The Prediction and Feature Importance Investigation in Titanic

Survival Prediction

Chutong Huang

Beijing Luhe High School International Academy, Beijing, China

Keywords: Artificial Intelligence, Random Forest, Feature Importance.

Abstract: Predicting the survival of Titanic passengers is one of the topics scientists are focusing on. This paper explores

the use of the Random Forest (RF) algorithm on a Titanic dataset and analyses the key features that influence

the predictions. The RF algorithm is applied to a processed dataset. Feature importance scores are returned

for each feature to demonstrate how much it is related to the survival prediction, and the scores are then

analyzed in their historical context. Age, fare and sex were found to be the three most significant features in

predicting survival. Age is significant as its correlation to survivability, the children are determined to live

while the elderly are unable to survive. Fare is a crucial attribute since it is correlated with passenger class,

meaning that those paying more are given better information and location to survive. Sex is important because

women and children are given priority to survival, while men don’t have that chance. The application of

Random Forests shows how well Artificial Intelligence (AI) algorithms can predict problems and spot

significant patterns in complex data sets. And the analysis could have useful implications for improving

predictive models in other areas where attributes are crucial.

1 INTRODUCTION

On April 15, 1912, the RMS Titanic sideswiped an

iceberg on its first voyage, causing over 1,500 of the

2,240 passengers and staff members on board to

perish in the disaster. This notorious disaster soon

became a warning and appears in many films, articles,

and novels, warning people the danger of nature

(Titanic History, 2024). Enhancing passenger

survival in such disasters is an issue that needs to be

taken seriously, and Artificial Intelligence, as an

emerging technology with strong feature extraction

and prediction capabilities, can be considered in

conjunction with this task.

AI has evolved rapidly, with significant progress

in machine learning, deep learning, and data

analytics. It utilizes sophisticated algorithms like

logistic regression, random forests, and neural

networks to analyze complex data patterns, which is

beneficial in forecasting outcomes and improving

choices. These advancements have enabled more

accurate predictions and enhanced decision-making

across various fields, such as medical science. Choi et

al. constructed a Recurrent Neural Network (RNN)-

https://orcid.org/0009-0003-2175-9681

based model that predicts future events of patients

(Choi, 2016). Wang et al. utilize a RNN model for the

prediction of the future statues of Alzheimer's

Disease for patients (Wang, 2018). Among the many

prediction tasks, one important direction is the

prediction of classification problems like survival of

a person. Hsieh et al. illustrated a model of Fuzzy

Hyper-Rectangular Composite Neural Network that

predicts the survival through the first 24 hours

physical data of patients (Hsieh, 2014). Pradeep et al.

applied machine learning algorithms include Naive

Bayes, classification trees, and Support Vector

Machine (SVM) to the information of lung cancer

patients and predict their survivability rate (Pradeep,

2018). Kakde et al. determined the impact of each

feature to the survival rate and compared algorithms

between SVM, decision tree, random forest, and

logistic regression (LR). They found that SVM as

well as logistic regression perform nearly the best,

and there was high influence of age on survival while

other features like passenger class, age, fare and

"sibsp"(siblings and spouses) all have influences as

well (Kakde, 2018). Nair et al. analyzed the

correlation between factors of passenger samples and

Huang and C.

The Prediction and Feature Importance Investigation in Titanic Survival Prediction.

DOI: 10.5220/0013487400004619

In Proceedings of the 2nd International Conference on Data Analysis and Machine Learning (DAML 2024), pages 60-63

ISBN: 978-989-758-754-2

the survivability of the passengers. They suggested

that LR perform the best with the lowest false

discovery rate and the highest accuracy. In their

model of logistic regression, it tells them that the top5

correlated features are "Pclass"(Passenger class),

sibsp, age, children, and sex (Singh, 2017). The

effectiveness of AI methods has been demonstrated

on many domain tasks, so this paper intends to

consider the use of AI algorithms in predicting

survival of people in Titanic disaster, but unlike

previous studies on the subject, this paper's focus is

more on the influence of passengers' features.

In this paper, based on the Kaggle dataset, the

random forest algorithm was used for prediction and

the feature importance of each feature was compared,

as well as the correlation between features and

survival was analyzed.

