Animating NeRFs from Texture Space: A Framework for

Pose-Dependent Rendering of Human Performances

Paul Knoll

1,3 a

, Wieland Morgenstern

1 b

, Anna Hilsmann

1,2 c

and Peter Eisert

1,2 d

Fraunhofer Heinrich Hertz Institute, HHI, Germany

Humboldt University of Berlin, Germany

Johannes Kepler University Linz, Germany

ﬁ

Keywords:

Computer Vision Representations, Neural Radiance Fields, Animation, Rendering.

Abstract:

Creating high-quality controllable 3D human models from multi-view RGB videos poses a signiﬁcant chal-

lenge. Neural radiance ﬁelds (NeRFs) have demonstrated remarkable quality in reconstructing and free-

viewpoint rendering of static as well as dynamic scenes. The extension to a controllable synthesis of dynamic

human performances poses an exciting research question. In this paper, we introduce a novel NeRF-based

framework for pose-dependent rendering of human performances. In our approach, the radiance ﬁeld is warped

around an SMPL body mesh, thereby creating a new surface-aligned representation. Our representation can be

animated through skeletal joint parameters that are provided to the NeRF in addition to the viewpoint for pose

dependent appearances. To achieve this, our representation includes the corresponding 2D UV coordinates

on the mesh texture map and the distance between the query point and the mesh. To enable efﬁcient learning

despite mapping ambiguities and random visual variations, we introduce a novel remapping process that re-

ﬁnes the mapped coordinates. Experiments demonstrate that our approach results in high-quality renderings

for novel-view and novel-pose synthesis.

1 INTRODUCTION

Creating fully animatable, high quality human avatars

has been a longstanding research question with signif-

icant potential impact. In visual applications involv-

ing human models, one desirable and essential capa-

bility is to render images from different viewpoints

while also having the ﬂexibility to manipulate the

pose as needed (Hilsmann et al., 2020). Traditional

methods for generating high-ﬁdelity human avatars

often come with a high cost, as they often require

manual modelling (Fechteler et al., 2019). Recently,

research has shifted towards using only 2D images to

capture and represent 3D human models. To achieve

this, the solution has to aggregate and distinguish vi-

sual information over time as the body performs 3D

motion.

Neural Radiance Fields (NeRFs) (Mildenhall

et al., 2021) have emerged as a powerful approach for

https://orcid.org/0009-0008-2990-1968

https://orcid.org/0000-0001-5817-7464

https://orcid.org/0000-0002-2086-0951

https://orcid.org/0000-0001-8378-4805

synthesizing photorealistic images of complex static

scenes and objects. This technique has shown re-

markable success in various domains, such as com-

puter graphics and virtual reality. However, the syn-

thesis of humans in unseen poses with NeRFs has re-

mained a challenging task, primarily due to the high

complexity and variability of human appearance. Var-

ious methods have been proposed to extend the NeRF

framework to encompass novel poses of dynamic hu-

mans (Noguchi et al., 2021; Liu et al., 2021; Peng

et al., 2021a; Xu et al., 2022; Zheng et al., 2022), but

so far none has achieved the ﬁdelity of static NeRFs.

The ability to generate controllable human synthesis

with NeRFs has the potential to substantially impact a

wide range of media production applications, includ-

ing avatar creation, telepresence, movie production,

gaming, and more.

In this paper, we present a novel NeRF-based

model, addressing the challenge of synthesizing hu-

mans in novel poses and views. Our work is inspired

by the idea of Xu et al. (Xu et al., 2022), transforming

the NeRF query space from absolute world coordi-

nates to surface-aligned coordinates. We ﬁnd a novel,

distinct, more compact representation of the NeRF

404

Knoll, P., Morgenstern, W., Hilsmann, A. and Eisert, P.

Animating NeRFs from Texture Space: A Framework for Pose-Dependent Rendering of Human Performances.

DOI: 10.5220/0012373800003660

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 19th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2024) - Volume 4: VISAPP, pages

404-413

ISBN: 978-989-758-679-8; ISSN: 2184-4321

Figure 1: Synthesized images of the hand wave sequence in novel view and novel pose.

space around the body, allowing a coherent represen-

tation across different poses. Additionally, we intro-

duce a neural network-based remapping of the query

coordinates to account for pose-dependent variations.

Speciﬁcally, our contributions are the following:

• We extend the NeRF framework to encompass

varying poses by introducing a novel surface

aligned uvh representation that is persistent be-

tween different frames and poses

• We introduce a novel uvh remapping process that

further reﬁnes this novel representation by ac-

counting for body model and ﬁtting inaccuracies

• We combine our method with the Instant-NGP

(Müller et al., 2022) multiresolution hash encod-

ing and adapt it to deal with our warped coor-

dinate space for signiﬁcantly improved training

times

2 RELATED WORK

Recent works have extended the Neural Radiance

Fields framework to model the time domain of dy-

namic scenes, including articulated models such as

humans in motion (Du et al., 2021; Park et al., 2021a;

Park et al., 2021b).

