Empirical Evaluation of Memory-Erasure Protocols

Reynaldo Gil-Pons

1 a

, Sjouke Mauw

1 b

and Rolando Trujillo-Rasua

2 c

University of Luxembourg, 6 Avenue de la Fonte, Belval, Luxembourg

Universitat Rovira i Virgili, 26 Avinguda dels Països Catalans, Tarragona, Spain

Keywords:

Security Protocol, Memory Erasure, Malware, Internet-of-Things, Empirical Evaluation.

Abstract:

Software-based memory-erasure protocols are two-party communication protocols where a veriﬁer instructs a

computational device to erase its memory and send a proof of erasure. They aim at guaranteeing that low-cost

IoT devices are free of malware by putting them back into a safe state without requiring secure hardware

or physical manipulation of the device. Several software-based memory-erasure protocols have been intro-

duced and theoretically analysed. Yet, many of them have not been tested for their feasibility, performance

and security on real devices, which hinders their industry adoption. This article reports on the ﬁrst empirical

analysis of software-based memory-erasure protocols with respect to their security, erasure guarantees, and

performance. The experimental setup consists of 3 modern IoT devices with different computational capabili-

ties, 7 protocols, 6 hash-function implementations, and various performance and security criteria. Our results

indicate that existing software-based memory-erasure protocols are feasible, although slow devices may take

several seconds to erase their memory and generate a proof of erasure. We found that no protocol dominates

across all empirical settings, deﬁned by the computational power and memory size of the device, the network

speed, and the required level of security. Interestingly, network speed and hidden constants within the protocol

speciﬁcation played a more prominent role in the performance of these protocols than anticipated based on

the related literature. We provide an evaluation framework that, given a desired level of security, determines

which protocols offer the best trade-off between performance and erasure guarantees.

1 INTRODUCTION

The low-cost characteristics of some classes of IoT

(Internet of Things) devices and the ecosystem in

which they operate make them particularly vulnerable

to malware infection and an attractive target for cyber-

attackers. Defenders, in a context of limited compu-

tational resources, cannot rely on health-monitoring

software installed on the IoT device to ﬁght malware.

Instead, defenders ought to resort to security services

provided by an external agent that, by interacting with

the IoT device and observing its behaviour, can con-

clude whether the device is malware-free.

There exist two fundamental security services to

ensure that computationally-constrained devices are

malware-free: memory attestation and memory era-

sure. The former starts from an expectation on

the contents of a device’s memory and the assump-

tion that its contents are malware-free, followed by

https://orcid.org/0000-0003-1804-3319

https://orcid.org/0000-0002-2818-4433

https://orcid.org/0000-0002-8714-4626

a mechanism to verify the integrity of the device’s

memory. That is, memory attestation checks whether

a device’s memory is in a known safe state. Mem-

ory erasure, instead, replaces the contents of a de-

vice’s memory with random data, effectively remov-

ing all information, including malware, from the de-

vice. Both memory attestation and memory erasure

have their use-cases. Our focus in this article is on

memory erasure, which allows defenders to remove

malware without making assumptions on the contents

of the device’s memory. This service is particularly

useful for updating the memory of a device with new

software securely, allowing the device to be rede-

ployed elsewhere.

Memory-erasure mechanisms that depend on hav-

ing physical access to the IoT device or using ded-

icated secure hardware on the IoT device, such as

a Trusted Platform Module, have the potential to

offer high security assurances. However, the ﬁrst

requirement makes memory erasure unscalable and

time-consuming, while the second requirement makes

memory erasure expensive or infeasible in low-cost

Gil-Pons, R., Mauw, S., Trujillo-Rasua and R.

Empirical Evaluation of Memory-Erasure Protocols.

DOI: 10.5220/0013554800003979

In Proceedings of the 22nd International Conference on Security and Cryptography (SECRYPT 2025), pages 209-220

ISBN: 978-989-758-760-3; ISSN: 2184-7711

209

devices. Mechanisms requiring none of those fea-

tures, which are, hence, suitable for low-cost IoT de-

vices, are called software-based memory-erasure pro-

tocols. In theory, these protocols have the advantage

of being able to operate on low-cost, even legacy, de-

vices. In practice, they have not been thoroughly eval-

uated for their feasibility on off-the-shelf IoT devices.

Before introducing software-based memory era-

sure, it is important to make a distinction between per-

manent memory erasure (a.k.a. data destruction) and

the type of memory erasure we are referring to. Per-

manent memory erasure requires the erasure process

to be irreversible against advanced forensics tech-

niques (Reardon et al., 2013), including those that

rely on physical access to the device. Irreversibility,

however, is not necessarily required for malware re-

moval, hence the literature on memory erasure (Per-

ito and Tsudik, 2010; Karvelas and Kiayias, 2014;

Karame and Li, 2015) where our work ﬁts in does not

aim at irreversibility.

Software-based memory erasure is a two-party

communication protocol executed between a veri-

ﬁer, acting as a powerful computational device, and

a prover, acting as a devise with limited computa-

tional resources. The role of the veriﬁer is to in-

struct the prover to ﬁll its memory with random

data and verify the erasure proof generated by the

prover. Even though several software-based memory-

erasure protocols have been proposed, they have

never been compared within the same experimental

setting. Moreover, those that have been implemented

and tested on real-world devices (Perito and Tsudik,

2010; Karame and Li, 2015; Ammar et al., 2018),

have not made their source-code publicly available

for further scrutiny and analysis. Hence, it is still an

open question how existing software-based memory-

erasure protocols perform on low-cost IoT devices

and how they compare in terms of computational and

communication complexity, erasure guarantees, and

security. This article provides an answer, which we

argue is a necessary step towards the adoption of

software-based memory-erasure protocols by the IoT

industry.

