Enclave Management Models for Safe Execution of Software

Components

Newton Carlos Will

1 a

and Carlos Alberto Maziero

2 b

Computer Science Department, Federal University of Technology, Paran

a, Dois Vizinhos, Brazil

Computer Science Department, Federal University of Paran

a, Curitiba, Brazil

Keywords:

Intel SGX, Programming Models, Software Architecture, Performance, Resource Optimization.

Abstract:

Data conﬁdentiality is becoming increasingly important to computer users, both in corporate and personal

environments. In this sense, there are several solutions proposed to maintain the conﬁdentiality and integrity

of such data, among them the Intel Software Guard Extensions (SGX) architecture. The use of such mecha-

nisms to provide conﬁdentiality and integrity for sensitive data imposes a performance cost on the application

execution, due to the restrictions and checks imposed by the Intel SGX architecture. Thus, the efﬁcient use

of SGX enclaves requires some management. The present work presents two management models for using

SGX enclaves: (i) enclave sharing; and (ii) enclave pool. In order to apply such models, an enclave provider

architecture is proposed, offering a decoupling between the enclave and the application, allowing to apply the

proposed management models and offering the resources provided by the enclaves to the applications through

an “as a service” approach. A prototype was built to evaluate the proposed architecture and management mod-

els; the experiments demonstrated a considerable reduction in the performance impact for enclave allocation,

while guaranteeing good response times to satisfy simultaneous requests.

1 INTRODUCTION

Technology is present in the lives of most people, who

trust their data to devices such as computers, smart-

phones, and online storage services. Data present on

such devices are quite diverse, from personal photos,

passwords, calendars, medical and banking data, and

work-related information, which can be very impor-

tant to users. It is thus necessary to specify mecha-

nisms and practices to ensure their conﬁdentiality and

integrity.

Several mechanisms have been developed in or-

der to support operating systems, libraries, and appli-

cations that aim to ensure trusted execution and han-

dling of sensitive user data. One of the most recent

technologies in this area is the Intel Software Guard

Extensions (SGX), which allows an application to be

split into two components: a trusted (called enclave)

and an untrusted one. Intel SGX brings a series of

new mechanisms and instructions that aim to ensure

the conﬁdentiality and integrity of the data being ma-

nipulated inside each enclave, which holds the trusted

https://orcid.org/0000-0003-2976-4533

https://orcid.org/0000-0003-2592-3664

component of the application (McKeen et al., 2013).

SGX security guarantees add considerable perfor-

mance overhead to both creating enclaves and running

code within them. Furthermore, the memory region

used by SGX is limited, restricting the size and num-

ber of active enclaves (Shaon et al., 2017; Mofrad

et al., 2017; Fuhry et al., 2017). An issue raised is the

possibility of reducing the performance impact inher-

ent to the use of enclaves for handling sensitive data,

especially at their creation time (Fisch et al., 2017).

Another issue to be tackled is the possibility of re-

ducing the use of the SGX trusted memory, allowing

more enclaves to be allocated simultaneously. Such

questions are very important for secure applications

that should satisfy several requests in a short period of

time, considering that the initialization of an enclave

to satisfy each request would be costly, from the point

of view of performance and memory usage.

Some works in the literature aim to improve the

performance of applications that use the Intel SGX

architecture, allowing the enclave to perform dynamic

memory allocation and, consequently, to be initialized

faster (Silva et al., 2017). Other works seek to reduce

the performance impact caused by context switching

between the enclave and the application (Arnautov

474

Will, N. and Maziero, C.

Enclave Management Models for Safe Execution of Software Components.

DOI: 10.5220/0012322600003648

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 10th International Conference on Information Systems Security and Privacy (ICISSP 2024), pages 474-485

ISBN: 978-989-758-683-5; ISSN: 2184-4356

et al., 2016; Orenbach et al., 2017), and to extend

the size of the SGX memory, so that it can cover all

available main memory (Taassori et al., 2018). The

common background in such approaches is the low-

level code reﬁnement and changes in the SGX soft-

ware tools.

It is thus necessary to look for alternatives to re-

duce such performance overhead in the application

and to ensure an efﬁcient use of the SGX memory re-

gion, without compromising the security guarantees

provided by SGX, and without changing its operating

structures. Furthermore, the use of enclaves is recent

and there is no clear position in the community on

the correct way to incorporate them into applications,

that is, on the most suitable programming models for

building programs using enclaves.

In this paper, we propose two models of enclave

management, enabling an efﬁcient allocation of re-

sources, aiming to reduce the use of SGX memory

and the time spent by an application to require an en-

clave. Thus, the main contributions of this work are:

• Deﬁnition of enclave management models aiming

to reduce the enclave creation overhead and the

usage of enclave memory;

• A new approach to provide multiple enclaves to

applications in a coordinated manner;

• A prototype that implements our approach vali-

dates it in real scenarios;

• Performance evaluation of our prototype, compar-

ing it with previous works;

• Security assessment of the proposed enclave man-

agement models.

The remainder of this paper is organized as fol-

lows: Section 2 provides background information

about the Intel Software Guard Extensions technol-

ogy. Section 3 presents previous research closely re-

lated to our proposal, in the ﬁeld of enclave manage-

ment. Section 4 presents the enclave management

models proposed in this work. Section 5 discuss the

Enclave as a Service approach implemented in our

prototype, which is described in Section 6. Perfor-

mance evaluation of our solution is presented in Sec-

tion 7 and the security assessment is discussed in Sec-

tion 8. Finally, Section 9 concludes the paper and

presents the future work.

2 INTEL SGX

The Intel Software Guard Extensions (SGX) architec-

ture allows an application to be split into trusted and

untrusted components. The trusted part of the appli-

cation runs in a secure environment called enclave,

in which all instructions and data are kept in an en-

crypted region of the memory called Processor Re-

served Memory (PRM) (McKeen et al., 2013). The

main goal of the SGX architecture is to reduce the ap-

plication’s Trusted Computing Base (TCB) to a small

piece of hardware and software.

To ensure data conﬁdentiality and integrity, the

SGX architecture provides new instructions, a new

processor architecture, and a new execution model,

which includes loading the enclave into the protected

memory area, accessing resources via page table map-

ping and application scheduling inside the enclaves.

