Scenario-Based Testing of Online Learning Programs

Maxence Demougeot

, Sylvie Trouilhet

, Jean-Paul Arcangeli

and Franc¸oise Adreit

IRIT, Universit

e de Toulouse, Toulouse, France

IRIT, Universit

e de Toulouse, UT2J, Toulouse, France

Keywords:

Online Machine Learning, Learning Program, Test, Test Scenario, Functional Testing, Testing Process.

Abstract:

Testing is a solution for veriﬁcation and validation of systems based on Machine Learning (ML). This paper

focuses on testing functional requirements of programs that learn online. Online learning programs build and

update ML models throughout their execution. Testing allows domain experts to measure how well they work,

identify favorable or unfavorable use cases, compare different versions or settings, or reveal defects. Testing

programs which learn online has particular features. To deal with them, a scenario-based approach and a test-

ing process are deﬁned. This solution is implemented and automates test execution and quality measurements.

It is applied to a program that learns online the end-user’s preferences in an ambient environment, conﬁrming

the viability of the approach.

1 INTRODUCTION

Machine Learning (ML) techniques (Mitchell, 1997)

can be used when a software solution cannot be pro-

grammed, either because there is no known algorithm,

or because the algorithm is too complex to imple-

ment. ML relies on a learning algorithm which pro-

cesses reference examples called training data, from

which it generalizes a behavior to hold (this may be

predicting, deciding, executing a task. . . ) when faced

with data other than training data. The learning pro-

gram (LP) is the program that implements the learn-

ing algorithm, and a model is a product of running the

learning program with training data.

ML therefore consists in building (training) a

model by means of a learning program. In produc-

tion, the model transforms input data into outputs

(i.e., predictions, decisions. . . ) in accordance with

the behavior learned from the training data. In Of-

ﬂine Machine Learning, the model is built and tuned

by one or more human experts (ML experts and do-

main experts). They are responsible for choosing

an off-the-shelf learning component (i.e., a learning

program) and setting the learning parameters (hyper-

parameters). Alternatively, a speciﬁc learning pro-

gram can be developed with the help of a software

expert. ML and domain experts also select and pre-

pare the training data. After construction and ﬁne-

tuning, the model is put in production. It can be re-

built, i.e., revised or adapted, depending on the results

obtained in production, however the rebuilt and pro-

duction phases are separate. The model is thus man-

aged like standard software with maintenance steps.

Sometimes, it is difﬁcult to anticipate the data

that the model will face in production, and the model

needs to adapt over time according to the data encoun-

tered. Online Machine Learning addresses this is-

sue. According to S. Russell and P. Norvig (Russell

and Norvig, 2010), online ML relies on repeated com-

parisons between the outputs delivered in production

and what they should be (the outputs assumed to be

the “right” ones): when the model produces an output

for a given input, a domain expert provides it with the

“right” one as a feedback, triggering a new learning

phase. In that case, learning and production are inter-

twined, and learning is continuous: the learning pro-

gram updates the model iteratively and incrementally

throughout its execution. Since, the learning context

may be open and unpredictable, it has to deal with

unanticipated training data arriving on the ﬂy, which

may be of poor quality but whose defects cannot be

corrected before learning as with ofﬂine learning.

In ML, testing is part of the model development

and tuning process, with the aim of assessing its qual-

ity, especially its compliance with functional require-

ments. Upstream, the LP must also be tested as de-

fects can lead to the production of poor models. Sec-

tion 2 analyzes these issues with a particular focus

on online learning, and highlights the differences be-

tween testing a model and testing a learning program.

Demougeot, M., Trouilhet, S., Arcangeli, J.-P. and Adreit, F.

Scenario-Based Testing of Online Learning Programs.

DOI: 10.5220/0013503100003964

In Proceedings of the 20th International Conference on Software Technologies (ICSOFT 2025), pages 99-110

ISBN: 978-989-758-757-3; ISSN: 2184-2833

This paper addresses the problem of testing

learning programs in the context of online ML. It

focuses on functional testing: the aim is to verify

that the machine learns “well”, i.e., that the LP builds

models whose behaviors are in line with the train-

ing data in the various learning situations it may face.

Testing is a way to show how well the LP works, to

identify favorable or unfavorable use cases, to com-

pare different versions or settings, or to reveal defects.

To solve this problem, we propose a scenario-

based approach and a testing process. Test scenar-

ios are designed by domain experts without neces-

sarily skills in ML, based on properties to be con-

trolled. Then, they are automatically transformed and

run to produce quality measurements. We apply this

solution to a program called OCE, which learns on-

line how to build applications for an end-user in an

open context. We show how our approach can be

used, present a toolset that implements our proposal

within the OCE framework, and examine several use

cases that show the viability of our solution.

The paper is organized as follows. Section 2 an-

alyzes the problem of testing learning programs and

sets out the research questions we are addressing.

Section 3 introduces our case study: the opportunistic

composition engine (OCE). Section 4 describes the

scenario-based approach to test programs that learn

online, with a process for carrying it out. Section 5

presents a solution to implement and run scenarios,

with a toolset we have developed to test OCE’s learn-

ing program. This approach has been validated in a

number of use cases, some of which are presented in

Section 6. Section 7 studies the related work. Finally,

we draw some conclusions in Section 8.

2 LP TESTING

Work on ML-based software testing mainly focuses

on models resulting from ofﬂine supervised learning

(Zhang et al., 2020). In this work, we target learning

programs that build models online and iteratively. In

the following, we highlight the differences between

testing models and testing learning programs, and fo-

cus on testing programs that learn online.

2.1 LP Testing vs Model Testing

Machine learning encompasses learning activities

(i.e., building a model by a learning program) and

decision-making activities (i.e., using the model),

whether learning and decision are interleaved or not.

Models and learning programs are distinct artifacts,

each of them requiring testing.

