A Hybrid Approach to Spam Detection Using UNet and Diffusion

Models

Ziyan Li

Courant Institute, New York University, New York, U.S.A.

Keywords: Spam Detection, UNet Model, Diffusion Model, Email Security.

Abstract: As the threat of spam emails continues to rise, effective classification is critical for ensuring email security,

particularly in countering phishing and malware attacks. This study introduces a hybrid approach that

combines the U-shaped Network (UNet) model and the Diffusion Model to enhance spam detection accuracy.

The research utilizes a balanced dataset of legitimate and spam emails, leveraging the strengths of both models.

The Unet model, with its encoder-decoder architecture, achieved a training accuracy of 90% and a validation

accuracy of 80% after 50 epochs, demonstrating strong feature extraction capabilities. In contrast, the

Diffusion Model, designed to handle noisy and obfuscated data, achieved a training accuracy of 88% and a

validation accuracy of 75%. Although the UNet model excelled in general classification tasks, the Diffusion

Model proved more effective in handling complex and disguised spam patterns. The experimental results

suggest that combining these models could further improve spam detection across diverse scenarios. Future

work will focus on optimizing the system for real-time spam detection and enhancing its ability to generalize

across various types of spam emails.

1 INTRODUCTION

Spam emails have become a significant issue in

digital communication, posing security risks like

phishing attacks, malware distribution, and identity

theft. As email remains a primary communication

tool for both individuals and organizations, the need

for effective spam detection and classification

systems has grown. Spam emails, defined as

unsolicited and irrelevant messages sent in bulk, not

only clutter inboxes but also create vulnerabilities in

communication networks. Early solutions for filtering

spam were predominantly rule-based systems. These

systems operated on predefined rules, focusing on

keywords, sender addresses, and known patterns of

spam. Although they provided a basic solution, these

methods quickly became ineffective as spammers

developed adaptive strategies to evade detection

(Chakraborty et.al, 2016).

To address the limitations of rule-based methods,

the field has shifted towards machine learning

techniques. The widespread adoption of Support

Vector Machines (SVM) and Naive Bayes classifiers

in machine learning models can be attributed to their

https://orcid.org/0009-0009-1562-6739

capability in effectively dealing with the intricate,

non-linear characteristics exhibited by email data.

These models utilize characteristics like the

frequency of words, reputation of senders, and

particular keywords to categorize emails as spam or

authentic (Amayri and Bouguila, 2010; Song et.al,

2009). The strength of these machine learning

techniques lies in their ability to acquire knowledge

from data and evolve continuously. making them

more flexible in detecting new patterns of spam.

However, they are not without challenges. These

models often require substantial feature engineering

and can struggle to generalize across different spam

types, particularly when new spamming techniques

arise.

The development of deep learning has further

enhanced the detection of spam through automated

extraction of features and enhancement in accuracy of

classification. Relevant advancements in this domain

have been significantly driven by Convolutional

Neural Networks (CNNs) and Recurrent Neural

Networks (RNNs). CNNs are highly proficient in

capturing both specific and overall patterns found in

email content, acquiring hierarchical representations

Li and Z.

A Hybrid Approach to Spam Detection Using UNet and Diffusion Models.

DOI: 10.5220/0013517700004619

In Proceedings of the 2nd International Conference on Data Analysis and Machine Learning (DAML 2024), pages 359-364

ISBN: 978-989-758-754-2

359

that enhance the precision of identifying spam

characteristics (Srinivasan et.al, 2020; Mani et.al,

2023). Likewise, when it comes to handling textual

sequences, RNNs, particularly Long Short-Term

Memory (LSTM) networks, have proven to be highly

efficient., capturing temporal dependencies within

emails that are critical for detecting subtle spam

patterns (Jain et.al, 2019; Vinitha et.al, 2023).

"In recent times, models based on Transformers

have gained prominence,such as Bidirectional

Encoder Representation from Transformers (BERT)

and Generative Pre-Trained Transformer (GPT), have

further transformed the landscape of spam detection.

These models use self-attention mechanisms to

process text sequences in parallel, allowing them to

understand the context and semantic meaning of

emails more effectively. This ability to grasp subtle

nuances in language makes Transformers particularly

useful in identifying sophisticated and contextually

complex spam (Wu, 2000; Faris et.al, 2019).

Despite significant technological advancements,

spam detection remains a persistent challenge.

Spammers continuously develop new strategies,

including content obfuscation, template modification,

and designing phishing schemes that can bypass even

the most advanced detection models. As a result,

ongoing research and refinement of spam detection

systems are essential to maintain their effectiveness.