After the application is loaded into an enclave, it is

protected from any external access to the enclave, in-

cluding access by applications that are in other en-

claves. Attempts to make unauthorized changes to

content within an enclave from outside are prevented

by the hardware. While enclave data passes between

the registers and other blocks of the processor, unau-

thorized access is prevented using the processor’s own

access control mechanisms. When data is written to

memory, it is transparently encrypted and its integrity

is maintained by avoiding memory probes or other

techniques to view, modify, or replace data contained

in the enclave (Costan and Devadas, 2016).

Memory encryption is performed using standard

encryption algorithms, containing safeguards against

replay attacks. Connecting the DRAM memory mod-

ules to another system will only give access to the data

in its encrypted form. In addition, encryption keys are

stored in registers inside the CPU, not accessible to

external components, and they are changed randomly

at every hibernation or system restart event.

2.1 Enclave Memory

Memory data protection is implemented by the En-

clave Page Cache (EPC), in which the memory pages

and the SGX control structures are stored; this re-

gion is protected from external access by hardware.

Data from different enclaves reside within the EPC;

each enclave has its own control structure, called SGX

Enclave Control Structure (SECS), and each memory

page in the EPC belongs to a single enclave. When an

enclave requests access to the EPC, the processor de-

cides whether to allow its access, managing security

and access control within the EPC through a hardware

structure called Enclave Page Cache Map (EPCM)

(McKeen et al., 2013; Costan and Devadas, 2016).

The EPC storage in main memory is protected by

encrypting the data to provide a defense against mem-

ory attacks. For that, a hardware unit called Memory

Enclave Management Models for Safe Execution of Software Components

475

Encryption Engine (MEE) takes care of the encryp-

tion and data integrity while it is transferred between

memory and the processor. A CPU with SGX support

allows the BIOS to reserve a memory range called

Processor Reserved Memory (PRM) to hold the EPC.

The CPU blocks any access to the PRM coming

from external agents, treating these accesses as in-

valid address references. Likewise, attempts to access

memory pages within an enclave by a process that is

not running in that enclave are also treated as invalid

references (Costan and Devadas, 2016).

2.2 Enclave Life Cycle

The enclave creation procedure consists of several

steps: initialization of the enclave control structure,

allocation of the memory pages in the EPC, loading

the contents of the enclave for these pages, measure-

ment of the contents of the enclave, and creation of an

identiﬁer for the enclave. Before starting the enclave

creation, the process will already be residing in the

main memory, being free for any inspection and anal-

ysis and, after it is loaded into the enclave, its data

and code will be protected from any external access.

The enclave life cycle is shown in Figure 1, which

also shows the machine instructions responsible for

managing the enclave.

Non-existing Uninitialized

Initialized

Not in use

Initialized

In use

ECREATE

EREMOVE

EINIT

EADD

EEXTEND

EEXIT

AEX

EENTER

ERESUME

Figure 1: Enclave life cycle management instructions and

state transition diagram (Costan and Devadas, 2016).

The ECREATE instruction starts the creation of

the enclave and initializes the SGX Enclave Con-

trol Structure (SECS) which contains global infor-

mation about the enclave. Memory pages are then

added to the enclave using the EADD instruction. The

EEXTEND instruction measures the contents of the en-

clave, which requires that all enclave code and data

are already loaded into memory. Finally, the EINIT

instruction completes the enclave creation process

and creates its identity, allowing it to be used.

Execution can enter and leave an enclave using

the SGX instructions EENTER and EEXIT, respectively.

If the execution leaves an enclave due to some event

or fault, the CPU will execute a routine called Asyn-

chronous Exit (AEX), which will save the enclave

state, clear the registers and store the address of the in-

struction that generated the fault, allowing to resume

the enclave later by invoking the ERESUME instruction.

Finally, the enclave is destroyed using the

EREMOVE instruction, which releases all EPC pages

used by the enclave, ensuring that no logical proces-

sor is executing instructions within the EPC pages

to be removed. The enclave is completely destroyed

when the EPC page containing its SECS structure is

released (McKeen et al., 2013; Costan and Devadas,

2016).

2.3 Attestation and Sealing

SGX provides attestation mechanisms, enabling an-

other party to be conﬁdent that a software is securely

running inside an enclave, in certiﬁed hardware, and

was not tampered with. The attestation process can be

performed locally or remotely. Local attestation en-

ables that two enclaves in the same platform securely

exchange data, attesting each other, by using symmet-

ric encryption and authenticating the data. Remote at-

testation enables third parties to check the identity of

an enclave running in a distinct SGX platform (Anati

et al., 2013).

A data sealing procedure is also provided by

SGX, allowing to securely store sensitive data in per-

sistent storage. Each enclave can request to the CPU

a unique key, called sealing key, derived from the en-

clave identity and the CPU itself. The sealing feature

ensures that only the same enclave that sealed the data

will be able to unseal them, and only when using the

same CPU (Anati et al., 2013).

2.4 Performance and Memory Usage

Fisch et al. (Fisch et al., 2017) point out that the ini-

tialization of several enclaves by an application may

impose a high computational cost, since, in principle,

the enclave must have allocated all the memory it will

need.

The size of the PRM should also be considered,

since it is limited to 128 MB and, according to previ-

ous works (Shaon et al., 2017; Mofrad et al., 2017;

Fuhry et al., 2017), only about 90 MB are effec-

tively available for enclave data and code. This PRM

limitation makes it necessary to think of alternatives

for situations in which enclaves need to work with

large amounts of data simultaneously. This may raise

problems when there are multiple instances of the

same enclave, or multiple enclaves in memory, forc-

ing some of them to be brought to secondary mem-

ory in order to free space in the PRM. The memory

swap/paging operation is supported by the Intel SGX

architecture, but it obviously impacts performance.

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

476

3 RELATED WORK

Some strategies to improve the overall performance

of applications that use SGX enclaves are presented

in the literature. To reduce the performance impact

caused by context switches, some solutions propose

to provide a communication interface between the en-

clave and the application without the need for such

switches, such as using threads running outside the

enclave to receive the requests and then perform the

system calls. Communication can be done through

Remote Procedure Call (RPC) (Orenbach et al., 2017)

or using a shared memory (Arnautov et al., 2016;

Weisse et al., 2017). The performance improvement

of system calls invocation by enclaves without con-

text switching is investigated by (Tian et al., 2018),

seeking to integrate this feature in the Intel SGX Soft-

ware Development Kit (SDK). Other works propose

to improve I/O performance by reducing the number

of enclave transitions (Svenningsson et al., 2021). An

approach to reduce the encryption/decryption over-

head when accessing data in memory is also proposed

(Shimizu et al., 2019).

