A Brief Reﬂection on Trusted Platform Module Support

Martin Pirker

and Robert Haas

Institute of IT Security Research, St. P

olten University of Applied Sciences, Austria

Keywords:

Trusted Computing, TPM, TSS.

Abstract:

Trusted Computing and its Trusted Platform Module were introduced about 20 years ago. However, their

impact is still limited, only a small number of applications use a TPM, only a few people know that their

computer hosts one and what it can be used for. With the ongoing transition from now dominant Windows 10

to Windows 11, every common PC is required to have a TPM to run Windows 11. This short paper reﬂects on

the current environment and state of support for TPMs. It investigates a selection of TPMs, their features, and

surveyed the available software stacks to use them. It reports on the ﬁndings and the ﬁner details discovered

while using TPMs. Overall, this paper contributes to the ongoing discovery and learning about TPM v2, as it

will be inevitably a part of our computing with PCs future.

1 INTRODUCTION

We live a digital life—on our PCs, laptops, mobile

phones, tablets, or other devices. As the latter ones

increase their market share, traditional PCs (or lap-

tops) are still used for much of our computing needs.

For common end-users the standard PC-class device

is usually sold with and runs the operating system

Microsoft Windows. An observation here is that any

market majority has positive and negative qualities.

From a security point of view, if the majority of

users run the same operating system, it is important

that there are no grave security issues. Microsoft con-

tinuously invests resources and engineering effort to

harden Windows installations against attacks and ma-

licious modiﬁcations. To assess and enforce the state

of an operating system’s installation is not as easy as

it appears to an end-user. An end-user may just in-

stall and run a virus scanner; however more techni-

cally knowledgeable minds know that software that

searches for other software running on the same plat-

form is not enough. Once malicious software is able

to compromise an operating system early in the boot

process, it can (theoretically) hide very well, if not

perfectly, from detection attempts by other software.

With the introduction of Windows 11 (in 2021)

Microsoft now demands

all PCs to have a Trusted

Platform Module (TPM) v2 and UEFI secure boot.

https://orcid.org/0000-0003-3517-5479

https://www.microsoft.com/en-us/windows/window

s-11-speciﬁcations

This is an explicit requirement for a component, a

dedicated TPM hardware chip or an equivalent imple-

mentation, that provides certain security support func-

tions, in order to implement a higher level of security.

The Trusted Platform Module is not a new tech-

nology. It was devised more than 20 years ago and

version 1 has been available on the market for about

15 years, it being replaced in recent years with the

improved and reimagined major revision version 2.

Although TPMs and their security potential have

been ignored by many until now, with the expected

end-of-life of current standard Windows 10, its main

retirement date projected to be October 2025

and

Windows 11 succeeding it, in the near future every

PC will have a TPM v2. One could argue Microsoft

is pushing the TPM into the market by force, however

one could also see an improvement of security on ev-

ery PC as a result, which would be very impressive.

Contribution. This short paper reﬂects on the cur-

rent overall state of support for TPM v2. For this, we

do a brief survey on the availability of TPMs v2 with

hardware available to us, their revisions, and features.

Then, we examine what (open-source) software sup-

port is available to work with the TPM v2 already to-

day, both under Windows and Linux. We report on

the insights we learned and reﬂect on them.

Enterprise long-term support can be bought separately.

https://learn.microsoft.com/en-us/lifecycle/products/windo

ws-10-home-and-pro

890

Pirker, M. and Haas, R.

A Brief Reﬂection on Trusted Platform Module Support.

DOI: 10.5220/0012466400003648

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 10th International Conference on Information Systems Security and Privacy (ICISSP 2024), pages 890-898

ISBN: 978-989-758-683-5; ISSN: 2184-4356

Outline. The background Section 2 ﬁrst provides a

brief review on the history of Trusted Computing and

the Trusted Platform Module, then examines the se-

curity of TPMs, and well-known selected TPM-using

applications. Section 3 provides our detailed ﬁndings

on the TPM v2 ecosystem: The TPMs examined, a

survey of TSSs, and some learnings from using them.

The paper concludes in Section 4.

2 BACKGROUND

2.1 Trusted Computing History

More than 20 years ago, if PCs failed due to “com-

puter problems”, for example a computer virus that

infected all PCs of a hospital, this was worthy for a

report in the evening TV news (and was obviously a

novel problem for all depending on the care of the

hospital). PCs deployed everywhere would surely not

disappear again, but inevitably PCs would be used in

more and more applications.

Mass-market PC Security. The challenge of PC

reliability and security inspired the so-called Trusted

Computing Platform Alliance (TCPA). They ob-

served: Since e-Business runs on the PC, enhanc-

ing trust in the computing platform is an issue of

fundamental and growing importance for the PC in-

dustry. (The Trusted Computing Platform Alliance,

2000). Their insight was the augmentation of the

common PC platform with a hardware-based trust

component and integrating it into security processes.