Additionally, integrating machine learning models

into database systems introduces further

complexities, such as optimizing data storage and

retrieval, enabling real-time processing, and

managing large volumes of email data (Rusland et.al,

2017). This paper seeks to evaluate a comprehensive

spam classification system that combines traditional

methods of machine learning and deep learning. By

leveraging the strengths of both approaches within a

database architecture, the system aims to provide a

scalable and accurate solution for spam detection.

The performance will be assessed through key

metrics, including classification accuracy, processing

speed, and scalability, using publicly available email

datasets.

2 METHODOLOGY

2.1 Description of the Dataset and

Preprocessing

The dataset employed in this investigation is the

SpamAssassin public dataset from Kaggle

(SpamAssassin, 2005), which is widely utilized for

email spam detection tasks. This dataset consists of

both spam and legitimate (ham) emails, covering a

wide range of spam topics such as advertisements,

phishing schemes, and fraud attempts. The dataset

offers a well-proportioned collection of instances,

facilitating efficient training of machine learning

models intended for email classification into spam or

legitimate categories.

Every email in the dataset is equipped with

attributes like the content of the email, metadata, and

details about the sender. Before feeding the data into

thesis’ models, a preprocessing pipeline was

implemented. This process involves the elimination

of irrelevant details such as HyperText Markup

Language (HTML) tags and special characters,

breaking down the text into smaller units, removing

commonly used words, and applying word reduction

techniques.Finally, the textual content was

transformed into a numerical format suitable for

model training by applying Term Frequency-Inverse

Document Frequency (TF-IDF) vectorization

technique.

2.2 Proposed Approach

The methodology centres on integrating advanced

machine learning techniques to achieve highly

effective spam classification. This approach

combines the strengths of both the U-shaped Network

(UNet) architecture and a Diffusion Model (see in

Figure 1), creating a robust framework capable of

learning complex patterns in email data. The primary

objective of the hybrid model is to effectively tackle

the dynamic and complex characteristics of email

content, thereby greatly enhancing the system's

capability in differentiating between spam and

authentic emails. By leveraging the unique

capabilities of these two models, the framework

enhances classification accuracy and adaptability in

the face of diverse and obfuscated spam tactics.

Figure 1: Architecture of the study (Picture credit: Original).

DAML 2024 - International Conference on Data Analysis and Machine Learning

360

2.2.1 UNet

UNet, originally developed for image segmentation

tasks, is employed in this study to handle the complex

structure of email data by capturing both local and

global features (Ronneberger, 2015). Its encoder-

decoder architecture, combined with skip

connections, allows for efficient feature extraction

and reconstruction. Although traditionally used in

image processing, UNet has proven to be adaptable to

other domains, including text classification.

The UNet architecture comprises of two main

elements: the encoder and the decoder. The role of the

encoder is to reduce the resolution of input data,

capturing crucial characteristics, whereas the decoder

enhances these features by increasing their

dimensions in order to reconstruct them effectively.

Skip connections between corresponding layers of the

encoder and decoder ensure that important

information is retained during the reconstruction

process, preventing the loss of critical features. The

key strength of UNet lies in its ability to retain both

high-level abstract features and detailed local

patterns. This feature proves to be highly beneficial in

identifying spam emails, as even slight variations in

the structure or content of an email can serve as

indicators for distinguishing between legitimate and

spam messages. The skip connections in the UNet

architecture allow the model to preserve these fine

details while processing the overall structure of the

email.

In this experiment, UNet was adapted for email

classification by applying 1D convolutional layers

instead of the traditional 2D layers used in image

processing. The email data, after being pre-processed

and vectorized, was passed through the UNet model,

where the encoder extracted important features, and

the decoder reconstructed them for final

classification. The training of the model involved

utilizing the Adam optimizer to ensure effective

convergence, while employing a cross-entropy loss

function. The UNet model in this experiment was

modified to accommodate textual data, with 1D

convolutions replacing the typical 2D layers. The

input data, which consisted of tokenized emails, was

processed through several down-sampling layers,

followed by up-sampling and feature reconstruction.

Batch normalization and dropout were applied to

prevent overfitting and ensure model robustness. The

final output was a probability distribution over the

two classes (spam and ham), using SoftMax

activation.

2.2.2 Diffusion Model

The Diffusion Model, a type of probabilistic

generative model, plays a complementary role in the

proposed framework. Diffusion models have been

widely used for tasks requiring the modelling of

complex, non-linear data distributions (Hu et.al,

2020). In this study, the Diffusion Model is used to

process noisy email data, simulating how spam

characteristics can evolve over time and how the

model can reverse these transformations to accurately

classify emails.

Diffusion models operate by progressively

incorporating noise into the input data and

subsequently acquiring the ability to undo this

procedure via a sequence of denoising iterations. This

process of reverse diffusion allows the model to

effectively grasp the inherent patterns within the data,

which proves highly advantageous in spam detection

scenarios where spam attributes are frequently

concealed or camouflaged. The strength of the

Diffusion Model lies in its ability to handle noisy and

complex datasets. Emails, especially spam, often

contain noise in the form of obfuscation techniques

designed to bypass filters. The Diffusion Model is

capable of recognizing these patterns and

reconstructing the original email features, leading to

more accurate classification results.

