A Comprehensive Approach to Urban Sound Detection with YAMNet

and Bi-Directional LSTM

Tonghui Wu

Information and Computer Science, Xi'an Jiaotong-Liverpool University, Jiangsu, China

Keywords: Sound Event Detection and Classification, Deep Learning, Audio Signal Processing.

Abstract: Urban sound event detection and classification are increasingly critical in addressing the challenges posed by

complex urban environments. As urbanization intensifies globally, traditional classification methods struggle

with the overlapping sounds typical of cities. Leveraging advances in deep learning, this research aimed to

enhance the accuracy of urban sound classification, which is essential for applications ranging from audio

signal processing to noise monitoring to public safety. Utilizing the UrbanSound8K dataset, YAMNet, a pre-

trained neural network, was combined with a custom Bidirectional LSTM network to develop a robust

classification model. The model was evaluated using cross-validation, achieving a high Matthews Correlation

Coefficient (MCC), indicating strong generalization to unseen data. Despite these positive outcomes, areas

for further improvement were identified, particularly in distinguishing between acoustically similar sounds.

This research contributes to advancing urban sound classification by integrating transfer learning and deep

learning techniques, offering a solid foundation for future exploration in complex audio classification tasks

and setting the stage for potential real-world applications.

1 INTRODUCTION

Urban sound detection and classification are critical

tasks in audio processing, with applications ranging

from noise monitoring to improving the quality of life

in smart cities. As urbanization accelerates globally,

cities are becoming denser and noisier, leading to

increasingly complex sound environments (Nogueira

et al., 2022). These environments are characterized by

overlapping sounds from traffic, construction, and

human activities, which pose challenges to traditional

classification methods (Salamon & Bello, 2015).

Effective sound classification is essential for

developing responsive urban systems, such as real-

time noise pollution monitoring and smart home

devices that can recognize and respond to specific

sounds. Accurate urban sound detection is also crucial

for public safety, enabling the real-time identification

of emergencies such as car accidents or gunshots.

Therefore, advancing urban sound detection

capabilities is both a technical challenge and a

societal necessity, driving the demand for innovative

approaches to manage the complexity and variability

of urban soundscapes.

Sound event detection (SED) has been a key focus

in audio processing, with several methods proposed

to enhance both accuracy and efficiency. Heittola et

al. emphasized the benefits of incorporating

contextual information into automatic SED,

significantly improving detection accuracy (Heittola

et al., 2013). Cakir et al. presented multi-label deep

neural networks for the identification of polyphonic

sound events, signifying a notable increase in

performance (Cakir et al., 2015). However, these

methods still face challenges in polyphonic

environments, where multiple sound events overlap.

Recognizing this challenge, Mesaros et al.

emphasized the need for robust evaluation metrics

tailored to realistic scenarios, where multiple sound

sources are active simultaneously (Mesaros et al.,

2016). Parascandolo et al. explored RNN, particularly

Bi-directional long short-term memory (Bi-LSTM)

networks, to address polyphonic SED (Parascandolo

et al., 2016). Expanding upon this work, Çakır et al.

and Xu et al. integrated convolutional and recurrent

neural networks (CRNNs) and proposed novel

architectures such as gated convolutional neural

networks (CNN) with temporal attention, which

improved classification accuracy and earned

recognition in challenges like DCASE 2017 (Çakır et

al., 2017; Xu et al., 2017). Further extending these

Wu and T.

A Comprehensive Approach to Urban Sound Detection with YAMNet and Bi-Directional LSTM.

DOI: 10.5220/0013486700004619

In Proceedings of the 2nd International Conference on Data Analysis and Machine Learning (DAML 2024), pages 23-29

ISBN: 978-989-758-754-2

ideas, Adavanne et al. developed CRNNs for joint

acoustic event localization and identification in three-

dimensional environments (Adavanne et al., 2018).

Finally, Turpault et al. explored SED in domestic

environments using weakly labeled data, significantly

contributing to the field by introducing the DESED

dataset (Turpault et al., 2019). While these studies

have advanced the field considerably, they primarily

focus on environments where sound sources are well-

defined or isolated. Accurately detecting and

classifying overlapping or noisy sound sources

remains a significant challenge in current research.