These approaches can be classiﬁed into

deformation-based methods such as Nerﬁes (Park

et al., 2021a) and HyperNeRF (Park et al., 2021b),

which mainly focus on the face, and other methods

that use human-prior information like skeletons,

parametric models like SMPL (Loper et al., 2015),

to account for deformations, such as HumanNeRF

(Weng et al., 2022). Still, these methods mainly focus

on free view-point rendering of the dynamic scenes

without the capability of modifying and animating

poses.

Very recently, researchers have proposed ﬁrst ap-

proaches towards controllable NeRFs by combining

them with mesh-based deformation, e.g. the SMPL

model (Peng et al., 2021a; Peng et al., 2021b; Xu

et al., 2022). These methods use the SMPL model

to learn a deformation ﬁeld (Liu et al., 2021; Noguchi

et al., 2021; Peng et al., 2021a) or directly learn a

NeRF on the surface (Xu et al., 2022; Zheng et al.,

2022).

Neural Body (Peng et al., 2021b) is a mesh-based

method that uses a per-vertex latent code to generate

a continuous latent code volume. Structured Local

Radiance Fields (Zheng et al., 2022) present a dis-

tinct approach in which a set of local radiance ﬁelds

is anchored to pre-deﬁned nodes of a body template.

Surface-Aligned NeRFs (Xu et al., 2022) present an-

other mesh-based approach, where the neural scene

representation is deﬁned on the surface points of a

human body mesh along with their signed distances

from the surface. While our method is inspired by

the work of Xu et al. (Xu et al., 2022), we propose

a more compact representation of the NeRF space

around the body, allowing a consistent representation

in pose space. Despite recent advancements in the

dynamic rendering of human models using NeRFs

with controllable pose, limitations persist, primarily

in the form of inferior image quality when compared

to static NeRFs.

One challenge with the vanilla NeRF approach

and the extensions is the time-consuming nature of the

training. To address the multi-day training time, re-

cent works have proposed various encoding schemes

to reduce costly backpropagation through deep net-

works. For instance, Instant-NGP (Müller et al.,

2022) employs a learned parametric multiresolution

hash encoding, simultaneously trained with the NeRF

MLPs. This leads to a signiﬁcant improvement in

training and inference speed, as well as scene recon-

struction accuracy. TensorRF (Chen et al., 2022), on

the other hand, uses a neural-network-free volume

rendering approach, where a scalar density and a vec-

tor color feature are stored in a 3D voxel grid. We

Animating NeRFs from Texture Space: A Framework for Pose-Dependent Rendering of Human Performances

405

Surface

Aligned

Mapping

NeRF

ResNet

Pose

Encoder

Multiresolution

Hashtable

UVH

remapping

SMPL pose

Ray query

point

Global Ray

direction

Color

Density

uvh

uvh’

Inputs

Outputs Function Blocks Intermediate Results

Local

direction d

Figure 2: Network architecture of the proposed UVH-NeRF.

leverage the training time improvement that Instant-

NGP achieved, by incorporating the multi resolution

hash encoding in our model.

3 UVH-NeRF FOR POSE

CONTROL

Our novel framework for NeRF based human rep-

resentation with pose control leverages the SMPL

(Loper et al., 2015) model as a prior for human poses.

Around the model, we construct a novel NeRF space

that is based on the projected 2D uv texture coordi-

nates of the SMPL mesh and its distance to the ray

query point. Thereby, we obtain a novel space (in

which we embed the NeRF ray query coordinates)

that is ﬁxed for all frames and poses. In addition, the

NeRF is controlled by a set of encoded joint angles

representing body pose. Though this procedure, we

achieve a fully animatable human model that can be

animated by simply adapting the SMPL pose param-

eters to the desired pose, while the NeRF is queried

to render high-quality free-viewpoint pose-dependent

images. In the following sections, we explain the uti-

lized data and the architecture of our model in detail.

3.1 Datasets

We use two different datasets for training and evalua-

tion.

First, we use our own dataset consisting of record-

ings of an actress performing a variety of tasks. These

recordings consist of 16 equally spaced camera pairs

on three different height levels. The images are

captured with a resolution of 3840x5120 pixels and

downscaled to 960x1280 pixels for further process-

ing. They show the actress in a well-lit environment

in front of a bright background. We asked the actress

to perform a variety of tasks, including hand gestures,

talking and whole body gestures, to aid us in building

an interactive model. The selection of the frames used

for training is described in Section 4.

