Post-Quantum Secure Channel Protocols for eSIMs:

Design, Validation and Performance Analysis

Luk Bettale

1 a

, Emmanuelle Dottax

2 b

and Laurent Grémy

2 c

IDEMIA Secure Transactions, Courbevoie, France

IDEMIA Secure Transactions, Pessac, France

Keywords:

Post-Quantum Cryptography, Secure Channel, Protocol Design, Formal Proof, Embedded Device.

Abstract:

The transition to Post-Quantum (PQ) cryptography is increasingly mandated by national agencies and orga-

nizations, often involving a phase where classical and PQ primitives are combined into hybrid solutions. In

this context, existing protocols must be adapted to ensure quantum resistance while maintaining their security

goals. These adaptations can signiﬁcantly impact performance, particularly on embedded devices. In this

article, we focus on standardized protocols which support application management on eSIMs across different

modes. This is a complex use-case, involving constrained devices with stringent security requirements. We

present PQ adaptations, including both hybrid and fully PQ versions, for all modes. Using ProVerif, we pro-

vide automated proofs that verify the security of these PQ variants. Additionally, we analyze the performance

impact of implementing PQ protocols on devices, measuring runtime and bandwidth consumption. Our ﬁnd-

ings highlight the resource overhead associated with achieving post-quantum security for eSIM management.

1 INTRODUCTION

With quantum computing advances, the security of

widely used cryptographic systems is increasingly

threatened, making it essential to plan for migration to

quantum-resistant solutions. With NIST’s recent pub-

lication of Post-Quantum Cryptography (PQC) stan-

dards, transitions can now be planned. This is partic-

ularly urgent for sectors deploying long-lived equip-

ment, such as automotive systems, smart meters, and

critical infrastructure sensors. In these cases, devices

remain operational for many years and rely on con-

nectivity based on an embedded Subscriber Identity

Module (eSIM), a digital version of a SIM card em-

bedded directly within the device hardware. Securing

these devices against quantum attacks is crucial, given

the high cost of upgrading hardware in the ﬁeld.

The migration of embedded elements and their as-

sociated remote management protocols is therefore

critical. This work focuses on protocols for remote

management of eSIMs (and, more generally, embed-

ded secure elements), as deﬁned by Global System

for Mobile communications Association (GSMA) and

https://orcid.org/0000-0002-8799-8568

https://orcid.org/0000-0001-8717-3462

https://orcid.org/0009-0008-2715-3169

GlobalPlatform (GP) standards. Speciﬁcally, we

study a protocol supporting a scripting mode, en-

abling pre-generated, sequenced commands in envi-

ronments without a continuous connectivity. This

protocol makes use of Elliptic Curve Difﬁe-Hellman

(ECDH) as a Non-Interactive Key Exchange (NIKE,

(Freire et al., 2012)), and thus presents complexi-

ties for post-quantum migration. Indeed, no suitable

PQ NIKE currently exists. Similar challenges are

noted in Signal’s key exchange (Brendel et al., 2020;

Hashimoto et al., 2021; Brendel et al., 2022; Kret and

Schmidte, 2024), WireGuard (Hülsing et al., 2021),

TLS (Celi et al., 2022) or Noise (Angel et al., 2022).

We propose a PQ adaptation using only standard-

ized PQ primitives. To our knowledge, this is the

ﬁrst approach combining a digital signature and key

encapsulation for mutual authentication. Though de-

signed for a speciﬁc use case, it may have broader

applications. This migration also considers resource

constraints in secure embedded elements, making it a

valuable case study.

This paper presents the background and the tar-

get protocols in Sect. 2, followed by PQ and hybrid

adaptations in Sect. 3, retaining their original secu-

rity properties. Formal veriﬁcation with ProVerif is

detailed in Sect. 4. Finally, Sect. 5 evaluates the per-

formance impact of migrating to PQ mechanisms.

108

Bettale, L., Dottax, E. and Grémy, L.

Post-Quantum Secure Channel Protocols for eSIMs: Design, Validation and Performance Analysis.

DOI: 10.5220/0013507200003979

In Proceedings of the 22nd International Conference on Security and Cryptography (SECRYPT 2025), pages 108-119

ISBN: 978-989-758-760-3; ISSN: 2184-7711

2 PROTOCOLS FOR ESIM

2.1 Context

The eSIM is a technological evolution of the tradi-

tional SIM card. Unlike physical SIM cards, eSIMs

are programmable secure chips soldered directly onto

the device’s motherboard

. A further evolution is

the Integrated SIM (iSIM), which is incorporated into

the device’s processor. Both technologies enable the

management of mobile subscriptions and various ser-

vices without requiring physical intervention.

The GSMA deﬁnes the interactions between the

various involved stakeholders, including Mobile Net-

work Operators (MNOs), Original Equipment Man-

ufacturers, and eSIM providers, across different use-

cases. For instance, in the process of downloading

a SIM proﬁle (when a user acquires a new subscrip-

tion), the GSMA speciﬁes how the new proﬁle is

transferred from the MNO to the eSIM, via the mo-

bile device (GSMA, 2023a; GSMA, 2023b).

Since eSIMs function as secure elements, they

can host additional security-sensitive services. For

instance, a banking mobile application could beneﬁt

from a counterpart on the eSIM for secure operations.

In these scenarios, the involved parties differ: indeed,

the service provider, as owner of the application, en-

ters in the process. A distinct set of documents gov-

erns these cases: the Secured Applications for Mobile

speciﬁcations (GSMA, 2023c) outlines how applica-

tions can be installed and managed on eSIMs. A se-

cure link between the eSIM and the entity responsible

for installation is established using the Secure Chan-

nel Protocol '11' (SCP11). This protocol is speciﬁed

by GP, the organization in charge of standards for

digital services that rely on secure elements (Glob-

alPlatform, 2023). This document speciﬁes a secure

channel protocol based on Elliptic Curve Cryptogra-

phy (ECC). We explore it in more detail in the next

section.

2.2 Protocol of GP SCP11

SCP11 is a secure channel protocol widely used in

secure element-based products, including eSIMs. It

employs ECC for mutual authentication and secure

channel initiation, and AES for transport encryption.

It deﬁnes three variants (referred to as modes), each

tailored to a speciﬁc use case. The protocol involves

Strictly speaking, eSIM refers to the service, while

eUICC (Embedded Universal Integrated Circuit Card) de-

notes the physical device operating the mobile functionality.

However, these terms are frequently used interchangeably.

two parties: the Card (e.g., an eSIM) and the Off-

Card Entity (OCE, such as a terminal or server).

Table 1 summarizes the security properties claimed

in (GlobalPlatform, 2023, §4.3-4.6), including au-

thentication, conﬁdentiality, integrity, Perfect For-

ward Secrecy (PFS) and session replay (these prop-

erties are discussed in Sect. 4). The different modes

are detailed below.

Table 1: Properties of the different SCP11 modes.

Property Mode A Mode B Mode C

Authentication OCE to Card ✓ ✓

Authentication Card to OCE ✓ ✓ ✓

Message Integrity ✓ ✓ ✓

Data Conﬁdentiality ✓ ✓ ✓

Perfect Forward Secrecy ✓ ✓

Session Replay (replayable) ✓

2.2.1 SCP11 Mode A

Mode A enables mutual authentication between the

Card and the OCE, as illustrated in Fig. 1. Both par-

ties hold an ECC key pair—(EC.sk

OCE

,EC.pk

OCE

)

for the OCE and (EC.sk

,EC.pk

) for the Card—

along with associated certiﬁcates Cert

OCE

and Cert

signed by an authority CA. Authentication is achieved

via static key ECDH, while a second, ephemeral

ECDH ensures PFS. The process involves the OCE

sending commands to trigger computations on the

Card, which responds accordingly.

