Probabilistic Model Checking of Stochastic Reinforcement Learning
Policies
Dennis Gross and Helge Spieker
Simula Research Laboratory, Norway
Keywords:
Reinforcement Learning, Model Checking, Safety.
Abstract:
We introduce a method to verify stochastic reinforcement learning (RL) policies. This approach is compatible
with any RL algorithm as long as the algorithm and its corresponding environment collectively adhere to the
Markov property. In this setting, the future state of the environment should depend solely on its current state
and the action executed, independent of any previous states or actions. Our method integrates a verification
technique, referred to as model checking, with RL, leveraging a Markov decision process, a trained RL policy,
and a probabilistic computation tree logic (PCTL) formula to build a formal model that can be subsequently
verified via the model checker Storm. We demonstrate our method’s applicability across multiple benchmarks,
comparing it to baseline methods called deterministic safety estimates and naive monolithic model checking.
Our results show that our method is suited to verify stochastic RL policies.
1 INTRODUCTION
Reinforcement Learning (RL) has revolutionized the
industry, enabling the creation of agents that can
outperform humans in sequential decision-making
tasks (Mnih et al., 2013a; Silver et al., 2016; Vinyals
et al., 2019).
In general, an RL agent aims to learn a near-
optimal policy to achieve a fixed objective by taking
actions and receiving feedback through rewards and
observations from the environment (Sutton and Barto,
2018). We call a policy memoryless policy if it only
decides based on the current observation. A determin-
istic policy selects the same action in response to a
specific observation every time, whereas a stochastic
policy might select different actions when faced with
the same observation. A popular choice is to employ
a function approximator like a neural network (NN)
to model such policies.
RL Problem. Unfortunately, learned policies are
not guaranteed to avoid unsafe behavior (Garc
´
ıa and
Fern
´
andez, 2015; Carr et al., 2023; Alshiekh et al.,
2018). Generally, rewards lack the expressiveness to
encode complex safety requirements (Littman et al.,
2017; Hahn et al., 2019; Hasanbeig et al., 2020; Vam-
plew et al., 2022).
To resolve the issues mentioned above, verifica-
tion methods like model checking (Baier and Ka-
toen, 2008) are used to reason about the safety of
RL, see for instance (Wang et al., 2020; Hasanbeig
et al., 2020; Br
´
azdil et al., 2014; Hahn et al., 2019).
Model checking is not limited by properties that can
be expressed by rewards but support a broader range
of properties that can be expressed by probabilistic
computation tree logic (PCTL; Hansson and Jonsson,
1994). At its core, model checking is a formal ver-
ification technique that uses mathematical models to
verify the correctness of a system concerning a given
(safety) property.
Hard to Verify. While existing research focuses on
verifying stochastic RL policies (Bacci and Parker,
2020; Bacci et al., 2021; Bacci and Parker, 2022),
these existing verification methods do not scale well
with neural network policies that contain many layers
and neurons.
Approach. This paper presents a method for veri-
fying memoryless stochastic RL policies independent
of the number of NN layers, neurons, or the specific
memoryless RL algorithm.
Our approach hinges on three inputs: a Markov
Decision Process (MDP) modeling the RL environ-
ment, a trained RL policy, and a probabilistic compu-
tation tree logic (PCTL) formula (Hansson and Jons-
son, 1994) specifying the safety measurement. Using
438
Gross, D. and Spieker, H.
Probabilistic Model Checking of Stochastic Reinforcement Learning Policies.
DOI: 10.5220/0012357700003636
Paper published under CC license (CC BY-NC-ND 4.0)
In Proceedings of the 16th International Conference on Agents and Artificial Intelligence (ICAART 2024) - Volume 3, pages 438-445
ISBN: 978-989-758-680-4; ISSN: 2184-433X
Proceedings Copyright © 2024 by SCITEPRESS – Science and Technology Publications, Lda.

an incremental building process (Gross et al., 2022;
Cassez et al., 2005; David et al., 2015) for the for-
mal verification, we build only the reachable MDP
portion by the trained policy. Utilizing Storm as
our model checker (Hensel et al., 2022), we assess
the policy’s safety measurement, leveraging the con-
structed model and the PCTL formula.
Our method is evaluated across various RL bench-
marks and compared to an alternative approach that
only builds the part of the MDP that is reachable via
the highest probability actions and an approach called
naive monolithic model checking. The results confirm
that our approach is suitable for verifying stochastic
RL policies.
