An Overview of Different Artificial Intelligence Applications in Games

Xuantao Chen

Quality School of International, Bitao Building, 8-5 Taizi Road, Shekou, Shenzhen, Guang Dong, China

Keywords: Artificial Intelligence, Games, Ad Hoc Behaviour Authoring, Tree Search, Machine Learning.

Abstract: With huge improvements being made in Artificial Intelligence (AI) in recent years, the power of AI is

gradually revealed to a greater extent. Game development is complicated and challenging due to the

requirement of knowledge in different fields and the gigantic amount of effort to complete it. Therefore, its

complexity undoubtedly creates an application scenario for the powerful AI. In this paper, an academic

perspective of game AI was presented by reviewing several fundamental AI methods used in the majority of

games such as ad hoc authoring, tree search, and machine learning. Besides this, the paper also mentioned

several specific AI algorithms or methods such as procedural generation techniques and constraint satisfaction

problems, methods that were applied to some common game genres. The research value of the paper arises

with the collision of the two hot complex topics, and its trend will become more popular in the future without

doubt. A conclusion on the topic is reached with some open problems mentioned, which demand new methods

and improvements.

1 INTRODUCTION

Games and Artificial Intelligence (AI) have a long

history. Since the late 20

century, people have been

trying to apply AI to games, and they have done well.

Some landmark achievements of AI applications in

games happened in 1994, 1997, and 2016, with AI

programming Chinook, Deep Blue, and AlphaGo

defeating the world champions in different games

respectively (Fan, Wu, Tian, 2020). Chinook,

developed in the 1990s, is one of the most

representative precursors in such fields as it is the first

time in history that a computer program won a world

championship.

On 15 August 1994, a checkers match was played

by the world checkers champion Marion Tinsley and

Chinook, in Boston, Massachusetts. The first six

games were drawn, with only two potential winning

chances shown. Right before the next round of games,

Tinsley claimed that he had a health issue, so the

match was canceled, and Tinsley was sent to the

hospital. Subsequently, Tinsley was diagnosed with

cancer, and he resigned his title of world champion

(Schaeffer, Lake, Lu, Bryant, 1996). This marked a

historical moment as it was the first time that a non-

human character defeated a world champion human

https://orcid.org/0009-0004-5537-7355

in the game domain even though it is not considered

as a glorious victory for Chinook. Nevertheless, a few

challengers came after Tinsley’s capitulation to

challenge this champion machine, but they failed to

win. With Chinook's strength being proved, the

human concept of AI development in the aspect of the

game was solidified, which laid the foundation for the

future AI’s domination over the field.

Chinook’s use of tree search was one of the key

factors that helped him win the match. To be more

specific, the algorithm is called the alpha-beta search

algorithm that is in a depth-first manner (Schaeffer,

Treloar, Lu, Lake, 1993). With studies suggesting that

a deeper search will translate into stronger play, it

indicates that the algorithm helps Chinook to

determine the optimal move in the game, thus

defeating Marion Tinsley and other

challengers (Thompson, 1982).

Speaking of tree search, it is known that

AlphaGo, another famous AI that created a landmark

in AI games, also involved applications of tree search

as one of its core components. Similar to alpha-beta

search algorithm, the Monte Carlo Tree Search

(MCTS) of AlphaGo is another tree search algorithm

that helps AI agents determine which step to execute

in a game through simulation process. More analysis

Chen, X.

An Overview of Different Artiﬁcial Intelligence Applications in Games.

DOI: 10.5220/0013337700004558

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 1st International Conference on Modern Logistics and Supply Chain Management (MLSCM 2024), pages 447-451

ISBN: 978-989-758-738-2

447

and explanation of MCTS will be mentioned later in

this paper.

With the rapid development of electronics and

programming in recent years, there are now many

more advanced AI techniques beyond just traditional

tree searches. Developers have come up with new AI

algorithms and invented new advanced AI methods

with improved ability (Bakkes, Spronck, Herik,

2009). However, in order for researchers to

understand the basic principles laid behind, this

article will mainly focus on the most fundamental

algorithms of game AI that laid the basis for the future

development of game AI. Some examples such as ad

hoc behavior authoring, tree search, and machine

learning are shown in Figure 1, which are the methods

that the newly invented game AI are based on.

