Modular Simulator for DAE-Based Systems Using DEVS Formalism

Aya Attia

, Cl

ement Foucher

and Luiz Fernando Lavado Villa

LAAS-CNRS, Universit

e de Toulouse, UPS, Toulouse, France

ﬂ

Keywords:

Theory of Modeling and Simulation, Differential-Algebraic Equation, Model Transformation, DEVS,

Symbolic Computations, Graph Grammar, Load Flow Analysis.

Abstract:

Modeling and Simulation of dynamic structure systems present some difﬁculties, particularly those repre-

sented by Differential-Algebraic Equations (DAEs), as structural changes often require modifying equations.

To address this, we propose a methodology to build simulators based on Theory of Modeling and Simulation,

laying as a foundation for rigorously handling such systems. Our proposal consists of a modular, domain-

independent simulator where system’s behavior can be represented by DAEs. Systems are represented as

graphs, dynamically updated at each step based on predeﬁned scenarios. The simulator automatically gener-

ates and processes equations using transformation rules applied to input graphs. To demonstrate the feasibility

of our proposal, we apply it to the domain of power systems, particularly the Load Flow Analysis process.

1 INTRODUCTION

Dynamic structure systems are characterized by a

composition and internal connections that can evolve

over time. The ever-changing nature of dynamic

structure systems leads to difﬁculties to provide a

formal representation that can be adjusted to ﬁt sys-

tem’s structural changes, notably, in systems where

models are represented by DAEs. Adapting to these

structural changes often requires modifying the equa-

tions themselves, which represent a break in the sim-

ulation ﬂow. Power systems are a concrete exam-

ple of dynamic structure systems that can be repre-

sented by DAEs. These systems may undergo struc-

tural changes when there is a fault, a black start or

a grid expansion. This challenge highlights the need

for formal approaches that provide seamless integra-

tion of mathematical rigor with practical adaptability.

The Theory of Modeling and Simulation (Zeigler

et al., 2018) provides a robust framework for this pur-

pose. Notably, the Discrete Event System Speciﬁca-

tion (DEVS) formalism provides a root approach to

build models. Despite the theoretical strength of the

DEVS formalism, in practice its implementation re-

mains a signiﬁcant challenge. Due to the very low

level of the formalism, it may be hard to provide

a mathematical description of the model, therefore,

https://orcid.org/0000-0002-8610-1851

https://orcid.org/0000-0001-9566-4173

https://orcid.org/0000-0002-7157-5106

developers usually go straight to the implementation

without building a formal model (Blas et al., 2023).

This difﬁculty highlights a recurring issue: the gap

between a strong mathematical formalism and its ac-

tual concrete implementation.

To address this, our goal is to take a formal

approach for the conception of a generic simulator

adapted to various ﬁelds of applications. This sim-

ulator should be conceived in a way that allows it to

handle structure changes in the systems using a set

of rules. In this article, we present the ﬁrst step to-

ward this approach: the root structure of a simulator

built using the DEVS formal speciﬁcation. It bridges

the gap between theoretical formalism and practical

implementation, offering a structured method for cre-

ating models and implementing them. To achieve

this, we base our simulator on the DEVS formal-

ism by providing a generic library of DEVS com-

ponents that can be assembled to create the simula-

tor. Input models of the simulator are represented

as graphs, a powerful yet simple formalism for rep-

resenting components and their connections. Finally,

using model transformations directly within the sim-

ulator, the graphs are turned into DAEs and processed

using symbolic computations. Symbolic computa-

tions ensure that executable description of system’s

components is conform to formal one. Our proposal

can be tailored to various domains using the provided

components that can be customized to carry on the

speciﬁc computations needed by a particular domain.

270

Attia, A., Foucher, C. and Villa, L. F. L.

Modular Simulator for DAE-Based Systems Using DEVS Formalism.

DOI: 10.5220/0013514100003970

In Proceedings of the 15th International Conference on Simulation and Modeling Methodologies, Technologies and Applications (SIMULTECH 2025), pages 270-277

ISBN: 978-989-758-759-7; ISSN: 2184-2841

2 BACKGROUND AND RELATED

WORK

This section provides an overview of the key concepts

and techniques underlying our proposed approach.

