A Coachable Parser of Natural Language Advice

Christodoulos Ioannou

and Loizos Michael

1,2

Open University of Cyprus, Nicosia, Cyprus

CYENS Center of Excellence, Nicosia, Cyprus

Keywords:

Knowledge Engineering, Knowledge Acquisition, Interactive Programming, Translation Policy, Machine

Coaching.

Abstract:

We present a system for parsing advice offered by a human to a machine. The advice is given in the form

of conditional sentences in natural language, and the system generates a logic-based (machine-readable) rep-

resentation of the advice, as appropriate for use by the machine in a downstream task. The system utilizes a

“white-box” knowledge-based translation policy, which can be acquired iteratively in a developmental manner

through a coaching process. We showcase this coaching process by demonstrating how linguistic annotations

of sentences can be combined, through simple logic-based expressions, to carry out the translation task.

1 INTRODUCTION

In the not-so-distant future, Ethan relies on his Cog-

nitive Car Assistant (CCA) to manage the driving

behavior of his self-driving car. Every morning, as

Ethan drives his car to work, he notices that when

the road signs are blurry, the visibility is quickly di-

minished. He coaches his CCA that “When the road

signs are blurry, activate the ESP system of the car,

especially if visibility is reduced.”, where ESP is un-

derstood to be the traction control system of the car

in question. His CCA responds with “Noted. When-

ever the road signs are blurry, I will activate the ESP

system, especially if visibility is reduced.”. Ethan also

notes that “If ESP is inactive, decrease the car’s maxi-

mum speed.”, with his CCA responding with “Noted.

I will decrease maximum speed when ESP is inac-

tive.”.

The interaction between Ethan and his CCA is an

example application of machine coaching (Michael,

2019): a dialectical human-machine interaction pro-

tocol whereby a (not necessarily technically-savvy)

human coach offers advice to a machine to improve

the latter’s decision-making policy in a certain do-

main of interest. As illustrated in the example above,

this form of interaction relies heavily on the ma-

chine’s ability to understand the natural language ad-

vice provided by the human. This understanding is

not always straightforward and cannot necessarily be

anticipated by the developer of Ethan’s CCA, as fur-

ther demonstrated below.

Prompted by an incident where Ethan’s son drove

the car at a high speed on the highway and the CCA

failed to keep the vehicle at a sufﬁcient distance from

the leading cars, Ethan remarks to his CCA to “In-

crease distance from leading cars when Joe is driv-

ing.”, with his CCA acknowledging the advice. Con-

tinuing their conversation, Ethan further advises his

CCA to “Engage the ﬂood lights when the road is

wet.”, with his CCA responding that “I cannot inter-

pret the meaning of the action ‘engage’ in your latest

advice.”. Ethan proceeds to revise the advice trans-

lation policy by clarifying that in his personal lingo,

‘engage’ actually means ‘activate’, with his CCA con-

ﬁrming the translation policy revision, and replying

with “Noted. When the road is wet I will activate the

ﬂood lights.”.

As evidenced by the running example above, ma-

chine coaching can be utilized not only on the domain

level — which, in our case, is that of self-driving ve-

hicles — but also at a meta level on how advice for

the domain level is to be parsed, ensuring that Ethan’s

personal linguistic idioms are faithfully translated and

represented by his CCA, without requiring extensive

retraining or sophisticated programming.

The architecture of the envisioned CCA could

involve several modules, both symbolic and neural.

Neural modules would be more suitable for low-level

atomic processes that require less guidance or amend-

ment by a human, need not be fully explainable, and

at the same time might be complicated enough for a

human to provide a policy to control their behavior.

500

Ioannou, C. and Michael, L.

A Coachable Parser of Natural Language Advice.

DOI: 10.5220/0012454500003636

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 16th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2024) - Volume 2, pages 500-510

ISBN: 978-989-758-680-4; ISSN: 2184-433X

Examples of such processes could be the identiﬁca-

tion of the road conditions and boundaries or the inter-

pretation of the road signs. On the other hand, high-

level processes that relate to the general plan of driv-

ing and which use sensor parameters and low-level

processes outputs, would beneﬁt from being imple-

mented as an adjustable “white-box” symbolic mod-

ule.

The same line of reasoning on choosing how

a process is implemented applies not only to the

domain-level problem, but also to the meta-level

problem of parsing advice in natural language. Re-

liability, explainabilty, and auditability of translating

advice into domain-level policy expressions become

critical properties in a domain like self-driving vehi-

cles, where mistakes could lead to injury or death.

Sidestepping the question of how the meta-level

advice is, itself, communicated to the CCA in a nat-

ural manner — which could be done, for instance,

through a graphical interface, or through a sufﬁciently

structured form of natural language that would be

amenable to off-the-shelf parsing methods — in this

work we focus on demonstrating how meta-level ad-

vice (once itself parsed) can be utilized through the

process of machine coaching to iteratively improve

the parsing of the domain-level advice, while keeping

both the domain-level (Michael, 2019) and the meta-

level (Ioannou and Michael, 2021) decision-making

processes efﬁcient, expressive, and explainable.

At a high level (see Figure 1), the parsing system

receives as input a piece of domain-level advice in

natural language, and applies Natural Language Pro-

cessing (NLP) tools to extract its linguistic annota-

tions, including word tokens, word lemmas, parts of

speech, named entities, and dependency relations be-

tween tokens. The system’s translation policy is then

applied on these annotations to generate a logic-based

representation of the input sentence. In case the out-

come is deemed to be incomplete or incorrect, an ex-

pert can coach the system towards updating its policy,

including providing exceptions to parts of the policy

that should be overridden in certain circumstances.

By virtue of this interaction, the translation policy can

be adapted to the idiosyncrasies and particularities of

the language, the domain expert, or the application

domain for which the logic expressions are generated.