A common problem is the lack of precise speci-

ﬁcations, which limits veriﬁcation possibilities. An-

other is the non-deterministic nature of machine

learning (Sugali, 2021), particularly (but not exclu-

sively) in the case of online learning. Randomness in-

herent in learning and decision-making mechanisms

leads to variable outcomes from one execution to an-

other, even with the same inputs. Thus, it can happen

that the expected results are not obtained during tests

even though the learning and decision-making mech-

anisms are working correctly (Khomh et al., 2018).

For example, in reinforcement learning (Sutton and

Barto, 2018), it is normal for the machine to some-

times choose, for exploration purposes, a solution

that is neither the best nor the logically expected one.

Therefore, it is difﬁcult to determine if an unexpected

output results from a random factor or a defect in the

learning mechanism.

Model Testing: Before deploying a model, testing

aims to answer the question: is the model a “good”

model? In other words, did the machine “learn” effec-

tively? Model testing shares the same goals as tradi-

tional software testing but focuses on quality proper-

ties speciﬁc to the model such as accuracy, relevance,

or robustness (Zhang et al., 2020). It consists in run-

ning the model and evaluate the decisions it makes.

This poses several challenges that we examine below.

Since models result from running a learning pro-

gram fed by examples, defects may arise from the

training data, the learning program, or a mismatch be-

tween the two (when a program poorly learns from

certain data) (Zhang et al., 2020). However, it is chal-

lenging to trace the source of a defect to correct it.

Indeed, models do not have the same materiality as

traditional software: they do not consist of a simple

source code but are composed of more or less tan-

gible various elements (code, parameters, data) and

often operate as a “black box”.

On the other hand, ML is sometimes used by de-

velopment teams in situations where the expected re-

sults are not known in advance (Murphy et al., 2007).

In this case, predicting and interpreting test results is

an additional challenge, and it can be difﬁcult to de-

termine whether a test passes or not. Software ex-

hibiting this problem, known as the oracle problem,

is often considered non-testable(Weyuker, 1982) due

to the absence of an oracle or the difﬁculty in design-

ing one (Nakajima, 2017).

Interpreting the results can also be tricky, due to

the nature of the outputs and their complexity. In this

context, it is so challenging to measure the quality of

models using commons criteria such as precision (ra-

tio of correct answers to given answers), recall (selec-

ICSOFT 2025 - 20th International Conference on Software Technologies

100

tion rate of correct answers), or F-scores (combina-

tion of precision and recall).

Learning Program Testing: Although the two

problems are closely related, testing a learning pro-

gram is not the same as testing a model. The question

is: does the learning program “learn well” across the

scope for which it was designed? In other words, does

the learning program build “good” models relative to

the training data provided to it?

The correspondence between training data and

model is captured by the formula 1, in which D is

a training dataset, Scope is the set of all training

datasets that the LP might encounter, P1 is a prop-

erty of D, M

is the model built by the LP from D,

and P2 is an expected property of M

∀D ∈ Scope, P1(D) =⇒ P2(M

) (1)

In other words, this formula means that if the

learning program has built a model M

from train-

ing data D that satisfy P1, then M

should satisfy P2.

For illustration purposes, let’s take the example of a

robot that learns to move from one point to another

in a complex and dynamic physical space. In this

case, the LP builds a model to guide the robot from

reference routes. We might want to check that IF D

contains no routes that use a given corridor C (P1)

THEN to go from point A to point B, M

guides the

robot without passing through corridor C (P2). As

usual in testing, the goal is to assess (un)satisfaction

of the formula 2, that captures the mismatch between

training data and model, i.e., a poor transformation

of training data into a model:

∃D ∈ Scope, P1(D) ∧ ¬(P2(M

)) (2)

However, identifying P1 as well as selecting D is

crucial to the overall signiﬁcance of the tests and de-

mands strong domain expertise. Neither D nor M

are simple data, as numerical data for example. In

the case of online ML, D is a sequence of training

data which is required to meet P1. Selecting D is all

the more delicate since, in production, data arrives in

sequence and are not always expected. Hence, the

question is not about the presence of a defect in the

training data (a common source of defects in models);

rather, it’s about checking the consistency between

training data and the model built from them (possi-

bly to conclude that there is a mismatch between the

two).

Deﬁning an expected property of the model (P2)

is another source of complexity: especially, it is not

possible to specify expected models for comparisons

and accuracy assessment (the oracle problem again).

P2 is thus a property related to the decisions that a

model makes. To check if the latter satisﬁes P2, and

thus indirectly evaluate the quality of the learning pro-

gram, it must be executed. Therefore, LP testing suf-

fers from the problems associated to model testing.

Cross-Validation and K-fold cross-validation

(Berrar, 2019) are standard methods for testing the

performance of models, especially overﬁtting and

underﬁtting. They are commonly used for compar-

ison and selection of the most appropriate model.

They consist in putting aside part of the training data

to use it as test data. But, in the context of online

learning, they are not applicable for assessing the

correspondence between the sequence of training

data and the model since they do not allow to capture

the consequence relationship between data and model

expessed by the IF-THEN formula 1.

Thus, to tackle the LP testing problem, testers

need to have different models built by the learning

program for different use cases, with the aim of sub-

sequently testing each of these models. So, running a

test case must ﬁrst construct a model then run and

evaluate it. This makes both design and execution of

the test cases more complex.

Testing learning programs is therefore costly; it

requires signiﬁcant expertise in terms of domain and

business and, as much as possible, automation.

2.2 Research Questions

Based on the above analysis, we have identiﬁed three

research questions regarding the testing of online

learning programs:

• RQ1: How to design test cases that include learn-

ing and evaluation steps and conform to expected

properties?

• RQ2: How to organize the testing workﬂow, from

the test set design to execution and evaluation?

• RQ3: As part of the workﬂow, how to implement

a test case, automate its execution, and determine

if the test passes or not?

