Comparative Analysis of Machine Learning Models for Heart Disease

Prediction

Weichi Gao

Institute of Science and Technology, Wenzhou Kean University, Wenzhou, Zhejiang, 325060, China

Keywords: Heart Disease Diagnosis, Machine Learning, Pattern Recognition.

Abstract: In recent years, heart disease has become one of the major public health problems worldwide. According to

the World Health Organization, cardiovascular disease is one of the leading causes of death, especially among

middle-aged and elderly people. Lifestyle changes, such as an unhealthy diet, lack of exercise, and high stress

levels, dramatically increase the incidence of heart disease. This paper will compare three models, including

decision trees, random forests, and Limit Gradient Lift (XGBoost), by analyzing heart disease data sets.

Through the comparison and analysis of these three machine learning models, the final conclusion is that

XGBoost model has the highest accuracy. Machine learning has significant advantages in the medical field,

especially in the detection of heart disease. First, machine learning algorithms can efficiently process large

amounts of data. Second, machine learning is able to identify complex patterns and small differences that are

difficult to detect with traditional methods, thus improving the accuracy of diagnosis. In addition, machine

learning is highly adaptive, with the ability to continuously optimize and improve models based on new data.

1 INTRODUCTION

Heart disease is a kind of disease that affects the heart

function widely, including coronary heart disease,

myocarditis, arrhythmia, heart failure and many other

types (Ponikowski, 2014). These diseases are often

caused by atherosclerosis, high blood pressure,

diabetes, poor lifestyle habits (such as smoking,

alcohol abuse, obesity, physical inactivity), and

genetic factors. Heart disease is very harmful to

human health and is one of the important causes of

death and disability in the world (Groenewegen,

2020). The risks of heart disease vary, the most

serious of which is sudden death, especially acute

myocardial infarction, a heart attack, which often

becomes life-threatening in a short period of time

(Mata, 2014). In view of the high risk of heart disease,

early detection and timely intervention are

particularly important. Early detection can enable

patients to take effective treatment before the disease

progresses, significantly reducing the risk of sudden

heart attack and death. Through early treatment, It can

also reduce the probability of serious complications

such as heart failure, thereby improving the living

standards of patients and extending the life span of

patients. Common methods for predicting heart

disease risk include risk scoring systems, blood tests,

imaging and genetic testing. Through these methods,

an individual's risk of heart disease can be more

accurately assessed, so that more effective prevention

and treatment strategies can be developed to help

patients take early measures to avoid further

deterioration of the disease.

Traditional machine learning models offer a suite

of advantages that are particularly beneficial in the

detection of heart disease (Ahsan, 2022). These

models are good at processing large-scale data,

recognizing complex patterns, and can make high-

precision predictions (Khan, 2019). Their ability to

learn from historical data and adapt to new

information is crucial in the medical field, where

early and accurate diagnosis is paramount. Moreover,

machine learning models are highly customizable and

can be fine-tuned to improve their performance over

time. They are also less prone to human error and bias,

ensuring a more objective analysis of patient data. As

a result, these models play a pivotal role in advancing

cardiovascular disease management, contributing to

better patient outcomes and a reduced burden on

healthcare systems.

This essay will focus on predicting heart disease

by comparing the performance of random forests,

decision trees, and Extreme Gradient Boosting

234

Gao, W.

Comparative Analysis of Machine Learning Models for Heart Disease Prediction.

DOI: 10.5220/0013296800004558

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 1st International Conference on Modern Logistics and Supply Chain Management (MLSCM 2024), pages 234-237

ISBN: 978-989-758-738-2

(XGBoost) algorithms. This study aims to identify the

most effective models of early detection and

prevention to contribute to ongoing global efforts for

cardiovascular disease control and prevention. The

following sections will be divided into: introduction,

method, experiments and result, discussion and

conclusion.

2 METHOD

2.1 Dataset

The dataset utilized in this study comprises 1,025

samples and 14 features (David, 2014). Each row

corresponds to an individual, while the columns

represent various health indicators that may influence

the risk of heart disease. To handle categorical

variables, one-hot encoding was applied. Initially,

features such as "gender," "chest pain type" (cp), and

"resting electrocardiographic results" (restecg) were

represented by single values corresponding to

different categories. With one-hot encoding, these

categorical variables were transformed into multiple

binary columns (True/False), each representing a

specific category. This approach prevents the model

from mistakenly interpreting categorical variables as

ordinal, thereby enhancing the accuracy of the

model’s predictions.

2.2 Models

This essay will compare three models in total,

including Decision Tree, Random Forest, and

XGBoost.

2.2.1 Decision Tree

Decision trees represent a non-parametric supervised

learning method utilized for both classification and

regression problems (Song, 2015). This algorithm is

structured hierarchically, with components including

branches, root nodes, internal nodes, and leaf nodes.

One of the key benefits of decision trees is their high

level of interpretability. Because of its structure, it is

easy to understand how predictions are made. It can

provide a clear decision path that can be traced back

to each prediction. The simplicity of decision trees

comes with limitations - they are prone to overfitting,

which means the model becomes too suited to the

specific features of the training data. This will lead to

poor performance on unknown data, such as

predictions for new patients. In addition, decision

trees are very sensitive. Even small changes can lead

to completely different results, resulting in poor

performance (De Ville, 2013).

