Designing Algorithms for the Shortest Path Reconﬁguration Problem

Using Decision Diagram Operations

Shou Ooba, Jun Kawahara

and Shin-ichi Minato

Graduate School of Informatics, Kyoto University, Japan

Keywords:

Decision Diagrams, Reconﬁguration Problem, Shortest Path, Graph Algorithm.

Abstract:

This paper proposes decision diagram (DD)-based algorithms for the (edge-unweighted) shortest s-t path

reconﬁguration problem. In the problem, given a graph and two shortest s-t paths, the task is to decide

whether one shortest path can be transformed into the other one by repeatedly applying the reconﬁguration

rule to the path, where the reconﬁguration rule is to change one vertex of the path at a time while maintaining

shortest s-t paths. We propose several DD-based algorithms for the problem and conﬁrm their performance

by computer experiments. We succeeded in ﬁnding a shortest reconﬁguration sequence with length 961,012

in 629.0 seconds for some instance.

1 INTRODUCTION

A combinatorial reconﬁguration problem is a prob-

lem in which two solutions of a combinatorial opti-

mization problem are given, and one solution is trans-

formed into the other one according to a given rule.

The task is to determine whether it can be transformed

from one to the other while satisfying that the in-

termediate states are also feasible. Taking the token

jumping model of the independent set reconﬁguration

problem (Ito et al., 2011) as an example, given a graph

G and two independent sets I

and I

of G, the rule is

to arbitrarily remove one element from the indepen-

dent set and arbitrarily add one element to it at the

same time, and to determine whether it is possible to

transform I

to I

, while maintaining the generated sets

being independent.

Combinatorial reconﬁguration is a young research

area (Ito et al., 2011; Nishimura, 2018). Accord-

ing to the web survey

on combinatorial reconﬁgura-

tion, 69 papers on combinatorial reconﬁguration have

been published, including the independent set recon-

ﬁguration problem (Ito et al., 2011) and the graph

coloring reconﬁguration problem (Bonsma and Cere-

ceda, 2009). Reconﬁguration problems can be viewed

as problems of changing the conﬁguration of a so-

cial system without stopping it, such as changing the

https://orcid.org/0000-0001-7208-044X

https://orcid.org/0000-0002-1397-1020

https://www.ecei.tohoku.ac.jp/alg/coresurvey/

switch conﬁguration of a power distribution network

to prevent power outages. However, many reconﬁgu-

ration problems, including the independent set recon-

ﬁguration, are known to be PSPACE-complete in gen-

eral (Ito et al., 2011; Nishimura, 2018), and it may be

hard to solve such problems in practically acceptable

time.

Under such circumstances, CoRe Challenge

2022 (Soh et al., 2022), a programming competition

for reconﬁguration, was held. Some 369 instances

of the independent set reconﬁguration problem were

provided and 10 solvers participated, including SAT-

based, answer set programming-based (Yamada et al.,

2023), model checking-based (Toda et al., 2023), and

AI planning-based solvers (Christen et al., 2023).

Some of the solvers successfully solved instances

consisting of graphs with several hundreds of vertices.

There exists a data structure called the Zero-

suppressed binary Decision Diagram (ZDD) (Minato,

1993) that efﬁciently represents a family of sets; a

solver for the reconﬁguration problem using ZDDs

also participated in the competition (Ito et al., 2023).

This solver is particularly good at instances where

the shortest reconﬁguration length is very long, and

has successfully solved instances that no other solver

has been able to solve. According to the paper (Ito

et al., 2023), the ZDD solver succeeded in obtaining

the shortest reconﬁguration sequence for an instance

consisting of a graph with 247 vertices, 1,578 edges

and shortest reconﬁguration length of 5,767,157. As

long as the family of objects that we want to trans-

Ooba, S., Kawahara, J. and Minato, S.

Designing Algorithms for the Shortest Path Reconﬁguration Problem Using Decision Diagram Operations.

DOI: 10.5220/0012379900003636

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 16th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2024) - Volume 3, pages 641-648

ISBN: 978-989-758-680-4; ISSN: 2184-433X

641

form is represented as a ZDD, the ZDD solver can

compute the shortest reconﬁguration sequence under

the token jumping model; that is, the rule of removing

one element and adding one element at the same time.

Their paper (Ito et al., 2023) designed a ZDD-based

algorithm that works only under the token jumping

model, using so-called ZDD operations. However,

there are some reconﬁguration rules (models) that are

more complex than it. If we would like to apply

the ZDD-based technique to reconﬁguration problems

under such rules, we need to design other ZDD oper-

ations.

