An Environmental Sound Classification Algorithm Based on

Multiscale Channel Feature Fusion

Wen Zhao

, Helong Wang

, Yizi Chen

, Xuesong Pan

*,2

, Kaiyue Zhang

and ZhenXiang Bai

Ocean University of China, Qingdao, China

Qingdao Haier Air Conditioner Co., Ltd, State Key Laboratory of Digital Household Appliances, Qingdao, China

Qingdao Haier Air Conditioner Co., Ltd, Qingdao, China

Keywords: Environmental Sound Classification, Feature Fusion, Deep Learning.

Abstract: In recent years, the automatic classification of urban environmental sounds has emerged as a pivotal task in

the urban informationization process. Despite the immense potential of environmental sound classification,

the accuracy and efficiency of automated classification often fall short of expectations. This paper proposes

an environmental sound classification algorithm that integrates multiscale channel feature fusion, aiming to

significantly reduce computational complexity while improving classification accuracy. The proposed

algorithm comprises two modules: a multiscale channel feature fusion module and a selective feature fusion

module, which dynamically merge temporal and frequency domain features. Finally, a series of ablation

experiments are conducted and compared with other mainstream algorithms in environmental sound

classification, revealing that the proposed algorithm possesses smaller parameter count and higher

classification accuracy, thus substantiating the effectiveness of the multiscale channel feature fusion

algorithm.

INTRODUCTION

Environmental sound refers to the non-linguistic

sounds that surround us in our daily lives, providing

important clues about our surroundings. Studying

environmental sound is of significant importance for

understanding the environment, predicting

environmental changes, and improving the

relationship between humans and the environment.

However, the current performance of environmental

sound classification is not ideal, and this field faces

numerous challenges. As a non-stationary signal,

environmental sound covers a wide range of audio

sources, making it difficult to represent with a single

template. Moreover, environmental sound itself is

similar to background noise, further complicating

the classification process. To address the main

challenge of extracting effective audio features in

environmental sound classification, this paper

proposes an algorithm based on multiscale channel

feature fusion and introduces a Multiscale Channel

Feature Fusion Module (MFFM). By processing the

mel spectrogram features through mel filters, the

algorithm extracts both temporal and frequency

domain features. It then utilizes a method of

attention-based multi-channel feature fusion to

generate a novel three-dimensional feature map,

thereby further enhancing the accuracy of

environmental sound classification.

RELATED WORK

Early research on environmental sound classification

primarily focused on traditional classification

methods (Temko, A.- Piczak, K.), with limited

attention given to audio feature extraction, leading to

lower classification accuracy. In recent years, the

integration of deep neural networks with feature

extraction has gradually become the mainstream

approach for environmental sound classification,

showcasing excellent generalization performance.

For instance, Piczak proposed a method for

environmental sound classification using a two-layer

convolutional network, pioneering the application of

convolutional neural networks in this field (Piczak,

2015). Dong, from both the temporal and frequency

domains, analyzed audio signals and verified the

effectiveness of processing audio data from both

temporal and frequency perspectives (Zhang, 2018).

Zhang et al. utilized a CRNN model based on

Zhao, W., Wang, H., Chen, Y., Pan, X., Zhang, K. and Bai, Z.

An Environmental Sound Classiﬁcation Algorithm Based on Multiscale Channel Feature Fusion.

DOI: 10.5220/0012273800003807

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 2nd International Seminar on Artiﬁcial Intelligence, Networking and Information Technology (ANIT 2023), pages 56-60

ISBN: 978-989-758-677-4

attention mechanism to capture the correlation

between the temporal and frequency domains,

achieving high classification accuracy. However, the

challenge of extracting effective representations for

audio features still persists. Therefore, this paper

proposes an algorithm model for environmental

sound classification based on multiscale channel

feature fusion, consisting of a temporal-frequency

feature extraction module and a selective feature

fusion module. Through ablative experiments on

temporal and frequency features and comparative

experiments on selective feature fusion, the

effectiveness of the proposed algorithm in this paper

is ultimately demonstrated.

