Research on Text Based Generative Image Editing

Yiren Wang

Jiangsu No.10 High School, Suzhou, China

Keywords: Image Editing, Deep Learning, Generative Adversarial Networks, Diffusion Model.

Abstract: In recent years, with the continuous development of artificial intelligence the quality of images generated by

using deep learning ability has gradually improved. Image editing uses the deep learning model to use

conditional information as a guide and modify some regions in the image, while other regions remain

unchanged. Generated image is a kind of automatic image editing, which can automatically generate images

that meet the requirements of the user. Editable content includes, but is not limited to, the color, shape, texture,

overall style and other features of the image to be edited. Generative image editing is an important part in the

field of computer vision, and generative image editing has important use and theoretical value. This paper is

a review based on the generative image editing with text as the control condition. This paper classifies the

implementation method of text-based generative image editing, which is divided into generative adversarial

network (GAN), diffusion model, CLIP model, and autoregressive model. The advantages and disadvantages

of various implementation methods are analyzed, and various evaluation indexes of image editing are

introduced. Finally, the future of the field is discussed.

1 INTRODUCTION

Over the past few years, artificial intelligence has

been continuously developing, the generative deep

learning ability of artificial intelligence has

continuously entered various fields. In the field of

image editing, the quality effect of pictures generated

by using generative deep learning is also gradually

increasing, bringing progress and innovation to this

field. Under this trend, generative image editing has

gradually matured and developed new research

directions in the field of image processing and

computer vision. Image editing uses the deep learning

model to use conditional information as guides,

modifying some areas in the image, while other

regions remain unchanged. Generated image is a kind

of automatic image editing, which can automatically

generate images that meet the requirements of users.

Generative image editing can create more

imaginative images, can generate images with new

artistic style, make images more innovative, and text-

based generative image editing refers to change some

scenes in the form of text input according to user

needs, while other scenes remain the same.

https://orcid.org/0009-0005-7423-6336

Nowadays, the application scenarios of generative

image editing technology are very wide: (1) newly

proposed texture expression in the field of clothing

design: texture (Bi-Colored edge）（Li, 2020） can

generate images with controllable texture and details

and interact with images; (2) e-commerce platform

through image editing technology to create Banner

charts related to business, and create virtual AI

characters for live broadcast. (3) In the medical field,

special image editing models can automatically

generate medical images that meet clinical needs; (4)

In the field of public safety, some image editing

models can improve the efficiency of the police and

the identification of children by editing the age

attributes of characters.

Text-based image editing follows text instructions

for image editing, allowing iterative refinement of

image editing capabilities with natural language.

With the development of the generative model, the

text conditional image model can synthesize the

images according to the text prompts, and the

irrelevant objects can be composed in a semantically

reasonable way, making the model flexible. Given

that text image editing has strict requirements for the

authenticity of the generated images and the

146

Wang, Y.

Research on Text Based Generative Image Editing.

DOI: 10.5220/0013241000004558

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 1st International Conference on Modern Logistics and Supply Chain Management (MLSCM 2024), pages 146-150

ISBN: 978-989-758-738-2

consistency with the text of the images, in addition to

the powerful generation power, the editing methods

must also have the ability to capture the high-

dimensional semantics of the target.

However, the text based generative image editing

literature review is relatively limited, in order to use

more convenient method based on text based

generative image editing, this paper based on text

generative image editing implementation method is

divided into through generative adversarial network

(GAN), CLIP, self regression and diffusion model

these four, and summarizes the four methods, analysis

of the advantages and disadvantages of various

methods. Finally, the shortcomings of the existing

text-based generative image editing methods are

summarized and analyzed, and the possible future

research directions are discussed.

2 OVERVIEW OF THE

TEXT-BASED GENERATIVE

IMAGE-EDITING METHODS

2.1 GAN-Based Text-Image Editing

Text-driven image editing based on GAN uses the

powerful generating ability of GAN to reverse the

real image into a controllable potential space and

obtain the target image through the forward

transmission. Xu（Xu, Zhang, Huang, et al., 2018)

proposed Attn-GAN, introduce the attention

generation network to focus on the relevant text in the

natural language description; Attn-GAN is capable of

synthesizing fine-grained in different areas of the

image by concentrating on the keywords in the user's

natural language description, and realize fine-grained

text-to-image generation through the attention

generation network. And the author presents an idea

for calculating the fine-grained image-text matching

loss for generator training by utilizing a deep

attention multimodal similarity model. The Attn-

GAN model achieved an initial score of 4.36 on the

CUB dataset, improving the initial score for the best

report on the CUB dataset by 14.14%.25.89 on the

more challenging COCO dataset, up 170.25%

compared to the best initial score. It is evident that

compared to the previous state-of-the-art methods , it

has a novel attention mechanism and has better results

in generating complex scenes.