Additionally, we use the ZJU-MoCap dataset

(Fang et al., 2021; Peng et al., 2021b) from Zhejiang

University, which was recorded using 21 cameras on

the same height level around an actor performing nat-

ural movements, for evaluation. The ZJU data already

contains ﬁtted SMPL parameters.

3.1.1 Preprocessing: SMPL Pose and Shape

Fitting

The suggested NeRF framework leverages the SMPL

model as a prior for human body shape and pose and

thus needs the corresponding pose and shape parame-

ters for each frame of the training sequence. To es-

timate SMPL parameters from recorded sequences,

we use an improved version of EasyMocap (ZJU3DV,

2021). EasyMocap is an open source toolbox for

human pose and shape estimation from multi-view

videos. While the original version of EasyMocap re-

lies on OpenPose (Cao et al., 2019) keypoints for the

optimization, we expanded it to incorporate an ad-

ditional loss on the 3D mesh reconstructed from the

multiview data (Chen et al., 2021) (which we will call

scan in the following). For this loss, we calculate the

shortest distance between the vertices of the current

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

406

best SMPL estimate, and the faces of the scan during

optimization of the shape and body pose parameters.

An example of a ﬁtted frame is depicted in Figure 3.

Figure 3: Depiction of complete SMPL ﬁtting process.

Left: ﬁtted SMPL model with distance to scan coloured

in green and red. Green represents a distance of zero, red

larger distances (up to a threshold). Right: scan, shifted to

the right for better comparison. The arrows in the back-

ground represent the locations of the cameras.

3.2 Network Overview

In this section, we present the architecture of our

proposed model. Our goal is to facilitate rendering

of human representations in unseen poses. In or-

der to achieve this objective, we have integrated con-

cepts from coordinate transformation, encoding and

remapping, along with a preprocessing of the query

points. With these extensions, our method differs sig-

niﬁcantly from the original NeRF network (Milden-

hall et al., 2021): The changes made to the original

model primarily focus on the processing of 3D query

points to extract density and color values. While our

method provides a novel parametrized scene repre-

sentation, we can use off-the-shelf NeRF sampling

methods when querying our customized scene to form

the ﬁnal 2D image. We choose to use the ray march-

ing procedure for sampling and combining points into

an image from (Müller et al., 2022) and will not fur-

ther explore the topic of sampling in this section.

Firstly, in order to allow for pose-dependent ren-

dering, we transform the set of query points to a novel

surface-aligned coordinate system, warped around the

mesh surface, utilizing the SMPL model as a prior.

During training, the query points in the new surface-

aligned space are remapped using a learned frame em-

bedding, correcting inaccuracies arising from both the

body prior and the ﬁtting process. Finally, the new co-

ordinates are processed in a modiﬁed NeRF network

together with the encoded body pose. The network’s

primary workﬂow, function blocks, input, and output

parameters are illustrated in Figure 2. They will be

explained step-by-step in the following paragraphs.

Additionally to the ray direction d ∈ R

and the

ray query point x ∈ R

, which serve as inputs for the

standard NeRF model, we provide the SMPL pose

and shape parameters of the corresponding frame to

the network to learn a pose-dependent representation

of color and density. The SMPL parameters are used

in various ways in this approach, and are estimated in

advance, as detailed in Chapter 3.1.1.

The initial estimations of the pose parameters are

then further improved during the NeRF training, by

leveraging a differentiable SMPL model, while the

body shape estimations stay constant for all frames of

the same person. The resulting improvement in ren-

dering quality is discussed in Chapter 4.

3.2.1 Surface-Aligned Mapping

To enable the model to represent humans in differ-

ent poses and motion, the coordinate system we op-

erate in is attached to a controllable surface mesh in-

stead of using a static global one. The goal is to ob-

tain the density and color values of a speciﬁc point in

the global coordinate system from a nearby point on

a surface mesh and its respective distance. This way,

when the pose of the human changes, the body prior

can be modiﬁed accordingly with the corresponding

parameters, and the network is still able to recon-

struct the scene correctly. Generally, this approach

allows for a simple way to model dynamic objects

of all kinds given a deformable mesh. In this work,

the human body is implemented using SMPL (Loper

et al., 2015).