Furthermore, most existing models are heavily data-

dependent and struggle to generalize to new, unseen

urban soundscapes, particularly in highly variable and

unpredictable urban environments. This gap

underscores the need for models that not only perform

well on standardized datasets like UrbanSound8K but

also demonstrate robust generalization capabilities in

real-world applications.

To address these limitations, this study

investigates the application of transfer learning by

utilizing YAMNet a pre-trained model designed for

general audio classification tasks. The motivation

behind this approach is to utilize YAMNet's robust

feature extraction capabilities, which have been

trained on a diverse range of sound categories, to

optimize the precision and generalization of urban

sound categorization models. This study also

integrates YAMNet with a custom Bidirectional

LSTM network to classify sounds from the

UrbanSound8K dataset. Cross-validation approaches

were employed to train and assess the model, hence

assuring its robustness. Key preprocessing steps

included waveform standardization and label

encoding. Metrics such as accuracy, F1-score, and

Matthews Correlation Coefficient (MCC) were used

to evaluate the effectiveness of the model. By

integrating YAMNet with a custom deep learning

model, improved classification accuracy and

generalization were achieved. This approach not only

addresses existing gaps in urban sound classification

but also opens new avenues for applying transfer

learning to other complex audio classification tasks.

2 METHODOLOGY

This section details the steps taken in preparing the

data, building the model, and optimizing it for urban

sound classification. It covers the data preparation,

feature extraction using YAMNet, the architecture of

the Bi-Directional LSTM model, and the choice of

loss function and optimizer. Figure 1 illustrates the

sequential process of this study.

2.1 Data Preparation

This study utilizes the UrbanSound8K dataset, a

widely recognized benchmark for urban sound

classification tasks. The dataset comprises 8,732

labeled sound excerpts, each lasting up to 4 seconds.

These excerpts are categorized into 10 classes

commonly found in urban environments such as the

street music, children playing, dog bark. These

classes were chosen for their prevalence in urban

noise complaints, making them highly relevant for

urban sound detection studies. The distribution of the

total occurrence duration per class and salience is

illustrated in Figure 2(a). To ensure balanced class

distribution, each class was limited to 1,000 slices,

totaling 8,732 labeled slices (8.75 hours). Figure. 2(b)

displays the allocation of slices for each class in

UrbanSound8K, categorized by salience.

Figure 1: The workflow of the study

DAML 2024 - International Conference on Data Analysis and Machine Learning

Figure 2 (a) Total duration of occurrences for each class

within the UrbanSound dataset (b) the distribution of audio

slices per class in UrbanSound8K, categorized into

foreground (FG) and background (BG) components

(Salamon, Jacoby, & Bello, 2014).

The UrbanSound8K dataset consists of audio

files and a CSV file with metadata, including

filenames, class designations, event start and end

times, and fold numbers. Pre-structured into 10 folds

for optimized cross-validation, it ensures consistent

training and evaluation while preventing data leakage

by keeping files from the same recording within the

same fold. The dataset is partitioned into training,

validation, and test sets: folds 1-6 for training, folds

7-8 for validation, and the remaining folds for testing.

2.2 Data Preprocessing

Each audio file in the UrbanSound8K dataset is

labeled with one of 10 sound categories. To prepare

these labels for the model, initial conversion of

categorical labels into numerical format was achieved

by label encoding. The numerical labels were then

transformed into binary vectors via one-hot encoding.

This step is crucial for multi-class classification,

allowing the model to predict the probability of each

class independently during training.

In this study, YAMNet, a pre-trained model

developed by Google, was utilized for feature

extraction. YAMNet is designed for general audio

classification, capable of recognizing over 500 sound

classes (detailed in Section 2.3). Leveraging YAMNet,

high-level audio embeddings were obtained to be

used as input features for the subsequent

classification model. This process involved loading

each audio file, processing it through YAMNet, and

extracting a 1024-dimensional embedding vector

from its penultimate layer. This embedding captures

the essential features of the audio clip, making it

suitable for machine learning models.

2.3 Model Architecture

2.3.1 Pre-Trained Model: YAMNet

Structure

YAMNet processes input audio signals using a

sequence of depthwise separable convolutional layers.