Before presenting our answers to RQ1 and RQ2

in Section 4, and to RQ3 in Section 5, Section 3 in-

troduces the fundamental principles of our case study,

OCE, which is a program that learns online in inter-

action with the end user.

3 OCE: A PROGRAM THAT

LEARNS ONLINE

Let’s start with some background to better understand

what the Opportunistic Composition Engine (OCE)

Scenario-Based Testing of Online Learning Programs

101

does. A software component is an executable soft-

ware entity that provides services and requires oth-

ers to function (Sommerville, 2016). Component-

based programming involves assembling components

by binding their services to form an application. The

Figure 1 represents in UML (OMG, 2017) a sim-

ple example of a text-to-speech application that as-

sembles four components: TextInput for text input,

TextToVoice for text-to-voice conversion, Speaker,

and Button. TextInput uses the TextProcess service

provided by TextToVoice to transmit the text. Text-

ToVoice converts the text into an audio signal and

passes it to Speaker via the VoiceProcess service.

Speaker plays the audio signal, which volume can be

adjusted using Button and transmitted to Speaker via

the SetVolume service.

Figure 1: UML component diagram (OMG, 2017) of the

Text-to-Speech application.

OCE is an ambient intelligence (Dunne et al.,

2021) prototype solution that dynamically builds ap-

plications based on software components present

in the ambient environment and knowledge learned

about the user’s preferences (Younes et al., 2020).

OCE automates the assembly operation. In ambient

environments, characterized by their open and dy-

namic nature, components may appear or disappear

unpredictably. So a major challenge is to manage the

variability of these environments and to offer the user

“right” applications according to their situation.

Figure 2: OCE application building process.

OCE consists of a reinforcement learning (Sutton

and Barto, 2018) program and a model that is con-

tinuously trained and evolving. An OCE “cycle” is a

sequence of several steps (Figure 2):

1. OCE detects the available components in the

user’s ambient environment.

2. Based on the available components and learned

knowledge about the user’s preferences, OCE’s

model decides on the assembly to build.

3. OCE presents the assembly proposition to the user

through a graphical interface.

4. The user accepts, modiﬁes, or rejects the assem-

bly proposition. These actions translate into pos-

itive or negative rewards, which serve as training

data for OCE’s learning program.

5. OCE learns by reinforcement, i.e., OCE’s learning

program increments and adapts the model.

Thus, through successive cycles and interactions

with the user, OCE learning solution builds and

evolves online a model on which the future decisions

will be made.

Several working prototypes of OCE have been de-

veloped. Do they propose applications to the user that

are tailored to their preferences in the current situa-

tion? Testing is a way to answer this question and to

build trust in OCE.

4 SCENARIO-BASED TESTING

APPROACH

4.1 Test Scenario

To be evaluated, a learning program must be executed

on training data. Then, the resulting model must be

evaluated in turn. Since the learning program builds

different models depending on the training data, dif-

ferent models must be evaluated. In an iterative and

incremental context such as online learning, design-

ing a test case requires deﬁning a sequence of inter-

actions between the learning program and its learning

environment to build a model. To check that the built

model behaves as expected, other interactions are re-

quired for evaluation purposes. Learning and evalu-

ation interactions can be intertwined. We call a se-

quence of such interactions a test scenario.

A learning phase consists in a sequence of inter-

actions which must conform to P1 with, for each in-

teraction, an output produced by the model from the

input data, a feedback, then a learning operation to

improve the model. Each interaction is so described

ICSOFT 2025 - 20th International Conference on Software Technologies

102

by: (i) a learning situation, i.e., the environment in

which the model should produce an output, (ii) an

output that the model should ideally return in this sit-

uation, called ideal output. Deﬁning the ideal output

for each learning interaction, as well as expected out-

puts facilitates automation: it avoids the need for the

tester to constantly interact with the learning program,

which is tedious and costly. Based on the outputs pro-

duced by the model and the ideal outputs, the learning

program learns and updates the model in the learning

phase of the test as it does in normal operation. At

the end of this phase, a model is built that is ready for

evaluation.

An evaluation phase consists of one or several

interactions too. An interaction is deﬁned by the de-

scription of both the situation in which the model has

to deliver an output and a property of this output that

must be checked (P2). In its simplest form, the prop-

erty can be the expected output or several possible

correct outputs. Expected outputs are intended to be

compared with the output returned by the model to

give a measure of quality. Depending on what the

designer expresses in terms of expected property (a

single or several expected outputs, or a more general

property), they act more or less like an oracle.

Organized in this way, such scenarios support the

testing of online learning programs, which answers

RQ1. We now apply this solution to a particular case:

OCE’s online learning program.

Application to OCE. For OCE, an interaction cor-

responds to a cycle, and a test scenario is a sequence

of learning and evaluation cycles. A learning cycle is

described by a list of software components populat-

ing the ambient environment and the ideal assembly.

The latter speciﬁes the assembly the user would ac-

cept in normal use in this situation, and which is used

to learn. An evaluation cycle is also deﬁned by a

list of software components, this time with a property

of the assembly that OCE’s model is expected to re-

turn. This can be in the form of one or more expected

assemblies for comparison, or take the form of more

general properties, e.g., the presence of certain com-

ponents or connections in the assembly.

It is possible to deﬁne scenarios to test OCE’s

learning program in different ambient environments,

with more or less dynamics according to P1.

For instance, as a tester, we seek to verify that IF a

user expresses a preference for a component in a cer-

tain situation, and that component disappears from

the ambient environment (P1) THEN if it reappears

in a similar situation, OCE again proposes an assem-

bly with that component (P2). To deﬁne a scenario,

let’s take a toy example adapted from (Younes et al.,

Figure 3: Learning cycles of the example scenario.

2020) and simpliﬁed for clarity. Mary is at work. In

her ambient environment, there are a software compo-

nent Desk that provides a room booking service called

Order, and three components, Text, Voice, and Tac-

tile, which allow the user to make a booking request

(with different interaction modes) and require the Or-

der service. Through the Order service, these three

components may be assembled with Desk. Thus,

three applications are possible (Text-Desk, Voice-

Desk, Tactile-Desk), enabling Mary to book a meet-

ing room. To do so, Mary prefers the component

Voice. Then, Voice disappears and reappears later.