The system has been implemented in Java, and

uses Stanford CoreNLP (Manning et al., 2014) for

natural language processing, and the Prudens frame-

work (Markos and Michael, 2022) for knowledge rep-

resentation and reasoning. The pipeline functions are

available both as a Java library and as a web service.

Web and desktop applications are also available for

experimenting with the pipeline

2 REPRESENTING A

TRANSLATION POLICY

Following the syntax and semantics of the Prudens

framework, the translation policy of our proposed sys-

tem comprises expressions in the form of logical im-

plications in a simple fraction of ﬁrst-order logic, with

associated priorities to resolve conﬂicts between them

(cf. Section 2 of (Markos and Michael, 2022) for the

syntax and semantics of the the Prudens framework).

Policy expressions are deﬁned over a set of predi-

cates, which constitute the atomic elements of the lan-

guage in which the linguistic annotations of an input

sentence are expressed. To represent these linguistic

annotations, we deﬁne two predicate types.

The ﬁrst predicate type represents a word token:

token(Word, POS Tag, NER Flag,

NER Tag, Lemma, Position)

where Word is a word in an input sentence, POS Tag

is its part-of-speech (POS) label, NER Flag takes the

values {ner, nner} to indicate whether the word is a

named entity, NER Tag is the type of the named entity

(if applicable, or otherwise is equal to the constant

o), Lemma is the lemmatized form of the word, and

Position is the word’s position in the sentence.

For example, the system will generate the follow-

ing token predicates for the words of the clause Signs

are blurry:

token(signs, nns, nner, o, sign, 1);

token(are, vbp, nner, o, be, 2);

token(blurry, jj, nner, o, blurry, 3);

The second predicate type is actually a predicate

schema, and it represents a dependency relation:

< dependency > (

Parent Word Lemma, Parent Word Position,

Child Word Lemma, Child Word Position)

where the predicate name < dependency > shows

the dependency relation type. Parent Word Lemma

and Child Word Lemma are the lemmatized forms of

the two words that have that dependency. These two

words appear in positions Parent Word Position

and Child Word Position in the sentence, respec-

tively.

Using the same clause as an example, the system

will generate the following predicates, based on the

https://nestor-system.github.io/webapp/

A Coachable Parser of Natural Language Advice

501

Annotation Module

Stanford

CoreNLP

Generate Logic

Predicates

NLP Data

Linguistic

Annotations

Generation Module

Prudens Reasoning

Engine

Translation

Policy

Generate Logic

Expression

Inferences

Logic-based

Representation

Natural Language

Advice

Figure 1: Parsing pipeline.

cop nsubj

blurry

be sign

Figure 2: Dependency tree generated by NLP for the clause

Signs are blurry.

dependencies identiﬁed by NLP as shown in Figure

nsubj(blurry, 3, sign, 1);

cop(blurry, 3, be, 2);

To deﬁne how the logic expressions will be gen-

erated, a third type of predicate is required. This type

of predicate is an action

and it is used as the head of

an implication expression of the translation policy to

specify how the outcome will be generated:

!generate(Type, Group,

[, P

, ...] [, args, A

[, A

, ...]][, next,

[, P

, ...] [, args, A

[, A

, ...]]][, next, ...])

To describe the constituent parts of this predicate,

we will use the terms meta-predicate, meta-argument

and meta-variable for the description of predicates,

arguments and variables of the translation policy ex-

pressions, and the terms predicate, argument and

variable for the description of the expressions to be

generated.

The meta-arguments Type and Group are used as

driving switches for the Generation Module of the

pipeline (see Figure 1) to guide it on how to process

the inferred !generate actions. The meta-argument

Type takes the values {head, body} to inform the

Generation Module whether the inferred conclusion

includes the head of the expression to be gener-

ated. The meta-argument Group is used to group

translation policy expressions. Each group is pro-

cessed separately by the Generation Module. Mul-

tiple !generate actions may be inferred for an input

sentence. Group 0 is reserved for !generate actions

with type head.

Actions are predicates preﬁxed by the character “!”

that represent a command and appear only in the head of

an implication expression.

The meta-arguments P

, P

, ... represent the con-

stituents of a predicate name to be generated. If a

predicate has arguments, then constant args follows

to mark the end of the predicate name constituents

and the start of the list of predicate’s arguments, rep-

resented by the meta-arguments A

, A

, .... If an ar-

gument of a generated predicate is a variable, then the

variable placeholder constant vph i is used, where i

is a positive integer number. If the same placeholder

constant is used in the same translation policy expres-

sion then it represents the same variable in the expres-

sion to be generated. The system automatically han-

dles the naming of the variables as Xi. The predicates

that a !generate meta-predicate represents are sepa-

rated by the constant next. If a !generate action has

type head, then the ﬁrst predicate will be the head of

the expression to be generated.

For example, the following !generate

meta-predicate represents the logic implication

is bird(X1) implies fly(X1):

!generate(head, 0,

fly, args, vph 1, next,

is, bird, args, vph 1);

Two or more !generate meta-predicates can be

combined to represent complex expressions, as shown

in the following example, which represents the logic

implication is bird(X1), at(antartica) implies

penguin(X1):

!generate(head, 0,

penguin, args, vph 1, next,

is, bird, args, vph 1);

!generate(body, 1, at, args, antartica);

3 DEMONSTRATION OF POLICY

COACHING

The ultimate goal of our research program is to have

Ethan to both advice the CCA on the domain-level

policy (on how the self-driving car will behave), but

also to offer meta-level advice on how to improve the

ICAART 2024 - 16th International Conference on Agents and Artiﬁcial Intelligence

502

translation policy that parses the domain-level advice.

In this work, we distinguish the two tasks, and assume

that the latter will be done with the help of an expert.