Chen Ziyi (Cheng, 2023) uses the Transformer-

based neural network instead of the convolutional

neural network to introduce it into the GAN, and the

discriminator integrates the word-level discriminator

to give the generator more granular feedback. In the

task of generating images for text, the diversity of

training data is particularly important. In the

qualitative experiment, bird images were generated

on the two data sets of CUB and COCO. It can be seen

that this model well realizes the multi-modal fusion

of text and image. It can be seen that the introduction

of Transformer makes the text model have more

advantages in the two modal information extraction

of text and image.

GigaGAN (Kang, Zhu, Zhang, et al., 2023) is the

first GAN model that can train billions of parameters

on large-scale datasets. It proposes a dynamic

convolution kernel selection mechanism based on

text conditions to increase generator capacity and

expression capacity to increase inference time by

several orders of magnitude. Self-attention and cross-

attention are staggered between convolution layers to

support various potential space editing applications.

Multi-scale training is reintroduced to improve the

generation quality of image text alignment and low-

frequency details to generate high-resolution images.

The advantage of GAN-based text image editing

is that only one forward transmission is required in

the generation process, which takes less time than

other methods. Disadvantages: it is difficult to control

the output, the resulting image may not meet the

user's expectations; GAN needs to judge whether the

produced image belongs to the same category as other

images, so the generated image is not innovative; the

training is unstable and it is easy to crash.

2.2 Text-Image Editing Based on the

Diffusion Model

The diffusion model gradually introduces noise to the

image, thereby destroying the initial data distribution,

and uses the prediction noise and denoising by

learning to obtain the probability distribution of the

generated image. Over time, the model learns to

generate new images based on noisy input through

multiple iterations.

Imagen (Saharia, Chan, Saxena, et al., 2022) A

model for the diffusion of text into images is what it

is. Imagen built on understanding the text of large

transformer language model, and rely on the diffusion

model of high fidelity image generation, using the

frozen text encoder to get text features, text features

into the image diffusion model get 64x64 images,

after two super resolution diffusion model finally get

1024x1024 image. Imagen Usually operates directly

in the pixel space, but generally requires a lot of time,

and has a high reasoning cost.

Research on Text Based Generative Image Editing

147

Stable Diffusion (Rombach, Blattmann, Lorenz,

et al., 2022) The diffusion model can be trained with

limited resources, reducing both the complexity and

retaining the details of the image when training the

diffusion model, so that the generated image can

achieve high fidelity.

ERNIE-ViLG 2.0 (Feng, Zhang, Yu, et al., 2023)

is the first image text generation model in the Chinese

field. It focuses on guiding the model to pay more

attention to the alignment of image elements and text

semantic in the learning process, so that the model

can deal with the relationship between various objects

and attributes. All of the above work is guided

without the classifier, without training the classifier

to guide the model learning.

2.3 Text Image Editing Based on the CLIP

Model

The CLIP (Radford, Kim, Hallacy, et al., 2021) model

uses contrast learning to collect 400 million image

text pairs from the network for training, acquiring a

multimodal embedding space that can be utilized to

determine the semantic similarity between a text and

image.

Patashnik (Patashnik, Wu, Shechtman, et al., 2021)

combined the generating ability of StyleGAN

generator with the visual language ability of CLIP,

proposing three methods of combining CLIP with

StyleGAN. Text-guided latent optimization is the first

approach, and the CLIP model serves as the loss

network. The second option is the latent residual

mapper that has been trained for specific text prompts,

based on the starting point of the latent space, the

mapper produces local steps in the latent space.

Finally, the method of mapping text prompts to input

unknown direction in the StyleGAN style provides

control over the strength of operation and the degree

of entanglement.

CLIP as a loss network: CLIPDraw (Frans, Soros,

et al., 2022) The cosine distance between the text cue

features and the generated image features obtained

from CLIP is used to calculate loss. VQGAN-CLIP

(Crowson, Biderman, Kornis, et al., 2022) modulates

the intermediate potential vector by comparing the

similarity of the generated image to the specified text

in the CLIP model, thus generating images consistent

with the text description.