We seek to verify that OCE again proposes the as-

sembly Voice-Desk when Voice reappears.

Let’s deﬁne a scenario with three cycles. Cycles

0 and 1 (Figure 3) deﬁne the learning phase. Cycle

0 is deﬁned by the list of the 4 components and the

ideal assembly Voice-Desk (Mary’s preference). For

cycle 1, Voice has disappeared, so the components are

Desk, Text, and Tactile, and the ideal assembly in this

case is Text-Desk. The composition of the ambient

environment and the ideal assemblies in cycles 0 and

1 satisfy P1.

Figure 4: Evaluation cycle of the example scenario.

In the evaluation phase, cycle 2 (Figure 4) deﬁnes

a situation, different from the two previous ones, in

which OCE must provide an assembly: the ambient

environment is composed of Desk, Text, and Voice

that has reappeared (Tactile has desappeared). Here,

Voice-Desk is speciﬁed as the expected assembly in

order to be compared with the assembly proposed by

OCE. Here, P2 is deﬁned at the simplest by a single

expected assembly and coupled with a function that

computes a distance between the expected assembly

and the OCE output. To measure this distance, such

a function may, for instance, compute a Jaccard Sim-

ilarity Index

https://en.wikipedia.org/wiki/Jaccard index

Scenario-Based Testing of Online Learning Programs

103

4.2 Scenario-Based Testing Process

Figure 5: Activity Diagram of the Scenario-based Testing

Process.

In a scenario-based testing process (Figure 5), the ﬁrst

activity is to identify a formula to be tested, namely

P1 which describes a property of the training data (in

the case of OCE, a property that the sequence of ambi-

ent environments and ideal outputs must satisfy), and

P2 which relates to the expected result.

Next, it is necessary to deﬁne the ways of veri-

fying that P2 is satisﬁed. A standard way is to use

statistical metrics based on the performance of the

model, such as accuracy, recall, or F1-score. In the

case of OCE, a metric based on the distance between

proposed assemblies and expected assemblies can be

used to check whether the model has made good as-

sembly proposals or not.

Then, an iterative design of the scenario test set

begins. Deﬁning scenarios is guided by tactics, e.g.,

limiting the complexity of the training sequence con-

forming to P1 in order to facilitate the analysis of

test results. For each scenario, the learning phase is

designed to meet P1 and the evaluation phase is de-

signed to enable the assessment of P2.

Once the set of scenarios is considered to sufﬁ-

ciently cover the scope for which the LP was designed

(as it stands, the question of the coverage of the ap-

plication scope by the set of test scenarios is up to

the tester - see sections 6.4), each scenario is imple-

mented then executed, and the results analyzed. The

metrics previously deﬁned support measures that en-

able testers to evaluate the model’s behavior and de-

termine whether it satisﬁes P2, i.e., whether the test

passes or not.

It is then possible to draw general conclusions

about the learning program depending on possibly in-

adequate model behaviors that have been highlighted

in the test. Note that the issues related to defect loca-

tion and their correction are beyond the scope of this

paper.

This process (represented in Figure 5) can be re-

peated for different formulas, answering so to RQ2.

Besides, since testing online LP is costly, it is cru-

cial to automate the process as much as possible. In

the following section, we propose an answer to RQ3,

which covers the Implementation, Run and, partially,

Analysis phases of the testing process.

5 TOOLING

This section ﬁrst presents the general principles of

scenario implementation and automatic execution.

Then, it describes the application of these principles

to the testing of OCE’s learning program, supported

by two tools: Maker and Runner.

5.1 General Principles

To achieve the scenario-based approach and provide

abstractions and facilities to testers, several tools are

required. To implement a scenario, domain experts

need a scenario editor. To describe the learning data,

the editor must enable the expression of the learning

interactions, each containing a learning situation with

its associated ideal output. In addition, it must al-

low evaluation interactions to be expressed, i.e., sit-

uations in which the model must produce a result, as

well as the measurement functions that evaluate the

expected properties of the results. Finally, the tool

must translate the scenario into an automatically exe-

cutable form.

To automatically run a scenario with the LP under

test, a second tool is required. This one orchestrates

the execution of a scenario by sequentially running

the interactions. It interacts with the online LP under

test, providing both learning situations and feedback.

In an evaluation interaction, the tool also provides a

situation, gets the LP output, applies the measurement

functions to it and delivers the measured values.

ICSOFT 2025 - 20th International Conference on Software Technologies

104

5.2 Application to OCE

To apply these principles to the test of OCE’s learn-

ing program, we have developed two tools: OCE Sce-

nario Maker to edit OCE scenarios and OCE Scenario

Runner to automatically run them. A short additional

video

demonstrates their usage in the scenario de-

scribed in Section 4.1.

5.2.1 OCE Scenario Maker

This is an interactive tool for implementing OCE sce-

narios. In practice, the tester can reuse or deﬁne ﬁc-

titious components (Figure 6, left panel). For a learn-

ing cycle, according to the formula they want to test,

they can drag and drop components into a panel to de-

ﬁne the ambient environment, and bind their services

to deﬁne the ideal assembly, following P1 (Figure 6,

right panel). The same principle applies for evalua-

tion cycles. In this case, the tester sets a measure-

ment function to assess the satisfaction of the prop-

erty they expect on the assembly proposed by OCE

(P2). For example, the function can measure a dis-

tance (e.g., a Jaccard Similarity Index) between the

proposed assembly and an expected one, or an aver-

age distance with several assemblies, or the presence

of a speciﬁc component or connection in the proposed

assembly. Additional features, such as the ability to

duplicate a cycle, reduce the tester’s workload. From

a sequence of cycles, Maker generates a JSON

ﬁle

that implements a scenario intended to be automati-

cally run with the second tool, Runner.