In this Section, thus, we will follow the steps taken

by Natalie, a NATural language And LogIc Expert,

as she coaches the system to identify clauses in con-

ditional sentences and translate them into symbolic

form. Natalie will interact with the system by in-

voking it on a corpus of conditional sentences in En-

glish that are used as pieces of domain-level advice

to the CCA. Starting with an empty translation pol-

icy we demonstrate how the system can be used by

an expert to iteratively coach a policy to translate

user advice to domain-level expressions, thus show-

ing that acquiring the translation knowledge with-

out any pre-programming is feasible (Ioannou and

Michael, 2021).

We consider a simpliﬁed version of the conversa-

tion of Ethan with his CCA. In this simpliﬁed version,

an advice in natural language given by the user to the

CCA is limited to a subset of zero conditional sen-

tences, deﬁned in the following paragraphs (see Sec-

tion 3.1). Furthermore, the CCA is assumed to be able

to perform only four actions on different car modules:

to activate or deactivate a car module and to increase

or decrease the value of a parameter of a car system.

The CCA can take these actions according to the state

of different sensors of the car. As the domain-level

policy is not part of the scope of this work, it is not

formally deﬁned. For this scenario, we assume that

the domain-level predicates to be generated are valid

predicates of the domain-level policy and refer to sen-

sors and/or car modules that the CCA can manage.

Below is the realisation of the simpliﬁed version

of the conversation, according to the above assump-

tions and constraints (CCA replies are not consid-

ered):

Ethan: “If signs are blurry, activate ESP.” (S1)

CCA: “When signs are blurry, I will activate

ESP.”

Ethan: “When ESP is inactive, decrease speed.”

(S2)

CCA: “If ESP is inactive, I will decrease speed.”

Ethan: “Increase the distance when Joe is driv-

ing.” (S3)

CCA: “I will increase the distance when Joe is

driving.”

Ethan: “Engage the lights when the road is wet.”

(S4)

CCA: “I cannot interpret action engage when the

road is wet.”

Ethan: Amends the translation policy and repeats

the domain-level advice.

CCA: “When the road is wet I will activate the

lights.”

We will use sentences S1, S2, S3, S4 of the con-

versation above in order to demonstrate the coaching

process and the capability of the process to specialize

or resolve conﬂicts.

In this section Predicate and Subject with capi-

tal ﬁrst letter refer to relevant linguistic terms and the

term generated expression will refer to a logic expres-

sion of the CCA’s domain-level policy.

For every iteration step of the coaching process the

following will be listed: the new expressions added to

the Translation Policy, the Translation Policy Infer-

ences on the sentence and the Translated Symbolic

Form of the sentence as inferred by the translation

policy emerged after each iteration step. The Linguis-

tic Annotations of each sentence and the ﬁnal Transla-

tion Policy emerged by the coaching process are listed

in the Appendix.

3.1 Supported Domain-Level Advice

Language

Conditional sentences describe what happens or what

stands (consequence part) when a certain condition

applies (antecedent part); e.g., If the weather is bad

tomorrow, John will take the car. The order in which

the two parts of the sentence are expressed or the word

that is used to mark the condition (i.e., if or when) do

not change the meaning of the sentence. Zero con-

ditional sentences, speciﬁcally, express facts, rules or

laws and both parts of the sentence are in the present

simple tense; e.g., If the road is bumpy, activate off-

road mode (Foley and Hall, 2003).

For simplicity of exposition, we consider a sub-

set of zero conditional sentences that are suitable to

be given as simple domain-level advice, in which the

antecedent part consists of a simple declarative to-be

clause and the consequent part consists of a simple

imperative clause; e.g., When the windshield is wet,

start the wipers.

A simple declarative to-be clause follows the

structure: <Subject> <To-Be Verb> <Predicate>,

where <Predicate> can be a noun, an adjective or a

verbal and <To-Be Verb> can be either singular or

plural; e.g., Notiﬁcations are possible, Alarm is ring-

ing and Mary is a colleague.

A simple imperative clause follows the structure:

<Imperative Verb> <Object>; e.g., Notify user or

Start the camera.

For conciseness, pronouns, negation, word mod-

A Coachable Parser of Natural Language Advice

503

advcl

mark

dobj

activate (W1)

esp (W2)

Activate ESP

cop nsubj

blurry (W1)

be sign (W2)

Signs are blurry

root

Figure 3: NLP-generated dependency tree for sentence

(S1).

iﬁers and multi-word nouns or verbs are not consid-

ered.

3.2 Identify Simple Declarative to-be

and Imperative Clauses

Natalie chooses ﬁrst to coach the system to identify

the basic clauses of the supported language: sim-

ple declarative to-be clauses and simple imperative

clauses. Based on her natural language expertise, she

decides how to use linguistic annotations to identify

these clauses. Natalie deﬁnes that a simple declara-

tive to-be clause is identiﬁed when a word W2 has a

nsubj dependency to some word W1, and the <To-Be

Verb> has a cop dependency to word W1 (expression

E001). Working in the same way, a simple imperative

clause is identiﬁed when a word W2 has a dobj de-

pendency to some verb W1 (expression E002). These

patterns are illustrated in Figure 3.

As explained earlier, the CCA supports only a spe-

ciﬁc set of actions. For this reason, Natalie decides

that a simple imperative clause can be identiﬁed as an

action clause only if the verb of such a clause is one

of the following: Activate, Deactivate, Increase and

Decrease (expression E003). The above are encoded

in the initial translation policy listed below.

Expressions Added to Translation Policy (Iteration

Step 1)

@Knowledge

E001 :: cop(W1, P1, be, PBe),

nsubj(W1, P1, W2, P2) implies

sdclause(_, W1, P1, W1, W2, P2, W2);

E002 :: token(Word1, POS_Tag,

NER_Flag, NER_Tag, W1, P1),

?startsWith(POS_Tag, vb),

dobj(W1, P1, W2, P2) implies

siclause(_, W1, P1, W1, W2, P2, W2);

E003 :: siclause(Prefix,

The Prudens language supports custom JavaScript

functions which return a Boolean value and can be used

as predicates. These functions are deﬁned under the

@Procedures directive.