Each convolutional block is followed by pooling

layers, leading to fully connected layers and,

ultimately, a softmax layer that outputs classification

probabilities for 521 classes. The primary advantage

of YAMNet is its ability to generate 1024-

dimensional embedding vectors from raw audio

inputs. These embeddings capture essential audio

characteristics, providing rich representations crucial

for subsequent classification tasks.

Leveraging these pre-trained embeddings reduces

the need for extensive training data, thereby

improving development efficiency. Additionally,

YAMNet's architecture is optimized for resource-

constrained environments, confirming optimal

utilization in practical scenarios. Figure 3 illustrates

the detailed architecture of YAMNet, showcasing the

sequence of convolutional layers and dimensional

transformations throughout the network.

Figure 3. YAMNet Body Architecture (Tena, Claria, & Solsona, 2022). Conv: Convolution. dw: Depthwise. pw: Pointwise.

A Comprehensive Approach to Urban Sound Detection with YAMNet and Bi-Directional LSTM

M YAMNet is efficient, making it suitable for

implementation in settings with limited

computational resources. This efficiency adds value

to the urban sound classification pipeline, serving as

a strong foundation for further processing stages.

2.3.2 Bi- Directional LSTM

The Bi-LSTM network is a crucial component in the

proposed model architecture. Unlike traditional

LSTMs, which process input sequences in a single

direction (typically from past to future), BiLSTMs

handle data in both directions. This flexibility allows

the network to effectively capture both forward and

bacward contexts, which is especially advantageous

for tasks that include sequential input, such as audio

categorization. In urban sound classification, the

BiLSTM layer boosts the capability of the model to

understand temporal dependencies in sound

sequences by analyzing the entire sequence

simultaneously. For example, BiLSTM can process

the start, middle, and end of an audio clip

simultaneously, allowing the recognition of patterns

that a unidirectional LSTM might miss.

The BiLSTM layer in this model contains 128

units in each direction, allowing the model to acquire

information from both preceding and following audio

frames simultaneously. This dual processing

enhances SED accuracy by integrating information

from different parts of the audio clip to make more

informed predictions. Integrating the Bi-LSTM layer

into the model ensures that the temporal

characteristics of the audio data are fully leveraged,

leading to more accurate urban sound classification.

By integrating the Bi-LSTM layer into the model,

the temporal characteristics of the audio data are fully

leveraged, leading to more accurate classification of

urban sounds. Figure.4 illustrates the structure of the

Bi-LSTM network used in this study, showing how

the forward and backward LSTMs process the input

Figure 4: The architecture of Bi-LSTM (Xie, Chen, Gu,

Liang, & Xu, 2019).

data, where {w

, w

, . . . ,w

} represent the word vector,

and n is the length of one sentence. {fh

, fh

, . . . , fh

}

and {bh

, bh

, . . . , bh

} represent the forward and

backward hidden vectors, respectively, with h

denoting the vector formed by connecting fh

and bh

2.4 Model Optimization

2.4.1 Loss Function:

In this study, Categorical Crossentropy was selected

as the loss function due to its effectiveness in multi-

class classification tasks. Categorical Crossentropy

quantifies the discrepancy between the anticipated

probability distribution and the actual data

distribution, penalizing incorrect classifications more

severely when the probability of the prediction

deviates significantly from the actual label. This

characteristic makes it particularly suitable for tasks

like urban sound classification, where the model

needs to distinguish between multiple sound classes.

The Categorical Crossentropy loss function

promotes the model to provide high likelihoods for

the accurate class selection while reducing the

likelihoods for the incorrect classes. Categorical

Crossentropy can be expressed by the following

formula:

𝐿

∑∑

𝑦



log ŷ













(1)

where: N represent the number of samples, C is the

total number of classes. The true probability of the i-

th sample belonging to the j-th class, denotes as 𝑦



(usually a one-hot encoded vector), ŷ



is the

predicted likelihood of the i-th sample being

classified as the j-th class.

