CPE-Identiﬁer: Automated CPE Identiﬁcation and CVE Summaries

Annotation with Deep Learning and NLP

Wanyu Hu

and Vrizlynn L. L. Thing

ST Engineering, Singapore

Keywords:

National Vulnerability Database (NVD), Common Vulnerabilities and Exposures (CVE), Common Platform

Enumeration (CPE), Named Entity Recognition (NER), Natural Language Processing (NLP).

Abstract:

With the drastic increase in the number of new vulnerabilities in the National Vulnerability Database (NVD)

every year, the workload for NVD analysts to associate the Common Platform Enumeration (CPE) with the

Common Vulnerabilities and Exposures (CVE) summaries becomes increasingly laborious and slow. The

delay causes organisations, which depend on NVD for vulnerability management and security measurement,

to be more vulnerable to zero-day attacks. Thus, it is essential to come out with a technique and tool to

extract the CPEs in the CVE summaries accurately and quickly. In this work, we propose the CPE-Identiﬁer

system, an automated CPE annotating and extracting system, from the CVE summaries. The system can

be used as a tool to identify CPE entities from new CVE text inputs. Moreover, we also automate the data

generating and labeling processes using deep learning models. Due to the complexity of the CVE texts, new

technical terminologies appear frequently. To identify novel words in future CVE texts, we apply Natural

Language Processing (NLP) Named Entity Recognition (NER), to identify new technical jargons in the text.

Our proposed model achieves an F1 score of 95.48%, an accuracy score of 99.13%, a precision of 94.83%,

and a recall of 96.14%. We show that it outperforms prior works on automated CVE-CPE labeling by more

than 9% on all metrics.

1 INTRODUCTION

As the world advances into the digital era, there is a

drastic increase in the number of softwares. These

modern softwares depend heavily on open-source li-

braries and packages. Many organizations spend a

lot of resources to monitor the new vulnerabilities in

those open source softwares. One of the most well-

known open-source vulnerability databases is the Na-

tional Vulnerability Database (NVD), maintained by

the National Institute of Standards and Technology

(NIST).

There are thousands of new vulnerabilities dis-

closed each year. In 2021, an average of ﬁfty [red-

scan] new vulnerabilities were disclosed daily, and a

total of 20169 [NVDCVE] new vulnerabilities were

published in 2021. The number of new vulnerabil-

ities is increasing rapidly. More than 8000 new vul-

nerabilities were published in the ﬁrst quarter of 2022,

around a 25 percent [Comparitech] increase from the

same period in 2021. Many organizations’ vulnera-

https://orcid.org/0000-0002-7600-808X

https://orcid.org/0000-0003-4424-8596

bilities databases heavily depend on the NVD notiﬁ-

cations. Therefore, timely analysis of the new open-

source vulnerabilities is crucial for an organization.

However, according to a survey, once a new vul-

nerability is publicly disclosed by the Common Vul-

nerabilities and Exposures (CVE) system and pub-

lished on the NVD, the metadata used in vulnerabil-

ity management, such as Common Platform Enumer-

ation (CPE) applicability statements, took 35 days on

average [Wareus]. This hinders organizations from

getting important vulnerability information in time

and leaves the organizations vulnerable to zero-day

attacks.

Therefore, this paper proposed an automated CPE

annotating system, called the CPE-Identiﬁer system,

which automates the CPE extraction process in the

CVE summaries and, in addition to the improved F1,

accuracy, precision, and recall scores, it increases the

potential time performance improvements in the anal-

ysis. This system serves as a tool to identify CPE en-

tities from new CVE text accurately, quickly and con-

veniently. Named entity recognition (NER) is used in

the system to automatically identify CPEs in CVE de-

Hu, W. and Thing, V.

CPE-Identiﬁer: Automated CPE Identiﬁcation and CVE Summaries Annotation with Deep Learning and NLP.

DOI: 10.5220/0012403500003648

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 10th International Conference on Information Systems Security and Privacy (ICISSP 2024), pages 67-78

ISBN: 978-989-758-683-5; ISSN: 2184-4356

scriptions. This can be useful for security researchers

who want to quickly identify the systems and pack-

ages affected by a particular CVE. Moreover, while

various past machine learning methods were exper-

imented, they require a large amount of annotated

training data, which is not publicly available for ev-

ery CVE summary since the year 1999. Past pa-

pers used various methods to annotate the training

data. Bridges et al. [Bridges] used ”Database Match-

ing, Heuristic Rules and Relevant Terms Gazetteer”

to label the CPEs in the sentence, Wareus E. et al.

[Wareus] mapped the words in the sentence to the

existing CPEs in the available CPE-list. However,

these methods are often costly and not a viable so-

lution. Therefore, we also proposed an idea to auto-

mate this data generating and labeling process using

deep learning models. Our work outperformed previ-

ous methods for automatic CPE labeling in all aspects

of performance metrics. Our best model obtains a F1

score of 95.48%, Accuracy score of 99.13%, Preci-

sion score of 94.83%, Recall score of 96.14%.

The structure of this paper is as follow: Section 2

introduces the relevant works while discussing their

advantages and challenges. Section 3 explores the re-

search methodologies, which include the system de-

sign and our proposed ﬁve NLP models for different

purposes in our system. Section 4 elaborates on all

the datasets and data engineering processes, includ-

ing the automated data annotation, generation, and

cleaning. Section 5 explains the three SoTA models:

BERT, XLNet and GPT-2. Section 6 describes the im-

plementation of the research, including the Data pre-

processing, models training and design of the Graphi-

cal User Interface (GUI). Section 7 analyses the ex-

periment result. Section 8 concludes the paper by

identifying the best model for the CPE-Identiﬁer sys-

tem and its usability. We also propose directions for

future work.