The process begins with the OCE retrieving the

Card’s certiﬁcate through a GET_DATA command

and verifying it using the CA’s public key EC.pk

The OCE then sends its own certiﬁcate via a Perform

Security Operation (PSO) command, which the Card

veriﬁes. Next, the OCE generates an ephemeral key

pair (EC.epk

OCE

,EC.esk

OCE

) and sends the public

component to the Card through a MUTUAL_AUTH

command. The Card, in turn, creates its own

ephemeral key pair (EC.epk

,EC.esk

) and performs

two elliptic curve key agreements (EC.KeyAgr, stan-

dard ECDH as speciﬁed in (BSI, 2018, §4.3)): one us-

ing the certiﬁed keys and another with the ephemeral

keys, ensuring PFS.

The shared secrets, Sss and See, are processed

through a key derivation function KDeriv to gener-

ate a receipt key SK

Receipt

and session keys for secure

channel SK

Session

. The KDeriv function uses SHA-

256, as speciﬁed in (BSI, 2018). The message Receipt

is an AES-CMAC (Dworkin, 2005) computed over

In the speciﬁcation (GlobalPlatform, 2023, Table

6.18), SK

Receipt

is the receipt key, while SK

Session

com-

prises the S-ENC, S-MAC, S-RMAC and S-DEK keys.

Post-Quantum Secure Channel Protocols for eSIMs: Design, Validation and Performance Analysis

109

OCE Card

Cert

, EC.sk

, EC.pk

Cert

OCE

, EC.sk

OCE

, EC.pk

GET_DATA()

Cert

EC.pk

← Cert.Verify(Cert

,EC.pk

)

PSO(Cert

OCE

)

EC.pk

OCE

← Cert.Verify(Cert

OCE

,EC.pk

)

PSO Response

(EC.esk

OCE

,EC.epk

OCE

) ← EC.KeyGen()

MUTUAL_AUTH(EC.epk

OCE

)

(EC.esk

,EC.epk

) ← EC.KeyGen()

Sss ← EC.KeyAgr(EC.sk

,EC.pk

OCE

)

See ← EC.KeyAgr(EC.esk

,EC.epk

OCE

)

(SK

Receipt

,SK

Session

) ← KDeriv(Sss∥See)

Receipt ← MAC(SK

Receipt

,EC.epk

OCE

∥EC.epk

)

EC.epk

,Receipt

Sss ← EC.KeyAgr(EC.sk

OCE

,EC.pk

)

See ← EC.KeyAgr(EC.esk

OCE

,EC.epk

)

(SK

Receipt

,SK

Session

) ← KDeriv(Sss∥See)

Verify Receipt

SCP03 protected exchanges

Figure 1: SCP11 Mode A.

EC.epk

OCE

and EC.epk

, and sent to the OCE along

with the Card’s ephemeral key. This enables the OCE

to compute and verify the MAC value, allowing it

to authenticate the Card before initiating the secure

channel.

If veriﬁed, the OCE and the Card continue with

the Secure Channel Protocol '03' (SCP03) (Glob-

alPlatform, 2020), using SK

Session

, which includes

one encryption/decryption key and two MAC keys,

one for each direction. All messages are encrypted

and MAC-ed.

It can be noted that the Card cannot authenticate

the OCE until it receives an SCP03 command with a

valid MAC, as prior messages could come from an at-

tacker without access to EC.sk

OCE

. Additionally, the

session cannot be replayed.

2.2.2 SCP11 Mode B

The Mode B provides authentication of the Card to

the OCE only; it is illustrated by Fig. 2. This mode

is useful when the OCE lacks certiﬁed keys, but can

achieve a limited level of authentication through alter-

native means. For instance, if the OCE is a card ter-

minal, a user-entered PIN veriﬁed by the Card offers a

weak, indirect form of OCE authentication. However,

these considerations are out of the scope of (Glob-

alPlatform, 2023), and are not discussed further here.

Mode B is similar to Mode A, with two distinc-

tions:

• The OCE does not send a certiﬁcate or use static

OCE Card

Cert

, EC.sk

, EC.pk

EC.pk

GET_DATA()

Cert

EC.pk

← Cert.Verify(Cert

,EC.pk

)

(EC.esk

OCE

,EC.epk

OCE

) ← EC.KeyGen()

INTERNAL_AUTH(EC.epk

OCE

)

(EC.esk

,EC.epk

) ← EC.KeyGen()

Ses ← EC.KeyAgr(EC.sk

,EC.epk

OCE

)

See ← EC.KeyAgr(EC.esk

,EC.epk

OCE

)

(SK

Receipt

,SK

Session

) ← KDeriv(Ses∥See)

Receipt ← MAC(SK

Receipt

,EC.epk

OCE

)

EC.epk

,Receipt

Ses ← EC.KeyAgr(EC.esk

OCE

,EC.pk

)

See ← EC.KeyAgr(EC.esk

OCE

,EC.epk

)

Session

← KDeriv(Ses∥See)

Verify Receipt

SCP03 protected exchanges

Figure 2: SCP11 Mode B.

keys (no PSO command is sent);

• The two key agreements involve the OCE’s

ephemeral key and both the static and ephemeral

keys of the Card (the command INTER-

NAL_AUTH replaces the MUTUAL_AUTH

one).

The rest of the protocol remains the same, ensuring

PFS due to the use of ephemeral keys, and anti-replay.

2.2.3 SCP11 Mode C

Mode C supports ofﬂine scripting, allowing the OCE

to pre-generate commands for later execution by a

third-party, as shown in Fig. 3. Typically, this mode

assumes the Card is an eSIM in a mobile device,

which plays the script. For instance, the script might

be distributed as part of a rich environment applica-

tion (e.g., an Android or iOS application) and exe-

cuted during the application installation. Importantly,

no secrets are handled by the mobile application, en-

abling the safe installation of services on the eSIM

to secure functions such as those of a banking appli-

cation. This mode also allows for remote administra-

tion of secure elements in general, without requiring a

continuous, direct connection, which may be imprac-

tical in certain scenarios.

Mode C resembles Mode A with the following

modiﬁcations:

• The OCE retrieves the eSIM’s public key from a

database.

• Only the eSIM’s static keys are used, as the of-

ﬂine nature of this mode precludes the use of

ephemeral data on eSIM side.

Mutual authentication, key derivation and command

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

110

OCE

Cert

OCE

, EC.sk

OCE

, EC.pk

Prepare

(EC.esk

OCE

,EC.epk

OCE

) ← EC.KeyGen()

Sss ← EC.KeyAgr(EC.sk

OCE

,EC.pk

)

Ses ← EC.KeyAgr(EC.esk

OCE

,EC.pk

)

(SK

Receipt

,SK

Session

) ← KDeriv(Sss∥Ses)

Receipt ← MAC(SK

Receipt

,EC.epk

OCE

∥EC.pk

)

Wrap following payloads into SCP03 using SK

Session

Distribute Commands to mobile app

Mobile eSIM

Cert

, EC.sk

, EC.pk

PSO(Cert

OCE

)

EC.pk

OCE

← Cert.Verify(Cert

OCE

,EC.pk

)

PSO Response

MUTUAL_AUTH(EC.epk

OCE

)

Sss ← EC.KeyAgr(EC.sk

,EC.pk

OCE

)

Ses ← EC.KeyAgr(EC.sk

,EC.epk

OCE

)

(SK

Receipt

,SK

Session

) ← KDeriv(Sss∥Ses)

Receipt ← MAC(SK

Receipt

,EC.epk

OCE

∥EC.pk

)

Receipt

Verify Receipt

Continue communication

SCP03 protected exchanges

Figure 3: SCP11 Mode C.

wrapping are performed by the OCE in advance. The

Receipt is based on EC.epk

OCE

and EC.pk

Mode C provides mutual authentication between

the OCE and the eSIM but lacks PFS for the eSIM’s

secrets. Furthermore, as the session relies only on

static data from the eSIM, it can be replayed, unlike

in Modes A and B. This is acknowledged by (Glob-

alPlatform, 2023), and as a consequence some sensi-

tive commands—like inserting new keys—are disal-

lowed in Mode C.