CLIP acts as a joint embedding space: StyleGAN-

NADA (Gal, Patashnik, Maron, et al., 2022) encodes

the differences between domains as the text

description direction of the CLIP embedded space,

using two generators, one generator remains frozen to

provide samples from the source domain, and the

other generator is optimized to generate images

different from the source domain in the CLIP space,

but separate adhesion and distortion during face

editing. HairCLIP (Wei, Chen, Zhou, et al., 2022) On

the basis of StyleCLIP, image and text features are

extracted by CLIP as conditions, and entanglement

information injection makes the properties separate to

different mappers.

No dot should be included after the section title

number.

2.4 Text Image Editing Based on the

Autoregressive Model

Early visual regression models executed visual

synthesis through pixel-by-pixel execution., however,

these methods are computationally costly on high-

dimensional data. With the rise of VQ-VAE (Oora,

Vinyals, Kavukcuoglu, et al., 2017), image visual

synthesis tasks can benefit from using large-scale pre-

training models, enabling autoregressive combination

with VQ-VAE or other methods to achieve better

image quality.

DALL-E (Ramesh, Pavlov, Gon et al., 2021)

borrows from Transformer (Vaswani, Shazeer,

Parmar, et al 2017) ideas to model image and text

autoregressions as a single data stream. The images

with the highest similarity were then screened by the

CLIP (Cheng,2023) classifier. However, DALL-E

(Ramesh, Pavlov, Gon et al., 2021) generates a

relatively small image size, and a large amount of

CPU memory is required to generate high-precision

images.

Parti (Yu, Xu, Koh, et al., 2022) is a two-stage

model composed of image marker and autoregressive

model: the first stage designs the training marker; the

second stage trains the autoregressive sequence of

image marker from text tag to sequence model. Text-

based generative image editing has become an

important part of the image editing field.

The advantages of autoregressive-based text

image editing are the advantages of clear probabilistic

modeling and stable training. However, Converting

the image into a token for autoregressive prediction is

necessary for this method, which requires a slow

inference speed and a large number of parameters.

Text image editing based on diffusion model belongs

to the likelihood model, so it is easier to train during

training, and the image generation is innovative,

which is more suitable for large-scale data set training

compared with GAN. Although iterative methods can

achieve stable training with simple goals, they can

generate high computational costs during inference.

MLSCM 2024 - International Conference on Modern Logistics and Supply Chain Management

148

3 EVALUATING INDICATOR

At present, specific evaluation indicators are lacking

in the field of image editing, so quantitative

evaluation indicators are employed to evaluate image

generation. Several quantitative evaluation indicators

have been proposed in the field of image generation,

which are used to measure the quality, authenticity,

and diversity of the generated images.

Generated image diversity evaluation index: the

diversity degree of the generated image can be

measured by it, and evaluate it by calculating the

degree of sample difference of the generated image.

Generated image authenticity evaluation index: It

has the ability to determine how closely the generated

image matches the actual image. Content consistency

evaluation index of the generated image: Ensure that

the content of the generated image is identical to that

of the input image. To measure the degree of

reconstruction error between the generated image and

the input condition, this index can be utilized.

4 CHALLENGES AND

PROSPECTS

At present, generative image editing based on text can

achieve good results, but the relevant research is still

in its initial stage, and there are still many valuable

research questions that need to be solved urgently.

1. Diversified image editing methods: Existing

image editing methods rely on text to generate images.

DragGAN (Pan, Tewari, Leimkuhler, et al., 2023)

proposes a new editing paradigm, based on point drag

and drop interactive image editing, which can drag

the content of the control points to the target points

by defining multiple control points in the image and

corresponding target points. This method uses

neighbor search technology and GAN discriminative

features to make precise handle point positioning

using feature-based motion supervision loss to guide

the handle points to the target point through the

intermediate feature map of GAN, ensuring that the

edited features remain stable around the control point.

In the future, diverse editing approaches will attract

wider academic attention in the research field.

2. Further fusion between modes: Although the

current generative image editing technology can

generate high-quality images, there are some

challenges in the control ability, especially when

using text to guide image generation. The difficulty

mainly stems from the divergent nature of the

generative model, leading to uncertainty between the

generative results and the user's expectations. In the

future, the closer integration of modes can be further

implemented in the following directions: text

combined with line draft, text combined with line

draft and physical example images, and text

combined with other conditions, including but not

limited to semantic map, depth map, normal vector

map, and other semantic correlation geometric

features.

3. Ensure that the image editing area and the non-

editing area transition is natural. In the physical

paradigm guiding image editing, the model is easy to

learn a simple mapping function, The network is

unable to comprehend the relationship between the

content of the reference image and the source image

due to this.. The transition area has obvious artifacts,

texture blur, structure distortion and other problems.