2 LITERATURE REVIEW

There are past research leveraging NLP methods for

CVE summaries. Most of these works are related to

Common Attack Pattern Enumeration and Classiﬁca-

tion (CAPEC), Common Vulnerability Scoring Sys-

tem (CVSS) score, and Common Weakness Enumer-

ation (CWE). K Kanakogi et al. [Kanakogi] have sug-

gested automatically associating the CVE-ID with the

CAPEC-ID using the Term Frequency-Inverse Doc-

ument Frequency (TF-IDF) technique [TFID]. Ros-

tami, S. et al. [Rostami] built 12 Multiple Layer Per-

ceptron (MLP) models to predict and map those miss-

ing ATT&CK tactic categories to those CAPEC with-

out tactic types.

Saba Janamian et al. [UC] have introduced the

VulnerWatch to predict the eight criteria for calcu-

lating the CVSS score. Similarly, Shahid, M. R. et

al [Shahid] suggested using multiple BERT classiﬁers

for each metric composing the CVSS vector. While

Ohuabunwa, B. C. et al. [Ohuabunwa] proposed Cate-

gorical Boosting (CatBoost) to predict the CVSS ver-

sion 3 scores, Evangelista, J. [Evangelista] compared

the predictive performance of Latent Dirichlet Allo-

cation (LDA) and BERT in predicting CVSS version

2 scores. Finally, to convert the metrics from CVSS

version 2 to version 3, Nowak, M. et al. [Nowak] com-

pared the three models – Naive Bayes classier (NB),

k-nearest Neighbors Algorithm (kNN), and Kernel

Support Vector Machine (KSVM). Each model is

trained on CVE summaries and predicts the CVSS

scores.

When dealing with vulnerabilities, Das, S. S. et al.

[Das] maps CVEs to CWEs using BERT model to un-

derstand the impact and mitigate the vulnerabilities.

Stephan Neuhaus et al. [Neuhaus] experimented with

a similar idea using the unsupervised LDA model to

classify CVE texts into vulnerabilities. Yang H. et al.

[Yang] used multiple ML models to analyze the num-

ber of CVE References containing PoC code and how

these References affect the CVE exploitability. Simi-

larly, Yin J. et al. [Yin] performed similar research us-

ing a Bert-based model with a Pooling layer. Bozorgi

M. et al. [Bozorgi] also researched the vulnerability’s

likelihood and exploitability using the Support vector

machines (SVMs) method.

To extract the CPE features from the NVD CVE

summaries. Huff P. et al. [Huff] proposed a recom-

mendation system using Random Forest and Fuzzy

Matching to automatically match the company’s hard-

ware and software inventory in the CVE summary to

CPEs’ Vendor and Product name. However, the size

of the data is insufﬁcient. Jia Y. et al. [Jia] proposed to

use multiple datasets and the Stanford NER to extract

cybersecurity-related entities and train an extractor to

extract cybersecurity-related CPE entities and build a

knowledge base. However, the F1 score is only be-

low 80%. Georgescu et al. [Georgescu] uses IBM

Watson Knowledge Studio services to train the CVE

IoT dataset to enhance the diagnosing and detect pos-

sible vulnerabilities within IoT systems. To extract

vulnerability types from CVE summaries, Bridges et

al. [Bridges] proposed a summarization tool called

CVErizer to summarise CVE texts and extract vulner-

ability types. The author used Auto-Labelling rules to

link CVE word with CPE entities through CWE clas-

siﬁcation. However, the Auto-Labelling rules, like

the Heuristic Rules, cannot provide an accurate re-

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

sult. Lastly, Wareus E. et al. [Wareus] have suggested

using the Bi-directional Long Short-Term Memory

(Bi-LSTM) and a Conditional Random Forest (CRF)

layer to identify the CPE labels, such as vendor and

product names, in the CVE summaries. The labels are

then combined to reconstruct the CPE names. This

method is like the approach we use in our paper. How-

ever, Wareus E. et al. [Wareus] only considers the

top 80% of the most common CPE products and ven-

dors names to ”avoid CPEs with very few mentions”.

Those CPEs with very few mentions are eliminated.

The disadvantage of this method is that it discourages

the prediction of those rare CPE entities names in new

CVE summaries, thus compromises the generality of

the model.

Despite their efforts to extract CPEs from CVE

summaries, achieving a high performance result is

challenging. Many of these works fail to produce an

accurate and precise CPE identiﬁcation result. The

model used in these researches are not the SoTA NLP

model and their performance metrics are not good.

Their F1 scores are below 90%. Also, prior researches

are not able to ﬁnd and annotate enough corpora

when training the model. Those proposed data an-

notation rules, such as the Database matching, Rel-

evant Terms Gazetteer, and Heuristic Rules, are not

able to provide an accurate annotation result. Hence,

we draw insights from the challenges and advantages

of the related works and design a system that ad-

dresses those disadvantages. Our proposed approach

uses the state-of-the-art (SoTA) natural language pro-

cessing (NLP) technique to automatically ﬁnd CPE

identities from new CVE summaries. We generated

and annotated our training data using the SoTA Trans-

formers models with two publicly available cyberse-

curity NER datasets. We also trained and evaluated

the three SoTA Deep Learning NER models – BERT,

XLNet, and GPT-2, to perform CPEs entity identi-

ﬁcation, and found that they outperformed previous

methods [Wareus] for automatic CPE labelling. The

best model is selected to construct the CPE-Identiﬁer

system.