The cost of enclave creation is also covered in

the literature, with approaches aimed at updating the

binary code during runtime, by paging the enclave

stack and allowing to load only parts of the enclave

into memory (Krieter et al., 2019). Strategies to

dynamically link libraries to enclaves and to allow

dynamic loading of enclave code are also presented

(Silva et al., 2017; Weichbrodt et al., 2021).

Approaches aimed at extending the PRM size are

also presented. Taassori et al. (Taassori et al., 2018)

propose a solution for the PRM to cover all available

physical memory, by changing the EPCM structure

and allowing to store non-sensitive memory pages

in the EPC. Solutions that seek to store sensitive

key-value data in primary memory also present ap-

proaches to use memory regions outside of PRM to

store such data securely (Kim et al., 2019; Tang et al.,

2019; Bailleu et al., 2019).

Programming paradigms are also used in order to

reduce the impacts caused in the communication and

synchronization of enclaves, which are needed in ap-

plications that use different enclaves to carry out their

operations. A paradigm used in such context is the

actor model, where each actor is self-contained and

communicates with other actors through the exchange

of messages, allowing the execution of parallel and

non-blocking operations. This paradigm is used by

(Sartakov et al., 2018), treating each enclave as an

actor and reducing the need for context changes and

synchronization between enclaves in parallel execu-

tions. Enclave replication in the cloud is addressed

by (Soriente et al., 2019), allowing seamless commis-

sioning and decommissioning of SGX-based applica-

tions to achieve more efﬁciency in enclave manage-

ment.

Despite there are solutions proposed in the liter-

ature that use programming models to overcome the

performance issues of SGX, they are limited to spe-

ciﬁc enclaves and applications. We present in this

work an architecture that deploys such models us-

ing an enclave management service, allowing multi-

ple enclaves to be offered to multiple applications as

logical resources, with their life cycle being managed

by the proposed service.

4 ENCLAVE MANAGEMENT

MODELS

The way the application manages the enclaves it uses

may impact its performance, thus it is important to use

efﬁcient management techniques to minimize such

impact. In addition, as previously mentioned, the lim-

itations imposed by the SGX architecture in the use of

PRM may increase this impact, due to the paging ac-

tivity incurred in the execution of a large number of

enclaves. Thus, management models that aim to re-

duce the number of enclave creations and simultane-

ously active enclaves in the system can bring a signiﬁ-

cant reduction in the performance overhead caused by

the use of enclaves. This Section discusses two mod-

els of enclave management aiming at reducing such

overhead.

4.1 Enclave Sharing

Some situations may present multiple instances of the

same enclave, performing the same function and us-

ing mostly the same data. This is the case, for in-

stance, of enclaves launched to perform user authen-

tication, which use the same credential database; this

may also happen in servers that receive a large num-

ber of requests to be processed in enclaves.

An alternative to reduce the number of instantiated

enclaves is to share them by multiple applications or

multiple instances of the same application, allowing

the same instance of an enclave to treat requests from

different sources and avoiding launching a new en-

clave for each request. The beneﬁt of having shared

long-life enclaves instead of exclusive short-life ones

is twofold: it reduces the use of the PRM area, allow-

ing more applications to have enclaves, and it avoids

the costs of frequent enclave creation and sensitive

data/code loading, which may be high, as discussed

Enclave Management Models for Safe Execution of Software Components

477

in Section 2.4, improving the applications’ response

time.

Enclave sharing was adopted by (Will and

Maziero, 2020) to centralize the handling of creden-

tials data in an authentication system. The model pro-

posed by the authors, using a client/server architec-

ture, made it possible to apply SGX security guaran-

tees without major performance impacts. A similar

approach is used by (Karande et al., 2017) to central-

ize the manipulation of log ﬁles in operating systems.

4.2 Enclave Pool

The pooling pattern, deﬁned by (Kircher and Jain,

2002), is a pattern that describes how the acquisition

and release of expensive resources can be minimized

by recycling the resources that are no longer needed.

This pattern can be used in a context where systems

continuously acquire and release the same or similar

resources and need to meet high demands for scalabil-

ity and efﬁciency, while seeking to ensure that system

performance and stability are not compromised.

The object pool idea ﬁts the limitation imposed by

the SGX architecture in the PRM size, which ends up

limiting the number of instances of enclaves that can

reside in memory simultaneously, as well as with the

cost of starting the enclaves, which increases in pro-

portion to their size. Maintaining a pool of enclaves

can decrease the response time of requests with fre-

quent demands to enclaves, a situation that can occur

in some implementations, as in the solution presented

by (Brenner et al., 2017).

The use of an enclave pool is addressed by (Li

et al., 2019), being applied in a multi-threaded web

server context. In their proposal, each enclave on the

server is linked to a thread responsible for direct com-

munication with that enclave, avoiding problems re-

sulting from race conditions within enclaves, in addi-

tion to a queue of requests to distribute each request

to an enclave in the pool. Tasks to be performed in

enclaves are queued and bound to available enclaves

as soon as possible, maintaining control over the ex-

ecution ﬂow. In addition to the reduction in the im-

pact resulting from an enclave creation for each new

request, using an enclave pool allows a reduction in

CPU usage, compared to the standard model of en-

clave use.

5 ENCLAVE AS A SERVICE

APPROACH

An enclave can be seen as a component for the trusted

execution of some sensitive routine, which is directly

linked to the application that uses it. On the other

hand, the enclave can also be considered as a ser-

vice provider for that application, for the execution

of trusted routines, and for the provision of an encap-

sulated and protected environment for handling sensi-

tive data.

The concept of offering resources or routines as

a service is widespread in cloud computing environ-

ments, where it is denoted by the term Everything as

a Service (XaaS). This concept allows integration be-

tween heterogeneous applications, with resources be-

ing packaged in services that are accessed by client

applications. Services are fundamental items, totally

independent from applications, allowing their use on-

demand (Robison, 2008; Li and Wei, 2014).