They proposed the Trusted Platform Module (TPM),

a new hardware chip that provides basic primitives

supporting security such as public-key cryptography,

isolated key generation, cryptographic hashing, true

random-number generation, and more supplemental

functions useful in implementing and strengthening

trust and security.

TPM v1.x Generation. The ﬁrst version of

the TPM design ready for the mass-market was

v1.1b (Trusted Computing Platform Alliance (TCPA),

2002), published by the now renamed consortium

Trusted Computing Group (TCG). Software support

followed with the TCG Software Stack (TSS) Spec-

iﬁcation (Trusted Computing Group (TCG), 2003a).

The TSS speciﬁcation provides an architecture on

how to integrate the TPM, from the low-level chip,

over software layers with C-language speciﬁed func-

tions, up to an application that wants to take

advantage of the TPM. The TPM v1.2 followed

soon (Trusted Computing Group (TCG), 2003b) and

an update for the TSS (Trusted Computing Group

(TCG), 2006) a bit later.

Once TPM chips became more widely available,

integrated into common PC mainboards and therefore

easy to buy, hardware vendors also included a TSS

for the speciﬁc chip on the mainboard. Although the

TSS C-language functions themselves were speciﬁed

by TCG, this was still insufﬁcient for code to “just

recompile” with a TSS provided by a different vendor

than it was originally developed for.

There were also two major open-source efforts to

provide a full TSS, they enabled open learning, under-

standing, and experimenting with Trusted Computing

and the TPM: 1) The TrouSerS

effort, a TSS written

in C, and the Trusted Java

effort, a TSS (and more

components beyond that) implemented in Java.

This ﬁrst generation of TPMs and related tech-

nologies were not perfect, as to be expected from

novel, complex security technologies. The speciﬁca-

tions were not unambiguous enough.

Consequently,

the TCG established a certiﬁcation program (Trusted

Computing Group (TCG), 2009), where vendors

could verify security and functional compliance of

their products that they developed. The ﬁrst discrete

TPM chip was certiﬁed at the end of 2009.

TPM v2.x Generation. The TPM v1.2 was for

about 15 years the standard, however the 1) known

issues, subtle speciﬁcation imprecisions and incom-

patibilities needed to be ﬁxed, 2) cryptography ad-

vanced and the core algorithms of the TPM v1.2,

RSA-based keys and SHA-1 as core hash function,

were no longer state of the art (secure), and 3) tech-

nological progress such as hardware virtualization

common PCs posed new challenges, such as the trans-

parent sharing of one hardware TPM between differ-

ent virtual machines. The TCG introduced the TPM

v2.0 revision. (Trusted Computing Group, 2013). It

was a major redesign of its commands and data struc-

tures; it tackles the known problems and also enables

new types of applications and scenarios.

https://trousers.sourceforge.net/

https://trustedjava.sourceforge.net/

For example, see Trusted Java TSS ﬁle src/jtss tsp

/src/iaik/tc/tss/impl/java/tsp/TcPcrCompositeInfo.java,

function getNumPcrs() for ﬁguring out the number of

PCRs on a TPM v1.2. Practical testing with different TPM

implementations showed that a special case for one vendor

was required.

https://trustedcomputinggroup.org/membership

/certiﬁcation/tpm-certiﬁed-products/

In the 2005/2006 timeframe both Intel and AMD intro-

duced hardware virtualization support into their processors.

A Brief Reﬂection on Trusted Platform Module Support

891

Still, the TPM v2 sees limited application use to-

day, although right from the start accompanying lit-

erature from authors close to the v2 speciﬁcation pro-

cess was available, for example (Proudler et al., 2014)

and (Arthur et al., 2015).

2.2 TPM v2 Applications

As a TPM is usually afﬁxed to a certain platform, this

predestines its use for platform related applications.

Bitlocker. One well-known application in the Win-

dows operating system is Bitlocker, a full disk encryp-

tion (FDE) software with the ability to harness TPM

functionality. Bitlocker uses a Volume Master Key

(VMK) and a Full Volume Encryption Key (FVEK),

which is protected by the VMK, for each encrypted

volume. If a measurement chain of the boot process is

available, a TPM key can be sealed to the correct boot

state. The TPM-based key is then used to encrypt the

VMK.

An optional PIN-code can provide additional

authentication, in addition to the required unmodiﬁed

boot process. A separate recovery key can be con-

ﬁgured to bypass all this in case of TPM failure or a

forgotten PIN.

LUKS. On Linux, the Linux Uniﬁed Key Setup

(LUKS) in cooperation with the dm-crypt subsystem

provides full disk encryption. The architecture is sim-

ilar to Bitlocker, by using an equivalent approach to

the VMK and FVEK. However, additional software

components for the use of TPM keys with LUKS are

needed. The Systemd

suite contains the tooling to

interact with the TPM: Sealing and unsealing keys

for LUKS use, also including support for sealed TPM

keys with an additional PIN.

