Learning Personalized and Context-Aware Violation Detection Rules in

Trigger-Action Apps

Mahsa Saeidi

, Sai Sree Laya Chukkapalli

, Anita Sarma

and Rakesh B. Bobba

University of Tehran, Tehran, Iran

IBM Research, New York, U.S.A.

Oregon State University, Oregon, U.S.A.

Keywords:

Privacy, Trigger-Action, Violation Detection Rules.

Abstract:

Trigger-action apps are being increasingly used by end users to connect smart devices and online services

to create new functionality. However, these apps can cause undesirable implicit information ﬂows (secrecy

violation) or lead to unintended accesses (integrity violation) depending on the usage context. Existing solu-

tions designed to address such risks rely on predeﬁned rules to control and mitigate such implicit information

ﬂows or unintended accesses. However, deﬁning such rules is difﬁcult for end users. In this work, we pro-

pose a learning-based approach to learn rules that ﬂag violating situations based on the usage context. We

also propose a set of reduction steps to reduce the complexity of the learned rules. We are able to achieve a

good F1-measure in predicting both secrecy (0.91) and integrity (0.75) violations and achieve 77% and 74%

complexity reduction while maintaining 88% and 97% of the original performance of the secrecy and integrity

violation prediction, respectively.

1 INTRODUCTION

Trigger-action programming frameworks such as

IFTTT (IFTTT, 2019), Microsoft Flow (Microsoft

Corporation, 2019), and Zapeir (Zapier Inc., 2019)

are getting increasingly popular. These frameworks

enable end users to connect different IoT devices and

online services using simple conditional logic (e.g., If-

this-then-that in IFTTT) to enable new and rich func-

tionality. It has been reported that for IFTTT alone,

18 million registered users were running over 1 bil-

lion applets each month in 2020 (McLaughlin, 2021).

While these platforms provide convenience and

ease of use, there are inherent security and privacy

risks. These include unexpected or undesirable im-

plicit information ﬂows (Surbatovich et al., 2017;

Cobb et al., 2020; Celik et al., 2018; Fernandes

et al., 2016). For example, an applet that automat-

ically uploads pictures taken by a motion-activated

smart home security camera during the day may cause

privacy violations when unexpected guests arrive or

home owners return early.

Surbatovich et al. (Surbatovich et al., 2017) high-

lighted such risks in IFTTT applets using a lattice-

based analysis framework. They used security la-

bels and information ﬂow analysis to identify se-

crecy (conﬁdentiality) and integrity violations. Mul-

tiple prior works have used a lattice-based model to

determine security and privacy violations in smart-

home solutions because of the simplicity and ease

of static information-ﬂow rules (Bastys et al., 2018;

Celik et al., 2019). However, recent work by

Cobb et al. (Cobb et al., 2020) has shown that lattice-

based models cannot capture security and privacy

risks accurately due to lack of contextual information.

They discussed how contextual information such as

device location within the home can help identify the

violations more accurately.

Contextual information alone may not sufﬁce to

accurately capture risks. We show that even with us-

age context considered, lattice-based evaluation, as

discussed in (Surbatovich et al., 2017; Cobb et al.,

2020), does not yield a unique decision on violations,

highlighting the inﬂuence of individual preferences.

Therefore, customizing security and privacy eval-

uation for each individuals’ personal preference is

going to be a necessity, which is inline with prior

work (Saeidi et al., 2020) that showed end-user

perception of security and privacy risks varies sig-

niﬁcantly between individuals. While some exist-

ing frameworks allow such personalization (e.g., Ex-

pat (Yahyazadeh et al., 2019), IoTGuard (Celik et al.,

Saeidi, M., Chukkapalli, S. S. L., Sarma, A. and Bobba, R. B.

Learning Personalized and Context-Aware Violation Detection Rules in Trigger-Action Apps.

DOI: 10.5220/0013528800003979

In Proceedings of the 22nd International Conference on Security and Cryptography (SECRYPT 2025), pages 429-442

ISBN: 978-989-758-760-3; ISSN: 2184-7711

429

2019)), where end users deﬁne policy rules through

specialised policy languages or graphical user inter-

faces, doing so is difﬁcult for end users (Smetters and

Good, 2009; Bauer et al., 2009). The already complex

task of deﬁning policy rules will be made much more

difﬁcult by end users having to consider different us-

age contexts for different applets.

To address this gap, we propose a framework

for learning integrity and secrecy violation detection

rules tailored to individual preferences. We frame

the problem as a classiﬁcation task that uncovers vi-

olation detection rules from a synthesized training

dataset, which includes various usage scenarios of

multiple applets created by combining different con-

textual information. Additionally, we use reduction

techniques to minimize complexity and redundancy

in the ﬁnal learned rules. In summary, this work:

• Validates that integrity and secrecy violations de-

pend on both the context and user preferences using

a synthesized dataset of smart-home applets labeled

considering contextual information.

• Shows that machine learning models can learn and

generalize violation detection rules for a given user.

Our Random Forest (RF) model achieved good F1-

measure in predicting both secrecy (0.91) and in-

tegrity (0.75) violations.

• Proposes reduction techniques to decrease the com-

plexity of the learned rules, achieving a 77% and

74% decrease in complexity while maintaining 88%

and 97% of the original performance in predicting

secrecy and integrity violations, respectively.

The paper is structured as follows: Section 2 cov-

ers the threat model and lattice-based approach. In

Section 3, we outline our method for creating a la-

beled smart-home dataset. Section 4 discusses the

limitations of lattice-based models for violation de-

tection and the role of contextual information. Sec-

tion 5 presents our framework for learning violation

detection rules and reducing complexity, along with

its evaluation on the dataset. We address limitations

and future work in Section 6 and review related work

in Section 7. Finally, we conclude in Section 8.

2 THREAT MODEL AND

LATTICE-BASED APPROACH

Threat Model. In this paper, we focus on violations

that arise when unauthorized users (e.g., visitors or

outsiders) trigger smart home applets to perform un-

intended or malicious actions or to access sensitive in-

formation through them. For example, a visitor could

issue a voice command to disable security cameras,

thus compromising home security, or exploit an on-

line service linked to a smart device to expose sen-

sitive information, such as daily routines of residents

and their presence or absence at home.

Our paper categorizes the above situations as

integrity and secrecy violations and discusses how to

determine and detect them. Speciﬁcally, an integrity

violation happens if an applet

allows unauthorized

or unintended access to a smart-home device (e.g., a

smart camera) or a resource on an online service (e.g.,

a Google spreadsheet). On the other hand, A secrecy

violation happens when an applet enables the ﬂow

of private information to a public destination (e.g.,

uploading footage from an indoor camera, considered

private, to a shared Google folder, considered public).

Lattice-Based Approach. One of the simple and

understandable approaches that can help to identify

the violations in smart-home apps is the lattice-based

model that was proposed by prior works (Cobb et al.,

2020; Surbatovich et al., 2017). A lattice-based secu-

rity model detects integrity (undesirable access) and

secrecy violations (undesirable information ﬂow) by

employing security labels that form a lattice, or par-

tial order, along with simple static rules based on in-

formation ﬂow analysis (Denning, 1976). Figure 1

shows the security lattice used in (Surbatovich et al.,

2017) to analyze information ﬂows and identify in-

tegrity and secrecy violations. The arrows in the ﬁg-

ure indicate the permissible information ﬂows and au-

thorized accesses. For instance, information ﬂow is

allowed from devices or services with Public label to

those with Private label, but not vice versa (Left side

of Figure 1). Similarly, devices or services labeled

Trusted are allowed to access or control those with

Untrusted label, but not vice versa (Right side of Fig-

ure 1).