MULTISCALE CHANNEL

FEATURE FUSION

This chapter presents the algorithm for multiscale

channel feature fusion. Since audio is typically

composed of three physical attributes: frequency,

time, and amplitude, and the human auditory system

perceives sounds through neural encoding along

these three dimensions, we propose a feature

extraction module that mimics the human auditory

system to capture the frequency-time characteristics

of environmental sounds.

3.1 Module for Temporal and Spectral

Feature Extraction

By simulating the mechanisms of the human

auditory system, this study adopts a dual perspective

from the time domain and frequency domain to

mimic how the human ear classifies environmental

sounds. By applying frequency attention and time

attention mechanisms, we can dynamically select

and fuse frequency domain and time domain features

to obtain more accurate representations of

environmental sound. As the spectrogram processed

by mel filters is a spectro-temporal representation,

the feature extraction module in this section

separately extracts features from the time domain

and frequency domain. The specific module

structure is illustrated in Figure 1.

Figure 1: Module for Temporal and Spectral Feature

Extraction.

3.2 Selective Feature Fusion Modules

Based on the temporal and spectral features obtained

from Section A, we propose the Selective Feature

Fusion Module (SFFM) for dynamically selecting

and fusing temporal and spectral features. Figure 2

illustrates the detailed architecture of this module.

Figure 2: Selective Feature Fusion Module.

The input of SFFM comprises three components,

including temporal feature map Et, frequency feature

map Ef, and Log Mel spectrogram S. Initially, we

merge the obtained S, Et, and Ef through element-

wise addition to create a new feature mapping E.

Subsequently, we perform global average pooling

(GAP) to derive the global feature mapping gap.

(1)

After passing through a fully connected (FC)

layer with a non-linear transformation, three

additional FC layers are utilized to learn crucial

features for each channel. A softmax layer is then

applied to generate feature mappings. Subsequently,

matrix multiplication is performed between the three

inputs and feature mappings to obtain weighted

feature maps. Following channel-wise summation,

the fused three-dimensional temporal-frequency

feature map E is obtained, which encapsulates

abundant temporal and frequency information.

(2)

An Environmental Sound Classiﬁcation Algorithm Based on Multiscale Channel Feature Fusion

EXPERIMENTAL SETUP AND

RESULT ANALYSIS

4.1 Experimental Setup

In this part of the experiment, we choose the

sampling rate of 11025 to balance the computational

efficiency and obtain higher classification accuracy.

The extracted logmel feature frames have a duration

of 1024, use a 60 mel filter, and utilize 50% window

overlap. The training process of the network model

consists of 120 epochs with a batch size of 128. For

ESC-10, ESC-50 and UrbanSound8K datasets, five

and ten cross-validations were used, respectively. In

addition, we choose to use classification cross

entropy as a loss function and adopt L2

regularization to enhance the generalization ability

of the model.

4.2 Temporal-Frequency Feature

Ablation Experiment

To validate the effectiveness of the multi-scale

channel feature fusion method, a series of ablation

experiments were conducted using the

UrbanSound8K, ESC-10, and ESC-50 datasets for

evaluation. Table 1 presents the results of the

temporal-frequency feature ablation experiments in

this section. The experimental results demonstrate

that, in the UrbanSound8K dataset, the classification

accuracy fluctuates between 94% and 95% when

using a single feature or fusing two features.

However, when all three features are fused together,

the classification accuracy reaches 96.7%. In the

ESC-10 and ESC-50 datasets, the classification

accuracy achieved after channel feature fusion is

80% for both datasets. Removing one or two

features leads to a significant decrease in the

classification accuracy. Therefore, the proposed

channel feature fusion method has advantages in

handling datasets with a smaller sample size and a

larger number of categories.

Table 1: Ablation results of time-frequency characteristics.

Time-

domain

feature

Frequency

-domain

feature

Logmel

feature

UrbanSoun

d8K

ESC-10 ESC-50

√ × × 95.1% 70.0% 74.0%

× √ × 95.3% 72.5% 74.5%

× × √ 94.5% 77.5% 75.0%

√ √ × 95.1% 72.5% 69.5%

× √ √ 95.3% 75.0% 68.0%

√ × √ 95.3% 72.5% 70.0%

√ √ √ 96.7% 82.0% 80.0%

4.3 Select Feature Fusion Comparative

Experiment

In the feature fusion part, the SFFM proposed in this

paper is compared with the average superposition,

weighted superposition, horizontal concatenation

and vertical concatenation feature fusion methods on

UrbanSound8K data set, so as to verify the feature

representation ability of SFFM after feature fusion.