2.3 TPMs and Security

The introduction of TPMs for common PCs in order

to enhance their security and their expected use, for

example in the operating system Windows 11, might

convey a “with the TPM everything is secure” think-

ing. This TPM chip magically solves security issues.

However, for a TPM to be a mass-market device cer-

tain trade-offs had to be accepted.

https://blog.scrt.ch/2023/09/15/a-deep-dive-into-tpm-

based-bitlocker-drive-encryption/

https://web.archive.org/web/20230709213454/https://

learn.microsoft.com/en-us/previous-

versions/windows/it-pro/windows-server-2008-R2-and-

2008/cc732774%28v=ws.10%29

https://media.ccc.de/v/all-systems-go-2023-186-

linux-tpms

Physical Attacks. If one has physical access to a

platform with a TPM, then a TPM can be inﬂuenced

to a certain degree. Some selected examples:

In 2010, an attack was demonstrated that involves

removing layers and reverse engineering of a dTPM

chip to probe speciﬁc locations inside. It shows that

physical attacks, despite intricate protection schemes

such as light sensors inside the chip, may eventually

lead to success, given enough time (several months)

and equipment (a focused ion beam microscope).

(Tarnovsky, 2010)

In 2013, a paper describes attacks on dedicated

hardware TPMs (dTPMs) v1.2 via LPC and I

busses for embedded systems, by modifying clock cy-

cle signals and selective resets of the TPM or plat-

form. The approach requires some hardware and re-

sembles a Man-in-the-Middle attack. The result is a

broken chain of trust during boot, but without com-

promise of TPM secrets. (Winter and Dietrich, 2013)

A blog article

from 2019 describes the process

to attack a dTPM v2 chip of a Surface Pro 3, by sol-

dering an FPGA to the LPC connection. This allows

reading the trafﬁc coming from the TPM. The result

is a decoded Bitlocker VMK, bypassing the FDE. The

attack can be mitigated by conﬁguring TPM+PIN in

Bitlocker. A TPM v2 supports encrypted parameters,

but this functionality was not used by Bitlocker.

Another blog article

from 2021 describes a sim-

ilar attack on a dTPM v2 of a Lenovo Laptop, via the

SPI bus. The laptop had the CMOS chip on the same

SPI bus, which allowed easier physical connection.

The result was a broken FDE and access to the OS.

In 2020, a paper described a timing-based side

channel attack on Intel fTPM and STMicroelectron-

ics dTPMs by reading the clock cycle count right be-

fore and after a TPM command is executed. The

attack speciﬁcally targets the elliptic curve signa-

ture schemes in the TPM v2 standard. The authors

managed to break VPN authentication relying on the

TPM, remotely over network, by analysing replies to

crafted trafﬁc. (Moghimi et al., 2020)

In May 2023, (Jacob et al., 2023) presented a

novel way to abuse voltage fault injection attacks,

which is a previously released exploit of the AMD

Secure Processor, to expose the internal fTPM state.

This attack demonstrates that physical attacks are also

available for AMD fTPMs.

Firmware Bugs. A modern TPM chip is a proces-

sor core that executes a ﬁrmware that implements

https://pulsesecurity.co.nz/articles/TPM-snifﬁng

https://dolosgroup.io/blog/2021/7/9/from-stolen-

laptop-to-inside-the-company-network

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

892

the functions of a TPM—and naturally, this ﬁrmware

may be defective.

For example, in 2017 it was discovered (CVE,

2017) that one TPM vendor’s ﬁrmware mishandled

RSA key pair generation, meaning the RSA key pairs

were of insufﬁcient quality and made it feasible for an

attacker to recover the private key corresponding to a

public key in certain cases.

In 2023 it was discovered that the reference im-

plementation in the TPM 2.0’s Module Library con-

tained an out-of-bounds write vulnerability (CVE,

2023a) and an out-of-bounds read vulnerability

(CVE, 2023b). All products that used this C code as

model for their own implementation inherited these

problems (and would subsequently require a ﬁrmware

update and reset to factory default values).

With the addition of ﬁrmware-based TPM func-

tionality (fTPM) to AMD’s Ryzen 2xxx CPUs and

newer models, an issue in the implementation resulted

in a performance and stability impact, by intermit-

tent freezings of the whole system (“stutter”). These

freezes were noticeable by end users, who then made

the connection between the fTPM and the issue dur-

ing troubleshooting. As explained by AMD (AMD,

2022) the issue is a result of extended SPI-attached

memory transactions. While end user reports ap-

peared already in mid 2021,

AMD only provided

a solution around Q2 2022.

3 AN EXPLORATION OF THE

TPM V2 ECOSYSTEM

3.1 Software Support

TPM Simulators. There are two software simula-

tors that resemble a hardware TPM chip and therefore

are invaluable tools to develop and debug code that is

communicating with a TPM, as a TPM’s internal cur-

rent state can be examined in detail.

1) Microsoft provides an Ofﬁcial TPM 2.0 Refer-

ence Implementation,

which is true to its name, the

ofﬁcial TCG reference implementation of the TPM

2.0 Speciﬁcation. These are the same fragments of

code that are part of the TPM v2 speciﬁcation docu-

ments, as they are available from the TCG homepage.