2.4.2 Optimizer:

The selection of the Adam (Adaptive Moment

Estimation) optimizer for model training was based

on its capacity to effectively manage extensive

datasets and sparse gradients. The Adam optimizer

integrates the advantageous features of two other

widely used optimizers, namely AdaGrad and

RMSProp. The algorithm adjusts the learning rate for

each parameter separately, resulting in accelerated

convergence and improved performance. In this work,

the learning rate was initially established at 0.001, a

widely employed figure that achieves a harmonious

equilibrium between speed and stability throughout

the training process. The default parameters of Adam

(β1=0.9, β2=0.999, and ε=1e-7) were used, as they

have been shown to work well across a wide range of

tasks.

DAML 2024 - International Conference on Data Analysis and Machine Learning

3 RESULTS AND DISCUSSION

3.1 Confusion Matrix

From the matrix shown in Figure 5, it is evident that

certain classes, such as "jackhammer" and "engine

idling," were occasionally misclassified, likely due to

their similar acoustic profiles. This observation

implies that the model could be improved by

additional refinement strategies, possibly through

enhanced feature engineering or data augmentation

techniques, to better differentiate between these

closely related sounds.

3.2 ROC Curves

Figure 6 displays Receiver Operating Characteristic

(ROC) curves that offer a systematic assessment of

the model's performance at various classification

thresholds. For each sound class, each curve depicts

the balance between the true positive rate and the

false positive rate. The area under the receiver

operating characteristic curve (AUC) is a crucial

performance measure, where values approaching 1.0

indicate improved model performance.

In this study, the ROC curves obtained in this

work have strong AUC values for all classes, with the

"gun_shot" class achieving the AUC of 1.0, indicating

exceptional accuracy. The "engine_idling" and

"car_horn" classes also exhibit strong performance,

with AUC values exceeding 0.99. However, classes

such as "air_conditioner" and "dog_bark" present

lower AUC values, suggesting that the model faces

challenges in distinguishing these sounds under

certain conditions. Overall, the ROC analysis

underscores the model's high effectiveness in

classifying urban sounds, especially for classes with

distinct acoustic signatures.

Figure 5: The confusion matrix for the training outcome

Figure 6: The ROC curves of training result

A Comprehensive Approach to Urban Sound Detection with YAMNet and Bi-Directional LSTM

Figure 7: The precision, recall, F1-score of 10 tested classes

3.3 Performance Matrix

Figure 7 and Table 1 provide a summary of the results

obtained from evaluating the performance of the

proposed model on the UrbanSound8K dataset using

various key criterion. A comprehensive analysis of

the model's performance across the 10 sound classes

is presented in Figure 7, including precision, recall,

and F1-score. Notably, the model achieved a high

level of accuracy in categories such as "gun_shot"

(0.97) and "car_horn" (0.82), reflecting a strong

ability to correctly identify these sounds when they

are present. However, the model exhibited lower

recall for classes like "air_conditioner" (0.55) and

"dog_bark" (0.78), indicating challenges in detecting

all instances of these sounds.

The YAMNet achieved an overall accuracy of

0.80, as shown in Table 1, the associated F1-score of

0.796 indicating a well-balanced performance in

terms of precision and recall. Furthermore, the

Matthews Correlation Coefficient (MCC) was 0.776,

underscoring the model's capacity to produce

effective predictions that exhibit a robust association

with the true labels. Collectively, these metrics

highlight the model's robustness in urban sound

classification, while also indicating areas for potential

improvement, particularly for classes with

overlapping acoustic features.

Table 1: Aggregate Performance Metrics.

Metric Quantity

Accuracy 0.79976

Precision 0.80492

Recall 0.79976

F1-Score 0.79628

Matthews Correlation

Coefficient (MCC)

0.77688

4 CONCLUSION

In this study, an urban sound classification model was

developed utilizing transfer learning, leveraging the

UrbanSound8K dataset. By extracting high-level

audio embeddings from YAMNet and integrating

them with a Bidirectional LSTM network, a robust

framework for urban sound classification was

achieved. The model demonstrated strong

performance, evidenced by a high Matthews

Correlation Coefficient (MCC), indicating the

statistical reliability of the model's predictions and

capable of generalizing to unseen data. Despite these

promising results, the model's relatively simple

architecture suggests significant potential for further

enhancement. Future improvements could focus on

incorporating more advanced and complicated

DAML 2024 - International Conference on Data Analysis and Machine Learning

architectures, such as transformer-based models,

which have shown promise in handling complex

audio signals. Additionally, exploring data

augmentation techniques or fine-tuning YAMNet on

domain-specific urban sound datasets could further

enhance the model's capacity of distinguishing

between classes that are acoustically quite similar.