2 RELATED WORK
There exist a variety of related work focusing on the
trained RL policy verification (Eliyahu et al., 2021;
Kazak et al., 2019; Corsi et al., 2021; Dr
¨
ager et al.,
2015; Zhu et al., 2019; Jin et al., 2022). Bacci and
Parker (2020) propose MOSAIC (MOdel SAfe Intel-
ligent Control), which combines abstract interpreta-
tion and probabilistic verification to establish prob-
abilistic guarantees of safe behavior. The authors
model the system as a continuous-space discrete-time
Markov process and focus on finite-horizon safety
specifications. They tackle the challenges of infi-
nite initial configurations and policy extraction from
NN representation by constructing a finite-state ab-
straction as an MDP and using symbolic analysis of
the NN. The main difference to our approach lies in
constructing the induced discrete-time Markov chain
(DTMC). Our approach verifies a specific probabilis-
tic policy derived from an MDP. In contrast, the MO-
SAIC approach verifies safety guarantees by creating
a finite-state abstraction of the MDP that accommo-
dates the NN-based policy and focuses on finding safe
regions of initial configurations. The abstraction must
also extract the policy from its NN representation.
Our approach only queries the trained policy and is
not limited by the time horizon.
Bacci et al. (2021) presented the first technique for
verifying if a NN policy controlling a dynamical sys-
tem maintains the system within a safe region for an
unbounded time. The authors use template polyhedra
to overapproximate the reach set and formulate the
problem of computing template polyhedra as an opti-
mization problem. They introduce a MILP (Mixed-
Integer Linear Programming) encoding for a sound
abstraction of NNs with ReLU activation functions
acting over discrete-time systems. Their method sup-
ports linear, piecewise linear, and non-linear systems
with polynomial and transcendental functions. The
safety verification verifies agents against a model of
the environment. The main difference to our approach
is that we are independent of the memoryless policy
architecture and do not need to encode the verification
problem as a MILP problem.
Bacci and Parker (2022) define a formal model
of policy execution using continuous-state, finite-
branching discrete-time Markov processes and build
and solve sound abstractions of these models. The
paper proposes a new abstraction based on interval
Markov decision processes (IMDPs) to address the
challenge of probabilistic policies specifying different
action distributions across states. The authors present
methods to construct IMDP abstractions using tem-
plate polyhedra and MILP for reasoning about the NN
policy encoding and the RL agent’s environment. Fur-
thermore, they introduce an iterative refinement ap-
proach based on sampling to improve the precision of
the abstractions.
Gross et al. (2022) incrementally build a formal
model of the trained RL policy and the environment.
They then use the model checker Storm to verify the
policy’s behavior. They support memoryless stochas-
tic policies by always choosing the action with the
highest probability (deterministic safety estimation).
In comparison, we build the model based on all pos-
sible actions with a probability greater than zero.
3 BACKGROUND
This section describes probabilistic model checking
and investigates RL’s details.
3.1 Probabilistic Model Checking
A probability distribution over a set X is a function
µ: X → [0, 1] with
∑
x∈X
µ(x) = 1. The set of all dis-
tributions on X is denoted Distr(X ).
Definition 1 (Markov Decision Process). A
Markov decision process (MDP) is a tuple
M = (S, s
0
, Act, Tr, rew,AP, L) where S is a finite,
nonempty set of states; s
0
∈ S is an initial state; Act is
a finite set of actions; Tr : S × Act → Distr(S)
is a partial probability transition function;
rew: S × Act → R is a reward function; AP is a
set of atomic propositions; L : S → 2
AP
is a labeling
function that assigns atomic propositions to states.
We employ a factored state representation where
each state s is a vector of features ( f
1
, f
2
, ..., f
d
) where
each feature f
i
∈ Z for 1 ≤ i ≤ d (d is the dimension
of the state). Furthermore, we denote Tr(s, a)(s
0
) with
Probabilistic Model Checking of Stochastic Reinforcement Learning Policies
439

Tr(s, a, s
0
) and Tr(s, a, s
0
) can be written as s
a
−→ s
0
. If
| Act(s) |= 1, we can omit the action a in Tr(s, a, s
0
)
and write Tr(s, s
0
). Also, we define NEIGH(s) for the
set of all states s
0
∈ S that Tr(s, s
0
) 6= 0.
The available actions in s ∈ S are Act(s) = {a ∈
Act | Tr(s, a) 6= ⊥} where Tr(s, a) 6= ⊥ is defined as
action a at state s does not have a transition (action
a is not available in state s). An MDP with only one
action per state (∀s ∈ S :| Act(s) |= 1) is a DTMC D.
Definition 2 (Discrete-time Markov Chain). A
discrete-time Markov chain (DTMC) is an MDP such
that | Act(s) |= 1 for all states s ∈ S. We denote a
DTMC as a tuple M
D
= (S, s
0
, Tr, rew) with S, s
0
, rew
as in Definition 1 and transition probability function
Tr : S → Distr(S).