In applying a lattice-based security model to

smart-home applets, integrity and secrecy labels for

triggers and actions are assigned by responding to two

questions: who can access and who can observe the

trigger and action (Surbatovich et al., 2017). For in-

stance, when a smart device is located within a home,

it means only a restricted group of people who are

physically present in the home could either access the

device to initiate a trigger or observe the action event

if it occurs in the device. In this case, the security la-

bel of the trigger/action would be restricted physical.

To see the security rule application, consider an

applet that adds one row to the user’s Google spread-

sheet when the front door gets unlocked. In this

case, an integrity violation can occur if an unknown

In this paper, app and applet are used interchangeably

to refer to IFTTT like recipes connecting smart-home de-

vices and online services.

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

430

Figure 1: The integrity and secrecy (conﬁdentiality) lattices

used in (Surbatovich et al., 2017).

person (untrusted user) unlocks the door and causes

the action of writing in the Google spreadsheet that

is allowed only by the Google spreadsheet owner (a

trusted user).

3 DATASET SYNTHESIS

METHODOLOGY

To investigate how usage context affects the accu-

racy of lattice-based integrity and secrecy violation

detection approaches, we need a trigger-action

app dataset that includes contextual information.

While smart-home datasets with smart sensor read-

ings (Washington State University, 2019) and IFTTT

app datasets (Surbatovich et al., 2017; Cobb et al.,

2020) were available, these did not include contextual

information. Therefore, we synthesized a dataset as

described below

Applet Selection: We chose our smart-home applets

from two IFTTT applet datasets used in previous

work (Cobb et al., 2020; Saeidi et al., 2020). The ﬁrst

dataset includes 396 unique IFTTT applets, with 218

related to smart homes, while the second includes

49 unique smart-home applets. An ideal scenario

would be to consider every applet that creates a

unique trigger and action pair. However, this would

make creating a labeled dataset very challenging as

will become evident later. To reduce the dimensions

of trigger/action events, we grouped triggers and

actions into semantic categories proposed by (Cobb

et al., 2020) with two additional subcategories (DS:A

and DS:P) to differentiate between appliances and

This dataset will be made available to the community.

A smart-home applet is an applet in which either the

trigger or action would happen in the smart-home environ-

ment.

printers from other IoT devices within the home.

We identiﬁed 39 unique pairs of trigger and action

semantic categories across the two datasets and

randomly sampled one applet from each pair of

trigger and action semantic categories across both

datasets (Cobb et al., 2020; Saeidi et al., 2020) to

create a semantically representative applet dataset.

Thus we picked 39 applets which represent the 39

unique pairs of semantic categories across the two

datasets.

Contextual Factors: Next step in creating a suit-

able dataset for our analysis is identifying contex-

tual factors that might inﬂuence or impact what might

be a considered a violation in smart-home trigger-

action apps. We identiﬁed a set of six contextual

factors that can have a potential impact on integrity

and secrecy violations by reviewing existing relevant

work (Naeini et al., 2017; Lee and Kobsa, 2016; Lee

and Kobsa, 2017; He et al., 2018; Saeidi et al., 2020;

Cobb et al., 2021; Jin et al., 2022). These selected

factors were also listed as the most mentioned con-

texts in a recent survey on contextual access controls

in homes (He et al., 2021). However, we note that this

set is not meant to be exhaustive but just a reasonable

starting point to illustrate the proposed approach.

• Trigger Location. The area in the home where

the trigger event can occur has security and pri-

vacy implications as it deﬁnes who can access the

trigger (Saeidi et al., 2020). This contextual factor

includes Living Room and Kitchen that are con-

sidered public areas, and Bedroom and Bathroom

that are considered private areas.

• Action Location. The area in the home where the

action event occurs also has security and privacy

implications as it deﬁnes who is able to observe

the action. Similar to Trigger Location, this factor

includes public areas (Living Room, Kitchen) and

private areas (Bedroom, Bathroom).

• Time. The time of day an end user uses the applet

can impact security and privacy, as cameras may

capture more sensitive footage at speciﬁc times.

We consider three values for this factor: Morning,

Afternoon, and Night.

• Online Service Trustworthiness/Secrecy.

This factor includes two situations when the trig-

ger/action occurs in online services. For triggers,

online service trustworthiness indicates whether

the trigger event is initiated by trusted or untrusted

online services. For instance, in an applet that

ﬂashes a light when a new feed item matches the

app rule, there might be security/privacy concerns

if the RSS feed is from an untrusted website. For

Learning Personalized and Context-Aware Violation Detection Rules in Trigger-Action Apps

431

actions, when these are reported/logged in online

services, online service secrecy indicates whether

the information available in online services is pri-

vate or shared with others. For instance, in an ap-

plet that uploads a Facebook post when the user

arrives home, there might be privacy concerns if

the Facebook post is on a public page.

• Trigger Device/Service. The trigger device or

service refers to the resource that initiates trigger

events. It is essential to identify the trigger device

or service to determine who has access to it and

what kind of information may be exposed. For

instance, if the trigger is a voice command acti-

vated through a voice assistant like Alexa, anyone

in close proximity to the device can initiate the

command. To identify the device or online ser-

vice used by the applet, we utilized the semantic

categories proposed by (Cobb et al., 2020) (e.g.,

Semantic label “V” for triggers that are “voice”

activated based on verbal interactions with a smart

assistant such as, Alexa, Siri).

• Action Device/Service. This factor refers to the

resource where the action events take place. The

type of device or service, along with its features,

can have an impact on privacy and security im-

plications. For instance, having access to a light

would be less sensitive than having access to a se-

curity camera. Similar to Trigger Device/service

we used the semantic labels proposed by (Cobb

et al., 2020) to identify the type of device and ser-

vice for action event.

• Homeowner Presence. Whether the homeowner

is home or away. We consider this factor to iden-

tify potential people who are likely to use or trig-

ger the applet. This and the next factor can help

identify if the applet is triggered by home mem-

bers, visitors or others (outsider, etc.).

• Visitor Presence. This factor shows if the home

has a visitor or not. It helps to identify potential

people who are nearby and are able to use the ap-

plet or observe when the applet is activated, i.e.,

observe the action. We considered this and the

previous factor to understand if the applet is likely

to be visible or used by the owner, visitors or oth-

ers (outsider, etc.).

Usage Scenario: For each applet, we created

deployment and usage contexts by considering all

applicable combinations of the six contextual factors.

For example, in an applet that connects a voice

assistant like Alexa to a security camera: the trigger

device (Alexa) can be located in the living room,

kitchen, bedroom, or bathroom; the action device

(camera) can be potentially located in the living

room, kitchen, or bedroom

; the homeowner can be

absent, present and awake, or present and asleep; a

visitor may or may not be at home; and the applet can

be run in the morning, afternoon, or night.

Violation Labeling: Violation types (e.g., integrity

and secrecy) may vary in relevance across deploy-

ment and usage contexts. Generated scenarios can

be grouped into two potentially overlapping sets

for secrecy and integrity violations, each labeled as

violating or non-violating. Violating means running

the applet in the given context may potentially

lead to an unintended access (integrity violation)

or an unintended information ﬂow (secrecy violation).

Dataset: For the 39 selected applets, we came up with

4104 applet deployment scenarios by considering all

applicable combinations of the six contextual factors.

All the generated scenarios were relevant for secrecy

violations. But, only 3666 among the 4104 were rele-

vant for integrity violations. This dataset was labeled

by two of the authors and is used to (i) empirically in-

vestigate if the lattice-based approach is sufﬁcient to

accurately determine security and privacy violations

in trigger-action smart-home applets (Section 4), and

(ii) for evaluating our proposed learning framework

(Section 5)

4 LATTICE-BASED MODEL

LIMITATIONS

The lattice-based approach (Surbatovich et al., 2017)

which uses a simple rule-based model (described in

Section 2) to assign lattice labels and detect informa-

tion ﬂow violations in trigger-action applets, provides

an efﬁcient and scalable way of assessing the security

and privacy issues in a large corpora of applets. How-

ever, it is prone to inaccurate detection (both false

positives and false negative).

Cobb et al. (Cobb et al., 2020) enhanced this

lattice-based model by adding two additional lattice

labels for trusted people in the restricted physical

space (e.g., family members) and restricted online

space (e.g., household members who can control de-

vices via an app). They found that about 57% of ap-

plets to be potentially violating compared to about

35% with the original lattice. However, when they

manually inspected the violating applets, not all of the

applets raised concerns leading them to conclude that:

We consider locations for apps that are likely to occur.

A camera in the bathroom is unlikely for most situations

and users.

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

432

(a) semantic labels of triggers and actions can help

ﬁnd risky applets more accurately, and (b) contextual

information (e.g., device location) matters when eval-

uating such violations and impacts the performance of

violation detection. Saeidi et al. (Saeidi et al., 2020)

found that in addition to usage context, users’ prefer-

ences also impact end-users perception of privacy and

security violations in trigger-action applets.

Here, we replicate the analysis done by

Cobb et al. by considering semantic labels of

triggers and actions and contextual information

to investigate the role of context in capturing the

unintended accesses or information ﬂows. We also

show that in some cases contextual information alone

may not sufﬁce to accurately capture risks.

In particular, two authors independently reviewed

each usage scenario, applying violation labels based

on the context across multiple labeling batches. To

ensure the validity of labeling for violation determi-

nation, in every step, the two authors discussed their

assigned labels of each applet scenario in the batch

and agreed on the ﬁnal labels if their labels were not

matched. As the authors progressed through multi-

ple batches, the inter-rater reliability among them has

consistently improved and we could achieve a high

(Cohen’s K ˜.8) in the ﬁnal batch. Labeling was done

under the assumption that applets are installed in a

single resident one-bedroom apartment. Under this

assumption, the resident will be the only trusted per-

son for online and physical access.

Here, we compare the violation labels ob-

tained through our context-based evaluation with

those derived by applying the same rules used by

Table 1: Comparison of context-based and lattice-based de-

tection of integrity and secrecy violations in the synthesized

dataset. TP: True Positives, FP: False Positives

Secrecy

Lattice Context Count

(T=4104)

Per%

Violating Violating (TP) 304 24%

(1248) Non-violating

(FP)

944 76% (23%)

Non-violating Violating 99 3% (2%)

(2856) Non-violating 2757 97%

Integrity

Lattice Context Count

(T=3666)

Per%

Violating Violating (TP) 498 58%

(853) Non-violating

(FP)

355 42% (10%)

Non-violating Violating 1212 43% (33%)

(2813) Non-violating 1601 57%

Cobb et al. (Cobb et al., 2020) in the lattice-based

analysis of the applets. Table 1 shows a comparison

of the resulting secrecy and integrity violations. Over-

all, for secrecy violations, we found 1248 (out of 4104

unique applet scenarios) as violating using the lattice

model. However, only 304 among those 1248 were

labeled as secrecy violation when examining the sce-

nario using contextual information. Similarly for in-

tegrity violations, we found 853 (out of 3666 unique

applet scenarios) cases as violating using the lattice-

based approach. However, when examined using con-

textual information, only 498 of them have been con-

sidered to be an integrity violation, with the remaining

355 being labeled as non-violation.

The lattice-based approach over detected viola-

tions (i.e., false positives), ﬂagging 23% and 10% of

all applet scenarios (See the last column in the Ta-

ble 1) as secrecy and integrity violations respectively

when compared context-based evaluation. This is

somewhat unsurprising as the lattice-based approach

can be expected to be more conservative. However, a

signiﬁcant number of cases that are considered viola-

tions when using context-based analysis were missed

(i.e., ﬂagged as non-violations and hence false nega-

tives) by the lattice based approach. Speciﬁcally, 99

secrecy cases (2% of all applet scenarios) and 1212

integrity cases (33% of all applet scenarios) were

missed (see the last column in the Table 1). While

some of the missed violations can be rectiﬁed by us-

ing ﬁner grained lattice labels, our review found that

others are a symptom of more fundamental limita-

tions of the lattice-based approach. For instance, in

a lattice-based approach, the lattice labels for the trig-

ger and action are typically assigned independently.

Such independent labeling, irrespective of the context

of use, can lead to inaccurate violation detection.

Consider two groups of applets: (i) applets con-

necting a voice assistant (e.g., Alexa) to online ser-

vices (e.g., Google Calendar) to enable end users to

write into online services via a voice command (e.g.,

adding a to-do list to Google Calendar), (ii) applets

connecting a smart IoT device within the home (e.g.,

smart lock) to online services (e.g., Google Calendar)

to notify or log the status of the IoT device (e.g., when

the smart lock gets unlocked, add an event to Google

Calendar).

In both groups of applets, suppose given the con-

textual information, the integrity label for the action

is trusted implying that only a trusted user (e.g., the

owner) can modify the Google Calendar. In this sit-

uation, if anyone but the homeowner triggers the app

(interacts with the assistant or unlocks the lock), the

lattice-based analysis will mark both groups of ap-

plets as violating applets (information ﬂows from un-

Learning Personalized and Context-Aware Violation Detection Rules in Trigger-Action Apps

433

trusted to trusted). While this kind of reasoning can

capture the violations related to the ﬁrst group of ap-

plets, it does not accurately model the second group

of applets. For instance, if homeowners install (smart

lock app) for surveillance purposes, they would like

to monitor whenever the lock gets unlocked regard-

less of who is triggering the event. Hence, even if an

unauthorized person (untrusted source) triggers writ-

ing to Google Calendar (a trusted resource), from a

user perspective this is a valid usage and not a viola-

tion.

As these examples show, even if one were to integrate

contextual information into the lattice-based model

approach of (Surbatovich et al., 2017; Cobb et al.,

2020), such a model still cannot accurately detect vio-

lations. In other words, contextual information alone

may not lead to accurate decisions about violations;

user perspectives must also be taken into account, and

both trigger and action events need to be considered

together for a more accurate evaluation.

To accommodate such multiple attribute evalua-

tion, we propose to employ rule expression that en-

ables us to evaluate many different attributes together.

Further, to provide such personalization we investi-

gate how learning-based techniques perform in iden-

tifying violations.

5 LEARNING DETECTION

RULES

We explore how machine learning classiﬁcation

techniques can effectively learn end-user preferences

to identify applet usage scenarios that may lead to

violations based on contextual information. Recall

from Section 4 how determining violations not only

depends on the context of use, but also individuals’

preferences. We propose a framework that can learn

violation detection rules by taking into account both

these factors to create a more personalized and ﬂexi-

ble way to determine integrity and secrecy violations.

More speciﬁcally, we examine the effectiveness of

our learning framework to learn the violations from

end-users’ decisions on a set of applets and identify

violations for unseen apps. Two criteria, inspired by

prior work (Beckerle and Martucci, 2013; de Fortuny

and Martens, 2015) in rule mining and extraction in

access control, are used to assess our framework.

Classiﬁcation Performance. The model’s perfor-

mance reﬂects how accurately the generated rules

by the framework can classify usage scenarios as

violating or non-violating.

Complexity. As our goal is to help end users by auto-

matically learning violation detection rules, it is im-

portant that these rules not be overly complex to un-

derstand or to maintain. Prior literature (Smetters and

Good, 2009; Bauer et al., 2009) showed that end users

are more comfortable with fewer number of rules and

those that are simpler to understand. We use rule com-

plexity as a way to evaluate how effective our frame-

work is in reducing the complexity of ﬁnal rules in

terms of their length and number.

5.1 Learning to Identify Violations

We deﬁne the problem of violation identiﬁcation as

a supervised classiﬁcation problem. Speciﬁcally, we

aim to learn a “rule” that maps a tuple of a trigger,

action, and a set of contextual factors to binary labels

specifying whether or not the use case is a violation.

Classiﬁer Selection. Several popular supervised

classiﬁcation models such as Decision Tree, Random

Forest, Support Vector Machines, and Logistic

Regression can potentially be used to create a

context-based prediction model (Sarker et al., 2019).

Among these models, we decided to explore tree-

based models such as Decision Tree and Random

Forest, as they are easier to interpret as a set of rules

and thus more suitable for our application. However,

we also used a subset of other popular classiﬁcation

models, including Support Vector Machines and

Logistic Regression, to baseline the performance

of tree-based models and measure how well they

perform compared to other models. Hence, for

each classiﬁcation problem (integrity and secrecy

violation respectively), we investigated the above

four algorithms.

Dataset. We used the synthesized dataset described

in Section 3 to train and evaluate our machine learn-

ing models. The dataset consists of 39 applets and

is divided into two subsets, each corresponding to a

type of violation: integrity and secrecy. Each record

(row) in the dataset includes 8 contextual factors (See

Section 3).

Since the “Online Service Trustworthi-

ness/Secrecy” feature applies only to applets

connecting online services with IoT devices, we

combined it with trigger/action location for online

service events. This approach eliminated null values

in the dataset for applets without online services.

Table 2 shows the feature values in the datasets.

The ﬁnal dataset is a set of tuples in the form of

< T S,AS,T L,AL,T,V P, HP,V L > where

• TS → trigger device/service,

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

434

Table 2: Features and their values in the ﬁnal datasets.

Features

Trigger Device/Service (TS)

= {V: Voice command, WT: Weather or time, N: News-ish, DS: Sensing IoT device state, DS:S: Home

security, DS:A: Appliances, DS:L: Lights, E: Environment sensing, IC: Intentional communication, P: Change personal device state,

OAcc: Sensing online account state}

Action Device/Service (AS)

= {DS: Changing IoT device state, DS:S: Home security, DS:L: Lights, DS:A: Appliances, DS:P: Printer,

E: Environment sensing, L: Log or notify, P: Change personal device state, OC: Outgoing communication}

Trigger Location (TL) = {Trusted/Private Online Service, Untrusted/Public Online Service, Kitchen, Living Room, Bathroom, Bed-

room}

Action Location (AL) = {Trusted/Private Online Service, Untrusted/Public Online Service, Kitchen, Living Room, Bathroom, Bed-

room}

Time (T) = {Morning, Afternoon, Night}

Visitor Presence (VP) = {Visitor, No-visitor}

Homeowner Presence (HP) = {Present-awake, Present-asleep, Absent}

Violating class label (VL) = {Violating, Non-violating}

DS categories (S: Security, A: Appliances, L: Lights) are subtypes of IoT device states.

Table 3: Dataset. V: Violating, NV: Non-Violating.

Violation V NV Total

Secrecy 403 3701 4104

Integrity 1710 1956 3666

• AS → action device/service,

• TL → trigger location,

• AL → action location,

• T → the time of the day,

• VP → visitor presence,

• HP → homeowner presence, and

• VL → violating class label

Table 3 shows the details of the dataset. For

integrity violation, there are 1710 and 1956 records

for violating (V) and non-violating (NV) classes,

respectively. For secrecy violation, the dataset

includes 403 violating (V) and 3701 non-violating

(NV) instances. Finally, to prepare the datasets

for the experiments, we transformed all categorical

features into numeric values using Label Encoder

method. For example, the values of the feature Time

(Morning, Afternoon, and Night) gets translated into

numeric values (0, 1,2). While one-hot encoding

is a recommended encoding method for categorical

variables, this method will impact the complexity

of tree-based machine learning models by adding

dummy variables with values of 0 and 1 and the re-

sulting growth of trees in the direction of zero values.

To be sure, besides numeric encoding, we used One-

Hot Encoding and repeated all experiments. While

we could achieve better performance with other

machine learning models like SVM with one-Hot

Encoding, we did not observe a signiﬁcant difference

in the performance of the RF model. However,

one-hot encoding inﬂuenced the complexity of the

learned rules and caused a signiﬁcant decrease in the

performance after application of rule reduction steps

due to the presence of rules including zero values

for dummy variables. Our ﬁndings are consistent

with the experience of others (Gorman, 2017) that

indicated one-hot encoding would not have better

performance compared with a numeric encoding

when the cardinality of categorical variables is

smaller than 1000 for tree-based models.

Training Setup. The synthesized datasets for secrecy

violations is unbalanced between the number of vio-

lating and non-violating cases. To address this, we

applied random oversampling to the minority class

to create a better-balanced dataset and improve clas-

siﬁcation performance (Chawla et al., 2002). Fur-

ther, we used a nested cross-validation approach for

model evaluation and hyper-parameter optimization

that helps to overcome the problem of overﬁtting

the training dataset. Speciﬁcally, the outer cross-

validation procedure helps to evaluate the model on

unseen data, while the inner cross-validation helps

with ﬁnding optimal model parameters.

Within the outer cross-validation procedure, we

split the dataset into K = 5 folds. In each iteration,

we used the K −1 folds (80% of the entire dataset) for

training the model and one fold (20% of the dataset)

for testing it. The held-out fold helps to validate

model performance on unseen data. We split the

dataset using the Stratiﬁed-Group-K-Fold split tech-

nique to keep the distribution of both violating and

non-violating samples the same in the training and

testing splits. Speciﬁcally, we selected a subset of the

applets (and all combinations of the contextual fac-

tors) for the training and testing split, such that each

split had the same rate of violating and non-violating

samples. We used the applet number that identiﬁes a

unique applet as the group factor. We computed the

average performance scores across all K trials to re-

port the ﬁnal evaluation scores.

Next, in the inner cross-validation, we evaluated

different hyper-parameter combinations to ﬁnd the

Learning Personalized and Context-Aware Violation Detection Rules in Trigger-Action Apps

435

Table 4: Classiﬁcation results using different classiﬁcation models.

Secrecy Integrity

Model Precision Recall F1 Precision Recall F1

RF 0.93 0.91 0.91 0.77 0.75 0.75

DT 0.93 0.92 0.92 0.75 0.76 0.75

SVM 0.90 0.89 0.90 0.66 0.65 0.65

LR 0.83 0.83 0.83 0.53 0.53 0.52

Table 5: Classiﬁcation and complexity results using Random Forest (R#: The number of rules, V: Violating, NV: Non-

Violating)

Precision Recall F1 WSC (V, NV) R# (V, NV)

Secrecy 0.93 0.91 0.91 2065.8, 2522.6 167, 197

Integrity 0.77 0.75 0.75 8340.2, 8382.8 629, 611

best-performing model. We used grid search to

train each model on the training set and identify

the optimal settings for each classiﬁer model. To

achieve that, we split the training dataset (i.e., 80%

of total data obtained from the outer cross-validation

procedure) into K

′

subsets. Then we ﬁt the model

′

times on the K

′

− 1 folds and evaluated it on

the K

′

th fold. Using Scikit-Learn GridSearchCV,

we evaluated all hyper-parameter combinations and

ran the K-fold-CV (K

′

= 5) process for each of the

combinations.

Performance Evaluation. We implemented our

framework using Python and ran the experiments on

a 64-bit macOS 10.12 machine having 16 GB RAM

and Intel Core i5 processor. We conducted all experi-

ments on the synthesized data set, which was labeled

by two of the authors. We performed each experiment

10 times and report the average of the evaluation met-

rics in our experiments. We used precision, recall,

and F1-measure metrics to measure the performance

of the models’ prediction.

Table 4 shows the details of the results for the

best performance of each model (when testing on ap-

plets in the 20% data split). When predicting in-

tegrity violations, all models except Logistic Regres-

sion (LR) performed well, with Random Forest (RF)

and Decision tree (DT) doing the best–an F1-measure

of 0.75, followed by Support Vector Machine (SVM,

F1-measure = 0.65). For secrecy violations, DT per-

formed the best (F1-measure = 0.92), followed by RF

(F1-measure = 0.91), and then SVM and LR with

F1-measures of 0.90 and 0.83, respectively. These

models had similar precision and recall values, show-

ing that the models are well balanced in the number

of false positives and false negatives they generate.

Given the “good” performance of the classiﬁcation

models, we believe that a learning framework is a vi-

able solution in learning from users’ security and pri-

vacy preferences in a given use context from a set of

applets and applying this learning to identify viola-

tions in other applets.

For both types of violations the tree-based learn-

ing models performed better indicating that viola-

tion detection based on the usage context is not a

linear problem. The RF model consistently demon-

strated higher precision in detecting integrity viola-

tions, while both models (RF and DT) performed sim-

ilarly for secrecy violations. Although secrecy viola-

tion dataset is imbalanced, RF showed slightly better

generalization than DT due to its ensemble structure,

which reduces variance and helps prevent overﬁtting.

However, it is important to note that RF does not in-

herently address class imbalance and additional tech-

niques might be necessary to improve fairness. We

focus on the RF model in the rest of the paper due to

its overall stability and performance.

5.2 Violation Rule Complexity

Machine learning systems typically appear as “black

boxes” to end users (Kulesza et al., 2015) leav-

ing users unable to understand their behavior, which

creates a knowledge gap regarding model out-

puts (Miller, 2019). In this paper we chose to in-

vestigate tree-based learning models, which make it

easier to interpret the model’s “decision-making” as

conditional (IF-THEN) rules. Another advantage is

that end users may also extract and employ these rules

in existing frameworks for controlling IFTTT applets

(e.g., SOTERIA (Celik et al., 2018), IoTGuard (Ce-

lik et al., 2019), Expat (Yahyazadeh et al., 2019)) that

require users to provide a set of rules.

Several previous works have used Decision

Tree (DT) and Random Forest (RF) algorithms for

anomaly detection or access control policy min-

ing (Bui and Stoller, 2020) for similar reasons. Here,

we selected RF as it was the model with the best per-

formance in our experiments (See Table 4).

However, RF models can create very large rule

sets. Therefore, to create a manageable set of vi-

olation detection rules for human consumption, we

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

436

reduce the complexity of extracted rules from the

trained RF model through a series of steps. We use

Weighted Structural Complexity (WSC) as a metric

to measure the complexity of learned rules. WSC

was introduced for studying complexity of mined po-

lices in Role-Based Access Control (RBAC) (Mol-

loy et al., 2010) and Attribute-Based Access Control

(ABAC) (Xu and Stoller, 2014) systems. Informally,

for a given rule set, WSC is a sum of the WSC for all

of its rules. For each rule, WSC is a weighted sum of

the number of elements (features) in that rule. Here,

we set the weight for all features to be 1.

As Table 5 shows, the best performing RF models

contain about 364 and 1240 rules (totaling rules

for violating and non-violating cases) for secrecy

and integrity detection, respectively. The WSC

metric for these rules is around 4588 and 16723,

respectively. Given the high complexity of the ﬁnal

rules, we aim to reduce both the number of rules and

the WSC score through a series of reduction steps

applied to the extracted rules for each prediction class.

Extracting Rules. We convert each decision tree in the

RF model into a set of rules by traversing each distinct

path from the root to a leaf node representing a pre-

diction class (violating, non-violating). Each rule will

be in the form of a conditional statement (Equation 1),

where each condition is associated with a node on the

path. We split the ﬁnal ruleset into two sets, where

each set includes the rules for each prediction class.

One example of an extracted rule from the violating

class for integrity violation is shown in Equation 2.

R =







IF ( f

< v

) AND ( f

< v

) AND ...

THEN C

where f

is a contextual factor,

∈ (0,v

max

) and v

max

is the

maximum encoded numeric value of f

and C is the prediction class







(1)

Transforming Rules. In this step, to make the ap-

plication and evaluation of the reduction steps

easier, we transform each rule into a form that

enables us to compare their attributes. In this step,

we replace each condition in the rule of the form

( f

< or >= v

), where v

is a splitting point, with

a triple of F

= [ f

], where l

and u

are the

lower-bound and upper-bound values meaning the

minimum and maximum numeric values that the

feature f

can have, respectively. The ﬁnal rule

will be a vector < F

,...,F

,C > where C is the

prediction class. The transformation of the rule in

Equation 2 is shown in Equation 3. For instance,

the condition (Homeowner − Presence <= 0.5)

in R1 indicates that this factor only takes 0 value

meaning ‘the homeowner is present and awake.’ This

condition will be transformed to a triple in the form

of (Homeowner − Presence,0,0).

Reducing Redundant Features. The Random Forest

approach generates each decision tree based on ran-

domly selected features or combinations of features

at each node in each tree (Breiman, 2001). That is,

some features can be selected multiple times to split a

node. Hence, each rule can have multiple similar fea-

tures. To reduce the complexity of the rules, in this

step we merge the redundant features by selecting the

least upper bound and the greatest lower bound of the

feature values. For instance, in rule R1 in Equation 3,

Trigger-Semantic is a redundant feature that can be

replaced with a single triple (Trigger-Semantic, 4, 8).

R1 = [ IF (Homeowner - Presence ≤ 0.5)

AND (Trigger - Semantic > 3.5)

AND (Trigger - Semantic ≤ 8.5)

AND (Visitor - Presence ≤ 0.5)

AND (Trigger - Location ≤ 4.0)

THEN prediction - class = 1 ] (2)

R1 = [ (Homeowner - Presence, 0,0),

(Trigger - Semantic,4,8),

(Trigger - Semantic,0,8),

(Visitor - Presence,0,0),

(Trigger - Location,0,4),

prediction - class = 1 ] (3)

Reducing Subset Rules. The RF approach creates

multiple trees, and it is possible to have similar rules

across multiple trees or for a rule extracted from one

tree to be a subset of a rule extracted from a different

tree. Given two rules R

and R

, R

is a subset of rule

, if the interval of values of each feature in R

a subset of interval of values of the same feature in

. In such a case, having both rules R

and R

redundant. In this step, we eliminate such redundant

rules by removing the less restrictive one, in this case

Reducing Similar Rules: In this step we search for

similar rules in the ruleset and prune rules such that it

does not decrease the quality of the ruleset. We deﬁne

a ruleset quality metric by combining two metrics, F1-

measure and WSC, based on Van Rijsbergen’s effec-

tiveness measure (Van Rijsbergen, 1979), as was also

done by (Karimi et al., 2021). The ruleset quality met-

ric is deﬁned as follows:

Learning Personalized and Context-Aware Violation Detection Rules in Trigger-Action Apps

437

Table 6: Comparison of performance and complexity results of the lattice-based approach and violating and non-violating

rules before and after reduction. (R#: The number of rules, V: Violating, NV: Non-Violating)

Lattice-based Approach

Precision Recall F1 WSC (V, NV) R# (V, NV)

Secrecy 0.64 0.64 0.54 due to simplicity of the lattice

Integrity 0.54 0.58 0.47 the complexity is too small

Original Rules

Precision Recall F1 WSC (V, NV) R# (V, NV)

Secrecy 0.93 0.91 0.91 2065.8, 2522.6 167, 197

Integrity 0.77 0.75 0.75 8340.2, 8382.8 629, 611

Post-reduction Rules

Precision Recall F1 WSC (V, NV) R# (V, NV)

Secrecy 0.81 0.81 0.80 432.2, 635.4 67, 76

Integrity 0.74 0.73 0.73 2194.2, 2220 251,242

Q = (

F1 − measure

1 − α

∆W SC

)

−1

(4)

In the above equation, α shows the importance of

F1-measure metric over the ruleset complexity, and

∆W SC shows the relative reduction in WSC score of

the ruleset compared to the original ruleset. In each

step, we select a rule from one tree and ﬁnd a similar

rule in other trees.

We measure the similarity between two rules R1

and R2 based on Jaccard similarity which is deﬁned

as follows: J(R1,R2) = |R1 ∩ R2|/|R1 ∪ R2|. We

deﬁne two rules as similar if their Jaccard similarity

is more than 80%, which means the size of their

common feature values is more than 80% of the

size of the union of their feature values

. To prune

similar rules in each step, we pick two rules from two

different trees in the RF model and calculate their

similarity. If the similarity score is more than 0.8, we

decide to remove one of the two rules depending on

how much each of the rules will improve the quality

score of the rules set.

Combining Rules: While in the Reducing Subset

Rules step, we aimed to remove the rules that are

a subset of other rules in the ruleset, it is likely to

have rules with similar value intervals for all features

except one. This happens because, for each rule,

the algorithm only searches the subset rule until it

ﬁnds the ﬁrst one. Hence, the algorithm will not ﬁnd

all subset rules for each rule. In the last step, we

calculate the union of each two rules in the set having

the same set of features and are different in interval

value of only one feature. We add the union rule to

the ruleset and remove the other two rules.

Rule Reduction Evaluation. We assess rule reduction

by comparing the ﬁnal reduced rules with the original

Other work in access control mining (Karimi et al.,

2021) have used a 50% threshold, but we chose to be more

conservative to preserve prediction performance.

rules (extracted rules from the RF model before rule

reduction) based on rule complexity (number of rules

and WSC), similarity, and prediction performance.

Table 6 represents the precision, recall, F1-

measure, WSC score, and the number of rules be-

fore and after reduction steps for both secrecy and

integrity violations. Our proposed rule reduction pro-

cess could reduce the WSC and the number of rules

by about 77% (from 4588 to 1067) and 61% (from

364 to 143), respectively, while still obtaining 88% of

the original F1-measure for secrecy violations. For

integrity violations we could decrease the WSC by

about 74% (from 16723 to 4414), and the number of

rules by about 60% (from 1240 to 492) on average,

and achieve about 97% of the original F1-measure.

Comparing the ﬁnal rules before and after rule reduc-

tion steps with the lattice-based approach, while the

lattice-based approach employs simple rules (recall

from Section 2) to identify violations, it does not per-

form well when predicting violations obtaining F1-

measure 0.54 and 0.47 for predicting secrecy and in-

tegrity violations, respectively.

These ﬁndings suggest that we can simplify

learned rulesets with minimal performance loss. Fu-

ture work will explore how users can ﬁne-tune these

rules to their preferences and assess their maintain-

ability as new applets are installed.

6 DISCUSSION

6.1 Deployment Challenges

Collecting Contextual Information. Our proposed

approach requires usage context data (e.g., location,

time, presence etc.). The interplay among users,

the physical environment, and devices creates a

dynamic context, making it challenging to identify

and collect relevant information. While smart home

devices can likely provide this data, collecting it in

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

438

a real system may not always be easy or possible.

Existing frameworks like SmartThings enable users

to deﬁne and collect some contextual information

allowing them to set variables such as “home mode”

or designate device locations on a map. Similarly,

the presence of visitors can be detected using motion

sensors or features in smart-home apps (e.g., party

mode) (Chi et al., 2020). However, such functionality

varies by IoT frameworks and may not be available

in all frameworks. Additionally, users may opt not to

provide or update this information. So, along with

our rule learning module, we need to include options

for end users to identify such common situations

depending on the existing framework or include a

dedicated module to collect such information from

sensors.

Collecting Labelled Data for Training. Another de-

ployment challenge is access to enough training data

labelled by the the end user. Such data can potentially

be collected from the end-user during the ﬁrst few

days or weeks of training phase post deployment.

For instance, in a similar work HAWatcher (Fu et al.,

2021), the required data (22,655 events) is collected

during the three weeks of training phase. In another

work AEGIS (Sikder et al., 2019), the authors created

their required dataset consisting of over 55000

events in a 10-day period for anomaly detection in

smart homes. Data collection can include collecting

contextual information and user’s preferences of al-

lowing or not allowing an applet to run in that context.

Enforcement Mode. Violation detection approaches

can be categorized into inline or ofﬂine based their

enforcement mode. Inline approaches prevent po-

tential violations by intercepting requested actions at

runtime necessitating app or framework instrumenta-

tion to be able to intercept actions in real-time. But,

this mode also provides easy access to current con-

textual information. This approach taken by previous

works such as Expat (Yahyazadeh et al., 2019), and

IoTGuard (Celik et al., 2019).

On the other hand, our approach can be deployed

in a monitoring or advisory mode, collecting contex-

tual data through sensors and app logs, and notifying

users of potential violations. This reduces the burden

of having to instrument the apps or the frameworks

but does not prevent or block actions that can cause

violations. AEGIS (Sikder et al., 2019) is an example

of prior work using this deployment mode.

Multiple User Home Environment. We evaluated

our approach with a synthesized dataset for a sin-

gle resident home. However, smart homes conﬁg-

ured for multiple residents face greater challenges.

For instance, different roles in the home (e.g., kids,

teenagers, and spouses) would have different levels

of access to devices. Prior work, Kratos (Sikder et al.,

2020), has proposed an access control for such an en-

vironment. This framework introduces a formal pol-

icy language enabling users to deﬁne access control

policies with their priorities. However, this approach

still needs manual effort by the end user to deﬁne the

policies. Further, gathering sufﬁcient contextual in-

formation to identify which user is interacting with

the applet complicates the deployment of the learning

framework. One solution could be using multiple sen-

sors to collect contextual data. Previous research on

daily activity recognition (Dahmen et al., 2017) has

shown it’s possible to learn the location and activi-

ties of home members using data from smart sensors.

However, both the learning approach and the contex-

tual factors used may need to change signiﬁcantly to

accommodate multi-user home environments.

6.2 Future Work

Learned Rules as Predeﬁned Rules. Several studies

have proposed solutions for detecting violations

in smart-home environments (Celik et al., 2019;

Yahyazadeh et al., 2019). These solutions need

manually deﬁned violation detection rules or poli-

cies. Some of these solutions enable users to deﬁne

such policies using policy languages (Yahyazadeh

et al., 2019). However, deﬁning such policies is a

complex task for users. For instance, study (Cao

and Iverson, 2006) shows that deﬁning intended

access as an access control rule is a complex task

with a heavy cognitive workload for users. Another

study (Mazurek et al., 2010) shows that users ﬁnd

specifying ﬁne-grained access control policies a dif-

ﬁcult task. In these cases, learned violation detection

rules can be used as predeﬁned or suggested rules

in those frameworks. This requires studying the

feasibility of modifying rules learned for one user

for use by another user and efﬁcient mechanisms for

doing so.

Dynamic Security Labels. Discussion in Section 4

showed that static (context agnostic) lattice labels

used by prior lattice-based approaches (Surbatovich

et al., 2017; Cobb et al., 2020) could not always de-

termine the violations associated with trigger-action

apps accurately. The context of use varies among

different individuals, which would determine the

appropriate lattice label for an individual and their

speciﬁc use scenario. For example, a trigger device

in a living room might have a trusted label when

Learning Personalized and Context-Aware Violation Detection Rules in Trigger-Action Apps

439

only family members and an untrusted label when

having a guest. In another example, the owner may

assign a trusted label even if a guest is at home

because she/he trusts the guest. One approach could

be learning the lattice labels based on the usage

context and individual preferences. In this approach,

the labels of the triggers and actions would change

based on the detected context and customized based

on individuals’ preferences.

Actual Violations vs Mis-Classiﬁcations. The pro-

posed framework based on usage context has shown

promising results in detecting violations. However,

further research is needed to determine if users per-

ceive misclassiﬁed violations as actual violations. A

large-scale user study can help identify these prefer-

ences and determine if the misclassiﬁed violations are

actual violations for most users. Even if the study

were to show that the misclassiﬁed violations are not

actual violations, it emphasizes the importance of

users’ preferences in determining violations. There-

fore, it’s crucial to allow users to modify rules or train

the model based on their needs, creating an adaptive

learning environment for better performance and out-

comes. This approach will enable us to create a learn-

ing environment that adapts to users’ preferences, ul-

timately leading to better performance and outcomes.

7 RELATED WORK

Our work aims to help end users detect undesir-

able or unintended access to information and appli-

cations/devices enabled through the use of trigger-

action frameworks in smart homes.

Much work has been done to identify security

and privacy risks in smart homes and more gen-

erally in IoT eco-systems. Among those, one of

the most closely related to our work is by Surba-

tovich et al. (Surbatovich et al., 2017), who employed

lattice-based information ﬂow analysis to evaluate the

potential integrity and secrecy violations in a 20K

IFTTT dataset. They employed security labels for

triggers and actions and determined the violations us-

ing information analysis. Their result showed more

than 50% of the IFTTT applets would potentially

cause a violation. More recently Cobb et al. (Cobb

et al., 2020) adjusted the security lattice by adding

two more ﬁne-grained labels to the lattice. While

they showed that IFTTT applets are not as risky as

initially portrayed in (Surbatovich et al., 2017), they

found that the lattice-based approach still has signif-

icant false positives and negatives. They acknowl-

edged that more contextual information is needed to

better evaluate the secrecy and integrity violations in

smart homes. Our work shows that even with contex-

tual information, determining violations depends on

users’ preferences and isn’t straightforward.

Other works have addressed security and privacy

risks in smart-home environments using model check-

ing. For instance, SOTERIA (Celik et al., 2018) uses

the state model of an individual or set of apps to check

safety, security, and functional properties and iden-

tify violations. IoTGuard (Celik et al., 2019) pro-

poses a dynamic policy-based enforcement system to

evaluate user-deﬁned safety, security, and functional

properties using model checking. SAFECHAIN (Hsu

et al., 2019) uses model-checking to discover the priv-

ilege escalation and privacy leakage threats across IoT

apps. While SAFECHAIN uses the security labels

proposed by Surbatovich to deﬁne the threats, it can

consider the actual attribute values of the rules and

decrease the false positive rate in privacy leakage de-

tection compared to the lattice-based approach. How-

ever, all the above solutions rely on static predeﬁned

rules. If these rules are predeﬁned by system design-

ers, then end user preferences will be unaccounted for.

On the other hand, tasking end users to deﬁne such

rules would be burdensome. Our work would ease

making policy rules for these existing solutions.

There are also works that focused on implicit

and explicit interaction across IoT applications. For

instance, IoTMon (Ding and Hu, 2018) uses risk

analysis to discover the potential physical chan-

nel interaction across IoT apps. In another work,

Wang et al. (Wang et al., 2019) propose a tool, iR-

uler, to identify vulnerabilities among trigger-action

rules. They use the NLP technique to ﬁnd the in-

formation ﬂows between actions and triggers across

IFTTT applets. HomeGuard (Chi et al., 2020) lever-

ages SMT solvers to discover cross-app interference

threats. This solution ranks identiﬁed threats using

risk analysis, allowing end users to evaluate them by

risk scores. However, it does not detect threats in in-

dividual applets. HAWatcher (Fu et al., 2021) uses

data mining to predict anomalies in smart IoT device

behavior but only detects malfunctions and assumes

all installed smart home apps are benign.

Further, most of the above solutions did not pay

attention to the ease of use of their systems. Our goal

was to reduce the complexity of the rules and gen-

erate more explainable rules for users to deploy and

manage. The rule reduction techniques that we used

are similar to those used in other research areas like

access control systems (e.g., (Karimi et al., 2021)) to

extract simple access control policies.

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

440

8 CONCLUSION

This paper presents a learning framework for pre-

dicting integrity and secrecy violations in smart-home

IFTTT applets. The framework considers contextual

factors (location, time, app trustworthiness, and pres-

ence of visitors and homeowners) that impact these

violations. Trained on a synthesized dataset, the pro-

posed framework was able to detect integrity viola-

tions with an average of 0.77 precision, 0.75 recall,

and 0.75 F1-measure, and secrecy violations with an

average of 0.93 precision, 0.91 recall, and 0.91 F1-

measure. We also showed that a learning framework

that accounts for contextual factors and users’ pref-

erences performs better than using lattice-based ap-

proaches. Future work will explore how mined rules

can help users reﬁne their privacy and security prefer-

ences and how these rules can be transferred to other

users with similar privacy attitudes for scalability.

Acknowledgements

Much of the work was completed while Mahsa Saeidi

was a Ph.D. student at Oregon State University. We

thank Souti Chattopadhyay, Matt Jansen, and Turguy

Caglar for their efforts in labeling preliminary ver-

sions of the synthesized applet dataset.

REFERENCES

Bastys, I., Balliu, M., and Sabelfeld, A. (2018). If this then

what?: Controlling ﬂows in iot apps. In Proceed-

ings of the 2018 ACM SIGSAC Conference on Com-

puter and Communications Security, pages 1102–

1119. ACM.

Bauer, L., Cranor, L. F., Reeder, R. W., Reiter, M. K., and

Vaniea, K. (2009). Real life challenges in access-

control management. In Proceedings of the SIGCHI

Conference on Human Factors in Computing Systems,

pages 899–908.

Beckerle, M. and Martucci, L. A. (2013). Formal deﬁni-

tions for usable access control rule sets from goals to

metrics. In Proceedings of the Ninth Symposium on

Usable Privacy and Security, pages 1–11.

Breiman, L. (2001). Random forests. Machine learning,

45(1):5–32.

Bui, T. and Stoller, S. D. (2020). A decision tree learning

approach for mining relationship-based access control

policies. In Proceedings of the 25th ACM Symposium

on Access Control Models and Technologies, pages

167–178.

Cao, X. and Iverson, L. (2006). Intentional access manage-

ment: Making access control usable for end-users. In

Proceedings of the second symposium on Usable pri-

vacy and security, pages 20–31.

Celik, Z. B., McDaniel, P., and Tan, G. (2018). Soteria:

Automated iot safety and security analysis. In 2018

USENIX Annual Technical Conference (USENIX ATC

18), pages 147–158.

Celik, Z. B., Tan, G., and McDaniel, P. D. (2019). Iotguard:

Dynamic enforcement of security and safety policy in

commodity iot. In NDSS.

Chawla, N. V., Bowyer, K. W., Hall, L. O., and Kegelmeyer,

W. P. (2002). Smote: synthetic minority over-

sampling technique. Journal of artiﬁcial intelligence

research, 16:321–357.

Chi, H., Zeng, Q., Du, X., and Yu, J. (2020). Cross-app in-

terference threats in smart homes: Categorization, de-

tection and handling. In 2020 50th Annual IEEE/IFIP

International Conference on Dependable Systems and

Networks (DSN), pages 411–423. IEEE.

Cobb, C., Bhagavatula, S., Garrett, K. A., Hoffman, A.,

Rao, V., and Bauer, L. (2021). ” i would have to evalu-

ate their objections”: Privacy tensions between smart

home device owners and incidental users. Proc. Priv.

Enhancing Technol., 2021(4):54–75.

Cobb, C., Surbatovich, M., Kawakami, A., Sharif, M.,

Bauer, L., Das, A., and Jia, L. (2020). How risky

are real users’{IFTTT} applets? In Sixteenth Sym-

posium on Usable Privacy and Security ({SOUPS}

2020), pages 505–529.

