Advancements, Challenges and Future Prospects of Reinforcement

Learning in Healthcare

Meiyi Feng

School of Business, Macau University of Science and Technology, Macau Special Administrative Region, China

Keywords: Reinforcement Learning, Healthcare Application, Machine Learning.

Abstract: Reinforcement Learning (RL) has become a groundbreaking approach in machine learning, significantly

impacting healthcare by providing solutions to intricate decision-making challenges. This comprehensive

review examines the current state of RL in healthcare, focusing on dynamic treatment protocols, automated

diagnostic systems, resource allocation, as well as privacy and security issues. RL's ability to adapt and

optimize treatment plans dynamically, enhance diagnostic accuracy, and manage healthcare resources

efficiently underscores its potential to revolutionize clinical practices. However, the implementation of RL in

healthcare is fraught with challenges, including the need for extensive, high-quality datasets, difficulties in

interpreting complex models, and significant data privacy concerns. To mitigate these challenges, recent

innovations have been introduced. Transitional Variational Autoencoders (tVAEs) are used to generate

realistic patient data, enhancing the simulation capabilities of RL models. Federated learning frameworks

have been developed to ensure data privacy by enabling collaborative model training without sharing raw

data. Additionally, transfer learning and domain adaptation techniques improve the generalization of RL

models across diverse healthcare settings. This review provides a thorough analysis of these advancements

and their implications for healthcare, offering a detailed understanding of RL's current applications and

limitations. Future research directions are proposed to address existing challenges, aiming to ensure the robust,

transparent, and ethical integration of RL technologies into clinical settings, thereby maximizing their

potential to improve healthcare outcomes.

1 INTRODUCTION

Reinforcement Learning (RL) is an approach within

the field of machine learning based on reward

mechanisms, which has gained widespread attention

and application in the healthcare sector in recent

years. RL interacts with the environment to

continuously adjust strategies to achieve the goal of

maximizing long-term rewards. Its unique features

make it particularly suitable for addressing complex

decision-making problems in healthcare, such as

optimizing disease diagnosis and treatment plans (Yu,

Liu, Nemati & Yin, 2021; Coronato et al., 2020). In

healthcare, RL applications range from dynamic

treatment regimens to automated medical diagnosis.

For example, in chronic disease management and

intensive care, RL can help optimize treatment plans

by dynamically adjusting drug dosages and treatment

strategies to improve therapeutic outcomes (Yu, Liu,

https://orcid.org/0009-0003-7693-933X

Nemati & Yin, 2021; Coronato et al., 2020).

Additionally, RL is used in medical image analysis

and disease prediction, such as early detection of lung

cancer and vessel centerline tracking (Yu, Liu,

Nemati & Yin, 2021; Yang et al. 2024).

Despite the promising prospects of RL in

healthcare, several challenges and gaps remain in

current research. First, training RL models often

relies on large amounts of high-quality data, which

are costly and ethically challenging to obtain in the

healthcare domain (Yu, Liu, Nemati & Yin, 2021).

Second, existing RL models exhibit limitations in

handling multi-class imbalanced data, which may

lead to poor predictive performance for minority

classes in practical applications (Yang et al. 2024).

Moreover, the application of RL in healthcare faces

issues with model generalization. Many current

models perform well on specific datasets but have not

been validated across different patient populations

Feng, M.

Advancements, Challenges and Future Prospects of Reinforcement Learning in Healthcare.

DOI: 10.5220/0013205700004568

In Proceedings of the 1st International Conference on E-commerce and Artiﬁcial Intelligence (ECAI 2024), pages 39-44

ISBN: 978-989-758-726-9

and medical settings (Yu, Liu, Nemati & Yin, 2021).

Additionally, data privacy and security are crucial

research directions, especially when using distributed

learning methods like federated learning (Otoum et

al. 2021).

To address these research gaps, recent studies

have proposed several improvements. For instance,

Transitional Variational Autoencoders (tVAEs) are

used to generate more realistic patient trajectories,

enhancing the model's ability to simulate patient data.

Furthermore, RL frameworks combined with

federated learning are explored to strengthen data

protection and confidentiality measures in healthcare

IoT systems. This method allows model training

without sharing raw data, thereby protecting patient

privacy (Otoum et al. 2021).

This paper endeavours to offer an exhaustive

analysis of the main research findings and recent

advancements in the application of RL in healthcare.

This paper explores a wide range of RL applications,

including dynamic treatment regimes, automated

medical diagnosis, and healthcare resource

management. The review includes a detailed

examination of existing models, their limitations, and

the innovative solutions proposed to address these

challenges. Additionally, this review is structured to

explore the different facets and impacts of RL in

healthcare, With the aspiration of offering an all-

encompassing overview pertaining to the current

framework and prospective developments of RL

research in this significant sector.

2 METHODS

2.1 Introduction to Reinforcement

Learning

Reinforcement learning, representing a sophisticated

branch within the broader domain of machine

learning, emphasizes enabling an agent to learn

optimal decision-making through interactions with its

environment. The fundamental principle involves the

agent performing actions in different states with the

aim of optimizing aggregate rewards over an

extended period. Through the acquisition of feedback

in the guise of rewards or penalties corresponding to

its actions, the agent is steered towards formulating

an optimal policy.

Reinforcement Learning challenges are

commonly framed within the construct of Markov

Decision Processes (MDPs), which are defined by the

following key tuple 𝑆, 𝐴, 𝑃, 𝑅, 𝛾 (Amparore et al.,

2013):

- 𝑠: A set of states

- 𝑎: A set of actions

- 𝑃 : A transition likelihood matrix 𝑃(𝑠′|𝑠, 𝑎) ,

defining the likelihood of shifting to states from state

𝑠 after executing an action 𝑎.

- 𝑅 : A reward function 𝑅(𝑠, 𝑎) , providing the

instantaneous reward after action 𝑎 in state 𝑠.

- 𝛾 : A discount factor gamma in [0, 1], which

quantifies the significance of future rewards.

The agent's paramount goal is to devise a

strategy 𝜋(𝑠)

that maximizes the anticipated

aggregated reward, commonly known as the return.

This return is calculated as the sum of discounted

rewards accrued over time, reflecting both immediate

and future benefits:

𝐺



= 𝑅



+ 𝛾𝑅



+ 𝛾



𝑅



+ ⋯ =

∑

𝛾



𝑅







(1)

A commonly employed algorithm in RL is Q-

learning, which updates the value of state-action pairs

(Q-values) using the Bellman equation:

𝑄(𝑠, 𝑎) ←𝑄(𝑠, 𝑎)+𝛼[𝑅 + 𝛾𝑚𝑎𝑥



𝑄(𝑠′, 𝑎′) −

𝑄(𝑠, 𝑎)] (2)

where 𝛼 is the learning rate.

Through continuous interaction with its

environment, the agent progressively learns to select

actions that maximize long-term cumulative rewards.

This ability renders RL especially effective for

handling complex decision-making tasks across

various fields, such as healthcare.

2.2 Dynamic Treatment Regimes

2.2.1 Enhancing DRL with Transitional

Variational Autoencoders

In their study, Baucum and Khojandi introduce

Transitional Variational Autoencoders (tVAEs) to

improve Deep Reinforcement Learning (DRL)

applications in healthcare. Temporal Variational

Autoencoders (tVAEs) are sophisticated generative

neural network models designed to create an explicit

correlation between the configurations of clinical

parameters across sequential temporal intervals,

utilizing retrospective patient data. These models

facilitate the accurate reconstruction of temporal

patterns in clinical datasets by capturing the

underlying distributional dynamics over time. One

significant benefit of the tVAE model is its minimal

reliance on distributional assumptions while

maintaining consistent training and testing

architectures. By utilizing tVAEs, researchers can

create more realistic patient trajectories, facilitating

the development of effective treatment policies

(Baucum et al., 2020).

ECAI 2024 - International Conference on E-commerce and Artiﬁcial Intelligence

2.2.2 Closed-Loop Healthcare Processing

with DRL and Human Body

Simulators

Dai et al. propose a closed-loop healthcare processing

method using DRL combined with Deep Neural

Networks (DNNs) to build human body simulators.

These simulators can dynamically accept

interventions and produce observations. By

integrating conceptual embedding techniques with

DRL, the study investigates effective healthcare

strategies. The system specifically consists of a

virtual human physiological simulator seamlessly

integrated with an advanced Deep Reinforcement

Learning (DRL)-driven therapeutic intervention

module. The treatment module diagnoses latent

health states from high-dimensional radiographic

observations and selects therapeutic actions to restore

the simulated physiological model to an optimal

healthy condition, creating

a highly adaptive,

autonomously self-regulating healthcare informatics

architecture (Dai et al., 2022).

2.2.3 Personalized Healthcare

Coronato et al. provide a comprehensive review of

RL's role in healthcare, emphasizing its potential to

support personalized treatments in precision

medicine. The document explores several RL

applications, such as Dynamic Treatment Regimes

(DTRs) for chronic illnesses like HIV, oncology,

hypertension, and anemia. Utilizing the Sequential

Multiple Assignment Randomized Trial (SMART)

approach, RL aids in developing DTRs by employing

sequential decision-making processes that consider

patient responses at each stage of treatment. This

approach aims to personalize drug dosages and

treatment schedules to maximize therapeutic

outcomes and minimize adverse effects (Coronato et

al., 2020).

2.2.4 Dual-Agent RL Model for Optimizing

Dynamic Treatment Regimes

Blumrosen et al. propose a Dual-Agent

Reinforcement Learning (DaRL) model utilizing

medical and natural agents to optimize healthcare

interventions. The medical agent employs external

data and sensors to adjust treatments, while the

natural agent's rewards are based on internal

biological states like neural circuits and dopamine

levels. This integration enhances treatment accuracy

and efficiency, dynamically adjusting drug dosages

and reducing incorrect interventions by continuously

monitoring patient health (Blumrosen et al., 2019).

2.3 Automated Medical Diagnosis

2.3.1 Automated Diagnosis with Machine

Learning Models

Structured medical data, such as physiological

signals, images, and lab tests, benefit from RL

methods for tasks like feature extraction and image

segmentation. Key techniques include Q-learning for

prostate segmentation in ultrasound images, Trust

Region Policy Optimization (TRPO) for surgical

gesture segmentation, and Deep Q-Network (DQN)

for automatic landmark detection in MRI and CT

images, achieving robustness and accuracy.

Unstructured medical data, such as clinical notes and

reports, use RL techniques for diagnosis inference.

Key methods include DQN to improve diagnosis

accuracy using external evidence, adaptive online

learning combining supervised learning for risk

assessment and RL for decision making, and

symptom checking systems using DQN to enhance

efficiency and accuracy in diagnosis (Yu, Liu, Nemati

& Yin, 2021).

2.3.2 Deep Reinforcement Learning for IoT-

Enabled Smart Healthcare Systems

Jagannath et al. present a novel IoT-enabled smart

healthcare system that utilizes DRL to automate

medical diagnosis and decision-making. The system

architecture is composed of four tiers: patient data

acquisition, edge processing, data conveyance, and

cloud computation. Patient data is gathered through

various sensors in a Body Area Network (BAN) and

sent to data centers using IoT protocols. DRL

algorithms, like Deep Q-Network (DQN), are utilized

to conduct intricate data analysis and formulate

sophisticated diagnostic and therapeutic

determinations. The system was evaluated with

synthetic data from BAN sensors, showing high

accuracy in estimating hidden health states and

making decisions that closely align with those of a

physician. This method not only improves diagnostic

accuracy but also provides an efficient telemedicine

solution (Jagannath et al., 2022).

2.3.3 Dueling Double Deep Q-Network for

Multi-Class Imbalance in Healthcare

Applications

Yang, EI-Bouri et al. introduce a dueling double deep

Q-network (D-DDQN) to tackle the issue of multi-

class imbalance in reinforcement learning,

particularly for healthcare applications. The Q-value

Advancements, Challenges and Future Prospects of Reinforcement Learning in Healthcare

function is optimized through policy iteration. The

dueling architecture separates value and advantage

estimation, enabling better state-action

representation. Double deep Q-learning mitigates

overestimation by using separate networks for action

selection and value estimation. This approach is

particularly beneficial in healthcare for optimizing

resource allocation and improving diagnostic

accuracy in class-imbalanced medical datasets (Yang

et al., 2024).

2.4 Health Resources Allocation and

Scheduling and Health

Management

2.4.1 Enhanced Intelligent Clustering-

Oriented Routing Framework for 5G-

Integrated Smart Healthcare Solutions

Ahad et al. introduce an sophisticated Clustering-

based Routing Protocol (CRP-GR) that integrates

game theory with reinforcement learning to improve

resource allocation within a 5G-driven smart

healthcare paradigms. This protocol is designed to

optimize energy usage and extend network lifespan

by selecting energy-efficient cluster heads and

determining the optimal multipath routes for data

transmission. By using reinforcement learning, the

protocol adapts to the heterogeneous and dynamic

nature of smart healthcare networks, improving the

quality of service (QoS) and ensuring efficient use of

resources (Ahad et al., 2021).

2.4.2 EPRAM: Enhancing Smart Healthcare

with Fog Computing

Talaat et al. introduce the Effective Prediction and

Resource Allocation Method (EPRAM) within fog

computing architectures for advanced cognitive

healthcare applications enhances real-time resource

management and prediction using deep reinforcement

learning and probabilistic neural networks. EPRAM

achieves low latency, high resource utilization, and

effective load balancing, outperforming traditional

algorithms (Talaat et al., 2022).

2.5 Security and Privacy

2.5.1 Federated Reinforcement Learning-

Augmented Intrusion Detection

Framework for IoT-Enabled

Healthcare Ecosystems

Otoum et al. discuss the implementation of an

Intrusion Detection System (FRL-IDS) which is

grounded in Federated Reinforcement Learning

designed to enhance security and privacy in IoT-

enabled healthcare systems. The proposed model

leverages federated learning to maintain data privacy

by ensuring that data remains localized while only

sharing model parameters. This approach helps in

detecting and mitigating cyber intrusions without

compromising patient data. The system processes

data from multiple healthcare entities and updates the

global detection model collaboratively, ensuring

robust and secure data communication across the

network (Otoum et al., 2021).

2.5.2 Reinforcement Learning-Based

Trajectory Design for WPT-Enabled

UAV Healthcare Delivery

Merabet et al. explore the deployment of

reinforcement learning methodologies to enhance the

security and efficiency of healthcare delivery systems

utilizing Unmanned Aerial Vehicles (UAVs). The

proposed system employs Wireless Power Transfer

(WPT) technology, enabling UAVs t

to replenish

their power reserves mid-mission, thereby extending

their operational range. The RL algorithm is used to

design optimal UAV trajectories that minimize travel

time and energy consumption while ensuring secure

data transmission during deliveries. By implementing

RL, the system can dynamically adapt to changing

environmental conditions and potential security

threats, providing a reliable and secure healthcare

delivery solution (Merabet et al., 2022).

3 DISCUSSIONS

3.1 Limitations and Challenges

3.1.1 Interpretability

RL models, particularly deep reinforcement learning,

are often termed "opaque systems" owing to the

intricate and enigmatic nature of their decision-

making processes, which are not easily interpretable

by humans. In healthcare, interpretability is crucial as

medical professionals need to trust and understand the

reasoning behind a model's recommendations. The

lack of transparency can impede the adoption of RL

in clinical settings, as practitioners may be hesitant to

trust systems they cannot fully understand. This

challenge necessitates the development of methods

that can elucidate the internal workings of RL models,

making them more accessible and trustworthy.

ECAI 2024 - International Conference on E-commerce and Artiﬁcial Intelligence

3.1.2 Applicability

The application of RL in healthcare is still in its

infancy, and its practical use is limited by several

factors. Firstly, RL requires extensive amounts of

data to train models effectively, which can be a

significant barrier in medical domains where data is

often scarce and sensitive. Secondly, healthcare

environments are highly complex and dynamic,

making it difficult to design RL algorithms that can

adapt to such variability. Finally, the integration of

RL systems into existing healthcare workflows

presents another layer of complexity, as these systems

must be seamlessly incorporated into routine

practices without disrupting care delivery.

3.1.3 Privacy

Patient data privacy is a paramount concern in

healthcare. RL models require substantial amounts of

data, which raises significant privacy issues. Ensuring

that patient information is protected while using it to

train RL models is a complex task. Methods such as

data anonymization and secure data sharing protocols

are necessary but may not be sufficient to address all

privacy concerns. Additionally, the potential for data

breaches and the misuse of sensitive information are

ongoing risks that need to be continually managed

and mitigated.

3.2 Future Prospects

3.2.1 The Solutions for Interpretability

To address the interpretability challenge, integrating

expert systems with RL can provide a framework

where the decision-making process is more

transparent. Expert systems utilize heuristic-based

methodologies to emulate the cognitive judgment

capabilities of a domain-specific specialist. By

combining this with RL, it is possible to create

systems that not only learn from data but also

incorporate domain-specific knowledge that is easier

for practitioners to understand. Approaches such as

SHapley Additive exPlanations (SHAP) and Local

Interpretable Model-agnostic Explanations (LIME)

present promising methods for interpreting the

outputs of complex models. SHAP assigns an

importance value to each feature for a specific

prediction, thereby elucidating the influence of each

feature on the model's output. LINE approximates the

model locally with a simpler interpretable model,

providing insights into how the original model works

in the vicinity of the instance being predicted. These

methods can help demystify the decisions made by

RL algorithms, thereby increasing their acceptance

and trust among healthcare professionals.

3.2.2 The Solutions for Applicability

Cross-domain knowledge transfer and domain

specific adaptation hold significant potential for

enhancing the applicability of RL in healthcare.

Transfer learning entails using a model pre-trained in

one domain and fine-tuning it for a related but

different domain, thus reducing the data needed for

training in the new domain. This is especially

beneficial in healthcare, where data is frequently

scarce and costly to acquire. Domain adaptation, on

the other hand, helps models generalize across

various settings by aligning the data distributions

between the source and target domains. This ensures

that RL models can perform well even when there are

differences between the training data and the real-

world data they encounter in deployment. By

applying these techniques, RL models can become

more robust and effective in various healthcare

environments, from hospitals in urban centers to rural

clinics with different patient demographics.

3.2.3 The Solutions for Privacy

Federated learning offers a solution to the privacy

challenge by enabling the training of RL models

across multiple institutions without sharing raw data.

This approach allows models to learn from a broader

dataset while maintaining patient confidentiality. In

federated learning, data remains localized at each

institution, and only the model updates (gradients) are

shared and aggregated to improve the global model.

This decentralized approach to training models

mitigates the risks associated with centralized data

storage, such as data breaches and privacy violations.

By aggregating insights from decentralized data

sources, federated learning can help create more

comprehensive and accurate RL models. For

example, hospitals in different regions can

collaborate to train an RL model on patient treatment

outcomes without exposing sensitive patient data.

This collective learning process can result in more

effective and generalized healthcare solutions,

potentially accelerating the adoption of reinforcement

learning in the healthcare sector.

4 CONCLUSIONS

To summarize, this paper has provided a thorough

analysis of RL applications, including dynamic

Advancements, Challenges and Future Prospects of Reinforcement Learning in Healthcare

treatment protocols, automated diagnostic systems,

resource allocation, as well as privacy and security

measures. The primary contribution of this study lies

in highlighting RL's ability to enhance healthcare

outcomes. However, RL faces significant limitations,

such as data scarcity, model interpretability, and

privacy concerns. Future research should aim to

integrate expert systems for improved

interpretability, leverage transfer learning to enhance

applicability, and employ federated learning to

address privacy issues. These advancements will be

crucial in fully realizing the potential of RL in

healthcare, ensuring robust, transparent, and ethical

deployment in clinical settings.

REFERENCES

Ahad, A., Tahir, M., Sheikh, M. A., Ahmed, K. I., &

Mughees, A. 2021. An intelligent clustering-based

routing protocol (crp-gr) for 5g-based smart healthcare

using game theory and reinforcement learning. Applied

Sciences, 11(21), 9993.

Amparore, E. G., & Donatelli, S. 2013. States, actions and

path properties in Markov chains (Doctoral dissertation,

PhD thesis, University of Torino, Italy).

Baucum, M., Khojandi, A., & Vasudevan, R. 2020.

Improving deep reinforcement learning with

transitional variational autoencoders: A healthcare

application. IEEE Journal of Biomedical and Health

Informatics, 25(6), 2273-2280.

Blumrosen, G. 2019, October. Enhancing healthcare quality

with reinforcement learning modeling. In 2019 IEEE

SENSORS (pp. 1-4). IEEE.

Coronato, A., Naeem, M., De Pietro, G., & Paragliola, G.

2020. Reinforcement learning for intelligent healthcare

applications: A survey. Artificial intelligence in

medicine, 109, 101964.

Dai, Y., Wang, G., Muhammad, K., & Liu, S. 2022. A

closed-loop healthcare processing approach based on

deep reinforcement learning. Multimedia Tools and

Applications, 81(3), 3107-3129.

Jagannath, D. J., Dolly, R. J., Let, G. S., & Peter, J. D. 2022.

An IoT enabled smart healthcare system using deep

reinforcement learning. Concurrency and Computation:

Practice and Experience, 34(28), e7403.

Merabet, A., Lakas, A., & Belkacem, A. N. 2022, May.

WPT-enabled UAV trajectory design for Healthcare

delivery using reinforcement learning. In 2022

International Wireless Communications and Mobile

Computing (IWCMC) (pp. 271-277). IEEE.

Otoum, S., Guizani, N., & Mouftah, H. 2021. Federated

reinforcement learning-supported IDS for IoT-steered

healthcare systems. In ICC 2021-IEEE International

Conference on Communications (pp. 1-6). IEEE.

Talaat, F. M. 2022. Effective prediction and resource

allocation method (EPRAM) in fog computing

environment for smart healthcare system. Multimedia

Tools and Applications, 81(6), 8235-8258.

Yang, J., El-Bouri, R., O’Donoghue, O., Lachapelle, A. S.,

Soltan, A. A., Eyre, D. W., ... & Clifton, D. A. 2024.

Deep reinforcement learning for multi-class

imbalanced training: applications in

healthcare. Machine Learning, 113(5), 2655-2674.

Yu, C., Liu, J., Nemati, S., & Yin, G. 2021. Reinforcement

learning in healthcare: A survey. ACM Computing

Surveys (CSUR), 55(1), 1-36.

ECAI 2024 - International Conference on E-commerce and Artiﬁcial Intelligence