Table 2: Comparison between feature fusion and other

fusion modes

Fusion

mode

Feature size

after fusion

UrbanSound8K ESC-10 ESC-50

Average

stac

(60,44,1) 94.9% 75.0% 75.0%

Weighted

stac

(60,44,1) 94.8% 77.5% 75.0%

Horizontal

splicing

(120,44,1) 94.7% 75.0% 64.0%

Vertical

splicing

(60,88,1) 96.3% 72.5% 80.0%

Selective

feature

fusion

(60,44,3) 96.7% 82.0% 80.0%

The comparative experimental results are shown

in Table 2, and it can be clearly seen that the SFFM

feature fusion method proposed in this paper shows

the optimal classification effect on each data set.In

order to better display the experimental results, this

section visualizes the experimental classification

results and presents them from multiple perspectives

by using curves and confusion matrix.

(a)

ANIT 2023 - The International Seminar on Artiﬁcial Intelligence, Networking and Information Technology

(b)

(c)

Figure 3: Accuracy curve and loss curve of ESC-10, ESC-

50, UrbanSound8K.

The curves depicting the classification accuracy

and loss of the environmental sound classification

algorithm used in this study, for the ESC-10, ESC-

50, and UrbanSound8K datasets, are presented in

Figure 3. Specifically, Figure (a) corresponds to the

ESC-10 dataset, Figure (b) represents the ESC-50

dataset, and Figure (c) relates to the UrbanSound8K

dataset. In these curves, the solid red line represents

the loss curve of the test set, while the dashed red

line represents the loss curve of the training set. On

the other hand, the solid green line depicts the

accuracy curve of the test set, while the dashed

green line signifies the accuracy curve of the

training set.

Figure 4: ESC-10 Confusion matrixAND and

UrbanSound8K confusion matrix.

4.4 Comparison with SOTA Methods

at Home and Abroad

Table 3 compares the environmental sound

classification method proposed in this paper based

on multi-scale channel feature fusion with other

mainstream methods at home and abroad. On the

UrbanSound8K dataset, our method achieves 97.3%

classification accuracy, which is 2% higher than the

enhanced DCNN model. It is slightly lower than

Mushtaq's NAA method and Inik's combined CNN

and PSO method. However, both methods achieve

high accuracy while significantly increasing

computational complexity and parameter size. In

contrast, the network architecture adopted in this

paper is a stacked four-layer neural network with a

parameter size of only 0.44M, which is smaller than

all current mainstream methods and saves

computing resources.

Table 3: Compares SOTA mainstream methods at home

and abroad on different datasets.

Year Author Method

Parameter

quantity

ESC-10 ESC-50

UrbanSound

2015 Piczak

Piczak-

CNN

26M 73.00% 64.50% 73.70%

2016 Dai et al. M18 8.7M / / 71.68%

2018 Zhang et al.

Improved

VGG8

/ 91.70% 83.90% 83.70%

2019 Su et al. CNN6 6.6M / 85.60% 93.40%

2020 Mushtaq et al. DCNN 3.0M 94.90% 89.20% 95.30%

2021 Zhang et al. ACRNN 3.81M 93.70% 86.10% /

2021 Mushtaq et al. NAA 112M 99.04% 97.57% 99.49%

2021 S. Luz et al.

Handcrafte

d+Deep

1.48M / 86.20% 96.80%

2023 Inik CNN+PSO 45.9M 98.64% 96.77% 98.45%

This Paper SFFM 0.44M 96.11% 95.90% 97.30%

An Environmental Sound Classiﬁcation Algorithm Based on Multiscale Channel Feature Fusion

CONCLUSION

In this paper, we propose a feature optimization

method called multi-scale channel feature fusion. It

involves extracting logmel features in both the time

and frequency domains for sound classification.

Subsequently, an attention mechanism is employed

to fuse the original features, time-domain features,

and frequency-domain features across channels,

enabling efficient classification of environmental

sounds. By comparing our method with current

state-of-the-art approaches in terms of accuracy and

parameter size, we provide a comprehensive

evaluation of the advantages and disadvantages of

our proposed method.