2 METHOD

2.1 Data Preparation

In this study, a dataset from Kaggle is used (Kaggle,

2017). It consists of 1309 samples of passengers on

the Titanic, each of these passengers are marked by 8

features such as sex, age and fare. In terms of data

preprocessing, it is divided into two parts. First,

missing values are handled by imputation using

statistical measures, and then categorical variables are

converted to numerical formats using label encoding.

2.2 Machine Learning-based

Prediction

2.2.1 Introduction of Machine Learning

Workflow

Machine learning generally involves several key

steps to create an effective predictive model. First,

data collection gathers relevant information from

various sources to ensure a comprehensive dataset.

Next, data preprocessing cleans and transforms this

data by fitting missing values, transforming

categorical variables, and then scaling features to

prepare it for analysis. Feature selection follows,

identifying and retaining the most important variables

that contribute to the model’s performance. Model

selection involves choosing the appropriate algorithm

based on the features included in the dataset and the

practical problem. It studies from the data to identify

patterns during training and make predictions.

Performance evaluation assesses the model's

accuracy and effectiveness using separate test data.

Finally, model tuning adjusts the settings or

parameters of the algorithm to enhance its

performance, ensuring the model is well-suited to the

specific problem and data.

2.2.2 Random Forest

Random Forest (RF) is an accurate and effective

supervised machine learning method which combines

various decision trees to form a "forest." It is

applicable to situations involving both regression and

classification. An additional kind of method for data

classification is a decision tree. It resembles a

flowchart that clearly illustrates the process of

progressing choice. It starts at one beginning tree and

produces two or more branches in which each tree

branch giving a distinct set of possible outcomes. The

RF model can achieve high prediction accuracy by

combining multiple decision trees. The principle

behind this is that several unrelated models of

decision tree produce a noticeable improvement when

used together. In detail, each 'tree' in the 'forest' casts

a 'vote' for a problem, the forest integrates all the

votes and chooses the one with the majority of those

votes. RF takes different votes from multiple trees,

which helps to increase the robustness and reduce the

overfitting problem of the algorithm, which is its

greatest merit (Careerfoundry, 2023).

In this study, Random Forest is used in Python,

scikit-learn (sklearn) provides a random forest

classifier library. After applying Random Forest to

the dataset, the 1309 survival predictions are fitted

into a confusion matrix to calculate the accuracy of

the prediction. A confusion matrix is a 2×2 matrix

with "True Positive" (TP) and "True Negative" (TN)

in one row and "Predict Positive" (PP) and "Predict

Negative" (PN) in another row. The accuracy is given

by (TN+TP) / (TN+TP+PN+PP). In addition, other

evaluations such as recall, precision and F1 score can

be calculated from the 4 values above. As for the

feature importance, it is returned by the function

"feature_importances_" in which list the feature

importance of each feature, the greater the value, the

more important it is.

The Prediction and Feature Importance Investigation in Titanic Survival Prediction

Figure 1: The confusion matrix of the prediction (Photo/Picture credit: Original).

Figure 2: The feature importances of each feature (Photo/Picture credit: Original).

3 EXPERIMENTAL RESULTS

AND DISCUSSION

According to Figure 1, the prediction accuracy is

76.0%, which is a good performance. Then moving to

Figure 2, the importance of the features shows that the

top 2 features are much more important than others,

while the third is also way ahead of the rest.

Therefore, age, fare, and sex are considered to be

dominant features, and the remaining features have

no significant effect on the prediction.

3.1 Feature Analysis

In the case of the Titanic disaster, "age" was an

essential factor because it was directly related to the

chances of survival. Due to the good customs of the

community, children were often given priority for

lifeboats, as were women. On the other hand, the

elderly usually don't have the same priority as

children, and their old age does not allow them to look

for survival opportunities like the young, making 'age'

a strong predictor. The strong effect of age can be

seen in statistical data. Kakde et al. suggest that the 0-

10 age group has the survival rate at 53%, which is

the greatest, while the 60-70 group has the lowest

survival rate at only 23%.

"Fare" is the second most important feature in the

prediction. As it is highly correlated with "Pclass",

they should be analyzed together. In both Kakde's

Kakde (Kakde, 2018) and Bruno's (Frey, 2011)

conclusion, passengers traveling in higher class had a

better chance of saving themselves compared to

passengers traveling in lower class. In fact, there is no

direct correlation between "fare" or "Pclass" and

survival rate, so the explanation is only speculative:

DAML 2024 - International Conference on Data Analysis and Machine Learning

People who can afford a higher fare live in a higher

class, have a better geographical location, have better

access to relational information and therefore manage

to survive faster than others on board.