A brief discussion on related work. The special char-

acteristics of constrained IoT devices have pushed

practitioners to ﬁnd the most performant and efﬁ-

cient algorithms for each task. Ultimately, testing the

behaviour of an algorithm requires deploying them

on real devices and conducting performance evalu-

ations. This has been done recently for lightweight

hash functions (Rao and Prema, 2019), cryptographic

algorithms (Silva et al., 2024), and data protection

mechanisms (Lachner and Dustdar, 2019). However,

as pointed out by recent surveys on the topic (Banks

et al., 2021; Kuang et al., 2022), such level of scrutiny

has not yet been achieved for memory erasure and

memory attestation. That is not to say that these pro-

tocols have never been compared with each other. For

example, Aman et al. (Aman et al., 2020) compare

their memory-attestation protocol against three alter-

natives from the literature. In the case of memory

erasure, Karame and Li (Karame and Li, 2015) and

Perito and Tsudik (Perito and Tsudik, 2010) evalu-

ate the performance of their protocols on off-the-shelf

IoT devices, but do not directly compare them, nor

implement other proposals. A common issue of these

examples is the lack of available open-source imple-

mentations, making it hard to reproduce their evalu-

ation and to comprehensively compare existing pro-

posals within a common empirical setting.

Contributions. This article provides the ﬁrst compari-

son and evaluation of software-based memory-erasure

protocols by directly observing and analysing their

performance in a real-world experimental setting. We

claim this to be a necessary step towards their adop-

tion by industry and their deployment in the real-

world. Crucially, we aim at answering the follow-

ing questions about existing software-based memory-

erasure protocols:

1. Can they be implemented in low-cost IoT de-

vices? If so, what is their memory footprint and

execution time?

2. How much is their execution time affected by the

computational power of the device, the size of the

memory to erase, the implementation of the un-

derlying hash function, and the speed of the com-

munication channel?

3. Is there a dominant protocol in terms of perfor-

mance and security, i.e. a protocol that performs

better than the others in all settings? If not, what

are the best trade-offs?

Our experimental setting consists of three off-the-

shelf IoT devices from the microcontroller unit fam-

ily MCU, namely F5529, FR5994 and CC2652. The

ﬁrst one does not have cryptographic accelerator sup-

port, the second one comes with AES built-in, and

the third one supports AES and SHA256. Aiming at

a more comprehensive evaluation, we provided those

three devices with software-based implementations of

various prominent hash functions.

We implemented seven software-based memory-

erasure protocols and evaluated them in terms of per-

formance, security and erasure guarantees. In par-

ticular, we measured the overall time of the proto-

col execution in relation to the speed of the commu-

nication channel, the device’s computational charac-

teristics and the choice of the hash function imple-

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

210

mentation. We placed the obtained performance val-

ues alongside other relevant protocol features, such as

their security and erasure guarantees, with the goal of

determining the protocols offering optimal trade-offs.

Speciﬁcally, given a desired security level, we iden-

tify which protocols strike the best balance between

performance and erasure assurances.

Structure of the article. The next section (Sec-

tion 2) describes existing software-based memory-

erasure protocols, highlights their most relevant fea-

tures, and provides a comparison and analysis based

on those features. The remainder of this article is ded-

icated to extending that analysis with empirical data

on the execution time of memory-erasure protocols,

with the goal of determining their feasibility and pro-

viding a more detailed comparison. Section 3 pro-

vides our experimental setup, Section 4 reports on the

results obtained after running the experiments, and

Section 5 discusses the results. Concluding remarks

are given in Section 6.

2 SOFTWARE-BASED MEMORY

ERASURE: A SURVEY

The earliest software-based protocol for secure mem-

ory erasure was introduced by Perito and Tsudik in

2010 (Perito and Tsudik, 2010). At the start of the

protocol, the veriﬁer sends a fresh random value of

the same size as the prover’s memory. The prover

computes the HMAC of this value, using as key the

last bits received. The security proof of this protocol

relies on the fact that, to compute the HMAC on a ran-

dom value, the prover needs to ﬁrst receive the key.

The proof of security is informal, though, and does

not specify which assumptions the HMAC function

must fulﬁl to make the protocol secure. This proto-

col, in addition, has the drawback of sending over the

network a message as large as the prover’s memory.

An improvement upon Perito and Tsudik’s protocol

in terms of efﬁciency was later proposed by Karame

and Li (Karame and Li, 2015).

To reduce the size of the random value sent over

the network by the veriﬁer, Dziembowski, Kazana

and Wichs (Dziembowski et al., 2011) introduced a

software-based memory-erasure protocol that, given

a nonce of standard size, asks the prover to store in

memory a random labelling function. Ideally, this

step requires the use of the entire memory of the

prover. The veriﬁer then challenges the prover to

quickly give the output of the labelling function on a

number of inputs. Dziembowski, Kazana and Wichs

provide an elegant security proof based on a reduc-

tion to a combinatorial game known as pebbling, plac-

ing the ﬁrst stone for the study of memory-erasure

protocols whose security depends on the structure

of a graph-based labelling function. The drawback

of their protocol is that the computational complex-

ity of building the labelling function is quadratic in

terms of the memory size of the prover, which might

quickly become inefﬁcient as the prover’s memory

increases. This computational complexity was re-

duced by Karvelas and Kiayias (Karvelas and Ki-

ayias, 2014), using a labelling function whose un-

derlying graph has quasilinear size in terms of the

memory size of the prover. A major limitation of

this design is that it can only provably erase

the prover’s memory. This means that Karvelas and

Kiayias’s protocol offers a lower erasure guarantee

than the protocols we have reviewed so far. The work

in (Karvelas and Kiayias, 2014) also introduces an

erasure protocol that is not based on graphs, but on

hard-to-invert hash functions. The security of this

protocol is proven assuming that the adversary cannot

query a hash function during the memory-challenge

phase. We are not aware how this could be enforced

in practice.

A key security assumption made by all software-

based memory-erasure protocols up to 2019 is that

prover and veriﬁer should run the protocol in iso-

lation, i.e. without interference from an external

attacker. This assumption is cumbersome to en-

force successfully for wireless communication, lim-

iting the use of software-based memory erasure to

rather speciﬁc use-cases. Trujillo-Rasua questioned

in (Trujillo-Rasua, 2019) whether such assumption

is necessary, offering a symbolic security proof of a

memory-erasure protocol that uses distance bounding

to thwart collusion between the prover and an exter-

nal conspirator. This work, however, left open the

question of how to bound the probability of success of

an adversary (i.e. malware colluding with an external

conspirator) passing the memory-erasure test without

removing the malware.