2) An alternative implementation of the TCG

TPM 2.0 speciﬁcation is IBM’s Software TPM 2.0.

It is “based on the TPM speciﬁcation Parts 3 and 4

For example in forum: https://linustechtips.com/topic

/1353904-amd-ftpm-causing-random-stuttering/

https://github.com/microsoft/ms-tpm-20-ref

https://sourceforge.net/projects/ibmswtpm2/

source code donated by Microsoft, with additional

ﬁles to complete the implementation.“

TPM Software Stack. According to Wikipedia

there are currently 5 noteworthy open-source TPM

software libraries. Their features and APIs vary:

1) The Trusted Computing Group’s (TCG) TPM2

Software Stack (TSS)

project is the ofﬁcial imple-

mentation of a TSS as envisioned by the TCG. It

is open-source, permissively BSD-2 licensed, which

makes it easy to integrate in projects. It is also full-

featured, meaning it is the only TSS project that im-

plements all layers, from a low-level System-API that

resembles low-level TPM chip commands basically

1:1, up to a high-level Feature API that enables a sim-

ple(r) usage of the TPM for common use cases.

This TSS is the standard package that is usually

included in Linux distributions. The included IN-

STALL documentation suggests Windows support,

although the included VS solution appears outdated

and required some tweaks for the libraries/DLLs to

build under Windows at our time of testing.

2) IBM’s TPM 2.0 TSS

is another implementa-

tion in C of a TSS-like library to talk to the TPM. It

provides a 1:1 mapping of all TPM commands and

some abstractions on top, plus sample CLI programs

to exercise each command.

3) The TPM Software Stack from Microsoft Re-

(TSS.MSR) project appears to be an ambi-

tious project to auto-generate the interfacing to the

individual TPM commands for multiple programming

languages. The project contains the TPM commands

extracted from the speciﬁcations as XML data and a

generator then creates code for the languages C(++),

JavaScript/Typescript, Java, C#/NET and Python. We

are unsure about the state/maintenance of the project

and the quality/completeness of the individual lan-

guages/generated code. The last check-in of code in

the code repository was in the middle of 2022, and

for example for Python there are more actively main-

tained projects like tpm2-pytss.

4) The wolfTPM

effort is a portable, open-

source (GPL v2) TPM 2.0 stack implemented in C

and designed for embedded use. It has native support

for Linux, Windows, and smaller platforms like Rasp-

berry Pi, STM32, and many more. Again, all TPM

https://en.wikipedia.org/wiki/Trusted Platform Module

#TPM software libraries

https://github.com/tpm2-software/tpm2-tss

https://sourceforge.net/projects/ibmtpm20tss/

https://github.com/microsoft/TSS.MSR

This projects wraps the TCG’s TSS into a Python

wrapper https://github.com/tpm2-software/tpm2-pytss

https://www.wolfssl.com/products/wolftpm/

A Brief Reﬂection on Trusted Platform Module Support

893

commands and example code for common use cases

are provided.

5) As another non-C implementation, go-tpm

a Go library that communicates directly with a TPM

device on Linux or Windows machines. It does not

implement the entire speciﬁcation; however, the pro-

vided examples cover common use cases.

TPM Access Multiplexing. There is usually only

one TPM hardware chip on a platform, and a TPM is

usually a rather resource constrained device. If multi-

ple applications want to use a TPM, access to it must

be managed so that each applications gets access to

the resources as required, and if necessary, data is

swapped in or out from the TPM on demand. Both

Windows and Linux must solve this.

Windows. On the Windows platform, Microsoft in-

troduced an abstraction layer between applications

and the TPM: The Windows TPM Base Services

were introduced with the Windows Server 2008 and

Windows Vista generation as a system service. The

TBS schedules calling applications so that they coop-

eratively get TPM access. Applications work with vir-

tual resources provided by the TBS, for example vir-

tualized key handles, but the TBS then transparently

manages these to map to the actual physical resources

of the underlying TPM.

Linux. On the Linux platform the so-called TPM2

Access Broker & Resource Manager system dae-

mon implements the respective TCG speciﬁcation. It

swaps objects, sessions, and sequences in and out of

the TPM’s limited resources as needed and handles

multi-process synchronization of access to the TPM.

A process accessing the TPM can be guaranteed that it

will be able to complete a TPM command without in-

terference from other competing processes. (Trusted

Computing Group, 2019).

3.2 TPM Models

In order to get a better understanding on the availabil-

ity of TPMs v2 (and their supported speciﬁcation revi-

sion), we tested computers available to us. We chose

models of different hardware generations, if possible.