W1, P1, WPredicate1,

W2, P2, WPredicate2),

?partOf(activate_deactivate_increase_decrease,

W1) implies

aclause(’!’,

W1, P1, WPredicate1,

W2, P2, WPredicate2);

@Procedures

function startsWith(word, start) {

return word.startsWith(start);}

function partOf(list, word) {

return list.split("_").includes(word);}

Predicates sdclause, siclause and aclause

are intermediate predicates deﬁned by Natalie to rep-

resent a simple declarative clause, a simple impera-

tive clause and an action clause, respectively. The ar-

guments of these predicates are deﬁned in such a way

to hold information that is expected to be required in

the following steps of the inference process. Place-

holder constant “ ” in a meta-predicate is ignored by

the Generation Module.

Applying this policy on sentence (S1), Natalie

gets the following results (see Linguistic Annotation

of (S1) in the Appendix):

Translation Policy Inferences on (S1):

sdclause(_, blurry, 4, blurry,

sign, 2, sign);

siclause(_, activate, 6, activate,

esp, 7, esp);

aclause(’!’, activate, 6, activate,

esp, 7, esp);

Natalie checks the translation policy output and

veriﬁes that the results are as anticipated. She also

observes that the policy is generic enough to capture

both plural and singular form clauses, as well as Sub-

jects that are or are not tagged as named entities.

3.3 Translate Consequent and

Antecedent Parts of a Sentence

Natalie speciﬁes that when the Verb (W1) of an ac-

tion clause in the consequent part of a sentence has

root dependency to the root token, then W1 should

be the name of a domain-level action, in the gener-

ated expression head. The Object (W2) of the clause

should become the name of a predicate in the gen-

erated expression body. Both generated predicates

should have as argument the same variable (expres-

sion E004). Natalie also speciﬁes that when the Pred-

icate (W1) of a simple declarative to-be clause in the

antecedent part of a sentence has an advcl depen-

dency to some word in the sentence, then both the

Predicate and the Subject (W2) of the simple declar-

ICAART 2024 - 16th International Conference on Agents and Artiﬁcial Intelligence

504

ative to-be clause should be the names of two pred-

icates in the generated expression body. Both gen-

erated predicates should have as argument the same

variable (expression E005). These patterns are illus-

trated in Figure 3 and are encoded in the expressions

listed below.

Expressions Added to Translation Policy (Iteration

Step 2):

E004 :: root(root, 0, W1, P1),

aclause(Prefix, W1, P1, WPredicate1,

W2, P2, WPredicate2) implies

!generate(head, 0, Prefix,

WPredicate1, args, vph_1, next,

WPredicate2, args, vph_1);

E005 :: advcl(WParent, PParent, W1, P1),

sdclause(_, W1, P1, WPredicate1,

W2, P2, WPredicate2) implies

!generate(body, 1, _,

WPredicate1, args, vph_1, next,

WPredicate2, args, vph_1);

Natalie applies the new policy on sentence (S1)

again, and she gets the following results:

Translation Policy Inferences on (S1):

sdclause(_, blurry, 4, blurry,

sign, 2, sign);

siclause(_, activate, 6, activate,

esp, 7, esp);

aclause(’!’, activate, 6, activate,

esp, 7, esp);

!generate(body, 1,

_, blurry, args, vph_1, next,

sign, args, vph_1);

!generate(head, 0,

’!’, activate, args, vph_1, next,

esp, args, vph_1);

Translated Symbolic Form of (S1):

blurry(X1), sign(X1), esp(X2) implies

!activate(X2);

The output of the system is as anticipated by Na-

talie, although she is not quite happy with how named

entities are represented in the generated expression.

3.4 Revise Translation Policy for

Handling NER Subject or Object

Natalie speciﬁes that named entities should not ap-

pear as distinct parts of the generated expression, but

should instead appear as constant arguments. For this

reason, Natalie adds two new translation policy ex-

pressions (E006 and E007) to override the existing

expressions (E004 and E005) that translate the an-

tecedent and consequent parts of the sentence. The

new expressions differentiate the output in case the

Subject of a simple declarative to-be clause or the Ob-

ject of a simple imperative clause are named entities.

Since the new expressions are essentially a specializa-

tion of the respective existing translation policy ex-

pressions, the existing expressions are also inferred,

when the new expressions are inferred. To handle this

situation, Natalie adds an explicit conﬂict expression

(E008) that forces only the specialized version of the

expressions to be inferred (cf. Section 3.5 of (Markos

and Michael, 2022) for the conﬂict semantics of the

Prudens language). The above are encoded in the ex-

pressions listed below.

Expressions Added to Translation Policy (Iteration

Step 3):

E006 :: root(root, 0, W1, P1),

token(Word2, POS_Tag, ner, NER_Tag, W2, P2),

aclause(Prefix, W1, P1, WPredicate1,

W2, P2, WPredicate2) implies

!generate(head, 0, Prefix,

WPredicate1, args, WPredicate2);

E007 :: advcl(WParent, PParent, W1, P1),

token(Word2, POS_Tag, ner, NER_Tag, W2, P2),

sdclause(_, W1, P1, WPredicate1,

W2, P2, WPredicate2) implies

!generate(body, 1, _,

WPredicate1, args, WPredicate2);

E008 ::

!generate(TYPE, GROUP, Prefix,

WPredicate1, args, WPredicate2) #

!generate(TYPE, GROUP, Prefix,

WPredicate1, args, vph_1, next,

WPredicate2, args, vph_1);