5.2.2 OCE Scenario Runner

This is a Java application that, coupled with OCE,

allows the automated execution of OCE scenarios in

JSON format, such as those generated by Maker. The

tester selects a scenario to run. Various parameters

need to be set, such as learning hyperparameters (e.g.,

exploration rate of reinforcement learning), and the

version of OCE to test. To mitigate the impact of the

non-deterministic nature of machine learning, Runner

allows to repeat the execution of the scenario.

Once the parameter values are set, it operates cou-

pled with OCE without further intervention from the

tester. To assess the relevance of OCE’s outputs, Run-

ner runs the measurement function at each evaluation

cycle, then provides an average value over all evalu-

ation cycles, last an average value over all scenario

repetitions. This measure indicates whether the con-

structed models made relevant propositions based on

https://www.irit.fr/OppoCompo/

makerrunnerusecase2024/

https://www.json.org/json-en.html

Figure 6: Maker’s interface for scenario implementation.

what OCE’s learning program learned, i.e., based on

the user’s preferences.

5.2.3 Architecture

Maker and Runner have been implemented and inte-

grated into the OCE system, which architecture can be

represented in the form of a UML component diagram

too (OMG, 2017). Figure 7 represents the conﬁgura-

tion of the OCE system in production. When the am-

bient environment changes, OCE receives from Am-

bient Env. the list of components that are currently

present (ProcessOneEnv service). OCE builds an as-

sembly and proposes it to the user via the User Inter-

face and the user provides feedback in the form of an

assembly (Feedback service).

Figure 7: Architectural view of OCE in production conﬁg-

uration.

Figure 8: Architectural view of OCE in testing conﬁgura-

tion.

Figure 8 shows how Maker and Runner have been

Scenario-Based Testing of Online Learning Programs

105

integrated into OCE architecture. The modularity of

this architecture allows replacing Ambient Env. and

User Interface by Runner to perform tests imple-

mented with Maker. In the testing conﬁguration,

Runner executes a scenario taken from the Repos-

itory of scenarios (ReadScenario service). The di-

rectory is populated by scenarios implemented with

Maker (SaveScenario service). For each cycle of the

scenario, Runner requests OCE to propose an assem-

bly (ProcessOneEnv service). In learning cycles, fol-

lowing the proposition, Runner provides OCE with

the ideal assembly (Feedback service), which OCE

treats as user feedback. In evaluation cycles, Run-

ner computes quality measurements on the assem-

blies proposed by OCE.

6 VALIDATION

We have applied the scenario-based testing approach

to conduct a test campaign of OCE’s learning pro-

gram. The aim of this campaign is to evaluate its abil-

ity to learn user preferences in various use cases. We

present three of them, all related to the disappearance

and appearance of components that are involved in the

user’s favorite assemblies. More speciﬁcally, the test-

ing process described in Section 4.2 is applied to:

1. The disappearance and reappearance of a compo-

nent involved in the user’s favorite assembly.

2. The disappearance and appearance of two compo-

nents used together and preferred by the user.

3. The disappearance and appearance of components

in a realistic case of a smart home.

For each use case, i.e., for each formula to be eval-

uated, several scenario were designed but only one

is presented in this paper. The experimental condi-

tions are as follows. We take the standard version

of OCE with default settings. In these settings, the

value of the reinforcement learning exploration co-

efﬁcient is 0.1. This means that the OCE’s model

has a 10% probability of exploring alternative con-

nections between components rather than exploiting

knowledge acquired about user preferences. In addi-

tion, to smooth out the impact of random factors, each

scenario is run 100 times.

6.1 Use Case 1: Disappearance and

Reappearance of a Component

Here is the ﬁrst use case for the scenario-based test-

ing approach: as OCE testers, we want to verify that

IF the user expresses a preference for a component

in their ambient environment and this component dis-

appears (P1), THEN OCE proposes again an assem-

bly including this component when it reappears (P2).

Different scenarios were designed for this use case

(by varying the number of cycles, appearances and

disappearances. . . ) using two tactics:

• Limit the complexity of the P1-compliant train-

ing sequence, i.e., the number of components, ser-

vices, and cycles.

• Ensure that OCE’s model has to make a choice be-

tween several possible connections at each cycle

(decide), in order to leverage knowledge of user’s

preferences and make them evolve from user’s

feedback.

In order to evaluate P2, the tester chooses to use the

Jaccard Similarity Index between the assembly pro-

posed by OCE and a given expected one.

A scenario designed for this use case is the three-

cycle scenario described in Section 4.1: the compo-

nent Voice, preferred by Mary in Cycle 0, disappears

in Cycle 1 then reappears in Cycle 2. Cycles 0 and 1

are the training data (D) satisfying P1. The goal is to

verify that OCE’s model proposes again the assembly

Voice-Desk when Voice reappears, i.e., P2(M

This scenario was implemented using Maker and

run using Runner. Running showed that out of the

100 runs, in about 90 the similarity index calculated

between the assembly proposed by OCE and the ex-

pected one in the evaluation cycle equals 1.0, indicat-

ing that the produced and expected outputs are identi-

cal. This means that OCE did actually propose the as-

sembly with the component Voice when it reappeared.

In the other 10 runs, OCE did not propose this as-

sembly, due to exploration during the evaluation cy-

cle. The other designed scenarios showed the same

results. Thus, for this use case, testing did not reveal

a value of D such as formula 2 is true, i.e., no incorrect

behavior of OCE’s learning program was identiﬁed.

In the following use cases, test design was based

on the same tactics and distance measurement func-

tion. So, we do not repeat these points in the text.

6.2 Use Case 2: Disappearance and

Reappearance of Two Components

Used Together

In this use case, we take component disappearance

and reappearance a step further, where two compo-

nents used together are affected. This time, we want

to verify that IF the user expresses a preference for

using two components together (P1), THEN OCE

later selects these two components when they are

available together again (P2).