“Sex” is significant because women are given

priority to survival, as well as children, reflecting the

'women and children first' policy. Kakde et al. also

found that people with the title Mrs in their name

column had a survival rate of 79%, while people

signed Mr had a survival rate of about 16% (Kakde,

2018). There's about a fourfold difference in survival

rate between male and female, indicating the

importance of "gender" and also that people follow

the "women and children first" rule.

In general, features such as "sibsp", "parch" and

"embarked" have less weight because they are less

relative to survival than age, sex, fare and Pclass.

However, these features may be weighted differently

in other algorithms.

3.2 Limitations and Future Prospects

In this study, only one algorithm, Random Forest, has

been used, which may have resulted in unimportant

attributes becoming apparent due to the specificity of

the method. As a solution, several machine learning

algorithms such as LR, Gradient Boosting, RNN, and

SVM should be used and then compared and critically

analyzed. Furthermore, a new dataset with a different

combination of features could be tried and compared

with the previous one, then make a deep dive into how

the features affect the predictions.

4 CONCLUSION

In this study, it was found that age, fare and sex were

the three most influential features in predicting the

survival of Titanic passengers by applying Random

Forest to a Kaggle dataset.

The results of this analysis highlight the

importance of specific passenger attributes in

predicting survival. Recognizing the importance of

age, fare and gender can contribute to more accurate

forecasts in similar datasets and improve historical

analysis. This may have practical implications for

improving prediction models in other fields where the

importance of characteristics is

essential. Furthermore, the use of Random Forests

demonstrates the effectiveness of AI algorithms in

predicting problems and identifying important

patterns in complicated datasets.

However, there are a number of shortcomings in

this analysis. Model robustness may be affected by

potential overfitting problems and by focusing on

feature importance without considering feature

interactions. Future studies could explore other

methods for comparative analysis, such as logistic

regression or gradient boosting machines. In addition,

using a variety of combinations of features, as well as

looking at feature interactions, may improve model

accuracy and provide a deeper understanding of

survival predictions.

REFERENCES

Careerfoundry, what is Random Forest? 2023. Retrieved

from https://careerfoundry.com/en/blog/data-

analytics/what-is-random-forest/

Choi, E., Bahadori, M. T., Schuetz, A., Stewart, W. F., &

Sun, J. 2016. Doctor AI: Predicting clinical events via

recurrent neural networks. JMLR Workshop and

Conference Proceedings, 56, 301-318. Epub 2016 Dec

10. PMID: 28286600; PMCID: PMC5341604.

Frey, B. S., Savage, D. A., & Torgler, B. 2011. Behavior

under extreme conditions: The Titanic disaster. Journal

of Economic Perspectives, 25(1), 209–22.

https://doi.org/10.1257/jep.25.1.209

History. Titanic History, 2024. Retrieved from

https://www.history.com/topics/early-20th-century-

us/titanic

Hsieh, Y.-Z., Su, M.-C., Wang, C.-H., & Wang, P.-C. 2014.

Prediction of survival of ICU patients using

computational intelligence. Computers in Biology and

Medicine, 47, 13-19.

Kakde, Y., & Agrawal, S. 2018. Predicting survival on

Titanic by applying exploratory data analytics and

machine learning techniques. International Journal of

Computer Applications, 179, 32-38.

https://doi.org/10.5120/ijca2018917094

Kaggle, 2017. Titanic Dataset. Retrieved from

https://www.kaggle.com/datasets/heptapod/titanic

Pradeep, K. R., & Naveen, N. C. 2018. Lung cancer

survivability prediction based on performance using

classification techniques of support vector machines,

C4.5 and naive Bayes algorithms for healthcare

analytics. Procedia Computer Science, 132, 412-420.

Singh, A., Saraswat, S., & Faujdar, N. 2017. Analyzing

Titanic disaster using machine learning algorithms. In

2017 International Conference on Computing,

Communication and Automation (ICCCA) (pp. 406-

411). Greater Noida, India: IEEE.

https://doi.org/10.1109/CCAA.2017.8229835

Wang, T., Qiu, R. G., & Yu, M. 2018. Predictive modeling

of the progression of Alzheimer’s disease with

recurrent neural networks. Scientific Reports, 8, 9161.

The Prediction and Feature Importance Investigation in Titanic Survival Prediction