The surface aligned function block is denoted by

(x,

⃗

β,

⃗

θ), with SMPL shape parameters

⃗

β ∈ R

SMPL pose parameters

⃗

θ ∈ R

, and 3D query point

x. The frame speciﬁc surface mesh is reconstructed

with the pre-ﬁtted pose and shape parameters. For

each query point x, a corresponding surface point s on

the mesh is found by the dispersed projection method,

as detailed in (Xu et al., 2022). We use the dispersed

projection method instead of the nearest point projec-

tion, as it does not suffer from the indistinguishability

issue near the edges of the mesh. Thereby, new sur-

face aligned query points uvh ∈ R

are obtained, con-

sisting of the uv texture coordinates of the correspond-

ing surface point s and the signed distance h from the

query point x to s. While u and v are naturally in

[0,1], the height is normalized by the maximum con-

sidered distance h

max

from the mesh surface. If the

query point has a distance of more than h

max

to the

mesh surface, a density of zero is returned.

Furthermore, a new local view direction d

is pro-

duced by the function block. The local view direction

is deﬁned in the local coordinates, i.e. the coor-

Animating NeRFs from Texture Space: A Framework for Pose-Dependent Rendering of Human Performances

407

dinates formed by the normal, tangent, and bi-tangent

directions on the surface of the posed mesh at the pro-

jected point s (Xu et al., 2022). In contrast, the global

view direction d is deﬁned in the global coordinate

system, and represents the global direction of the ray.

The local and global view direction are encoded

using a concatenation of the original (3D) values and

the frequency encoding (Vaswani et al., 2017) func-

tion shown in Equation (1), scaling the input accord-

ing to L frequency bands and injecting the result into

alternating sine and cosine functions:

γ(p) =



sin(2

πp),cos(2

πp),...,

sin(2

L−1

πp),cos(2

L−1

πp)



(1)

where L = 6, leading to encoded directions d, d

∈

. By transforming the input into a higher-

dimensional representation, this encoding method en-

ables easier pattern recognition within the input data,

potentially improving the model’s ability to learn and

generalize. The encoded global and local view direc-

tions are concatenated and used together in the NeRF

ResNet color subnetwork, similarly to the standard

NeRF procedure (Mildenhall et al., 2021).

While the SMPL shape is only used directly for

the mesh generation, in the surface aligned mapping

function block, the pose is encoded in the pose en-

coder E

pose

: R

7→ R

for later use. We adapt the

latent pose dimension P

with respect to the number

of different poses the model had to account for. The

pose encoder E

pose

consists of a simple neural net-

work with one linear layer and a hyperbolic tangent

(Tanh) output activation function and is trained jointly

with the rest of the network. E

pose

is employed to

create a rich and informative latent code of the pose

dependent features and differences in appearance.

3.2.2 UVH Remapping

As the surface geometry of the SMPL model cannot

model the real human surfaces in sufﬁcient detail and

due to inaccuracies and variations in ﬁtting the model

to real data, we introduce a uvh-remapping subnet-

work to enable the network to learn a sharp repre-

sentation despite these misalignments. The network

takes two inputs: the learned pose embedding

⃗

enc

and the surface aligned coordinates uvh. The network

calculates an offset ∆uvh = F

(uvh,E

pose

), where ψ

represents the weights of the neural network. From

these offsets, we obtain the remapped surface aligned

coordinates uvh

′

= uvh + ∆uvh.

The neural network F

of the remapping module

consists of three linear layers with ReLU activation

and a scaled Tanh output activation function. This

way, the maximum possible distance the network can

remap the query points is limited, to avoid undesired

large offsets. Furthermore, an additional loss is intro-

duced by the sum of the total offsets, to keep them

limited to where they are really useful and necessary

for a sharp representation.

3.2.3 Multiresolution Hash Encoding

In the original NeRF paper, the authors found that

having the NeRF network F

operate directly on the

3D query points x leads to poorly represented high

frequency variation in color and geometry (Milden-

hall et al., 2021). Therefore, the authors employ the

frequency encoding in Equation (1) to map the inputs

to a higher dimensional space. Subsequently, in the

Instant-NGP paper (Müller et al., 2022), a new im-

proved encoding method named multiresolution hash

encoding was proposed, which signiﬁcantly speeds up

training time.

The technical details of this approach can be found

in (Müller et al., 2022). Fundamentally, voxel grids

on different resolution levels are employed, contain-

ing learnable parameters in their corners. While the

parameters can be mapped one to one to the corners

on the coarser levels, on the ﬁner levels a hash map-

ping is introduced. The values of the correspond-

ing corner parameters on each level are then inter-

polated linearly and concatenated to obtain a repre-

sentation for every resolution. While Instant-NGP

operates in the static 3D space, our proposed model

resides in the warped space around the mesh of the

given person. In our approach, we feed the remapped

surface aligned coordinates uvh

′

into the multireso-

lution hash encoding E

hash

instead of the absolute

3D world coordinates x in Instant-NGP. This leads to

hash

: R

N×3

7→ R

N×(L·F)

, with the number of levels

L = 16 and feature dimension F = 4. The remain-

ing parameters of the encoding stay the same as in

(Müller et al., 2022), while N represents the dynamic

number of query points in one forward pass of the

network.