Unfortunately, the PCs available to us were mainly

Intel-based platform, only one AMD-based, and fur-

ther two kinds of virtual machines.

https://github.com/google/go-tpm

https://learn.microsoft.com/en-

us/windows/win32/tbs/tpm-base-services-portal

We discovered the discrete hardware TPM chips

were solely provided by Inﬁneon (IFX). Some plat-

forms contained Intel’s ﬁrmware-based TPM, which

is part of Intel’s Platform Trust Technology (PTT),

and AMD’s ﬁrmware TPM (ftpm)

Table 1 is an overview of our collected data.

Table 1: Overview of hardware platforms queried for their

TPM’s self-reported properties. Revision is TCG’s TPM

speciﬁcation version, errata format is day of year/year.

platform rev errata chipmodel, by vendor

VMWare 17 1.16 15/2016 VMware TPM2, by VMW

Virtualbox 7 1.64 75/2021 SW TPM, by IBM

Intel GeminiLake 1.38 352/2019 Intel, by INTC

AMD Ryzen 3000 1.38 61/2018 AMD, by AMD

Intel 8

generation 1.16 265/2016 SLB9670, by IFX

Intel 9

generation 1.38 8/2018 SLB9670, by IFX

Intel 10

generation 1.38 303/2019 Intel, by INTC

Intel 10

generation 1.38 8/2018 SLB9670, by IFX

Intel 13

generation 1.38 352/2019 ADL, by INTC

We observe several things:

1) The quite new 13

generation Intel CPU-based

PC uses an integrated Intel ﬁrmware-based TPM that

is still based on speciﬁcation revision 1.38, and not

on the newest TPM speciﬁcation revision 1.59. The

reported chipmodel ADL refers to previous 12

gen-

eration, and indeed the chipset in this PC was a B660,

originally released for earlier Alder-Lake (12

gen)

and the fTPM runs on the chipset, not the CPU.

2) The newest reported revision is 1.64, by the

TPM of Virtualbox 7, although the TCG has not pub-

lished such a speciﬁcation, yet? When we check the

sources of the SW TPM (see Section 3.1), indeed in

TpmTypes.h it is 1.64. We assume a forthcoming re-

vision is already being implemented and tested via

this TPM software simulator, which is then integrated

as a software TPM by the Virtualbox project.

3) The TPM errata levels vary wildly. The for-

mat of “day of year/year” is uncommon, but for ex-

ample for version 1.38 there are really 10 errata docu-

ments

readily available from the TCG’s TPM page.

The matching errata are identiﬁed by the datestamps.

How and how much these small patches to the speci-

ﬁcation and resulting slightly different behaviours of

TPMs affect practical deployment and use, we are not

experienced enough to assess.

4) VMWare Workstation 17 Pro, released end of

2022, introduced a new virtual Trusted Platform Mod-

ule 2.0 support, to support the Windows 11 operating

PTT does not run on the main CPU, but instead on

the Intel’s Management Engine (Intel ME), an embedded

microcontroller integrated on some Intel chipsets.

The AMD fTPM runs on Zen’s dedicated Platform Se-

curity Processor (PSP).

Errata 1.0 to 1.13, seemingly not all revs are published.

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

894

system.

We only had brief access to this setup, and

now looking at this result in the context of the other

platforms we tested, we would like to take another,

closer look. However, unfortunately we were unable

to do this in time for this paper.

3.3 Algorithms of TPMs

One of the learnings from the TPM 1.x generation was

its hardwired use of only a restricted set of cryptog-

raphy. As the years pass, cryptographers are creative

and invent new attacks to weaken and even break es-

tablished algorithms and protocols. To our knowledge

the TPM v1 was never broken due to cryptography

(see also Section 2.3), however its ﬁxation on mainly

RSA and SHA-1 in its design was unfortunate.

Therefore, the TPM v2 introduced algorithm

agility throughout its data structures and the TCG

speciﬁed (Trusted Computing Group, 2023a) so far

about 60 algorithms (respectively ALG ID constants)

for various operations used by a TPM.

As an example, Table 2 lists the algorithms we

found supported on our Intel B660-based platform

fTPM (see Section 3.2). This list is quite extensive,

with 30 different algorithms, about half of the ones

the TCG has speciﬁed. In our testing the SW TPM

used by Virtualbox offered the most, 33 algorithms in

total. In contrast, an Inﬁneon hardware TPM provides

only 19, see Table 3. We interpret this due to the lim-

ited resources on a hardware chip, whereas a software

implementation is not as constrained.

3.4 TPM Applications not in C

As discussed in Section 3.1, the TCG Software Stack

speciﬁcation is primarily C-language based. Natu-

rally, programs are not solely implemented in C, other

programming languages also want to communicate

with the TPM. The already mentioned TSS.MSR and

the tpm2-pytss projects provide for that.

An interesting aspect are the typical errors that

happen in the C-language, see for example the out-of-

bound reads/writes in Section 2.3. Instead of a TSS

in C, one candidate is the modern (and rising in popu-

larity) programming language Rust, which claims on

its homepage:

A language empowering everyone to

build reliable and efﬁcient software.

