The Advancements of Machine Learning Applications in Cancer

Research and Treatment

Xinze Li

Hefei NO.8 High School, Hefei, China

Keywords: Cancer, Machine Learning, Neural Networks, Machine Deep Learning.

Abstract: The cancer, also known as the malignant tumor, is a disease caused by the abnormal cell proliferation. It

ranked sixth in the top 10 causes of death published by the World Trade Organization in 2019, and seriously

threatens human life and health. The mortality rate is 93% and 19.3 million people developed cancer in 2022

alone. This paper discusses some well-established machine learning-based cancer treatment research methods,

including the application of simple models like random forests and some complex models such as neural

networks in breast cancer, lung cancer and thyroid cancer. In addition, most of the models in this article are

deep learning models because their application scope and value are generally higher than traditional models.

For each cancer mentioned, two or three models are presented, along with their basic information and their

results. This review can provide some references for the application of machine learning in cancer treatment

research.

1 INTRODUCTION

Cancer, also called as malignant tumor, is a disease

caused by abnormal cell proliferation, ranked sixth in

the top 10 causes of death published by the WTO in

2019, and seriously threatens human life and health.

According to IARC data (WHO, 2024), in 2022

alone, 19.3 million people developed cancer, and the

mortality rate is as high as 93%. Although the

traditional diagnostic methods, such as imaging

examination and pathological section analysis are

effective, they rely on the doctor's personal

experience and subjective judgment, and they have

problems of high misdiagnosis rate, low efficiency

and high cost. Therefore, it is necessary to introduce

some new advanced technologies as auxiliary.

Artificial intelligence technology has strong learning,

accurate feature extraction ability and feature

prediction ability, which can provide doctors with

objective and comprehensive diagnostic basis,

effectively assist doctors to judge patients' conditions,

so as to improve efficiency and reduce costs in cancer

research.

In the current cancer-related machine learning

(ML), ensemble learning and transfer learning, as the

two main core strategies, have significant advantages

in improving prediction accuracy and accelerating

https://orcid.org/0009-0000-6880-3211

research process. Ensemble learning, with its strong

generalization ability, has become the key to

improving the accuracy of cancer prediction by using

integrated algorithms such as random forest and

gradient elevator. With the flexibility of cross-domain

application, transfer learning can transfer models

trained on common cancer types to rare cancer types,

reduce the dependence on large amounts of labeled

data, significantly shorten the development cycle of

new models, and open up a new path for the study of

rare cancer types.

For example, Downs et al. used a fuzzy ARTMAP

neural network model to extract the features of breast

cancer to support network prediction and validation

(Downs, 1996). GVani et al. used an Extreme

Learning Machine (ELM) to distinguish between

benign and malignant breast tumors, which is

significantly more efficient than other algorithms

(Vani, 2011). HRH et al. used Monte Carlo methods

to build an auxiliary diagnostic system for lung

cancer with a diagnostic accuracy of 99.15% for

benign and 98.70% for malignant tumors (Al-Absi,

2014). Olatunji et al. used different methods,

including random forest and neural network, to

predict thyroid cancer on the data set of Saudi Arabia,

and the accuracy of the random forest model even

reached 90.91% (Olatunji, 2021). Li et al. (Li, 2023)

Li and X.

The Advancements of Machine Learning Applications in Cancer Research and Treatment.

DOI: 10.5220/0013509400004619

In Proceedings of the 2nd International Conference on Data Analysis and Machine Learning (DAML 2024), pages 101-105

ISBN: 978-989-758-754-2

101

used least absolute shrinkage and selection operator

(LASSO) and Support Vector Machine-Recursive

Feature Elimination (SVM-RFE), two machine

learning algorithms, to identify ATC feature genes

and build a prediction model for anaplastic thyroid

cancer.