3 RESEARCH METHODOLOGY

3.1 System Design

The system architecture of the CPE-Identiﬁer is a

client and server model. The client interacts with the

CPE-Identiﬁer using the Named Entity Highlighter

GUI. After a string of CVE text is provided to the

GUI, the text is encoded, supplied to the model, and

then decoded to the prediction result. The Named En-

Figure 1: CPE-Identiﬁer Design.

tity Highlighter GUI highlights the named entities and

displays them to the client through the GUI. The Fig-

ure 1 illustrates the proposed CPE-Identiﬁer design

and its component.

3.2 Proposed Approach

The Figure 2 presents the design of the models train-

ing process. The research consists of three stages:

1. Data Pre-processing stage: This stage includes

data collection, cleaning, annotation, augmenta-

tion, and merging. The CVE dataset is down-

loaded and undergone feature engineering pro-

cesses. The result is used to generate new dataset

and annotate raw dataset in this stage.

2. Build and train models stage: This stage consists

of constructing one Data Annotator model, one

Data Augmentator model, as well as three SoTA

NER models – BERT, XLNet, and GPT-2, which

are trained using the pre-processed data.

3. Analysis and build Graphical User Interface

(GUI) stage: The predictive performance of each

model are compared. A GUI is constructed to vi-

sualize the prediction result of the best model.

4 DATASET AND LABELS

To ﬁne-tune a model capable of understanding cy-

bersecurity domain-speciﬁc jargon, we need a large

set of labeled data speciﬁcally for the Named En-

tity Recognition (NER) task that are tailored to the

cybersecurity domain. Moreover, high-quality anno-

tated entities closely related to the CVE-CPE ﬁeld

are also important for identifying new entities in this

domain. In a recent paper [Aghaei], Aghaei et al.

also suggested that the absence of publicly available

domain-speciﬁc NER labeled dataset has caused their

research on training a NER model in cybersecurity a

”challenging task”. The author employed a relatively

small sized dataset called MalwareTextDB [Malware-

TextDB]. However, after investigating the Malware-

TextDB dataset, it consists of four NER tags, which

are not related to our research target. Furthermore,

CPE-Identiﬁer: Automated CPE Identiﬁcation and CVE Summaries Annotation with Deep Learning and NLP

Figure 2: Models Training Process Design.

the size of the dataset is relatively small for training a

deep learning model, which may cause the model to

overﬁt. Therefore, it is crucial to collect high-quality

publicly available training datasets exclusively com-

piled for the cybersecurity CVE-CPE domain.

However, large and annotated CVE-CPE datasets

are not publicly available. A few possible reasons for

this challenge include:

• Challenge 1: There are few publicly available an-

notated CVE datasets for NER tasks.

Compared to other natural language processing

tasks such as text classiﬁcation or relation extrac-

tion, Named Entity Recognition is not common

on CVE datasets. There is only a few past re-

search works focused on the NER task of the CVE

dataset, making it even more challenging to ﬁnd a

large amount of annotated NER corpus. To the

best of our knowledge, there is only one such

publicly available dataset from the Stucco project

[GitHubdata].

• Challenge 2: Those publicly available annotated

CVE datasets are not the latest.

The CVE summary and its corresponding CPE

metadata are updated every day. It is difﬁcult for

the cybersecurity analysts to keep an eye on ev-

ery new CVE released and maintain an updated

database. Moreover, the CVE NER dataset is

not used by any speciﬁc application or comput-

ing environment but only by developers. There-

Figure 3: Challenges and Proposed Solutions.

fore, there is no complete set of the latest anno-

tated CVE NER dataset.

• Challenge 3: Manual annotation of NER training

data is costly.

The manual annotation of a high-quality CVE

dataset for Named Entity Recognition in the cy-

bersecurity domain is time-consuming, requiring

experts who are professionals in cybersecurity.

Training a model using a small amount of data

or a highly skewed dataset will cause the model to

over-ﬁt. The model “sees” a small number of to-

kens repeatedly and learns to recognize those training

data correctly but is not capable of generalizing to the

novel inputs in the test dataset. The training error of

the model becomes extremely small at the expense of

high test-error.

The ﬁgure 3 shows our proposed solution to each

challenge of the data availability:

4.1 CPE Data

CPE is a standardized identiﬁcation system for Infor-

mation and Communications Technology (ICT) prod-

ucts. It provide a more consistent and accurate way to

identify products across different security databases,

and make it easier for security researchers to col-

lect and share information about vulnerabilities and

products. Each CPE is linked to a particular CVE

ID, which includes the following features [Andrew]:

cpe version, part, vendor, product, version, update,

edition, and language. The CPE texts are available at

the NVD ofﬁcial website [NVDdata].

4.2 Padding/Trimming the Sentences

Since each of the sentences in the dataset is of a dif-

ferent length, we have padded and trimmed the in-

put sentences to keep all the sentences to be the same

length.

Out of 361088 sentences, the length ranges from

3 to 449 words. There are 93.96% of the sentences

are shorter than 128 words, therefore we have set

the maximum length of the sentences to 128 tokens.

Those sentences shorter than 128 are padded with

[PAD] tokens. Those sentences longer than 128 are

truncated.

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

Figure 4: Sentence Length Distribution.

4.3 Tagging Schemes

The training corpora are required to be tagged before

performing training. The tagging scheme, BIO (Be-

ginning, Inside, Outside), is used in this paper.

5 MODELS

We trained and used ﬁve pre-trained models and one

Masked-Language Model (MLM) to construct our

CPE-Identiﬁer system. These six models are:

1. BERT Pre-Trained NER Model

• This is a pre-trained bert-base-cased model

downloaded from huggingface.co. It is used to

ﬁne-tune our own Data Annotator model from

scratch.