In 2024, Bursuc et al. (Bursuc et al., 2024a; Bur-

suc et al., 2024b) introduced the ﬁrst memory-erasure

protocols with provable security bounds that do not

depend on the isolation assumption. Two of the pro-

tocols follow the methodology established in (Dziem-

bowski et al., 2011; Karvelas and Kiayias, 2014),

consisting of the construction of a graph-based la-

belling function and an analysis of the protocol’s se-

curity via a reduction to a graph-pebbling game. The

third protocol is an extension of Perito and Tsudik’s

protocol with a distance-bounding technique. The

goal is to guarantee that the prover does not re-

ceive external help during the execution of the pro-

tocol. This protocol is proven secure unconditionally,

Empirical Evaluation of Memory-Erasure Protocols

211

while those based on graph-based labelling functions

are proven secure within the random oracle model.

Like in (Trujillo-Rasua, 2019), the three protocols

introduced in (Bursuc et al., 2024a; Bursuc et al.,

2024b) use a distance-bounding mechanism consist-

ing of several round-trip-time measurements, each re-

quiring a round of communication between prover

and veriﬁer. The number of round-trip-time measure-

ments thus become a security parameter in these pro-

tocols, which we denote r in Table 1.

The SPEED protocol (Ammar et al., 2018) per-

forms memory erasure using a Trusted Software Mod-

ule (TSM) as a lightweight alternative to hardware se-

curity modules. In practice, it might add a signiﬁcant

overhead to any program running on the platform, as

the software-based memory protection continuously

monitors the platform to ensure memory isolation at

all times. Since memory erasure can start from any

state of the device, it is more desirable to avoid im-

posing constraints on programs running on it. SPEED

uses distance-bounding to ensure that only a nearby

veriﬁer can start the memory-erasure procedure. This

does not make the protocol secure in the presence

of external attackers, unless the security of the TSM

guarantees that the prover device can only communi-

cate with the veriﬁer during the run of SPEED.

We summarize our study of the literature on

software-based memory-erasure protocols in Table 1.

The table shows to what extent each of the protocols

we have discussed satisﬁes the following relevant fea-

tures, as claimed in the literature.

• Proof: There exists a formal proof of security,

which gives security guarantees with mathemat-

ical rigour.

• Prob.: There exists a formula to bound the proba-

bility of success of the attacker given the device

characteristics and protocol parameters. Unlike

asymptotic analysis, this feature allows the ana-

lyst to measure the actual security of the protocol

on a given device.

• No-Isolation: The protocol does not assume that

the device is isolated during the execution of the

protocol, meaning that the protocol resists net-

work attacks to some extent.

• Erasure: The proportion of the device’s mem-

ory that can be erased. Together with security

guarantees, this is the most important feature of

a memory-erasure protocol.

• Time: The time complexity of running the proto-

col.

• Comm.: The communication complexity of run-

ning the protocol.

From Table 1 one can already draw a prelimi-

nary and theoretical comparison of software-based

memory-erasure protocols. The series of protocols

PoSE

light

, PoSE

graph

and PoSE

random

are the only

ones that come with a formal security proof, a bound

on the probability of success of the attacker, and a

mechanism to operate without relying on the isola-

tion assumption. Their erasure guarantee, however, is

not asymptotically close to 1 for realistic values of r.

Further, it is unclear how the parameter r affects their

computational and communicational complexity in

practice. The other two protocols that resist network

attacks (no-isolation) are TR and SPEED. The for-

mer provides no erasure guarantees, though, while the

latter comes with no security proof and has the draw-

back of relying on a device-speciﬁc Trusted Software

Platform that negatively impacts the performance of

all programs running on the device. The DFKP pro-

tocol does ensure full memory erasure while, at the

same time, it comes with a formal security proof.

However, it offers the worst computational complex-

ity amongst all protocols, hinting that it might be a

viable option only for devices with low memory size.

This computational complexity is improved upon by

KK, but at the cost of erasing only a small fraction of

the device’s memory. Lastly, KL and PT offer opti-

mal computational complexity, but offer neither a for-

mal proof of security nor a bound on the adversary’s

success probability.

To enable a more detailed and accurate compar-

ison of the protocols above, it is necessary to obtain

empirical data on their performance (last two columns

of Table 1). That is the goal of the remainder of this

article.

3 EXPERIMENTAL SETUP

In this section we describe the procedure we have fol-

lowed to implement and test the protocols of inter-

est, providing all the necessary details for the repro-

ducibility of the experiments.

3.1 IoT Proving Devices, Veriﬁer Device

and Communication Channel

For our experiments we considered 3 IoT microcon-

trollers produced by Texas Instruments with differ-

ent characteristics: FR5994, F5529, CC2652. These

devices acted as provers in the memory-erasure pro-

tocol. All prover implementations were done in

Portable C, making them usable on any platform or

architecture. To create the binaries, we conﬁgured the

compiler to optimize for code size. A personal Dell

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

212

Table 1: Characteristics of the implemented memory-erasure protocols. The asymptotic bounds for the execution time and

communication complexity are given in terms of the memory size (denoted n) and the number of round-trip measurements

(denoted r). The erasure guarantees of the three protocols in (Bursuc et al., 2024a; Bursuc et al., 2024b) depend on r, n

and a bound p on the desired probability of success of the attacker. As an example, given r = 71, n = 8KB and p = 10

−3

f (r,n, p) = 0.9.

Proof Prob. No-Isolation Erasure Time Comm.