2.1 The Theory of Modeling and

Simulation

Complex systems modeling and simulation repre-

sent a major challenge in various ﬁelds. The The-

ory of Modeling and Simulation (TM&S) provides a

structured approach using formalisms such as DEVS.

DEVS is a modular formalism that uses discrete

events to trigger computations at speciﬁc points in

time. However, as it is very low-level, it may be hard

to express complex models purely in terms of DEVS

models. DEVS has been provided various extensions,

and we will here use the Parallel-DEVS (PDEVS)

variant (Chow and Zeigler, 1994) that allows for par-

allelism in models execution.

In the TM&S approach, the term model can refer

to two representations of a system: formal model or

executable model. The formal model, also known

as mathematical or abstract model, is a type of rep-

resentation that follows the mathematical grammar of

the formalism in order to provide a formal represen-

tation of the system model. On the other hand, the

executable model, or concrete model, is derived by

translating abstract models into computer programs,

which are then integrated with a simulator capable of

executing the deﬁned functions of these models. The

formal deﬁnition of a PDEVS model uses the follow-

ing description: M =< X,Y, S, δ

ext

, δ

int

, δ

con

, λ,ta >

In a DEVS formalism, a model is deﬁned by sets

and functions. The sets include the inputs X, the out-

puts Y, and the internal state S. The behavior of the

model is described through core functions that gov-

ern its dynamics. The external transition function

(δ

ext

) updates the system’s state in reaction to input

events. The internal transition function (δ

int

) man-

ages the system’s autonomous transitions and is in-

voked when the time allocated to a state (t

(s)) ex-

pires, also triggering the output function (λ). As the

PDEVS formalism is an extension of DEVS that han-

dles concurrent events, it uses the conﬂuent transition

function (δ

con

) to resolve conﬂicts.

Formal models are translated to executable code

that can be run using simulators. The goal of simu-

lators is to reproduce the behavior of a real system in

a virtual environment, using models, input data, and

speciﬁc parameters. TM&S constituents and their re-

lationships can be represented by Figure 1. In this

ﬁgure, we explicitly make the difference between the

Meta-model

Abstract models syntax Abstract simulator

Formal model

Executable models Executable simulator

realization

implemented

into

represented

realization

System of interest

Software implementation

0..*

instance of

1..*

1 1

0..1

0..*

Figure 1: TM&S structural diagram.

formal model, which uses the mathematical syntax of

the meta-model, and the executable model which is an

implementation of the abstract model within a soft-

ware simulation tool. However, it is often the case

that the formal model deﬁnition is skipped in favor of

describing the model directly into the simulator (Blas

et al., 2023). While this should not be an issue if the

simulator conforms to the formalism, problems arise

when the simulator allows for some ﬂexibilities that

are not present in the formalism. The modeler can

then be at risk of accidentally breaking the rules of

the formalism without noticing it, which can lead to

fundamentally incorrect models that behave in an un-

predictable way over the simulation course.

2.2 Symbolic Computations

Symbolic computation, or computer algebra, deals

with the automatic generation using computer algo-

rithms of mathematical equations, functions and for-

mulas based on symbols and algebra rules (Buch-

berger, 1996). Through the use of symbolic compu-

tation, mathematical expressions can be represented

with the same strictness as they would be in an ab-

stract model. Symbolic computations can be provided

by various software tools like SymPy (Meurer et al.,

2017), Mathematica (Trott, 2007), Maple (Caravantes

et al., 2019), etc. In this work, we chose to use sym-

bolic equations as the base data that will be acted on

by our simulator. The components of the simulator

will communicate data between each other in the form

of equations, variables and values that they will use to

compute the results of the simulation.

2.3 Graphs

Graphs (Bickle, 2020) are mathematical structures

that can be used to model complex systems in various

domains. The modeling process using graphs consists

in sets of vertices, also called nodes, which repre-

sent system components, and edges, also called links,

which represent the relationships between system’s

Modular Simulator for DAE-Based Systems Using DEVS Formalism

271

components. The interactions between components

are provided by the incidence function ψ which maps

an edge to a pair of vertices. Graph grammar (Xu,

2013) is described by: G = (V, E, ψ), where V and E

are ﬁnite sets that represent the vertices and edges re-

spectively, and ψ a mapping function with domain E

and co-domain V ×V .