At time of writing there is a project that wraps the

ofﬁcial TCG C-based TSS and provides a Rust API,

https://docs.vmware.com/en/VMware-Workstation-

Pro/17.0/rn/vmware-workstation-170-pro-release-

notes/index.html

https://www.rust-lang.org/

Table 2: Algorithms implemented on the fTPM that is

part of Intel’s B660 chipset. asy = asymmetric algorithm,

sym = symmetric algo., hash = hash algorithm, obj = an ob-

ject type, sign = a signing algorithm, enc = an encryption

mode, met = a method such as a mask generation function.

id algorithm Asy Sym Hash Obj Sign Enc Met

0x01 Rsa asy — — obj — — —

0x04 Sha1 — — hash — — — —

0x05 Hmac — — hash — sign — —

0x06 Aes — sym — — — — —

0x07 Mgf1 — — hash — — — met

0x08 KeyedHash — — hash obj sign enc —

0x0a Xor — sym hash — — — —

0x0b Sha256 — — hash — — — —

0x0c Sha384 — — hash — — — —

0x12 Sm3 256 — — hash — — — —

0x13 Sm4 — sym — — — — —

0x14 RsaSsa asy — — — sign — —

0x15 RsaEs asy — — — — enc —

0x16 RsaPss asy — — — sign — —

0x17 Oaep asy — — — — enc —

0x18 EcDsa asy — — — sign — met

0x19 EcDh asy — — — — — met

0x1a EcDaa asy — — — sign — —

0x1b Sm2 asy — — — sign — met

0x1c EcSchnorr asy — — — sign — —

0x20 Kdf1Sp800 56a — — hash — — — met

0x22 Kdf1Sp800 108 — — hash — — — met

0x23 Ecc asy — — obj — — —

0x25 SymCipher — — — obj — — —

0x3f Cmac — sym — — sign — —

0x40 Ctr — sym — — — enc —

0x41 Ofb — sym — — — enc —

0x42 Cbc — sym — — — enc —

0x43 Cfb — sym — — — enc —

0x44 Ecb — sym — — — enc —

Table 3: Algos implemented on an Inﬁneon hardware TPM.

id algorithm Asy Sym Hash Obj Sign Enc Met

0x01 Rsa asy — — obj — — —

0x04 Sha1 — — hash — — — —

0x05 Hmac — — hash — sign — —

0x06 Aes — sym — — — — —

0x08 Keyedhash — — hash obj sign enc —

0x0a Xor — sym hash — — — —

0x0b Sha256 — — hash — — — —

0x14 RsaSsa asy — — — sign — —

0x15 RsaEs asy — — — — enc —

0x16 RsaPss asy — — — sign — —

0x17 Oaep asy — — — — enc —

0x18 EcDsa asy — — — sign — met

0x19 EcDh asy — — — — — met

0x1a EcDaa asy — — — sign — —

0x20 Kdf1Sp800 56a — — hash — — — met

0x22 Kdf1Sp800 108 — — hash — — — met

0x23 Ecc asy — — obj — — —

0x25 SymCipher — — — obj — — —

0x43 Cfb — sym — — — enc —

the TSS 2.0 Enhanced System API Rust Wrapper.

It builds on the C-based code, with an automatically

generated foreign function interface (FFI) layer and

adds a custom Rust data types-based API on top.

The advantage is that Rust is e.g. stricter in check-

ing of data types as C and thus certain errors do not

https://github.com/parallaxsecond/rust-tss-esapi

A Brief Reﬂection on Trusted Platform Module Support

895

happen in Rust. A disadvantage is that certain API

calls turn out to be unergonomic. For example, a

query call to determine the maximum size of a digest

that can be produced by a certain TPM is:

let res : Result = context.get_capability(

CapabilityType::TpmProperties,

TPM2_PT_MAX_DIGEST, 1);

The expected return value is the number of bytes, an

integer. However, the returned data structure is:

Ok(

(

TpmProperties(

TaggedTpmPropertyList {

tagged_tpm_properties: [

TaggedProperty {

property: MaxDigest,

value: 48,

true,

)

It is a Rust Result (call succeeded = Ok), encapsu-

lating an enum CapabilityData, more speciﬁcally a

TpmProperties(TaggedTpmPropertyList), containing

one TaggedProperty. It is the MaxDigest we asked

for and the value is 48 (bytes) on this speciﬁc TPM.

While strong API data typing reduces errors, we

wonder whether a design is possible where the trade-

off between convenience of use and robustness is bet-

ter? This Rust-based API is still a work in progress,

as for example Windows support is still missing, but

we are looking forward on how this project develops

further.

3.5 TPMs and Certiﬁcates

The non-volatile storage of a TPM, meaning data

stored in a TPM’s memory that survives power loss,

is very limited. Certain data has to be kept inside the

TPM, such as the unique Endorsement Key (EK). The

EK can be thought of as the unique identity of a spe-

ciﬁc TPM. The public EK alone is not sufﬁcient, an

EK certiﬁcate supplies further information about the

EK. A manufacturer issued EK certiﬁcate is then the

evidence that a speciﬁc public key belongs to hard-

ware TPM (and not to a software simulated TPM).

We surveyed the non-volatile storage of our TPMs

for EK certiﬁcates. They have speciﬁc handle num-

bers in the 0x01c0xxxx range (Trusted Computing

Group, 2022). The most commonly found ones are

just individual EK certiﬁcates, in RSA and ECC vari-

ants. An example here from our oldest IFX TPM:

0x01c00002 = RSA 2048 EK Certificate

0x01c0000a = ECC NIST P256 EK Certificate

Modern TPMs have more storage and also have

supplemental certiﬁcates to build the certiﬁcate

chain(s) for validation:

0x01c10102 = EK Certificate Chain

0x01c10103 = EK Certificate Chain

0x01c10104 = EK Certificate Chain

0x01c10105 = EK Certificate Chain

Some TPMs NV-storage contained nothing at all

by default, such as the TPM of the Virtualbox TPM,

which makes sense as it is a software simulator TPM.

However, the NV storage was also empty on our

GeminiLake platform with its Intel PTT-based TPM.

The B660 chipset TPM provided the most vari-

ants, one RSA-based and two ECC-based:

0x01c00002 = RSA 2048 EK Certificate

0x01c0000a = ECC NIST P256 EK Certificate

0x01c00016 = ECC NIST P384 EK Certificate(H-3)

The P384-one was uncommon and the Rust TSS

(Section 3.4) did not initially support this handle in its

API, to be able to retrieve it. However, a recent patch

added additional certiﬁcate handle constants, as listed

in the EK Credential Proﬁle Speciﬁcation.

3.6 Additional Insights

Detailed Parameters for Algorithms. The tables

presented in Section 3.3 give an overview on the avail-

able algorithms, but for practical use this is not sufﬁ-

cient. While testing the TPMs, we found that AES as

a standard algorithm for symmetric en-/decryption is

always supported, but not all key sizes are.

The explanation for this behaviour can be found in

TCG’s PC Client Platform TPM Proﬁle (PTP) Spec-

iﬁcation (Trusted Computing Group, 2023b), which

speciﬁes for the PC platform the features to be imple-

mented (a subset of all the features in the full TPM

speciﬁcation). In the PC Client TPM Algorithms ta-

ble a note states TPM ALG AES: SHALL support for

128- and 256-bit keys and TPM ALG CFB at a mini-

mum. [...] AES 256 support is mandatory as of PTP

1.03. Consequently, the ﬁrst TPMs for PCs followed

the initial version of the PTP speciﬁcation, where

AES-256 was not mandatory to be implemented.

This matches our observed behaviour that e.g.

for the command TPM2 StartAuthSession the sym-

metric block cipher has to be TPM ALG CFB, and

AES 128 CFB worked on all tested TPMs, but

AES 256 CFB did not work on all of them.

Low-level TPM Interactions. Section 3.4 already

showed an example of trade-offs to be made when

programming the TPM. Another aspect of a strict API

that implements all TCG speciﬁc commands and data

start auth session: value is out of range or is not cor-

rect for the context (associated with parameter number 4)

Parameter 4 is symmetric, meaning the algorithm and key

size for parameter encryption.

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

896

structures is that it does not implement vendor spe-

ciﬁc commands and data types.

Our selection of TPMs tested was limited, how-

ever a closer look at the wolfTPM (see Section 3.1)

source, ﬁle tpm2.h speciﬁcally, suggests TPM ven-

dors do indeed add custom additional low-level com-

mands to their TPMs. This makes sense, as e.g. TPMs

for embedded projects surely beneﬁt from additional

commands speciﬁc for embedded use. However, a

TSS must offer these.

A strictly typed API, where the command codes

are an enum(eration) of the ofﬁcially speciﬁed TPM

commands, and data input and outputs are strictly de-

ﬁned structs, may not be as easily adapted for these

low-level commands. These extra commands for each

vendor must be implemented in the TSS. So far, we

have only found wolfTPM to support them.

4 CONCLUSION

Originally this paper was motivated by the upcoming

requirements for a TPM v2 in every PC in the near

future, driven by Windows 11. Once we identiﬁed

candidate PCs in our working environment, we were

motivated to explore the ﬁner differences between the

individual hardware and software TPM implementa-

tions. Further, as Wikipedia only provides a high-

level overview, we set out to explore the support soft-

ware stacks, their trade-offs and how to use the TPM

v2 in different languages.

This paper provides an intermediate review, a

snapshot of the ecosystem, a reﬂection of our insights

and experiences made. This is still a work in progress

and not an exhaustive survey. As we discovered, the

TSSs are a work in progress, too. This short paper

is another contribution in the discovery and learning

about TPM v2.

ACKNOWLEDGEMENTS

The work presented in this paper was done at the Josef

Ressel Center for Blockchain Technologies and Se-

curity Management, St. P

olten University of Applied

Sciences, Austria.