3.2.4 NeRF ResNet

In order to enable the network to account for various

pose dependent feature variations in the same surface

aligned coordinate uvh

′

, we introduce a NeRF ResNet

into the architecture. The idea of a NeRF ResNet was

introduced by Xu et al. (Xu et al., 2022). Its archi-

tecture is similar to the one of the original NeRF net-

work (Mildenhall et al., 2021), which can be divided

into two separate MLPs. The ﬁrst one takes the en-

coded query point x

enc

and produces the density σ and

a feature vector. The second one takes the feature vec-

tor and the encoded ray direction d

enc

and produces

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

408

the RGB color values. While we maintain the sec-

ond network unchanged, the ﬁrst one is substituted by

a ResNet (He et al., 2016), consisting of 5 residual

blocks with a layer width of 64 neurons., with the en-

coded pose

⃗

enc

as an additional (residual) input.

The NeRF ResNet receives the encoded remapped

surface aligned coordinates uvh

′

enc

, and the encoded

pose

⃗

enc

as inputs, producing the density σ and the

feature vector. Finally, the feature vector and the

encoded and concatenated local and global view di-

rection d

enc

⊕ d

l,enc

, are fed into the RGB network,

consisting of 2 linear layers, ReLU activation func-

tion and Sigmoid output activation, producing the ﬁ-

nal RGB values.

With this, our new model is complete. Thanks

to the incorporation of the ResNet and the remap-

ping module, the network has two mechanisms to

account for pose dependent visual variations in our

new surface aligned space that would otherwise result

in blurry representations. In essence, the remapping

is intended to correct the imperfections of the body

model and its ﬁtting by mapping the uvh coordinates

to their ideal position, while the ResNet is capable

of accommodating pose-dependent differences in ap-

pearance, such as clothing folds. As a result, we ob-

tain a fully animatable human body model that can be

controlled by adapting the SMPL pose parameters

⃗

to the desired values.

4 EXPERIMENTS

To demonstrate the effectiveness of our model, we

implemented it on top of the torch-ngp (Tang, 2022)

library, which is a reimplementation of Instant-NGP

(Müller et al., 2022) leveraging the expressiveness of

Python and PyTorch (Paszke et al., 2019).

We conducted different experiments and provide

an additional ablation study. In all experiments, we

left one camera out to be able to evaluate the quality

of the novel view synthesis, and used the remaining

ones for training.

To mitigate the inﬂuence of the background in the

evaluation, the Peak Signal-to-Noise Ratio (PSNR) is

calculated only on the non-masked area of the ground

truth images, covering only the human body. This re-

sults in reduced PSNR values compared to other ap-

proaches. Creating high-quality controllable 3D hu-

man models from multi-view RGB videos poses a sig-

niﬁcant chal- lenge. Neural radiance ﬁelds (NeRFs)

have demonstrated remarkable quality in reconstruct-

ing and free- viewpoint rendering of static as well as

dynamic scenes. The extension to a controllable syn-

thesis of dynamic human performances poses an ex-

citing research question. In this paper, we introduce

a novel NeRF-based framework for pose-dependent

rendering of human performances. In our approach,

the radiance ﬁeld is warped around an SMPL body

mesh, thereby creating a new surface-aligned rep-

resentation. Our representation can be animated

through skeletal joint parameters that are provided to

the NeRF in addition to the viewpoint for pose depen-

dent appearances. To achieve this, our representation

includes the corresponding 2D UV coordinates on the

mesh texture map and the distance between the query

point and the mesh. To enable efﬁcient learning de-

spite mapping ambiguities and random visual varia-

tions, we introduce a novel remapping process that re-

ﬁnes the mapped coordinates. Experiments demon-

strate that our approach results in high-quality ren-

derings for novel-view and novel-pose synthesis. that

calculate the PSNR on the whole image, a method-

ological difference that does not diminish the satis-

factory visual quality achieved by our model.

We train all components of our model simultane-

ously. We train the models for 100,000 steps with a

batch size of 1 on the dataset. This results in training

times of less than 12 hours on a GeForce RTX 3090.

The rendering of novel images in 1024x1024 resolu-

tion takes about 25 seconds in our model, which is not

optimized for speed. We leverage the Adam optimizer

(Kingma and Ba, 2014) with a decaying learning rate

from 1e-2 to 1e-3.