Due to the importance of this field and the fact

that AI has proven its superiority for many tasks, it is

necessary to give a comprehensive overview of this

aspect. The rest of this article is arranged as follows:

Part 2 will explain ML and present existing methods

on several common cancers. These sections will be

further discussed in part 3 and summarized in Part 4.

2 METHOD

There are many types of cancer, and each cancer has

its own detection and treatment methods. In order to

show the research of machine learning in the field of

cancer more succinctly and intuitively, the paper

selected three cancers with high incidence and strong

representation as the review object.

2.1 Introduction of the Machine

Learning

There are two types of ML, “supervised learning” and

“unsupervised learning”. The “supervised learning”

is to Provide training data consisting of input-output

pairs and learn mapping; and the “unsupervised

learning” is to find patterns in the data without the

help of labels (outputs) (Mitchell, 2003). In order for

the machine to accurately identify the desired cancer,

the model is usually trained through a few steps

shown in Figure 1:

At present, the more common supervised learning

models include random forest, decision tree, etc.,

which are generally suitable for common cancers with

many cases. The common unsupervised models are

neural networks, clustering algorithms, etc., which

are suitable for very rare cancers. Before a model can

be confirmed as viable, it needs to be trained on data

to ensure that its accuracy is up to the required

standard. Not only the supervised learning but also

unsupervised learning needs to be trained in these

steps.

2.2 Cancer-Based Prediction

2.2.1 Breast Cancer

HOF-ATR-MIR Spectroscopy with Deep

Learning in Breast Cancer

Shang et al. (Shang, 2024) recently proposed a three-

way classification model based on HOF-ATR-MIR

spectroscopy to predict different breast tissues, which

is significantly more accurate for breast cancer

diagnosis than other common models. They added

their self-developed hollow on top of baseline

correction (BC) and data-enhanced the one-

dimensional convolutional neural network (1D-CNN)

model optical fiber attenuated total reflection (HOF-

ATR). To obtain a more correct model, they coupled

the model with Fourier transform infrared

spectroscopy (FTIR), and its accuracy rate is as high

as 95.09%.

Deep Neural Network

Vaka et al (Vaka, 2020) comparing various methods

in the past, and found that most of them have certain

limitations. Therefore, they introduced Deep Neural

Network with Support Value (DNNS) to repair the

previous images to obtain more accurate images, thus

improving the accuracy of breast cancer diagnosis,

and its performance, efficiency and image quality

have been greatly improved compared with the

previous models.

2.2.2 Lung Cancer

Cancer death in men is dominated by lung cancer,

which is second only to breast cancer in women.

Numerous efforts have been made to develop a

realistic and accurate prediction model due to its

extremely high mortality rate.

Predictive Model of Radiation Pneumonia

Choi SH et al. (Choi, 2024) successfully developed a

predictive model of radiation pneumonia after

studying samples from 59 volunteers who had

received

radiation therapy for primary lung cancer.

Figure 1. The workflow of the machine learning (Photo/Picture credit: Original).

DAML 2024 - International Conference on Data Analysis and Machine Learning

102

They used three models, including logistic regression,

to predict different genomes, and three models,

including random forests, to evaluate the performance

of each functional set. Finally, the importance of

single nucleotide polymorphisms (SNPs) for the

prediction of radiation pneumonia was confirmed and

the feasibility of its model was confirmed.

Shepard Convolutional Neural Network

A new model for accurate segmentation and

classification of lung cancer using CT images was

proposed by Shetty et al. (Shetty, 2022) after

synthesizing a variety of models. The method is

divided into several steps. Median filtering and

Bayesian fuzzy clustering were used to segment the

lung lobes. Then the lung cancer was segmented

using a deformation model based on Water Cycle Sea

Lion Optimization (WSLnO). They used data

enhancement methods to improve the classification

accuracy, that is, increasing the size of the

segmentation area. Finally, using WSLnO algorithm

to train the Shepard Convolutional neural network

(ShCNN) to effectively classify lung cancer. The

proposed algorithm combines the water cycle

algorithm (WCA) and the Sea lion optimization

algorithm (SLnO), which improves the accuracy,

sensitivity, specificity and average segmentation

accuracy compared with the previous models.