In this paper, we treat the shortest s-t path recon-

ﬁguration problem, where each edge is unweighted;

that is, all the edges have unit length one. In the prob-

lem, given a graph and two shortest s-t paths, the task

is to decide whether one shortest path can be trans-

formed into the other one by repeatedly applying the

reconﬁguration rule to the path, where the reconﬁg-

uration rule is to change one vertex of the path at a

time while maintaining shortest s-t paths. We propose

several ZDD-based algorithms for the problem by de-

signing ZDD operations. We conducted computer ex-

periments to compare them, and succeeded in ﬁnd-

ing a shortest reconﬁguration sequence with length

961,012 in 629.0 seconds for some instance.

The paper is organized as follows. In Sec. 2, pre-

liminaries for reconﬁguration problems, ZDDs, and

a ZDD-based framework for solving reconﬁguration

problems are provided. Sec. 3 describes ZDD-based

algorithms. The results of computer experiments are

shown in Sec. 4. We conclude the paper in Sec. 5.

2 PRELIMINARIES

We denote by U + a the addition to a set U , i.e.,

U ∪ {a}. We also denote by U − a and U − U

the

removal of an element a and all the elements in U

from a set U, i.e., U \ {a} and U \ U

, respectively.

For a graph G = (V,E), we denote by uv ∈ E an edge

whose endpoints are u,v ∈ V .

2.1 Reconﬁguration Problems

Let F be the set of feasible solutions of a combina-

torial problem. By ﬁxing some reconﬁguration rule,

the adjacency relation between two solutions in F is

determined. Given F and two solutions S,T ∈ F ,

the reconﬁguration problem of (F ,S,T ) asks us to

decide whether there is a reconﬁguration sequence

S = F

,. . .,F

= T such that F

∈ F holds for

i = 0, 1, ...,` and F

and F

i+1

are adjacent for i =

0,1, . ..,` − 1 under the given adjacency relation.

Let us consider the token jumping model of the

independent set reconﬁguration as an example. In

the token jumping model, two independent sets I

and I

are adjacent if |I \ I

| = |I

\ I| = 1. Given

a graph G and two independent sets S and T of

G, the independent reconﬁguration problem asks to

decide whether there is a reconﬁguration sequence

S = I

,. . .,I

= T such that I

,. . .,I

all are

independent and I

and I

i+1

are adjacent for all i =

0,1, . ..,` − 1.

2.2 ZDD

ZDD is a data structure for compactly representing

the family of sets. We brieﬂy explain the charac-

teristics of ZDD (Minato, 1993). In this subsection,

assume that the universe set of families represented

by ZDDs is U = {x

,. . .,x

} and the elements are or-

dered as x

< ··· < x

. A ZDD Z is a directed acyclic

graph that has two nodes with outdegree 0, called 0-

and 1-terminals, and one node with indegree 0, called

root, and denoted by root(Z). The outdegree of each

non-terminal nodes is two; the arcs are called 0- and

1-arc. Each non-terminal node ν has a label, one of

,. . .,x

n−1

or x

, which we denote by label(ν). For

non-terminal nodes ν and ν

, if ν points at ν

by its 0-

or 1-arc, label(ν) < label(ν

) must hold.

We interpret that a ZDD represents the fam-

ily of sets in the following manner: We con-

sider a route from the root to 1-terminal, say

,ν

,. . .,ν

,ν

k+1

, where ν

is a non-

terminal node for i = 1, ...,k, a

is a 0- or 1-arc of

and ν

k+1

is 1-terminal. Then, the route represents

the set {label(ν

) | a

is 1-arc}; that is, collecting the

labels of the nodes each of whose outgoing arc on the

route is 1-arc. A ZDD represents the family of sets

each of which is represented by a route from the root

to 1-terminal. For a ZDD Z, the family of sets repre-

sented by Z is denoted by S(Z).

A ZDD has the following recursive structure.

Given a ZDD Z, consider the root node ν of Z and

the nodes pointed by 0- and 1-arcs of ν, which we

denote by ν

and ν

, respectively. Then, for i = 0,1,

we consider a directed graph consisting of the nodes

and arcs reachable from ν

. The graph can be re-

garded as a ZDD whose root is ν

and we denote it by

child

(Z). The ZDDs child

(Z) and child

(Z) repre-

sent the family of sets in S(Z) not including the label

of root(Z) and the family of sets in S(Z) including

the label of root(Z), respectively.

We use the following operations, which are efﬁ-

ciently performed by recursive algorithms. See the

book (Knuth, 2011) for detail. Let F , G be ZDDs,

and a be an element in U.

ICAART 2024 - 16th International Conference on Agents and Artiﬁcial Intelligence

642

• F ∪ G, F ∩ G, and F \ G are ZDDs

representing the union, intersection, and

subtraction of S(F ) and S(G), respec-

tively; that is,

{

F ∈ S(F ) or F ∈ S (G)

}

{F | F ∈ S(F ) and F ∈ S(G)}, and

{F | F ∈ S (F ) and F /∈ S (G)} (Bryant, 1986;

Minato, 1993; Knuth, 2011).