Natalie applies the new policy on sentence (S1)

once more, and she gets the following results:

Translation Policy Inferences on (S1):

sdclause(_, blurry, 4, blurry,

sign, 2, sign);

siclause(_, activate, 6, activate,

esp, 7, esp);

aclause(’!’, activate, 6, activate,

esp, 7, esp);

!generate(body, 1,

_, blurry, args, vph_1, next,

sign, args, vph_1);

!generate(head, 0, ’!’, activate, args, esp);

Translated Symbolic Form of (S1):

blurry(X1), sign(X1) implies !activate(esp);

Natalie is happy with the outcome on sentence

(S1). She proceeds to apply the same policy also on

sentence (S2), which has a simple declarative to-be

clause with a named entity Subject in the antecedent

part of the sentence (see Figure 4 and Linguistic An-

notation of (S2) in the Appendix). Natalie gets the

following results, as anticipated:

Translation Policy Inferences on (S2):

sdclause(_, inactive, 4, inactive,

A Coachable Parser of Natural Language Advice

505

advcl

when

advmod

root

cop

nsubj

inactive(W1)

be esp (W2)

ESP is inactive

dobj

decrease (W1)

speed (W2)

Decrease speed

Figure 4: NLP-generated dependency tree for sentence

(S2).

esp, 2, esp);

siclause(_, decrease, 6, decrease,

speed, 7, speed);

aclause(’!’, decrease, 6, decrease,

speed, 7, speed);

!generate(body, 1,

_, inactive, args, esp);

!generate(head, 0,

’!’, decrease, args, vph_1, next,

speed, args, vph_1);

Translated Symbolic Form of (S2):

inactive(esp), speed(X1) implies !decrease(X1);

In either of the two sentences, one might note that

two translation policy expressions with a !generate

action are applicable: the generic one and the NER-

speciﬁc one. Yet, the translation policy inference out-

put includes only one of those two conclusions: the

one coming from the expression with the higher pri-

ority. This is a direct consequence of the reasoning

semantics of Prudens (Markos and Michael, 2022),

which the system adopts in representing the transla-

tion policy, and which allows for conﬂicting expres-

sions to co-exist, and resolves their conﬂicting con-

clusions gracefully, as needed.

3.5 Revise Translation Policy to Identify

Declarative to-be Clauses with a

Verbal Predicate

Natalie proceeds to apply the current policy on sen-

tence (S3). The system fails to translate correctly the

antecedent part of the advice (see Linguistic Annota-

tion of (S3) in the Appendix).

Natalie observes that the antecedent clause Joe is

driving of (S3) is not identiﬁed correctly by the sys-

tem. This happens because simple declarative to-be

clauses with a verbal Predicate are not identiﬁed yet

by the current translation policy. So she proceeds to

deﬁne that a simple declarative to-be clause with a

verbal Predicate is identiﬁed when a word W2 has a

nsubj dependency to some word W1 and the <To-Be

Verb> has an aux dependency to word W1 (see Figure

advcl

when

advmod

root

aux

nsubj

drive (W1)

be joe (W2)

Joe is driving

dobj

increase (W1)

distance (W2)

Increase the

distance

the

det

Figure 5: NLP-generated dependency tree for sentence

(S3).

5). She encodes the above in a new expression (E009)

that is added to the translation policy.

Expressions Added to Translation Policy (Iteration

Step 4):

E009 :: aux(W1, P1, be, PBe),

nsubj(W1, P1, W2, P2) implies

sdclause(_, W1, P1, W1, W2, P2, W2);

Natalie applies the new policy on sentence (S3) again,

and she gets the following results, as anticipated:

Translation Policy Inferences on (S3):

siclause(_, increase, 1, increase,

distance, 3, distance);

sdclause(_, drive, 7, drive,

joe, 5, joe);

aclause(’!’, increase, 1, increase,

distance, 3, distance);

!generate(body, 1, _, drive, args, joe);

!generate(head, 0,

’!’, increase, args, vph_1, next,

distance, args, vph_1);

Translated Symbolic Form of (S3):

drive(joe), distance(X1) implies

!increase(X1);

3.6 Revise Translation Policy to Adjust

to Ethan’s Personal Lingo

Natalie applies the current policy on sentence (S4)

which the parsing system, as expected, is unable to

translate because verb engage is a particularity of

Ethan’s language (see Linguistic Annotation of (S4)

in the Appendix). Natalie “translates” Ethan’s meta-

level advice When I say engage I mean activate into a

logic expression (E010) that identiﬁes a simple imper-

ative clause as an Activate action clause, if the verb

of the clause is engage (see Figure 6), and adds it to

the translation policy.

Expressions Added to Translation Policy (Iteration

Step 5):

E010 :: siclause(Prefix,

W1, P1, WPredicate1,

W2, P2, WPredicate2),

?startsWith(W1, engage) implies

ICAART 2024 - 16th International Conference on Agents and Artiﬁcial Intelligence

506

advcl

when

advmod

root

cop

nsubj

wet (W1)

be road (W2)

The road is wet

dobj

engage (W1)

light (W2)

Engage the lights

the

det

the

det

Figure 6: NLP-generated dependency tree for sentence

(S4).

aclause(’!’, W1, P1, activate,

W2, P2, WPredicate2);

The system returns the following results, as antici-

pated:

Translation Policy Inferences on (S4):

sdclause(_, wet, 8, wet,

road, 6, road);

siclause(_, engage, 1, engage,

light, 3, light);

!generate(body, 1,

_, wet, args, vph_1, next,

road, args, vph_1);

aclause(’!’, engage, 1, activate,

light, 3, light);

!generate(head, 0,

’!’, activate, args, vph_1, next,

light, args, vph_1);

Translated Symbolic Form of (S4):

wet(X1), road(X1), light(X2) implies

!activate(X2);

4 RELATED WORK AND

CONCLUSIONS

We have demonstrated an implemented system with a

novel take on knowledge acquisition through the use

of machine coaching, as applied on the problem of

parsing natural language advice. In doing so, the sys-

tem allows for the development of explainable trans-

lation policies that can be easily debugged, iteratively

enhanced, and customized. This work does not aspire

to demonstrate a comprehensive and fully expressive

parser, but rather to demonstrate the potential of using

a coaching methodology towards that end.

