Conditions and Methods of Research of the Combined Frontal Plug

Active Work Body

Sherzodkhuja Mirzakhodjaev

, Uktamkhuja Boboev

, Jonibek Abdunabiev

Sardorbek Ismonaliyev

and Jurabek Toshtemirov

1 e

Tashkent State Agrarian University, 100140, University str. 2, Tashkent, Uzbekistan

FE LLC "UzAutoTRAILER", Samarkand, Uzbekistan

Keywords: Plow, Soil Properties, Energy Efficiency.

Abstract: Article data on the average moisture and hardness of the soil before the tests are carried out. The combined

plow with an active working organ developed in field tests 630Cwas added to the Claas ARION tractor, the

theoretical and working depth, working speed were determined and the principle of operation was presented.

The obtained results show that all the quality parameters of the plow with an active working organ, ie coverage

width, processing depth, completeness and depth of burial of plant residues, soil compaction quality and the

height of irregularities on the surface of the plow fully meet the agrotechnical requirements. given The

developed combined frontal plow with an active working body reliably performed the specified technological

process compared to the plow with a passive working body and O'P-4/5-40, and its results are presented.

Research of the results reliability of research modern style and measure from tools used without held,

combined frontal plug active the work bodies parameters theoretical in terms of in justification higher math,

theoretical of mechanics main the rule and methods action done, experiences to the results mathematician

statistics methods with processing given, theoretical and practical studies of the results mutually adequacy,

done studies based on work developed active the work body the field of tests positive results and to practice

current done with explained

1 INTRODUCTION

In the world, scientific and research work is being

carried out aimed at the development of new

scientific and technical bases of resource-saving

technologies of land plowing and the technical means

that implement them. In this direction, among other

things, one of the important tasks is to conduct

targeted scientific research on the development of a

combined plow that plows flat without forming egate

and the justification of the technological work

processes of its working parts, ensuring energy

efficiency during their interaction with the soil. is

considered In this regard, it is necessary to develop a

highly maneuverable, suspension-combined frontal

https://orcid.org/0000-0001-8593-1450

https://orcid.org/0009-0004-7995-6087

https://orcid.org/0000-0001-8593-1450

plug consisting of active and passive working parts

(Augambaev et al., 1993; Spirin & Lavrov, 2004;

Vedenyapin, 1973; Kobzar, 2006; Johnson & Lyon,

1990; Mirzakhodjaev et al., 2024a; Mirzakhodjaev et

al., 2024b; Mirzakhodjaev et al., 2024c; Khudayorov

et al., 2023a; Khudayorov et al., 2023b; Khudayorov

et al., 2023c; Mirzakhodjaev et al., 2021; Mamatov et

al., 2021; Mirzaev et al., 2019; Akhmetov et al., 2024;

Akhmetov et al., 2023; Zhanikulov et al., 2022;

Saidova et al., 2024; Akhmetov et al., 2021; Irgashev

et al., 2021; Obidov et al., 2021; Alimova et al., 2022;

Eshpulatov et al., 2021a; Eshpulatov et al., 2021b;

Ashirov et al., 2021; Farmonov et al., 2020; Isakova

et al., 2024; Astanakulov et al., 2023; Irisov et al.,

2023; Irisov et al., 2022; Irisov et al., 2021a; Irisov et

Mirzakhodjaev, S., Boboev, U., Abdunabiev, J., Ismonaliyev, S. and Toshtemirov, J.

Conditions and Methods of Research of the Combined Frontal Plug Active Work Body.

DOI: 10.5220/0014043100004738

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 4th International Conference on Research of Agricultural and Food Technologies (I-CRAFT 2024), pages 31-35

ISBN: 978-989-758-773-3; ISSN: 3051-7710

al., 2021b; Khaliknazarov et al., 2021; Bokiev et al.,

2021; Muhammadiev et al., 2020; Anarbaev et al.,

2020; Yunusov et al., 2020; Rakhmonov et al., 2020a;

Rakhmonov et al., 2020b; Turdiboyev et al., 2023;

Davirov et al., 2020; Djiyanov et al., 2024).