Furthermore, this paper also summarized two

designated AI algorithms or methods specifically

used in some common game genres: procedural

generation techniques and constraint satisfaction

problems. With such a review, researchers, scholars,

or developers will have a clear understanding of the

logic behind game AI algorithms and how different

AI helps in the game industries.

Figure 1: Representative AI methods in games.

2 FUNDAMENTAL AI

ALGORITHMS IN GAMES

In general, building and controlling a non-player

character (NPC) is always considered one of the

primary goals when developing video games. With

AI, such an essential task can be easily accomplished.

2.1 Ad Hoc Behaviour Authoring

Ad Hoc behaviour authoring methods are the most

popular AI methods used to control the non-player

characters in games. Some of the most represented

algorithms include finite state machines (FSM),

behaviour trees (BT), and utility-based AI.

FSM, as its name indicates, is a model of

computation with a finite number of sequential states

or conditions. The main purpose of this model is to

change from one state to another based on the inputs

and the current state, which is very simple and

therefore, such model had been applied to most of the

video games in the world (Lee, 2014). However, there

are some defects in the FSM model, namely lack of

reactive and hard to cope with complicated

scenario, which led to the creation of BT.

Just like FSM, BT also has transformation

between a limited number of behaviours and relies on

the current state and situation to decide what action or

behaviour should be taken. It breaks down desired

behaviour into hierarchy tree structures, with nodes in

each branch representing a specific decision point and

its corresponding action. It is its tree structure that

allows developers to break down complex behaviours

into smaller, more manageable modules, making it

easier to design and maintain the whole system

(Colledanchise, Parasuraman, Ogren, 2019).

In order to further alleviate the modular limitation

of FSM and BT, utility-based AI was invented.

Unlike FSMs and BTs, the utility-based AI methods

check all available options rather than one at a time,

make an analysis between them, and determine the

most appropriate output. To do this, the method made

an objective comparison between actions that the

NPC can take and the game demands by assigning

normalized values to all possible actions that the NPC

can take at that moment. As for output, the action with

the highest value is usually chosen as the most

suitable decision. Therefore, utility-based AI has an

apparent advantage over complex scenarios,

indicating its flexibility and extensibility.

2.2 Tree Search

The vast majority of tasks people ask AI to do can be

transferred into a problem, which can be solved by AI

through searching for the best-fit solution. Tree

Search algorithms can be considered one of the

simplest while efficacious algorithms that can be used

to complete such a task.

Tree Search is a tree data structure and has a root

node known as the starting point. Then, it proceeds as

it explores each and every single node where each

node represents a state. When a node is reached, the

tree will have to decide which branches to execute

based on specific criteria since there are a variety

of paths with different operations and transitions to

the next corresponding step.

One famous representative of the Tree Search

algorithm is MCTS mentioned in the introduction,

which is highly applied in various games and has

achieved gigantic success. For instance, it is well-

known that MCTS played a crucial role in the Google

DeepMind AlphaGo that defeated the world Go game

MLSCM 2024 - International Conference on Modern Logistics and Supply Chain Management

448

champion in 2016 (Silver, Huang, Maddison et al,

2016). The key component of MCTS can be divided

into 4 steps:

1. Selection: starting from the root node that

represents the current game state, MCTS repeatedly

selects child nodes based on a selection policy, such

as the Upper Confidence Bound (UCB) formula, until

it reaches a leaf node, a state that is unexpanded.

2. Expansion: Following the previous step,

MCTS adds new nodes, known as the child nodes, to

the leaf nodes.

3. Simulation: MCTS then plays a random

simulation with random decisions until a terminal

state is reached. Once the terminal state is reached, it

sends a result of how well it performs with score

being calculated.

4. Backpropagation: The result of the simulation

is then propagated back to the starting point, updating

the statistics of the visited nodes and corresponding

data.

The algorithm repeats these four steps numerous

times, gradually building up the search tree and

guaranteeing the best solution.

MCTS has not only applied to Go or other classic

board games, but it has also applied to modern board

games and video games that are way more complex.

For example, researchers’ implementation of MCTS

in Settler of Catan had outperformed previous

heuristic game AI, providing a challenging opponent

for players (Chaslot, Bakkes, Szita, Spronck, 2021).