For the purposes of demonstrating the idea of a

coachable parser and for the sake of simplicity, we

have used in this paper simple zero conditional sen-

tences for acquiring gradually the translation policy.

Obviously, the system can be used for more complex

sentences and other types of conditional sentences

and natural language structures, or even for languages

other than English as long as reliable NLP tools and

dependency parsers are available.

Alternative methodologies have been proposed for

speciﬁc domains requiring extraction of structured

logic from text (Delannoy et al., 1993; Dragoni et al.,

2016; Hassanpour et al., 2011). Such methodologies

can take advantage of pre-deﬁned information related

to the application domain. Although machine coach-

ing may not be suitable for the extraction of all re-

quired knowledge for a system from day one, this is

compensated by the advantages of explainability and

adaptability. Also, the gradual acquisition of knowl-

edge does not require restriction of the language used

and allows customization to user speciﬁc needs. Ap-

proaches using Controlled Natural Languages (CNL)

(Kuhn, 2014; Kain and Tompits, 2019) can be restric-

tive to the language form and the application domain.

To a certain extent, the problem of parsing natural

language advice relates to the argument mining prob-

lem of extracting logical argument structures from un-

structured text sentences. Both neural and symbolic

methodologies have been used for argument mining,

and extensive progress has been made over the past

years, and especially after the social media rise, which

provided new information-rich domains of applica-

tion (Lippi and Torroni, 2016). Neural systems, in

particular, have shown a great promise over the last

few years (Devlin et al., 2019; Zhao and Eskenazi,

2016; Wen et al., 2017; Rajendran et al., 2018), even

though they still suffer from high training cost and in-

efﬁcient results in speciﬁc domains. Inherently, these

systems use “black-box” approaches, which do not

provide accurate, deep reasoning for decision expla-

nations (Valmeekam et al., 2022; Wei et al., 2022;

Zhou et al., 2023), a feature that along with acquired

knowledge and concept accuracy is very important

in certain domains (Nye et al., 2021; Jansen et al.,

2017). Our work demonstrates that a coachable policy

for argument mining might offer a cheap and light-

weight “white-box” complementary approach to the

existing ones, which could potentially provide an ex-

plainable but also ﬂexible and adaptable solution; and

one that could be part of a neural-symbolic architec-

ture (Tsamoura et al., 2021) that utilizes both sym-

bolic coaching and neural learning (Michael, 2023;

Yang et al., 2023; Defresne et al., 2023).

Our system was developed to act as a tool whose

generated expressions could be used to coach an

application-speciﬁc policy (Ioannou and Michael,

2021). Our ﬁctional character Natalie acts, then, as

a facilitator in enhancing the usability of the ma-

chine coaching paradigm for such application-speciﬁc

users, since the latter need not be experts in logic, and

can, instead use natural language for communicating

A Coachable Parser of Natural Language Advice

507

the revisions they wish to make to the application-

speciﬁc policy. Interestingly, this courtesy is not (and

it is unclear whether it is even possible to be) extended

to Natalie herself, since she needs to communicate her

revisions for the translation policy directly in logic

(Ioannou and Michael, 2021). Nonetheless, future

work could seek to mitigate Natalie’s burden by pro-

viding her or the user, for example, with visual aids in

constructing expressions for the translation policy, or

asking her to complete the less cognitively demand-

ing, but perhaps more time consuming, task of evalu-

ating numerous potential translations, and then letting

another process that combines machine learning and

machine coaching to actually generate the translation

policy (Markos et al., 2022).

Beyond our initial empirical evaluation of the sys-

tem, a more systematic user study will help us assess

the accuracy, the performance and the usability of the

demonstrated system and methodology. Future work

could focus on this task by identifying suitable data-

sets and benchmarks that would quantify the claimed

advantages of the proposed ideas (Ruder, 2021).

ACKNOWLEDGMENTS

This work was supported by funding from the EU’s

Horizon 2020 Research and Innovation Programme

under grant agreement no. 739578, and from the

Government of the Republic of Cyprus through the

Deputy Ministry of Research, Innovation, and Digital

Policy.

REFERENCES

Defresne, M., Barbe, S., and Schiex, T. (2023). Scal-

able coupling of deep learning with logical reasoning.

In International Joint Conference on Artiﬁcial Intelli-

gence (IJCAI 2023).

Delannoy, J. F., Feng, C., Matwin, S., and Szpakowicz,

S. (1993). Knowledge extraction from text: machine

learning for text-to-rule translation. In Proceedings of

the ECML Workshop on Machine Learning and Text

Analysis, pages 7–13.

Devlin, J., Chang, M.-W., Lee, K., and Toutanova, K.

(2019). BERT: Pre-training of deep bidirectional

transformers for language understanding. In Pro-

ceedings of the 2019 Conference of the North Amer-

ican Chapter of the Association for Computational

Linguistics: Human Language Technologies, Volume

1 (Long and Short Papers), pages 4171–4186, Min-

neapolis, Minnesota. Association for Computational

Linguistics.

Dragoni, M., Villata, S., Rizzi, W., and Governatori, G.

(2016). Combining NLP approaches for rule extrac-

tion from legal documents. In Proceedings of the 1st

Workshop on Mining and Reasoning with Legal Texts.

Foley, M. and Hall, D. (2003). Longman advanced learn-

ers’ grammar: a self-study reference & practice book

with answers. Longman London and New York.