DFKP (Dziembowski et al., 2011) ✓ ✗ ✗ 1 O n

O 1

KL (Karame and Li, 2015) ✗ ✗ ✗ 1 O n O n

KK (Karvelas and Kiayias, 2014) ✓ ✗ ✗

O (n) O1

PT (Perito and Tsudik, 2010) ✗ ✗ ✗ 1 O n O n

PoSE

graph

(Bursuc et al., 2024a) ✓ ✓ ✓ f (r,n, p)

O (n + r) O r

PoSE

light

(Bursuc et al., 2024b) ✓ ✓ ✓ f (r,n, p) On + r O r

PoSE

random

(Bursuc et al., 2024a) ✓ ✓ ✓ f (r,n, p) On + r On + r

TR (Trujillo-Rasua, 2019) ✓ ✗ ✓ ✗ On + r Or

SPEED (Ammar et al., 2018) ✗ ✗ ✓ 1 O n O 1

laptop acted as veriﬁer, running Python 3 implemen-

tations of each protocol. The Bluetooth protocol was

used as communication channel between the veriﬁer

and the prover.

Table 2 depicts the characteristics of each de-

vice, namely memory (code size

+ data size

maximum clock speed, on-device crypto accelerators,

Bluetooth version, architecture, microcontroller unit

family (MCU), and IoT class (Bormann et al., 2014).

Notice that some devices have hardware accelerators.

For these, we also experimented using a hardware-

accelerated version of the hash function.

3.2 Hash Function Implementations

Most software-based memory-erasure protocols in-

voke multiple hash function calls, while at the same

time being independent of the particular hash function

that was implemented. Hence, given their prominent

role, we provide different hash function implementa-

tions to compare their performance and memory re-

quirements.

We selected these functions according to popular-

ity, amenability to software-based implementations,

and applicability to the IoT domain. All of them cal-

culate a digest of 256 bits. The following hash func-

tions were selected:

• ascon (Dobraunig et al., 2021): a sponge-based

hash function selected in the Lightweight Cryp-

tography Standardization Process by NIST

Code size refers to the amount of memory occupied

by the executable code running on an IoT device. This in-

cludes, for example, applications and libraries.

Data size refers to the memory used by the data used

during execution. This includes, for example, variables and

buffers used by the running code.

https://csrc.nist.gov/News/2023/

lightweight-cryptography-nist-selects-ascon

• blake2 (Aumasson et al., 2013): a widely de-

ployed and highly efﬁcient hash function. It was

designed to be especially performant in software

implementations.

• blake3

: a recent improvement on the blake2

hash function which is claimed to be much faster

while offering similar security guarantees. This is

the fastest (in software implementations) crypto-

graphic hash function we could ﬁnd.

• sha256 (Eastlake and Hansen, 2006): a well

known and widely used hash function based on

the Merkle-Damgård construction proposed by

NIST. Up to this day, it is still considered se-

cure, although it is prone to length extension at-

tacks (Tsudik, 1992).

• aeshash

: an unpublished hash function whose

core utilizes AES instructions. It was selected

mainly to check how much speed-up could be

achieved in a device with only an AES accelerator

(FR5994). As far as we are aware, this hash func-

tion has not been thoroughly analysed, so it does

not offer (yet) strong security guarantees, and it is

only used here for the purpose mentioned before.

Table 3 shows the memory footprint (in bytes) of

the hash implementations on each device. The lower

the memory footprint the better, as these bytes cannot

be erased during the execution of the protocol. One

surprising result is that the memory footprint of the

sha256hw function, which uses the hardware acceler-

ator, actually occupies more space than the software-

based implementation sha256. We conjecture this

must be the result of the extra code necessary to ac-

cess the hardware module. In the case of the hash

implementation used by PT, which originally uses an

https://github.com/BLAKE3-team/BLAKE3-specs/

blob/master/blake3.pdf

https://csrc.nist.rip/groups/ST/toolkit/BCM/

documents/proposedmodes/aes-hash/aeshash.pdf

Empirical Evaluation of Memory-Erasure Protocols

213

Table 2: Microcontroller characteristics.

Device Memory Clock Crypto BT Arch MCU IoT

F5529 (128 + 10) KB 25MHz — 2 RISC-16 MSP430 Class 1

FR5994 (256 + 8) KB 16MHz AES 2 RISC-16 MSP430 Class 1/2

CC2652 (352 + 88) KB 48MHz AES,SHA2 5.2 RISC-32 Arm Cortex-M Class 2

HMAC instantiated with sha256, the memory occu-

pied by the hash function is not shown in the table,

because the implementation used was tightly coupled

with the HMAC routine, making it incomparable to

the others.

The memory footprint of each hash function varies

according to the device, due to the use of C implemen-

tations optimized for each architecture. For exam-

ple, the blake2 implementation used for the CC2652

is optimized for the 32 bit architecture, which is not

suitable for the others. For some hash functions this

leads to lower sizes (blake2, blake3 and sha256) in the

CC2652 with a 32bit architecture, or lower sizes (the

rest) in the F5529 and FR5994 with a 16bit architec-

ture. Taking into account the three devices, sha256 is

the hash function with the lowest memory footprint,

followed by ascon and aeshash.

For reproducibility purposes, we remark that, to

measure the memory footprint of the hash function

implementations on each device, we used as baseline

a trivial hash function with minimal memory foot-

print. This allows us to measure the memory foot-

print of a hash function on a device by comparing it

against the implementation of the trivial hash function

on the same device. We measure memory in this way

to ensure (i) that the compiler code optimization rou-

tine does not remove the hash function and (ii) that all

hash functions implementations share the rest of the

program code.

3.3 Protocol Selection

Out of the 9 protocols described in Section 2, we se-

lected 7 protocols for their implementation and evalu-

ation. SPEED (Ammar et al., 2018) was discarded be-

cause it relies on a memory-isolation technique that is

neither open-source nor fully speciﬁed in the original

article. We also discarded the protocol in (Trujillo-

Rasua, 2019) because the protocol speciﬁcation is

given symbolically, abstracting away from important

implementation details, such as the number of round-

trip-time measurements, the size of the nonces, etc.

Even though the author in (Trujillo-Rasua, 2019) of-

fers an instantiation of the symbolic protocol speci-

ﬁcation, it leaves as future work the analysis of its

security and erasure guarantees.