When an agent is executed in an environment
modeled as an MDP, a policy is a rule that an agent
follows in deciding which action to take based on its
current observation of the state of the environment to
optimize its objective.
Definition 3 (Deterministic Policy). A mem-
oryless deterministic policy for an MDP
M=(S, s
0
, Act, Tr, rew) is a function π: S → Act
that maps a state s ∈ S to action a ∈ Act.
Applying a policy π to an MDP M yields an in-
duced DTMC D where all non-determinisms within
the system are resolved.
Definition 4 (Stochastic Policy). A memoryless
stochastic policy for an MDP M=(S, s
0
, Act, T, rew) is
a function
ˆ
π: S → Distr(Act) that maps a state s ∈ S
to distribution over actions Distr(Act).
Permissive policies facilitate a richer exploration
of the state space by allowing the selection of multi-
ple actions at each observation, potentially uncover-
ing nuanced policies.
Definition 5 (Permissive Policy). A permissive policy
τ: S → 2
Act
selects multiple actions in every state.
We specify the properties of a DTMC via the spec-
ification language PCTL (Wang et al., 2020).
Definition 6 (PCTL Syntax). Let AP be a set of
atomic propositions. The following grammar defines
a state formula: Φ ::= true | a | Φ
1
∧ Φ
2
| ¬Φ |
P
p
| P
max
p
(φ) | P
min
p
(φ) where a ∈ AP, ∈ {<, >, ≤
, ≥}, p ∈ [0, 1] is a threshold, and φ is a path formula
which is formed according to the following grammar
φ ::= XΦ | φ
1
U φ
2
| φ
1
F
θ
i
t
φ
2
with θ
i
= {<, ≤}.
We further define “eventually” as ♦φ
:
= true U φ.
For MDPs, PCTL formulae are interpreted over
the states of the induced DTMC of an MDP and
a policy. In a slight abuse of notation, we use
RL Agent
Environment
Action
New State, Reward
Figure 1: This diagram represents an RL system in which
an agent interacts with an environment. The agent receives
a state and a reward from the environment based on its pre-
vious action. The agent then uses this information to select
the next action, which it sends to the environment.
PCTL state formulas to denote probability values.
That is, we sometimes write P
p
(φ) where we
omit the threshold p. For instance, in this pa-
per, P(♦coll) denotes the reachability probability
of eventually running into a collision. There exist
a variety of model checking algorithms for verify-
ing PCTL properties (Courcoubetis and Yannakakis,
1988, 1995). PRISM (Kwiatkowska et al., 2011) and
Storm (Hensel et al., 2022) offer efficient and mature
tool support for verifying probabilistic systems.
3.2 Reinforcement Learning
For MDPs with many states and transitions, obtaining
optimal policies π
∗
is difficult. The standard learn-
ing goal for RL is to learn a policy π in an MDP
such that π maximizes the accumulated discounted re-
ward, that is, E[
∑
N
t=0
γ
t
R
t
], where γ with 0 ≤ γ ≤ 1 is
the discount factor, R
t
is the reward at time t, and N
is the total number of steps (see Figure 1). In RL,
an agent learns through interaction with its environ-
ment to maximize a reward signal, via RL algorithm
such as deep Q-learning (Mnih et al., 2013b). Note
that rewards lack the expressiveness to encode com-
plex safety requirements which can be specified via
PCTL (Littman et al., 2017; Hahn et al., 2019; Hasan-
beig et al., 2020; Vamplew et al., 2022). Therefore,
model checking is needed to verify that the trained
RL policies satisfy the complex requirements.
4 METHODOLOGY
In this section, we introduce a method for verifying
the safety of stochastic RL policies via probabilis-
tic model checking concerning a safety measurement.
Given the MDP M of the environment, a trained RL
policy
ˆ
π, and a safety measurement m, the general
workflow is as follows and will be detailed below:
1. Induced MDP Construction: We construct a
new MDP using the original MDP and the trained
RL policy
ˆ
π. This new MDP includes only the
states that are reachable by the policy and actions
ICAART 2024 - 16th International Conference on Agents and Artificial Intelligence
440

that the policy considers, i.e., those for which the
policy selection probability is greater than zero.
2. Induced DTMC Transformation: The newly
constructed MDP
ˆ
M is transformed into an in-
duced DTMC, denoted as
ˆ
D. The transition prob-
abilities between states in
ˆ
D are updated based on
both the modified MDP
ˆ
M and the action distribu-
tion of the original RL policy
ˆ
π.
3. Safety Verification: Finally, the safety measure-
ment m of
ˆ
D is rigorously verified using the Storm
model checker.
