Analyzing Image Based Strategies for Android Malware Detection and

Classiﬁcation: An Empirical Exploration

Chirag Jaju

1,∗

, Dhairya Agrawal

1,∗

Rishi Poddar

1,∗

, Shubh Badjate

1,∗

, Sidharth Anand

1,∗

Barsha Mitra

1,†

and Soumyadeep Dey

Department of CSIS, BITS Pilani, Hyderabad Campus, Hyderabad, India

Microsoft India, India

Soumyadeep.Dey@microsoft.com

Keywords:

Android Malware, APK, Image Conversion, CNN, Classiﬁcation.

Abstract:

In recent years, the popularity of Android as a mobile operating system has grown exponentially and so it has

been widely used in a huge array of mobile phones. This large scale proliferation of Android has resulted

in it being extensively targeted by malware. Numerous families of malware have been developed with the

sole purpose of infecting mobile phones and perpetrating different types of attacks on these devices and their

users. Naturally, in the past few years, researchers have focused on developing strategies for detecting and

classifying malware families. A large number of such strategies are based on converting the malware APK ﬁles

to grayscale or color images. In this paper, we survey six APK to image conversion techniques and perform

a comparative empirical analysis of these methods with respect to malware detection and classiﬁcation. We

implement the six approaches to convert the benign as well as malware binaries into images and then use

three CNN-based models to distinguish between benign and malware ﬁles and also to classify the various

malware families. We use two very popular open-source Android malware datasets, CICAndMal2017 and the

Drebin dataset for comparing the performance of the different image conversion techniques for the detection

and classiﬁcation tasks in terms of accuracy and F1-score. The results of the study provide insights into

the relative performance of these approaches and help to determine the combination of the image conversion

approach and the classiﬁcation model that provides the best detection and classiﬁcation performance.

1 INTRODUCTION

Mobile phones, especially smartphones have become

an indispensable aspect of our lives. These smart-

phones have several types of applications installed on

them and store a huge amount of data, a large percent-

age of which is user data and thus is quite sensitive

in nature. As a result, smartphones are targeted by

hackers and cyber criminals for stealing private user

information and for perpetrating various malicious ac-

tivities exploiting such information. These attacks are

primarily launched by infecting the smartphones with

malicious softwares or malwares. Since Android is

one of the most widely used mobile operating sys-

tems, in recent years, scores of Android malware have

been developed and disseminated into the cyberspace.

This has triggered the design and development of var-

∗

Chirag Jaju, Dhairya Agrawal, Rishi Poddar, Shubh

Badjate and Sidharth Anand have equal contribution

†

Corresponding Author

ious malware detection and classiﬁcation strategies as

countermeasures. In the recent past, researchers have

focused on creating image based malware detection

and classiﬁcation methods which include (Ni et al.,

2018), (Gibert et al., 2020), (Mohammed et al., 2021),

(O’Shaughnessy and Sheridan, 2022), (Joyce et al.,

2023). These approaches convert the malware APKs

into images (grayscale or color) and identify the mal-

ware families by classifying these converted images.

Such methods differ from one another with respect to

the algorithm for creating the images.

In this paper, we study six APK to image con-

version techniques and compare as well as analyze

their performance. The methods that we have se-

lected include (Kumar et al., 2016), (Kalash et al.,

2018), (Fang et al., 2020), (

Unver and Bakour, 2020),

(Zhang et al., 2021) and (Zhu et al., 2023). We have

implemented the image conversion methods proposed

in these papers to obtain either grayscale or color

images from the APKs. The converted images are

Jaju, C., Agrawal, D., Poddar, R., Badjate, S., Anand, S., Mitra, B. and Dey, S.

Analyzing Image Based Strategies for Android Malware Detection and Classiﬁcation: An Empirical Exploration.