We note that the protocols PoSE

light

, PoSE

graph

and PoSE

random

(Bursuc et al., 2024a; Bursuc et al.,

2024b), depend on an additional security parameter

r that establishes the number of round-trip-time mea-

surements performed by the protocol. For our empiri-

cal setting, we set r = 71, which gives an erasure guar-

antee of 90% of the device’s memory with probability

(1−10

−3

). If one wishes to erase 1/32 of the memory

only, like in the KK protocol, then it would be sufﬁ-

cient to set r = 3, which is efﬁcient. If one wishes to

erase 99% of the device’s memory, like in DFKP, KL

and PT, then the protocols in (Bursuc et al., 2024a;

Bursuc et al., 2024b) would need to execute hundreds

of round-trip-time measurements, which is inefﬁcient.

We thus believe that r = 71 strikes a good balance

between erasure guarantees and performance. This

means that, for the remainder of this article, when

we refer to PoSE

graph

, PoSE

light

and PoSE

random

, we

are assuming that they all execute 71 round-trip-time

measurements.

In Table 4, we show the memory footprint of

our protocol implementations for each combination

of protocol and device. To calculate the memory

footprint of a protocol on a device, we considered a

dummy implementation of each protocol, that, while

sending messages of the same size and in the same

order, occupies a negligible amount of memory. The

rest of the code remained exactly the same. Compar-

ing this dummy implementation with the original one

allowed us to compute the actual size of each proto-

col implementation taking into account compiler op-

timizations.

Notice that the values in Table 4 vary between de-

vices because their architectures are different. An-

other reason for the size variation is that we used the

best available implementation for each hash function

and architecture. In general, the CC2652 implemen-

tations take more space than the F5529 or FR5994

ones. This is probably due to the use of byte size vari-

ables throughout the implementations, which can be

more efﬁciently represented in the 16 bits architecture

than in the 32 bits architecture. Taking into account

the three devices, the protocols with smaller memory

footprint are PT and PoSE

random

3.4 Memory to Be Erased

To be able to run all protocols in a reasonable time

and avoid the need for device-speciﬁc engineering,

while erasing the same amount of memory with each

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

214

Table 3: Memory footprint of the hash function in device CC2652 while attempting to erase 2KB.

aeshash ascon blake2 blake3 sha256 sha256hw

DFKP 1250 5860 6365 21177 1043 1397

KL 1245 5886 6364 21216 1038 1402

KK 1253 5866 6364 21158 1043 1391

PT — — — — 3730 —

PoSE

graph

1251 5868 6367 21182 1044 1401

PoSE

light

1251 5867 6366 21195 1044 1402

PoSE

random

— — — — — —

Table 4: Memory footprint (in bytes) of the protocol implementations on each device.

DFKP KL KK PT PoSE

graph

PoSE

light

PoSE

random

CC2652 620 1023 1343 274 1182 1181 312

F5529 777 1343 1868 356 1610 1644 415

FR5994 781 1353 1876 357 1610 1644 416

protocol, we set up our experiments in such a way

that a ﬁxed portion of the memory of each device is

erased. Our implementation creates an array with a

ﬁxed size at compile time, and this array is exactly

what is erased while running the protocol. This makes

our implementation simple and device-independent.

Because the array must ﬁt in the data size of each de-

vice, we restrict ourselves to the following memory

sizes. For the devices F5529 and FR5994 we erase

exactly 2KB, and for CC2652 we erase exactly 2 KB,

4 KB and 8 KB. Increasing the maximum erased size

in each device beyond the limits mentioned before,

led to the risk of overwriting memory addresses used

during execution, therefore making it unfeasible.

We notice that our implementations are limited

to performance testing, and will need to be adapted

for deployment in a real setting. The reason being

that, in practice, memory erasure protocols deﬁne the

segment of memory to be erased prior compilation,

rather than letting the compiler decides. Doing so,

however, requires device-dependent implementations,

which we considered would add unnecessary com-

plexity to the comparison task.

3.5 Distance

The distance between the device (prover) and the lap-

top (veriﬁer) was approximately 1 meter. Each run

of the protocol was done independently, as the main

objective was to compare the protocols against each

other in the simplest possible setting.

4 EXPERIMENTAL RESULTS

This section reports on the time each combination of

protocol and hash function implementation takes to

(i) erase a ﬁxed amount of memory on a device and

(ii) to generate a proof of erasure.

4.1 Impact of the Hash Function

Implementations

Most protocols under analysis, namely

DFKP,KL, KK,PoSE

graph

and PoSE

light

, re-

sort to several hash function calls to ﬁll the device’s

memory with fresh data. This contrasts with the

approach followed by PT and PoSE

random

where the

device’s memory is ﬁlled with random data sent by

the veriﬁer. Hence, we start measuring the impact of

the hash function implementation on the execution

time of the former class of protocols. We do so

by measuring the execution time of the protocols

right until the point where the device’s memory has

been erased, thereby ignoring the veriﬁcation of

the proof of erasure. We will refer to this (partial)

execution time by erasure time, to distinguish it

from the veriﬁcation time where the veriﬁer checks

the erasure proof, and from the total execution time

which accounts for both: the erasure and veriﬁcation

time.

Tables 5 to 7 display erasure time values for ev-

ery combination of protocol and hash function, each

table focusing on a given device and memory size to

be erased. Notice that the protocols PoSE

random

and

PT do not appear in the tables, as they do not call the

hash function to ﬁll the device’s memory.