Hassanpour, S., O’Connor, M. J., and Das, A. K. (2011). A

framework for the automatic extraction of rules from

online text. In Proceedings of the International Work-

shop on Rules and Rule Markup Languages for the

Semantic Web, pages 266–280. Springer.

Ioannou, C. and Michael, L. (2021). Knowledge-based

translation of natural language into symbolic form.

In Proceedings of the 7th Linguistic and Cognitive

Approaches To Dialog Agents Workshop - LaCA-

TODA 2021 (IJCAI 2021), volume 2935, pages 24–32.

CEUR-WS.

Jansen, P., Sharp, R., Surdeanu, M., and Clark, P. (2017).

Framing QA as building and ranking intersentence

answer justiﬁcations. Computational Linguistics,

43(2):407–449.

Kain, T. and Tompits, H. (2019). Uhura: An authoring tool

for specifying answer-set programs using controlled

natural language. In Proceedings of the 16th European

Conference on Logics in Artiﬁcial Intelligence, pages

559–575. Springer.

Kuhn, T. (2014). AsSurvey and classiﬁcation of con-

trolled natural languages. Computational Linguistics,

40(1):121–170.

Lippi, M. and Torroni, P. (2016). Argumentation mining:

state of the art and emerging trends. ACM Trans. In-

ternet Technol., 16(2).

Manning, C. D., Surdeanu, M., Bauer, J., Finkel, J. R.,

Bethard, S., and McClosky, D. (2014). The Stan-

ford CoreNLP natural language processing toolkit. In

Proceedings of 52nd Annual Meeting of the Associa-

tion for Computational Linguistics: System Demon-

strations, pages 55–60.

Markos, V., Thoma, M., and Michael, L. (2022). Ma-

chine coaching with proxy coaches. In Proceedings of

the 1st International Workshop on Argumentation and

Machine Learning (ArgML’22), volume 3208, pages

45–64. CEUR-WS.

Markos, V. T. and Michael, L. (2022). Prudens:

An argumentation-based language for cognitive as-

sistants. In Proceedings of the 6th Interna-

tional Joint Conference on Rules and Reasoning

(RuleML+RR’22), pages 296–304, Berlin, Germany.

Springer.

Michael, L. (2019). Machine coaching. In Proceedings

of the IJCAI Workshop on Explainable Artiﬁcial In-

telligence (XAI’19), pages 80–86, S.A.R. Macau, P.R.

China.

Michael, L. (2023). Autodidactic and coachable neural ar-

chitectures. In Hitzler, P., Sarker, M. K., and Eber-

hart, A., editors, Compendium of Neurosymbolic Ar-

tiﬁcial Intelligence, volume 369 of Frontiers in Arti-

ﬁcial Intelligence and Applications, pages 235–248.

IOS Press.

Nye, M., Tessler, M. H., Tenenbaum, J. B., and Lake,

B. M. (2021). Improving coherence and consistency

ICAART 2024 - 16th International Conference on Agents and Artiﬁcial Intelligence

508

in neural sequence models with dual-system, neuro-

symbolic reasoning. In Beygelzimer, A., Dauphin, Y.,

Liang, P., and Vaughan, J. W., editors, Advances in

Neural Information Processing Systems.

Rajendran, J., Ganhotra, J., Singh, S., and Polymenakos, L.

(2018). Learning end-to-end goal-oriented dialog with

multiple answers. In Proceedings of the 2018 Confer-

ence on Empirical Methods in Natural Language Pro-

cessing, pages 3834–3843, Brussels, Belgium. Asso-

ciation for Computational Linguistics.

Ruder, S. (2021). Challenges and opportunities in NLP

benchmarking. Technical report, ruder.io A blog about

natural language processing and machine learning.

Tsamoura, E., Hospedales, T., and Michael, L. (2021).

Neural-symbolic integration: a compositional per-

spective. In Proceedings of the 35th AAAI Confer-

ence on Artiﬁcial Intelligence (AAAI’21), pages 5051–

5060.

Valmeekam, K., Olmo, A., Sreedharan, S., and Kambham-

pati, S. (2022). Large language models still can’t

plan (a benchmark for llms on planning and reasoning

about change). In NeurIPS 2022 Foundation Models

for Decision Making Workshop.

Wei, J., Wang, X., Schuurmans, D., Bosma, M., brian ichter,

Xia, F., Chi, E. H., Le, Q. V., and Zhou, D. (2022).

Chain of thought prompting elicits reasoning in large

language models. In Oh, A. H., Agarwal, A., Bel-

grave, D., and Cho, K., editors, Advances in Neural

Information Processing Systems.

Wen, T.-H., Vandyke, D., Mrk

c, N., Ga

c, M., Rojas-

Barahona, L. M., Su, P.-H., Ultes, S., and Young, S.

(2017). A network-based end-to-end trainable task-

oriented dialogue system. In Proceedings of the 15th

Conference of the European Chapter of the Associa-

tion for Computational Linguistics: Volume 1, Long

Papers, pages 438–449, Valencia, Spain. Association

for Computational Linguistics.

Yang, Z., Ishay, A., and Lee, J. (2023). Coupling large lan-

guage models with logic programming for robust and

general reasoning from text. In Findings of the As-

sociation for Computational Linguistics: ACL 2023,

pages 5186–5219, Toronto, Canada. Association for

Computational Linguistics.

Zhao, T. and Eskenazi, M. (2016). Towards end-to-end

learning for dialog state tracking and management us-

ing deep reinforcement learning. In Proceedings of

the 17th Annual Meeting of the Special Interest Group

on Discourse and Dialogue, pages 1–10, Los Angeles.

Association for Computational Linguistics.