G.N.Sineokov abroad on the creation and use of

plugs with active and passive working bodies, the

study of their performance and the justification of

their parameters, as well as the study of the processes

of soil interaction with the active working body, V.I.

Medvedev, V.A. Sakun, Ya.P. Lobachevsky, A.P.

Akimov, A.I. Vedeneev, M.N. Chatkin, A.F. Juk,

V.V. Sharov, V.A.Tumasov, G.Kant, N.V.

Bugaychenko, Yu.A. Kuznesov, B.M. Shmelev, L.C.

Kaufman, V.K. Klbik, N.G. Kobiashvili, G.F. Popov

and others conducted scientific research.

R.I. Baymetov, A. Tokhtakoziev, F.M. Mamatov,

I.T. Ergashev, A.A. Akhmetov and others conducted

research in this direction in our republic.

Plugs created on the basis of the results of these

studies are being used in agricultural production with

certain positive results. However, in these studies, the

issues of justifying the parameters of the active

working body of the combined frontal plug, which

provide high work quality with low energy

consumption, have not been sufficiently studied.

2 MATERIALS AND METHODS

In order to verify the results of the theoretical studies

and to determine the parameters of the combined

frontal plug active working body that ensure the

required quality of work with low energy

consumption, the following were included in the

experimental research program:

• development and construction of a laboratory-

field device for conducting experimental

studies;

• to study the influence of the number, diameter,

kinematic mode of operation and processing

depth of the blades of the active working organ

on the quality indicators and traction resistance

of the plug;

• using the method of mathematical planning of

experiments, justifying the optimal values of

the parameters of the active working body of

the combined frontal plug;

• conducting comparative tests of a device with

a passive and active working body.

The following agrotechnical parameters of the

plow were determined in experimental studies:

coverage width, tillage (plowing) depth, level of soil

crushing.

To determine the actual coverage width of the

plow with an active working organ, the plowed field

was divided into 50 m long zones, and wooden stakes

were driven every 5 m along a straight line at a

distance of 10-15 m from the edge wall of the last pass

of the plow. Before and after the passage of the

driving unit, the distance from the opposite side of

each pile to the egate wall was measured with a tape

measure with an accuracy of 0.5 cm. The difference

in these dimensions gave the actual coverage width of

the plug with the active working organ.

The plowing depth was measured using a special

depth gauge. The number of measurements is at least

25 times.

The plane of the plow surface after the driving

unit passes yin was determined. On the surface of the

plow, perpendicular to the direction of movement of

the unit, a special rail with 5 cm sections was installed

on wooden pegs driven over the entire width of the

plug. The alignment of the rail was checked with a

level gauge. Then the distance from the lower edge of

the rail to the surface of the plow was measured.

Measurements were taken from 21 points at 5 cm

intervals and at 3 locations along the length of the

plow in one pass of the driving unit.

The plane of the bottom of the plow was

determined in the same way as above. Only in this

case, the plowed soil in the entire coverage width of

the plow with an active working organ was removed

and measurements were made.

3 RESULTS AND DISCUSSION

During experimental research, the device was used in

conjunction with the Claas ARION 630C tractor of

the 3rd class.

During the experiments, the transverse distance

between the working bodies was changed from 10 cm

to 25 cm with an interval of 5 cm. Each option was

conducted at aggregate speeds of 7 and 9 km/h. In

addition, when one parameter was changed, other

parameters remained constant, i.e. remained

unchanged.

A mathematical method of planning experiments

was used to optimize the parameters of active

working bodies. Experiments were conducted based

on a four-factor plan (Akhmetov et al., 2023, Akhmetov

et al., 2021).

According to the initial data obtained in the

experiments, mathematical statistical methods were

used to determine the arithmetic mean values and

I-CRAFT 2024 - 4th International Conference on Research of Agricultural and Food Technologies

mean square deviations of the indicators

(Vedenyapin, 1973; Kobzar, 2006; Johnson & Lyon,

1990).

The tests were carried out at speeds of 7.8 and 9

km/h. In this case, the depth of processing with active

working bodies was determined to be the same for all

options, i.e. 12-14 cm.

The experiments were carried out in the summer

months of June-July in the fields of the experimental

plot (Fig. 1).

Figure 1: Working process of combined frontal plug with

active working body.