2. Model 1: Finetuned BERT Data Annotator

Model

• This is a ﬁne-tuned bert-base-cased model

from training annotated cybersecurity NER

texts from GitHub (Dataset a). This model is

used to annotate the named entities in NVD

CVE Dataset from 1999-2021 (Dataset B) and

produces an Automatically Annotated dataset

(Dataset C).

3. Model 2: DistilRoBerta Data Augmentator

Model

• This is a distilroberta-base Masked Language

model. This model generates the Augmented

NER dataset (Dataset D) by randomly replac-

ing word tokens in sentences from the Auto-

matically Annotated dataset (Dataset C).

4. Model 3: BERT NER Model

• This is a pre-trained bert-base-cased model.

• We use the Final Training Corpora (Dataset E)

to train this model and analyze its performance

against Model 4 and Model 5.

5. Model 4: XLNet NER Model

• This is a pre-trained xlnet-base-cased model.

• We use Final Training Corpora (Dataset E) to

train this model and analyze its performance

against Model 3 and Model 5.

6. Model 5: GPT-2 NER Model

• This is a pre-trained gpt2 model.

• We use Final Training Corpora (Dataset E) to

train this model and analyze its performance

against Model 3 and Model 4.

5.1 BERT Model

BERT is an AutoEncoder (AE) language model and

uses only the Encoder portion of the Transformer

architecture. We construced our Data Augmentator

model by utilizing the BERT MLM property to gen-

erate new sentences. We masked seven tokens in each

sentence and asked the model to predict the masked

word.

The advantage of the AE language model is that

it can see the context in both the forward and back-

ward directions. However, it uses the [MASK] token

in the pre-training, which is absent from the real data

during ﬁne-tuning and results in the pretrain-ﬁnetune

discrepancy. It also assumes the masked token is inde-

pendent of unmasked tokens, which is not always the

case. For example, “Microsoft Word” where “Word”

is dependent on “Microsoft”. If “Word” is masked

and predicted, Bert may output “Microsoft Ofﬁce”.

Therefore, we also tested the XLNet model, which

addresses this issue.

5.2 XLNet Model

The XLNet model is a generalized Auto-Regressive

(AR) Permutation Language model [Liang]. It is a bi-

directional Language model. The AR model can pre-

dict the next word using the context word from either

forward or backward, but not both directions.

Figure 5: XLNet Permutation Language Modelling (PLM).

CPE-Identiﬁer: Automated CPE Identiﬁcation and CVE Summaries Annotation with Deep Learning and NLP

XLNet solved this issue by introducing Permu-

tation Language Modelling (PLM), PLM allows for

predicting the upcoming words by permutating a se-

quence and gathering information from all positions

on both sides of the token. In the ﬁgure, the target

token w3 is located at the i-th position, and the i-1 to-

kens are the context words for predicting w3. There

are ﬁve patterns in 120 permutations. The words are

permutated at each iteration; therefore, every word

will be used as the context word. This way, it can

avoid the disadvantages of the MASK method in the

AE language model.

5.3 GPT-2 Model

GPT-2 is Auto-Regressive (AR) model as well

[Liang]. It is good at generative NLP tasks because

of its forward direction property. However, it can

only use forward or backward contexts, which means

it can’t use forward and backward context simulta-

neously. Therefore, GPT-2 is a Uni-directional Lan-

guage Model, unlike the other two NLP models. Dif-

ferent from the Bert model, GPT-2 uses the Decoder

portion of the Transformers architecture.

6 IMPLEMENTATION

The implementation of the research follows three

stages: Data pre-processing, models training, and de-

sign and development of the Graphical User Interface

(GUI).

6.1 Data Pre-Processing Stage

This stage aims to create a set of clean, annotated, and

structured NER corpora, which will be used to train

the three SoTA models.

We identiﬁed ﬁve datasets to be used for our work.

They are:

1. Dataset A: GitHub annotated CVE Dataset from

Jan 2010 to March 2013 publicly available online

[GitHubdata].

2. Dataset B: Raw CVE Dataset from 1999-2021

publicly available online [NVDdata].

3. Dataset C: Self-annotated NER dataset using our

proposed Data Annotator model.

4. Dataset D: Self-augmented NER dataset using

our proposed distilroberta-base Masked Language

model.

5. Dataset E: Final Training Corpora generated by

combining both Dataset C and Dataset D, which

is used to train the three SoTA models.

Figure 6: The details of all Datasets used and generated.

6.1.1 Data Collection

Dataset A is downloaded from GitHub [GitHubdata].

It consists of CVE summaries from three sources:

Microsoft Security Bulletin, Metasploit Framework

database, and the NVD CVE database. The entity

types of each dataset is shown in ﬁgure 7:

Figure 7: Dataset A.

While the same CVE-ID describes the same kind

of vulnerabilities, the descriptions in each source are

different. For example, in Figure 8 the descriptions of

CVE-ID: CVE-2013-1293 are different from various

sources:

Figure 8: CVE text Description from different sources.

Dataset B contains the raw CVE summaries and

CPEs from 1999 to 2021 that is downloaded from

[NVDdata].

6.1.2 Data Cleaning

Our proposed CPE-Identiﬁer system only considers

the top ﬁve popular named entities in the CPEs – “edi-

tion”, ”product”, ”update”, ”vendor”, and ”version“,

because the remaining named entities are not always

available in the CPE identiﬁer strings dataset. These

ﬁve types are enough for the cybersecurity analyst

to quickly narrow down to the vulnerability details.