In cloud environments, there are several resources

delivered to applications in the form of services, such

as software resources, with the concept of Software

as a Service (SaaS), and hardware resources, with the

concept of Infrastructure as a Service (IaaS). In the

context of computer security, the Security as a Service

(SECaaS) model is also presented, which provides, in

the form of services, authentication and authorization

mechanisms, intrusion detection, and veriﬁcation of

malicious software, among others. A wide classiﬁ-

cation of such services is presented by (Duan et al.,

2015a) and (Duan et al., 2016). Despite being quite

widespread and used in cloud environments, the XaaS

paradigm is not restricted to these environments and

can also be used locally, through the use of daemon

processes to treat requests from system users or other

processes (Duan et al., 2015b).

The XaaS paradigm key concept of unbinding re-

sources from applications can be applied to the use of

enclaves, offering them as a service to applications.

Thus, an Enclave as a Service (EaaS) paradigm can

be deﬁned, which is characterized by a set of inde-

pendent enclaves that are made available to different

applications for the execution of trusted routines. This

concept is already partially explored with the execu-

tion of secure microservices, which offer a trusted en-

vironment for the execution of small services in the

cloud.

This paper proposes an approach to provide on-

demand enclaves to applications, through an enclave

provider, which creates and manages multiple en-

claves in behalf of them. In this Enclave as a Service

(EaaS) framework, applications only need to indicate

the enclave they need, among a set of previously reg-

istered ones, and submit requests to it through the

provider. All the enclave launching and management

functions is performed by the provider.

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

478

6 ENCLAVE PROVIDER

The use of an enclave is restricted to the process that

instantiated it; other processes are denied access when

trying to make requests to a third-party enclave. Thus,

to allow enclaves to be shared by several applications,

it is necessary to include a mediator entity between

the requesting applications and the shared enclaves.

This mediator, called here as enclave provider, pro-

vides means for applications to communicate with the

available enclaves safely and manages the life cycle of

enclaves, relieving the applications of such task.

The enclave provider manages, in a coordinated

manner, the request of N applications for M enclaves,

according to the parameters contained in each request,

whose details are described in Section 6.2. For that,

the enclave provider centralizes all requests from ap-

plications in a broker, which is in charge of validat-

ing the request parameters, forwarding it to the cor-

responding enclave, and returning the corresponding

response back to the requesting application. The pro-

posed architecture, at a high level, is shown in Figure

App

Enclave Provider

Broker

Enclave A

Enclave B

Enclave C

Enclave N

Enclave

Manager

Figure 2: General architecture of the enclave provider, in

which several applications communicate with different en-

claves through a broker, which handles requests, forwards

them to the corresponding enclave, and returns the result to

the requesting application.

The sensitive information for the conﬁguration

and management of the enclave provider is kept

sealed and manipulated within an enclave manager,

ensuring its conﬁdentiality and integrity. Such infor-

mation includes the list of enclaves registered with the

provider, with their respective conﬁgurations, and the

list of active applications, enclaves, and the communi-

cation channels established between them. The archi-

tectural design details are described in the following

sections.

6.1 Enclave Registration

The ﬁrst step for an enclave to be made available for

use by applications through the enclave provider is

its registration on the platform. Enclave registration

is necessary for the provider to become aware of the

enclave and its additional settings so that it can be

properly instantiated when requested.

The registered enclave will be identiﬁed by a

unique name, which will be used by applications to

make requests to the enclave. In this stage the cri-

teria for the management of the enclave is deﬁned,

identifying whether the enclave will be managed as a

pool or a shared instance among the applications, the

number of client applications that the same enclave

instance can serve, and whether one or more instances

of that enclave should be created at the startup of the

enclave provider. Also, the ECALLs available in that

enclave are informed with their indexes, according to

the order in which they appear in the Enclave Def-

inition Language (EDL) ﬁle; ﬁnally, are deﬁned the

speciﬁc ECALLs to be executed when the enclave is

instantiated or released.

Finally, the enclave provider performs the enclave

validation procedure for the registration. This proce-

dure ﬁrst checks if there already is an enclave regis-

tered with the same requested name: if it exists, the

registration is denied. After that, the enclave cryp-

tographic hash is calculated and compared with the

hash provided in the registration request: if they are

not equal, the registration is denied. If both checks

succeed, the enclave is registered in the provider and

is made available for use by applications.

6.2 Communication

For an application to be able to use an enclave pro-

vided by the enclave provider, it should request an in-

stance of that enclave to the enclave provider. This

procedure is described in Figure 3 and consists of the

following steps:

1. The application initiates a key agreement with the

enclave provider, aiming to establish a secret key

between both parties to encrypt the exchanged

data. At the end of this step, the application and

provider share a secret key SK

, which will be

used to protect the subsequent communication be-

tween them;

2. A second key agreement is then performed be-

tween the application and the target enclave, to

establish another secret key (SK

) to protect the

communication between them;

(a) The ﬁrst step of this communication, between

the application and the provider, is already en-

Enclave Management Models for Safe Execution of Software Components

479

crypted using key SK

, with the provider de-

crypting the content of the request and collect-

ing the necessary information to identify the

target enclave;

(b) The request is sent to the target enclave to pro-

ceed with the key agreement;

provider, encrypted using SK

and sent back to

the application;

3. The subsequent communications between the ap-

plication and the enclave are protected with end-

to-end encryption, with the necessary data for the

provider being encrypted with the SK

key, and

the data that will be sent to the enclave (payload)

encrypted with the SK

key;

(a) The provider uses the SK

key to decrypt the

request header, in order to identify the target

enclave;

(b) The request payload is sent to the enclave’s

ECALL function requested by the client appli-

cation;

plication.

Application

Provider Enclave

Client Server

Key Agreement

2(a)

2(b)

3(a)

3(b)

2(c)

3(c)

Figure 3: Communication between the application and the

enclave, mediated by the enclave provider, with end-to-end

encryption.

The request payload should not be seen by the

provider, but it must be informed of which enclave

is being requested and which method/action should

be invoked on that enclave. To satisfy such require-

ments, the request data is protected by two encryption

layers: the request payload, to be sent to the target

enclave, is encrypted using the SK

key, maintaining

the conﬁdentiality of such data even for the provider;

a header containing information for the provider is

added to the request, and the whole data is then en-

crypted with the SK

key. This protects the request

conﬁdentiality while allowing the provider to decrypt

its header and manage the request.

A service request received by the provider should

contain the requester identity, the target enclave, the

ECALL to be invoked, and its parameters (payload).