ACKNOWLEDGMENTS

This work was financially supported by Major

scientific and technological innovation Project of

Shandong Key R & D Plan "Smart and Healthy Air

Industry Project based on New Generation

Information Technology" , and Key R & D projects

of Shandong Province (2020JMRH0201).

REFERENCES

Temko, A., Nadeu, C. Acoustic Event Detection in

Meeting-Room Environments[J]. Pattern Recognition

Letters 2009, 30 (14), 1281–1288. https://doi.org/

10.1016/j.patrec.2009.06.009.

Gupta, S.; Karanath, A.; Mahrifa, K.; Dileep, A.;

Thenkanidiyoor, V. Segment-Level Probabilistic

Sequence Kernel and Segment-Level Pyramid Match

Kernel Based Extreme Learning Machine for

Classification of Varying Length Patterns of Speech[J].

International Journal of Speech Technology 2019, 22

(1), 231–249. https://doi.org/10.1007/s10772-018-0958

7-1.

Stowell, D.; Giannoulis, D.; Benetos, E.; Lagrange, M.;

Plumbley, M. Detection and Classification of Acoustic

Scenes and Events[J]. IEEE Transactions On

Multimedia 2015, 17 (10), 1733–1746.

https://doi.org/10.1109/TMM.2015.2428998.

Piczak, K.; ACM. ESC: Dataset for Environmental Sound

Classification[C]; 2015; pp 1015–1018.

https://doi.org/ 10.1145/2733373.2806390.

Piczak KJ. Environmental Sound Classification With

Convolutional Neural Networks.[C] In: Erdogmus D,

Akcakaya M, Kozat S, Larsen J, eds. 2015 IEEE

International Workshop on Machine Learning for

Signal Processing. IEEE International Workshop on

Machine Learning for Signal Processing. IEEE Signal

Processing Soc; Northeast Univ; Intel; 2015.

Zhang, Z.; Xu, S.; Cao, S.; Zhang, S. Deep Convolutional

Neural Network with Mixup for Environmental Sound

Classification[J]; Pattern Recognition and Computer

Vision, PT II, Eds.; 2018; Vol. 11257, pp 356–367.

https://doi.org/10.1007/978-3-030-03335-4_31.

Dai W, Dai C, Qu S, et al. Very Deep Convolutional

Neural Networks for Raw Waveforms[C], IEEE

International Conference on Acoustics, 2017,421-425.

Su, Y.; Zhang, K.; Wang, J.; Zhou, D.; Madani, K.

Performance Analysis of Multiple Aggregated

Acoustic Features for Environment Sound

Classification[J]. Applied Acoustics 2020, 158.

https://doi.org/10.1016/j.apacoust.2019.107050.

Mushtaq, Z.; Su, S. Environmental Sound Classification

Using a Regularized Deep Convolutional Neural

Network with Data Augmentation[J]. Applied

Acoustics 2020, 167. https://doi.org/10.1016/

j.apacoust.2020.107389.

Zhang, Z.; Xu, S.; Zhang, S.; Qiao, T.; Cao, S. Attention

Based Convolutional Recurrent Neural Network for

Environmental Sound Classification[J].

Neurocomputing 2021, 453, 896–903. https://doi.org/

10.1016/j.neucom.2020.08.069.

Mushtaq, Z.; Su, S.; Tran, Q. Spectral Images Based

Environmental Sound Classification Using CNN with

Meaningful Data Augmentation[J]. Applied Acoustics

2021, 172. https://doi.org/10.1016/j.apacoust.

2020.107581.

Luz, J.; Oliveira, M.; Araujo, F.; Magalhaes, D. Ensemble

of Handcrafted and Deep Features for Urban Sound

Classification[J]. Applied Acoustics 2021, 175.

https://doi.org/10.1016/j.apacoust.2020.107819.

Inik, O. CNN Hyper-Parameter Optimization for

Environmental Sound Classification[J]. Applied

Acoustics 2023, 202. https://doi.org/10.1016/

j.apacoust.2022.109168.

ANIT 2023 - The International Seminar on Artiﬁcial Intelligence, Networking and Information Technology