Dahmen, J., Thomas, B. L., Cook, D. J., and Wang, X.

(2017). Activity learning as a foundation for security

monitoring in smart homes. Sensors, 17(4):737.

de Fortuny, E. J. and Martens, D. (2015). Active learning-

based pedagogical rule extraction. IEEE trans-

actions on neural networks and learning systems,

26(11):2664–2677.

Denning, D. E. (1976). A lattice model of secure informa-

tion ﬂow. Communications of the ACM, 19(5):236–

243.

Ding, W. and Hu, H. (2018). On the safety of iot de-

vice physical interaction control. In Proceedings of

the 2018 ACM SIGSAC Conference on Computer and

Communications Security, pages 832–846.

Fernandes, E., Paupore, J., Rahmati, A., Simionato, D.,

Conti, M., and Prakash, A. (2016). Flowfence:

Practical data protection for emerging iot application

frameworks. In 25th {USENIX} security symposium

({USENIX} Security 16), pages 531–548.

Fu, C., Zeng, Q., and Du, X. (2021).

{HAWatcher}:{Semantics-Aware} anomaly de-

tection for appiﬁed smart homes. In 30th USENIX

Security Symposium (USENIX Security 21), pages

4223–4240.

Gorman, B. (2017). Visiting: Categorical features and en-

coding in decision trees. https://towardsdatascience.c

om/visiting-categorical-encoding-techniques-in-dec

ision-trees-74f40d3a5d3d. Accessed: 2025-04-28.

He, W., Golla, M., Padhi, R., Ofek, J., D

urmuth, M., Fer-

nandes, E., and Ur, B. (2018). Rethinking access con-

trol and authentication for the home internet of things

Learning Personalized and Context-Aware Violation Detection Rules in Trigger-Action Apps

441

(iot). In 27th USENIX Security Symposium (USENIX

Security 18), pages 255–272.

He, W., Zhao, V., Morkved, O., Siddiqui, S., Fernandes, E.,

Hester, J., and Ur, B. (2021). Sok: Context sensing

for access control in the adversarial home iot. In 2021

IEEE European Symposium on Security and Privacy

(EuroS&P), pages 37–53. IEEE.

Hsu, K.-H., Chiang, Y.-H., and Hsiao, H.-C. (2019).

Safechain: Securing trigger-action programming from

attack chains. IEEE Transactions on Information

Forensics and Security, 14(10):2607–2622.

IFTTT (2019). If this, then that (ifttt). https://www.ifttt.co

m/. Accessed: 2025-04-28.

Jin, H., Liu, G., Hwang, D., Kumar, S., Agarwal, Y., and

Hong, J. I. (2022). Peekaboo: A hub-based approach

to enable transparency in data processing within smart

homes. In 2022 IEEE Symposium on Security and Pri-

vacy (SP), pages 303–320. IEEE.

Karimi, L., Aldairi, M., Joshi, J., and Abdelhakim, M.

(2021). An automatic attribute based access control

policy extraction from access logs. IEEE Transactions

on Dependable and Secure Computing.

Kulesza, T., Burnett, M., Wong, W.-K., and Stumpf, S.

(2015). Principles of explanatory debugging to per-

sonalize interactive machine learning. In Proceedings

of the 20th international conference on intelligent user

interfaces, pages 126–137.

Lee, H. and Kobsa, A. (2016). Understanding user privacy

in internet of things environments. In 2016 IEEE 3rd

World Forum on Internet of Things (WF-IoT), pages

407–412. IEEE.

Lee, H. and Kobsa, A. (2017). Privacy preference model-

ing and prediction in a simulated campuswide iot en-

vironment. In 2017 IEEE International Conference

on Pervasive Computing and Communications (Per-

Com), pages 276–285. IEEE.

Mazurek, M. L., Arsenault, J., Bresee, J., Gupta, N., Ion, I.,

Johns, C., Lee, D., Liang, Y., Olsen, J., Salmon, B.,

et al. (2010). Access control for home data sharing:

Attitudes, needs and practices. In Proceedings of the

SIGCHI Conference on Human Factors in Computing

Systems, pages 645–654.

McLaughlin, S. (2021). Ifttt pro offers advanced features for

a monthly subscription. https://techxplore.com/news/

2020-09-ifttt-pro-advanced-features-monthly.html.

Accessed: 2025-04-28.

Microsoft Corporation (2019). Microsoft ﬂow: Automate

processes and tasks. https://ﬂow.microsoft.com/.

Accessed: 2025-04-28.

Miller, T. (2019). Explanation in artiﬁcial intelligence: In-

sights from the social sciences. Artiﬁcial intelligence,

267:1–38.

Molloy, I., Chen, H., Li, T., Wang, Q., Li, N., Bertino, E.,

Calo, S., and Lobo, J. (2010). Mining roles with multi-

ple objectives. ACM Transactions on Information and

System Security (TISSEC), 13(4):1–35.

Naeini, P. E., Bhagavatula, S., Habib, H., Degeling, M.,

Bauer, L., Cranor, L. F., and Sadeh, N. (2017). Pri-

vacy expectations and preferences in an iot world. In

Thirteenth Symposium on Usable Privacy and Secu-

rity (SOUPS 2017), pages 399–412.

Saeidi, M., Calvert, M., Au, A. W., Sarma, A., and Bobba,

R. B. (2020). If this context then that concern: Explor-

ing users’ concerns with ifttt applets. arXiv preprint

arXiv:2012.12518.

Sarker, I. H., Kayes, A., and Watters, P. (2019). Effective-

ness analysis of machine learning classiﬁcation mod-

els for predicting personalized context-aware smart-

phone usage. Journal of Big Data, 6(1):1–28.

Sikder, A. K., Babun, L., Aksu, H., and Uluagac, A. S.

(2019). Aegis: A context-aware security framework

for smart home systems. In Proceedings of the 35th

Annual Computer Security Applications Conference,

pages 28–41.

Sikder, A. K., Babun, L., Celik, Z. B., Acar, A., Aksu, H.,

McDaniel, P., Kirda, E., and Uluagac, A. S. (2020).

Kratos: Multi-user multi-device-aware access control

system for the smart home. In Proceedings of the 13th

ACM Conference on Security and Privacy in Wireless

and Mobile Networks, pages 1–12.

Smetters, D. K. and Good, N. (2009). How users use ac-

cess control. In Proceedings of the 5th Symposium on

Usable Privacy and Security, pages 1–12.

Surbatovich, M., Aljuraidan, J., Bauer, L., Das, A., and Jia,

L. (2017). Some recipes can do more than spoil your

appetite: Analyzing the security and privacy risks of

ifttt recipes. In Proceedings of the 26th International

Conference on World Wide Web, pages 1501–1510.

International World Wide Web Conferences Steering

Committee.

Van Rijsbergen, C. J. (1979). Information retrieval. 2nd.

newton, ma.

Wang, Q., Datta, P., Yang, W., Liu, S., Bates, A., and

Gunter, C. A. (2019). Charting the attack surface

of trigger-action iot platforms. In Proceedings of the

2019 ACM SIGSAC conference on computer and com-

munications security, pages 1439–1453.

Washington State University (2019). Wsc datasets. http:

//casas.wsu.edu/datasets/. Accessed: 2025-04-28.

Xu, Z. and Stoller, S. D. (2014). Mining attribute-based ac-

cess control policies. IEEE Transactions on Depend-

able and Secure Computing, 12(5):533–545.

Yahyazadeh, M., Podder, P., Hoque, E., and Chowdhury, O.

(2019). Expat: Expectation-based policy analysis and

enforcement for appiﬁed smart-home platforms. In

Proceedings of the 24th ACM Symposium on Access

Control Models and Technologies, pages 61–72.

Zapier Inc. (2019). Zapier: Automate workﬂows. https:

//zapier.com/. Accessed: 2025-04-28.

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

442