• Operation subset1(F ,a) is a ZDD representing

the family of sets obtained by extracting the sets

containing a from S(F ) and removing a from the

sets; that is, {S − a | S ∈ S(F ), S 3 a} (Minato,

1993).

• Operation multip(F ,a) is a ZDD representing the

family of sets obtained by adding a to each set in

S(F ); that is, {S + a | S ∈ S(F )} (Okuno et al.,

1998).

• Operation restrict(F ,G) is a ZDD represent-

ing the family of sets obtained by extract-

ing the sets from S(F ) each of which com-

pletely subsumes a set in S(G); that is,

{

F ∈ F

G ∈ G,G ⊆ F

}

(Okuno et al., 1998).

2.3 ZDD-Based Algorithmic

Framework for Reconﬁguration

Problems

Ito et al. (Ito et al., 2023) proposed a ZDD-based algo-

rithmic framework for solving reconﬁguration prob-

lems. We explain the framework taking the token

jumping model of the independent set reconﬁguration

as an example. First, we construct a ZDD represent-

ing the family of solutions. In the case of the inde-

pendent set reconﬁguration, we construct the ZDD,

say Z

sol

, representing the family of all the indepen-

dent sets of a given graph. This can be performed by

an existing algorithm (Hayase et al., 1995). Then, for

a ZDD Z, let swap

(Z) be the ZDD representing

{U + v − v

| U ∈ S (Z),v ∈ I \U, v

∈ U}.

This is the family of sets obtained by applying the re-

conﬁguration rule (removing one element and adding

another element) to each set in S(Z) and collecting

all the possible resulting sets. Let Z

be the family of

sets obtained by applying the reconﬁguration rule to

S, i times, where Z

is the ZDD representing {S}. Z

can be computed by Z

= swap

i−1

) ∩ Z

sol

. Since

S(swap

i−1

)) includes not independent sets, we ex-

clude them by “∩ Z

sol

,” which can be performed by a

ZDD operation described in Sec. 2.2. By computing

for i = 1,2,... , and checking whether T ∈ S(Z

we can ﬁnd a shortest reconﬁguration sequence from

S to T . If S(Z

) =

0 for some i, there is no reconﬁgu-

ration sequence.

Instead explaining the construction of swap

(Z),

we explain how to compute remove(Z), a ZDD for

{U − v | U ∈ S(Z),v ∈ U}

because remove(Z) is easier than swap

(Z) and

swap

(Z) can be computed in similar to the way

for remove(Z). The algorithm uses the recursive

structure of ZDDs. Let x = root(Z). We divide

S(remove(Z)) into two groups: (i) sets including x

and (ii) sets not including x. Group (i) can be obtained

by collecting the sets obtained by removing some el-

ement other than x from each set including x in S(Z).

The ZDD representing the family of group (i) can be

constructed by recursively calling remove(F

), where

= child

(Z), because child

(Z) is the family of

sets containing x (see the description of the recursive

structure in Sec. 2.2). Group (ii) is further divided into

two subgroups: (ii-1) the sets obtained by removing

some element from each set not including x in S(Z),

and (ii-2) the sets obtained by removing x from each

set including x in S(Z). The ZDD for (ii-1) is con-

structed by recursively calling remove(child

(Z)),

and that for (ii-2) is exactly child

(Z). The ZDD for

(ii) is the union of the ZDDs (ii-1) and (ii-2). Let

= remove(child

(Z)) ∪ child

(Z). Therefore, the

ZDD for remove(Z) is constructed as follows: First,

we construct F

and F

by recursive calls. Then, we

create a node labeled x and make its 0-arc and 1-arc

point at the roots of F

and F

, respectively.

The add

operation is deﬁned by the ZDD repre-

senting

{U + v | U ∈ S(Z),v /∈ U,v ∈ I},

which can be computed similarly. We need index I

because we need to specify what we add to a set. The

swap

operation can also be performed similarly. Re-

fer to the paper (Ito et al., 2023) for detail.

3 SHORTEST s-t PATH

RECONFIGURATION

PROBLEM

We begin with the deﬁnition of the shortest s-t path re-

conﬁguration problem (Kami

nski et al., 2011), where

each edge is unweighted. Given an edge-unweighted

undirected simple graph G and two s-t paths S and T

of G, the problem asks us to decide whether there is

a reconﬁguration sequence P

= S, P

,. . .,P

= T ,

where P

is an s-t path for i = 0,...,` and two s-

t paths P

and P

i+1

have all common edges except

two edges and all common vertices except one ver-

tex. This problem is shown to be PSPACE-complete

Designing Algorithms for the Shortest Path Reconﬁguration Problem Using Decision Diagram Operations

643

in general, but can be solved in polynomial-time if

the input graph G is a planar graph (Kami

nski et al.,

2011).

