Labelled Vulnerability Dataset on Android Source Code (LVDAndro) to

Develop AI-Based Code Vulnerability Detection Models

Janaka Senanayake

1,2 a

, Harsha Kalutarage

1 b

, Mhd Omar Al-Kadri

3 c

, Luca Piras

4 d

and Andrei Petrovski

1 e

School of Computing, Robert Gordon University, Aberdeen, U.K.

Faculty of Science, University of Kelaniya, Kelaniya, Sri Lanka

School of Computing and Digital Technology, Birmingham City University, Birmingham, U.K.

Department of Computer Science, Middlesex University, London, U.K.

Keywords:

Android Application Security, Code Vulnerability, Labelled Dataset, Artiﬁcial Intelligence, Auto Machine

Learning.

Abstract:

Ensuring the security of Android applications is a vital and intricate aspect requiring careful consideration

during development. Unfortunately, many apps are published without sufﬁcient security measures, possibly

due to a lack of early vulnerability identiﬁcation. One possible solution is to employ machine learning models

trained on a labelled dataset, but currently, available datasets are suboptimal. This study creates a sequence

of datasets of Android source code vulnerabilities, named LVDAndro, labelled based on Common Weakness

Enumeration (CWE). Three datasets were generated through app scanning by altering the number of apps

and their sources. The LVDAndro, includes over 2,000,000 unique code samples, obtained by scanning over

15,000 apps. The AutoML technique was then applied to each dataset, as a proof of concept to evaluate

the applicability of LVDAndro, in detecting vulnerable source code using machine learning. The AutoML

model, trained on the dataset, achieved accuracy of 94% and F1-Score of 0.94 in binary classiﬁcation, and

accuracy of 94% and F1-Score of 0.93 in CWE-based multi-class classiﬁcation. The LVDAndro dataset is

publicly available, and continues to expand as more apps are scanned and added to the dataset regularly. The

LVDAndro GitHub Repository also includes the source code for dataset generation, and model training.

1 INTRODUCTION

Approximately 90,000 Android mobile apps are re-

leased through the Google Play Store monthly. In

January 2023, Android holds a 71.74% market share

(Statista, 2023; Statcounter, 2023). However, many

of these apps are developed without adhering to se-

cure coding best practices and standards, resulting in

source code vulnerabilities, which appeal to attack-

ers. In contrast to iOS, Android applications are not

thoroughly checked for security aspects (Senanayake

et al., 2021), and therefore the security of these apps

is not guaranteed, and they may fail to comply with

rigorous security protocols.

https://orcid.org/0000-0003-2278-8671

https://orcid.org/0000-0001-6430-9558

https://orcid.org/0000-0002-1146-1860

https://orcid.org/0000-0002-7530-4119

https://orcid.org/0000-0002-0987-2791

To ensure the security of apps, it is recommended

to implement secure coding practices while writing

the code, as many vulnerabilities stem from ﬂaws in

the source code. The Security Development Life-

cycle (SDL) recommends following secure develop-

ment practices in real-time, rather than waiting until

the application is developed (Souppaya et al., 2021).

To help enforce these practices, researchers have de-

veloped automated tools for identifying Android app

vulnerabilities using various scanning methods, in-

cluding conventional, Machine Learning (ML), and

Deep Learning (DL) methods (Shezan et al., 2017;

Senanayake et al., 2023). These methods utilise three

analysis approaches: static, dynamic, and hybrid.

However, many existing vulnerability detection meth-

ods require Android Application Package (APK) ﬁles

that are ready to be installed, limiting their usefulness

during development. To overcome that, it is possible

to use well-trained ML/DL models, which can detect

vulnerabilities simultaneously when the code is writ-

Senanayake, J., Kalutarage, H., Al-Kadri, M., Piras, L. and Petrovski, A.

Labelled Vulnerability Dataset on Android Source Code (LVDAndro) to Develop AI-Based Code Vulnerability Detection Models.

DOI: 10.5220/0012060400003555

In Proceedings of the 20th International Conference on Security and Cryptography (SECRYPT 2023), pages 659-666

ISBN: 978-989-758-666-8; ISSN: 2184-7711

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

659

ten. A properly labelled dataset on Android source

code vulnerability is required to train such models.

Hence, this paper makes the following contributions.