Combining graph grammar and Chomsky’s gener-

ative grammars (Chomsky, 1956), it is possible to in-

troduce dynamic structure to the system thanks to pro-

duction rules that deﬁne how the system’s structure

and composition change over time (Bouassida Ro-

driguez et al., 2010). These evolving graphs can be

represented as follows: G =< AX, NT, T, P >, where

AX is the axiom, NT denotes the set of non-terminal

vertices, T the set of terminal vertices, and P the set

of transformation rules. Figure 2 visualizes the con-

cept of graph grammar and its transformation using

Chomsky’s generative grammars.

vertices

graphs

transformation

edges

Figure 2: Graph grammar and its transformation.

We chose graphs as the base grammar for systems

representation for their simplicity and ability to rep-

resent system changes based on transformation rules.

2.4 Power Systems and LFA

Power systems is a ﬁeld of electrical engineering that

studies energy distribution and management (Weedy

et al., 2012), typically involve three main elements:

electrical components (such as generators and loads)

that either consume or produce electrical energy,

buses that interconnect nearby electrical components,

and transmission lines that ensure the transfer of

electrical ﬂow between buses over long distances.

Load Flow Analysis (Albadi and Volkov, 2020),

also known as power ﬂow analysis, is a method used

in the electrical engineering ﬁeld to evaluate and an-

alyze the behavior of electrical networks. This tech-

nique aims to check the steady-state of operating con-

ditions of a power system. A power system is char-

acterized by the following variables: voltage magni-

tudes V (the amplitude of voltage at a bus), angles

δ (the phase shift of a bus voltage relative to a refer-

ence bus), active power P (the power transmitted to

system loads), and reactive power Q (the non-useful

power required to maintain system operation).

The generated results of Load Flow Analysis are

used to make important decisions in planning, design-

ing and operating electrical networks. In particular,

equipment sizes, load ﬂows optimization and evalua-

tion of the stability of the system in response to load

variations and external perturbations.

Many simulators were developed in order to

model power systems, including many based on

MATLAB/Simulink such as (Chaturvedi, 2017). An-

other example of power systems modeling based

on mathematical equations as models can be found

in (Sadnan and Dubey, 2021). This work aims to

model power system using equations that represent

the behavior and interactions of various components

in the power distribution system. Numerous soft-

ware tools dedicated for power systems were created

like RAPSIM (P

ochacker and Elmenreich, 2014),

HOMER (Energy, 1993). Despite their powerful fea-

tures, these are closed tools that must be used as they

are (de Durana et al., 2014). This prevents checking

the simulator itself for ﬂaws in the design or simula-

tion algorithm.

3 FORMAL APPROACH FOR

M&S DAE-BASED SYSTEMS

Our approach focuses on creating a simulator for

DAE-based systems. Our contribution aims to pro-

vide a proposal that is formally deﬁned and can be

used in diverse domains and applications. Applied to

LFA, this simulator is able to simulate static power

grid, and represents a preliminary for future work

on simulating dynamic-structure grids. This proposal

is designed around solid bases such as graphs, the

DEVS formalism and symbolic computations. The

approach we propose consists in three layers, each

addressing a different aspect for M&S of DAE-based

systems as shown in Figure 3. Each layer builds on

rules and structures deﬁned in its underlying layers.

layer 3:

system

speciﬁcation

layer 2:

speciﬁc-domain

abstraction

layer 1:

context-free framework

Figure 3: Multi-layer proposed approach for M&S.

3.1 Layer 1 - Context-Free Framework

The context-free framework represents the root layer

of our approach. This layer consist in a general simu-

lator architecture and a library of generic DEVS com-

ponents. It is deﬁned once and for all and is indepen-

SIMULTECH 2025 - 15th International Conference on Simulation and Modeling Methodologies, Technologies and Applications

272

dent from the domain of application and the simulated

systems. This general simulator architecture can be

adapted to various ﬁelds by assembling and special-

izing the generic components in order to perform the

speciﬁc computations required by the domain.

This architecture, presented in Figure 4, is com-

posed of a clock and three primary blocks: the data

management, the mathematical symbols generator

and the computational engine.

data

management

mathematical

symbols

generator

computational

engine

clock

Figure 4: Proposed simulator architecture.

The clock orchestrates the simulation by provid-

ing time steps to data management block. The data

management block treats the input data, runs the

given scenarios (that represent how changes occur

in systems properties over time, these scenarios are

speciﬁed in the third layer), and prepares the nec-

essary outputs for the next steps in the simulation

workﬂow. The output data of this block is sent to

the mathematical symbols generator block to gener-

ate mathematical symbols that represent system prop-

erties. The computational engine proceed to compu-

tations related to speciﬁc needs described into the spe-

ciﬁc domain abstraction layer. Each block has to be

speciﬁed in the second layer as an assembly of com-

ponents from the library in order to deﬁne a base al-

gorithm for a speciﬁc domain. We further detail the

library of components available to build each of these

blocks in Section 4.

3.2 Layer 2 - Speciﬁc Domain

Abstraction

This second layer focuses on developing the abstract

requirements related to a speciﬁc domain. This layer

has to be done once for each domain of application we

want to support with our approach. This currently has

been done for LFA, as will be presented in Section 5.

One aspect of this layer is the deﬁnition of a

Domain-Speciﬁc Modeling Language (DSML) (Blas

et al., 2023), which rigorously identiﬁes the main con-

stituents of any given domain. Within this layer, we

deﬁne the key properties and characteristics of a spe-

ciﬁc domain to achieve the following objectives:

1. Build a graph-based DSML for the domain.

2. Deﬁne the transformation rules that allow to trans-

form graph-based models into equations.

3. Implement an actual simulator for the domain,

based on simulator structure deﬁned in ﬁrst layer.

The graph-based syntax is deﬁned by specifying the

nodes and edges properties in order to provide a rep-

resentation of systems from the target domain that

contains all the information required to generate the

equations to solve. We also have to specify the trans-

formation rules that guide the conversion from graph

syntax to obtain the DAEs that represent the system.

In order to implement a simulator for a given do-

main, we study the base algorithms that describe the

workﬂow in use within that domain. These algo-

rithms, as well as the transformation rules deﬁned pre-

viously, are used to build the simulator. This is done

by assembling the generic DEVS components avail-

able in the component library and specifying their ab-

stract parameters.

3.3 Layer 3 - System Speciﬁcation

The third and ﬁnal layer consists in representing a

speciﬁc system in the domain of interest, as well as

a scenario that represents the system evolution over

time. A graph representing the system is injected into

the simulator that was built for the domain, along with

the scenario. The execution of the scenario over the

base system generates the necessary data for the evo-

lution of values directly within the simulator. The

simulator then outputs the results in the form of new

graphs with updated values at each time step.

4 LIBRARY OF GENERIC

COMPONENTS

We have organized the simulator into distinct blocks,

each representing a core functionality as represented

in Figure 4. To build each block, we provide a library

of generic components. The set of components pre-

sented here forms a basis, but is not extensive yet. It

still needs extension to provide all the required tools

that may be necessary for comprehensive support of

symbolic computation. For now, only the components

required by our target domain were deﬁned.

Each of the components described here is for-

mally speciﬁed using the DEVS mathematical syn-

tax. These formal deﬁnitions are available in the

documentation of our git repository (Attia, 2025).

The components also have a concrete implementa-

tions that was done using the PyPDEVS simula-

tor (Van Tendeloo and Vangheluwe, 2015) and are

available in the demonstrator for the LFA use case,

also provided in the same git repository. For the con-

crete implementation of these components, the sym-

bolic computation part is taken care of by SymPy. Ad-

ditionally, system’s graph representation is carried out

Modular Simulator for DAE-Based Systems Using DEVS Formalism

273

using GraphML (Brandes et al., 2010). In the follow-

ing, we detail each block of the simulator, and the

base components available as of today in the library.

In the data management block, the data genera-

tor component provides input data to the simulator as

a graph representing the system and simulation sce-

narios. The execution result produces input data in the

form of a graph with updated property values reﬂect-

ing system’s current state. The process data com-

ponent receives these generated graphs, extracts their

nodes and edges, and organizes them into structured

data usable by other components.

The mathematical symbols generator block in-

cludes three components. The symbols genera-

tor component receives structured data and gener-

ates mathematical symbols for the system’s proper-

ties. The equations generator takes structured data

and the set of symbols as inputs to generate equations

addressing the core computations of a particular do-

main. The mapping symbols values component gen-

erates, from the structured data and received symbols,

a set of pairs containing symbols and their associated

numerical values.

In the computational engine block, the compute

equations component performs speciﬁc calculations

needed to solve particular domain equations, often in-

volving iterative algorithms or domain-speciﬁc math-

ematical operations. It substitutes symbols with their

concrete values and evaluates equations. The conver-

gence checker determines whether calculated values

will diverge or converge. If convergence is achieved,

the solving process has reached a steady state and it-

erative computations are stopped. Otherwise, it sends

a message to other components to continue iterative

computations and adjusts simulation parameters.

Components from the library are generic and thus

make use of parameters. The parameters can be val-

ues, variables or functions which are initially abstract,

meaning that they are not yet speciﬁed. These param-

eters are speciﬁed at layer 2 when building the simu-

lator for a speciﬁc domain.

All the components, except for the clock, are time-

less. From a DEVS perspective, this means that their

internal state change (δ

int

) is carried on either in-

stantly (t

= 0) or never (t

= ∞). In that second case,

the state change can only be triggered by an exter-

nal event (δ

ext

). From the simulation perspective, this

means that the simulated time will never evolve as a

result of a component changing its state. Only the

clock has a function of time t

that will make the sim-

ulator time evolve. This behavior is dictated by the

fact that the components we deal with here are not part

of a system simulation, they rather are the simulator.

Of course, working with components whose evolution

is done in zero-time can lead to issues such as inﬁ-

nite events being triggered without the time advanc-

ing, leading to a stuck simulation. In our case, this

is solved by carefully designing the abstract compo-

nents so that they wait for all their required data to be

received before emitting events themselves. As this

precaution is taken at the generic component level,

the specialized components used in an actual simu-

lator won’t have to deal with that issue.

5 APPLICATION: LFA OF

POWER SYSTEMS

In this section, we apply our approach to the domain

of power systems by building a simulator able to con-

duct a LFA. The traditional workﬂow for conducting

a LFA is represented in the Figure 5. The process be-

Δ[unkown_parameters]

(k)

-> 0

Write the admittance, P, Q and Jacobian

matrices containing the respective equations

Evaluate equations of admittance and Jacobian matrices

Evaluate P

(k)

and Q

(k)

of given parameters

Compute ΔP

(k)

and ΔQ

(k)

of given parameters

Compute Δ[unknown_values]

(k)

= [Jacobian_matrix]

-1

* Δ[P_Q_values]

(k)

Compute V

(k)

and δ

(k)

from Δ[unknown_values]

(k)

Update buses data with new values of V and δ computed

k = k + 1

Evaluate unknowns (P and Q) that will be computed with resolved values

k=1

Yes

Figure 5: Flowchart of a typical LFA process.

gins with formulating the mathematical structures re-

quired for LFA (yellow frame). Then, an iterative pro-

cess is conducted (gray frame) that corresponds to the

Newton-Raphson method (Akram and Ann, 2015).

This ﬂowchart will be used as a base to conduct the

application.

5.1 Power Systems Graph DSML

Using the characteristics of power systems as deﬁned

in Section 2.4, we establish the abstract syntax of

power systems as graphs. The usual representation

of power systems have a quite natural translation to

graphs, as illustrated in Figure 6.

We deﬁne the syntax of the graph as follows:

- Nodes (Vertices) V : is the set of buses. Each bus

SIMULTECH 2025 - 15th International Conference on Simulation and Modeling Methodologies, Technologies and Applications

274

Bus 1

Bus 2

represented

as graph

Bus 3

Figure 6: Power system representation with graph.

can contain one or multiple interconnected electrical

components (e.g., load, battery, wind turbine, etc.).

Each node v

∈ V has several attributes that describe

its electrical properties: bus type (bus type), bus num-

ber (bus no), active power (P), reactive power (Q),

voltage magnitude (V ), voltage angle (δ). To these in-

trinsic characteristics, we add the list of unknown it-

erative variables (it unknown), which refers to the set

of variables whose values are initially unknown and

have to be determined iteratively. During the analysis,

these variables are updated repeatedly using compu-

tational algorithm until the solution converges. Each

node can be described formally as:

= {bus type, bus no, P, Q,V, δ, it unknown}

- Edges E: is the set of electrical transmission

lines that ensures the connection between two nodes.

Each edge e

i j

∈ E represents an electrical connection

between two buses and has the following attributes:

resistance (R), reactance (X), line charging capacity

(L), and transformer tap (T ).

Formally, an edge between nodes v

and v

is de-

scribed as: e

i j

= {R, X,L, T}

- Mapping function ψ: this function associates to

each edge the pair of nodes it connects. It operates as

follows: ∀ e

i j

∈ E, ψ(e

i j

) = (v

, v

)

5.2 Graph to Equations Transformation

Rules

Based on the LFA workﬂow (Figure 5), we have to

produce a few transformation rules to generate the

mathematical objects required to conduct the analy-

sis. As shown in Figure 7, the ﬁrst rule consists in

generating the admittance matrix from graph’s edges.

The second rule aims to map graph’s nodes to gener-

ate P and Q equations. Finally, the third rule consist

in generating the Jacobian matrix from graph’s nodes

and the generated P and Q equations.

5.3 Simulator Speciﬁcation

By following these transformation rules as well as the

Newton-Raphson algorithm as deﬁned in Figure 5, we

specify a simulator that is represented on Figure 8.

We developed this simulator by exploiting the library

of generic components described into Section 4.

Rule 2: nodes → mathematical symbols (P , Q, V , δ)

Vertice properties:

- bus_type

- bus_no

- P

- Q

- V

- δ

Edges properties: R, X, L, T

Rule 1: edges → admittance matrix Y

Rule 3: nodes → iteration mathematical symbols (P , Q, V , δ)

Figure 7: Transformation rules.

The data management block generates a graph

that represents the system’s data. The mathematical

symbols generator block receives this data and imple-

ments the transformation rules. We used the symbols

generator component to create symbolic representa-

tions of the system’s essential data, including the volt-

age, resistance, reactance, P, Q etc. Multiple instances

of the equations generator component exploit these

symbols to generate the admittance, P, Q and Jaco-

bian matrices equations In addition, to provide sys-

tem’s data values we use the symbols numerical val-

ues component to introduce the corresponding values

of deﬁned symbols.

The iterative process is implemented within the

computational engine block of the simulator. This

block instantiate the compute equations component

that use the data provided by the mathematical sym-

bols generator block to compute the admittance, P,

Q and Jacobian matrices, and another instance of the

same component uses this data to process to the global

LFA computations. The iterative process is achieved

by an event sent by convergence checker to inform the

other components if convergence is reached or not.

Once convergence is reached, the system uses yet

another instance of compute equations to compute the

speciﬁed P and Q equations that should be computed

as results, along with the associated variables, and

reinjects the results into the data management block.

Using data received from the computational en-

gine block and the evolution scenario of the power

system, the data management block generates a new

graph. This graph represents the updated state of the

system that can be used in the next simulation step.

Modular Simulator for DAE-Based Systems Using DEVS Formalism

275

mathematical symbols generator

data management

admittance:

equations

generator

computational engine

jacobian:

equations

generator

symbols

generator

LFA data:

process

data

jacobian:

compute

equations

admittance

compute

equations

PQ:

equations

generator

symbols

numerical

values

PQ:

compute

equations

load ﬂow

analysis

computations:

compute

equations

PQ results:

compute

equations

convergence

checker

clock

data

generator

Figure 8: Architecture of Load Flow Analysis simulator.

6 APPLICATION RESULTS AND

ANALYSIS

In this section, we present an example of simulated

power systems composed of 14 buses. Figure 9 il-

lustrates the architecture of simulated power system

represented using the previously deﬁned DSML.

S: Slack

G: Generator

L: Load

Figure 9: Architecture of simulated power system.

For its evolution, we use a scenario in which

we assume that the power generation capacity of the

simulated system, represented as P generator, varies

throughout the day, as follows:

generator







0 if t = 0,

init

+ α

× P

generator

, if 1 ≤ t < 7,

× P

generator

, if 7 ≤ t < 15,

× P

generator

, if 15 ≤ t < 24.

Where α

init

, α

and α

are constants used to spec-

ify the generator’s performance during different peri-

ods of the day. The variable t corresponds to the hour

within a 24-hour day and is used in the simulator as

the simulation time step.

For this system, the following constants deﬁne

the variations of the P generator parameter: α

init

= 0.1;0.2;0.05;0.0011 respectively for its four gen-

erators. The other constants values are: α

= 1.1,

= 1.2, α

= 0.9. In these examples, P generator

increases during the morning and decreases in the

evening, similarly as a photovoltaic production.

By injecting the systems speciﬁcations and the

scenarios into the LFA simulator, we obtain various

results, including the charts as illustrated in Figure 10.

In these charts, blue color presents slack’s power,

green color presents generator’s power and other col-

ors present the load’s power. The simulation results,

according to a speciﬁc scenario described in section 5,

Figure 10: P and Q variations of 14-bus power system.

exhibit the key patterns of power system behavior

across different network conﬁgurations. For instance,

as shown in Figure 10, during daytime (t ∈ [1,14]) the

generated electrical power by the generator (e.g pho-

tovoltaic panel) increases. During evening periods (t

≥ 15), the generated power decreases. These varia-

tions reﬂect a daily power generation pattern.

The simulation results highlight the slack bus’s

crucial role in system stability. As generation in-

creases in the morning, slack power (P and Q) de-

creases. In the evening, as generation decreases, slack

power rises to compensate, ensuring balance between

consumption and generation.

The simulation results validate key aspects of our

proposed approach: the graph-based representation

successfully captures system topology across conﬁg-

urations, revealing component relationships and tem-

poral evolution; transformation rules ensure faithful

conversion of graph structures to mathematical equa-

tions, properly generating the necessary system rep-

resentations; and the modular simulator architec-

ture demonstrates ﬂexibility in handling different net-

work conﬁgurations for DAE-based systems. Out of

lack of space, only one example can be provided here.

However, various test cases have been deﬁned and are

available in our git repository (Attia, 2025).

Although the proposed simulator has been suc-

cessfully implemented for M&S of LFA, certain as-

pects require further attention such as the integration

of dynamic structure systems. We are now on the pro-

cess of adding the structure change rules required to

make this a complete, dynamic structure simulator. It

SIMULTECH 2025 - 15th International Conference on Simulation and Modeling Methodologies, Technologies and Applications

276

will then be able to represent a system and simulate its

internal structure changes over time. To address this,

we are exploring a graph tool called GMTE (Han-

nachi et al., 2013) that is able to automatically gener-

ate new system structures according to speciﬁed rules.

7 CONCLUSION AND FUTURE

WORKS

This paper presents a formal approach to build sim-

ulators and models for DAE-based systems. Our ap-

proach proposes a methodology as well as building

blocks that can be used to address simulation in var-

ious domains. The proposed methodology is built

upon three layers: context-free framework, domain-

speciﬁc abstraction and system speciﬁcation.

To demonstrate the practical application of this ap-

proach, we implemented a simulator for LFA, mod-

eled power systems with a graph-based DSML. We

built the domain-speciﬁc abstraction based on LFA

methodology, developed transformation rules, and

speciﬁed the simulator for the domain.

In summary, this work presents a ﬂexible frame-

work for building models and simulators for DAE-

based systems. The layered structure is thought with

adaptability of the framework to various domains and

applications in mind.

Future work will focus on the integration of dy-

namic structure systems, which is still an ongoing

process. Another major work to come is to apply the

approach depicted in this article to other domains. Po-

tential candidate domains include power electronics

and electric vehicle charging, which represent differ-

ent scales of power systems.

REFERENCES

Akram, S. and Ann, Q. U. (2015). Newton raphson method.

International Journal of Scientiﬁc & Engineering Re-

search, 6(7):1748–1752.