3 QUANTUM-RESISTANT

VERSIONS

As seen, current protocols rely on ECC, which is vul-

nerable to quantum attacks, necessitating a shift to

quantum-resistant alternatives. This is crucial to pro-

tect long-term sensitive data and secure eSIMs in de-

vices with extended lifespans, like vehicles or smart

meters. This section addresses the complexities of

this migration and the required adaptation efforts.

3.1 Quantum-Resistant Mode C

We analyze Mode C, the variant used for scripting,

where the off-card entity (OCE) prepares a script for

the eSIM. Mutual authentication ensures that only the

intended eSIM, with the correct ECDH key, can read

the script, while the eSIM can verify its origin. Our

goal is to maintain these properties against quantum-

capable adversaries.

Standardized post-quantum algorithms now exist

for signature (NIST, 2024a; NIST, 2024c) and Key

Encapsulation Mechanism (KEM) (NIST, 2024b).

Since the original protocol relies on ECDH, a natural

approach is replacing it with a KEM. However, this

alone fails: while the OCE can encrypt for the eSIM

using its long-term KEM public key, it cannot prove

authorship of the script, as KEMs require interaction

for authentication. This limitation is also observed in,

e.g., post-quantum adaptations of Signal (see Sect. 1):

while KEMs work for key establishment, they cannot

replace ECDH in protocols requiring asynchronous

authentication.

To address this, the OCE needs a signature key

to enable the eSIM to verify the script’s origin. Re-

placing the eSIM’s long-term KEM key with a sig-

nature key is not feasible here, as it would again re-

quire interaction with the eSIM, allowing it to sign an

ephemeral KEM key.

Thus, we construct a protocol with a signature key

on the OCE side, and a KEM key on the eSIM side.

To the best of our knowledge, this is the ﬁrst approach

of its kind to leverage such a combination. The pro-

tocol is illustrated by Fig. 4 (the colored text is for a

hybrid version presented in Sect. 3.3 and should be

omitted for now). The OCE is now equipped with a

signature key SIG.sk

OCE

and the corresponding cer-

tiﬁcate Cert

OCE

. As in the classic case, the OCE al-

ready knows the eSIM’s public key, which is now a

KEM key KEM.pk

. The OCE begins by perform-

ing an encapsulation on this key to produce a shared

secret Ss and its ciphertext c.Ss, which are used to de-

rive the secure channel and receipt keys. The cipher-

text is signed, to authenticate the origin of the script.

The script is sent to the mobile device and played on

the eSIM. The eSIM veriﬁes the OCE’s certiﬁcate,

checks the signature, and decapsulates the ciphertext

to obtain the shared secret and derive the session keys.

The remainder of the process aligns with the classic

protocol.

Regarding PFS, the situation is the same as in the

classical case: it is not ensured on the eSIM’s side (re-

covering KEM.sk

allows to decrypt past communi-

cations), but it is on the OCE’s one (the shared secret

Ss is ephemeral). Similarly, replay is possible.

3.2 Quantum-Resistant Modes A and B

For completeness and coherence, we explore how PQ

versions of Modes A and B can be constructed using

Post-Quantum Secure Channel Protocols for eSIMs: Design, Validation and Performance Analysis

111

OCE

Cert

OCE

, EC.sk

OCE

,EC.pk

, SIG.sk

OCE

, KEM.pk

Prepare

(EC.esk

OCE

,EC.epk

OCE

) ← EC.KeyGen()

Sss ← EC.KeyAgr(EC.sk

OCE

,EC.pk

)

Ses ← EC.KeyAgr(EC.esk

OCE

,EC.pk

)

(Ss,c.Ss) ← KEM.Encaps(KEM.pk

)

sig

OCE

← SIG.Sign(SIG.sk

OCE

,c.Ss)

(SK

Receipt

,SK

Session

) ← KDeriv(Sss∥Ses∥EC.pk

∥Ss∥c.Ss)

Receipt ← MAC(SK

Receipt

,EC.epk

OCE

∥EC.pk

∥KEM.pk

∥c.Ss)

Wrap following payloads into SCP03 using SK

Session

Distribute Commands to mobile app.

Mobile eSIM

KEM.sk

, EC.sk

, pk

PSO(Cert

OCE

)

(EC.pk

OCE

,SIG.sk

OCE

) ← Cert.Verify(Cert

OCE

,pk

)

PSO Response

MUTUAL_AUTH(EC.epk

OCE

,c.Ss,sig

OCE

)

Sss ← EC.KeyAgr(EC.sk

,EC.pk

OCE

)

Ses ← EC.KeyAgr(EC.sk

,EC.epk

OCE

)

ok/nok ← SIG.Verify(SIG.pk

OCE

,sig

OCE

)

Ss ← KEM.Decaps(KEM.sk

,c.Ss)

(SK

Receipt

,SK

Session

) ← KDeriv(Sss∥Ses∥EC.pk

∥Ss∥c.Ss)

Receipt ← MAC(SK

Receipt

,EC.epk

OCE

∥EC.pk

∥KEM.pk

∥c.Ss)

Receipt

Verify Receipt

Continue communication

SCP03 protected exchanges

Figure 4: Hybrid version for Mode C (the colored part can

be omitted for a purely post-quantum version).

the same credentials as Mode C: a signature key for

the OCE and a KEM key for the eSIM. While these

protocols could certainly rely exclusively on either

signature keys or KEM keys—and possibly achieve

better performances in these setting—using the same

functions as in Mode C would streamline the process.

This approach removes the need for additional cre-

dentials and avoids introducing extra functionalities

on the eSIM.

For Mode A, we want to maintain the original mu-

tual authentication and PFS properties. This can be

achieved following the process illustrated by Fig. 5

(ignoring the colored part for now). Compared to the

classic protocol, we need one more command, that we

call MUTUAL_AUTH2. This is again due to the us-

age of a KEM in place of an ECDH key agreement.

The beginning of the protocol is the same: the

Card and the OCE exchange their certiﬁcates, ver-

ify them using SIG.pk

and extract the public keys

SIG.pk

OCE

and KEM.pk

. Of course, the certiﬁ-

cates are signed with a PQ signature algorithm. The

ﬁrst MUTUAL_AUTH command is used to make the

eSIM generate a KEM ephemeral key and send the

public part to the OCE. The OCE can then use this

ephemeral key and the static one to generate two

shared secrets Se and Ss, and their respective cipher-

OCE Card

Cert

OCE

, EC.sk

OCE

, SIG.sk

OCE

Cert

, EC.sk

, KEM.sk

GET DATA()

Cert

(EC.pk

,KEM.pk

) ← Cert.Verify(Cert

,pk

)

PSO(Cert

OCE

)

(EC.pk

OCE

,SIG.pk

OCE

) ← Cert.Verify(Cert

OCE

,pk

)

PSO Response

(EC.esk

OCE

,EC.epk

OCE

) ← EC.KeyGen()

MUTUAL_AUTH(EC.epk

OCE

)

(EC.esk

,EC.epk

) ← EC.KeyGen()

Sss ← EC.KeyAgr(EC.sk

,EC.pk

OCE

)

See ← EC.KeyAgr(EC.esk

,EC.epk

OCE

)

(KEM.esk

,KEM.epk

) ← KEM.KeyGen()

EC.epk

,KEM.epk

Sss ← EC.KeyAgr(EC.sk

OCE

,EC.pk

)

See ← EC.KeyAgr(EC.esk

OCE

,EC.epk

)

(Ss,c.Ss) ← KEM.Encaps(KEM.pk

)

(Se,c.Se) ← KEM.Encaps(KEM.epk

)

sig

OCE

← SIG.Sign(SIG.pk

OCE

,KEM.epk

∥c.Ss∥c.Se)

MUTUAL_AUTH2(c.Ss,c.Se,sig

OCE

)

ok/nok ← SIG.Verify(SIG.pk

OCE

,sig

OCE

)

Ss ← KEM.Decaps(KEM.sk

,c.Ss)

Se ← KEM.Decaps(KEM.esk

,c.Se)