To demonstrate the expressiveness of our model,

we train it on 20 equally spaced frames of our arm

rotation sequence. In this sequence, the actress stands

still with one arm to the side while the other arm is

performing a full rotation. We selected this sequence

to show that even this very limited training pose space

enables the model to generalize to unseen poses.

Figure 4 and 5 show exemplary qualitative results

of the novel view synthesis of this model. The model

is able to accurately reconstruct the image while pro-

ducing a natural and visually pleasing appearance.

In Figure 4, the rendered subject has her eyes open,

contrasting the closed eyes in the ground truth im-

age. This discrepancy illustrates the model’s capacity

to infer visual features, such as the eyes, from other

training frames. Figure 5 demonstrates accurate re-

construction of pose depended features in relation to

Figure 4, e.g. in the lifted shirt and the folds and shad-

ows of the shirt of the actress as her arm rises. On the

20 images of this validation set, we achieved an aver-

age PSNR of 28.64 dB.

We also test this model on novel poses, which is

the primary focus of our work. For this, we identify

a set of frames with highly diverse poses by perform-

ing a cluster analysis on the SMPL parameters of each

Animating NeRFs from Texture Space: A Framework for Pose-Dependent Rendering of Human Performances

409

(a) (b)

Figure 4: Qualitative comparison of (a) novel view synthe-

sis and (b) ground truth.

(a) (b)

Figure 5: Qualitative comparison of (a) novel view synthe-

sis and (b) ground truth.

frame of our datasets. We then manually selected 10

frames from different pose clusters that show natural

poses. By testing those frames with all of our train-

ing cameras, we achieved an average PSNR of 19.16

dB for the novel pose synthesis. Figure 6 and 7 show

qualitative results of novel pose synthesis. These two

poses were selected to show the ability of the network

to produce natural high ﬁdelity results of poses com-

pletely distinct to the training poses. Figure 6 shows

the actress with a tilted head, a pose that was not

seen during training. Figure 7 shows a synthesized

pose where the actress lifts one leg up, while she was

standing on both legs in all training frames. While

the result is visually plausible, the PSNR decreases.

This is expectable as (i) the model adheres to the leg

positioning of the SMPL model and encounters chal-

lenges to account for pose dependent variations, thus,

a slight misalignment between the synthesized leg and

the corresponding location in the ground truth is ob-

served, and (ii) remains of the folds around the neck

of the actress are visible in the synthesized images, as

the network has not seen images with both arms in a

lowered position.

(a) (b)

Figure 6: Qualitative comparison of (a) novel pose synthesis

and (b) ground truth.

(a) (b)

Figure 7: Qualitative comparison of (a) novel pose synthesis

and (b) ground truth.

We also show that our approach works on alterna-

tive data by training the model on a short sequence of

the ZJU-MoCap dataset. The quality of synthesized

frames is comparable to those reported in (Xu et al.,

2022), although a comparison is difﬁcult as we em-

ployed a distinct training conﬁguration. As a conse-

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

410

(a) (b)

Figure 8: Qualitative results on ZJU-MoCap data. Compar-

ison between (a) novel view synthesis and (b) ground truth,

and (c) novel pose synthesis and (d) ground truth.

quence, we present qualitative outcomes only to vali-

date the overall efﬁcacy of our model on foreign data

in Figure 8.

We trained another model on the hand wave se-

quence depicted in Figure 1 with only 5 selected

frames of the 85 frame sequence. The frames were

chosen in order to sample the whole range of the exe-

cuted motion to obtain the best result in synthesizing

unseen poses. The full result of the reconstructed 85

frames in a novel view can be seen as a video in the

supplementary materials, showcasing the possibility

to render natural looking human gestures with our ap-

proach. Notice the qualitative difference of the results

when optimizing the SMPL parameters during train-

ing. This results in a more accurate representation,

leading to sharper results and mitigation of holes in

the arms, which were not ﬁtted accurately. Further-

more, it is evident, that the model produces artifacts at

the right hand. Since the training dataset consistently

depicts the hand resting on the leg, the model faces

difﬁculty in differentiating the distinguishing charac-

teristics between the hand and the leg. Consequently,

errors occur when the hand is in motion. This limi-

tation can be mitigated by adding according training

samples.

4.1 Ablation Study

To show the inﬂuence of the main components of the

network, we present ablation results in Table 1. For

this study, we used the dataset with the 20 sampled

frames from our arm rotation sequence as in the novel

pose and view synthesis results. We show the re-

sults of the full approach, and an ablation of the cru-

cial components that allow for pose dependent feature

learning. First, the replacement of the NeRF ResNet

with the conventional NeRF MLP, without having the

encoded pose as an input. Furthermore, we show the

results without the uvh remapping module, and with-

out the ResNet and the remapping module. For the

sake of comparison, we trained all models for 100,000

steps in this study. As expected, we got the best re-

sults for the novel pose and the novel view synthesis

with our full approach. In the novel view synthesis, it

appears that one of the pose dependent modules is suf-

ﬁcient to nearly reach the quality of the full approach.