1. Producing a properly labelled novel dataset of An-

droid source code vulnerabilities named LVDAn-

dro, which offers the following characteristics:

A. LVDAndro contains more than ﬁfteen million

distinct code samples scanned from over ﬁfteen

thousand Android Apps;

B. within LVDAndro, vulnerable code examples

were labelled with Common Weakness Enu-

meration (CWE)

identiﬁcations and contain

additional attributes such as vulnerability cate-

gory, severity, and description. As a result, this

dataset is unique compared to existing ones;

C. within LVDAndro, the labelling process was

done by combining multiple vulnerability scan-

ners including Mobile Security Framework

(MobSF)

and Quick Android Review Kit

(Qark)

. Hence ML models trained with LV-

DAndro learn the capabilities of all scanners.

2. Performing binary and multi-class classiﬁcation-

related AutoML experiments as a Proof-of-

Concept (PoC) to determine the applicability of

the LVDAndro dataset for Android source code

vulnerability detection with ML. The classiﬁers

achieved:

A. accuracy of 94% and F1-Score of 0.94 in binary

classiﬁcation, which predicts vulnerable codes;

B. accuracy of 94% and F1-Score of 0.93 in multi-

class classiﬁcation, which predicts the CWE ID

of a vulnerable code.

3. Making the dataset available for public access as

a GitHub repository

, along with the dataset gen-

eration scripts and the instructions to enhance the

dataset by adding more data as needed.

The remaining sections of the paper are structured

as follows: in Section 2, prior research on the sub-

ject is reviewed, and in Section 3, the dataset gener-

ation is discussed. Section 4 outlines the attributes

and the statistics of the LVDAndro dataset, and Sec-

tion 5 examines how the LVDAndro can be used to

train ML models to identify vulnerabilities in Android

code. Section 6 provides the conclusion by discussing

the ﬁndings and future plans.

https://cwe.mitre.org/

https://github.com/MobSF/

Mobile-Security-Framework-MobSF

https://github.com/linkedin/qark/

https://github.com/softwaresec-labs/LVDAndro

2 RELATED WORK

This section discusses the related studies on code vul-

nerabilities and datasets, which can be used to detect

software vulnerabilities using ML-based methods.

Organisations and communities have identiﬁed a

number of vulnerabilities. CWE and Common Vul-

nerabilities and Exposures (CVE)

are generally used

as references for identifying weaknesses and vulner-

abilities across many programming languages. As a

result, mobile app developers can also refer to these

references to identify vulnerabilities and address se-

curity issues in their source code.

Previous research has proposed a number of

datasets and repositories focused on vulnerabilities.

For instance, AndroVul (Namrud et al., 2019) is a

repository that deals with security issues related to

Android, such as security code smells, dangerous per-

missions, and dangerous shell commands. It was cre-

ated by analysing APKs downloaded from Andro-

Zoo (Allix et al., 2016), and serves as a benchmark

for detecting Android malware. It can also be used

for ML experiments to detect malware with static

analysis. Another dataset, introduced in (Challande

et al., 2022), is a commit-level dataset for real-world

vulnerabilities, which has analysed more than 1,800

projects and over 1,900 vulnerabilities based on CVE

from the Android Open Source Project. Ghera (Mi-

tra and Ranganath, 2017), an open-source repository

of benchmarks, has captured 25 known vulnerabili-

ties in Android apps and also presented some com-

mon characteristics of vulnerability benchmarks and

repositories. Additionally, the National Vulnerabil-

ity Database (NVD)

is another dataset that can be

utilised as a reference for vulnerabilities. However,

it lacks the ability to support the development of AI-

based models because vulnerable categories for code

lines are not correctly labeled.

It is possible to create new datasets by examin-

ing Android apps for vulnerabilities. There are two

methods for analysing Android applications. The ﬁrst

approach involves reverse-engineering the developed

APKs and analysing the code. However, this method

requires a pre-built application and is not applicable

in the early stages of the SDLC (Senanayake et al.,

2022). The second approach involves analysing the

source code while it is being written. Both meth-

ods utilise static, dynamic, and hybrid analysis tech-

niques as the initial step of application scanning.