(SK

Receipt

,SK

Session

) ← KDeriv(Sss∥See∥EC.pk

∥EC.epk

∥Ss∥Se∥c.Ss∥c.Se)

Receipt ← MAC(SK

Receipt

,EC.epk

OCE

∥EC.epk

∥KEM.epk

∥c.Ss)

Receipt

(SK

Receipt

,SK

Session

) ← KDeriv(Sss∥See∥EC.pk

∥EC.epk

∥Ss∥Se∥c.Ss∥c.Se)

Verify Receipt

SCP03 protected exchanges

Figure 5: Hybrid version for Mode A (the colored part can

be omitted for a purely post-quantum version).

texts c.Se and c.Ss. The OCE signs these ciphertexts,

together with the eSIM’s ephemeral key. The result-

ing signature and the ciphertexts are sent to the eSIM

via the new command. The eSIM can then verify the

signature, decapsulate both ciphertexts and derive se-

cret material from the concatenation of shared secrets

and ciphertexts (as advised by (ETSI, 2020)). The rest

of the protocol is unchanged: the eSIM computes an

authentication value Receipt, and both parties use the

session keys SK

Session

for further exchanges through

SCP03.

Note that the ephemeral key could be generated

by the OCE, this is equivalent for the PFS (assuming

both parties correctly manage ephemeral values), and

both options need two commands for the mutual au-

thentication.

The PQ version of Mode B is similar to the one

of Mode A, with the difference that the OCE does not

send any certiﬁcate, nor perform any signature. It is

illustrated by Fig. 6 (again ignoring the colored part).

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

112

OCE Card

Cert

, EC.sk

, KEM.sk

, pk

GET DATA()

Cert

(EC.pk

,KEM.pk

) ← Cert.Verify(Cert

,pk

)

(EC.esk

OCE

,EC.epk

OCE

) ← EC.KeyGen()

INTERNAL_AUTH(EC.epk

OCE

)

(EC.esk

,EC.epk

) ← EC.KeyGen()

Sss ← EC.KeyAgr(EC.sk

,EC.epk

OCE

)

See ← EC.KeyAgr(EC.esk

,EC.epk

OCE

)

(KEM.esk

,KEM.epk

) ← KEM.KeyGen()

EC.epk

,KEM.epk

Sss ← EC.KeyAgr(EC.esk

OCE

,EC.pk

)

See ← EC.KeyAgr(EC.esk

OCE

,EC.epk

)

(Ss,c.Ss) ← KEM.Encaps(KEM.pk

)

(Se,c.Se) ← KEM.Encaps(KEM.epk

)

INTERNAL_AUTH2(c.Ss,c.Se)

Ss ← KEM.Decaps(KEM.sk

,c.Ss)

Se ← KEM.Decaps(KEM.esk

,c.Se)

(SK

Receipt

,SK

Session

) ← KDeriv(Sss∥See∥EC.pk

∥EC.epk

∥Ss∥Se∥c.Ss∥c.Se)

Receipt ← MAC(SK

Receipt

,EC.epk

OCE

∥EC.epk

∥KEM.epk

∥c.Ss)

Receipt

(SK

Receipt

,SK

Session

) ← KDeriv(Sss∥See∥EC.pk

∥EC.epk

∥Ss∥Se∥c.Ss∥c.Se)

Verify Receipt

SCP03 protected exchanges

Figure 6: Hybrid version for Mode B (the colored part can

be omitted for a purely post-quantum version).

3.3 Hybrid Versions

Hybrid versions combine classical and PQ algorithms

to mitigate the limited maturity of PQ solutions. This

ensures security as long as one algorithm set remains

secure. This approach is endorsed by European cy-

bersecurity agencies (ANSSI, 2023; BSI, 2024) and

supported by NIST (Alagic et al., 2025).

Several options are available for constructing hy-

brid protocols, the main ones are:

• Concatenate hybrid key agreement, where both

cryptographic methods are combined in single

messages by concatenating their respective data.

• Cascade hybrid key agreement, where the ﬁrst

key agreement is executed before the second.

With the ﬁrst option, each command conveys more

data, while the second one augments the number of

commands. We opted for the ﬁrst option—the second

one can easily be derived.

Figure 5 illustrates the hybrid protocol for Mode

A, the classical part being colored. In this set-up, the

OCE and the eSIM use hybrid certiﬁcates, denoted

Cert

OCE

and Cert

. Multiple formats for hybrid cer-

tiﬁcates exist (see (Gray and Onsworth, 2024) for an

overview), but all include both classical and PQ keys

and are signed by the classical and PQ keys of the CA,

denoted pk

. The Cert.Verify function returns both

classical and PQ public keys: for the OCE, EC.pk

OCE

and SIG.pk

OCE

; for the eSIM, EC.pk

and KEM.pk

Hybrid versions of Modes B and C (Fig. 6 and 4) are

based on these same principles.

Our hybrid protocols incorporate both classical

and PQ computations while maintaining the same

command count as the PQ-only versions. Shared se-

crets are derived from classical and PQ key agree-

ments, then combined using the KDeriv function.

This step requires careful design to ensure hybrid

security. This aspect has been studied in various

works (Herzberg, 2009; Giacon et al., 2018; Bindel

et al., 2019). Currently, only a few standardized op-

tions exist (ETSI, 2020; Alagic et al., 2025). Follow-

ing these standards, we input KDeriv with all shared

secrets, along with the public keys for ECDH and the

ciphertexts for KEM.

As seen, implementing these new protocols re-

quires modifying the commands sent to the eSIM. The

approach presented is one possibility, but the exact

implementation will be deﬁned by GlobalPlatform.

4 FORMAL PROOFS

The security properties of the different modes of

SCP11 are listed in Sect. 2.2 and summarized in

Table 1. However, no formal security proof exists

in the literature conﬁrming that these properties are

achieved. We therefore propose a formal veriﬁcation

of the different modes of SCP11, and then consider

the PQ-only and hybrid variants.

4.1 Symbolic Formal Veriﬁcation

Our proofs are conducted in the symbolic model, also

known as the Dolev–Yao attacker model (Dolev and

Yao, 1983). In this setting, the protocol participants

communicate over a public channel and employ per-

fect cryptographic primitives, where, for instance, de-

cryption is only possible with the corresponding key.

An active attacker in this model has full control over

the public channel, enabling her to read, drop, mod-

ify, replay messages, and inject new messages. Addi-

tionally, the attacker may selectively compromise par-

ticipants, e.g., through long term key leaks, or gain

access to oracles that break cryptographic assump-

tions, e.g., retrieving a private key from a public key.

In this setting, we can model a protocol and deter-

mine whether certain (mathematical) properties hold

despite such an adversary. We designate the OCE, the

Card and the attacker as O, C and A , respectively.

Post-Quantum Secure Channel Protocols for eSIMs: Design, Validation and Performance Analysis

113

Authentication. Formalizing cryptographic proper-

ties into precise mathematical formulations can be

challenging, as illustrated by the various deﬁnitions of

authentication (Lowe, 1997). Interested readers can

ﬁnd a near-mathematical formalization of these prop-

erties in (The Tamarin Team, 2024, pp.82–83). We

aim to prove the two strongest forms of agreement for

classical SCP11: the non-injective agreement (Lowe,

1997, §2.3) and (injective) agreement (Lowe, 1997,

§2.4). The authentication of C to O may represent an

injective agreement upon Receipt. The authentication

of O to C , which is unattainable in Mode B, may rep-

resent an injective agreement on the SCP commands

in Mode A, but a non-injective agreement in Mode C,

since O may replay a previous session.

Message Integrity. Message integrity is required

during SCP03 exchanges. For any command a sent

by O and any command b received by C , integrity is

achieved if a and b are identical. However, this condi-

tion may not hold for the Mode B, where any A may

impersonate an O. Message integrity is veriﬁed across

all modes if, for any command a whose authenticated

encryption e is sent by O and for any command b de-

crypted after the reception of e by C , the commands a

and b are the same.