Running Example. To elucidate the methodology,
let’s consider a running example featuring an MDP
that models a grid-like environment (see Figure 2). In
this environment, an RL agent can navigate among
four discrete states, denoted as x = 1, x = 2, x = 3,
and x = 4, corresponding to positions A, B, C, and D,
respectively. From each state, the agent can execute
one of three actions: UP, NOP (No Operation), or
DOWN. The transition probabilities between states
are defined based on the chosen actions. For instance,
executing the UP action from state A (x = 1) gives
the agent a 0.2 probability of transitioning to state B
(x = 2) and a 0.8 probability of transitioning to state
C (x = 3). For simplicity, let’s assume one reward
for each state-action pair. This example functions as
a foundational MDP against which we will test our
verification method.
4.1 Induced MDP Construction
To perform the verification of stochastic RL poli-
cies, we initially construct an induced MDP
ˆ
M from
a given MDP M (as shown in Figure 2), a trained
stochastic RL policy
ˆ
π, and a safety measurement m.
We commence the construction process at the ini-
tial state s
0
of the original MDP M. Starting from
the initial state s
0
, we iteratively visit each state s that
is reachable under the policy
ˆ
π by only including ac-
tions a for which
ˆ
π(a|s) > 0. This creates an MDP
ˆ
M
induced by a permissive policy τ and ensures that
ˆ
M
is reduced to those states and actions that are reach-
able by
ˆ
π (see Figure 3). This induced MDP serves
as the basis for the subsequent transformation into an
induced DTMC
ˆ
D for formal verification.
4.2 Induced DTMC Transformation
To convert the induced MDP
ˆ
M into an induced
DTMC
ˆ
D, we perform a probabilistic transformation
on the state transitions (refer to Figure 4). Specif-
ically, we update the transition function
ˆ
Tr
ˆ
D
(s, s
0
),
A : x = 1
UP
DOWN
B : x = 2
C : x = 3
D : x = 4
UP,NOP,DOWN
0.2
0.8
0.4
0.6
UP,NOP,DOWN
UP,NOP,DOWN
UP,NOP,DOWN
Figure 2: The MDP M with S = {x = 1, x = 2, x = 3, x = 4},
A={UP,NOP,DOWN}, and rew: S × A → {1}.
A : x = 1
UP
DOWN
B : x = 2
C : x = 3
D : x = 4
0.2
0.8
0.4
0.6
Figure 3: Induced MDP
ˆ
M. We add the state-action transi-
tion to the MDP for each action with a probability greater
than zero
ˆ
π(a|s). In this example, the chosen actions are UP
and DOWN with the corresponding probabilities
ˆ
π(UP|x =
1) = 0.3 and
ˆ
π(DOW N|x = 1) = 0.7 at state x = 1.
A : x = 1 B : x = 2
C : x = 3
D : x = 3
0.3 · 0.2
0.7 · 0.4 + 0.3 ·0.8
0.7 · 0.6
Figure 4: Transitions update for
ˆ
D. For example,
ˆ
Tr
ˆ
D
(x =
1)(x = 2) = Tr(x = 1,UP, x = 2)·
ˆ
π(UP | x = 1) = 0.2·0.3 =
0.06 at state x = 1. Repeat with step from Figure 3 for all
reachable states by the trained RL policy.
which defines the probability of transitioning from
state s to state s
0
, for each s
0
that is a neighboring state
NEIGH(s) of s within the set of all states S
ˆ
M
of the
induced MDP
ˆ
M.
The transition function
ˆ
Tr
ˆ
D
(s, s
0
) is given by the
following equation:
ˆ
Tr
ˆ
D
(s, s
0
) =
∑
a∈Act
ˆ
M
(s)
Tr
ˆ
M
(s, a, s
0
)
ˆ
π(a|s)
Where Act
ˆ
M
(s) represents the set of actions available
in state s of
ˆ
M, Tr
ˆ
M
(s, a, s
0
) denotes the original tran-
sition probability of moving from state s to state s
0
when action a is taken in
ˆ
M, and
ˆ
π(a|s) is the action-
selection probability of action a in state s under the
RL policy
ˆ
π. The equation essentially performs a
weighted sum of all possible transitions from state s to
state s
0
, using the probabilities of selecting each action
a in
ˆ
M according to
ˆ
π as the weights. This transforma-
tion inherently incorporates the decision-making be-
havior of the RL policy into the probabilistic structure
of
ˆ
D, enabling us to perform verification tasks.
Probabilistic Model Checking of Stochastic Reinforcement Learning Policies
441

Table 1: Trained PPO Policies. The learning rates are
0.0001, the batch sizes are 32, and the seeds are 128. ”Ep.”
is shorthand for ”episode.” The reward is averaged over a
sliding window of 100 episodes.