The application process identiﬁer (PID) can be used

as requester identity; the target enclave is deﬁned by

the enclave identiﬁer (EID) received by the applica-

tion at the end of the ﬁrst key agreement; the ECALL

to be invoked is deﬁned by its name in the EDL ﬁle; ﬁ-

nally, the payload is opaque data encrypted using SK

and passed as-is to the enclave. This data will allow

the provider to make the function call to the target

enclave and return the response to the requesting ap-

plication. The response is protected using the same

double-key schema and contains an opaque payload

with the data returned by the enclave, when applica-

ble, and a status indicating the success or failure in the

execution of the requested operation by the provider.

6.3 Enclave Life Cycle

The enclave provider mediates the communication

between the application and the enclave, but is also re-

sponsible for managing the life cycle of registered en-

claves, seeking to maintain efﬁciency in the use of the

resources required by each enclave. From the point

of view of the requesting application, the use of en-

claves mediated by the provider is similar to the use of

an enclave directly by the application itself, maintain-

ing the same steps of requesting the enclave, calling

ECALLs, and releasing the enclave.

When the provider receives the request for an en-

clave, it veriﬁes if there is already an active instance

of the requested enclave. If there is no such active

instance, the provider creates a new instance of that

enclave. Otherwise, the provider veriﬁes whether the

maximum number of applications able to share the

same enclave instance has been reached. If this num-

ber has not yet been reached, the provider returns the

existing instance to the application, otherwise, a new

instance of the enclave is created to attend the request.

The execution of ECALLs occurs as described in

Section 6.2, with the request data being encapsulated,

encrypted, and sent to the provider. It then decrypts its

header to get the necessary information to identify the

requested enclave and function, makes the requested

call, and returns the response data back to the appli-

cation.

The enclave provider also has a structure that

maintains a list of all instantiated enclaves and which

applications are using them, with each application re-

ceiving a unique identiﬁer for each enclave it is using

(EID). In this way, it is possible to validate the number

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

480

of client applications that are using a certain enclave

instance and also to validate subsequent requests for

applications to execute ECALLs.

6.4 Enclave Release

When an enclave is no longer needed, the applica-

tion that requested it must indicate this to the provider.

This operation is analogous to the call to the function

sgx_destroy_enclave available at SGX API and,

for this, the application makes a request to the enclave

provider informing the identiﬁer it holds.

When the provider receives the request to release

an enclave by an application that was using it, the

provider removes the entry corresponding to that ap-

plication in its list of instantiated enclaves; that en-

clave instance will remain available for use by other

applications. Even if there is no other application us-

ing the same instance of the enclave, that instance is

still maintained for some time, being able to meet new

requests.

In addition, the enclave provider must ensure re-

sponsible use of the enclaves: if an application re-

quested an enclave instance and, after a long period

of time, is no longer using it, the provider will re-

move its entry from the list of instances and, if there

is no other application using that enclave instance, it

is then removed.

7 PERFORMANCE EVALUATION

A performance analysis was carried out, to measure

the impact caused by the use of the enclave provider,

with either enclave sharing or pool, compared to en-

claves instantiated and accessed directly an applica-

tion. We run the performance tests in a Dell Inspiron

7460 laptop with the following settings: dual core

2.7 GHz Intel Core i7-7500U Central Processing Unit

(CPU), 16 GB RAM, 128 GB SSD and SGX enabled

with 128 MB PRM size. Intel TurboBoost, SpeedStep,

and HyperThread CPU extensions were disabled, to

provide stable results. We used Ubuntu 18.04 LTS,

kernel 4.15.0-112-generic, libdbus 1.12.20, Intel SGX

SDK 2.9.101.2, and set the enclave heap size at 64 KB

and the enclave stack size varying from 8 KB to 128

KB. The conﬁdence interval width at 95% is 0.67%

of the average. All times were measured using the

RDTSCP instruction (Paoloni, 2010).

Figure 4 shows the average response time for re-

questing a given enclave, for 10,000 sequential re-

quests with different enclave sizes (no ECALL is in-

voked). Note that the average response time for re-

quests made directly by the application, without an

enclave provider, increases as enclave stack size in-

creases, due to the need to statically allocate the nec-

essary memory at the time of enclave initialization.

Also, there is no signiﬁcant difference in response

times when using enclave sharing or pool approaches,

they remain constant regardless of the enclave stack

size.

0

10

20

30

40

50

60

70

8KB 16KB 32KB 64KB 128KB

CPUcycles(x1,000,000)

Enclavestacksize

Directinstantiation

22.3

24.9

30.9

42.8

67.4

Enclavesharing

15.4 15.3

15.2 15.2 15.2

Enclavepool

15.0

15.2 15.2 15.2 15.1

Figure 4: Average response time for enclave requests.

We also evaluated our solution with a real applica-

tion, an authentication module of the Pluggable Au-

thentication Modules (PAM) framework. We com-

pared ﬁve distinct solutions:

• Solution 1. The PAM module itself, without any

changes;

• Solution 2. The PAM module using SGX en-

claves (UniSGX), as proposed by (Cond

e et al.,

2018);

• Solution 3. The PAM module with an authenti-

cation server and enclave sharing, as proposed by

(Will and Maziero, 2020);

• Solution 4. The PAM module with the enclave

provider, which handles a shared enclave to vali-

date the authentication requests;

• Solution 5. Same as Solution 4, adding the

payload encryption and ensuring application-to-

enclave conﬁdentiality;

The results presented in Figure 5 show that the di-

rect initialization of an enclave to validate the user’s

credentials (UniSGX solution, proposed by (Cond

et al., 2018)) imposes a high performance cost. On the

other hand, the use of an enclave sharing approach,

such as the one proposed by (Will and Maziero,

2020), guarantees the security properties of SGX

when manipulating the credentials ﬁle within an en-

clave, while having a virtually zero performance im-

pact compared to using standard PAM.

The use of the enclave provider also does not have

a signiﬁcant performance impact, and maintains the

same conﬁdentiality assumptions of the data trans-

ported on the communication bus, since these are

fully encrypted. Finally, since user credentials are

strictly sensitive data, payload encryption ensures that

Enclave Management Models for Safe Execution of Software Components

481

0

10

20

30

40

50

60

70

PAM

UniSGX

UniSGXwithenclavesharing

Enclaveprovider

(encryptedpayload)

CPUcycles(x1,000,000)

32.408

63.154

33.655

33.834

43.896

Figure 5: Response times for user authentication using

PAM directly and the SGX-based solutions.

not even the enclave provider is aware of what is be-

ing passed between the client application and the re-

quested enclave. Such operation adds a performance

cost of approximately 30%, as a result of the data en-

cryption and decryption operations and the additional

key agreement operation.