DOI: 10.5220/0012139100003555

In Proceedings of the 20th International Conference on Security and Cryptography (SECRYPT 2023), pages 863-869

ISBN: 978-989-758-666-8; ISSN: 2184-7711

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

863

then classiﬁed using Convolutional Neural Network

(CNN) based models like Resnet50 (He et al., 2015),

MobileNetV2 (Sandler et al., 2019), and 3C2D (Mo-

hammed et al., 2021). The primary objective of our

work is to provide an experimental comparative anal-

ysis of the above-mentioned image conversion based

malware detection and categorization techniques and

present an insight regarding the relative performance

of these approaches to researchers exploring this do-

main. The insights obtained from our empirical study

will help to determine the combination of the image

conversion approach and the classiﬁcation model that

provides the best detection as well as classiﬁcation

performance. It is to be noted here that we focus

only on the algorithms to obtain the converted im-

ages presented in the above-mentioned works in an

attempt to study and analyze how the performance of

malware detection and categorization is affected by

various image transformation techniques. Our study

does not focus on presenting any new neural network

architecture or classiﬁcation method for malware de-

tection and identiﬁcation.

The rest of the paper is organized as follows. Sec-

tion 2 outlines the preliminaries related to APK ﬁles.

In Section 3, we describe the different techniques to

convert the APK ﬁles to grayscale and color images.

Section 4 presents detailed information regarding the

datasets used for the experiments. Experimental re-

sults and their analysis are presented in Section 5 with

Section 6 concluding the paper.

2 APK PRELIMINARIES

An APK ﬁle is an Android application package,

which is used to distribute and install applications on

devices running the Android operating system. It is

essentially a compressed archive of all the ﬁles that

make up the application. The APK ﬁle contains the

compiled code, resources, and manifest ﬁles that are

necessary for the application to run properly. The

contents of an APK ﬁle typically include the follow-

ing components:

• AndroidManifest.xml. This is an XML ﬁle that

contains information about the application, such

as the package name, version number and nec-

essary permissions. It also contains information

about the application’s activities, services, broad-

cast receivers, and content providers.

• resources.arsc. This folder contains all the re-

sources used by the application such as images,

audio, video, strings, and layouts.

• classes.dex. This ﬁle format is used for stor-

ing compiled code for Android applications. It

contains the Dalvik bytecode, which is the byte-

code that Android devices use to run applications.

The Dalvik bytecode is compiled from Java class

ﬁles and is optimized for Android devices. The

.dex ﬁle format consists of several distinct com-

ponents:

– Header: contains the header information which

includes the ﬁle size, the number of strings,

types, classes, and methods, and the checksum.

– Strings: contains the strings used in the appli-

cation.

– Types: contains information about the types of

data used in the application.

– Classes: contains information about the classes

that are used in the application.

– Methods: contains information about the meth-

ods that are used in the application.

– Data: contains the actual data used by the ap-

plication.

– Debug Info: contains debugging information

which can be used to debug the application.

• lib. This folder contains any native libraries used

by the application.

• Assets. This folder contains any additional as-

sets needed by the application, such as text ﬁles,

databases and other ﬁles.

• META-INF. This is the directory that contains the

cryptographic signature of the application and is

used to verify the authenticity of the application.

3 IMAGE CONVERSION

TECHNIQUES STUDIED

In this section, we ﬁrst describe the method for trans-

forming binary ﬁles to images and then brieﬂy discuss

the techniques that we have considered in this work

for converting the malware APKs to images.

3.1 Byteplot-based Binary File to Image

Conversion for APKs

The process of converting binary ﬁles to images is

known as byteplot-based binary ﬁle to image conver-

sion. This process is a powerful tool for reverse en-

gineering binary ﬁles and allows for the visualization

of their internal static structure. The byteplot-based

binary ﬁle to image conversion method was ﬁrst in-

troduced by (Conti et al., 2008). The authors present

an approach for transforming binary ﬁles into visual

SECRYPT 2023 - 20th International Conference on Security and Cryptography

864

images that are referred to as byteplots. This method

provides a visual representation of binary ﬁle frag-

ments to help in the identiﬁcation of common ﬁle

formats, thus improving the capabilities of text-based

hex editors. Byteplot-based binary ﬁle to image con-

version involves converting a binary ﬁle into a 1D ar-

ray containing 8-bit unsigned integers. (Nataraj et al.,

2011) applied byteplots for the ﬁrst time to represent

malware binaries as images for the purpose of mal-

ware classiﬁcation.