Environment Layers Neurons Ep. Reward
Freeway 2 64 898 0.78
Crazy Climber 2 1024 3,229 76.22
Avoidance 2 64 7,749 6, 194
4.3 Safety Verification
Once the induced DTMC
ˆ
D is constructed, the final
step in our methodology is to do the safety measure-
ment using the Storm model checker. It takes as in-
put the DTMC
ˆ
D and a safety measurement m. Upon
feeding
ˆ
D and the specified safety measurement m
into Storm, the model checker systematically explores
all possible states and transitions in
ˆ
D to return the
safety measurement result.
4.4 Limitations
Our method is independent of the RL algorithm;
therefore, we can verify any neural network size.
However, it requires the policy to obey the Markov
property, i.e., there is no memory, and the action is
selected only using the current state. Furthermore, we
are limited to discrete state and action spaces due to
the discrete nature of the model checking component.
5 EXPERIMENTS
We now evaluate our method in multiple RL environ-
ments. We focus on the following research questions:
• Can we model check RL policies in common
benchmarks such as Freeway?
• How does our approach compare to COOL-
MC’s deterministic estimation and naive mono-
lithic model checking?
• How does the method scale?
The experiments are performed by initially training
the RL policies using the PPO algorithm (Barhate,
2021), then using the trained policies to answer our
research questions.
5.1 Setup
We now describe our setup. First, we describe the
used environments, then the trained policies, and fi-
nally, our technical setup.
5.1.1 Environments
We focus on environments that have previously been
used in the RL literature.
Freeway. The RL agent controls a chicken (up,
down, no operation) running across a highway filled
with traffic to get to the other side. Every time the
chicken gets across the highway, it earns a reward of
one. An episode ends if the chicken gets hit by a car
or reaches the other side. Each state is an image of the
game’s state. Note that we use an abstraction of the
original game, which sets the chicken into the middle
column of the screen and contains fewer pixels than
the original game, but uses the same reward function
and actions (Mnih et al., 2015).
Avoidance. This environment contains one agent
and two moving obstacles in a two-dimensional grid
world. The environment terminates when a collision
between the agent and an obstacle happens. For each
step that did not resolve in a collision, the agent gets
rewarded with a reward of 100. The environment con-
tains a slickness parameter, which defines the proba-
bility that the agent stays in the same cell (Gross et al.,
2022).
Crazy Climber. It is a game where the player has to
climb a wall (Mnih et al., 2015). This environment is
a PRISM abstraction based on this game. Each state
is an image. A pixel with a One indicates the player’s
position. A pixel with a Zero indicates an empty pixel.
A pixel with a Three indicates a falling object. A pixel
with a four indicates the player’s collision with an ob-
ject. The right side of the wall consists of a window
front. The player must avoid climbing up there since
the windows are unstable. For every level the play
climbs, the player gets a reward of 1. To avoid falling
obstacles, the player has the option to move left, move
right, or stay idle.
5.1.2 Trained RL Policies
We trained PPO agents in the previously introduced
RL environments. The RL training results are sum-
marized in Table 1.
5.1.3 Technical Setup
We executed our benchmarks in a docker container
with 16 GB RAM, and an AMD Ryzen 7 7735hs with
Radeon graphics x 16 processor with the operating
system Ubuntu 20.04.5 LTS. For model checking, we
use Storm 1.7.1 (dev) (Hensel et al., 2022).
ICAART 2024 - 16th International Conference on Agents and Artificial Intelligence
442

Table 2: RL benchmarks across various environments and metrics. Columns display the number of built states, transitions,
safety measures, and computational time required. The time is calculated by adding the time taken to build the model to the
time taken to check it and is expressed in seconds. Notably, the time for model checking is negligible and, therefore, not
explicitly mentioned.
Setup Deterministic Policy Stochastic Policy Naive Monolithic (No RL Policy)
Environment Measurement States Transitions Result Time States Transitions Result Time States Transitions Result Time
Freeway P(♦goal) 123 340 0.7 2.5 496 2,000 0.7 11 496 2800 1.0 0.06
Freeway P(mid U mid
−1
) 21 36 1.0 0.5 272 1,120 1.0 6 272 1552 1.0 0.07
Crazy Climber P(♦coll) 8, 192 32, 768 0.0 146 40,960 270,336 1.0 1,313 40,960 385,024 1.0 0.4
Avoidance P(♦
≤100
coll) 625 8698 0.84 1.5 15,625 892,165 0.84 1,325 15,625 1,529,185 1.0 2.0
5.2 Analysis
We now go through our evaluation and answer our
research questions.
5.2.1 Can We Verify Stochastic RL Policies in
Common Benchmarks Such as Freeway?
In this experiment, we investigate the applicability of
our approach to evaluating RL policies, specifically
focusing on the Freeway environment.