Data Conﬁdentiality and PFS. Like message in-

tegrity, data conﬁdentiality applies only to SCP03 ex-

changes. A command is conﬁdential if A cannot ac-

cess it at any point. Proving PFS adds a temporal con-

dition: we assume A obtains the long-term secret key

of C or O after the protocol’s completion. A protocol

is perfect forward secure (Günther, 1990; Difﬁe et al.,

1992) if A cannot compute the symmetric keys, such

as SK

Session

, exchanged before impersonating C or O.

Session Replay. The session replay is also ad-

dressed by the (non-)injection agreement discussed

above. To validate the negation of this property, ses-

sion uniqueness, we need to conﬁrm that if two tuples

of keys (SK

Receipt

, SK

Session

) established by C and O

are identical at two different time periods, those peri-

ods must be the same.

To be automatically proved, all these (mathemati-

cal) properties need to be encoded in the formalism

of software programs designed for the formal veri-

ﬁcation of cryptographic protocols. The two lead-

ing tools for formally proving protocols in the sym-

bolic model are ProVerif (Blanchet et al., 2008) and

Tamarin (Schmidt et al., 2012). A comprehensive

comparison of these tools, along with others, can

be found in (Barbosa et al., 2021a, §II.A-C). Two

newer software options may also be considered: Ver-

ifpal (Kobeissi et al., 2020) and PQ-Squirrel (Cre-

mers et al., 2022). All these tools generally involve

two stages: the ﬁrst models the protocol, and the

second assesses the security properties, expressed as

(mathematical) queries. In this work, we chose to use

ProVerif (version 2.05).

4.2 ProVerif Security Protocol Analysis

In this section, we discuss our modeling choices in the

ProVerif language. For comprehensive details, refer

to the ProVerif manual (Blanchet et al., 2023).

4.2.1 Model

ProVerif requires explicit deﬁnitions of the crypto-

graphic primitives used in the protocol. These def-

initions resemble an API description, accompanied

by the mathematical equations each primitive veri-

ﬁes (Blanchet et al., 2023, §4.2). For instance, a mes-

sage authentication code (MAC) is illustrated in List-

ing 1. To compute a MAC, the function Mac takes a

key k and a message m to produce the MAC c of m. To

verify if c is the MAC of m under the key k, the func-

tion MacVerify takes the key k, the message m and the

alleged MAC c and outputs true if c = Mac(k,m) (i.e.,

MacVerify(k,m,Mac(k,m)) = 1) and false otherwise

(i.e., MacVerify(k,m,c ̸= Mac(k, m)) = 0).

Listing 1: ProVerif model of the MAC computation and ver-

iﬁcation.

t y p e mackey . t yp e macs .

fun Mac ( mackey , b i t s t r i n g ) : macs .

fun M a c V erify ( mackey , b i t s t r i n g , macs ) : b o o l

reduc f o r a l l k : mackey , m: b i t s t r i n g ;

MacV e r i f y ( k , m, Mac ( k , m) ) = t r u e

o t h er wi se f o r a l l k : mackey , m: b i t s t r i n g , c : macs ;

MacV e r i f y ( k , m, c ) = f a l s e .

The primitives are embedded within two process

macros pCard and pOCE representing the Card and

the OCE in Listing 3. Unlike Tamarin which relies

on state sharing, we deﬁne a single process macro

for each actor. The two actors communicate over an

open channel, vulnerable to a Dolev–Yao attacker (see

Sect. 4.1). Each process macro is initialized in the

main process with the public and private keys required

for the chosen mode, with public keys also broad-

casted over the public channel, making them accessi-

ble to the attacker. Additionally, the certiﬁcate author-

ity is modeled as a separate macro process that signs

trusted public keys stored in an immutable table.

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

114

4.2.2 Queries

To prove PFS, ProVerif allows to work with the notion

of phase (Blanchet et al., 2023, §4.1.6). The complete

execution of the protocol is considered phase 0, fol-

lowed by phase 1, which necessarily occurs after the

completion of phase 0, during which the long term

keys are leaked. The proof of PFS is done for phase 1.

The conﬁdentiality query is expressed in Listing 2,

where we deﬁne a command and query whether the

attacker obtains this command.

Listing 2: ProVerif model of a conﬁdentiality query.

f r e e commands : b i t s t r i n g [ p r i v a t e ] .

que ry a t t a c k e r ( commands ) .

To formalize other queries in the ProVerif model,

we ﬁrst create events. An event denotes a signiﬁcant

sequence of actions. For instance, the authentication

of the Card to the OCE via injective agreement on

the receipt message is brieﬂy formalized in Listing 3.

The issuance and sending of the receipt message by

the Card to the OCE is the goal of sendRec, which

takes as arguments the receipt message and the two

actors, ﬁrst the sender and second the receiver. To

prove the authentication query, we must deﬁne an-

other event to conﬁrm that the MAC veriﬁcation is

correctly performed: this is the goal of acceptRec,

which takes as arguments the receipt message and the

two actors, ﬁrst the receiver and second the issuer.

Once events are deﬁned and placed correctly in the

model, we use the injective correspondence with the

inj-event keyword.

Listing 3: ProVerif model of the two process macros.

. . .

e v en t send R e c ( macs , ho s t , h o s t ) .

e v en t a c c e p t Re c ( macs , ho s t , h o s t ) .

. . .

que ry r e c : macs , OCE : h os t , Card : h o s t ,

i : ti m e , j : t i me ;

e v en t ( a c c e p t R e c ( r e c , OCE , C a r d ) ) @i ==>

i n j − e v en t ( sendRe c ( r e c , Card , OCE ) ) @j &&

j < i .

. . .

l e t pOCE( pkS : signCApub , SKOCE : e c k a p r i v ) =

. . .

i n ( c , (ePKSD : e c kapub , r e c : macs ) ) ;

. . .

l e t ( r k e y : mackey , se nc : symkey , smac : mackey ) =

k d f ( ( ShSss , S hSee ) ) in

i f M acVerify ( rkey , (ePKOCE , ePKSD ) , r e c ) t h en (

e v en t a c c e p t Re c ( re c , OCE, Card ) ;

. . .

) .

l e t p C ard ( pkS : signCApub , SKSD: e c k a p r i v ) =

. . .

l e t ( r k e y : mackey , se nc : symkey , smac : mackey ) =

k d f ( ( ShSss , S hSee ) ) in

l e t r e c = Mac ( rke y , (ePKOCE , ePKSD ) ) i n

e v en t send R e c ( r e c , Card , OCE ) ;

out ( c , ( ePKSD , r e c ) ) ;

. . .

Regarding the integrity query in Listing 4, events

relate to the (encrypted) commands sent over the

SCP03 channel. The query states that if an actor sends

a command a through an encrypted message e with

an authentication tag m, and another actor receives a

command b from the decryption of message e with

tag m, then a and b are the same.

Listing 4: ProVerif model of an integrity query.

e v en t sendCom ( b i t s t r i n g , b i t s t r i n g , macs ) .

e v en t readCom ( b i t s t r i n g , b i t s t r i n g , macs ) .

que ry a : b i t s t r i n g , b : b i t s t r i n g , e : b i t s t r i n g ,

m: macs ; e v e nt ( sendCom ( a , e , m) ) &&

e v en t ( readCom ( b , e , m) ) ==> a = b .

Finally, Listing 5 formalizes the session unique-

ness query. After the Card derives the key, the event

SCP03SK is triggered. This property states that if the

three keys established by the Card with the (believed)

OCE are identical for different time periods i and j,

then i and j must match, i.e., i = j.

Listing 5: ProVerif model of a replay query.

e v en t SCP03SK ( mackey , symkey , mackey , ho s t , h o s t ) .

que ry r k e y : mackey , se n c : symkey , smac : mackey ,

i : ti m e , j : t i me ;

e v en t ( SCP03SK ( r k e y , senc , smac , Card , OCE ) ) @i &&

e v en t ( SCP03SK ( r k e y , senc , smac , Card , OCE ) ) @j

==> i = j .