Besides this, some other scholars have deployed

MCTS on RTS games such as StarCraft to create AI

agents with multifaceted strategic decisions that are

more effective, achieving performance comparable to

that of human players (Uriarte, Ontañón, 2021).

Overall, it is easy to see the shadows of Tree Search

in various games, stating its importance and relevance

towards game industries.

2.3 Machine Learning

Machine learning, as its name implies, is a field of

artificial intelligence that enables computers and

systems to learn and improve, where the system will

adapt to the new circumstances gradually as it

explores. The are three major categories of machine

learning: supervised learning (SL), unsupervised

learning (UL) and reinforcement learning (RL).

In (SL, humans feed data to the system, where the

inputs and their corresponding outputs are labelled

and provided. The system is likely to learn the

relationship between input and output, creating a set

of rules that will predict the expected output. Unlike

SL, the dataset fed to UL is unlabelled and only

contains input. The system will make observations

and find the association of inputs according to their

features. Totally different from SL and UL of analysis,

RL works well in the field of decision-making,

especially sequential one. The system or agent is able

to interact with an environment and determine what

is deemed as good or bad behaviour in the context of

the game objective. It receives rewards or penalties as

it executes and adjusts its behaviour accordingly. The

RL model focuses more on delayed rewards, which

maximizes the cumulative long-term rewards, rather

than simply the immediate rewards. Therefore,

researchers have applied RL models to games that

emphasize such features, such as StarCraft (Zhao,

Shao, Zhu et al, 2016).

As seen, machine learning algorithms rely heavily

on data to train models and make predictions or

decisions. And so, for the data of games, video data

such as replay of players would provide gigantic

value to the training model. Many organizations such

as DeepMind and Facebook have released a great

amount of replay data sets to train their model and try

to mimic the player’s behaviour. As long as there is

sufficient data, whether it is SL, UL, or RL, it can

strongly enhance the game experience of players by

creating challenging AI agents.

3 SPECIFIC AI ALGORITHMS

FOUND IN SOME COMMON

GAME GENRES

In addition to the simple task of applying AI to the

work of NPCS, AI can also help humans in many

more areas of the game. Indeed, some specific AI has

been applied to a wide range of video game genres to

accomplish different tasks such as procedural

generation techniques for content generation in

sandbox games and constraint satisfaction problems

for a further realistic experience in simulation games

respectively.

3.1 Procedural Generation Techniques

In Sandbox game, creating a random game world is

an indispensable step. Procedural generation

techniques are powerful tools in computer

programming that can accomplish this task by its

function of automating the creation of certain data

according to algorithms. One of the major AI

algorithms of procedural generation techniques that

work in Sandbox games is noise function, such as

Perlin Noise and Simplex Noise.

An Overview of Different Artiﬁcial Intelligence Applications in Games

449

Created by Ken Perlin in 1983, Perlin noise is a

procedural noise algorithm that generates a smooth,

continuous, and random pattern, which makes the

texture look more realistic even though it is generated

by AI. It accomplishes such a task as it calculates the

noise patterns by performing a series of actions such

as interpolating between a grid of random gradient

vectors and combining multiple octaves of noise.

On the other hand, also introduced by Perlin in

2002, Simplex noise served as an alternative to the

early Perlin noise, with a higher efficiency and

smoother noise pattern in complex terrain. Simplex

noise has a faster gradient evaluation that allows it to

extend to a higher dimension (Gustavson S, McEwan

I, 2022).

3.2 Constraint Satisfaction Problems

Normally, in simulation games, problems will always

arise as time progresses. For NPC to act like humans

is also an important factor in determining whether a

simulation game is good or bad. Therefore, this led to

the introduction of Constraint Satisfaction Problems,

a technique involving a series of problems that match

the above key points, into simulation games.

Constraint Satisfaction Problems is a powerful

problem-solving technique that finds solutions to

problems that involve satisfying a set of constraints

or requirements. The fundamental principle behind

Constraint Satisfaction Problems is to represent the

problem as a set of variables, each with a domain that

represents the possible value stored, and a set of

constraints that limit the values (Barták, Salido, Rossi,

2010). The goal is also set but must be accomplished

under constraint.