Zhou, D., Sch

arli, N., Hou, L., Wei, J., Scales, N., Wang,

X., Schuurmans, D., Cui, C., Bousquet, O., Le, Q. V.,

and Chi, E. H. (2023). Least-to-most prompting en-

ables complex reasoning in large language models. In

The Eleventh International Conference on Learning

Representations.

APPENDIX

Linguistic Annotation of Sentences

Linguistic Annotation of (S1):

token(root, root, nner, o, root, 0);

token(if, in, nner, o, if, 1);

token(signs, nns, nner, o, sign, 2);

token(are, vbp, nner, o, be, 3);

token(blurry, jj, nner, o, blurry, 4);

token(activate, vbp, nner, o, activate, 6);

token(esp, nnp, ner, system, esp, 7);

root(root, 0, activate, 6);

mark(blurry, 4, if, 1);

nsubj(blurry, 4, sign, 2);

cop(blurry, 4, be, 3);

advcl(activate, 6, blurry, 4);

dobj(activate, 6, esp, 7);

Linguistic Annotation of (S2):

token(root, root, nner, o, root, 0);

token(when, wrb, nner, o, when, 1);

token(esp, nnp, ner, system, esp, 2);

token(is, vbz, nner, o, be, 3);

token(inactive, jj, nner, o, inactive, 4);

token(decrease, vb, nner, o, decrease, 6);

token(speed, nn, nner, o, speed, 7);

root(root, 0, decrease, 6);

advmod(inactive, 4, when, 1);

nsubj(inactive, 4, esp, 2);

cop(inactive, 4, be, 3);

advcl(decrease, 6, inactive, 4);

dobj(decrease, 6, speed, 7);

Linguistic Annotation of (S3):

token(root, root, nner, o, root, 0);

token(increase, vb, nner, o, increase, 1);

token(the, dt, nner, o, the, 2);

token(distance, nn, nner, o, distance, 3);

token(when, wrb, nner, o, when, 4);

token(joe, nnp, ner, person, joe, 5);

token(is, vbz, nner, o, be, 6);

token(driving, vbg, nner, o, drive, 7);

root(root, 0, increase, 1);

det(distance, 3, the, 2);

dobj(increase, 1, distance, 3);

advmod(drive, 7, when, 4);

nsubj(drive, 7, joe, 5);

aux(drive, 7, be, 6);

advcl(increase, 1, drive, 7);

Linguistic Annotation of (S4):

token(root, root, nner, o, root, 0);

token(engage, vb, nner, o, engage, 1);

token(the, dt, nner, o, the, 2);

token(lights, nns, nner, o, light, 3);

token(when, wrb, nner, o, when, 4);

token(the, dt, nner, o, the, 5);

token(road, nn, nner, o, road, 6);

token(is, vbz, nner, o, be, 7);

A Coachable Parser of Natural Language Advice

509

token(wet, jj, nner, o, wet, 8);

root(root, 0, engage, 1);

det(light, 3, the, 2);

dobj(engage, 1, light, 3);

advmod(wet, 8, when, 4);

det(road, 6, the, 5);

nsubj(wet, 8, road, 6);

cop(wet, 8, be, 7);

advcl(engage, 1, wet, 8);

Translation Policy Emerged from

Coaching Process

@Knowledge

E001 :: cop(W1, P1, be, PBe),

nsubj(W1, P1, W2, P2) implies

sdclause(_, W1, P1, W1, W2, P2, W2);

E002 :: token(Word1, POS_Tag,

NER_Flag, NER_Tag, W1, P1),

?startsWith(POS_Tag, vb),

dobj(W1, P1, W2, P2) implies

siclause(_, W1, P1, W1, W2, P2, W2);

E003 :: siclause(Prefix,

W1, P1, WPredicate1,

W2, P2, WPredicate2),

?partOf(activate_deactivate_increase_decrease,

W1)

implies

aclause(’!’,

W1, P1, WPredicate1,

W2, P2, WPredicate2);

E004 :: root(root, 0, W1, P1),

aclause(Prefix, W1, P1, WPredicate1,

W2, P2, WPredicate2) implies

!generate(head, 0, Prefix,

WPredicate1, args, vph_1, next,

WPredicate2, args, vph_1);

E005 :: advcl(WParent, PParent, W1, P1),

sdclause(_, W1, P1, WPredicate1,

W2, P2, WPredicate2) implies

!generate(body, 1, _,

WPredicate1, args, vph_1, next,

WPredicate2, args, vph_1);

E006 :: root(root, 0, W1, P1),

token(Word2, POS_Tag, ner, NER_Tag, W2, P2),

aclause(Prefix, W1, P1, WPredicate1,

W2, P2, WPredicate2) implies

!generate(head, 0, Prefix,

WPredicate1, args, WPredicate2);

E007 :: advcl(WParent, PParent, W1, P1),

token(Word2, POS_Tag, ner, NER_Tag, W2, P2),

sdclause(_, W1, P1, WPredicate1,

W2, P2, WPredicate2) implies

!generate(body, 1, _,

WPredicate1, args, WPredicate2);

E008 ::

!generate(TYPE, GROUP, Prefix,

WPredicate1, args, WPredicate2) #

!generate(TYPE, GROUP, Prefix,

WPredicate1, args, vph_1, next,

WPredicate2, args, vph_1);

E009 :: aux(W1, P1, be, PBe),

nsubj(W1, P1, W2, P2) implies

sdclause(_, W1, P1, W1, W2, P2, W2);

E010 :: siclause(Prefix,

W1, P1, WPredicate1,

W2, P2, WPredicate2),

?startsWith(W1, engage) implies

aclause(’!’, W1, P1, activate,

W2, P2, WPredicate2);

@Procedures

function startsWith(word, start) {

return word.startsWith(start);}

function partOf(list, word) {

return list.split("_").includes(word);}

ICAART 2024 - 16th International Conference on Agents and Artiﬁcial Intelligence

510