This paper explores the use of byteplot-based bi-

nary ﬁle to 1D array of unsigned integers conver-

sion strategy for converting APK ﬁles to 1D arrays

of unsigned integers. Subsequently, these arrays are

used to obtain the image representations of the APKs.

Six techniques are explored for this purpose, includ-

ing three grayscale and three color image conversion

methods. The converted images are then used for var-

ious downstream tasks such as benign vs. malware

classiﬁcation and malware family classiﬁcation. In

the following sub-sections, we describe the methods

considered in this study for converting APKs to im-

ages.

3.1.1 Converting APKs to Grayscale Images

Converting a binary ﬁle into an image can be done

using byteplot. The resultant 1D array can be con-

sidered as a grayscale image with a range of 0 to

255 (0 corresponding to black and 255 correspond-

ing to white). The width of the image is ﬁxed, while

the height can vary across different ﬁle sizes as men-

tioned in Table 1. The information presented in the

tables is obtained from (Nataraj et al., 2011).

Table 1: Relation between File Size and Image width

(Nataraj et al., 2011).

File Size (in kB) Width

< 10 32

10 – 30 64

30 – 60 128

60 – 100 256

100 – 200 384

200 – 500 512

500 – 1000 768

> 1000 1024

Based on the above-mentioned strategy to convert

binary ﬁles to grayscale images, we have explored

three approaches that are discussed next. We refer to

the methods as M1Gray, M2Gray and M3Gray.

• M1Gray. In this method, the entire APK ﬁle is

considered as a binary ﬁle, and then the byteplot-

based technique is utilized to represent the APK

as an image ﬁle (Kalash et al., 2018).

• M2Gray. The AndroidManifest.xml and

classes.dex ﬁles have been observed to contain

enough information to classify various malware

families (Zhang et al., 2021). As a result, these

two ﬁles have been used to convert an APK to

an image for the purpose of malware classiﬁ-

cation. The AndroidManifest.xml ﬁle describes

the behavior of the application and how it will

be executed, while the classes.dex code is the

compiled form of the application, containing the

main code.

• M3Gray. Researchers have investigated the

use of resources.arsc ﬁles, along with Android-

Manifest.xml, and classes.dex ﬁles for malware

classiﬁcation (

Unver and Bakour, 2020). Re-

sources.arsc ﬁles contain binary version of the

compiled resources of an Android application as

well as important information about user interface

layouts.

3.1.2 Converting APKs to Color Images

In this paper, we have investigated three methods for

visualizing an APK as a color image for malware

identiﬁcation. The approaches explored in this work

are referred to as M1Color, M2Color and M3Color

and are discussed below.

• M1Color. The AndroidManifest.xml ﬁle and the

data part of the classes.dex ﬁle are initially used to

create a 1D array consisting of unsigned integers

as per the method described in Sub-section 3.1.

This 1D array is then converted to a 2D array us-

ing the width information from Table 1. Finally,

the 2D array is reshaped into a 3D array, which

can be used to construct an RGB image, providing

a visual representation of the data (Kumar et al.,

2016).

• M2Color. Researchers have observed that the In-

dex region of the classes.dex ﬁle contains enough

information for effective malware classiﬁcation.

To reduce redundancy and facilitate analysis, the

.dex ﬁle is pre-processed by removing the header

and data sections, leaving only the Index sec-

tion (Zhu et al., 2023). The six hexadecimal

characters are then converted to three channels of

numbers between 0 and 255 and stored in a 2D

array. This array is reshaped to a 3D array to con-

struct an RGB image.

• M3Color. Using information from different sec-

tions of a .dex ﬁle, an APK to a color image

conversion technique is presented in (Fang et al.,

2020). The header section contains the byte off-

set of each section, and this information is used

to calculate the RGB channels for that section.