The ﬁnancial support by the Christian Doppler

Research Association, the Austrian Federal Ministry

for Digital, and Economic Affairs and the National

Foundation for Research, Technology and Develop-

ment is gratefully acknowledged.

REFERENCES

AMD (2022). Intermittent System Stutter Experienced

with fTPM Enabled on Windows® 10 and 11.

https://www.amd.com/en/support/kb/faq/pa-410.

Arthur, W., Challener, D., and Goldman, K. (2015). A Prac-

tical Guide to TPM 2.0: Using the Trusted Platform

Module in the New Age of Security. Apress Berkeley.

https://doi.org/10.1007/978-1-4302-6584-9.

CVE (2017). CVE-2017-15361. https://cve.mitre.org/cgi-

bin/cvename.cgi?name=CVE-2017-15361.

CVE (2023a). CVE-2023-1017. https://cve.mitre.org/cgi-

bin/cvename.cgi?name=CVE-2023-1017.

CVE (2023b). CVE-2023-1018. https://cve.mitre.org/cgi-

bin/cvename.cgi?name=CVE-2023-1018.

Jacob, H. N., Werling, C., Buhren, R., and Seifert, J.-P.

(2023). faulTPM: Exposing AMD fTPMs’ Deepest

Secrets. https://arxiv.org/abs/2304.14717.

Moghimi, D., Sunar, B., Eisenbarth, T., and Heninger, N.

(2020). TPM-FAIL: TPM meets timing and lattice at-

tacks. In 29th USENIX Security Symposium (USENIX

Security 20), pages 2057–2073. USENIX Association.

https://www.usenix.org/conference/usenixsecurity20/

presentation/moghimi-tpm.

Proudler, G., Dalton, C., and Chen, L. (2014). Trusted Com-

puting Platforms: TPM2.0 in Context. Springer Ver-

lag. https://doi.org/10.1007/978-3-319-08744-3.

Tarnovsky, C. (2010). Hacking the Smartcard Chip.

Blackhat DC’10. http://www.blackhat.com/html/bh-

dc-10/bh-dc-10-brieﬁngs.html#Tarnovsky.

The Trusted Computing Platform Alliance (2000). Building

A Foundation of Trust in the PC. TCPA Whitepaper,

http://www.trustedcomputinggroup.org/.

Trusted Computing Group (2013). TPM Spec-

iﬁcation Version 2.0 Revision 00.96.

https://trustedcomputinggroup.org/resource/tpm-

library-speciﬁcation/.

Trusted Computing Group (2019). TCG TSS 2.0

TAB and Resource Manager Speciﬁcation, Fam-

ily 2.0, Level 00 Version 1.0 Revision 18.

https://trustedcomputinggroup.org/resource/tss-

tab-and-resource-manager/.

Trusted Computing Group (2022). TCG EK Credential

Proﬁle, For TPM Family 2.0 Version 2.5 Revision

2. https://trustedcomputinggroup.org/resource/http-

trustedcomputinggroup-org-wp-content-uploads-tcg-

ek-credential-proﬁle-v-2-5-r2 published-pdf/.

Trusted Computing Group (2023a). TCG Algorithm

Registry, Family 2.0 Level 00 Revision 01.34.

https://trustedcomputinggroup.org/resource/tcg-

algorithm-registry/.

Trusted Computing Group (2023b). TCG

PC Client Platform TPM Proﬁle (PTP)

Speciﬁcation for TPM 2.0, Version 1.05.

https://trustedcomputinggroup.org/resource/pc-

client-platform-tpm-proﬁle-ptp-speciﬁcation/.

Trusted Computing Group (TCG) (2003a). TCG Software

Stack (TSS) Speciﬁcation, Version 1.10 Golden.

https://trustedcomputinggroup.org/resource/tcg-

software-stack-tss-speciﬁcation/.

A Brief Reﬂection on Trusted Platform Module Support

897

Trusted Computing Group (TCG) (2003b). TPM

Main Speciﬁcation Level 2 Version 1.2.

https://trustedcomputinggroup.org/resource/tpm-

main-speciﬁcation/.

Trusted Computing Group (TCG) (2006). TCG Soft-

ware Stack (TSS), Speciﬁcation Version 1.2, Level

1. https://trustedcomputinggroup.org/resource/tcg-

software-stack-tss-speciﬁcation/.

Trusted Computing Group (TCG) (2009). TCG Certiﬁ-

cation Programs. https://trustedcomputinggroup.org/

membership/certiﬁcation/.

Trusted Computing Platform Alliance (TCPA)

(2002). TCPA Main Speciﬁcation Version 1.1b.

https://trustedcomputinggroup.org/resource/tcpa-

main-speciﬁcation-version-1-1b/.

Winter, J. and Dietrich, K. (2013). A hijacker’s

guide to communication interfaces of the

trusted platform module. Computers & Math-

ematics with Applications, 65(5):748–761.

https://doi.org/10.1016/j.camwa.2012.06.018.

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

898