To apply the ZDD-based framework to the short-

est s-t path reconﬁguration, we ﬁrst represent the so-

lution space as a ZDD, and then we design recursive

ZDD operation(s) to obtain Z

from Z

i−1

, which we

deﬁne in Sec 2.3.

Let us consider what variables of ZDDs are. A

path on a graph is uniquely speciﬁed by its edge set.

Therefore, we can represent the solution space by the

family of edge sets each of which consists of a path.

Our ﬁrst direction is to make the edges of G the vari-

ables of ZDDs, which we call edge variables.

We can consider another direction of ZDD vari-

ables by using the characteristics of shortest paths.

Once the input graph G and the input vertices s and

t are ﬁxed, the shortest distance from s to each ver-

tex can be easily determined by ordinary breadth ﬁrst

search. We partition V into V

,. . .,V

n−1

, where V

the set of vertices to which the length of a shortest

path from s is i for i = 0,... , d (recall that we assume

that the weights of all the edges of G are 1). Then,

any s-t shortest path P can be uniquely speciﬁed by

= s, v

,. . .,v

d−1

= t, where d is the length of

any shortest s-t path, and v

∈ V

for i = 0,. . .,d. This

implies that the set {v

,. . .,v

} can uniquely rep-

resent an s-t path. Our second direction is to make the

vertices of G the variables of ZDDs, which we call

vertex variables.

In the setting of edge variables, we can use

frontier-based search for representing various objects

such as s-t paths, cycles, spanning trees, matchings,

as ZDDs (Kawahara et al., 2017). Therefore, the edge

variable direction can solve various reconﬁguration

problems. On the other hand, the vertex variable di-

rection highly depends on the structure of shortest s-t

paths, and thus it is specialized to solve the shortest

s-t path reconﬁguration problem. As we will show in

the experiment section, the vertex variable direction

is faster than the edge variable direction for almost all

instances, although the results are omitted due to the

space limitation. The rest of the section is devoted

to solving the shortest s-t path reconﬁguration using

edge variable ZDDs and vertex variable ZDDs.

3.1 Algorithms on Edge Variables

Kawahara et al. (Kawahara et al., 2017) proposed an

algorithm to construct a ZDD representing the fam-

ily of all the s-t paths of a given graph G and given

vertices s,t of G, where ZDD variables are edge

variables, which we denote by Z

path

. It is easy to

construct a ZDD representing the family of all the

sets whose cardinality is exactly k, which we de-

note by Z

(Knuth, 2011). Therefore, by comput-

ing Z

path

∩ Z

, we obtain the solution space ZDD

sol

, which represents the family of all the s-t short-

est paths of G, where ‘∩’ is the intersection operation

of ZDDs (Bryant, 1986), described in Sec. 2.2.

Next, we show how to construct the ZDD Z

from

i−1

. First, we design a naive algorithm. We consider

a cycle x, u, y,v,x of G with length four. We extract

all the sets including xu and uy from S(Z

i−1

), remove

xu and uy from each extracted set, and add xv and vy

to each of them. Each obtained edge set consists of a

shortest s-t path transformed from a path in S (Z

i−1

We conduct the process for all cycles with length four

and take the union of all of them. Thus, we obtain

[

xu,uy,xv,vy∈E

multip(multip(subset1(

subset1(Z

i−1

,xu), uy), xv), vy),

where multip and subset1 are described in Sec. 2.2.

Note that for a ZDD Z, subset1(Z,a) conducts both

the extraction of the sets containing a from S(Z) and

removing a. The symbol ‘∪’ is the union operation of

ZDDs, described in Sec. 2.2. Since the above equa-

tion computes the union O(n

) times, the computation

is not efﬁcient. In the following, we propose ﬁve al-

gorithms to compute it. Their efﬁciency will be com-

pared by computer experiments in Sec. 4.

Remove-Add Algorithm. It is natural to consider

the use of remove(Z) and add

(Z), which removes

and adds one arbitrary element from and to S(Z), re-

spectively. In the setting of edge variables, to trans-

form a shortest s-t path, we remove two edges and add

another two edges. One might think that if we remove

arbitrary two edges by calling remove twice and add

arbitrary two edges by calling add twice, some gen-

erated results would not consist of a (shortest) path.

However, such not (shortest) paths can be eliminated

by the intersection operation of Z

sol

(the ZDD for the

family of edge sets consisting of shortest s-t paths).

Therefore, we have

= add

(add

(remove(remove(Z

i−1

)))) ∩ Z

sol

Moreover, we can design new operations that con-

duct remove k times at once, and that conduct add

times at once:

remove(F ,k) =

{

F − X

X ⊆ F ∈ F ,

= k

}

add

(F ,k) = {F ∪ X | F ∈ F , X ∩ F =

X ⊆ I,

= k}.