Execution. Our analysis encompasses two dimen-
sions: (1) the probability of reaching the desired goal,
denoted by P(♦goal), and (2) the complex behavior
involving the likelihood of the agent reverting to its
starting position, denoted by P(midU mid
−1
).
Results. For the first dimension, we evaluated the
probability of the trained Freeway RL agent suc-
cessfully crossing the street without colliding with a
car. The model checking result for this safety mea-
surement yielded P(♦goal) = 0.7, indicating that the
agent has a 70% chance of safely reaching the other
side of the road.
For the second dimension, we examined the
agent’s likelihood of reversing direction and return-
ing to the starting position after having entered the
street. The model checking process, in this case, re-
vealed that P(mid U mid
−1
) = 1, confirming that the
agent will indeed return to the starting position with
certainty under the analyzed conditions.
In summary, our findings demonstrate that it is
not only feasible to apply model checking methods to
stochastic RL policies in commonly used benchmarks
like Freeway but also that these methods are versatile
enough to evaluate complex safety requirements.
5.2.2 How Does Our Approach Compare to
COOL-MC’s Deterministic Estimation
and Naive Monolithic Model Checking?
This experiment compares our approach with deter-
ministic estimations of the safety measures of trained
policies and naive monolithic model checking. Deter-
ministic estimation incrementally builds the induced
DTMC by querying the policy at every state for the
highest probability action (Gross et al., 2022). Naive
monolithic model checking is called ”naive” because
it does not take into account the complexity of the sys-
tem or the number of possible states it can be in, and
it is called ”monolithic” because it treats the entire
system as a single entity, without considering the in-
dividual components of the system or the interactions
between them (Gross et al., 2023a). In short, it does
not verify the trained RL policy but rather the overall
environment. For instance, P(♦goal) = 1 indicates a
path to reach the goal state eventually.
Execution. We use the trained stochastic policy to
build and verify the induced DTMCs correspondingly
for the deterministic estimation and our approach. For
naive monolithic model checking, we build the whole
MDP and verify it correspondingly.
Results. The data presented in Table 2 indicates
that our method yields precise results (see Crazy
Climber). In contrast, the deterministic estimation
technique exhibits faster performance. This is due
to its method of extending only the action transitions
associated with the highest-probability action. The
naive monolithic model checking results are bounds
and do not reflect the actual RL policy performance.
In the context of naive monolithic model checking,
the number of states and transitions is larger than the
other two approaches. This indicates that naive mono-
lithic model checking runs faster out of memory than
the other two approaches, which is critical in environ-
ments with many states and transitions (Gross et al.,
2023b).
5.2.3 How Does the Method Scale?
Based on our experiments, detailed in Table 2, we
find that the primary limitations of our approach stem
from the increasing number of states and transitions.
Given the probabilistic characteristics inherent in the
RL policy, there is an increase in the number of states
Probabilistic Model Checking of Stochastic Reinforcement Learning Policies
443

and transitions that can be reached compared to a de-
terministic RL policy. This expansion results in more
extended times for the overall model checking. Op-
timizing our method’s incremental building process
may increase the model checking performance (Gross
et al., 2023a).
6 CONCLUSION
We presented a methodology for verifying memo-
ryless stochastic RL policies, thus addressing a gap
in the current body of research regarding the safety
verification of RL policies with complex, layered
NNs. Our method operates independently of the spe-
cific RL algorithm in use. Furthermore, we demon-
strated the effectiveness of our approach across vari-
ous RL benchmarks, confirming its capability to ver-
ify stochastic RL policies comprehensively.
For future work, exploring the integration of safe
RL (Carr et al., 2023) and stochastic RL verification
offers a promising path to validate policies’ reliabil-
ity and enhance their operational safety across diverse
environments. Additionally, merging stochastic RL
verification with interpretability (Zhao et al., 2023)
and explainability (Vouros, 2023) approaches could
significantly bolster the understanding of RL policies.
REFERENCES
Alshiekh, M., Bloem, R., Ehlers, R., K
¨
onighofer, B.,
Niekum, S., and Topcu, U. (2018). Safe reinforcement
learning via shielding. In AAAI, pages 2669–2678. AAAI
Press.
Bacci, E., Giacobbe, M., and Parker, D. (2021). Verifying
reinforcement learning up to infinity. In IJCAI, pages
2154–2160. ijcai.org.
Bacci, E. and Parker, D. (2020). Probabilistic guarantees for
safe deep reinforcement learning. In FORMATS, volume
12288 of Lecture Notes in Computer Science, pages 231–
248. Springer.
Bacci, E. and Parker, D. (2022). Verified probabilistic poli-
cies for deep reinforcement learning. In NFM, volume
13260 of Lecture Notes in Computer Science, pages 193–
212. Springer.
Baier, C. and Katoen, J. (2008). Principles of model check-
ing. MIT Press.