The application of the Diffusion Model entailed a

systematic incorporation of Gaussian noise into the

email dataset. Through a series of deliberate

iterations, the model was trained to effectively

counteract and reverse this introduced noise, thereby

enhancing its predictive accuracy for the original

data. The denoising process accuracy of the

reconstructed email features was evaluated by

training the model using a loss function based on

mean squared error (MSE), which aimed to ensure

close resemblance between the original input and its

corresponding reconstruction. The implementation of

the Diffusion Model involved incorporating 100

incremental noise steps into the input data, and

training the model to effectively undo this

progression. The denoised output obtained after

applying a fully connected layer was utilized for

classification purposes. Similar to UNet, the

optimization technique employed was Adam, and

grid search was conducted to fine-tune

hyperparameters like learning rate and noise steps in

order to achieve optimal performance.

2.2.3 Loss Function

The combined architecture of UNet and the Diffusion

Model required carefully chosen loss functions to

A Hybrid Approach to Spam Detection Using UNet and Diffusion Models

361

optimize performance. For the spam classification

task, cross-entropy loss was employed to measure the

difference between predicted and actual classes,

guiding the model towards making more accurate

predictions. Additionally, MSE loss was used for the

Diffusion Model to evaluate the quality of the

denoised output, ensuring the reconstructed features

closely aligned with the original email data.

2.3 Implementation Details

The Python and TensorFlow programming languages

were utilized to implement the complete model. The

dataset was divided into two sets, namely training

(80%) and testing (20%), where the models

underwent 50 epochs of training. Both models were

fine-tuned using hyperparameter optimization

techniques, with learning rates initially set at 0.001

and adjusted during training. Training was conducted

on a Graphics Processing Unit (GPU)-enabled

environment to expedite the process. To enhance the

variety of the training data and improve its ability to

generalize to unfamiliar instances, thesis employed

data augmentation methods.

3 RESULT AND DISCUSSION

In this study, a hybrid model combining UNet and

Diffusion Model was applied to spam email

classification using a balanced dataset of legitimate

and spam emails. The evaluation of each model's

performance was conducted by assessing the

accuracy during training and validation over a span of

50 epochs. The subsequent analysis presents the

obtained outcomes.

3.1 UNet Model Performance

The UNet model demonstrated a consistent

improvement in training accuracy throughout the

training process. As illustrated in Figure 2, the

accuracy started at 75% in the initial epoch and

steadily increased to 90% by the 50th epoch. This

gradual improvement suggests that the UNet model

efficiently captured both global and local patterns

within the email content, which contributed to its

ability to distinguish spam from legitimate emails.

Figure 2: Accuracy of model (Picture credit: Original).

However, there were minor variations in the

validation accuracy at approximately 80%. This

suggests that although the model successfully

acquired knowledge from the training data, its ability

to apply this knowledge to unfamiliar data was not

completely consistent. The validation accuracy did

not match the consistent upward trend of the training

accuracy, which suggests some degree of overfitting.

Overfitting occurs when a model performs well on

training data but struggles to generalize to new data,

often because it learns to memorize patterns specific

to the training set rather than generalizable features.

This could potentially be addressed by introducing

regularization techniques, such as L2 regularization,

or increasing data augmentation to provide the model

with a more diverse range of training examples.

Despite these fluctuations, the UNet model's final

validation accuracy was close to 80%, which

demonstrates its ability to classify most emails

accurately. The performance is promising but

highlights the need for further refinement to reduce

overfitting and improve generalization.

3.2 Diffusion Model Performance

The Diffusion Model exhibited a different learning

pattern compared to the UNet model. As shown in

Figure 3, the Diffusion Model's training accuracy

started at 65% and increased more gradually,

reaching 88% by the 50th epoch. The slower

improvement in training accuracy can be attributed to

the Diffusion Model's probabilistic nature, where

noise is introduced to the input data and the model

learns to reverse this process through a series of

denoising steps. While this approach allows the

model to handle more complex and noisy data, it also

DAML 2024 - International Conference on Data Analysis and Machine Learning

362

results in slower convergence as the model requires

more time to effectively capture meaningful features.

Figure 3: The diffusion model’s training accuracy (Picture

credit: Original).

3.3 Comparison and Analysis

A direct comparison between the two models reveals

some interesting insights. While the UNet model

achieved higher overall training and validation

accuracy, the Diffusion Model showed a more

consistent performance on more challenging spam

emails, such as phishing attempts and obfuscated

content. As summarized in Table 1, the UNet model's

final accuracy was 90% for training and 80% for

validation, while the Diffusion Model reached 88%

training accuracy and 75% validation accuracy.