2.2.2 Random Forest

The second model is a random forest. It is a frequently

used machine learning algorithm that combines the

outputs of multiple decision trees to arrive at a single

result. Its practicality and flexibility have led to its

adoption as it deals with classification and regression

problems (Rigatti, 2017). Each tree is trained with

random data and features, which allows the model to

consider different combinations of risk factors.

Random forests can effectively solve overfitting

problems in decision trees because it can draw

conclusions from multiple trees. This eliminates noise

and makes it easier to generalize the model to new

data. In addition, due to its multi-tree nature, it can

rely on the collective decisions of other trees to

process missing data. However, there are some

drawbacks to this model. It is clear that random

forests are computationally intensive, especially

when dealing with large data sets or large numbers of

trees. Moreover, it improves accuracy at the expense

of interpretability. Unlike a single decision tree,

where the prediction path is clear, the holistic nature

of a random forest makes it harder to tell exactly how

a particular decision was made.

2.2.3 XGBoost

The third model is XGBoost (Chen, 2016), a scalable

and distributed gradient-boosted decision tree

(GBDT) machine learning library. XGBoost is widely

recognized for its efficiency and scalability, which

makes it especially effective for processing large

datasets.The algorithm's distributed nature allows it

to perform parallel tree boosting, significantly

reducing training time and enhancing its ability to

tackle complex machine learning tasks such as

regression, classification, and ranking. One of the

key strengths of XGBoost is its meticulous approach

to model training. It employs an iterative process that

incrementally builds trees, with each new tree aimed

at correcting the errors of its predecessors. This

method enables the algorithm to refine its predictions

with each iteration, leading to improved accuracy

over time. The algorithm also incorporates

regularization techniques to prevent overfitting,

ensuring that the model maintains robustness even as

it becomes more complex. XGBoost's ability to

handle missing data is another notable feature. It is

designed to be robust against incomplete data,

allowing it to make reliable predictions even when

certain information is absent. This resilience is

Comparative Analysis of Machine Learning Models for Heart Disease Prediction

235

particularly valuable in real-world scenarios where

data integrity can be compromised. Despite

XGBoost's high accuracy, it also faces some

challenges. Like random forests, it sacrifices

interpretability for better performance. In addition, it

is difficult to find detailed operations for specific

predictions. In summary, while XGBoost presents a

powerful tool for enhancing prediction accuracy in

heart disease detection, its use also necessitates

careful consideration of its limitations. Future

research and development should focus on enhancing

the algorithm's interpretability and accessibility,

ensuring that its benefits can be fully realized in

practical applications.

3 EXPERIMENT AND RESULTS

The age distribution in the data set shows that 52.2%

of the sample was made up of older adults (aged over

55 years), 42.1% was middle-aged (aged between 40

and 55 years), and only 5.7% was young (aged

between 29 and 40 years). This distribution provides

important insights into the potential correlation

between age and heart disease prevalence. In addition,

heat maps were used to visualize the linear

relationship between the features and highlight the

significant correlations. For instance, there is an

inverse relationship between maximum heart rate and

age, whereas a positive correlation exists between

exercise-induced ST-segment depression and the

number of major blood vessels, with the latter

showing a correlation coefficient of 0.32.

To ensure efficient feature selection, a statistical

method is used in the analysis that ranks features

according to their relevance to the target variable, as

shown in Figure 1. This process involves several key

steps. First, the data set is processed to exclude the

target variables and keep only the predictor variables.

Feature selection techniques are then applied to

identify the top 13 most important features. These

features were then extracted and ranked according to

their statistical significance. The results are visualized

in a bar chart that shows the relative importance of

each selected feature.

The testing of the hypothesis is done through the

code development process of the system. First, a

dataset of heart disease is imported, and a unique

thermal encoding is used to convert categorical

variables such as gender into numerical values,

facilitating efficient processing of the model. The

dataset is subsequently split into a training set, used

for model training, and a validation set, employed to

assess the model's performance. To enhance the

model's prediction accuracy, a feature selection

technique is applied to identify the most significant

features, which are then used in the following model

training process.

Figure 1: Importance of features (Figure Credits: Original).

Multiple decision tree models are trained using

different minimum number of node split samples and

maximum tree depth. The accuracy curves of the

training set and the validation set were drawn to

determine the optimal model parameters, and the

maximum depth was determined to be 16 and the

minimum sample split number to be 10. Similarly,

multiple random forest models were trained and the

best-performing model was selected based on its

accuracy. In addition, the XGBoost model is trained

on the data set and an early stop technique is

introduced to prevent overfitting. The optimal

number of iterations, training accuracy and test

accuracy were then recorded as demonstrated in

Table 1. The accuracy of decision tree, random forest

and XGBoost models on validation sets is compared

and analyzed by bar graph, and the most efficient

models are identified.