Barhate, N. (2021). Minimal pytorch imple-
mentation of proximal policy optimization.
https://github.com/nikhilbarhate99/PPO-PyTorch.
Br
´
azdil, T., Chatterjee, K., Chmelik, M., Forejt, V.,
Kret
´
ınsk
´
y, J., Kwiatkowska, M. Z., Parker, D., and Ujma,
M. (2014). Verification of markov decision processes us-
ing learning algorithms. In ATVA, volume 8837 of Lec-
ture Notes in Computer Science, pages 98–114. Springer.
Carr, S., Jansen, N., Junges, S., and Topcu, U. (2023). Safe
reinforcement learning via shielding under partial ob-
servability. In AAAI, pages 14748–14756. AAAI Press.
Cassez, F., David, A., Fleury, E., Larsen, K. G., and Lime,
D. (2005). Efficient on-the-fly algorithms for the analysis
of timed games. In CONCUR, volume 3653 of Lecture
Notes in Computer Science, pages 66–80. Springer.
Corsi, D., Marchesini, E., and Farinelli, A. (2021). For-
mal verification of neural networks for safety-critical
tasks in deep reinforcement learning. In de Campos, C.
and Maathuis, M. H., editors, Proceedings of the Thirty-
Seventh Conference on Uncertainty in Artificial Intelli-
gence, volume 161 of Proceedings of Machine Learning
Research, pages 333–343. PMLR.
Courcoubetis, C. and Yannakakis, M. (1988). Verifying
temporal properties of finite-state probabilistic programs.
In FOCS, pages 338–345. IEEE Computer Society.
Courcoubetis, C. and Yannakakis, M. (1995). The complex-
ity of probabilistic verification. J. ACM, 42(4):857–907.
David, A., Jensen, P. G., Larsen, K. G., Mikucionis, M., and
Taankvist, J. H. (2015). Uppaal stratego. In TACAS, vol-
ume 9035 of Lecture Notes in Computer Science, pages
206–211. Springer.
Dr
¨
ager, K., Forejt, V., Kwiatkowska, M. Z., Parker, D., and
Ujma, M. (2015). Permissive controller synthesis for
probabilistic systems. Log. Methods Comput. Sci., 11(2).
Eliyahu, T., Kazak, Y., Katz, G., and Schapira, M. (2021).
Verifying learning-augmented systems. In SIGCOMM,
pages 305–318. ACM.
Garc
´
ıa, J. and Fern
´
andez, F. (2015). A comprehensive sur-
vey on safe reinforcement learning. J. Mach. Learn. Res.,
16:1437–1480.
Gross, D., Jansen, N., Junges, S., and P
´
erez, G. A. (2022).
COOL-MC: A comprehensive tool for reinforcement
learning and model checking. In SETTA, volume 13649
of Lecture Notes in Computer Science, pages 41–49.
Springer.
Gross, D., Schmidl, C., Jansen, N., and P
´
erez, G. A.
(2023a). Model checking for adversarial multi-agent re-
inforcement learning with reactive defense methods. In
ICAPS, pages 162–170. AAAI Press.
Gross, D., Schmidl, C., Jansen, N., and P
´
erez, G. A.
(2023b). Model checking for adversarial multi-agent re-
inforcement learning with reactive defense methods. In
Proceedings of the International Conference on Auto-
mated Planning and Scheduling, volume 33, pages 162–
170.
Hahn, E. M., Perez, M., Schewe, S., Somenzi, F., Trivedi,
A., and Wojtczak, D. (2019). Omega-regular objectives
in model-free reinforcement learning. In TACAS (1), vol-
ume 11427 of Lecture Notes in Computer Science, pages
395–412. Springer.
Hansson, H. and Jonsson, B. (1994). A logic for reason-
ing about time and reliability. Formal Aspects Comput.,
6(5):512–535.
Hasanbeig, M., Kroening, D., and Abate, A. (2020). Deep
ICAART 2024 - 16th International Conference on Agents and Artificial Intelligence
444

reinforcement learning with temporal logics. In FOR-
MATS, volume 12288 of Lecture Notes in Computer Sci-
ence, pages 1–22. Springer.
Hensel, C., Junges, S., Katoen, J., Quatmann, T., and Volk,
M. (2022). The probabilistic model checker Storm. Int.
J. Softw. Tools Technol. Transf., 24(4):589–610.
Jin, P., Wang, Y., and Zhang, M. (2022). Efficient LTL
model checking of deep reinforcement learning systems
using policy extraction. In SEKE, pages 357–362. KSI
Research Inc.