Algorithms that compute remove(F ,k) and

add

(F ,k) will be designed later. Using them,

we obtain

= add

(remove(Z

i−1

,2), 2) ∩ Z

sol

ICAART 2024 - 16th International Conference on Agents and Artiﬁcial Intelligence

644

which we call the remove-add algorithm. Note that

S(Z

) includes paths each of which is completely

equal to a path in S(Z

i−1

), which violates our recon-

ﬁguration rule, but it does not affect the decision of

the existence of a reconﬁguration sequence and com-

puting a shortest reconﬁguration sequence.

Remove-Restrict and Remove-Restrict-k Algo-

rithms. In the remove-add algorithm, we add arbi-

trary two edges after removing two edges. It generates

a huge number of edge sets consisting of non-paths

(although they are compactly represented as a ZDD).

The algorithm proposed here adds two edges so that

the resulting edge sets consist of paths. This can be

performed using the restrict operation, described in

Sec. 2.2, as follows:

= restrict(Z

sol

,remove(Z

i−1

,2)),

which we call the remove-restrict algorithm. Re-

call that the deﬁnition of restrict. Each edge set

∈ S(restrict(Z

sol

,remove(Z

i−1

,2))) is a member

of S(Z

sol

) such that there exists an edge set X ∈

S(remove(Z

i−1

,2)) satisfying X ⊆ E

. This means

that we ﬁrst remove two edges from S(Z

i−1

) (the re-

sulting set is X), and then add edges to X (the resulting

set is E

) so that E

is in S(Z

sol

); i.e., E

consists of a

shortest s-t path.

We know the size of E

is larger than that of X by

two. By using the fact, we expect to accelerate the

computation. We propose a new operation:

restrict(F ,G, k) = {F ∈ F | G ∈ G,

G ⊆ F,

F − G

= k}.

The computation of it and the reason this makes the

computation faster will be shown later. By using the

extended restrict operation, we write

= restrict(Z

sol

,remove(Z

i−1

,2), 2),

which we call the remove-restrict-k algorithm.

Dist Algorithm. In the remove-restrict and remove-

restrict-k algorithms, we ﬁrst call remove(Z

i−1

,2).

Here, we consider to compute remove and restrict at

once. We propose a new operation, called dist:

dist(F ,G, k) =

{

F ∈ F

G ∈ G,

F ∆ G

= k

}

where F ∆ G = (F − G) ∪ (G −F). This operation ex-

tracts the sets F from S(F ) such that the hamming

distance between F and a set G in S(G) is k. Using

the operation, we compute Z

as follows:

= dist(Z

sol

i−1

,4),

which we call the dist algorithm.

Delta Algorithm. Knuth (Knuth, 2011) proposed in

his book “The art of computer programming” a ZDD

operation, called delta:

delta(F ,G) =

{

F ∆ G

F ∈ F ,G ∈ G

}

Using delta, we can compute Z

. First, we con-

struct the ZDD C representing the family of edge sets

each of which consists of a cycle with length four by

frontier-based search (Kawahara et al., 2017). Then,

we compute

= Z

sol

∩ delta(Z

i−1

,C ),

which we call the delta algorithm.

3.2 Algorithms on Vertex Variables

First, we construct the solution space ZDD Z

sol

when

the ZDD variables are the vertices of the input graph

G = (V,E). For i = 0,. . .,d, exactly one vertex in V

is included in a shortest s-t path. Let V

be the ZDD

for the family of sets containing exactly one vertex in

and arbitrary vertices in V −V

; that is,

S(V

) =

{

X ⊆ V

|X| = 1

}

∪

{

X ⊆ V −V

}

Two vertices that are not adjacent on G cannot be in-

cluded in a shortest s-t path. Let X

be the ZDD

for the family of sets containing both u and v; that

is, S(X

) =

{

X ⊆ V

X ⊇ {u,v}

}

sol

i=0,...,d





[

u,v∈V,uv/∈E





The ZDDs V

and X

can be easily constructed and

the above equation can be computed by ZDD opera-

tions. Therefore, we can construct the ZDD Z

sol

Next, we describe how to construct Z

from Z

i−1

This is similar to the edge variable algorithms. The

main difference of them is to remove and add one

variable in the setting of vertex variables. We propose

the following algorithms:

• Naive algorithm:

[

u,v∈V

multip(subset1(Z

i−1

,u), v)

∩ Z

sol

• Remove-add algorithm:

= add

(remove(Z

i−1

)) ∩ Z

sol

• Remove-restrict algorithm:

= restrict(Z

sol

,remove(Z

i−1

,1)),

• Remove-restrict-k algorithm:

= restrict(Z

sol

,remove(Z

i−1

,1), 1),

• Dist algorithm: Z

= dist(Z

sol

i−1

,2),

• Delta algorithm: Z

= Z

sol

∩ delta(Z

i−1

where C

is the ZDD for the family of all the subsets

of V whose cardinality is two.