Unexpectedly, in the novel pose synthesis study, the

network performed better with no extra modules com-

pared to only the remapping module. It’s not clear if

this result is expressive about the quality of the pro-

duced images, as the largest inﬂuence on those values

is the shifted appearance. This greatly reduces the

PSNR values, even though the results might visually

look natural and as expected.

Table 1: Quantitative analysis of the ablation study: Evalu-

ation of Peak Signal-to-Noise Ratio (PSNR) in decibel (dB)

inside the non-masked area of the ground truth images. The

best results are highlighted in bold font.

Novel view Novel pose

full 28.64 19.16

w/o ResNet 28.24 18.52

w/o Remapping 28.20 19.04

w/o Both 26.82 18.98

5 CONCLUSIONS AND FUTURE

RESEARCH

We have introduced a novel NeRF-based frame-

work for pose-dependent rendering of human perfor-

mances. Our approach involves warping the NeRF

Animating NeRFs from Texture Space: A Framework for Pose-Dependent Rendering of Human Performances

411

space around an SMPL body mesh, resulting in a

surface-aligned representation that can be animated

through skeletal joint parameters. These joint param-

eters serve as additional input to the NeRF, allowing

for pose-dependent appearances in the rendered out-

put. Moreover, our representation includes 2D UV

coordinates on the mesh texture map and the distance

between the query point and the mesh, facilitating ef-

ﬁcient learning despite mapping ambiguities and ran-

dom visual variations.

Through extensive experiments, we have demon-

strated the effectiveness of our approach in generat-

ing high-quality renderings for novel-view and novel-

pose synthesis. The results showcase the capabilities

of our framework in producing visually appealing and

controllable 3D human models, offering realistic and

pose-dependent renderings, even from a very limited

set of training frames. In future, we plan to train the

model on a more diverse set of poses to enable even

more accurate reconstructions.

Although our model produces high-ﬁdelity ren-

derings, there remain aspects and challenges that have

room for enhancement. Primarily, as in similar meth-

ods, the model struggles with rendering individual

ﬁngers, as visible in Figure 1. We have been using the

standard SMPL model, which does not capture hand

geometry well and will improve by using models spe-

cialized on hands, such as SMPL-H, as well as custom

model ﬁtting for ﬁnger parameters.

ACKNOWLEDGEMENTS

This work has partly been funded by the German Fed-

eral Ministry of Education and Research (Voluprof,

grant no. 16SV8705) and the German Federal Min-

istry for Economic Affairs and Climate Action (To-

HyVe, grant no. 01MT22002A).

REFERENCES

Cao, Z., Hidalgo Martinez, G., Simon, T., Wei, S., and

Sheikh, Y. A. (2019). Openpose: Realtime multi-

person 2d pose estimation using part afﬁnity ﬁelds.

IEEE Transactions on Pattern Analysis and Machine

Intelligence.

Chen, A., Xu, Z., Geiger, A., Yu, J., and Su, H. (2022). Ten-

sorf: Tensorial radiance ﬁelds. In Computer Vision–

ECCV 2022: 17th European Conference, Tel Aviv, Is-

rael, October 23–27, 2022, Proceedings, Part XXXII,

pages 333–350. Springer.

Chen, D., Worchel, M., Feldmann, I., Schreer, O., and Eis-

ert, P. (2021). Accurate human body reconstruction

for volumetric video. In Proc. Int. Conf. on 3D Im-

mersion (IC3D).

Du, Y., Zhang, Y., Yu, H.-X., Tenenbaum, J. B., and Wu,

J. (2021). Neural radiance ﬂow for 4d view synthesis

and video processing. In Proc. of the IEEE/CVF In-

ternational Conference on Computer Vision (ICCV).

Fang, Q., Shuai, Q., Dong, J., Bao, H., and Zhou, X. (2021).

Reconstructing 3d human pose by watching humans in

the mirror. In CVPR.

Fechteler, P., Hilsmann, A., and Eisert, P. (2019). Marker-

less multiview motion capture with 3d shape model

adaptation. Computer Graphics Forum, 38(6):91–

109.

He, K., Zhang, X., Ren, S., and Sun, J. (2016). Deep resid-

ual learning for image recognition. In Proceedings of

the IEEE conference on computer vision and pattern

recognition, pages 770–778.