Kazak, Y., Barrett, C. W., Katz, G., and Schapira, M.
(2019). Verifying deep-rl-driven systems. In Ne-
tAI@SIGCOMM, pages 83–89. ACM.
Kwiatkowska, M. Z., Norman, G., and Parker, D. (2011).
PRISM 4.0: Verification of probabilistic real-time sys-
tems. In CAV, volume 6806 of LNCS, pages 585–591.
Springer.
Littman, M. L., Topcu, U., Fu, J., Isbell, C., Wen, M., and
MacGlashan, J. (2017). Environment-independent task
specifications via GLTL. CoRR, abs/1704.04341.
Mnih, V., Kavukcuoglu, K., Silver, D., Graves, A.,
Antonoglou, I., Wierstra, D., and Riedmiller, M. A.
(2013a). Playing atari with deep reinforcement learning.
CoRR, abs/1312.5602.
Mnih, V., Kavukcuoglu, K., Silver, D., Graves, A.,
Antonoglou, I., Wierstra, D., and Riedmiller, M. A.
(2013b). Playing atari with deep reinforcement learning.
CoRR, abs/1312.5602.
Mnih, V., Kavukcuoglu, K., Silver, D., Rusu, A. A., Ve-
ness, J., Bellemare, M. G., Graves, A., Riedmiller, M. A.,
Fidjeland, A., Ostrovski, G., Petersen, S., Beattie, C.,
Sadik, A., Antonoglou, I., King, H., Kumaran, D., Wier-
stra, D., Legg, S., and Hassabis, D. (2015). Human-
level control through deep reinforcement learning. Nat.,
518(7540):529–533.
Silver, D., Huang, A., Maddison, C. J., Guez, A., Sifre, L.,
van den Driessche, G., Schrittwieser, J., Antonoglou, I.,
Panneershelvam, V., Lanctot, M., Dieleman, S., Grewe,
D., Nham, J., Kalchbrenner, N., Sutskever, I., Lillicrap,
T. P., Leach, M., Kavukcuoglu, K., Graepel, T., and Has-
sabis, D. (2016). Mastering the game of go with deep
neural networks and tree search. Nat., 529(7587):484–
489.
Sutton, R. S. and Barto, A. G. (2018). Reinforcement learn-
ing: An introduction. MIT press.
Vamplew, P., Smith, B. J., K
¨
allstr
¨
om, J., de Oliveira Ramos,
G., Radulescu, R., Roijers, D. M., Hayes, C. F., Heintz,
F., Mannion, P., Libin, P. J. K., Dazeley, R., and Foale,
C. (2022). Scalar reward is not enough: a response to
silver, singh, precup and sutton (2021). Auton. Agents
Multi Agent Syst., 36(2):41.
Vinyals, O., Babuschkin, I., Czarnecki, W. M., Mathieu,
M., Dudzik, A., Chung, J., Choi, D. H., Powell, R.,
Ewalds, T., Georgiev, P., Oh, J., Horgan, D., Kroiss,
M., Danihelka, I., Huang, A., Sifre, L., Cai, T., Aga-
piou, J. P., Jaderberg, M., Vezhnevets, A. S., Leblond, R.,
Pohlen, T., Dalibard, V., Budden, D., Sulsky, Y., Molloy,
J., Paine, T. L., G
¨
ulc¸ehre, C¸ ., Wang, Z., Pfaff, T., Wu,
Y., Ring, R., Yogatama, D., W
¨
unsch, D., McKinney, K.,
Smith, O., Schaul, T., Lillicrap, T. P., Kavukcuoglu, K.,
Hassabis, D., Apps, C., and Silver, D. (2019). Grandmas-
ter level in starcraft II using multi-agent reinforcement
learning. Nat., 575(7782):350–354.
Vouros, G. A. (2023). Explainable deep reinforcement
learning: State of the art and challenges. ACM Comput.
Surv., 55(5):92:1–92:39.
Wang, Y., Roohi, N., West, M., Viswanathan, M., and
Dullerud, G. E. (2020). Statistically model checking
PCTL specifications on markov decision processes via
reinforcement learning. In CDC, pages 1392–1397.
IEEE.
Zhao, C., Deng, C., Liu, Z., Zhang, J., Wu, Y., Wang, Y.,
and Yi, X. (2023). Interpretable reinforcement learning
of behavior trees. In ICMLC, pages 492–499. ACM.
Zhu, H., Xiong, Z., Magill, S., and Jagannathan, S. (2019).
An inductive synthesis framework for verifiable rein-
forcement learning. In PLDI, pages 686–701. ACM.
Probabilistic Model Checking of Stochastic Reinforcement Learning Policies
445