Designing Algorithms for the Shortest Path Reconﬁguration Problem Using Decision Diagram Operations

645

3.3 Recursive Operations

In this subsection, we show how to con-

duct the recursive operations described in

the previous subsections. First, we explain

remove(F ,k) =

{

F − X

X ⊆ F ∈ F ,

= k

}

If k = 0, remove(F , 0) = F . We consider the case of

k > 0. Let x = root(F ). We create a node labeled x

and make its 0-arc and 1-arc point at the ZDDs F

and F

, explained below, respectively.

and F

can be constructed by

← remove(child

(F ),k)

∪ remove(child

(F ),k − 1),

← remove(child

(F ),k).

The second term remove(child

(F ),k − 1) in the ﬁrst

equation means that x is removed and k − 1 elements

other than x will be removed in the recursive call. We

omit the explanation of the termination in the recur-

sion.

The add

(F ,k) = {F ∪X | F ∈ F ,X ∩F =

0,X ⊆

= k} operation can be computed similarly. We

show just F

and F

as follows: If x /∈ I, we have

← add

(child

(F ),k),

← add

(child

(F ),k).

If x ∈ I, we obtain

← add

I−x

(child

(F ),k),

← add

I−x

(child

(F ),k)

∪ add

I−x

(child

(F ),k − 1).

Next, we consider

restrict(F ,G, k) = {F ∈ F | G ∈ G,

G ⊆ F,

F − G

= k}.

and F

can be obtained by

← restrict(child

(F ),child

(G),k),

← restrict(child

(F ),child

(G),k)

∪ restrict(child

(F ),child

(G),k − 1).

Finally, we consider

dist(F ,G, k) =

{

F ∈ F

G ∈ G,

F ∆ G

= k

}

and F

can be obtained by

← dist(child

(F ),child

(G),k)

∪ dist(child

(F ),child

(G),k − 1),

← dist(child

(F ),child

(G),k)

∪ dist(child

(F ),child

(G),k − 1).

4 COMPUTER EXPERIMENTS

We conducted computer experiments on N × N grid

graph instances, the instances provided by the pa-

per (Kami

nski et al., 2011), and randomly generated

instances. For grid graph instances, we implemented

and measured a polynomial-time solution method for

planar graphs as a comparison with the proposed

method (Bonsma, 2017). The N × N grid graph in-

stance, denoted by gridN, has N

vertices, 2N(N −1)

edges, and a shortest reconﬁguration sequence with

length (N −1)

. We set s and t to be the upper-left and

lower-right corners of a grid graph. We set the start

and goal shortest s-t paths to be the path consisting

of the uppermost and rightmost edges via the upper

right corner, and the path consisting of the leftmost

and lowermost edges via the lower left corner, respec-

tively. The instances provided by the paper (Kami

nski

et al., 2011) are used for proving that the shortest

s-t reconﬁguration is PSPACE-complete. Each of

the instances has a parameter N, which we denote

by expN. It has 13N + 2 vertices, 36N − 11 edges,

and a shortest reconﬁguration sequence with length

11(2

− 1). As for the randomly generated instances,

we generate random graphs by randomly adding ver-

tices to V

,. . .,V

for a given integer d and ran-

domly connecting vertices between V

and V

i+1

. We

pick up the generated instances whose execution time

was the ﬁfth longest, denoted by random5, random6,

random9, random10, random11. The features of the

instances are shown in Table 1.

Table 1: Features of input graphs. The length of a shortest

s-t path reconﬁguration sequence is shown as `.

Instance |V | |E| `

grid10x10 100 180 81

grid20x20 400 760 361

grid30x30 900 1740 841

grid40x40 1600 3120 1521

grid50x50 2500 4900 2401

grid60x60 3600 7080 3481

exp6 80 205 891

exp8 106 277 3696

exp10 132 349 14949

exp12 158 421 59994

exp14 184 493 240207

exp16 210 565 961092

random5 470 1887 113

random6 482 1938 111

random9 385 2971 38

random10 437 3423 34

random11 458 3676 41

Due to the memory limitation, we did not restore

a shortest reconﬁguration sequence, but measured the

ICAART 2024 - 16th International Conference on Agents and Artiﬁcial Intelligence

646

Table 2: Results for vertex variable (in seconds). ‘−’ means timeout (exceeding 1000 seconds).