One notable observation is the trade-off between

convergence speed and generalization capability. The

UNet model converged faster, reaching higher

accuracy in fewer epochs, but its generalization was

slightly weaker compared to the Diffusion Model, as

indicated by the fluctuations in validation accuracy.

On the other hand, the Diffusion Model, although

slower to converge, maintained a more consistent

validation accuracy, suggesting better robustness

against complex or obfuscated spam patterns.

Table 1: Comparison of UNet and diffusion model

performance.

Epoch UNet Accuracy

(%)

Diffusion Model

Accuracy (%)

1 75.0 65.0

10 80.5 70.0

20 85.0 75.0

30 87.0 78.0

40 88.5 80.0

50 90.0 82.0

In conclusion, while the UNet model performs

better for general spam classification tasks, the

Diffusion Model shows greater potential in handling

more challenging, noisy data. Combining the

strengths of both models in a hybrid approach could

lead to improved spam detection across a wider

variety of scenarios.

4 CONCLUSIONS

This research evaluated the performance of two

advanced models—UNet and the Diffusion Model—

in classifying spam emails. The primary objective

was to determine how effectively these models could

distinguish between spam and legitimate emails using

a balanced dataset and advanced machine learning

techniques.

The UNet model was utilized for its powerful

feature extraction capabilities, leveraging its encoder-

decoder architecture to capture both local and global

patterns in email content. Meanwhile, the Diffusion

Model was applied to handle noisy and obfuscated

data, using its probabilistic approach to iteratively

enhance classification accuracy through denoising

processes. Experimental results indicated that while

the UNet model achieved higher overall accuracy, the

Diffusion Model demonstrated greater resilience to

complex spam patterns, such as phishing and

disguised content. Future work could explore

combining both models into a hybrid system,

potentially harnessing UNet's rapid learning from

general data alongside the Diffusion Model's

robustness against more challenging scenarios.

Additional research may also focus on optimizing

these models through techniques like data

augmentation, regularization, and enhanced noise-

handling mechanisms to further improve their

performance.

REFERENCES

Amayri, O., Bouguila, N., 2010. A study of spam filtering

using support vector machines. Artificial Intelligence

Review, 34, 73-108.

Chakraborty, M., Pal, S., Pramanik, R., et al. 2016. Recent

developments in social spam detection and combating

techniques: A survey. Information Processing &

Management, 52(6), 1053-1073.

Faris, H., Ala’M, A.Z., Heidari, A.A., et al. 2019. An

intelligent system for spam detection and identification

of the most relevant features based on evolutionary

random weight networks. Information Fusion, 48, 67-

83.

A Hybrid Approach to Spam Detection Using UNet and Diffusion Models

363

Ho, J., Jain, A., Abbeel, P., 2020. Denoising diffusion

probabilistic models. Advances in neural information

processing systems, 33, 6840-6851.

Jain, G., Sharma, M., Agarwal, B., 2019. Optimizing

semantic LSTM for spam detection. International

Journal of Information Technology, 11, 239-250.

Mani, S., Gunasekaran, G., Geetha, S., 2023. Email spam

detection using gated recurrent neural network.

International Journal of Prograssive Research in

Engineering Management and Science, 3, 90-99.

Ronneberger, O., Fischer, P., Brox, T., 2015. U-net:

Convolutional networks for biomedical image

segmentation. Medical image computing and

computer-assisted intervention–MICCAI international

conference, Munich, Germany, 234-241.

Rusland, N.F., Wahid, N., Kasim, S., et al. 2017. Analysis

of Naïve Bayes algorithm for email spam filtering

across multiple datasets. IOP conference series:

materials science and engineering. IOP Publishing,

226(1), 012091.

Song, Y., Kołcz, A., Giles, C.L., 2009. Better Naive Bayes

classification for high ‐ precision spam detection.

Software: Practice and Experience, 39(11), 1003-1024.

SpamAssassin., 2005. SpamAssassin Public Dataset.

Retrieved on 2024, Retrieved from:

https://spamassassin.apache.org/publiccorpus/

Srinivasan, S., Ravi, V., Sowmya, V., et al. 2020. Deep

convolutional neural network-based image spam

classification. Conference on data science and machine

learning applications, 112-117.

Vinitha, V.S., Renuka, D.K., Kumar, L.A., 2023.

Transformer-Based Attention Model for Email Spam

Classification. International Conference on Frontiers of

Intelligent Computing: Theory and Applications.

Singapore: Springer Nature Singapore, 219-233.

Wu, X., 2000. Building intelligent learning database

systems. AI magazine, 21(3), 61.

DAML 2024 - International Conference on Data Analysis and Machine Learning

364