Hilsmann, A., Fechteler, P., Morgenstern, W., Paier, W.,

Feldmann, I., Schreer, O., and Eisert, P. (2020). Go-

ing beyond free viewpoint: Creating animatable volu-

metric video of human performances. IET Computer

Vision, Special Issue on Computer Vision for the Cre-

ative Industries, 14(6):350–358.

Kingma, D. P. and Ba, J. (2014). Adam: A

method for stochastic optimization. arXiv preprint

arXiv:1412.6980.

Liu, L., Habermann, M., Rudnev, V., Sarkar, K., Gu, J., and

Theobalt, C. (2021). Neural actor: Neural free-view

synthesis of human actors with pose control. ACM

Trans. Graph.(ACM SIGGRAPH Asia).

Loper, M., Mahmood, N., Romero, J., Pons-Moll, G., and

Black, M. (2015). Smpl: a skinned multi-person linear

model. volume 34.

Mildenhall, B., Srinivasan, P. P., Tancik, M., Barron, J. T.,

Ramamoorthi, R., and Ng, R. (2021). Nerf: Repre-

senting scenes as neural radiance ﬁelds for view syn-

thesis. Communications of the ACM, 65(1):99–106.

Müller, T., Evans, A., Schied, C., and Keller, A. (2022).

Instant neural graphics primitives with a multiresolu-

tion hash encoding. ACM Transactions on Graphics,

41(4):1–15.

Noguchi, A., Sun, X., Lin, S., and Harada, T. (2021). Neu-

ral articulated radiance ﬁeld. In Proc. International

Conference on Computer Vision (ICCV).

Park, K., Sinha, U., Barron, J. T., Bouaziz, S., Goldman,

D. B., Seitz, S. M., and Martin-Brualla, R. (2021a).

Nerﬁes: Deformable neural radiance ﬁelds. In Proc.

International Conference on Computer Vision (ICCV).

Park, K., Sinha, U., Hedman, P., Barron, J. T., Bouaziz, S.,

Goldman, D. B., Martin-Brualla, R., and Seitz, S. M.

(2021b). Hypernerf: A higher-dimensional represen-

tation for topologically varying neural radiance ﬁelds.

ACM Transaction on Graphics, 40(6).

Paszke, A., Gross, S., Massa, F., Lerer, A., Bradbury, J.,

Chanan, G., Killeen, T., Lin, Z., Gimelshein, N.,

Antiga, L., et al. (2019). Pytorch: An imperative style,

high-performance deep learning library. Advances in

neural information processing systems, 32.

Peng, S., Dong, J., Wang, Q., Zhang, S., Shuai, Q., Zhou,

X., and Bao, H. (2021a). Animatable neural radiance

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

412

ﬁelds for modeling dynamic human bodies. In Proc.

International Conference on Computer Vision (ICCV.

Peng, S., Zhang, Y., Xu, Y., Wang, Q., Shuai, Q., Bao, H.,

and Zhou, X. (2021b). Neural body: Implicit neural

representations with structured latent codes for novel

view synthesis of dynamic humans. In Proc. of the

IEEE/CVF Conference on Computer Vision and Pat-

tern Recognition, pages 9054–9063.

Tang, J. (2022). Torch-ngp: a pytorch implementation of

instant-ngp. https://github.com/ashawkey/torch-ngp.

Vaswani, A., Shazeer, N., Parmar, N., Uszkoreit, J., Jones,

L., Gomez, A. N., Kaiser, Ł., and Polosukhin, I.

(2017). Attention is all you need. Advances in neural

information processing systems, 30.

Weng, C.-Y., Curless, B., Srinivasan, P. P., Barron, J. T.,

and Kemelmacher-Shlizerman, I. (2022). Human-

nerf: Free-viewpoint rendering of moving people

from monocular video. In Proc. IEEE/CVF Con-

ference on Computer Vision and Pattern Recognition

(CVPR).

Xu, T., Fujita, Y., and Matsumoto, E. (2022). Surface-

aligned neural radiance ﬁelds for controllable 3d hu-

man synthesis. In Proc. International Conference on

Pattern Recognition (CVPR, pages 15862–15871.

Zheng, Z., Huang, H., Yu, T., Zhang, H., Guo, Y., and

Liu, Y. (2022). Structured local radiance ﬁelds for

human avatar modeling. In Proc. of the IEEE/CVF

Conference on Computer Vision and Pattern Recogni-

tion (CVPR).

ZJU3DV (2021). Easymocap - make human motion capture

easier. Github Repository, https://github.com/zju3dv/

EasyMocap.

Animating NeRFs from Texture Space: A Framework for Pose-Dependent Rendering of Human Performances

413