Therefore, We have replaced the unrelated entities in

dataset A with the Out-of-Word label (”O”). After

investigating the dataset, we have noted that the ”ap-

plication”, ”hardware” and ”os” labels correspond to

the ”product” label in the CPE identiﬁer strings, so

we have renamed the three entities to ”product”.

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

We then constructed two 2-dimensional lists to

store the data in NER format. The two sample 2-

dimensional lists to store the data in NER format is

illustrated 9:

Figure 9: Sample data format after Data Cleaning step.

For dataset B, we combined the dataset from 1999

to 2021 into one text ﬁle.

6.1.3 Data Annotation

This step allows an NLP model to automate the

named entity labeling process. Manually annotat-

ing the 169092 unlabelled CVE summaries is time-

consuming and costly and requires expert knowledge

in both cybersecurity and natural language process-

ing. Therefore, we built a deep learning model to an-

notate the unlabelled CVE summaries automatically.

It dramatically improves efﬁciency and accuracy of

the data labeling process. The model accuracy is

98.73%, and its F1 score is 95.64%. The time taken to

annotate 169092 sentences is only 2 hours. The high

F1 score as well as the accuracy score proves that our

ﬁne-tuned BERT Data Annotator model is capable of

tagging the sentences with NER tags accurately. Fur-

thermore, we have also randomly picked sentences

from the output dataset (dataset C) and manually ex-

amined its accuracy. The steps to generate and anno-

tate the dataset C is described.

1. Constructed the Data Annotator model by ﬁnetun-

ing the bert-base-cased NER model from scratch

using dataset A. The resulting model (model 1)

learns the domain knowledge from cybersecurity

texts and will be used as a tool in the next step.

2. We used model 1 as an annotating tool to identify

the named entities in the unlabelled NVD CVE

dataset (dataset B) from the Data Cleaning stage.

3. The resulting labeled data (datast C) contains

169092 sentences. The distribution of the entities

is shown in the ﬁgure 6.

6.1.4 Data Augmentation

The next step in the Data Pre-processing stage is Data

Augmentation. The augmented dataset was generated

using the NVD CVE summary with BERT Masked

Language Model. Data augmentation helps to im-

prove the data skewness problem by increasing the

data size of the speciﬁc named entity. For example,

in our automatically annotated NVD CVE summary

dataset, there are only 19298 tokens that are tagged as

the “update” entity, while 288228 words are classiﬁed

as the “product” entity. This highly imbalanced data

causes the resulting model to be less generalized on

the “edition” tag.

We build a BERT Masked Language Model and

augment new sentences by randomly replacing seven

words with their synonyms based on the dictionary.

There are very few “edition”, “vendor” and “update”

named entities in our automatically annotated NVD

CVE summary dataset – 5560 words for “edition,

114656 for “vendor” and 19298 for “update”; we plan

to generate more sentences containing these three en-

tities.

We extracted sentences containing “edition”,

“vendor” and “update” only. There are a total of

13288 sentences. We created 192380 new sentences

using our augmentation model, the Data Augmentor.

The distribution of the augmented data is shown in the

Figure 6.

6.1.5 Data Merging

The last step in the Data Pre-processing stage is

to merge the Automatically Annotated NER dataset

(dataset C) and the Augmented NER dataset (dataset

D). The distribution of the entities is shown in the Fig-

ure 6. The Final Training Corpora contains 361472

sentences and will be used to train the three SoTA

NER models.

6.2 Models Training Stage

The models are trained in the Ubuntu Kernel, using

GeForce RTX 3070 Graphics Card. CUDA version

11.3.

6.2.1 Model 1: Finetuned BERT Data Annotator

Model

The ﬁne-tuned BERT Data Annotator model is ﬁne-

tuned from the bert-base-cased pre-trained model

for 5 epochs, using the annotated CVE summaries

(dataset a) from GitHub. The purpose of the Data An-

notator model is to serve as a tool to annotate the un-

labelled NVD CVE summaries (Dataset B) with the

named entities.

The algorithm of the approach is shown in Fig. 10:

CPE-Identiﬁer: Automated CPE Identiﬁcation and CVE Summaries Annotation with Deep Learning and NLP

Figure 10: Data Annotator Approach.

The F1 score of the model is 95.64%, and the ac-

curacy score is 98.72%. The F1 score is plotted in

Fig. 11. This approach improves efﬁciency and saves

the cost of the manual labeling process.

Figure 11: F1 score of Data Annotator model.

6.2.2 Model 2: DistilRoBerta Data Augmentor

Model

The DistilRoBerta Data Augment model is built on

top of the DistilRoBerta [Distilroberta] pre-trained

model. The purpose of the Data Augmentor model

is to serve as a tool to generate new labeled NER cor-

pora. The imbalanced data causes skewness issue in

the model, which degrades the model to describe typ-

ical cases as it must deal with rare cases on extreme

values. The model will predict better on entities with

more training words than those with fewer training

words [C.]. This approach solves the data skewness

issue by generating new sentences with speciﬁc enti-

ties. The algorithm of the approach is shown in 12:

Figure 12: Data Augmentation Approach.

Figure 13: Model Training Hyperparameters Details.

6.2.3 Model 3, 4, 5: BERT, XLNet and GPT-2

NER models

The three SoTA NER models are trained for 20

epochs each. The ﬁgure 13 shows the hyperparam-

eters used when training the models:

We have tested the BERT, XLNet and GPT-2 mod-

els and compared their performances and determined

the most suitable architecture for the NER task on

CVE summaries.