4.3 Veriﬁcation of the Models

We model all three modes. In our ProVerif models,

we include a sanity check to verify that at least one

trace allows the Card to receive the commands sent

by the OCE. Without this check, a query may be con-

sidered as veriﬁed only because the event(s) of the

query are not reached; for instance, if the ﬁrst event

is not reached, both true and false can be assumed for

the second event, see Listing 3. All properties are ver-

iﬁed in less than 3 seconds on a personal computer.

4.4 Post-Quantum Protocols

With the ProVerif models established for the clas-

sical modes of SCP11, we now aim to prove that

the quantum-resistant versions introduced in Sect. 3

achieve the same properties as their classical counter-

parts in the symbolic model.

Post-Quantum Secure Channel Protocols for eSIMs: Design, Validation and Performance Analysis

115

4.4.1 Previous Works

Unlike computational tools (Barbosa et al., 2021b;

Blanchet and Jacomme, 2023), symbolic tools typ-

ically do not require adaption to take into account

quantum adversaries. Consequently, we can utilize

ProVerif directly, given an appropriate model for the

new primitives introduced in the post-quantum vari-

ants. Several studies have already explored automated

proofs in the symbolic model for post-quantum ver-

sions of various protocols, as summarized in Table 2.

Table 2: Post-quantum protocols with security proofs in the

symbolic model with an automated tool.

(Sub)Protocol Article ProVerif Tamarin Verifpal PQ-Squirrel

OPC UA (Paul and Scheible, 2020) ✓ ✓

PQ-Wireguard (Hülsing et al., 2021) ✓

PQ IKEv2 (Gazdag et al., 2021) ✓

KEMTLS (Celi et al., 2022) ✓

PQ IKEv1 (Cremers et al., 2022) ✓

PQ IKEv2 (Cremers et al., 2022) ✓

PQ X3DH (Cremers et al., 2022) ✓

PQ Signal (Beguinet et al., 2024) ✓

PQXDH (Bhargavan et al., 2024) ✓

iMessage PQ3 (Linker et al., 2024) ✓

PQ SCP11 This work ✓

4.4.2 Modeling PQ SCP11

The main distinction from classical protocols is the

introduction of a KEM algorithm. Following (Bhar-

gavan et al., 2024), a generic KEM encapsulation is

modeled as the generation of a secret value m, asym-

metrically encrypted with the recipient’s public key,

where m serves as the shared secret. However, the

ML-KEM standard (NIST, 2024b) differs by using a

shared secret which can be modeled as (the hash of)

m concatenated with the public key, as shown in List-

ing 6. Unless stated otherwise, all our proofs use a

generic KEM model.

Listing 6: ProVerif model of a simpliﬁed version of ML-

KEM.

t y p e ke m p riv . t yp e kempub .

fun kempk ( ke m p riv ) : kempub .

fun h ( b i t s t r i n g , kempub ) : b i t s t r i n g .

fun p kee n c ( kempub , b i t s t r i n g ) : b i t s t r i n g .

fun p ked e c ( kempriv , b i t s t r i n g ) : b i t s t r i n g

reduc f o r a l l sk : kempriv , m: b i t s t r i n g ;

pk e dec ( sk , pk e e nc ( kempk ( sk ) , m) ) = m.

l e t f u n kemenc ( pk : kempub ) = new m: b i t s t r i n g ;

l e t k = h (m, pk ) i n ( p kee n c ( pk , m) , k ) .

l e t f u n kemdec ( sk : kempriv , c t : b i t s t r i n g ) =

l e t m = p ked e c ( sk , c t ) i n h (m, kempk ( sk ) ) .

To prevent public key confusion attacks (Bharga-

van et al., 2024, §4.1.1), we incorporate an identiﬁer

into public key certiﬁcates, ensuring domain separa-

tion. We model the PQ signature algorithm as the

standard signature model (Jackson et al., 2019, §2.2).

PQ-Only versions. The events and queries from the

classical models can be directly reused in the models

for the PQ SCP11 versions. Our models for the PQ

modes validate the expected proofs outlined for the

classical versions, as summarized in Table 1. Notably,

the PQ versions of Modes A and C allow to reach

the authentication of the OCE to the Card sooner

than in the classical version through the use of sig-

natures. More precisely, the sequence involving the

issuance of a signature by the OCE followed by its

veriﬁcation by the Card guarantees aliveness (Lowe,

1997, §2.1) of the OCE in Mode C. This same se-

quence guarantees to the Card agreement with the

OCE on the signature in Mode A; however, the omis-

sion of the ephemeral key in the signed message re-

duces the authentication to aliveness, akin to Mode C.

This reduction may be acceptable if the PQ protocol

aims to align with the timeline the security properties

achieved in the classical protocol.

During the modeling stage of the PQ protocols,

we model ﬁrstly a simple rough key derivation step,

by only considering the concatenation of the shared

secret without taking into account the ciphertexts.

This is in contrast with what is described for exam-

ple in (ETSI, 2020, §8). While assessing the proper-

ties related to SCP11, we found that our initial (incor-

rect) model did not signiﬁcantly diverge from expec-

tations, except for the replay property in Mode B. In

this case, since the OCE is not authenticated, an at-

tacker could send the same shared secret, for two runs

of the protocol. Interestingly, using ML-KEM (NIST,

2024b) defeats this attack since the public key used

for the encapsulation is embedded into the shared se-

cret construction, but this is not a perennial solution.

By aligning our model on the protocol described in

Fig. 6, the attack is defeated for a generic KEM.

Hybrid Versions. Hybrid protocols are of ﬁrst im-

portance today to prepare the migration between pure-

classical and pure-post-quantum protocols. In addi-

tion to ensuring that an SCP11 mode provides the

requisite security when its primitives are secure, hy-

brid protocols must also remain secure if either of the

combined primitives—classical or else PQ—is com-

promised. To model this, we introduce oracles for the

attacker via ProVerif process macros, allowing her to

submit public keys and obtain the associated secret

keys, but only for either PQ or classical primitives, as

shown in Listing 7.

Listing 7: ProVerif model of the oracle which breaks the

public key of a KEM.

f r e e a t t : c h a n n e l . (

Chan n e l f o r t h e a t t a c k e r

)

fun r e cover K E M priv ( kempub ) : k e mpri v

reduc f o r a l l sk : k e mpri v ;

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

116

rec o v erKEM p r i v ( kempk ( sk ) ) = s k [ p r i v a t e ] .

l e t k e m_ a t t a c k s ( ) = i n ( a t t , pk : kempub ) ;

out ( a t t , r ecove r K E Mpriv ( pk ) ) .

We can verify that the hybrid protocols ensure

the same security properties as the classical proto-

cols when PQ primitives are broken, and conversely

the same security as PQ protocols when the classi-

cal primitives are compromised. Note that, since the

signatures issued by the certiﬁcate authority are also

hybrid, we model it as a single unbroken signature

algorithm rather than a combination of two signature

algorithms—one compromised and one secure.

5 IMPLEMENTATION

When implementing cryptographic protocols in em-

bedded devices, a lot of constraints come into play.

First, the amount of available resources (RAM, CPU

frequency) is usually very low. Implementing post-

quantum algorithms can be challenging. This is even

more the case as implementations on embedded de-

vices have to be resistant against physical attacks.

The cost of securing an implementation against side-

channel and fault attacks can drastically increase the

required amount of RAM, as well as the execution

time. On top of that, protocols are designed for two

parties to communicate with each other. The amount

of data exchanged by the parties would directly im-

pact the overall performance of the protocols.

In this section, we study these metrics for an im-

plementation on a typical embedded device (32-bit

Cortex-M3 CPU at 100 MHz) with a hardware ac-

celerator for ECC. The chip supports a baud-rate of

600 kbit/s. We discuss the impact of the choice of

the PQ algorithm on the execution time of a complete

protocol execution.