ICSOFT 2025 - 20th International Conference on Software Technologies

106

Figure 9: Learning cycles of the use case 2.

Figure 10: Evaluation cycle of the use case 2.

Here is a scenario with components for a text-to-

speech application. It includes four learning cycles

that deﬁne D, which satisﬁes P1 (Figure 9) followed

by one evaluation cycle that speciﬁes P2 (Figure 10).

When the user uses the keyboard (Keyboard), they

prefer to use the room’s speaker (Speaker) at the

same time. This preference is expressed by the ideal

assemblies of cycles 0 and 3. But when the smart-

phone’s virtual keyboard (VKeyboard) is available in

the ambient environment, they prefer to use it together

with the smartphone’s speaker (PhoneSpeaker). This

is expressed by the ideal assemblies of cycles 1 and

2. In this context, we would like to check that if

VKeyboard disappears, OCE actually proposes to

use Speaker together with Keyboard.

This scenario yielded some interesting results. In

about 90 runs, the similarity index is equal to 0.33.

This score means that the produced output is far from

the expected one. In these runs, OCE proposed an

assembly with PhoneSpeaker even though VKey-

board was unavailable, thus did not learn well the

user’s preferences. In the other 10 runs, OCE did pro-

pose the expected assembly due to exploration at cy-

cle 4. This result shows a value of D for which the

formula 2 is true. This use case thus reveals an un-

expected behavior of OCE’s learning program, proba-

bly requiring further tests and in-depth analysis which

could lead to the conclusion that, in such cases, OCE

fails to generalize what it has learned.

6.3 Use Case 3: Towards a More

Realistic Use Case

Figure 11: Learning cycles of the use case 3.

Figure 12: Evaluation cycles of the use case 3.

In this use case, we want to test the behavior of OCE’s

learning program in a more realistic context of a smart

home. The aim is to verify that IF the user moves

around several rooms in their home, involving a se-

ries of appearances and disappearances of compo-

nents in their surrounding environment (P1) THEN

when the user returns to these rooms, OCE proposes

their favorite assemblies in the room, despite slight

variations in the ambient environment (P2). To do

so, we designed a scenario where the user navigates

between the bedroom, kitchen and living room. As

a result, several components become available or un-

available in their ambient environment depending on

the room. Besides, the user has a smartphone pro-

Scenario-Based Testing of Online Learning Programs

107

viding a button for switching a device on or off, and

a plus-minus button for adjusting a device (e.g., the

volume of a speaker). Embedded in the user’s phone,

which they keep close at all times, these two compo-

nents are permanently available.

The scenario comprises three learning cycles (Fig-

ure 11) followed by three evaluation cycles (Fig-

ure 12). When the user wakes up, they are in their

bedroom. Here, there are three components: a heater,

a treadmill and a lamp. In this context, the user prefers

to use the ﬁrst button provided by the smartphone to

turn on the lamp, and the plus-minus button to turn

down the heating. In the cycle 0 of the scenario (see

Figure 11), these preferences are translated into the

ideal assembly. Next, the user heads for the kitchen to

make a coffee. On the way, they ﬁnd their headphones

and want to listen to the news on the radio. The user

then uses the buttons on their smartphone to switch

on the coffee machine and adjust the volume of the

headphones, which corresponds to the ideal assembly

in the cycle 1. Finally, the user sits down in the liv-

ing room to watch an episode of their favorite show.

To do this, the user uses their smartphone’s streaming

application to project the show onto the TV, using the

second speaker (ideal assembly of the cycle 2).

This sequence is repeated the next day. In the sce-

nario, it is deﬁned by the three evaluation cycles, to

check that OCE’s learning program learned the user’s

preferences in each room of the home. However, a

few changes took place: the user has received their

brand-new pressure cooker, which they store in the

kitchen. This new component can be turned on/off

via the button of the smartphone. Besides, in the liv-

ing room, the battery of their tablet is fully recharged.

The user might now project shows on it and adjust

the volume using the plus-minus button. Lastly, the

ﬁrst speaker in the living room is broken thus is no

longer available in the ambient environment. These

changes have an impact on the composition of ambi-

ent environments of the evaluation cycles, but as the

user preferences remain unchanged, the expected as-

semblies are the same as the ideal ones that have been

stated in the learning phase.

For each evaluation cycle, in about 90% of runs,

we got an average similarity score equals to 1.0,

which means that OCE’s model proposed the right

assembly. In the remaining 10%, the score is low-

ered (between 0.33 and 0.5) because OCE’s model

explored one or several connections in its proposition.

Here, as for the use case 1, testing did not reveal an

incorrect behavior of OCE’s learning program.

6.4 Lessons Learned

The scenario-based testing approach has been applied

beyond the three use cases described in this paper.

It made possible to test both simple and more com-

plex cases, with a greater number of cycles, compo-

nents and services. The test campaign highlighted

situations where OCE’s LP behaves as expected, but

also the presence of defects, e.g., in the way the user

feedback was taken into account by the learning pro-

gram. Despite its black-box nature, making default

location and correction difﬁcult, the revealed defects

have been corrected by the OCE development team.

At this stage of our work, our solution suffers from

certain limitations. In particular, domain experts have

to design test cases by hand. In addition to the formu-

las to be tested, they must imagine the scenarios they

believe to be the most signiﬁcant, which can easily

lead to oversights. As it stands, designing a scenario-

based test set (see Fig. 5) is rather cumbersome and

costly, without guaranteeing a good coverage of the

application domain. This point argues for more au-

tomation within the process to further answer RQ1.

7 RELATED WORK

7.1 Testing ML-Based Systems

Research work on testing and formal veriﬁcation of

AI-based software systems is reviewed in (De Ange-

lis et al., 2023). Research on testing software based

on ML is relatively recent compared to work on soft-

ware testing in general. Several papers address the

general problem of developing ML-based software

from a software engineering perspective but provide

only brief explanations on testing issues (Giray, 2021;

Mart

ınez-Fern

andez et al., 2022).

However, signiﬁcant papers have been published

in recent years. Zhang et al. (Zhang et al., 2020)

provided a comprehensive study on testing ML-based

software, focusing on model evaluation and properties

such as accuracy, robustness, and fairness. Among

other things, a testing process is deﬁned which targets

the ML model and debugging: it is organized in two

phases, ofﬂine testing (before deployment) and online

testing (after deployment, in a real environment). Our

process is limited to the ofﬂine phase and focuses on

the learning program. In (Braiek and Khomh, 2020),

Ben Braiek and Khomh reviewed the engineering is-

sues of ML programs and examined the testing prac-

tices. Unlike our point of view, which separates the

learning part (the LP) and the decision-making part

(the model), models are considered as a whole (in-

ICSOFT 2025 - 20th International Conference on Software Technologies

108

cluding the learning part) for testing, which does not

highlight the problem of transforming training data

into decision-making models. Riccio et al. (Riccio

et al., 2020) systematically analyzed the literature and

highlighted the main challenges related to testing, in-

cluding test case speciﬁcation, adequacy criteria, cost,

and the oracle problem. In (Mazouni et al., 2023), the

recent literature is surveyed but restricted to the test-

ing of software based on neural networks.

Among the solutions for testing ML-based sys-

tems, metamorphic testing (Chen et al., 2020) is used

to verify model behavior in the absence of an oracle.

Our approach tackles the oracle problem but in a dif-

ferent way from metamorphic testing, by expressing

P2 with a modulable level of abstraction relative to

the expected assembly.

There are works that target model testing with par-

ticular concerns. The one by Mazouni et al. aims

to reveal, not the maximum number of defects, but

their diverse natures in the context of reinforcement

learning (RL) (Mazouni et al., 2024). Biagiola and

Tonella focus on deep RL and the test of models,

called agents, by means of surrogate models (Biagi-

ola and Tonella, 2024): for that, they propose to gen-

erate environmental conﬁgurations likely to be at the

origin of agent failures. In a previous work, the same

authors examined the problem of plasticity of solu-

tions based on deep RL, i.e., their ability to adapt to

environmental conditions that deviate from the train-

ing one (Biagiola and Tonella, 2022), in the context

of continuous learning. Their approach allows to get

measures to verify the continuous evolution of mod-

els (including their non-regression) and thus to char-

acterize favorable and unfavorable use cases in open

environments. OCE also learns continuously in open

environments, but this objective differs from our own,

which is to check the alignment between the training

data and the model built by the learning program.

7.2 Scenario-Based Approaches

C. Kaner (Cem Kaner, 2013) deﬁnes a scenario as a

story of a person trying to accomplish something with

the tested product. Hussain et al. (Hussain et al.,

2015) propose a similar deﬁnition, but not directly

tied to testing: a scenario is an informal description

of a speciﬁc use of software, or of a part of it, by a

user. Here, scenarios are deﬁned from user needs (use

cases) and are used to derive test cases. According to

these deﬁnitions, a scenario is described as a sequence

of interactions between the software and a user. This

is precisely how we use scenarios to test OCE. Indeed,

a scenario describes a sequence of ambient environ-

ments (where an environment is represented by a list

of software components) as well as ideal assemblies

that model interactions between the user and OCE.

In the domain of autonomous vehicles, the con-

cept of scenario is used to evaluate vehicle behaviors

based on machine learning. For instance, Ulbrich et

al. (Ulbrich et al., 2015) describe a scenario as a tem-

poral sequence of scenes, where each scene represents

a conﬁguration of the physical environment in which

one or more autonomous vehicles operate. A scenario

details the scenes, the transitions between scenes, and

the evaluation criteria. In this context, a scenario

speciﬁes sequences of physical environments rather

than user-software interactions.

The scenario-based approach enables the compre-

hensive description of a use case, thereby facilitat-

ing end-to-end (system level) testing. This makes it

particularly suitable for evaluating machine learning-

based software due to their black-box nature. We have

tailored this approach for online learning by interleav-

ing learning and evaluation phases within a scenario.

7.3 Tools

Tools like Gymnasium (Brockman et al., 2016),

DotRL (Papis and Wawrzy

nski, 2013), and Cogment

(AI Redeﬁned et al., 2021) are designed for the devel-

opment and experimentation of reinforcement learn-

ing solutions. Evaluation of a solution typically in-

volves comparing it against other algorithms in pre-

deﬁned environments. However, these tools do not

include the notion of scenario. They only offer bench-

marks to compare algorithms, providing the tester raw

result data that need to be analyzed. In contrast, Run-

ner provides facilities such as tester-speciﬁed quality

measures of outputs, thereby making analysis easier.

8 CONCLUSION

In this paper, we deﬁne a scenario-based approach for

functional testing of online learning programs, i.e.,

of programs which iteratively build and update ML

models. Using test scenarios designed by domain ex-

perts without ML knowledge, this approach makes

them able to show how well the learning program

works, identify favorable or unfavorable use cases,

compare several versions or setting, or reveal the pres-

ence of defects. A testing process accompanying the

approach is also deﬁned, where the activities of im-

plementation, execution and result analysis can be au-

tomated, at least in part. This solution has been ap-

plied to OCE, a ML-based solution that learns online

human user preferences in an ambient environment. It

helped to better delimit the application scope of OCE,

Scenario-Based Testing of Online Learning Programs

109

and revealed several defects. Although the scenario-

based testing approach has only been experimented

with OCE using OCE-speciﬁc tooling, we believe that

the general principles, which are independent of OCE

and the application domain, are transferable to other

online learning systems.

REFERENCES

AI Redeﬁned, Gottipati, S. K., Kurandwad, S., Mars,

C., Szriftgiser, G., and Chabot, F. (2021). Cog-

ment: Open Source Framework For Distributed Multi-

actor Training, Deployment & Operations. CoRR,

abs/2106.11345.

Berrar, D. (2019). Cross-validation. In Ranganathan, S.,

Gribskov, M., Nakai, K., and Sch

onbach, C., editors,

Encyclopedia of Bioinformatics and Computational

Biology, pages 542–545. Academic Press, Oxford.

Biagiola, M. and Tonella, P. (2022). Testing the plasticity

of reinforcement learning-based systems. ACM Trans.

Softw. Eng. Methodol., 31(4).

Biagiola, M. and Tonella, P. (2024). Testing of deep re-

inforcement learning agents with surrogate models.

ACM Trans. Softw. Eng. Methodol., 33(3).

Braiek, H. B. and Khomh, F. (2020). On testing machine

learning programs. Journal of Systems and Software,

164:110542.

Brockman, G., Cheung, V., Pettersson, L., Schneider, J.,

Schulman, J., Tang, J., and Zaremba, W. (2016). Ope-

nAI Gym. CoRR.

Cem Kaner, J. (2013). An introduction to scenario testing.

Florida Institute of Technology, Melbourne, pages 1–

13.

Chen, T. Y., Cheung, S. C., and Yiu, S. M. (2020). Meta-

morphic testing: a new approach for generating next

test cases. arXiv preprint arXiv:2002.12543.

De Angelis, E., De Angelis, G., and Proietti, M. (2023). A

classiﬁcation study on testing and veriﬁcation of ai-

based systems. In 2023 IEEE Int. Conf. On Artiﬁcial

Intelligence Testing (AITest), pages 1–8.

Dunne, R., Morris, T., and Harper, S. (2021). A survey

of ambient intelligence. ACM Computing Surveys

(CSUR), 54(4):1–27.

Giray, G. (2021). A software engineering perspective

on engineering machine learning systems: State of

the art and challenges. J. of Systems and Software,

180:111031.

Hussain, A., Nadeem, A., and Ikram, M. T. (2015). Re-

view on formalizing use cases and scenarios: Scenario

based testing. In 2015 Int. Conf. on Emerging Tech-

nologies (ICET), pages 1–6. IEEE.

Khomh, F., Adams, B., Cheng, J., Fokaefs, M., and Anto-

niol, G. (2018). Software engineering for machine-

learning applications: The road ahead. IEEE Soft-

ware, 35(5):81–84.

Mart

ınez-Fern

andez, S., Bogner, J., Franch, X., Oriol, M.,

Siebert, J., Trendowicz, A., Vollmer, A.-M., and Wag-

ner, S. (2022). Software engineering for AI-based sys-

tems: a survey. ACM Trans. on Software Engineering

and Methodology (TOSEM), 31(2):1–59.

Mazouni, Q., Spieker, H., Gotlieb, A., and Acher, M.

(2023). A review of validation and veriﬁcation of

neural network-based policies for sequential decision

making. https://arxiv.org/abs/2312.09680.

Mazouni, Q., Spieker, H., Gotlieb, A., and Acher, M.

(2024). Testing for fault diversity in reinforcement

learning. page 136–146, New York, NY, USA. ACM.

Mitchell, T. (1997). Machine Learning. McGraw-Hill, New

York.

Murphy, C., Kaiser, G. E., and Arias, M. (2007). An ap-

proach to software testing of machine learning appli-

cations. In Int. Conf. on Software Engineering and

Knowledge Engineering.

Nakajima, S. (2017). Generalized Oracle for Testing Ma-

chine Learning Computer Programs. In Software En-

gineering and Formal Methods - SEFM 2017, volume

10729 of LNCS, pages 174–179. Springer.

OMG (2017). Uniﬁed Modeling Language, chapter 11.6.

https://www.omg.org/spec/UML/2.5.1/PDF.

Papis, B. and Wawrzy

nski, P. (2013). dotRL: A platform

for rapid Reinforcement Learning methods develop-

ment and validation. In 2013 Fed. Conf. on Computer

Science and Information Systems (FEDCSIS), pages

129–136. IEEE.

Riccio, V., Jahangirova, G., Stocco, A., Humbatova, N.,

Weiss, M., and Tonella, P. (2020). Testing machine

learning based systems: a systematic mapping. Em-

pirical Software Engineering, 25:5193–5254.

Russell, S. J. and Norvig, P. (2010). Artiﬁcial intelligence:

A Modern Approach. Pearson Education, Inc.

Sommerville, I. (2016). Component-based software engi-

neering. In Software Engineering, pages 464–489.

Pearson Education, 10

edition.

Sugali, K. (2021). Software testing: Issues and challenges

of artiﬁcial intelligence & machine learning. Int. J. of

Artiﬁcial Intelligence & Applications, 12(1):101–112.

Sutton, R. and Barto, A. (2018). Reinforcement Learning:

An Introduction. MIT Press, 2nd edition.

Ulbrich, S., Menzel, T., Reschka, A., Schuldt, F., and Mau-

rer, M. (2015). Deﬁning and substantiating the terms

scene, situation, and scenario for automated driving.

In IEEE 18th Int. Conf. on intelligent transportation

systems, pages 982–988. IEEE.

Weyuker, E. J. (1982). On testing non-testable programs.

The Computer Journal, 25(4):465–470.

Younes, W., Trouilhet, S., Adreit, F., and Arcangeli, J.-

P. (2020). Agent-mediated application emergence

through reinforcement learning from user feedback.

In 29th IEEE Int. Conf. on Enabling Technologies: In-

frastructure for Collaborative Enterprises (WETICE),

pages 3–8. IEEE Press.

Zhang, J. M., Harman, M., Ma, L., and Liu, Y. (2020). Ma-

chine learning testing: Survey, landscapes and hori-

zons. IEEE Trans. on Software Eng., 48(1):1–36.

ICSOFT 2025 - 20th International Conference on Software Technologies

110