Figure 2: Placement of measuring instruments in the tractor

cab.

A measuring cylinder was used for determination,

and the volume of fuel in it was recorded on a

continuous basis.

During the experiments, measuring instruments

were placed in the cab of the tractor (Fig. 2).

The lack of possibility to comprehensively take

into account in theoretical research the properties of

the soil of grain-growing zones, which affect the

process of flat plowing, requires extensive laboratory-

field experiments.

Table 1: Test conditions.

Indicators, their

measurement units

Values of indicators

Background (crop planted

efore the

low

)

A field empty of wheat

Soil t

eMedium

rain

Relief Flat

Microrelief Light wav

Soil moisture (%), in layers

0-10 cm 9.1

10-20 cm 10.8

20-30 cm 12.5

Average value 10.8

Soil hardness (MPa), in layers

0-10 cm 3.05

20-20 cm 4.05

20-30 cm 4.98

Avera

e value 4.02

The amount of plant

stems in 1 m

, kg

0.857

Average stem height, cm 9.27

The energy and quality indicators of plugs,

including the combined frontal plug, depend on its

design parameters (covering width of the body, mutual

arrangement of working bodies, size of overlapping

between plowshares, location of the active working

body and its parameters, etc.) depending on the laws

of change and technological and operational

parameters (driving depth, driving speed and

kinematic working mode of the active working body),

the mechanical composition of the soil, moisture,

density, microrelief and other properties.

Figure 3 shows the position of the tensioner

fingers mounted on the device's shaft and gimbal.

Figure 3: The position of the tension fingers on the device's

hinge and cardan.

Accordingly, research was conducted on typical

wheat-free fields and the following were considered:

Conditions and Methods of Research of the Combined Frontal Plug Active Work Body

• to determine the quality and energy indicators

of the flat working plug with active and passive

working body depending on its structural and

operational parameters;

• to determine the nature of changes in the

quality and energy indicators of the frontal

plow depending on the structural and

operational parameters of the active working

body that processes the surface layer of the soil;

• conducting comparative economic tests of a

combined plow with active and passive

working organs.

In the course of the research, the following

aggregate technical parameters of the working

process of the two-body device were determined:

coverage width, plowing depth, level of soil crushing,

depth and level of burial of plant residues.

4 CONCLUSIONS

Thus, in addition to performing the function of a

mover with the help of active working organs, it

ensures the improvement of the work quality and

energy indicators of the plug in soils with low

moisture and high density of the surface layer.

According to experimental studies, in order to

ensure the required soil compaction with minimal

energy consumption at 22-26 cm working depths of

the hulls, the active working body should be installed

at a distance of 40 mm forward from the nose of the

hull plow and 30 mm to the side of the hull. will be

compatible

REFERENCES

Akhmetov, A.A., Akhmedov, Sh.А., Allanazarov, M.A.,

Asamov, R.H., 2023, IOP Conference Seres: Earth and

Envronmental Scence, 1138(1), 012047 do:

10.1088/1755-1315/1138/1/012047

Akhmetov, A.A., Allanazarov, M.A., Muratov, L.B.,

Kambarova, D.U., 2021, IOP Conference Seres: Earth

and Envronmental Scence, 868(1), 012075

Akhmetov, A.A., Allanazarov, M.A., Rakhmboyeva, D.S.,

Rajabov, I.R., 2024, AIP Conference Proceedngs,

3045(1), 040008. https://do.org/10.1063/5.0198816

Almova, F.A., Prmkulov, B.Sh., Sadova, M.T., &

Bobonyozov, E.A., (2022). Combned aggregate for

strp tllage and smultaneous sowng of re-crops. IOP

Conference Seres: Earth and Envronmental Scence,

1112(1). https://do.org/10.1088/1755-

1315/1112/1/012021

Anarbaev, A., Zakhdov, R., Tursunov, O., Yusupov, Z.,

Kushev, A., 2020. IOP Conference Seres: Earth and

Envronmental Scence, 614(1), 012015. DOI

10.1088/1755-1315/614/1/012015

Ashrov, M., Omonov, D., Khallov, R., Rakhmov, U.,

2021. E3S Web of Conferences, 244, 02018

https://do.org/10.1051/e3sconf/202124402018

Astanakulov, K., Kurbonov, F., Isakova, F., 2023. E3S Web

of Conferences, 381, 01001

https://do.org/10.1051/e3sconf/202338101001

Augambaev M., Ivanov A.Z., Terekhov Yu.I., 1993.

Osnovy planrovanya nauchno-ssledovatelskogo

expermenta. - Tashkent: Teacher, - 336 p.

Bokev, A., Nuraleva, N., Sultonov, S., Botrov, A.,

Kholknazarov, U., 2021. E3S Web of Conferences,

264, 04022.

https://do.org/10.1051/e3sconf/202126404022

Davrov, A., Tursunov, O., Kodrov, D., ...Baratov, D.,

Tursunov, A., 2020. IOP Conference Seres: Earth and

Envronmental Scence, 614(1), 012039. DOI

10.1088/1755-1315/614/1/012039

Djyanov, M., Xallov, R., Isakova, F., 2024. BIO Web of

Conferences, 85, 01034.

https://do.org/10.1051/boconf/20248501034

Eshpulatov, N., Khalmuradov, T., Khallov, R., Nurmanov,

S., Omonov, D., 2021b. E3S Web of Conferences, 264,

04086.

Eshpulatov, N., Khalmuradov, T., Khallov, R., Obdov, A.,

Allanazarov, M., 2021a. E3S Web of Conferences, 264,

04072. https://do.org/10.1051/e3sconf/202126404072

Farmonov, E., Lakaev, S., Khallov, R., Gorlova, I., 2020.

IOP Conference Seres: Materals Scence and

Engneerng, 883(1), 012097.

Irgashev, A., Ishmuratov, Kh.K., Allanazarov, M.A.,

Ishmuratova, K.Kh., 2021. IOP Conference Seres:

Earth and Envronmental Scence, 868(1), 012068.

Irsov, K.D., Akhmedov, D.A., Alboyev, B.A., 2022. IOP

Conference Seres: Earth and Envronmental Scence,

1076(1), 012011. DOI: 10.1088/1755-

1315/1076/1/012011.

Irsov, K.D., Bekmurodov, I.R., 2023. IOP Conference

Seres: Earth and Envronmental Scence, 1284(1),

012041. DOI 10.1088/1755-1315/1284/1/012041

Irsov, Kh.D., Botrov, R.M., Khudoykulov, R.F., 2021a.

IOP Conference Seres: Earth and Envronmental

Scence, 868(1), 012001. DOI: 10.1088/1755-

1315/868/1/012001.

Irsov, Kh.D., Olmjonov, R.Z., 2021b. IOP Conference

Seres: Earth and Envronmental Scence, 868(1),

012034. DOI: 10.1088/1755-1315/868/1/012034.

Isakova, F., Tadjbekova, I., Kurbonov, F., 2024. BIO Web

of Conferences, 85, 01037.

https://do.org/10.1051/boconf/20248501037

Johnson N., Lyon F., 1990. Statstcs and plannng of

experments and technques n scence. Methody

obrabotk dannyx. Moscow: Mr, 610 p.

Khalknazarov, U., Akbarov, D., Tursunov, A., Gafforov, S.,

Abdunabev, D., 2021. IOP Conference Seres: Earth

and Envronmental Scence, 939(1), 012020. DOI:

10.1088/1755-1315/939/1/012020.

Khudayorov, Z., Khallov, R., Gorlova, I., Mrzakhodjaev,

S., Mambetsherpova, A., 2023c. E3S Web of

I-CRAFT 2024 - 4th International Conference on Research of Agricultural and Food Technologies

Conferences, 365, 04011

https://do.org/10.1051/e3sconf/202336504011

Khudayorov, Z., Khallov, R., Mrzakhodjaev, S.,

Nurmkhamedov, B., Mamasov, S. 2023b, E3S Web of

Conferences, 376, 02013.

https://do.org/10.1051/e3sconf/202337602013 .