Analyzing Image Based Strategies for Android Malware Detection and Classiﬁcation: An Empirical Exploration

865

To calculate the green channel, the binary format

of the .dex ﬁle is used to build a vector consist-

ing of zeros and ones, which is then transformed

into an n × m matrix. The entropy matrix, which

represents the red channel of the image, is cal-

culated using Eq 1, where c

represents the fre-

quency of byte i and p(ci) is its probability. The

entropy is then mapped to the range [0 - 255] us-

ing Eq 2. The blue channel represents the propor-

tion of each section in the .dex ﬁle, which is cal-

culated and converted to the range [0 - 255] using

Eq 3.

entropy = −

255

∑

i=0

p(c

)log

p(c

) (1)

R = (entropy

mod 8) ×

255

(2)

B =

SectionSize

FileSize

× 255 (3)

4 DATASET DESCRIPTION

In this work, we have used two datasets for the

malware detection and classiﬁcation tasks - the

Drebin dataset (Arp et al., 2014) and CICAnd-

Mal2017 (Lashkari et al., 2018). In the following sub-

sections, we provide a detailed description of each

dataset.

4.1 Drebin Dataset

The Drebin dataset is a publicly available resource for

classiﬁcation of Android malware families. It con-

tains 1,29,013 Android applications, with 5,560 of

them being malicious. The dataset was collected over

a period of more than two years, from August 2010

to October 2012. The samples have been collected

from Google Play Store, different alternative Chinese

and Russian Markets as well as from other sources

like Android websites, security blogs and malware fo-

rums. Moreover, all samples from the Android Mal-

ware Genome Project (Spreitzenbarth et al., 2013),

(Arp et al., 2014) are present in the dataset.

The dataset is divided into two categories - benign

applications (Google Play Store - 96,150 applications,

different alternative Chinese Markets - 19,545 appli-

cations, alternative Russian Markets - 2,810 applica-

tions, and other sources - 13,106 applications) and

malicious applications (detected by at least two of the

ten anti-virus scanners used which include ClamAV,

AVG, F-Secure, Kaspersky, AntiVir, McAfee, Panda,

BitDefender, Sophos and ESET).

The Drebin dataset comprises of 179 different

malware families, including several families that are

in active distribution in current application markets.

Drebin is one of the largest and most widely used

datasets for Android malware classiﬁcation and is a

valuable resource for researchers and practitioners to

test and develop their malware identiﬁcation algo-

rithms. The dataset contains a high degree of imbal-

ance with respect to the number of malware instances

per family. To address this issue, we have limited our

experiments to the top 20 malware families present in

the dataset. These top 20 families are shown in Ta-

ble 2.

Table 2: Top 20 Families of Malware of the Drebin dataset

(Arp et al., 2014).

Family Number Family Number

FakeInstaller 925 Adrd 91

DroidKungFu 667 DroidDream 81

Plankton 625 LinuxLotoor 70

Opfake 613 GoldDream 69

GingerMaster 339 MobileTx 69

BaseBridge 330 FakeRun 61

Iconosys 152 SendPay 59

Kmin 147 Gappusin 58

FakeDoc 132 Imlog 43

Geinimi 92 SMSreg 41

4.2 CICAndMal2017

CICAndMal2017 is an Android malware dataset

that consists of over 10,854 samples (4,354 mal-

ware and 6,500 benign) obtained from multiple

sources (Lashkari et al., 2018). The malware sam-

ples are classiﬁed into four categories: Ransomware,

Adware, SMS Malware and Scareware. The Ran-

somware category consists of samples from the fol-

lowing malware families - (i) Charger, (ii) Jisut, (iii)

Koler, (iv) LockerPin, (v) Simplocker, (vi) Pletor,

(vii) PornDroid, (viii) RansomBO, (ix) WannaLocker

and (x) Svpeng. The Adware category consists of

samples of (i) Dowgin, (ii) Ewind, (iii) Feiwo, (iv)

