not essential for time

series data as it is common in audio watermarking.

For cropping attacks, the use of Barker codes proved

partially effective: with f

Barker

= 600, only one intact

block of 600 values is needed to fully recover the wa-

termark. This outperforms the method in (Attari and

A. Shirazi, 2018), which handles only a 200-sample

removal at the beginning of an audio signal. While

our method remains robust when up to 10% of data is

affected at random, performance drops beyond that.

Unlike in Attari et al.’s audio watermarking, us-

ing a Fibonacci mult of 1.618 in time series data in-

creased perceptibility and had limited robustness ben-

eﬁts. A smaller mult (1.2) worked better, likely due

to the lower value spread in time series compared to

audio. While we use standard distortion metrics, dis-

tortion is highly use-case dependent and inﬂuenced

by attack types. As noted in (

Is¸ler et al., 2024), opti-

mizing and generalizing distortion remains a complex

challenge, which we plan to explore further both the-

oretically and experimentally.

6 FUTURE WORK AND

CONCLUSION

We proposed a novel technique to watermark non-

medical time series by adapting an audio watermark-

ing technique (Attari and A. Shirazi, 2018). We

experimentally showed that our approach is robust

against cropping, scaling, and small-scale randomly

sampled attacks. We also evaluated the effect of wa-

termarking on data utility (imperceptibility) using dif-

ferent multiplication rates. Determining the optimal

parameters for a given time-series dataset is an inter-

esting future direction.

ACKNOWLEDGEMENTS

This paper is supported by the European Union’s

Horizon Europe research and innovation program un-

der grant agreement No. 101094901, the Septon

and 101168490, the Recitals Projects. Devris¸

Is¸ler

was supported by the European Union’s HORIZON

project DataBri-X (101070069).

REFERENCES

Agrawal, R. and Kiernan, J. (2002). Watermarking rela-

tional databases. In VLDB. Morgan Kaufmann.

Attari, A. and A. Shirazi (2018). Robust audio watermark-

ing algorithm based on DWT using ﬁbonacci num-

bers. Multim. Tools Appl.

Brownlee, J. (2020). 7 time series datasets for machine

learning.

Campbell, C. (1989). 13 - coding techniques using linear

saw transducers. In Surface Acoustic Wave Devices

and their Signal Processing Applications. Academic

Press.

Fallahpour, M. and Meg

ıas, D. (2014). Robust audio water-

marking based on ﬁbonacci numbers. In MSN.

Guo, K., Xu, Z., Luo, S., Wei, F., Wang, Y., and Zhang, Y.

(2023). Invisible video watermark method based on

maximum voting and probabilistic superposition. In

ACM MM.

Is¸ler, D., Cabana, E., Garc

ıa-Recuero,

A.., Koutrika, G.,

and Laoutaris, N. (2024). Freqywm: Frequency wa-

termarking for the new data economy. IEEE ICDE.

Maesen, P.,

Is¸ler, D., Laoutaris, N., and Erkin, Z. (2023).

Image watermarking for machine learning datasets. In

ACM Data Economy Workshop, DEC.

Malanowska, A., Mazurczyk, W., Araghi, T. K., Meg

ıas, D.,

and Kuribayashi, M. (2024). Digital watermarking - A

meta-survey and techniques for fake news detection.

IEEE Access.

Panah, A. S., van Schyndel, R. G., Sellis, T. K., and Bertino,

E. (2016). On the properties of non-media digital wa-

termarking: A review of state of the art techniques.

IEEE Access.

Pham, T. D., Tran, D., and Ma, W. (2017). An intelligent

learning-based watermarking scheme for outsourced

biomedical time series data. In IJCNN.

Raave, M. P.,

Is¸ler, D., and Erkin, Z. (2024). Watermarking

time-series data using dwt. TU Delft repository.

Rani, S. and Halder, R. (2022). Comparative analysis of

relational database watermarking techniques: An em-

pirical study. IEEE Access.

Shen, J., Pan, F., and Guo, Y. (2012). Digital audio wa-

termark sharing based on the chinese remainder theo-

rem. In International Congress on Image and Signal

Processing.

Dataset Watermarking Using the Discrete Wavelet Transform

681