Albadi, M. and Volkov, K. (2020). Power ﬂow analysis.

Computational Models in Engineering, pages 67–88.

Attia, A. (2025). Approach to model simulate load

ﬂow analysis. https://gitlab.laas.fr/aattia/load ﬂow

analysis simulator.

Bickle, A. (2020). Fundamentals of graph theory, vol-

ume 43. American Mathematical Soc.

Blas, M. J., Gonnet, S., Kim, D., and Zeigler, B. P. (2023).

A context-free grammar for generating full classic

devs models. In 2023 Winter Simulation Conference

(WSC), pages 2579–2590. IEEE.

Bouassida Rodriguez, I., Drira, K., Chassot, C., Guennoun,

K., and Jmaiel, M. (2010). A rule-driven approach for

architectural self adaptation in collaborative activities

using graph grammars. International Journal of Auto-

nomic Computing, 1(3):226–245.

Brandes, U., Eiglsperger, M., Lerner, J., and Pich, C.

(2010). Graph markup language (graphml).

Buchberger, B. (1996). Symbolic computation: Computer

algebra and logic. In Frontiers of Combining Systems:

First International Workshop, Munich, March 1996,

pages 193–219. Springer.

Caravantes, J., Sendra, J. R., and Sendra, J. (2019). A maple

package for the symbolic computation of drazin in-

verse matrices with multivariate transcendental func-

tions entries. In Maple Conference, pages 156–170.

Springer.

Chaturvedi, D. K. (2017). Modeling and simulation of sys-

tems using MATLAB and Simulink. CRC press.

Chomsky, N. (1956). Three models for the description of

language. IRE Transactions on information theory,

2(3):113–124.

Chow, A. C. H. and Zeigler, B. P. (1994). Parallel devs:

A parallel, hierarchical, modular modeling formal-

ism. In Proceedings of Winter Simulation Conference,

pages 716–722. IEEE.

de Durana, J. M. G., Barambones, O., Kremers, E., and

Varga, L. (2014). Agent based modeling of en-

ergy networks. Energy Conversion and Management,

82:308–319.

Energy, H. (1993). Homer energy: Hybrid optimization of

multiple energy resources. Accessed: 2025-01-23.

Hannachi, M. A., Bouassida Rodriguez, I., Drira, K., and

Pomares Hernandez, S. E. (2013). Gmte: A tool for

graph transformation and exact/inexact graph match-

ing. In International Workshop on Graph-Based

Representations in Pattern Recognition, pages 71–80.

Springer.

Meurer, A., Smith, C. P., Paprocki, M.,

Cert

ık, O., Kir-

pichev, S. B., Rocklin, M., Kumar, A., Ivanov, S.,

Moore, J. K., Singh, S., et al. (2017). Sympy: sym-

bolic computing in python. PeerJ Computer Science,

3:e103.

ochacker, M. and Elmenreich, W. (2014). Rapsim: A sim-

ulation tool for microgrids. Accessed: 2025-01-23.

Sadnan, R. and Dubey, A. (2021). Learning optimal power

ﬂow solutions using linearized models in power distri-

bution systems. In 2021 IEEE 48th Photovoltaic Spe-

cialists Conference (PVSC), pages 1586–1590. IEEE.

Trott, M. (2007). The Mathematica guidebook for symbol-

ics. Springer Science & Business Media.

Van Tendeloo, Y. and Vangheluwe, H. (2015). Python-

PDEVS: a distributed parallel devs simulator. In Pro-

ceedings of the Symposium on Theory of Modeling

& Simulation: DEVS Integrative M&S Symposium,

pages 91–98.

Weedy, B. M., Cory, B. J., Jenkins, N., Ekanayake, J. B.,

and Strbac, G. (2012). Electric power systems. John

Wiley & Sons.

Xu, J. (2013). Theory and application of graphs, volume 10.

Springer Science & Business Media.

Zeigler, B., Muzy, A., and Kofman, E. (2018). Theory of

Modeling and Simulation: Discrete Event & Iterative

System Computational Foundations. Academic press.

Modular Simulator for DAE-Based Systems Using DEVS Formalism

277