In the future, attempts can be made to smooth image

editing boundaries, including image priors, data

enhancement and classifier guidance. Therefore,

ensuring a smooth transition between boundaries

should be a key study of image editing.

5 CONCLUSION

This paper classifies the method of generative image

editing based on text and introduces the method, sorts

out the advantages and disadvantages of image

editing through different methods, and introduces the

evaluation indexes that can evaluate the quality of

image editing. In the future, in the field of image

editing, it is hoped to develop more image editing

methods, and also need to strengthen the control

ability of generative image editing. And develop

specific evaluation indicators in the field of image

editing.

REFERENCES

Li, Y., 2020. Clothing image generation and interactive

editing based on deep learning.

Xu, T., Zhang, P., Huang, Q., et al. 2018. AttnGAN: Fine-

Grained Text to Image Generation with Attentional

Generative Adversarial Network Proceedings of the

IEEE Conference on Computer Vision and Pattern

Recognition, 1316-1324.

Chen, Z., et al. 2023. Research on text-oriented image

editing algorithm. Jiangxi University of Science and

Technology.

Kang, M., Zhu, J., Zhang, R., et al. 2023. Scaling up gans

for text-to-image synthesis Proceedings of the IEEE

Conference on Computer Vision and Pattern

Recognition, 10124-10134.

Saharia, C., Chan, W., Saxena, S., et al. 2022. Photorealistic

Text-to-Image Diffusion Models with Deep Language

Research on Text Based Generative Image Editing

149

Understanding. Advances in Neural Information

Processing Systems, 35: 36479-36494.

Rombach, R., Blattmann, A., Lorenz, D., et al. 2022. High-

Resolution Image Synthesis with Latent Diffusion

Models Proceedings of the IEEE Conference on

Computer Vision and Pattern Recognition, 10684-

10695.

Feng, Z., Zhang, Z., Yu, X., et al. 2023. ERNIE-ViLG 2.0:

Improving Text-to-Image Diffusion Model with

Knowledge-Enhanced Mixture-of-Denoising-Experts

Proceedings of the IEEE Conference on Computer

Vision and Pattern Recognition. 10135-10145.

Radford, A., Kim, J., Hallacy, C., et al. 2021. Learning

transferable visual models from natural language

supervision international conference on machine

learning. PMLR, 8748-8763.

Patashnik, O., Wu, Z., Shechtman, E., et al. 2021.

StyleCLIP: Text-Driven Manipulation of StyleGAN

Imagery Proceedings of the IEEE International

Conference on Computer Vision, 2085-2094.

Frrans, K., Soros, L., 2022. WITKOWSKI O. Clipdraw:

Exploring text-to-drawing synthesis through language-

image encoders. Advances in Neural Information

Processing Systems, 35: 5207-5218.

Crowson, K., Biderman, S., Kornis, D., et al. 2022.

VQGAN-CLIP: Open Domain Image Generation and

Editing with Natural Language Guidance European

Conference on Computer Vision. Cham: Springer

Nature Switzerland, 88-105.

Gal, R., Patashnik, O., Maron, H., et al. 2022. StyleGAN-

NADA: CLIP-guided domain adaptation of image

generators. ACM Transactions on Graphics, 41(4): 1-

13.

Wei, T., Chen, D., Zhou, W., et al. 2022. Hairclip: Design

your hair by text and reference image Proceedings of

the IEEE Conference on Computer Vision and Pattern

Recognition,18072-18081.

Oord, A., Vinyals, O., Kavukcuoglu, K., 2017. Neural

discrete representation learning. Advances in neural

information processing systems.

Ramesh, A., Pavlov, M., Goh, G., et al. 2021. Zero-Shot

Text-to-Image Generation International Conference on

Machine Learning. PMLR, 8821-8831.

Vaswani, A., Shazeer, N., Parmar, N., et al. 2017 Attention

is All you Need. Neural Information Processing

Systems.

Yu, J., Xu, Y., Koh, J., et al. 2022. Scaling Autoregressive

Models for Content-Rich Text-to-Image Generation. A

Computational Study. arXiv:2206.10789[EB/OL].

Pan, X., Tewari, A., Leimkühler, T., et al. 2023. Drag your

gan: Interactive point-based manipulation on the

generative image manifold ACM SIGGRAPH 2023

Conference Proceedings.

MLSCM 2024 - International Conference on Modern Logistics and Supply Chain Management

150