In addition to the response times for sequential

requests, we also seek to assess the behavior of the

enclave provider to respond to multiple simultaneous

requests. In this case, the response time for each re-

quest was evaluated, considering the enclave request

and the execution of the ECALL, and the number of

requests replied per second. For the tests, the en-

clave stack was set at 8 KB, to evaluate the shortest

response time, and three different scenarios were con-

sidered:

• Scenario 1. 20 simultaneous instances of the

client application are launched, each making 500

sequential requests to the enclave. The enclaves

pool is conﬁgured with 20 instances;

• Scenario 2. 50 simultaneous instances of the

client application are launched, each making 200

sequential requests to the enclave. The enclaves

pool is conﬁgured with 20 instances;

• Scenario 3. 50 simultaneous instances of the

client application are launched, each making 200

sequential requests to the enclave. The enclaves

pool is conﬁgured with 50 instances;

Figure 6 shows the response times for each re-

quest. Note that in Scenario 1 the use of both en-

clave sharing and pool provide lower response time

when compared to the direct initialization of the en-

clave by the application. Scenario 2 presents addi-

tional overhead to enclave sharing, due to the seri-

alization imposed by the enclave provider to the in-

coming requests. This can be seen also in the enclave

pool, mainly due to the pool under sizing. Finally, in

Scenario 3, with the size of the enclave pool properly

sized, the response time for each request is very simi-

lar to that presented when the application instantiates

the enclave directly.

In addition to the response time for each request,

0

100

200

300

400

500

600

700

Scenario1

Scenario2

Scenario3

CPUcycles(x1,000,000)

Directinstantiation

284.5

487.8 487.8

Enclavesharing

191.0

550.9 550.9

Enclavepool

183.8

645.0

483.1

Figure 6: Average response time for each request (including

enclave request and ECALL execution).

the average number of requests replied to per sec-

ond in each scenario was also evaluated, with the re-

sults being presented in Figure 7. It is noted that, in

Scenario 1, both enclave sharing and pool performed

better than direct enclaves initialization. In Scenario

2, the enclave sharing approach maintained a good

performance, whereas the enclave pool had a perfor-

mance far below since the pool was undersized. With

the correct sizing of the pool (Scenario 3), the enclave

provider has a high response rate, again higher than

direct initialization.

0

50

100

150

200

Scenario1

Scenario2

Scenario3

Throughput(requestspersecond)

Directinstantiation

174.0

165.5 165.5

Enclavesharing

189.5

183.6 183.6

Enclavepool

194.9

143.2

199.0

Figure 7: Enclave requests served per second.

The behavior of the enclave provider in the pres-

ence of multiple requests was also evaluated in a real

application. Again, the PAM and the solutions pro-

posed by (Cond

e et al., 2018) and (Will and Maziero,

2020) were used for this analysis. Two scenarios were

considered:

• Scenario 1. 20 simultaneous application in-

stances are launched, each instance makes 500 re-

quests for user authentication;

• Scenario 2. 50 simultaneous application in-

stances are launched, each instance makes 200 re-

quests for user authentication;

The average response time for each request is

shown in Figure 8. The solutions based on the enclave

provider showed a response time higher than PAM

and the enclave sharing solution proposed by (Will

and Maziero, 2020), but still lower than the use of an

enclave instantiated directly by the PAM authentica-

tion module, as proposed by (Cond

e et al., 2018). It

is also noted that the payload encryption adds a small

overhead on the performance of the enclave provider.

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

482

0

200

400

600

800

1000

1200

Scenario1

Scenario2

CPUcycles(x1,000,000)

PAM

283.4

752.2

UniSGX

503.6

1265.1

UniSGXwithenclavesharing

81.8

513.4

Enclaveprovider

373.8

1101.8

Enclaveprovider

(encryptedpayload)

495.9

1166.4

Figure 8: Average response time for each authentication

process.

When analyzing the average number of requests

handled per second, the enclave provider shows good

performance, presenting rates higher than other solu-

tions based on enclaves in Scenario 1, as presented in

Figure 9. In Scenario 2, the enclave provider achieved

a response rate equivalent to the enclave sharing so-

lution described in (Will and Maziero, 2020) and,

when added the payload encryption, demonstrated

a response rate equivalent to direct initialization of

the enclave, as proposed by (Cond

e et al., 2018).

Such results demonstrate the robustness of the enclave

provider in the demand for several simultaneous re-

quests.

0

20

40

60

80

100

120

140

160

180

Scenario1

Scenario2

Throughput(requestspersecond)

PAM

172.3

162.8

UniSGX

94.9 94.7

UniSGXwithenclavesharing

103.0

122.1

Enclaveprovider

132.8

122.3

Enclaveprovider

(encryptedpayload)

103.7

95.7

Figure 9: Rate of requests replied per second for user au-

thentication using PAM.

8 SECURITY ASSESSMENT

Our threat model takes into account that the attacker

can monitor the communication mechanism between

applications and can collect the data exchanged be-

tween them. Thus, sensitive data exchanged between

applications and the enclave provider must be guaran-

teed conﬁdentiality. Full control of the communica-

tion mechanism by the attacker, allowing it to change

or replace the data that are transmitted, is considered

out of scope.

The enclaves managed by the provider are previ-

ously registered, and the attacker can access the ﬁle

that contains this information and tamper with or re-

place its contents. In this case, protection mechanisms

must be applied to guarantee the conﬁdentiality and

integrity of this content. Additionally, the attacker can

substitute the code ﬁles for the registered enclaves,

making it necessary to use mechanisms to validate

these ﬁles before loading them.

Internal data structures of the enclave provider can

be manipulated by an attacker, aiming to seize re-

quests from legitimate applications and forward them

to malicious enclaves. Such structures must be kept in

a protected area, preventing them from being deliber-

ately tampered with in memory. Finally, client appli-

cation vulnerabilities are considered out of scope in

our threat model.

All sensitive data structures for the execution of

the enclave provider are maintained and handled by

an enclave manager, thus using the conﬁdentiality

and integrity mechanisms provided by SGX. The en-

clave manager is also responsible for receiving and

distributing requests from client applications, keeping

records of which enclaves are instantiated, which ap-

plications are making requests, and which instances

of enclaves are associated with these applications.