Khudayorov, Z., Mrzakhodjaev, S., Khallov, R.,

Nurmkhamedov, B., Mamasov, S., 2023a. E3S Web of

Conferences., 390, 01033.

https://do.org/10.1051/e3sconf/202339001033

Kobzar A.I., 2006. Practcal mathematcal statstcs. For

engneers and scentfc workers. - Moscow: Fzmatlt,

816 p.

Mamatov, F., Mrzaev, B., Mrzahodzhaev, S., Uzakov, Z.,

Choryeva, D., 2021. IOP Conference Seres: Materals

Scence and Engneerng, 1030(1), 012164. DOI:

10.1088/1757-899x/1030/1/012164

Mrzaev, B., Mamatov, F., Ergashev, I., ...Kodrov, U.,

Ergashev, G., 2019. E3S Web of Conferences, 135,

01065. https://do.org/10.1051/e3sconf/201913501065

Mrzakhodjaev, S., Allanazarov, M., Ishmuratov, K., 2024a.

BIO Web of Conferences, 85, 01043

https://do.org/10.1051/boconf/20248501043

Mrzakhodjaev, S., Djyanov, M., Nurmkhamedov, B.,

Mamasov, S., 2024b. BIO Web of Conferences, 85,

01035. https://do.org/10.1051/boconf/20248501035

Mrzakhodjaev, S., Shodev, K., Uralov, G., Badalov, S.,

Choryeva, D., 2021. E3S Web of Conferences, 264,

04047. https://do.org/10.1051/e3sconf/202126404047

Mrzakhodjaev, S., Utaganov, K., Musurmonov, A., 2024c.

BIO Web of Conferences, 85, 01036.

https://do.org/10.1051/boconf/20248501036

Muhammadev, A., Yunusov, R., Bayzakov, T.,

Xalqnazarov, U., Sattarov, M., 2020. IOP Conference

Seres: Earth and Envronmental Scence, 614(1),

012013. DOI: 10.1088/1755-1315/614/1/012013.

Obdov, A., Nurev, K., Allanazarov, M., Kurbonov, E.,

Khudoyberdev, R., 2021. E3S Web of Conferences,

284, 02012.

https://do.org/10.1051/e3sconf/202128402012.

Rakhmonov, I., Berdshev, A., Khusanov, B.,

Khalknazarov, U., Utegenov, U., 2020a. IOP

Conference Seres: Materals Scence and Engneerng,

883(1), 012104. DOI: 10.1088/1757-

899X/883/1/012104.

Rakhmonov, I., Berdshev, A., Nyozov, N., Muratov, A.,

Khalknazarov, U., 2020b. IOP Conference Seres:

Materals Scence and Engneerng, 883(1), 012103.

DOI: 10.1088/1757-899X/883/1/012103

Sadova, M., Tursunbaev, S., Boltaeva, M., & Isakulova, N.,

2024. Comparson of pneumatc sowng machnes by

the number of seeds n the slots of the dscs and the

dstance between the slots. BIO Web of Conferences,

105. https://do.org/10.1051/boconf/202410501004

Sprn N.A., Lavrov V.V., 2004. Methods of plannng and

processng of results of engneerng experments. –

Yekaternburg: GOU VPO Uralsky gosudarstvennyy

teknchesky unverstet. UPI, 258.

Turdboyev, A., Aytbaev, N., Mamutov, M., ...Toshev, T.,

Kurbonov, N., 2023. IOP Conference Seres: Earth and

Envronmental Scence, 1142(1), 012027. DOI:

10.1088/1755-1315/1142/1/012027

Vedenyapn V.V., 1973. Obshchaya metodka

ekspermentalnogo ssledovanya  obrabotk opytnykh

dannyx. Moscow: Kolos, 184 p.

Yunusov, R.F., Bayzakov, T.M., Sattarov, N.E., Nazarov,

O.A., Dnqulov, D.U., 2020. IOP Conference Seres:

Earth and Envronmental Scence, 614(1), 012017.

DOI: 10.1088/1755-1315/614/1/012017

Zhankulov, S., Khalmuradov, T., Allanazarov, M., 2022.

IOP Conference Seres: Earth and Envronmental

Scence, 1112(1), 012015. DOI: 10.1088/1755-

1315/1112/1/012015.

Conditions and Methods of Research of the Combined Frontal Plug Active Work Body