REFERENCES

Nogueira, A. F. R., Oliveira, H. S., Machado, J. J. M., &

Tavares, J. M. R. S. (2022). Sound classification and

processing of urban environments: A systematic

literature review. Sensors, 22(22), 8608.

https://doi.org/10.3390/s22228608

Salamon, J., & Bello, J. P. (2015). Unsupervised feature

learning for urban sound classification. In 2015 IEEE

International Conference on Acoustics, Speech and

Signal Processing (ICASSP) (pp. 171-175). IEEE.

https://doi.org/10.1109/ICASSP.2015.7177954

Heittola, T., Mesaros, A., Eronen, A. J., & Virtanen, T.

(2013). Context-dependent sound event detection.

EURASIP Journal on Audio, Speech, and Music

Processing, 2013(1), 1-15.

https://doi.org/10.1186/1687-4722-2013-1

Cakir, E., Heittola, T., Huttunen, H., & Virtanen, T. (2015).

Polyphonic sound event detection using multi-label

deep neural networks. In 2015 International Joint

Conference on Neural Networks (IJCNN) (pp. 1-7).

IEEE. https://doi.org/10.1109/IJCNN.2015.7280518

Mesaros, A., Heittola, T., & Virtanen, T. (2016). Metrics for

polyphonic sound event detection. Applied Sciences,

6(6), 162. https://doi.org/10.3390/app6060162

Parascandolo, G., Huttunen, H., & Virtanen, T. (2016).

Recurrent neural networks for polyphonic sound event

detection in real life recordings. arXiv preprint

arXiv:1604.00861.

https://doi.org/10.48550/arXiv.1604.00861

Çakır, E., Parascandolo, G., Heittola, T., Huttunen, H., &

Virtanen, T. (2017). Convolutional recurrent neural

networks for polyphonic sound event detection.

IEEE/ACM Transactions on Audio, Speech, and

Language Processing, 25(6), 1291-1303.

https://doi.org/10.1109/TASLP.2017.2690575

Xu, Y., Kong, Q., Wang, W., & Plumbley, M. D. (2017).

Large-scale weakly supervised audio classification

using gated convolutional neural network. arXiv

preprint arXiv:1705.02304.

https://doi.org/10.48550/arXiv.1705.02304

Adavanne, S., Politis, A., Nikunen, J., & Virtanen, T. (2018).

Sound event localization and detection of overlapping

sources using convolutional recurrent neural networks.

IEEE Journal of Selected Topics in Signal Processing,

13(1), 34-48.

https://doi.org/10.1109/JSTSP.2018.2885636

Turpault, N., Serizel, R., Shah, A., & Salamon, J. (2019).

Sound event detection in domestic environments with

weakly labeled data and soundscape synthesis. In

Proceedings of the Detection and Classification of

Acoustic Scenes and Events 2019 Workshop

(DCASE2019) (pp. 253-

257).http://dcase.community/documents/challenge201

9/technical_reports/DCASE2019_Turpault_42.pdf

Salamon, J., Jacoby, C., & Bello, J. P. (2014, November). A

dataset and taxonomy for urban sound research. In

Proceedings of the 22nd ACM international conference

on Multimedia (pp. 1041-1044).

Tena, A., Claria, F., & Solsona, F. (2022). Automated

detection of COVID-19 cough [Image of YAMNet

Body Architecture]. Biomedical Signal Processing and

Control, 71, 103175.

https://doi.org/10.1016/j.bspc.2021.103175

Xie, J., Chen, B., Gu, X., Liang, F., & Xu, X. (2019). Self-

attention-based BiLSTM model for short text fine-

grained sentiment classification. IEEE Access, 7,

180558-180570.

A Comprehensive Approach to Urban Sound Detection with YAMNet and Bi-Directional LSTM