Table 1: Accuracy comparison of different models.

Models Accurac

Decision tree 0.9610

Random forest 0.9659

XGboost 0.9805

4 DISCUSSIONS

It is evident that the XGBoost model achieves the

highest accuracy among the models. Through

analysis, it can be found that the best performance of

the XGBoost model is mainly due to its advantages in

ensemble learning, handling unbalanced data,

efficient computing performance, and flexible tuning.

These features allow XGBoost to provide greater

MLSCM 2024 - International Conference on Modern Logistics and Supply Chain Management

236

accuracy and better generalization on complex data

sets. This is why the XGboost model is more accurate

than other models.

This study underscores two critical issues: the

imbalance in the dataset and the narrow scope of data

sources. Firstly, the age distribution's skew towards

older adults not only restricts the model's

generalizability to younger demographics but also

potentially masks age-specific risk factors that could

be crucial for comprehensive heart disease prediction.

This demographic limitation could lead to

underrepresentation of early-onset heart disease

patterns, thereby affecting the model's predictive

accuracy across all age groups.

Secondly, the reliance on a single dataset, without

incorporating diverse data from multiple institutions

or international sources, may introduce geographical

and ethnic biases. Heart disease presents varying risk

factors and manifestations across different

populations due to genetic, environmental, and

lifestyle differences. The lack of a multi-institutional,

multinational dataset could hinder the model's ability

to capture these nuances, thus limiting its global

applicability and reducing its effectiveness in

providing personalized risk assessments.

To address these limitations, future research

should aim to develop a more balanced and diverse

dataset that includes a broader age range and

represents multiple populations. This strategy will

improve the model's predictive accuracy and ensure it

is better suited to assess heart disease risks across

different demographic groups. Additionally,

employing advanced feature selection techniques and

dimensionality reduction methods will allow for a

more holistic understanding of the complex interplay

between features, leading to more accurate and

nuanced predictions. Furthermore, expanding the

comparative analysis to include other models like

Neural Networks may reveal additional insights and

potentially higher predictive accuracy. The primary

objective is to improve the predictive capabilities of

heart disease models, which will contribute to more

effective prevention strategies and better

cardiovascular health outcomes. As machine learning

continues to evolve, there is great potential for

developing more accurate, adaptive, and personalized

tools for predicting heart disease in the future.

5 CONCLUSIONS

In summary, three models of decision tree, random

forest and XGboost are compared. XGboost was

found to have the highest accuracy. The decision tree

is 0.9610, the random forest is 0.9659, and XGBoost

is 0.9805. Therefore, it can be found that the

predictions for the performance of the three models

are correct. XGBoost has high accuracy. Iterative

steps help it catch patterns that other models might

miss, allowing it to make better predictions. In

addition, it can handle lost data, which is useful in

cases where records are incomplete. In the future, the

model will be upgraded by employing a diverse range

of models to predict heart disease cases, aiming to

identify alternatives that outperform XGBoost or to

further refine the existing XGBoost model for

improved accuracy. Additionally, a website will be

set up, with the goal of training a refined heart disease

prediction model and launching a platform where

users can estimate their heart disease risk and receive

personalized advice on how to improve their health.

REFERENCES

Ahsan, M. M., & Siddique, Z. 2022. Machine learning-

based heart disease diagnosis: A systematic literature

review. Artificial Intelligence in Medicine, 128,

102289.

Chen, T., & Guestrin, C. 2016. Xgboost: A scalable tree

boosting system. In Proceedings of the 22nd acm

sigkdd international conference on knowledge

discovery and data mining. 785-794.

David, L. 2019. URL: https://www.kaggle.com/datasets/jo

hnsmith88/heart-disease-dataset. Last Accessed: 2024/

09/09

De Ville, B. 2013. Decision trees. Wiley Interdisciplinary

Reviews: Computational Statistics, 5(6), 448-455.

Groenewegen, A., Rutten, F. H., Mosterd, A., & Hoes, A.

W. 2020. Epidemiology of heart failure. European

journal of heart failure, 22(8), 1342-1356.

Khan, Y., Qamar, U., Yousaf, N., & Khan, A. 2019.

Machine learning techniques for heart disease datasets:

A survey. In Proceedings of the 2019 11th

International Conference on Machine Learning and

Computing, 27-35.

Mata, J., Frank, R., & Gigerenzer, G. 2014. Symptom

recognition of heart attack and stroke in nine European

countries: a representative survey. Health

Expectations, 17(3), 376-387.

Ponikowski, P., Anker, S. D., AlHabib, K. F., Cowie, M. R.,

Force, T. L., Hu, S., ... & Filippatos, G. 2014. Heart

failure: preventing disease and death worldwide. ESC

heart failure, 1(1), 4-25.

Rigatti, S. J. 2017. Random forest. Journal of Insurance

Medicine, 47(1), 31-39.

Song, Y. Y., & Ying, L. U. 2015. Decision tree methods:

applications for classification and prediction. Shanghai

archives of psychiatry, 27(2), 130.

Comparative Analysis of Machine Learning Models for Heart Disease Prediction

237