We observe that it is notably faster to erase mem-

ory when the device has a higher clock frequency,

as can be seen when comparing performance in the

CC2652 with respect to the FF5529 and the FR5994

devices. Amongst the hash functions, sha265hw was

the fastest in the CC2652 device, which was expected

as it uses the hardware accelerator. One surprising

result is that ascon, which is meant to be used in

Empirical Evaluation of Memory-Erasure Protocols

215

Table 5: Erasure time in seconds on device CC2652 while attempting to erase 8KB.

aeshash ascon blake2 blake3 sha256 sha256hw

DFKP 10.9 31.5 5.1 3.8 7.3 1.7

KL 0.0 0.0 0.0 0.0 0.0 0.0

KK 7.4 20.9 3.6 2.7 5.1 1.2

PoSE

graph

14.8 60.0 5.9 4.4 8.7 2.1

PoSE

light

4.4 20.0 2.0 1.3 2.6 0.6

Table 6: Erasure time in seconds on device FR5994 while

attempting to erase 2KB.

aeshash ascon blake2 blake3 sha256

DFKP 3.1 80.5 20.1 15.6 27.8

KL 0.1 0.3 0.1 0.1 0.2

KK 4.9 130.8 34.5 26.9 48.1

PoSE

graph

8.6 218.7 56.7 44.0 78.5

PoSE

light

4.6 108.7 28.7 22.3 39.5

Table 7: Erasure time in seconds on device F5529 while

attempting to erase 2KB.

ascon blake2 blake3 sha256

DFKP 47.5 12.6 9.9 17.4

KL 0.7 0.6 0.6 0.6

KK 76.3 21.2 16.5 30.1

PoSE

graph

128.9 34.0 26.3 48.2

PoSE

light

64.1 17.5 13.6 24.6

lightweight cryptography, had a consistently worst

performance. In every device blake3 was faster than

blake2, although the difference is around 25 percent

only. Aeshash was much faster than other hash func-

tions in the FR5994 device, as expected by the us-

age of the AES hardware module present on this de-

vice. On the contrary, it performed worse than blake2,

blake3 and even sha256 in the CC2652 device. There-

fore, we deduce that if the device is fast enough, pure

software implementations might be more performant

than hybrid implementations such as the one used in

aeshash.

To conclude, the impact of the hash function im-

plementation is high in most of the protocols anal-

ysed, with the exceptions of PT and PoSE

random

. In-

terestingly, the smaller erasure time on each device

is achieved with a different hash function. This sug-

gests that, before deploying a memory-erasure proto-

col on a given device, it is worth testing it with dif-

ferent hash functions implementations. Lastly, cross-

checking Table 3 (memory cost) with Tables 5 to 7

(computational cost), we conclude that (i) aeshash is

the fastest and smaller hash function implementation

on device FR5994, (ii) sha256 and sha256hw outper-

form the other hash functions on the device CC2652,

and (iii) on the device F5529 there is a clear looser,

namely ascon, but no clear winner.

4.2 Total Execution Time

Next, we measure the total execution time of each

combination of protocol and hash function implemen-

tation. This is admittedly the most important perfor-

mance variable in our experiments. The values can be

found in Tables 8 to 10, each table focusing on a given

device and memory size to be erased.

In the CC2652 device, the fastest protocols were

KK and DFKP, despite the latter being the one with

worst (asymptotic) time complexity. We believe this

to be possible because (i) the constants hidden in the

asymptotic notation are very small for this protocol

and somewhat larger for the others, and (ii) the size

of the erased memory is small. Looking at the proto-

cols PT and PoSE

random

, which follow the approach

of sending a large random nonce over the network,

we observe that they perform poorly in comparison to

the others. Interestingly, that is not case if we shift

our attention to the devices FR5994 and F5529. In

those devices, PT and PoSE

random

are amongst the

fastest protocols. This difference in result can be

explained by the version of the Bluetooth protocol

used. The CC2652 device has a Bluetooth module

included, able to run version 5.2, which means that in

each challenge-response round the message needs to

go through the whole Bluetooth stack. On the other

hand, for the FR5994 and F5529 devices, a simple

HC-05 module was used, which makes the Bluetooth

protocol overhead much smaller, as it does not sup-

port as many features.

A summary of the results just described is given

in Figure 1. In that ﬁgure, we display the total execu-

tion time of each protocol on each device by choosing

the hash function implementation that gives the fastest

execution time. From the ﬁgure we derive that the

choice of the most performant (fastest) protocol for a

device depends on the speciﬁc conditions in which it

will operate. In particular, clock speed, network cost

and memory size determine which protocol is more

suitable. Cross-checking Table 4 (memory cost) with

Figure 1 (computational cost), we conclude that PT

offers an optimal trade-off between memory footprint

and execution time on the devices F5529 and FR5994;

other good alternatives are DFKP and PoSE

random

In the CC2652 the winner is DFKP.

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

216

Table 8: Total execution time in seconds on device CC2652 while attempting to erase 8KB.

aeshash ascon blake2 blake3 none sha256 sha256hw

DFKP 11.1 31.7 5.3 4.0 — 7.5 1.9

KL 23.4 23.4 23.3 23.3 — 23.4 23.3

KK 7.6 21.1 3.8 2.9 — 5.3 1.3

PT — — — — — 23.2 —

PoSE

graph

21.4 66.6 12.5 11.0 — 15.3 8.7

PoSE

light

11.0 26.6 8.6 8.0 — 9.2 7.2

PoSE

random

— — — — 29.7 — —

F5529 FR5994 CC2652

Communication + Computation Time (seconds)

10.0

16.7

2.9

31.1

18.3

6.8

3.2

5.1

2.4

13.3

9.3

6.8

0.3

0.4

6.0

5.8

6.9

6.8

12.3

DFKP

PoSE

graph

PoSE

light

PoSE

random

Figure 1: Total execution time in seconds, partitioned by communication time (striped) and computation time, using the best

hash function for each device.

Table 9: Total execution time in seconds on device FR5994

while attempting to erase 2KB. For PoSE

random

it was 6.8

seconds.

aeshash ascon blake2 blake3 sha256

DFKP 3.2 80.7 20.2 15.7 27.9

KL 2.4 2.6 2.5 2.4 - 2.5

KK 5.1 131.0 34.6 27.1 48.2

PT — — — — 2.4

PoSE

graph

13.3 223.4 61.4 48.7 83.4

PoSE

light

9.3 113.3 33.5 27.2 44.4

Table 10: Total execution time in seconds on device F5529

while attempting to erase 2KB. For PoSE

random

it was 6.8

seconds.

ascon blake2 blake3 sha256

DFKP 47.6 12.7 10.0 17.5

KL 3.0 2.9 2.9 2.9

KK 76.4 21.3 16.7 30.2

PT — — — 2.9

PoSE

graph

133.5 38.7 31.1 52.9

PoSE

light

68.9 22.1 18.3 29.3

4.3 How Much Does the Size of Memory

Impact the Execution Time?