Instance Naive Remove-add Remove-restrict Remove-restrict-k Dist Delta

grid10x10 0.1 0.1 < 0.1 < 0.1 < 0.1 < 0.1

grid20x20 67.4 4.5 1.3 0.4 0.5 1.7

grid30x30 − 47.5 14.7 5.0 6.5 17.0

grid40x40 − 208.3 69.3 37.4 55.7 89.3

grid50x50 − 571.4 241.7 173.9 323.1 331.8

grid60x60 − − 684.2 509.4 − 945.5

exp6 0.6 0.3 0.2 0.1 0.1 0.1

exp8 6.9 2.1 2.0 0.3 0.4 0.7

exp10 48.3 12.3 11.9 2.6 2.1 4.1

exp12 323.1 66.1 61.4 14.7 12.1 22.8

exp14 − 314.6 300.7 68.6 60.0 105.4

exp16 − − − 351.8 291.3 500.1

random5 − 143.7 390.0 34.1 731.4 346.1

random6 − 19.6 45.4 7.2 189.5 35.9

random9 − − − 49.7 61.5 269.2

random10 − − − 323.6 777.6 −

random11 − 656.3 − 73.8 199.8 53.2

time taken to ﬁnd the length of a shortest sequence.

However, since the polynomial-time method for pla-

nar graphs cannot ﬁnd the length of a shortest recon-

ﬁguration sequence, we measured the time taken to

determine the reachability. The time required to em-

bed a planar graph into a plane was not measured in

the polynomial-time method for planar graphs. Due

to the space limitation, we omit the experimental re-

sults for the edge variable method. Results for the

vertex variable method and the polynomial-time al-

gorithm (Bonsma, 2017) are shown in Tables 2, and

3, respectively. The values in the table represent the

execution time in seconds, in particular, <0.1 means

that the solution was completed in less than 0.1 sec-

ond.

For the vertex variable setting, remove-restrict-

k was the fastest for both instances. The remove-

restrict was almost as fast as the dist algorithm in

the grid graph instance, but in the exponential in-

stance, remove-restrict was about three times slower

in the largest case, and the delta algorithm was faster

in the largest case. The remove-add algorithm was

the fastest after rem+restrict and delta, and the slow-

est was the naive algorithm. Comparing the speed of

the same type of algorithms between vertex and edge

variables, the vertex variable was faster in both cases.

The polynomial-time algorithm for planar graphs

are considerably faster than other algorithms. How-

ever, considering that it is not possible to ﬁnd the

shortest reconﬁguration sequence length or the short-

est reconﬁguration sequence, and that it can only be

used on planar graphs, the proposed algorithms with-

out these restrictions can also be considered valuable.

The reason why the remove-restrict, remove-

restrict-k, and dist algorithms are relatively fast is that

they ﬁnd Z

by ZDD operations with Z

sol

, which has a

small number of nodes. The remove-add and delta al-

gorithms are fast once the remove-add and delta algo-

rithms generate a set that includes combinations that

may not necessarily be a shortest s-t path and then

intersect with Z

sol

, which may result in many unnec-

essary (non shortest s-t path) combinations. However,

for the delta algorithm, it is easy to reduce the num-

ber of unnecessary combinations by limiting the ver-

tex variables to pairs of u,v in the same V

or limit-

ing the edge variables to four edges that form a cycle.

The remove-add algorithm is considered to be slower

because it takes into account a large number of unnec-

essary combinations, especially when k, the argument

of add, is large.

In both cases, the remove-restrict-k algorithm is

faster than the remove-restrict algorithm. This is be-

cause the restrict(F ,G,k) operation is equivalent to

the product set operation at k = 0. When k > 0, the

child pointed to by the 1-arc of restrict(F ,G, k) is

restrict(F

,k)∪restrict(F

,k −1). In particu-

lar, when k = 1, the second term is replaced by the

product set F

∩ G

. On the other hand, the child

pointed to by the 1-arc in the restrict(F ,G) operation

is computed as restrict(F

) ∪ restrict(F

). In

general, the restrict(F ,G,k) operation is faster than

the restrict(F , G) operation because the product set

operation is lighter than the restrict(F , G) operation.

However, the addition of k to the argument may re-

duce the cache hit ratio. In other words, the larger k

is, the smaller the speedup effect is, and it should be

noted that the restrict(F , G) operation may be more

efﬁcient in some cases.

Designing Algorithms for the Shortest Path Reconﬁguration Problem Using Decision Diagram Operations

647

In conclusion, the remove-restrict-k and dist algo-

rithms in the vertex variable seem to be the best for

the shortest s-t path reconﬁguration problem.

Table 3: Results for the polynomial time algorithm for pla-

nar graphs.

Instance Time (sec.)

grid20x20 < 0.1

grid40x40 < 0.1

grid60x60 0.1

grid80x80 0.3

grid100x100 0.7

5 CONCLUSION

In this paper, we have proposed several algorithms for

the shortest s-t path reconﬁguration problem. All of

them are based on DD operations. Computer experi-

ments were conducted to compare these algorithms.