5.1 Algorithm Choice

For our experiments, we restrict ourselves to the al-

gorithms that were standardized by the NIST, namely

ML-KEM (NIST, 2024b) for key encapsulation, and

ML-DSA (NIST, 2024a) and FN-DSA for signature.

As the FN-DSA speciﬁcations are not yet available,

we implemented the latest version submitted to the

NIST competition, that is the Round 3 version of Fal-

con (Fouque et al., 2020). In the rest of the paper,

we will use the name FN-DSA. The ML-KEM prim-

itives were implemented with side-channel counter-

measures such as (Coron et al., 2022; Coron et al.,

2023).

We excluded SLH-DSA (NIST, 2024c) from our

study because even with the small variant, the per-

formances would be very low with processing time

reaching up to 5 seconds whenever a veriﬁcation is

required. This algorithm is not suited for embedded

devices.

To align the security levels with the post-quantum

algorithms, we implemented the ECC component

with three distinct security levels: 128, 192, and 256

bits, corresponding to NIST categories 1, 3, and 5, re-

spectively. We used the P-256, P-384 and P-521 El-

liptic Curve domain parameters as speciﬁed in SP800-

186 (Chen et al., 2023). Since we simulated the OCE

using a desktop computer, the timing results for the

OCE are not relevant. However, the OCE typically

has signiﬁcantly greater processing power than the

chip, making its timing negligible in this context.

5.2 Performance Analysis

In Tables 3 and 4, we present the communication and

processing time of the chip for the hybrid version us-

ing the standardized post-quantum signatures, respec-

tively ML-DSA and FN-DSA. Note that we measure

only the secure channel establishment part, before any

SCP03 exchanges. As the communication time may

depend on the negotiated baud-rate and transmission

protocol, it is clearly separated from the processing

time of the chip. This communication time includes

both the sending and receiving of data by the chip.

Finally, we compare these implementations to a clas-

sic SCP11 using ECC by giving the ratio to see the

overhead of hybridation.

For ML-DSA in Table 3, it is worth noticing

that while the impact on the processing time is non-

negligible, it is not more than a factor of 8 at worst.

However, the communication time is more than 40

times slower. Despite this, the total time remains less

than one second for the 128-bit security level.

The results for FN-DSA in Table 4 are much bet-

ter due to the relatively small signature size and the

efﬁcient veriﬁcation process. At the 128-bit security

level, all modes run in less than 500 ms. In a context

where the constrained device only performs veriﬁca-

tions, it is advantageous to choose a signature algo-

rithm with a short signature and fast veriﬁcation, such

as FN-DSA.

6 CONCLUSION

Through our exploration of SCP11’s modes, we iden-

tify challenges in transitioning from classical to post-

quantum cryptography. Beyond proving that SCP11

achieves its claimed security properties, we designed

new PQ-only and hybrid protocols that uphold the

Post-Quantum Secure Channel Protocols for eSIMs: Design, Validation and Performance Analysis

117

Table 3: Chip-based measurements of hybrid SCP11 proto-

cols execution, with ratio relative to classic versions, using

ML-DSA signature.

Protocol Sec. level Communication Processing Total

(ms) (ratio) (ms) (ratio) (ms) (ratio)

128 267 (×35) 516 (×7.7) 783 (×11)

Mode A 192 380 (×33) 796 (×6.1) 1176 (×8.3)

256 515 (×32) 1184 (×5.3) 1698 (×7.1)

128 117 (×23) 290 (×6.0) 406 (×7.6)

Mode B 192 165 (×21) 427 (×4.6) 591 (×5.9)

256 228 (×22) 629 (×4.0) 857 (×5.1)

128 167 (×43) 348 (×7.1) 516 (×9.8)

Mode C 192 239 (×42) 559 (×5.8) 797 (×7.8)

256 321 (×40) 837 (×5.0) 1157 (×6.5)

Table 4: Chip-based measurements of hybrid SCP11 proto-

cols execution, with ratio relative to classic versions, using

FN-DSA (Round 3 Falcon) signature. Note that FN-DSA

does not specify a parameter set for security level 192.

Protocol Sec. level Communication Processing Total

(ms) (ratio) (ms) (ratio) (ms) (ratio)

Mode A 128 136 (×18) 341 (×5.1) 477 (×6.4)

256 265 (×17) 750 (×3.3) 1014 (×4.2)

Mode B 128 82 (×16) 290 (×6.0) 371 (×7.0)

256 162 (×15) 629 (×4.0) 791 (×4.7)

Mode C 128 72 (×19) 173 (×3.5) 244 (×4.6)

256 137 (×17) 403 (×2.4) 540 (×3.0)

same guarantees as classical modes, validated by for-

mal proofs.

We test different standardized PQ cryptographic

primitives and FN-DSA, due to its short signatures

and fast veriﬁcation, proves to be the best ﬁt. Even if

FN-DSA signature generation is challenging to secure

against side-channel attacks, there is no problem here

as the card only needs to perform veriﬁcation. More-

over, it is usually not possible to perform physical

attacks on the OCE. Regarding performance on the

card, it could be further enhanced through specialized

accelerators, higher clock speeds, or expanded mem-

ory provided by chip manufacturers. Enhancing com-

munication speed remains another avenue, though it

requires coordinated efforts among stakeholders and

will likely take longer to implement.

Future research will extend to other protocols

in embedded ecosystems, offering formal proofs for

PQ adaptations. Collaboration with GlobalPlatform

working groups will support PQ standardization and

ensure smooth migration across embedded applica-

tions.

ACKNOWLEDGEMENTS

The author would like to thank anonymous referees

for useful and detailed comments on a previous ver-

sion of the paper.

REFERENCES

Alagic, G., Barker, E., Chen, L., Moody, D., Robinson, A.,

Silberg, H., and Waller, N. (2025). Recommendations

for Key Encapsulation Mechanisms. NIST. Special

Publication 800-227, Initial Public Draft.

Angel, Y., Dowling, B., Hülsing, A., Schwabe, P., and We-

ber, F. (2022). Post quantum Noise. In ACM CCS

2022, page 97–109. ACM Press.

ANSSI (2023). ANSSI views on the Post-Quantum Cryp-

tography transition.

Barbosa, M., Barthe, G., Bhargavan, K., Blanchet, B., Cre-

mers, C., Liao, K., and Parno, B. (2021a). SoK:

Computer-aided cryptography. In 2021 IEEE Sympo-

sium on Security and Privacy, pages 777–795. IEEE

Computer Society Press.

Barbosa, M., Barthe, G., Fan, X., Grégoire, B., Hung, S.-H.,

Katz, J., Strub, P.-Y., Wu, X., and Zhou, L. (2021b).

EasyPQC: Verifying post-quantum cryptography. In

Vigna, G. and Shi, E., editors, ACM CCS 2021, pages

2564–2586. ACM Press.

Beguinet, H., Chevalier, C., Ricosset, T., and Senet, H.

(2024). Formal veriﬁcation of a post-quantum Signal

protocol with Tamarin. In Ben Hedia, B., Maleh, Y.,

and Krichen, M., editors, VECoS ’23, volume 14368

of LNCS, pages 105–121. Springer.

Bhargavan, K., Jacomme, C., Kiefer, F., and Schmidt, R.

(2024). Formal veriﬁcation of the PQXDH post-

quantum key agreement protocol for end-to-end se-

cure messaging. In Balzarotti, D. and Xu, W., editors,

USENIX Security 2024. USENIX Association.

Bindel, N., Brendel, J., Fischlin, M., Goncalves, B., and

Stebila, D. (2019). Hybrid key encapsulation mecha-

nisms and authenticated key exchange. In Ding, J. and

Steinwandt, R., editors, PQCrypto 2019, pages 206–

226. Springer.

Blanchet, B., Abadi, M., and Fournet, C. (2008). Auto-

mated veriﬁcation of selected equivalences for secu-

rity protocols. Journal of Logic and Algebraic Pro-

gramming, 75(1):3–51.