A rather surprising result from the empirical data we

have presented so far is that the DFKP protocol seems

to perform very well across all devices, despite having

the worst asymptotic computational complexity. As

the memory to be erased increases, one should expect

a worse performance of DFKP in comparison to the

other protocols. That is precisely what we test next,

i.e. how the execution time changes as we increase

the memory size. We perform this experiment on the

CC2652 device, which allows us to erase up to 8KB

of memory. Figure 2 displays the results.

Observe that the execution time of most protocols

seem to increase linearly with the memory size. Ex-

ceptions are PoSE

graph

and PoSE

light

, whose execu-

tion time is dominated by the communication time

rather than by the erasure time. The performance of

DFKP on the erasure of 8KB of memory starts get-

ting worse than that of KK, supporting the hypothe-

sis that its quadratic computational complexity might

make it unsuitable for larger memory sizes. We ac-

knowledge, that further experiments are needed to de-

termine the memory threshold where DFKP starts be-

having worse than the other protocols.

Empirical Evaluation of Memory-Erasure Protocols

217

2KB 4KB 8KB

Communication + Computation Time (seconds)

0.3

0.4

6.0

5.8

6.9

6.8

12.3

0.6

11.8

11.6

7.3

6.8

18.5

1.9

1.3

23.3

23.2

8.7

7.2

29.7

DFKP

PoSE

graph

PoSE

light

PoSE

random

Figure 2: Total execution time in seconds on device CC2652, partitioned by communication time (striped) and computation

time, using the best hash function.

5 COMPARATIVE ANALYSIS

Our results have not revealed a clear winner with re-

spect to performance. That said, PT, KL, KK and

DFKP seem to perform relatively well across all de-

vices. KK, however, provides little erasure guarantees

(only 1/32 of the memory is guaranteed to be erased),

while PT and KL come with no formal security proof.

Hence, our next step is to provide a holistic compar-

ison of the protocols, one where security and erasure

guarantees are considered alongside performance.

To reach our conclusions, we considered the fol-

lowing facts:

• Protocols KL, KK and PT offer a low level of

security

• Protocols PoSE

random

, PoSE

graph

, PoSE

light

and

DFKP offer a high level of security. Note, though,

that the DFKP protocol is less secure than the oth-

ers given that it is not resistant against distant at-

tackers.

• Protocols PoSE

random

, PT or KL require send-

ing the full memory of the device through the net-

work.

• DFKP has quadratic complexity, hence its perfor-

mance is worse when the amount of memory is

large.

Next, we provide a ﬁne-grained analysis of the

results, by projecting them onto speciﬁc use-cases.

These results are summarized in Table 11. They were

obtained by extrapolating the behaviour of the proto-

cols in each device.

• When the network cost is high, communication

needs to be minimized, therefore protocols such

as PoSE

random

, PT or KL are impractical.

– When memory is small, protocol DFKP is the

clear winner (see for example Table 10). Even

though it has quadratic complexity, its very low

constant factor makes it faster than the rest of

the protocols. We are considering that this pro-

tocol has high security even though it assumes

the isolation assumption. If security against

distant attackers is necessary, the winner for

this category is the PoSE

light

protocol.

– When memory is large, the most performant

protocols are PoSE

light

and KK, for high se-

curity and low security, respectively.

• When the network cost is low, the most perfor-

mant protocols are PoSE

random

and PT, for high

security and low security, respectively. A surpris-

ing result in this setting is that KL had a very sim-

ilar performance to PT, which should not have

been the case as it was speciﬁcally designed to

improve its performance. If the device in ques-

tion has hardware accelerators, then for the high

security case it is possible that DFKP is faster, as

shown for example in Table 8.

It is noteworthy that the clock speed only changed

the selection of the winner when the network cost is

low and memory is small. In this scenario, the DFKP

protocol outperforms PoSE

random

and KK outper-

forms PT (see for example Table 8).

We end our analysis by completing the compari-

son table given in Section 2 with the empirical data

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

218

Table 11: Summary of results. For each combination of Network cost (high, low), Clock speed (high, low), Memory size

(large, small) and Security (high, low) the most performant protocol is shown.

Network cost

High Low

Clock speed Clock speed

High Low High Low

Memory size

Large Security

High PoSE

light

PoSE

light

PoSE

random

PoSE

random

Low KK KK PT PT

Small Security

High DFKP DFKP DFKP PoSE

random

Low DFKP DFKP KK PT

Table 12: Summary of results, contrasting performance with security. The last three columns show the total time on each

device, when using the highest possible memory to erase (in parentheses) and the hash function leading to the lowest execution

time.

Proof Prob. No-Isol. Erasure Total Time

F55292KB FR59942KB CC26528KB

DFKP (Dziembowski et al., 2011) ✓ ✗ ✗ 1 ✓ 10.0 ✚ 3.2 ✓ 1.9 ✓

KL (Karame and Li, 2015) ✗ ✗ ✗ 1 ✓ 2.9 ✓ 2.4 ✓ 23.3 ✗

KK (Karvelas and Kiayias, 2014) ✓ ✗ ✗

✗ 16.7 ✚ 5.1 ✓ 1.3 ✓

PT (Perito and Tsudik, 2010) ✗ ✗ ✗ 1 ✓ 2.9 ✓ 2.4 ✓ 23.2 ✗

PoSE

graph

(Bursuc et al., 2024a) ✓ ✓ ✓ 0.9 ✚ 31.1 ✗ 13.3 ✗ 8.7 ✚

PoSE

light

(Bursuc et al., 2024b) ✓ ✓ ✓ 0.9 ✚ 18.3 ✚ 9.3 ✚ 7.2 ✚

PoSE

random

(Bursuc et al., 2024a) ✓ ✓ ✓ 0.9 ✚ 6.8 ✓ 6.8 ✚ 29.7 ✗

obtained during our experiments. This provides an-

other angle to compare the results obtained across

devices, this time contrasting performance with the

same protocol features shown before in Table 1. The

results are displayed in Table 12. For a simpler visual

comparison amongst the protocols, we labelled each

cell in the table with a symbol that indicates whether

the protocol performs well (✓), average (✚) or poorly

(✗), relative to the other protocols. For the numerical

values in the table, we determined their labels by clus-

tering the values in a column in three clusters. Speciﬁ-

cally, we used k-means for clustering. For example, in

the last column of the table, which gives the execution

time of each protocol on the CC2652 device when

erasing 8KB, there are three clusters that minimize

the sum of the squared Euclidean distances of each

point to its closest centroid, namely ✓ = {1.9,1.3},

✚ = {8.7,7.2} and ✗ = {23.3,23.2,29.7}. The table

reinforces the analysis results we have mentioned ear-

lier. An interesting observation is that PoSE

light

is the

only protocol that does not perform poorly on any of

the features considered.