Constraint Satisfaction Problems fit well with

simulation games since problems emerge at any time

in this kind of game. In order to act like humans

(that’s what simulation games are looking for), the

constraints in Constraint Satisfaction Problems will

limit the behaviour of the NPC and govern the game

world. These constraints can capture the complex and

often conflicting issues that humans face in the real

world. This flexibility allows the simulation to

produce further nuanced and realistic scenarios, thus

enhancing the player’s experience.

4 CONCLUSIONS

With the summary of previous section had implies,

games are an ideal domain of AI. In this paper,

different basic AI methods and algorithms as well as

AI applications in games are summarized and

presented. However, there are still many open

questions about the application of AI in such fields.

Some of the potential challenges are listed below:

 Whether the ai can become a qualified

teammate and cooperate with different types of

players, so that the player's experience would rise.

 Whether the AI’s output in some algorithms

may be too predictable, which will reduce challenge

and excitement for players.

 Whether humans can create a universal game

AI with a unified framework, resulting in a lower cost

of game development.

Apparently, different AI methods are most likely

relevant to each other, with each based on the other's

ability to extend new AI methods. Therefore, it is

suggested that enrolling the combination of various

AI methods that already exist in order to learn from

each other’s strong points is an essential and

ineluctable thing to do for development of new AI

methods or algorithms.

REFERENCES

Bakkes, S., Spronck, P., Herik, J., 2011. Rapid and Reliable

Adaptation of Video Game AI. IEEE Transactions on

Computational Intelligence and AI in Games, 34(1):

30-31.

Barták, R., Salido, M.A. & Rossi, F., 2010. Constraint

satisfaction techniques in planning and scheduling. J

Intell Manuf 21, 5–15.

Bayliss, J. D., 2012. Teaching game AI through Minecraft

mods. 2012 IEEE International Games Innovation

Conference, Rochester, NY, USA, pp. 1-4.

Chaslot, G., Bakkes, S., Szita, I., & Spronck, P., 2021.

Monte-Carlo Tree Search: A New Framework for

Game AI. Proceedings of the AAAI Conference on

Artificial Intelligence and Interactive Digital

Entertainment, 4(1), 216-217.

Colledanchise, M., Parasuraman, R., Ogren, P., 2019.

Learning of Behavior Trees for Autonomous Agents.

2018 IEEE, IEEE TRANSACTIONS ON GAMES,

11(2).1

Fan, X., Wu, J., Tian, L., 2020. A review of artificial

intelligence for games//Artificial Intelligence in China:

Proceedings of the International Conference on

Artificial Intelligence in China. Singapore: Springer

Singapore, 298-303.

Gustavson, S., McEwan, I., 2022. Tiling Simplex Noise and

Flow Noise in Two and Three Dimensions. Journal of

Computer Graphics Techniques 11(1).

Lee, M., 2014. An Artificial Intelligence Evaluation on

FSM-Based Game NPC. Journal of Korea Game

Society, vol. 14, no. 5. Korea Academic Society of

Games, pp. 127–135.

MLSCM 2024 - International Conference on Modern Logistics and Supply Chain Management

450

Schaeffer, J., Lake, R., Lu, P., & Bryant, M., 1996.

CHINOOK The World Man-Machine Checkers

Champion. AI Magazine, 17(1), 21.

Schaeffer, J., Treloar, N., Lu, P., & Lake, R., 1993. Man

Versus Machine for the World Checkers Championship.

AI Magazine, 14(2), 28.

Silver, D., Huang, A., Maddison, C. J., et al., 2016.

Mastering the game of Go with deep neural networks

and tree search. Nature 529(7587): 484–489.

Thompson, K., 1982. Computer Chess Strength. In

Advances in Computer Chess 3, ed. M. R. B. Clarke,

55–56.

Uriarte, A., & Ontañón, S., 2021. Game-Tree Search over

High-Level Game States in RTS Games. Proceedings

of the AAAI Conference on Artificial Intelligence and

Interactive Digital Entertainment, 10(1), 73-79.

Zhao, D., Shao, K., Zhu, Y., et al., 2016. Review of deep

reinforcement learning and discussions on the

development of computer Go. IET Control Theory A

33(6):701–717.

An Overview of Different Artiﬁcial Intelligence Applications in Games

451