6.3 Analysis and build Graphical User

Interface (GUI)

We have also designed a GUI to visualize the pre-

diction result. The interface of the CPE-Identiﬁer is

hosted on a web using the Streamlit Python pack-

age. The Interface allows the analysts to input the

new CVE texts into the “Enter Text Here” text box

and select a speciﬁc model, or all the three ﬁne-tuned

models to retrieve the annotated result. This feature

allows the analysts to choose the best model that ﬁts

their CVE text.

The prediction result is highlighted in different

colors, where each color indicates a named entity

type. The colors and their corresponding entities are

shown in Figure 14

Figure 14: CPE Entities Colors.

The ﬁgure 15 shows the input text box and the cor-

responding prediction result, where entities are high-

lighted in the corresponding colors:

In the example, the word ”Adobe” is highlighted

in green, indicating it belongs to the ”VENDOR” cat-

egory, The word ”Shockwave Player” is in orange,

which means that it is part of ”PRODUCT” cate-

gory. One interesting ﬁnding is that, instead of one

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

Figure 15: GUI of CPE-Identiﬁer.

word corresponds to one entity, the same word can

be identiﬁed as different entities at different positions

of the sentence. For example, according to dictio-

nary.com [dict], the word ”before” is deﬁned as ”pre-

vious to the time when”. It does not belong to any

entities when used alone. However, in the example

sentence, the word ”before” is identiﬁed as different

entities when it is positioned differently. The word

”before” at the beginning of the sentence is not high-

lighted, which indicates that it is not an entity. How-

ever, the word ”before” in the front of the word ”11.6”

is highlighted in purple, which indicates that it be-

longs to the ”VERSION” entity. This ﬁnding shows

that our ﬁne-tuned BERT model is intelligent enough

to identify the meanings of the words based on their

syntactic and semantic positions in the sentence, and

not purely based on the deﬁnitions of that particular

words. This is a good indicator of the performance of

our ﬁne-tuned model.

7 RESULT ANALYSIS

The models’ performances are evaluated using Accu-

racy, Precision, Recall, and the F1 score and training

time. The results are shown in the table.

7.1 Precision

The formula to calculate the precision score is

Precision Score =

TruePositive

TruePositive + FalsePositive

Figure 16: Model Results Comparison.

The BERT model achieved the highest Precision

score, with a value of 94.83%. XLNet gained 94.71%,

and GPT-2 obtained 89.16%.

Figure 17: Model Precision Comparison.

7.2 Recall

The formula to calculate the recall score is

Recall Score =

TruePositive

TruePositive + FalseNegative

The XLNet model achieved the highest Recall score,

with a value of 96.15%. Bert gained 96.14%, and

GPT-2 obtained 90.69%.

Figure 18: Model Recall Comparison.

7.3 Accuracy

A model with a high accuracy means it can locate

most of the named entities correctly. The formula to

calculate accuracy is

Accuracy Score =

T P + T N

T P + FP + T N + FN

The BERT and XLNet models achieved the highest

Accuracy scores, with a value of 99.13%, and GPT-2

obtained 98.28%.

However, although the model achieves an accu-

racy above 90%, 10% of the cases are the named iden-

tities, but the model predicts that they are not. This is

obviously too high a cost for the cybersecurity expert

to neglect that case. One missed named entity may

CPE-Identiﬁer: Automated CPE Identiﬁcation and CVE Summaries Annotation with Deep Learning and NLP

Figure 19: Model Accuracy Comparison.

cause the CPE-Identiﬁer becomes unreliable and re-

sults in a single point of failure. Therefore, we also

take the F1 score into account.

7.4 F1 Score

The F1 score is the most critical evaluation metric in

machine learning. It considers precision and recall

and gives a measure of the incorrectly identiﬁed cases.

F1 score is a good assessment of the model as it con-

siders the distribution of the data. If the data is highly

imbalanced, the F1 score better assesses the model’s

predictive performance.

If our model incorrectly predicts positive named

entities as negative or vice versa, the cybersecurity an-

alysts will get confused about the prediction result. It

is crucial to ensure there is as few False Positive and

False Negative as possible, which means both preci-

sion and recall are maximal. However, in practice, it

is impossible to maximize the precision and recall to-

gether. Improving the precision score will reduce the

recall score and vice versa. Therefore, we used the F1

score as it considers both precision and recall.

The F1 score is the weighted average of the

model’s precision and recall. The range of the F1

score is between 0 and 1. 0 indicates the predictive

performance of the model is worst, while 1 represents

the predictive performance of the model is the best.

The formula of the F1 score is

F1 = 2 ∗

Precision ∗ Recall

Precision + Recall

The F1 score of the three models is plotted in a graph

and compared. The BERT model achieved the high-

est F1 score, with a value of 95.48%. XLNet gained

95.43%, and GPT-2 obtained 89.92%.

Figure 20: Model F1 Score Comparison.

Hence, from the performance metrics above, the

Bert model is the best model which obtained the high-

est Precision, Accuracy, and F1 score. Its Recall score

is 0.01% lower than the XLNet model.

7.5 Error Analysis

For the model with the best performance – the Bert

model, we have done an error analysis and checked

the number of CVEs in the test set have been correctly

labeled for CPE without any error. The classiﬁcation

report of the prediction result is as shown in the Figure

Figure 21: Classiﬁcation Report.

Since our dataset is imbalanced and every class is

equally important, we chose the Macro Averaged F1

score as the performance metric. According to the

Classiﬁcation report21, four out of ﬁve classes have

achieved a F1 score above 95%. The F1 score for the

”product” class is 87%. The reason for this low F1

score may due to the overﬁtting problem of the model.