Computer-aided Classification via Deep

Learning Technique

Hua et al. (Hua, 2015) proposed to simplify the

traditional CAD image analysis process by using deep

learning technology to distinguish pulmonary

nodules on CT images. Two deep learning models,

Deep belief Network (DBN) and CNN, were

introduced by the authors because lung nodes are an

important factor in lung cancer diagnosis. They

compared them to two baseline methods that involve

feature computation steps. LIDC datasets were

utilized to classify the malignancy of pulmonary

nodules, preventing the necessity of calculating

morphological and textural features. According to the

result, the proposed deep learning framework is

obviously outperforming conventional hand-crafted

feature computing CAD frameworks.

2.2.3 Thyroid Cancer

Worldwide, thyroid cancer is becoming more

common as it is one of the most common malignant

tumors of the head and neck. Its trigger factors are

very common, so it also troubles many high-risk

people.

Deep Artificial Neural Network Model for

Prediction

Barfejani et al. (Barfejani, 2024) intends to create a

deep neural network that can predict mortality in

patients with differentiated thyroid cancer.They used

data from the SEER database to develop the Thy-

DAMP (Deep Artificial Neural Network Model for

Prediction) to predict mortality in DTC patients.

Demographic, histological, and staging information

is included in this dataset. After standardization and

feature coding, they segment the data into three

subsets, including training, testing, and validation

subsets, and adjust the model hyperparameters by

cross-validation. The predictive potential of Thy-

DAMP for differentiated thyroid cancer was

demonstrated after testing on a separate dataset.

Deep Learning Techniques

Shah et al. (Shah, 2024) used deep learning

technologies such as Long Short-Term Memory

(LSTM), Gated Recurrent Units (GRUs), and Bi-

directional LSTM (Bi-LSTM) to make timely

prediction of thyroid cancer. Shah et al. (Shah, 2024)

used deep learning technologies such as Long Short-

Term Memory (LSTM), Gated Recurrent Units

(GRUs), and Bi-directional LSTM (Bi-LSTM) to

make timely prediction of thyroid cancer. The model

was trained on datasets from asia.ensembl.org and

IntOGen.org, information was extracted using a

variety of matrix-based methods, including the Hahn

moment, and the model was tested using three

methods, one of them being SCT. In tests with

independent data sets, the model achieved 96 percent

accuracy.

3 DISCUSSION

3.1 Contrast Between Traditional ML and

Deep Neural Networks

ML models are often used to automate the

construction of analytical models, extracting patterns

from past learning and databases to help people make

reliable and repeatable decisions. This is why these

conventional models need to invest a lot of data in

training and constantly modify the model to have a

certain accuracy. ML has proved to be useful in tasks

that require high-dimensional data, such as

classification, regression, and clustering (Janiesch,

2021; Shinde, 2018). However, the large number of

data sources makes it difficult for conventional

models to predict some rare symptoms. Neural

The Advancements of Machine Learning Applications in Cancer Research and Treatment

103

networks, especially deep ones, make up for this

shortcoming on the basis of traditional ML. Some

conventional ML can also be classified as shallow

neural networks. Deep neural networks are able to

automatically discover a representation needed for

the corresponding learning task because they are

organized in deeply nested network architectures.

This is why deep neural networks outperform shallow

ML algorithms in most situations, such as processing

text, images, video, speech, and audio data (LeCun,

2015). However, shallow ML can still yield better

results with low data input or limited data samples

(Zhang, 2018).

3.2 Limitations and Challenges

Although machine learning and its various models

have shown great promise in cancer prediction and

research, and have many mature applications, it still

has many problems. Because neural network

simulates the working mode of human brain, its

operation process is in a "black box" state (Shinde,

2018; Shehab, 2022), so doctors cannot know what

kind of reasons the model gives diagnosis based on.