Gooligan, (v) Kemoge, (vi) koodous, (vii) Mobidash,

(viii) Selfmite, (ix) Shuanet, and (x) Youmi fami-

lies. The Scareware category consists of the fol-

lowing malware families - (i) AndroidDefender, (ii)

AndroidSpy.277, (iii) AV for Android, (iv) AVpass,

(v) FakeApp, (vi) FakeApp.AL, (vii) FakeAV, (viii)

FakeJobOffer, (ix) FakeTaoBao, (x) Penetho and (xi)

VirusShield. Lastly, the SMS Malware category con-

sists of samples from (i) BeanBot, (ii) Biige, (iii)

FakeInst, (iv) FakeMart, (v) FakeNotify, (vi) Jifake,

(vii) Mazarbot, (viii) Nandrobox, (ix) Plankton, (x)

SMSsniffer and (xi) Zsone families. The samples

have been collected from Google play published in

three consecutive years - 2015, 2016, and 2017.

SECRYPT 2023 - 20th International Conference on Security and Cryptography

866

Table 3: Experimental Results for CICAndMal2017 for Benign vs. Malware Classiﬁcation.

M1Gray M2Gray M3Gray M1Color M2Color M3Color

Model

Acc F

Resnet50 79.90 80.02 82.84 82.86 79.90 79.92 81.86 81.65 78.92 79.04 84.80 84.89

MobileNetV2 88.24 88.17 88.24 88.22 89.22 89.23 85.78 85.65 84.80 84.48 84.80 84.87

3C2D 85.78 85.72 86.76 86.79 86.27 86.27 82.84 82.83 85.29 85.33 83.82 83.84

5 RESULTS AND DISCUSSION

In this section, we discuss our experimental setup, the

experimental results and an analysis of the results ob-

tained. We have used Convolutional Neural Network

(CNN) based architectures such as Resnet50 (He

et al., 2015), MobileNetV2 (Sandler et al., 2019), and

a simple but efﬁcient shallow CNN-based architecture

3C2D (Mohammed et al., 2021) for our experiments.

We have evaluated the performance of the methods

with respect to the ability to distinguish between be-

nign and malware data using the benign data present

in the CICAndMal2017 dataset. We have also evalu-

ated the performance of the six APK to image trans-

formation methods on the CICAndMal2017 dataset

and the Drebin dataset with the top 20 malware fam-

ilies. For classiﬁcation purposes, each converted im-

age is resized to a 256 × 256 dimension image before

feeding it to the CNN architectures. We have com-

pared the performance in terms of the popular classi-

ﬁcation metrics Accuracy (Acc) and F1-Score (F

) to

show the effectiveness of each of the techniques.

The overall comparison of the strategies for the

benign vs. malware classiﬁcation on the CICAnd-

Mal2017 dataset, malware family classiﬁcation on the

CICAndMal2017 dataset and the Drebin dataset are

presented in Tables 3, 4, and 5 respectively. In these

tables, the red colored cells indicate the best perfor-

mance of a particular method across the three CNN-

based models, the gray colored cells correspond to

the best performance of a speciﬁc model across the

six methods and the bold-faced cells indicate the best

overall performance across all methods and models.

For the overall best performance, the cells are colored

gray and the values are also written in bold-face (the

red color has not been shown). We have used only

the CICAndMal2017 for classifying benign and mal-

ware ﬁles because out of the two datasets considered

in this work, only CICAndMal2017 contains benign

APK samples. The Drebin dataset contains the ex-

tracted features from the benign APKs and hence is

not suitable for our empirical study.

Results for the benign vs. malware classiﬁcation

depicted in Table 3 provide the following insights:

• Resnet50 model achieved the highest accuracy of

84.8% and the highest F1-score of 84.89% for

the M3Color conversion technique. The model

achieved the lowest accuracy of 79.9% and low-

est F1-score of 79.92% when used for the M2Gray

conversion technique.

• MobileNetV2 achieved the highest accuracy of

89.22% and the highest F1-score of 89.23% while

using the M3Gray method. The model achieved

the lowest accuracy of 84.8% and lowest F1-score

of 84.48% when used for the M2Color approach.

• 3C2D gave the highest accuracy of 86.76% and

the highest F1-score of 86.79% for M2Gray,

whereas achieved the lowest accuracy of 82.84%

and the lowest F1-score of 82.83% for M1Color.

• Overall, MobileNetV2 provided the highest accu-

racy and F1-score values when used in conjunc-

tion with M3Gray conversion technique. How-

ever, all three classiﬁcation models gave, on an

average, an accuracy and F1-score of more than

80% for all six conversion methods.

We next analyze the results of malware categoriza-

tion. Some observations from Table 4 for CICAnd-

Mal2017 are as follows:

• Resnet50 model achieved the highest accuracy

and F1-score for the M1Color method, with

54.76% accuracy and 54.95% F1-score.

• MobileNetV2 achieved the maximum accuracy

and F1-score for M3Gray, with 54.76% accuracy

and 55.38% F1-score.

• 3C2D model achieved the highest accuracy and

F1-score for M1Gray method, with 61.90% accu-

racy and 62.47% F1-score.

• Overall, the results demonstrate that 3C2D is

the most accurate and performs the best for the

M3Color method, while the MobileNetV2 model

performs the best for M2Gray. MobileNetV2

gives the best performance for M3Gray, and its

performance is more or less consistent across all

the conversion techniques. Resnet50 gives the

best performance for the color-based conversion

methods.

Table 5 provides the performance of the three classi-

ﬁcation models for the six APK to image conversion

approaches for top 5, top 10 and top 20 classes of the

Analyzing Image Based Strategies for Android Malware Detection and Classiﬁcation: An Empirical Exploration

867

Table 4: Experimental Results for CICAndMal2017.

M1Gray M2Gray M3Gray M1Color M2Color M3Color

Model

Acc F

Resnet50 42.86 43.39 39.29 39.22 53.57 53.80 54.76 54.95 53.57 53.32 51.19 51.92

MobileNetV2 47.62 48.27 51.19 50.70 54.76 55.38 46.43 47.43 50.00 50.83 50.00 50.59

3C2D 61.90 62.47 48.81 49.20 59.52 60.56 59.52 59.94 59.52 60.23 55.95 56.87

Table 5: Experimental Results for the Top 5, Top 10 and Top 20 Malware Families of the Drebin Dataset.

M1Gray M2Gray M3Gray M1Color M2Color M3Color

Dataset Model

Acc F

Resnet50 93.36 93.25 92.73 92.80 92.89 93.21 91.47 91.61 88.78 88.76 93.05 93.06

MobileNetV2 91.47 91.64 92.73 92.79 92.42 92.53 90.84 90.93 88.47 88.31 90.52 90.31Top5

3C2D 92.42 92.40 93.52 93.49 91.94 92.00 93.52 93.52 90.36 90.48 93.84 93.85

Resnet50 80.31 76.26 91.50 89.62 91.30 90.52 91.91 90.93 83.75 80.81 76.87 71.59

MobileNetV2 76.20 69.64 81.05 76.02 84.69 81.70 75.46 69.91 78.35 73.34 79.97 75.36Top10

3C2D 97.71 97.69 97.24 97.23 97.10 97.07 96.70 96.63 95.08 95.01 96.22 96.15

Resnet50 74.66 66.89 51.23 37.51 80.95 75.88 74.66 67.23 69.62 61.02 71.42 63.01

MobileNetV2 65.79 54.50 73.58 65.51 63.51 53.52 64.41 56.12 54.34 43.52 65.43 55.12Top20

3C2D 96.29 96.28 96.29 96.20 96.29 96.23 94.97 94.83 93.65 93.56 93.53 93.20

Drebin dataset. The following can be observed for the

top 5 classes from the table.

• For top 5 classes, the Resnet50 model performs

the best with an accuracy of 93.36% and an

F1-score of 93.25% for the conversion method

M1Gray.

• MobileNetV2 gives the best performance with

M2Gray which has an accuracy of 91.47% and an

F1-score of 91.64%.

• 3C2D performs the best among all the three clas-

siﬁers giving an accuracy of 93.84% and an F1-

score of 93.85% for the M3Color method.

• All three models with all six APK to image con-

version techniques perform similarly for Drebin

top 5 classes.

The observations for the top 10 classes of Drebin from

Table 5 are:

• The best performance of Resnet50 has an accu-

racy of 91.91% and an F1-score of 90.93% for the

method M1Color.

• For the M3Gray method, MobileNetV2 has the

best accuracy of 84.69% and the highest F1-score

of 81.70%.

• 3C2D performs the best with an accuracy of

97.71% and an F1-score of 97.69% with M1Gray.

Table 5 depicts the following for the top 20 classes.

• The best performance of the Resnet50 model

is obtained for the conversion method M3Gray

with an accuracy of 80.95% and an F1-score of

75.88%.

• The best performance of MobileNetV2 provides

an accuracy of 73.58% and an F1-score of 65.51%

with the M2Gray conversion technique.

• 3C2D model has 96.29% accuracy and 96.28%

F1-score for M1Gray. These metric values are the

highest across all the methods.

Overall, the performance of the models varies for the

three different dataset classes with the 3C2D model

performing the best for all the three dataset classes,

in terms of the highest values of accuracy and F1-

score. Resnet50 gives the second best performance,

followed by MobileNetV2. It can be observed from

Table 5 that the performance of the 3C2D model in-

creases signiﬁcantly with the increase in the number

of classes and the imbalance in the classes compared

to that of Resnet50 and MobileNetV2. Thus, it can be

said that 3C2D is capable of handling class imbalance

existing in the malware dataset effectively. This is a

vital aspect of classiﬁcation performance since in the

real-world, it is not necessary that the same number

of samples will be available for all types of malware.

Moreover, it has been observed through experiments

that the simple APK to image conversion technique

M1Gray, which uses the byteplot method to convert

the entire APK ﬁle into a grayscale image without any

parsing of the individual ﬁles present in the APK, is

effective for malware classiﬁcation.

3C2D is a shallow network composed of three

convolutional layers followed by two fully connected

layers. Each convolutional layer is accompanied by a

max pooling layer, resulting in a reduced input image

size of

before entering the fully connected layers.

This allows the model to learn long-range dependen-

cies present in the embedded feature space. We are of

the opinion that this fact contributes towards the im-

proved performance of 3C2D compared to other clas-

siﬁcation models. However, the lesser degree of im-

age size reduction before the fully connected layers

SECRYPT 2023 - 20th International Conference on Security and Cryptography

868

leads to a large number of parameters being associ-

ated with the model, resulting in a larger model size

for 3C2D.

6 CONCLUSION

In this paper, we have empirically analyzed the per-

formance of image based malware detection and clas-

siﬁcation techniques. Each approach converts an

APK to either a grayscale or a color image. These

converted images are then input to CNN-based mod-

els like Resnet50, MobileNetV2, and 3C2D to distin-

guish between benign and malware samples as well

as identify the various malware families. We have

used two widely used open-source datasets, CICAnd-

Mal2017 and the Drebin dataset for our experiments.

Our experimental results show that 3C2D is capa-

ble of providing the most accurate performance for

grayscale-based techniques. Based on the observa-

tions and insights obtained from this work, in fu-

ture, we intend to design lightweight malware detec-

tion and categorization strategies suitable for resource

constrained environments like mobile devices. More-

over, we wish to explore different non-image based

features as well for malware classiﬁcation.

ACKNOWLEDGEMENT

The authors gratefully acknowledge the computing

time provided on the high performance computing fa-

cility, Sharanga, at the Birla Institute of Technology

and Science - Pilani, Hyderabad Campus.

REFERENCES

Arp, D., Spreitzenbarth, M., Hubner, M., Gascon, H., and

Rieck, K. (2014). Drebin: Effective and explain-

able detection of android malware in your pocket. In

NDSS. The Internet Society.

Conti, G., Dean, E., Sinda, M., and Sangster, B. (2008). Vi-

sual reverse engineering of binary and data ﬁles. In In-

ternational Workshop on Visualization for Computer

Security, page 1 – 17.

Fang, Y., Gao, Y., Jing, F., and Zhang, L. (2020). Android

malware familial classiﬁcation based on dex ﬁle sec-

tion features. IEEE Access, 8:10614–10627.

Gibert, D., Mateu, C., and Planes, J. (2020). Hydra: A mul-

timodal deep learning framework for malware classi-

ﬁcation. Computers & Security, 95:101873.

He, K., Zhang, X., Ren, S., and Sun, J. (2015). Deep resid-

ual learning for image recognition.

Joyce, R. J., Amlani, D., Nicholas, C., and Raff, E. (2023).

Motif: A malware reference dataset with ground truth

family labels. Computers & Security, 124:102921.

Kalash, M., Rochan, M., Mohammed, N., Bruce, N. D. B.,

Wang, Y., and Iqbal, F. (2018). Malware classiﬁcation

with deep convolutional neural networks. In 2018 9th

IFIP International Conference on New Technologies,

Mobility and Security (NTMS), pages 1–5.

Kumar, A., Sagar, K. P., Kuppusamy, K. S., and Aghila, G.

(2016). Machine learning based malware classiﬁca-

tion for android applications using multimodal image

representations. In 2016 10th International Confer-

ence on Intelligent Systems and Control (ISCO), pages

1–6.

Lashkari, A. H., Kadir, A. F. A., Taheri, L., and Ghor-

bani, A. A. (2018). Toward developing a system-

atic approach to generate benchmark android malware

datasets and classiﬁcation. In 2018 International Car-

nahan Conference on Security Technology (ICCST),

pages 1–7.

Mohammed, T. M., Nataraj, L., Chikkagoudar, S., Chan-

drasekaran, S., and Manjunath, B. (2021). Malware

detection using frequency domain-based image visu-

alization and deep learning. In Proceedings of the 54th

Hawaii International Conference on System Sciences,

page 7132.

Nataraj, L., Karthikeyan, S., Jacob, G., and Manjunath, B.

(2011). Malware images: Visualization and automatic

classiﬁcation.

Ni, S., Qian, Q., and Zhang, R. (2018). Malware identiﬁ-

cation using visualization images and deep learning.

Computers & Security, 77:871–885.

O’Shaughnessy, S. and Sheridan, S. (2022). Image-

based malware classiﬁcation hybrid framework based

on space-ﬁlling curves. Computers & Security,

116:102660.

Sandler, M., Howard, A., Zhu, M., Zhmoginov, A., and

Chen, L.-C. (2019). Mobilenetv2: Inverted residuals

and linear bottlenecks.

Spreitzenbarth, M., Freiling, F., Echtler, F., Schreck, T.,

and Hoffmann, J. (2013). Mobile-sandbox: Having a

deeper look into android applications. In Proceedings

of the 28th Annual ACM Symposium on Applied Com-

puting, SAC ’13, page 1808–1815, New York, NY,

USA. Association for Computing Machinery.

Zhang, W., Luktarhan, N., Ding, C., and Lu, B. (2021). An-

droid malware detection using tcn with bytecode im-

age. Symmetry, 13(7).

Zhu, H., Wei, H., Wang, L., Xu, Z., and Sheng, V. S.

(2023). An effective end-to-end android malware de-

tection method. Expert Systems with Applications,

218:119593.

Unver, H. and Bakour, K. (2020). Android malware de-

tection based on image-based features and machine

learning techniques. SN Applied Sciences, 2(1299).

Analyzing Image Based Strategies for Android Malware Detection and Classiﬁcation: An Empirical Exploration

869