Blanchet, B. and Jacomme, C. (2023). CryptoVerif:

a computationally-sound security protocol veriﬁer.

Technical Report RR-9526, Inria.

Blanchet, B., Smyth, B., Cheval, V., and Sylvestre, M.

(2023). ProVerif 2.05: Automatic cryptographic pro-

tocol veriﬁer, user manual and tutorial.

Brendel, J., Fiedler, R., Günther, F., Janson, C., and Ste-

bila, D. (2022). Post-quantum asynchronous deniable

key exchange and the Signal handshake. In Hanaoka,

G., Shikata, J., and Watanabe, Y., editors, PKC 2022,

Part II, volume 13178 of LNCS, pages 3–34. Springer.

Brendel, J., Fischlin, M., Günther, F., Janson, C., and Ste-

bila, D. (2020). Towards post-quantum security for

Signal’s X3DH handshake. In Dunkelman, O., Jacob-

son, Jr., M. J., and O’Flynn, C., editors, SAC 2020,

volume 12804 of LNCS, pages 404–430. Springer.

BSI (2018). Elliptic Curve Cryptography. Technical Guide-

line TR-03111, version 2.10.

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

118

BSI (2024). Cryptographic Mechanisms: Recommenda-

tions and Key Lengths. Technical Guideline TR-

02102-1, version 2024-01.

Celi, S., Hoyland, J., Stebila, D., and Wiggers, T. (2022). A

tale of two models: Formal veriﬁcation of KEMTLS

via Tamarin. In Atluri, V., Di Pietro, R., Jensen, C. D.,

and Meng, W., editors, ESORICS 2022, Part III, vol-

ume 13556 of LNCS, pages 63–83. Springer.

Chen, L., Moody, D., Randall, K., Regenscheid, A., and

Robinson, A. (2023). Recommendations for Discrete

Logarithm-based Cryptography: Elliptic Curve Do-

main Parameters. NIST. Special Publication 800-186.

Coron, J.-S., Gérard, F., Montoya, S., and Zeitoun, R.

(2022). High-order table-based conversion algorithms

and masking lattice-based encryption. IACR TCHES,

2022(2):1–40.

Coron, J.-S., Gérard, F., Montoya, S., and Zeitoun, R.

(2023). High-order polynomial comparison and

masking lattice-based encryption. IACR TCHES,

2023(1):153–192.

Cremers, C., Fontaine, C., and Jacomme, C. (2022). A logic

and an interactive prover for the computational post-

quantum security of protocols. In 2022 IEEE Sympo-

sium on Security and Privacy, pages 125–141. IEEE

Computer Society Press.

Difﬁe, W., van Oorschot, P. C., and Wiener, M. J.

(1992). Authentication and authenticated key ex-

changes. DCC, 2(2):107–125.

Dolev, D. and Yao, A. C. (1983). On the security of pub-

lic key protocols. IEEE Transactions on Information

Theory, 29(2):198–207.

Dworkin, M. (2005). Recommendation for Block Cipher –

Modes of Operation: The CMAC Mode for Authenti-

cation.

ETSI (2020). Quantum-safe Hybrid Key Exchanges. ETSI

TS 103 744 V1.1.1.

Fouque, P.-A., Hoffstein, J., Kirchner, P., Lyubashevsky, V.,

Pornin, T., Prest, T., Ricosset, T., Seiler, G., Whyte,

W., and Zhang, Z. (2020). Falcon: Fast-Fourier

Lattice-based Compact Signatures over NTRU. speci-

ﬁcation v1.2.

Freire, E. S. V., Hofheinz, D., Kiltz, E., and Paterson, K. G.

(2012). Non-interactive key exchange. Cryptology

ePrint Archive, Paper 2012/732.

Gazdag, S.-L., Grundner-Culemann, S., Guggemos, T.,

Heider, T., and Loebenberger, D. (2021). A formal

analysis of IKEv2’s post-quantum extension. In AC-

SAC ’21, page 91–105, New York, NY, USA. Associ-

ation for Computing Machinery.

Giacon, F., Heuer, F., and Poettering, B. (2018). KEM

combiners. In Abdalla, M. and Dahab, R., editors,

PKC 2018, Part I, volume 10769 of LNCS, pages 190–

218. Springer.

GlobalPlatform (2020). Secure Channel Protocol '03' –

Card Speciﬁcation v2.3 — Amendment D – Version

1.2.

GlobalPlatform (2023). Secure Channel Protocol '11' –

Card Speciﬁcation v2.3 – Amendment F – Version 1.4.

Gray, J. and Onsworth, M. (2024). Certiﬁcate mechanisms

for transitioning to post-quantum cryptography. Inter-

national Cryptographic Module Conference (ICMC)

2024.

GSMA (2023a). RSP Architecture SGP.21 v3.1.

GSMA (2023b). RSP Technical Speciﬁcation SGP.22 v3.1.

GSMA (2023c). Secured Applications for Mobile v1.1.

Günther, C. G. (1990). An identity-based key-exchange

protocol. In Quisquater, J.-J. and Vandewalle, J., ed-

itors, EUROCRYPT’89, volume 434 of LNCS, pages

29–37. Springer.

Hashimoto, K., Katsumata, S., Kwiatkowski, K., and Prest,

T. (2021). An efﬁcient and generic construction

for Signal’s handshake (X3DH): Post-quantum, state

leakage secure, and deniable. In Garay, J., editor,

PKC 2021, Part II, volume 12711 of LNCS, pages

410–440. Springer.

Herzberg, A. (2009). Folklore, practice and theory of robust

combiners. J. Comput. Secur., 17(2):159–189.

Hülsing, A., Ning, K.-C., Schwabe, P., Weber, F. J., and

Zimmermann, P. R. (2021). Post-quantum WireGuard.

In 2021 IEEE Symposium on Security and Privacy,

pages 304–321. IEEE Computer Society Press.

Jackson, D., Cremers, C., Cohn-Gordon, K., and Sasse, R.

(2019). Seems legit: Automated analysis of subtle

attacks on protocols that use signatures. In Cavallaro,

L., Kinder, J., Wang, X., and Katz, J., editors, ACM

CCS 2019, pages 2165–2180. ACM Press.

Kobeissi, N., Nicolas, G., and Tiwari, M. (2020). Verifpal:

Cryptographic protocol analysis for the real world.

In Bhargavan, K., Oswald, E., and Prabhakaran, M.,

editors, INDOCRYPT 2020, volume 12578 of LNCS,

pages 151–202. Springer.

Kret, E. and Schmidte, R. (2024). The PQXDH key agree-

ment protocol. Technical report, Signal.

Linker, F., Sasse, R., and Basin, D. (2024). A formal anal-

ysis of Apple’s iMessage PQ3 protocol. Cryptology

ePrint Archive, Paper 2024/1395.

Lowe, G. (1997). A hierarchy of authentication speciﬁca-

tion. In Computer Security Foundations Workshop,

pages 31–44. IEEE Computer Society.

NIST (2024a). Module-Lattice-Based Digital Signature

Standard. FIPS 204.

NIST (2024b). Module-Lattice-Based Key-Encapsulation

Mechanism Standard. FIPS 203.

NIST (2024c). Stateless Hash-Based Digital Signature

Standard. FIPS 205.

Paul, S. and Scheible, P. (2020). Towards post-quantum

security for cyber-physical systems: Integrating PQC

into industrial M2M communication. In Chen, L.,

Li, N., Liang, K., and Schneider, S. A., editors, ES-

ORICS 2020, Part II, volume 12309 of LNCS, pages

295–316. Springer.

Schmidt, B., Meier, S., Cremers, C., and Basin, D. A.

(2012). Automated analysis of Difﬁe-Hellman pro-

tocols and advanced security properties. In Chong, S.,

editor, CSF 2012, pages 78–94. IEEE Computer Soci-

ety.

The Tamarin Team (2024). Tamarin prover manual.

Post-Quantum Secure Channel Protocols for eSIMs: Design, Validation and Performance Analysis

119