In this case, it is difficult to assign responsibility if a

model diagnosis error leads to a bad result.

Similarly, due to the difference in the training set

data, the model will also have applicability problems.

There are always subtle differences between different

cancers in different regions and different people.

Forcing a model that works for one population to

another does not guarantee the original accuracy; The

development of multiple models corresponds to a

huge cost of money and time. All these reasons

increase the difficulty of developing and applying

predictive models

Access to data sources may also be denied for a

number of reasons, making it impossible to develop

the most suitable model. Because the leakage of these

patient data can lead to serious consequences, such as

being used by terrorists to develop targeted viruses,

or reverse the rollout of other patient data, researchers

need to ensure the security of their data sources and

fully consider the privacy of patients.

3.3 Future Prospects

Although the algorithms mentioned above all have

some problems such as "black box", there are still

some methods that can be used to try to solve the

problem. Among them, expert system is a very

potential scheme. By adding an expert system to the

model, the expert system can sort out the information

in the model and put forward explanations like real

people, which can alleviate the problem of "black

box" to a certain extent (Liao, 2005). SHAP

Explanations are another potential solution. SHAP

Explanations are a feature-attribution mechanism that

uses game theory concepts to discuss individual

features in a model to explain the model as a whole

(Broeck, 2022). However, because this concept has

not been put forward for too long, the academic

community cannot confirm its accuracy and

reliability for the time being.

For the adaptability of the model, it is possible to

consider trying to solve the problem through transfer

learning and domain adaptation security. Transfer

learning is especially suitable for situations where

data sets are limited or difficult to obtain. It can

reduce model training costs by extracting similar

features between data sets and optimizing

information from the source data set to the new data

set (Weiss, 2016). Domain adaptation security is to

obtain a new database by labeling different data,

matching and comparing the labels one by one. The

database contains both old and new data and is able

to extract similarities between different libraries

(Singhal, 2023).

4 CONCLUSIONS

This paper discusses some well-established machine

learning-based cancer treatment research methods,

including the application of simple models such as

random forests and complex models such as neural

networks in breast, lung, and thyroid cancers. For

each cancer mentioned, two or three models are

given, along with their basic information and results.

This review can provide some references for the

application of machine learning in cancer treatment

research.

But there are still some shortcomings in this

paper. Although some traditional machine learning

algorithms such as random forest are mentioned in

this article, most of the content is introduced to

models based on neural networks. Of course, this is

not that traditional machine learning algorithms are

not good enough, but that neural networks are more

widely used. In the follow-up research, the further

study can still try the traditional algorithm, or

combine the traditional algorithm with the new

algorithm to achieve better results.

REFERENCES

Al-Absi, H. R. H., Belhaouari Samir, B., & Sulaiman, S.

2014. A computer aided diagnosis system for lung

cancer based on statistical and machine learning

techniques. International Symposium on VLSI Design.

IEEE.

DAML 2024 - International Conference on Data Analysis and Machine Learning

104

Barfejani, A. H., Rahimi, M., Safdari, H., Gholizadeh, S.,

Borzooei, S., Roshanaei, G., ... & Tarokhian, A. 2024.

Thy-DAMP: Deep artificial neural network model for

prediction of thyroid cancer mortality. European

Archives of Oto-Rhino-Laryngology, 1-7.

Choi, S. H., Kim, E., Heo, S. J., Seol, M. Y., Chung, Y., &

Yoon, H. I. 2024. Integrative prediction model for

radiation pneumonitis incorporating genetic and

clinical-pathological factors using machine learning.

Clinical and Translational Radiation Oncology, 48,

100819.

Downs, J., Harrison, R. F., Kennedy, R. L., & Cross, S. S.

1996. Application of the fuzzy artmap neural network

model to medical pattern classification tasks. Artificial

Intelligence in Medicine, 8(4), 403.

Hua, K. L., Hsu, C. H., Hidayati, S. C., Cheng, W. H., &

Chen, Y. J. 2015. Computer-aided classification of lung

nodules on computed tomography images via deep

learning technique. OncoTargets and therapy, 2015-

2022.

Janiesch, C., Zschech, P., & Heinrich, K. 2021. Machine

learning and deep learning. Electronic Markets, 31(3),

685-695.

LeCun, Y., Bengio, Y., & Hinton, G. 2015. Deep learning.

Nature, 521(7553), 436-444.

Li, C., Dong, X., Yuan, Q., Xu, G., Di, Z., & Yang, Y., et

al. 2023. Identification of novel characteristic

biomarkers and immune infiltration profile for the

anaplastic thyroid cancer via machine learning

algorithms. Journal of endocrinological investigation.

Liao, S. H. 2005. Expert system methodologies and

applications—a decade review from 1995 to 2004.

Expert Systems with Applications, 28(1), 93-103.

Mitchell, T. M. 2003. Machine Learning. McGraw-Hill.

Olatunji, S. O., Alotaibi, S., Almutairi, E., Alrabae, Z., &

Alhiyafi, J. 2021. Early diagnosis of thyroid cancer

diseases using computational intelligence techniques: a

case study of a Saudi Arabian dataset. Computers in

Biology and Medicine, 131(4), 104267.

Shang, H., Wu, Q., Wu, J., Zhou, S., Wang, Z., Wang, H.,

& Yin, J. 2024. Study on breast cancerization and

isolated diagnosis in situ by HOF-ATR-MIR

spectroscopy with deep learning. Spectrochimica Acta

Part A: Molecular and Biomolecular Spectroscopy,

124546.

Shah, A. A., Daud, A., Bukhari, A., Alshemaimri, B.,

Ahsan, M., & Younis, R. 2024. DEL-Thyroid: Deep

ensemble learning framework for detection of thyroid

cancer progression through genomic mutation. BMC

Medical Informatics and Decision Making, 24(1), 198.

Shetty, M. V., & Tunga, S. 2022. Optimized deformable

model-based segmentation and deep learning for lung

cancer classification. The Journal of Medical

Investigation, 69(3.4), 244-255.

Shehab, M., Abualigah, L., Shambour, Q., Abu-Hashem,

M. A., Shambour, M. K. Y., Alsalibi, A. I., & Gandomi,

A. H. 2022. Machine learning in medical applications:

A review of state-of-the-art methods. Computers in

Biology and Medicine, 145, 105458.

Shinde, P. P., & Shah, S. 2018. A review of machine

learning and deep learning applications. In 2018 Fourth

international conference on computing communication

control and automation (ICCUBEA), 1-6. IEEE.

Singhal, P., Walambe, R., Ramanna, S., & Kotecha, K.

2023. Domain adaptation: Challenges, methods,

datasets, and applications. IEEE Access, 11, 6973-

7020.

Van den Broeck, G., Lykov, A., Schleich, M., & Suciu, D.

2022. On the tractability of SHAP explanations. Journal

of Artificial Intelligence Research, 74, 851-886.

Vani, G., Savitha, R., & Sundararajan, N. 2011.

Classification of abnormalities in digitized

mammograms using Extreme Learning Machine.

International Conference on Control Automation

Robotics & Vision. IEEE.

Vaka, A. R., Soni, B., & Reddy, S. 2020. Breast cancer

detection by leveraging Machine Learning. ICT

Express, 6(4), 320-324.

Weiss, K., Khoshgoftaar, T. M., & Wang, D. 2016. A

survey of transfer learning. Journal of Big Data, 3, 1-

40.

WHO, IARC. 2024. Retrieved from

https://www.iarc.who.int/

Zhang, Y., & Ling, C. 2018. A strategy to apply machine

learning to small datasets in materials science. NPJ

Computational Materials, 4(1), 25.

The Advancements of Machine Learning Applications in Cancer Research and Treatment

105