6 CONCLUSIONS

In this paper we presented the outcome of our exper-

iments with various memory-erasure protocols in an

IoT setting. We implemented

7 protocols, each with

https://gitlab.com/uniluxembourg/fstm/dcs/satoss/

memory-erasure-experiments

several variants depending on the hash function used,

and tested them on 3 modern IoT devices. Further-

more, we compared the security guarantees provided

by each protocol, and contrasted them with their per-

formance in a practical setting.

Our results revealed that current memory-erasure

protocols are practical, although erasing the full mem-

ory securely could take several minutes for the slower

devices. Network speed might be faster than local

computation, therefore aiming at minimal communi-

cation complexity is not always the best choice. For

protocols that use hash functions, the choice of the

hash function may dramatically inﬂuence the proto-

col performance and memory footprint. Finally, the

most performant protocol might not be the best ac-

cording to the asymptotic complexity analysis, as for

small memory sizes the hidden constants may play a

determining role.

ACKNOWLEDGEMENTS

Reynaldo Gil-Pons was funded by the Luxem-

bourg National Research Fund, Luxembourg, under

the grant AFR-PhD-14565947. Rolando Trujillo-

Rasua was supported by a Ramón y Cajal grant

(RYC2020-028954-I) from the Spanish Ministry of

Science and Innovation and the EU, as well as

by projects PROVTOPIA (PID2023-150098OB-I00),

funded by MICIU/AEI/10.13039/501100011033 and

FEDER (EU), and HERMES, funded by INCIBE and

the EU’s NextGenerationEU/PRTR.

Empirical Evaluation of Memory-Erasure Protocols

219

REFERENCES

Aman, M. N., Basheer, M. H., Dash, S., Wong, J. W., Xu, J.,

Lim, H. W., and Sikdar, B. (2020). HAtt: Hybrid Re-

mote Attestation for the Internet of Things With High

Availability. IEEE Internet of Things Journal.

Ammar, M., Daniels, W., Crispo, B., and Hughes, D.

(2018). Speed: Secure provable erasure for class-1

iot devices. In Eighth ACM Conference on Data and

Application Security and Privacy.

Aumasson, J.-P., Neves, S., Wilcox-O’Hearn, Z., and Win-

nerlein, C. (2013). BLAKE2: Simpler, Smaller, Fast

as MD5. In Applied Cryptography and Network Secu-

rity.

Banks, A., Kisiel, M., and Korsholm, P. (2021). Remote

Attestation: A Literature Review. ArXiv.

Bormann, C., Ersue, M., and Keranen, A. (2014). RFC

7228: Terminology for constrained-node networks.

IETF RFC.

Bursuc, S., Gil-Pons, R., Mauw, S., and Trujillo-Rasua, R.

(2024a). Software-based memory erasure with relaxed

isolation requirements. In Proc. 37th IEEE Computer

Security Foundations Symposium (CSF’24).

Bursuc, S., Gil-Pons, R., Mauw, S., and Trujillo-Rasua, R.

(2024b). Software-Based Memory Erasure with re-

laxed isolation requirements: Extended Version. arXiv

preprint arXiv:2401.06626.

Dobraunig, C., Eichlseder, M., Mendel, F., and Schläffer,

M. (2021). Ascon v1.2: Lightweight Authenticated

Encryption and Hashing. Journal of Cryptology.

Dziembowski, S., Kazana, T., and Wichs, D. (2011). One-

time computable self-erasing functions. In Theory of

Cryptography Conference.

Eastlake, D. and Hansen, T. (2006). US Secure Hash Al-

gorithms (SHA and HMAC-SHA). Technical Report

RFC4634, RFC Editor.

Karame, G. O. and Li, W. (2015). Secure erasure and code

update in legacy sensors. In International Conference

on Trust and Trustworthy Computing. Springer.

Karvelas, N. P. and Kiayias, A. (2014). Efﬁcient proofs

of secure erasure. In International Conference on Se-

curity and Cryptography for Networks, Amalﬁ, Italy.

Springer.

Kuang, B., Fu, A., Susilo, W., Yu, S., and Gao, Y. (2022).

A survey of remote attestation in Internet of Things:

Attacks, countermeasures, and prospects. Computers

& Security.

Lachner, C. and Dustdar, S. (2019). A Performance Eval-

uation of Data Protection Mechanisms for Resource

Constrained IoT Devices. In 2019 IEEE International

Conference on Fog Computing (ICFC).

Perito, D. and Tsudik, G. (2010). Secure code update for

embedded devices via proofs of secure erasure. In Eu-

ropean Symposium on Research in Computer Security.

Springer.

Rao, V. and Prema, K. V. (2019). Comparative Study

of Lightweight Hashing Functions for Resource Con-

strained Devices of IoT. In 2019 4th CSITSS.

Reardon, J., Basin, D., and Capkun, S. (2013). SoK: Secure

data deletion. In 2013 IEEE Symposium on Security

and Privacy.

Silva, C., Cunha, V. A., Barraca, J. P., and Aguiar, R. L.

(2024). Analysis of the Cryptographic Algorithms in

IoT Communications. Information Systems Frontiers,

(4).

Trujillo-Rasua, R. (2019). Secure memory erasure in the

presence of man-in-the-middle attackers. Journal of

Information Security and Applications.

Tsudik, G. (1992). Message authentication with one-way

hash functions. ACM SIGCOMM Computer Commu-

nication Review.

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

220