There are 322344 unique words that are labeled as

”product”, which is only 30% of the overall ”product”

class size. The size of the unique data is too small,

and there are not enough data samples to accurately

represent all possible input data values. Therefore,

the model is unable to generalize well on the novel

data of the ”product” class. This issue is a potential

future work we will address in the last section.

Among the 64982 CVE sentences in the test

dataset, the Bert model predicts 95% of the CPE enti-

ties correctly on average. We have manually checked

the dataset with wrong prediction result. There are

two main causes for the errors.

1. The original label is wrong. As shown in the Fig-

ure 22, the sentence is ”Integer overﬂow in . . .

SP3 allows remote attackers to execute arbitrary

queries via a crafted . ﬁle that triggers an over-

ﬂow allocation - size error , aka ” . Integer Over-

ﬂow Vulnerability .”. The model predict the ”.”

at the fourth position of the sentence as ”O” en-

tity. However, the Ground Truth label of the ”.”

word in the entity is ”B-vendor”. The model pre-

dicts the correct result, while the original dataset

is wrong.

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

Figure 22: Ground Truth is Wrong.

2. The dataset treat the two continuous symbols as

one single token, while the model predicts the two

continuous symbols as two separate tokens. As

shown in the Figure 23, the sentence is ”REST

ING endpoints j Jenkins 2 .. 218 and earlier , Java

2 .. 204 .. 1 and earlier were prone to clickjack-

ing attacks ..”. The model treats the two continu-

ous symbols ”..” as two separate tokens and gives

two separate labels – ”O” and ”O”. However, the

dataset treat the two continuous symbols as one

single token, thus corresponds to one single label

”O”. This problem can be solved with better qual-

ity of training dataset.

Figure 23: Different number of tokens.

8 CONCLUSION & FUTURE

WORK

This paper designs an automated CPE labeling system

called CPE-Identiﬁer. The system can help the cy-

bersecurity analysts automatically annotate new CVE

summaries and identify key CPE entities, such as edi-

tion, product name, vendor name, version number,

and update number. We have demonstrated the au-

tomated data annotation and augmentation processes

by building two deep learning models. We have

also compared the predictive performance of the three

SoTA NER models when dealing with CVE summary

text. We have concluded that the best model is the

Bert model, which achieves an F1 score of 95.48%

and outperforms the baseline model from past related

work. We have also built a Graphical User Interface

that allows the cybersecurity analysts to use the CPE-

Identiﬁer system conveniently and zoom into the re-

spective CPE entities accurately and efﬁciently. This

paves the way for further discussions on various se-

curity operations to accelerate the incident handling

processes when a new vulnerability emerges.

Regarding the limitations of the proposed ap-

proach, it is noteworthy that while the performance

metrics of the Data Annotation model are commend-

able, the automated labeling process applied to the

Named Entity Recognition (NER) dataset might in-

troduces a degree of noise into the resultant dataset.

This, in turn, exerts an adverse impact on the train-

ing process of the XLNet, BERT, and GPT-2 NER

models. Therefore, for future research endeavors, we

advocate for a meticulous manual examination of the

labeled dataset prior to its utilization in training the

aforementioned NER models. Additionally, we rec-

ommend enhancing the Data Annotation model by

training it on more recent datasets, as it is currently

ﬁne-tuned on data spanning from 2010 to 2013. This

limited temporal scope may result in suboptimal per-

formance when annotating contemporary data, where

novel technical terminologies frequently emerge.

Furthermore, in light of the increasing promi-

nence of Large Language Models (LLMs) such as the

GPT series, LlaMa LLMs, and the PaLM LLMs, we

propose collaboration with these advanced language

models in our future research endeavors to harness

their capabilities effectively.

REFERENCES

Stucco. (n.d.). GitHub - stucco/auto-labeled-corpus: Cor-

pus of auto-labeled text for the cyber secu-

rity domain. GitHub. https://github.com/stucco/auto-

labeled-corpus

NVD - Data Feeds. (n.d.). https://nvd.nist.gov/vuln/data-

feeds

areus, E., & Hell, M. (2020). Automated CPE labeling of

CVE summaries with machine learning. In Detection

of Intrusions and Malware, and Vulnerability Assess-

ment: 17th International Conference, DIMVA 2020,

Lisbon, Portugal, June 24–26, 2020, Proceedings 17

(pp. 3-22). Springer International Publishing.

Team, R., & Team, R. (2022, October 5). Redscan anal-

ysis of NIST NVD reveals record number of criti-

cal and high severity vulnerabilities in 2020. Redscan.

https://www.redscan.com/news/nist-nvd-analysis/

Browse CVE vulnerabilities by date. (n.d.).

https://www.cvedetails.com/browse-by-date.php

O’Driscoll, A., & O’Driscoll, A. (2023, June

14). Cybersecurity vulnerability statis-

tics and facts of 2023. Comparitech.

https://www.comparitech.com/blog/information-

security/cybersecurity-vulnerability-statistics/

Kanakogi, K., Washizaki, H., Fukazawa, Y., Ogata, S.,

Okubo, T., Kato, T., ... & Yoshioka, N. (2021). Tracing

CVE Vulnerability Information to CAPEC Attack Pat-

terns Using Natural Language Processing Techniques.

Information, 12(8), 298.

Understanding TF-ID: A simple introduction.

(2019, May 10). MonkeyLearn Blog.

https://monkeylearn.com/blog/what-is-tf-idf/

Rostami, S., Kleszcz, A., Dimanov, D., & Katos, V. (2020).