We believe that the value of this study is that it

showed that ZDD operations can solve combinatorial

reconﬁguration problems under various rules. Future

work includes considering what rules of combinato-

rial reconﬁguration problems our method can be ap-

plied to.

ACKNOWLEDGEMENTS

This work was partially supported by JSPS KAK-

ENHI Grant Numbers JP20H00605, JP20H05794,

JP20H05964, and JP23H04383.

REFERENCES

Bonsma, P. and Cereceda, L. (2009). Finding paths between

graph colourings: PSPACE-completeness and super-

polynomial distances. Theoretical Computer Science,

410(50):5215–5226.

Bonsma, P. S. (2017). Rerouting shortest paths in planar

graphs. Discrete Applied Mathematics, 231:95–112.

Bryant, R. E. (1986). Graph-based algorithms for Boolean

function manipulation. IEEE Transactions on Com-

puters, C-35(8):677–691.

Christen, R., Eriksson, S., Katz, M., Muise, C., Petrov, A.,

Pommerening, F., Seipp, J., Sievers, S., and Speck, D.

(2023). PARIS: planning algorithms for reconﬁguring

independent sets. In Gal, K., Now

e, A., Nalepa, G. J.,

Fairstein, R., and Radulescu, R., editors, ECAI 2023

- 26th European Conference on Artiﬁcial Intelligence,

September 30 - October 4, 2023, Krak

ow, Poland - In-

cluding 12th Conference on Prestigious Applications

of Intelligent Systems (PAIS 2023), volume 372 of

Frontiers in Artiﬁcial Intelligence and Applications,

pages 453–460. IOS Press.

Hayase, K., Sadakane, K., and Tani, S. (1995). Output-size

sensitiveness of OBDD construction through maximal

independent set problem. In Du, D.-Z. and Li, M., ed-

itors, Computing and Combinatorics, pages 229–234,

Berlin, Heidelberg. Springer Berlin Heidelberg.

Ito, T., Demaine, E. D., Harvey, N. J. A., Papadimitriou,

C. H., Sideri, M., Uehara, R., and Uno, Y. (2011). On

the complexity of reconﬁguration problems. Theoret-

ical Computer Science, 412(12–14):1054–1065.

Ito, T., Kawahara, J., Nakahata, Y., Soh, T., Suzuki, A.,

Teruyama, J., and Toda, T. (2023). ZDD-based al-

gorithmic framework for solving shortest reconﬁgu-

ration problems. In 20th International Conference

on the Integration of Constraint Programming, Artiﬁ-

cial Intelligence, and Operations Research (CPAIOR

2023), pages 167–183.

Kami

nski, M., Medvedev, P., and Milani

c, M. (2011).

Shortest paths between shortest paths. Theoretical

Computer Science, 412(39):5205–5210.

Kawahara, J., Inoue, T., Iwashita, H., and Minato, S.

(2017). Frontier-based search for enumerating all con-

strained subgraphs with compressed representation.

IEICE Transactions on Fundamentals of Electron-

ics, Communications and Computer Sciences, E100-

A(9):1773–1784.

Knuth, D. E. (2011). The Art of Computer Program-

ming, Volume 4A, Combinatorial Algorithms, Part 1.

Addison-Wesley Professional, 1st edition.

Minato, S. (1993). Zero-suppressed BDDs for set manip-

ulation in combinatorial problems. In Proc. of the

30th ACM/IEEE design automation conference, pages

272–277.

Nishimura, N. (2018). Introduction to reconﬁguration. Al-

gorithms, 11(4):52.

Okuno, H. G., Minato, S., and Isozaki, H. (1998). On the

properties of combination set operations. Information

Processing Letters, 66(4):195–199.

Soh, T., Okamoto, Y., and Ito, T. (2022). Core chal-

lenge 2022: Solver and graph descriptions. CoRR,

abs/2208.02495.

Toda, T., Ito, T., Kawahara, J., Soh, T., Suzuki, A., and

Teruyama, J. (2023). Solving reconﬁguration prob-

lems of ﬁrst-order expressible properties of graph ver-

tices with boolean satisﬁability. In The 35th IEEE In-

ternational Conference on Tools with Artiﬁcial Intel-

ligence, pages 294–302.

Yamada, Y., Banbara, M., Inoue, K., and Schaub, T.

(2023). Recongo: Bounded combinatorial recon-

ﬁguration with answer set programming. In Logics

in Artiﬁcial Intelligence: 18th European Conference,

JELIA 2023, Dresden, Germany, September 20–22,

2023, Proceedings, pages 278–286, Berlin, Heidel-

berg. Springer-Verlag.

ICAART 2024 - 16th International Conference on Agents and Artiﬁcial Intelligence

648