The enclaves handled by the provider are previ-

ously registered, and such records are maintained and

updated by the enclave manager, being stored in sec-

ondary memory in encrypted form, using the SGX

sealing feature. Thus, the records can only be read

by the manager enclave itself, and only on the plat-

form used to seal the data. In addition, any change in

the encrypted data is identiﬁed by the authentication

mechanisms contained in the sealing procedure itself.

Each enclave registered in the provider is accom-

panied by an SHA-256 cryptographic hash, which

aims to validate the content of the enclave before it

is loaded. Thus, the enclave provider validates the

cryptographic hash obtained from the content of the

enclave (including code and data) with that informed

in the registration data, ensuring that the code and

data of the enclave have not been altered or replaced.

This veriﬁcation is carried out both when the enclave

is registered and when creating each of its instances,

which allows one to identify the changes made to the

enclave after its registration. The entire veriﬁcation

procedure is carried out within the limits of the man-

aging enclave, avoiding the manipulation of such data

by unauthorized entities. After creating the instances,

the mechanisms provided by SGX guarantee the in-

tegrity of the data and code of the enclave.

The communication between the client applica-

tion and the enclave provider is fully encrypted, and

the enclave manager is responsible for handling ses-

sion keys and decrypting incoming requests. The ses-

Enclave Management Models for Safe Execution of Software Components

483

sion keys are agreed between the client application

and the managing enclave through an elliptic curve

Difﬁe-Hellman (ECDH) key agreement protocol, us-

ing the curve X25519 proposed by (Bernstein, 2006).

The use of the Difﬁe-Hellman protocol allows the def-

inition of an encryption key between the two parties

through an insecure channel, preventing an attacker

from obtaining this key.

The requests sent to the enclave provider are en-

crypted using a symmetric AES-CTR encryption al-

gorithm, using the 128-bit key agreed between the

parties. This key is used to encrypt all communication

between the application and the enclave provider, in-

cluding the responses sent by the provider. The appli-

cation can reset the encryption key at any time by ini-

tiating a new key agreement with the enclave provider.

The encryption of messages exchanged between the

parties ensures that if an attacker is connected to the

message bus and collects the information exchanged,

she will not have direct access to it, requiring the

application of techniques to obtain the key used for

encrypting the data. Even using high computational

power, the process of obtaining the key is extremely

expensive, making it unfeasible.

The procedures for decrypting the request and en-

crypting the response to be sent to the application oc-

cur within the manager enclave, which manipulates

the session keys. In this way, the encryption keys

are always protected by the enclave provider, ensuring

that they are not accessed by unauthorized entities.

Client applications can add an extra layer of secu-

rity by making a key agreement directly with the re-

quested enclave, thus enabling end-to-end encryption

of the data sent to the enclave. This possibility makes

the data exchanged between the application and the

enclave totally opaque to the enclave provider, in ad-

dition to adding an extra obstacle to an attacker who

may be collecting data in transit.

The client-server architecture also implies a single

point of failure: the server application. Thus, the en-

clave provider must be resilient and capable of recov-

ering from failures, to avoid denial of service attacks,

which prevent legitimate client applications from ac-

cessing the requested enclaves.

Finally, in addition to the security issues that

should be considered for the enclave provider in gen-

eral, we must consider the implications of each pro-

posed enclave management model. It should be noted,

however, that the management mode is a choice made

by the developer of the enclave, and he must take into

account the balance between performance and the ex-

pected security guarantees.

9 CONCLUSION

This paper proposes some programming models for

building applications using Intel SGX enclaves, to re-

duce the performance impact of this technology and

optimize resource utilization. Two different models

of enclave management were described: sharing and

pool. Each model has its own characteristics and

can be used in different contexts. Considering these

models, an architecture was proposed for an enclave

provider, which offers each enclave as a software re-

source to the applications and makes it available to

client applications in the form of a service, decou-

pling the enclave from the application that uses it and

allowing centralized management and efﬁcient use of

enclave instances. After the speciﬁcation of the en-

clave provider, a prototype was developed to validate

the proposal.

As future work, we intend to mitigate the problem

of under sizing the enclave pool by using more efﬁ-

cient policies in releasing enclaves, causing the en-

clave provider to monitor pool usage and create new

instances in the background when necessary. Other

enclave management models may be added to the

provider, ensuring a greater diversity of models and

meeting other types of demand.

Extensions to the presented solution, in order to

work with requests from IoT devices and to run the

provider in a cloud environment, are also being stud-

ied, including operations that depend on the state of

the enclave, by using enclave migration techniques.

REFERENCES

Anati, I., Gueron, S., Johnson, S. P., and Scarlata, V. R.

(2013). Innovative technology for CPU based attesta-

tion and sealing. In Intl Wksp on Hardware and Archi-

tectural Support for Security and Privacy, Tel-Aviv,

Israel. ACM.

Arnautov, S., Trach, B., Gregor, F., Knauth, T., Martin, A.,

Priebe, C., Lind, J., Muthukumaran, D., O’Keeffe, D.,

Stillwell, M., et al. (2016). SCONE: Secure Linux

containers with Intel SGX. In Sym on Operating

Systems Design and Implementation, Savannah, GA,

USA. USENIX Association.

Bailleu, M., Thalheim, J., Bhatotia, P., Fetzer, C., Honda,

M., and Vaswani, K. (2019). SPEICHER: Securing

LSM-based key-value stores using shielded execution.

In Conf on File and Storage Technologies, Boston,

MA, USA. USENIX Association.

Bernstein, D. J. (2006). Curve25519: New Difﬁe-Hellman

speed records. In Intl Wksp on Public Key Cryptogra-

phy, New York, NY, USA. Springer.

Brenner, S., Hundt, T., Mazzeo, G., and Kapitza, R. (2017).

Secure cloud micro services using Intel SGX. In Intl

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

484

Conf on Distributed Applications and Interoperable

Systems, Neuchatel, Switzerland. Springer.

Cond

e, R. C. R., Maziero, C. A., and Will, N. C. (2018).

Using Intel SGX to protect authentication credentials

in an untrusted operating system. In Sym on Comput-

ers and Communications, Natal, RN, Brazil. IEEE.

Costan, V. and Devadas, S. (2016). Intel SGX explained.

IACR Cryptology ePrint Archive, 2016:86.

Duan, Y., Cao, Y., and Sun, X. (2015a). Various “aaS” of

Everything as a Service. In Intl Conf on Software En-

gineering, Takamatsu, Japan. IEEE.