A machine learning approach to dataset imputation for

software vulnerabilities. In Multimedia Communica-

tions, Services and Security: 10th International Con-

ference, MCSS 2020, Krak

ow, Poland, October 8-9,

CPE-Identiﬁer: Automated CPE Identiﬁcation and CVE Summaries Annotation with Deep Learning and NLP

2020, Proceedings 10 (pp. 25-36). Springer Interna-

tional Publishing.

Cook, Bryan; Janamian, Saba; Lim, Teck; Logan, James;

Ulloa, Ivan; Altintas, Ilkay; Gupta, Amarnath (2021).

Using NLP to Predict the Severity of Cyber Secu-

rity Vulnerabilities. In Data Science & Engineering

Master of Advanced Study (DSE MAS) Capstone

Projects. UC San Diego Library Digital Collections.

https://doi.org/10.6075/J0TX3F89

Shahid, M. R., & Debar, H. (2021, December). Cvss-

bert: Explainable natural language processing to de-

termine the severity of a computer security vulnera-

bility from its description. In 2021 20th IEEE Interna-

tional Conference on Machine Learning and Applica-

tions (ICMLA) (pp. 1600-1607). IEEE.

Ohuabunwa, B. C. (2022). Predicting Cybersecurity Vul-

nerability Severity via Boosted Machine Learning En-

sembles and Feature Ranking (Doctoral dissertation,

The George Washington University).

Evangelista, J. F. (2021). Cybersecurity Vulnerability

Classiﬁcation Utilizing Natural Language Processing

Methods (Doctoral dissertation, The George Washing-

ton University).

Das, S. S., Serra, E., Halappanavar, M., Pothen, A., & Al-

Shaer, E. (2021, October). V2w-bert: A framework

for effective hierarchical multiclass classiﬁcation of

software vulnerabilities. In 2021 IEEE 8th Interna-

tional Conference on Data Science and Advanced An-

alytics (DSAA) (pp. 1-12). IEEE.

Neuhaus, S., & Zimmermann, T. (2010, November). Se-

curity trend analysis with cve topic models. In 2010

IEEE 21st International Symposium on Software Re-

liability Engineering (pp. 111-120). IEEE.

Yang, H., Park, S., Yim, K., & Lee, M. (2020). Better not to

use vulnerability’s reference for exploitability predic-

tion. Applied Sciences, 10(7), 2555.

Yin, J., Tang, M., Cao, J., & Wang, H. (2020). Apply trans-

fer learning to cybersecurity: Predicting exploitability

of vulnerabilities by description. Knowledge-Based

Systems, 210, 106529.

Bozorgi, M., Saul, L. K., Savage, S., & Voelker, G. M.

(2010, July). Beyond heuristics: learning to classify

vulnerabilities and predict exploits. In Proceedings of

the 16th ACM SIGKDD international conference on

Knowledge discovery and data mining (pp. 105-114).

Huff, P., McClanahan, K., Le, T., & Li, Q. (2021, August).

A recommender system for tracking vulnerabilities. In

Proceedings of the 16th International Conference on

Availability, Reliability and Security (pp. 1-7).

Jia, Y., Qi, Y., Shang, H., Jiang, R., & Li, A. (2018). A

practical approach to constructing a knowledge graph

for cybersecurity. Engineering, 4(1), 53-60.

Bridges, R. A., Jones, C. L., Iannacone, M. D., Testa,

K. M., & Goodall, J. R. (2013). Automatic labeling

for entity extraction in cyber security. arXiv preprint

arXiv:1308.4941.

Aghaei, E., Niu, X., Shadid, W., & Al-Shaer, E. (2022,

October). SecureBERT: A Domain-Speciﬁc Language

Model for Cybersecurity. In International Conference

on Security and Privacy in Communication Systems

(pp. 39-56). Cham: Springer Nature Switzerland.

Statnlp-Research. (n.d.). statnlp-

datasets/dataset/MalwareTextDB-1.0.zip at mas-

ter · statnlp-research/statnlp-datasets. GitHub.

https://github.com/statnlp-research/statnlp-

datasets/blob/master/dataset/MalwareTextDB-1.0.zip

Andrew Buttner, The MITRE Corporation Neal Zir-

ing, National Security Agency. (2008, January).

Common Platform Enumeration (CPE) – Speciﬁ-

cation. https://cpe.mitre.org/speciﬁcation/2.1/cpe-

speciﬁcation 2.1.pdf

bert-base-cased · Hugging Face. (2023, June 1).

https://huggingface.co/bert-base-cased

distilroberta-base · Hugging Face. (n.d.).

https://huggingface.co/distilroberta-base

Cheryl. (2022, March 30). study notes: Handling Skewed

data for Machine Learning models. Medium.

https://reinec.medium.com/my-notes-handling-

skewed-data-5984de303725

Liang, X. (2021, December 10). What is XLNet and

why it outperforms BERT - Towards Data Sci-

ence. Medium. https://towardsdatascience.com/what-

is-xlnet-and-why-it-outperforms-bert-8d8fce710335

Nowak, M., Walkowski, M., & Sujecki, S. (2021, June).

Machine learning algorithms for conversion of CVSS

base score from 2.0 to 3. x. In International Confer-

ence on Computational Science (pp. 255-269). Cham:

Springer International Publishing.

Georgescu, T. M., Iancu, B., & Zurini, M. (2019). Named-

entity-recognition-based automated system for diag-

nosing cybersecurity situations in IoT networks. Sen-

sors, 19(15), 3380.

Dictionary.com — Meanings & Deﬁnitions of

English Words. (n.d.). In Dictionary.com.

https://www.dictionary.com/browse/before

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy
