Towards Quantum Machine Learning in Ransomware Detection

Francesco Mercaldo

4,2 a

, Giovanni Ciaramella

1,2 b

Fabio Martinelli

3 c

and Antonella Santone

4 d

IMT School for Advanced Studies Lucca, Lucca, Italy

Institute for Informatics and Telematics, National Research Council of Italy (CNR), Pisa, Italy

Institute for High Performance Computing and Networking, National Research Council of Italy (CNR), Rende, Italy

University of Molise, Campobasso, Italy

Keywords:

Ransomware, Malware, Machine Learning, Quantum Computing, Security.

Abstract:

Ransomware represent one of the most aggressive malware, due to their capability to prevent access to data

and, as a consequence, totally paralyze the activity of any organization, such as companies, but also hospitals or

banks. Considering the inadequacy of the signature-based approach, mainly exploited by free and commercial

current antimalware, researchers are proposing new ransomware detection techniques based on deep learning.

Recently, with the introduction of quantum computing, there is the possibility to introduce quantum principles

into machine learning. In this paper, we propose an approach for ransomware detection through a quantum

machine learning model aimed to analyse images obtained from the application opcodes. In particular, a

hybrid model is proposed, composed of quantum and convolutional layers to discern between ransomware,

generic malware, and trusted applications. To demonstrate that quantum machine learning is promising in

ransomware detection, a real-world dataset composed by 15,000 applications is evaluated, by showing that the

proposed hybrid quantum model obtains promising performances if compared to (fully) convolutional models

(i.e., Alex Net, MobileNet, and a convolutional model developed by authors).

1 INTRODUCTION

Ransomware is malicious software employed by

threat actors to penetrate a network. This process

entails encrypting discovered data and withholding

the decryption key until a speciﬁed ransom is paid

to the hackers. With the advent of the digital age,

ransomware groups ﬁnd it increasingly advantageous

to operate covertly on the internet and typically re-

quest ransom payments in Bitcoin to evade detection.

In 2021, over one-third of organizations worldwide

experienced attempted ransomware attacks. There

were 623.3 million ransomware attacks globally in

2021, marking a 105% increase compared to 2020 ﬁg-

ures. This surge can be partly attributed to businesses

encountering difﬁculties adapting their networks and

https://orcid.org/0000-0002-9425-1657

https://orcid.org/0009-0002-9512-0621

https://orcid.org/0000-0002-6721-9395

https://orcid.org/0000-0002-2634-4456

supply chains for remote and hybrid work

. It is im-

portant to note that not all of these attacks were suc-

cessful; instead, they were attempted breaches. How-

ever, in 2022, the volume of ransomware attacks de-

creased by 23%, indicating that increased govern-

ment scrutiny and growing awareness of the associ-

ated risks are starting to have an impact

. Neverthe-

less, attack methods are evolving. In the past, ”tra-

ditional” ransomware techniques involved encrypting

target data and demanding a fee for the decryption

key. Now, cybercriminals are resorting to ”double-

extortion” schemes, threatening to release or sell the

data if the ransom is not paid. Other methods of extor-

tion include Denial of Service attacks and harassment

through email or phone communications. According

to Fortinet security experts, as cybercriminals utilize

data inﬁltrations and the threat of data leaks, attacks

continue to surge, exerting more signiﬁcant pressure

https://www.sangfor.com/blog/cybersecurity/ransomw

are-attacks-2022-overview

https://aag-it.com/the-latest-ransomware-statistics/

Mercaldo, F., Ciaramella, G., Martinelli, F. and Santone, A.

Towards Quantum Machine Learning in Ransomware Detection.

DOI: 10.5220/0013326400003979

In Proceedings of the 22nd International Conference on Security and Cryptography (SECRYPT 2025), pages 301-308

ISBN: 978-989-758-760-3; ISSN: 2184-7711

301

on companies to pay the ransom, and this trend will

continue in 2023

. Even if a company can restore

its data from backups, the leaked data from organi-

zations that refuse to comply with ransom demands

may surface on database websites operated by threat

actors. Cyptocurrency is commonly used for ran-

somware payments due to its anonymity. According

to Chainalysis, over $602 million in ransom payments

for attacks were made using cryptocurrency. Cyber-

security Ventures estimates that global ransomware

damage will witness a 30% year-over-year growth

over the next decade. By 2031, the damages are pro-

jected to exceed $265 billion annually, with a new at-

tack occurring approximately every two seconds. Tra-

ditional malware detection struggles with new threats

as it relies on signature-based methods. To address

this, researchers are exploring machine learning and

deep learning for improved detection. With the rise of

quantum computing, there is growing interest in ap-

plying quantum machine learning to enhance malware

detection capabilities. A quantum computer leverages

quantum mechanical phenomena to perform compu-

tations. Unlike classical computers, which use bits,

quantum computers use qubits that can exist in super-

position, allowing for parallel processing. This en-

ables them to solve certain problems exponentially

faster than classical computers, with potential appli-

cations in encryption breaking and complex simula-

tions. However, quantum computing is still largely

experimental. Quantum algorithms are designed to

exploit quantum properties like wave interference to

achieve efﬁcient computations. Recently, researchers

introduced the concept of quantum computing in the

malware detection ﬁelds, using full quantum and hy-

brid approaches (Ciaramella et al., 2022) (Mercaldo

et al., 2022) (Ciaramella et al., 2023) (He et al., 2024).

Starting from these considerations, we propose a

method for ransomware detection by exploiting quan-

tum machine learning in this paper. In detail, we pro-

pose a model aimed at discriminating between ran-

somware, (generic) malware, and legitimate applica-

tions by exploiting a network composed of a layer to

simulate quantum convolutions by considering trans-

formations in circuits to simulate a quantum com-

puter’s behavior.

The remaining of the paper proceeds as fol-

lows:the next Section provides the state-of-the-art

literature related to malware detection, while the

proposed quantum machine learning model for ran-

somware detection is described in Section 3; exper-

imental results obtained by evaluating a real-world

dataset composed of ransomware, malware, and le-

https://www.fortinet.com/resources/cyberglossary/ran

somware-statistics

gitimate applications are presented in Section 4 and,

ﬁnally, conclusion and future research lines are drawn

in the last Section.

2 RELATED WORK

Authors in (Ferrante et al., 2017) presented a method

able to detect ransomware using a static and dynamic

approach. The ﬁrst takes into account the frequency

of opcodes, while the second takes into account CPU

use, memory consumption, network usage, and sys-

tem call data. The results suggest that this combi-

nation of techniques performs well. It can detect ran-

somware with 100% precision and a false positive rate

of less than 4%.

In (Chen et al., 2017), researchers proposed a dy-

namic ransomware detection method for identifying

known and undiscovered malware utilizing data min-

ing techniques such as Random Forest, Support Vec-

tor Machine, Simple Logistic, and Naive Bayes. To

deceive the most recent concealment strategies, they

utilized a dynamic approachable to monitor program

actions and build an API call ﬂow graph. Results ob-

tained good performances.

Authors in (Jeng et al., 2022) proposed a malware

classiﬁcation method based on the static feature in

the Android environment. In particular, they extract

the opcode from the static feature of the applications

selected to build the dataset. Jeng et al. also applied

an attention mechanism that improved the accuracy of

the CNN model for the classiﬁcation performed.

In (Xing et al., 2022), authors introduced a deep

learning method to recognize malware using an au-

toencoder network. To train the latter Xing et al.

employed a dataset composed of gray-scale images

retrieved from Android applications. The detection

method proposed achieved a good accuracy of 96%.

Despite them, who obtain images from applications

by converting bytecodes, we create a script to detect

the opcodes present in each executable program. We

transformed each element stored in the list of opcodes

into a triple of integers to create an RGB picture.

3 METHOD

In this section, we describe the proposed method for

ransomware detection by means of quantum machine

learning. Thus, we introduce a model combining

quantum and convolutional layers, and several (fully)

convolutional models exploited for direct comparison

with the quantum model, in terms of performance, are

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

302

let filter_words as a set of opcode

let newLines as list

let data as list

for file in dir:

subprocess.run(objdump -b binary -D -m \

i386 file > application.txt)

for file in dir:

if file.endswith('.txt'):

open(file, 'r') as f:

for line in f:

words = line.split()

for word in words:

if word in filter_words:

newLines.append(word)

open(file, 'w') as f:

for line in newLines:

f.write(line)

f.close

for file in dir:

open(file, 'r') as f:

for line in f:

for key, values in \

dictionary.items():

if key == item:

data.append(values)

open(file, 'w') as f:

for line in newLines:

f.write(line)

f.close

Listing 1: The script converts the applications into images,

by invoking the objdump disassembler to obtain the opcodes

and then convert each opcode into an RGB pixel.

presented. The proposed method is depicted in Fig-

ures 1 and 2: in particular in Figure 1 we show how

we represent an application as an image (by obtaining

the opcode sequences through a reverse engineering

process), while Figure 2 is related to the hybrid quan-

tum model building and evaluation.

From a (ransomware, generic malware, or legiti-

mate) application under analysis, we obtain the appli-

cation opcodes through a Python script developed by

authors (shown in Listing 1).

From the Listing 1 we observe that to obtain the

opcode for each application we exploited to objdump

disassembler, natively available on Linux operating

systems

. Thus, the extracted opcode sequence is

https://man7.org/linux/man-pages/man1/objdump.1.ht

stored into a text ﬁle (from row 6 to row 8 in Listing

1).

Once stored the opcode code sequence into a text

ﬁle (named application.txt in Listing 1), from row 10

to row 24 in Listing 1, each opcode is ﬁltered i.e., we

consider opcodes without argument, and we save the

opcode list in a text ﬁle (we overwrite the applica-

tion.txt ﬁle).

From row 26 to row 37 in Listing 1 we set a unique

color for each opcode found previously in RGB (i.e.,

a triple of integers) and save them overwriting the pre-

vious application.txt ﬁle. Obviously, the same opcode

will be coded with the same color for all applications

Subsequently, by storing each pixel, we compose

the image for the application under analysis.

Figures 3, 4 and 5 report three examples of im-

ages obtained by applying the steps depicted in Fig-

ure 1 related to two different ransomware applications

(shown in Figure 3 and 4) and a legitimate one, shown

in Figure 5. The sizes of the output images are not

equal to each other, this happens because the propor-

tions are related to the number of opcodes contained

in the analyzed ﬁle.

In particular in Figure 3 we show the image ob-

tained from the ransomware identiﬁed by the 2d7ded

792db11781276f2e5f42b29b1ae37055b1f306c5bc24

7448275ea6b40f hash.

This ransomware is belonging to the Shade fam-

ily, diffused through malicious websites and infected

email attachments. Once inﬁltrated, the ransomware

belonging to the Shade family are able to encrypt

most ﬁles stored on the infected machine

. The Virus-

total report of this sample is available

In Figure 4 a second example of an image obtained

from a ransomware sample (identiﬁed by the fbeb23

5e9a95e4cfefd6fe2201e3bf9350eb23f79a98c44961

3951c2384c4671 hash) is shown.

The image shown in Figure 4 is related to a ran-

somware sample belonging to the Ransom-NB fam-

ily delivered, similarly to the Shade ransomware, as

attached to phishing emails but also as a repercussion

of user winding up on a repository that hosts a harm-

ful software. This ransomware too is able to cipher

ﬁles on the victim’s computer and it is also able to

show a ransom money note

The Virustotal report of this sample is available

https://www.malwarebytes.com/blog/news/2019/03/s

potlight-troldesh-ransomware-aka-shade

https://www.virustotal.com/gui/file/2d7ded792db117

81276f2e5f42b29b1ae37055b1f306c5bc247448275ea6b4

https://howtofix.guide/win32ransom-nb-trj/

https://www.virustotal.com/gui/file/fbeb235e9a95e4cf

efd6fe2201e3bf9350eb23f79a98c449613951c2384c4671

Towards Quantum Machine Learning in Ransomware Detection

303

Figure 1: Steps to convert an application into an image through the application opcodes.

Figure 2: Steps for ransomware detection model building with the hybrid quantum network.

Figure 3: An example of an image obtained from a ran-

somware sample belonging to the Shade family.

Figure 4: An example of an image obtained from a ran-

somware sample belonging to the Ransom-NB family.

The third example of image is obtained from a le-

gitimate application i.e., WordPad, a word process-

ing buil-in in Microsoft Windows operating systems,

which allows to create simple texts with basic format-

ting.

In particular, we consider the 22H2 version of

WordPad included in the Microsoft Windows 10 oper-

ating system, which hash is a70d52eda892edc07393

2b462cc367cdbfbace3f4196857d8d4fa869a13de792.

The related VirusTotal report is available also for this

application

https://www.virustotal.com/gui/file/a70d52eda892ed

c073932b462cc367cdbfbace3f4196857d8d4fa869a13de7

Figure 5: An example of an image obtained from the Word-

Pad application, a legitimate application included in the Mi-

crosoft Windows 10 operating system.

The hybrid quantum model building and evalua-

tion is shown in Figure 2. Once obtained a set of im-

ages belonging to (ransomware, generic malware and

trusted) applications, we need a quantum deep learn-

ing model.

We call the proposed quantum machine learn-

ing model Hybrid Quantum Convolutional Neu-

ral Network i.e., Hybrid-QCNN. The proposed quan-

tum model is considered hybrid because it considers

quantum and classical neural network-based function

blocks composed with one another in the topology

of a directed graph. We consider this a rendition

of a hybrid quantum-classical computational graph

where the inner workings (variables, component func-

tions) of various functions are abstracted into boxes.

The edges represent the ﬂow of classical information

through the metanetwork of quantum and classical

functions(Broughton et al., 2020).

The Python code we developed for the Hybrid-

QCNN is shown in Listing 2: in rows 2,3,4 and 5 there

is the quantum layer (i.e., QConv), while from rows 6

to 11 there are the convolutional layers, in particular

a Conv2D, a Flatten and two Dense layers.

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

304

model = models.Sequential()

model.add(QConv(filter_size=2, depth=8,

activation='relu', name='qconv1',

input_shape=(self.input_width_height,

self.input_width_height, \

self.channels)))

model.add(layers.Conv2D(16, (2, 2),

activation='relu'))

model.add(layers.Flatten())

model.add(layers.Dense(32, activation='relu'))

model.add(layers.Dense(self.num_classes,

activation='softmax'))

Listing 2: The Hybrid Convolutional Neural Network for

ransomware detection.

With the aim to compare to Hybrid-QCNN model

with (full) convolutional models, the following archi-

tectures are exploited in this paper: a Convolutional

Neural Network (i.e., called Standard CNN) model

LeNet and MobileNet.

model = models.Sequential()

model.add(layers.Conv2D(32,(3, 3),

activation='relu',

input_shape=(self.input_width_height,

self.input_width_height,

self.channels)))

model.add(layers.MaxPooling2D((2, 2)))

model.add(layers.Conv2D(64,(3, 3), \

activation='relu'))

model.add(layers.MaxPooling2D((2, 2)))

model.add(layers.Conv2D(128,(3, 3), \

activation='relu'))

model.add(layers.MaxPooling2D((2, 2)))

model.add(layers.Flatten())

model.add(layers.Dropout(0.5))

model.add(layers.Dense(512, activation='relu'))

model.add(layers.Dropout(0.5))

model.add(layers.Dense(256, activation='relu'))

model.add(layers.Dropout(0.5))

model.add(layers.Dense(self.num_classes,

activation='softmax'))

model.compile(loss='categorical_crossentropy',

optimizer=Adam(self.learning_rate),

metrics=['acc', Precision(name="prec"),

Recall(name="rec"), AUC(name='auc')])

Listing 3: The developed Classic CNN network.

Due to hardware limitations, we need to consider

small images for the Hybrid-QCNN model: in order

to make a fair and direct comparison we try to set the

same parameters we consider for the Hybrid-QCNN

also for the remaining networks. As a matter of fact,

for the Hybrid-QCNN model, an image size equal to

25x25x1 is considered. Once built the Hybrid-QCNN

and the remaining models, the evaluation results are

analysed in order to perform the model comparison

for ransomware detection.

4 EXPERIMENTAL ANALYSIS

In this section, we present and discuss the results of

the experiments we performed.

Relating to the model implementation, we resort

to the Python programming language and we consid-

ered two different open-source libraries, Tensorﬂow

and Tensorﬂow Quantum

, to develop the models.

TensorFlow(Goldsborough, 2016) is an open-source

machine learning software library that provides tested

and optimized modules for building deep learning

models, while Tensorﬂow Quantum(Broughton et al.,

2020) is a library aimed to offer high-level abstrac-

tions for the design and training of both discriminative

and generative quantum, compatible with the Tensor-

Flow library, along with quantum circuit simulators.

The machine considered for the experiments is

an Intel Xeon Gold 6140M CPU at 2.30GHz, 64GB

RAM equipped with the Ubuntu 22.04.01 LTS oper-

ating system.

A dataset composed by 15000 real-world appli-

cations is considered: in particular we take into

account 5000 ransomware, 5000 generic malware,

and 5000 trusted applications. The generic malware

and the ransomware samples were obtained from the

VirusShare

web site, a repository of malware sam-

ples to provide security researchers, incident respon-

ders and forensic analysts, while the legitimate sam-

ples were collected from libraries (for example, DLL

ﬁles) and executable ﬁles obtained from a Microsoft

Windows 10 machine. To conﬁrm the maliciousness

or the trustworthiness of the samples we obtained, we

submitted the ransomware, (generic) malware and le-

gitimate samples to the Virustotal

, and the Jotti

web services. In particular, we conﬁrm that all the

ransomware considered in the experiment are crypto-

ransomware, i.e., malicious ﬁles with the ability to

hunt for and encrypt targeted ﬁles (for example, im-

age, video, and document ﬁles), for instance, belong-

ing to the TeslaCrypt, Wawnnacry and Petya families.

We exploited the code snippet shown in List-

ing 1 to obtain the related images from ransomware,

(generic) malware and trusted applications.

We split the dataset into training, validation and

testing, in particular, 12000 applications are related

to the training dataset (i.e., 4000 ransomware, 4000

generic malware and 4000 trusted), 1500 applications

(i.e., 500 ransomware, 500 generic malware and 500

trusted) are reserved for the validation and the remain-

https://www.tensorﬂow.org/

https://www.tensorﬂow.org/quantum

https://virusshare.com/

https://www.virustotal.com/

https://virusscan.jotti.org/

Towards Quantum Machine Learning in Ransomware Detection

305

Table 1: Hyper-parameters setting.

Model Epochs Batch size Learning rate Image size

STANDARD CNN 10 16 0.01 100x3

ALEX NET 10 16 0.01 100x3

MobileNet 10 16 0.01 50x3

Hybrid-QCNN 1 10 64 0.0001 25x3

Hybrid-QCNN 2 20 64 0.0001 25x3

Hybrid-QCNN 3 20 16 0.001 25x3

Hybrid-QCNN 4 20 32 0.0001 25x3

Hybrid-QCNN 5 20 64 0.001 25x3

Hybrid-QCNN 6 20 16 0.0001 25x3

Hybrid-QCNN 7 15 16 0.0001 25x3

Hybrid-QCNN 8 15 16 0.001 25x3

Hybrid-QCNN 9 15 64 0.0001 25x3

Hybrid-QCNN 10 15 32 0.0001 25x3

Hybrid-QCNN 111 15 16 0.001 25x3

Hybrid-QCNN 12 20 32 0.001 25x3

Hybrid-QCNN 13 10 32 0.001 25x3

Hybrid-QCNN 14 10 64 0.001 25x3

Hybrid-QCNN 15 10 32 0.0001 25x3

Hybrid-QCNN 16 10 16 0.0001 25x3

Hybrid-QCNN 17 10 16 0.001 25x3

Hybrid-QCNN 18 15 32 0.001 25x3

ing 1500 (i.e., 500 ransomware, 500 generic malware

and 500 trusted) as testing dataset.

In Table 1 are shown the hyper-parameters for the

models considered in the experimental evaluation.

As shown in Table 1 we perform several experi-

ments, with the aim to tune the Hybrid-QCNN with

the best parameters: we consider 18 different conﬁg-

urations for the Hybrid-QCNN (each conﬁguration is

different from the other ones in terms of epochs, batch

size or learning rate).

The image size is ﬁxed due to the huge request

for computational resources: it is limited for the

Hybrid-QCNN to 25x3 i.e., we resize the images

with a width and a height of 25 pixels for 3 chan-

nels (i.e., RGB). Relating to the STANDARD CNN,

Alex Net and MobileNet networks, we consider an

image size respectively equal 100x3 for the STAN-

DARD CNN and Alex Net networks and equal to

50x3 for the MobileNet model, by considering for

these models a number of epochs of 10. We consider

these parameters, for the (fully) convolutional mod-

els to make a comparison as direct as possible with

the Hybrid-QCNN by considering, when possible, the

same hyper-parameters.

In Table 2 we present the experimental analysis

results for each conﬁguration considered in Table 1.

As shown from Table 2 the Hybrid-QCNN 1

model reaches an accuracy equal to 0.73, a preci-

sion of 0.75, and a recall equal to 0.7: this is symp-

tomatic that the proposed hybrid quantum convolu-

tional model is able to discriminate between ran-

somware, (generic) malware and trusted applications.

Also the other Hybrid-QCNN conﬁgurations gener-

ally obtain interesting performances, for instance, the

Hybrid-QCNN 2 model reaches an accuracy equal to

0.712, the Hybrid-QCNN 4 accuracy is of 0.728. The

worst accuracy is obtained bu the Hybrid-QCNN 12

Table 2: The results of the experimental analysis.

Model Loss Accuracy Precision Recall

STANDARD CNN 1.0 0.33 0 0

ALEX NET 1.10 0.33 0 0

MobileNet 1.17 0.39 0.47 0.25

Hybrid-QCNN 1 0.71 0.73 0.75 0.70

Hybrid-QCNN 2 0.745 0.712 0.735 0.686

Hybrid-QCNN 3 2.411 0.713 0.713 0.709

Hybrid-QCNN 4 0.713 0.728 0.754 0.705

Hybrid-QCNN 5 1.01 0.707 0.713 0.694

Hybrid-QCNN 6 0.713 0.731 0.749 0.712

Hybrid-QCNN 7 0.735 0.723 0.748 0.702

Hybrid-QCNN 8 1.502 0.712 0.715 0.708

Hybrid-QCNN 9 0.790 0.678 0.693 0.649

Hybrid-QCNN 10 0.736 0.726 0.747 0.700

Hybrid-QCNN 11 2.543 0.679 0.682 0.677

Hybrid-QCNN 12 1.098 0.332 0.0 0.0

Hybrid-QCNN 13 0.946 0.703 0.714 0.688

Hybrid-QCNN 14 0.779 0.722 0.739 0.712

Hybrid-QCNN 15 0.708 0.727 0.749 0.705

Hybrid-QCNN 16 0.746 0.713 0.744 0.690

Hybrid-QCNN 17 0.933 0.707 0.715 0.698

Hybrid-QCNN 18 1.098 0.333 0.0 0.0

conﬁguration, where an accuracy equal to 0.332 is

reached, probably due to the extended number of

epochs (equal to 20, as shown from Table 1) that

conduct the network in overﬁtting, with the related

performance decay. Relating to the remaining con-

ﬁgurations, as shown from the results obtained in

Table 2, the performances obtained by the Hybrid-

QCNN are satisfactory for the ransomware detection

task. With regard to the (fully) convolutional mod-

els, built with the set of parameters shown in Table

1, obtain an accuracy equal to 0.33 (for the STAN-

DARD CNN, Alex Net) models and equal to 0.39 for

the MobileNet one, conﬁrming that with a similar set

of hyper-parameters, the Hybrid-QCNN is able to ob-

tain better performances in the discrimination of ran-

somware, (generic) malware and legitimate applica-

tions.

This result is symptomatic of how promising hy-

brid networks can be, in fact considering that due to

the limitations of the hardware on which the exper-

iments were performed it was possible to evaluate a

hybrid model with only one convolutional layer, supe-

rior performances were obtained from convolutional

networks composed of many more layers. Therefore,

probably, when it will be possible to test quantum net-

works with different convolutional layers and with a

greater number of epochs, but also with a greater size

of images, higher performances than those of the cur-

rent convolutional networks will be obtained.

Figure 6 shows the confusion matrix (consider-

ing only the testing dataset) for the Hybrid-QCNN

conﬁguration. We show the confusion matrix of this

speciﬁc conﬁguration considering that with this set of

hyper-parameters we obtained the best performances

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

306

Figure 6: Confusion matrix for the Hybrid-QCNN 1 model.

Figure 7: Training and validation accuracy trend for the

Hybrid-QCNN 1 model.

in terms of accuracy, as shown from the experimental

analysis results shown in Table 2.

From the confusion matrix in Figure 6 we can note

that most of the applications were detected as belong-

ing to the right category: as a matter of fact, 344

(generic) malware (on 500), 433 ransomware (on 500)

and 326 trusted applications (on 500) were rightly

recognised. Relating to the misclassiﬁcations, 65 ran-

somware and 91 trusted applications were wrongly

labelled as (generic) malware, 48 (generic) malware

and 19 trusted application were wrongly labelled as

belonging to the ransomware category and 107 mal-

ware and 67 ransomware were wrongly classiﬁed as

trusted applications.

To understand how the Hybrid-QCNN 1 is learn-

ing through the epochs, in the follow we consider the

trends of accuracy and loss in both training and vali-

dation.

Figure 7 shows the accuracy trend of the training

and the validation for the Hybrid-QCNN 1 model.

From the trends shown in Figure 7 it emerges that

the network is training during the 10 epochs, and for

each epoch is learning more information aimed to

Figure 8: Training and validation loss trend for the Hybrid-

QCNN 1 model.

rightly discriminate between ransomware, malware,

and legitimate applications.

Figure 8 shows the trend of the training and the

validation loss for the Hybrid-QCNN 1 model.

From the loss trend shown in Figure 8, we can

note that the loss is decreasing, and this is expected

behaviour: this happens for both the training and the

validation. In particular, the decreasing trend is more

accentuated for the training, but also in the validation

we can note this behaviour.

The trend of loss that decreases, when accuracy

increases simultaneously with increasing epochs is

a symptom of the fact that the model is correctly

learning the information to distinguish between ran-

somware, (generic) malware, and legitimate applica-

tions, thus conﬁrming the experimental analysis re-

sults and that quantum machine learning is promising

in ransomware detection.

5 CONCLUSION AND FUTURE

WORK

One of the most sneaky threats in the malware land-

scape is represented by the so-called ransomware, a

malware aimed to cipher data and user documents

asking for a certain amount of money (typically in

Bitcoin) to hand data access back to users. Free and

commercial antimalware are not adequate to detect

novel malicious payloads, this is the reason why ran-

somware are free to perpetrate damages undisturbed.

Considering the recent introduction of quantum com-

putation in machine learning, in this paper we propose

a method for ransomware detection exploiting quan-

tum machine learning. We propose a hybrid neural

network model composed by quantum and convolu-

tional layers. We experiment several conﬁgurations

with the proposed model in the evaluation of a dataset

Towards Quantum Machine Learning in Ransomware Detection

307

composed by 15000 real-world applications (5000

ransomware, 5000 generic malware, and 5000 legit-

imate applications), by obtaining an accuracy equal

to 0.73, by conﬁrming that quantum machine learn-

ing can be promising in ransomware detection.

Future works will consider novel quantum deep

learning models, composed of several quantum lay-

ers. Moreover, we will investigate whether quantum

machine learning can be considered for the detection

of malware families and variants, not only categories

such as ransomware and malware.

ACKNOWLEDGMENT

This work has been partially supported by EU DUCA,

EU CyberSecPro, SYNAPSE, PTR 22-24 P2.01 (Cy-

bersecurity) and SERICS (PE00000014) under the

MUR National Recovery and Resilience Plan funded

by the EU - NextGenerationEU projects, by MUR -

REASONING: foRmal mEthods for computAtional

analySis for diagnOsis and progNosis in imagING -

PRIN, e-DAI (Digital ecosystem for integrated anal-

ysis of heterogeneous health data related to high-

impact diseases: innovative model of care and re-

search), Health Operational Plan, FSC 2014-2020,

PRIN-MUR-Ministry of Health, the National Plan for

NRRP Complementary Investments D

∧

3 4 Health:

Digital Driven Diagnostics, prognostics and therapeu-

tics for sustainable Health care, Progetto MolisCTe,

Ministero delle Imprese e del Made in Italy, Italy,

CUP: D33B22000060001, FORESEEN: FORmal

mEthodS for attack dEtEction in autonomous driv-

iNg systems CUP N.P2022WYAEW and ALOHA: a

framework for monitoring the physical and psycho-

logical health status of the Worker through Object de-

tection and federated machine learning, Call for Col-

laborative Research BRiC -2024, INAIL.

REFERENCES

Alom, M. Z., Taha, T. M., Yakopcic, C., Westberg, S.,

Sidike, P., Nasrin, M. S., Van Esesn, B. C., Awwal,

A. A. S., and Asari, V. K. (2018). The history began

from alexnet: A comprehensive survey on deep learn-

ing approaches. arXiv preprint arXiv:1803.01164.

Broughton, M., Verdon, G., McCourt, T., Martinez, A. J.,

Yoo, J. H., Isakov, S. V., Massey, P., Halavati, R., Niu,

M. Y., Zlokapa, A., et al. (2020). Tensorﬂow quantum:

A software framework for quantum machine learning.

arXiv preprint arXiv:2003.02989.

Chen, Z.-G., Kang, H.-S., Yin, S.-N., and Kim, S.-R.

(2017). Automatic ransomware detection and analysis

based on dynamic api calls ﬂow graph. In Proceedings

of the International Conference on Research in Adap-

tive and Convergent Systems, pages 196–201.

Ciaramella, G., Iadarola, G., Mercaldo, F., Storto, M.,

Santone, A., and Martinelli, F. (2022). Introducing

quantum computing in mobile malware detection. In

Proceedings of the 17th International Conference on

Availability, Reliability and Security, pages 1–8.

Ciaramella, G., Martinelli, F., Mercaldo, F., and Santone,

A. (2023). Exploring quantum machine learning for

explainable malware detection. In 2023 International

Joint Conference on Neural Networks (IJCNN), pages

1–6. IEEE.

Ferrante, A., Malek, M., Martinelli, F., Mercaldo, F., and

Milosevic, J. (2017). Extinguishing ransomware-a hy-

brid approach to android ransomware detection. In In-

ternational Symposium on Foundations and Practice

of Security, pages 242–258. Springer.

Goldsborough, P. (2016). A tour of tensorﬂow. arXiv

preprint arXiv:1610.01178.

He, H., Yang, H., Mercaldo, F., Santone, A., and Huang,

P. (2024). Isolation forest-voting fusion-multioutput:

A stroke risk classiﬁcation method based on the mul-

tidimensional output of abnormal sample detection.

Computer Methods and Programs in Biomedicine,

253:108255.

Jeng, T.-H., Chang, Y.-C., Yang, H.-H., Chen, L.-K., and

Chen, Y.-M. (2022). A novel deep learning based at-

tention mechanism for android malware detection and

explanation. In Proceedings of the 10th International

Conference on Computer and Communications Man-

agement, pages 226–232.

Mercaldo, F., Ciaramella, G., Iadarola, G., Storto, M.,

Martinelli, F., and Santone, A. (2022). Towards ex-

plainable quantum machine learning for mobile mal-

ware detection and classiﬁcation. Applied Sciences,

12(23):12025.

Xing, X., Jin, X., Elahi, H., Jiang, H., and Wang, G. (2022).

A malware detection approach using autoencoder in

deep learning. IEEE Access, 10:25696–25706.

SECRYPT 2025 - 22nd International Conference on Security and Cryptography

308