Duan, Y., Fu, G., Zhou, N., Sun, X., Narendra, N. C., and

Hu, B. (2015b). Everything as a Service (XaaS) on the

cloud: Origins, current and future trends. In Intl Conf

on Cloud Computing, New York, NY, EUA. IEEE.

Duan, Y., Sun, X., Longo, A., Lin, Z., and Wan, S. (2016).

Sorting terms of “aaS” of everything as a service. Int.

J. Networked Distrib. Comput.

Fisch, B. A., Vinayagamurthy, D., Boneh, D., and Gor-

bunov, S. (2017). Iron: Functional encryption using

Intel SGX. In Conf on Computer and Communica-

tions Security, Dallas, TX, USA. ACM.

Fuhry, B., Bahmani, R., Brasser, F., Hahn, F., Kerschbaum,

F., and Sadeghi, A.-R. (2017). HardIDX: Practical and

secure index with SGX. In Conf on Data and Appli-

cations Security and Privacy, Philadelphia, PA, USA.

Springer.

Karande, V., Bauman, E., Lin, Z., and Khan, L. (2017).

SGX-Log: Securing system logs with SGX. In

Asia Conf on Computer and Communications Secu-

rity, Abu Dhabi, UAE. ACM.

Kim, T., Park, J., Woo, J., Jeon, S., and Huh, J. (2019).

ShieldStore: Shielded in-memory key-value storage

with SGX. In EuroSys Conf, Dresden, Germany.

ACM.

Kircher, M. and Jain, P. (2002). Pooling pattern. In Euro

Conf on Pattern Languages of Programs, Irsee, Ger-

many. UVK.

Krieter, S., Thiem, T., and Leich, T. (2019). Using dynamic

software product lines to implement adaptive SGX-

enabled systems. In Intl Wksp on Variability Mod-

elling of Software-Intensive Systems, Leuven, Bel-

gium. ACM.

Li, D., Lin, R., Tang, L., Liu, H., and Tang, Y. (2019). SGX-

Pool: Improving the performance of enclave creation

in the cloud. Trans. Emerging Telecommun. Technol.

Li, G. and Wei, M. (2014). Everything-as-a-service plat-

form for on-demand virtual enterprises. Inf. Syst.

Front.

McKeen, F., Alexandrovich, I., Berenzon, A., Rozas, C. V.,

Shaﬁ, H., Shanbhogue, V., and Savagaonkar, U. R.

(2013). Innovative instructions and software model

for isolated execution. In Intl Wksp on Hardware and

Architectural Support for Security and Privacy, Tel-

Aviv, Israel. ACM.

Mofrad, M. H., Lee, A., and Gray, S. L. (2017). Leverag-

ing Intel SGX to create a nondisclosure cryptographic

library. Preprint arXiv:1705.04706.

Orenbach, M., Lifshits, P., Minkin, M., and Silberstein, M.

(2017). Eleos: Exitless OS services for SGX enclaves.

In Euro Conf on Computer Systems, Belgrade, Serbia.

ACM.

Paoloni, G. (2010). How to benchmark code execution

times on Intel IA-32 and IA-64 instruction set archi-

tectures. Intel Corporation.

Robison, S. (2008). The next wave: Everything as a Ser-

vice. Hewlett-Packard Company.

Sartakov, V. A., Brenner, S., Ben Mokhtar, S., Bouchenak,

S., Thomas, G., and Kapitza, R. (2018). EActors:

Fast and ﬂexible trusted computing using SGX. In

Intl Middleware Conf, Rennes, France. ACM.

Shaon, F., Kantarcioglu, M., Lin, Z., and Khan, L. (2017).

SGX-BigMatrix: A practical encrypted data ana-

lytic framework with trusted processors. In Conf on

Computer and Communications Security, Dallas, TX,

USA. ACM.

Shimizu, A., Townley, D., Joshi, M., and Ponomarev, D.

(2019). EA-PLRU: Enclave-aware cache replacement.

In Intl Wksp on Hardware and Architectural Support

for Security and Privacy, Phoenix, AZ, USA. ACM.

Silva, R., Barbosa, P., and Brito, A. (2017). DynSGX:

A privacy preserving toolset for dinamically load-

ing functions into Intel SGX enclaves. In Intl Conf

on Cloud Computing Technology and Science, Hong

Kong, China. IEEE.

Soriente, C., Karame, G., Li, W., and Fedorov, S. (2019).

ReplicaTEE: Enabling seamless replication of SGX

enclaves in the cloud. In Euro Sym on Security and

Privacy, Stockholm, Sweden. IEEE.

Svenningsson, J., Paladi, N., and Vahidi, A. (2021). Faster

enclave transitions for IO-intensive network applica-

tions. In Wksp on Secure Programmable Network In-

frastructure, Virtual Event. ACM.

Taassori, M., Shaﬁee, A., and Balasubramonian, R. (2018).

VAULT: Reducing paging overheads in SGX with ef-

ﬁcient integrity veriﬁcation structures. In Intl Conf

on Architectural Support for Programming Languages

and Operating Systems, Williamsburg, VA, USA.

ACM.

Tang, Y., Li, K., and Chen, J. (2019). Authenticated LSM

trees with minimal trust. In Intl Conf on Security

and Privacy in Communication Systems, Orlando, VA,

USA. Springer.

Tian, H., Zhang, Q., Yan, S., Rudnitsky, A., Shacham, L.,

Yariv, R., and Milshten, N. (2018). Switchless calls

made practical in Intel SGX. In Wksp on System Soft-

ware for Trusted Execution, Toronto, ON, Canada.

ACM.

Weichbrodt, N., Heinemann, J., Almstedt, L., Aublin, P.-

L., and Kapitza, R. (2021). sgx-dl: Dynamic loading

and hot-patching for secure applications: Experience

paper. In Intl Middleware Conf, Qu

ebec City, QC,

Canada. ACM.

Weisse, O., Bertacco, V., and Austin, T. (2017). Regaining

lost cycles with HotCalls: A fast interface for SGX se-

cure enclaves. In Intl Sym on Computer Architecture,

Toronto, ON, Canada. ACM.

Will, N. C. and Maziero, C. A. (2020). Using a shared SGX

enclave in the UNIX PAM authentication service. In

Intl Systems Conf, Montreal, QC, Canada. IEEE.

Enclave Management Models for Safe Execution of Software Components

485