Static analysis techniques identify code issues with-

out executing the application or source code and can

be categorised into two types: manifest analysis and

https://cve.mitre.org/

https://nvd.nist.gov/vuln

SECRYPT 2023 - 20th International Conference on Security and Cryptography

660

code analysis. Manifest analysis can identify package

names, permissions, activities, services, intents, and

providers. On the other hand, code analysis provides

deeper insights into the source code by analysing

features such as API calls, information ﬂow, native

code, taint tracking, clear-text analysis, and opcodes

(Senanayake et al., 2021). Dynamic analysis, in con-

trast to static analysis, requires a runtime environment

to execute the application for scanning. This approach

is commonly used for malware detection and identi-

fying vulnerabilities in pre-built applications. Hybrid

analysis combines both static and dynamic analysis

techniques, where static analysis is used to analyse

the manifest ﬁle and source code ﬁles, and dynamic

analysis is used to analyse the application’s charac-

teristics at runtime.

Various tools are available to conduct such anal-

ysis. For instance, APKTool

can extract code-

level information by decompiling the APK using a

static analyser. This tool is widely used as the foun-

dation for vulnerability detection methods based on

static analysis that involve reverse-engineering APKs

(Senanayake et al., 2021). Qark is another tool that

can identify vulnerabilities in Android apps by exam-

ining pre-built APKs or source code ﬁles. MobSF,

on the other hand, uses a hybrid analysis model to de-

tect vulnerabilities, malware, and perform penetration

testing. It is a security framework designed for An-

droid and iOS, which offers REST API for develop-

ment integration. HornDroid (Calzavara et al., 2016)

is a tool that can analyse information ﬂow in Android

apps by abstracting their semantics to construct secu-

rity properties, while COVERT (Bagheri et al., 2015)

can perform compositional analysis of inter-app vul-

nerabilities in Android. Another tool that can be use-

ful for identifying vulnerabilities in Android source

code through static analysis is Android Lint (Goa

er,

2020), which uses Abstract Syntax Trees (AST) or

Universal AST generated from source code.

Previous research has noted that both ML-based

and non-ML-based methods can be employed to de-

tect vulnerabilities. However, in recent years, there

has been a greater tendency to use ML-based ap-

proaches over non-ML-based methods (Ghaffarian

and Shahriari, 2017). Additionally, model accu-

racy and performance can be improved by enhancing

datasets and tuning parameters through various ML

experiments. While Alloy (Bagheri et al., 2018) and

VulArcher (Qin et al., 2020) have presented non-ML-

based techniques such as formal and heuristic-based

methods, ML-based vulnerability detection methods

have been proposed in studies such as (Senanayake

et al., 2022; Gajrani et al., 2020). These studies have

https://ibotpeaches.github.io/Apktool/

employed various classiﬁers, including Decision Tree

(DT), Naive Bayes (NB), AdaBoost (AB), Random

Forest (RF), Gradient Boosting (GB), Extreme Gradi-

ent Boosting (XGB), Logistic Regression (LR), Sup-

port Vector Classiﬁer (SVC), and Multi-Layer Per-

ception (MLP) trained on labelled datasets.

The detection of source code vulnerabilities in

Android has been a challenge due to the absence of

an accurate method during code writing, as well as

a lack of appropriately labelled datasets to train ma-

chine learning (ML) models for vulnerability predic-

tion (Senanayake et al., 2023). To address this gap,

the LVDAndro dataset is introduced in this study, and

a proof of concept (PoC) is presented that uses ML

techniques to detect Android code vulnerabilities.

3 DATASET GENERATION

PROCESS

The LVDAndro dataset is a comprehensive and di-

verse collection of labelled data that is speciﬁcally de-

signed to address the challenges of detecting Android

source code vulnerabilities using ML techniques. The

dataset contains a wide range of source code samples

with varying degrees of complexity and security vul-

nerabilities. The overall process of LVDAndro dataset

generation is illustrated in Figure 1, and the genera-

tion process consists of three main stages, as follows.

1. Scrapping of APKs and corresponding source

ﬁles (Data collection).

2. Scanning APKs for vulnerabilities using exist-

ing tools to label the source code with CWE-IDs

(Data labelling).

3. Generating processed dataset (Preprocessing).

Figure 1: LVDAndro dataset generation process.

3.1 Scrapping APKs and Source Files

(Data Collection)

To generate the LVDAndro dataset, the ﬁrst step is to

scrape APKs, and their source code, from application

repositories. This includes Google Play, Fossdroid

Labelled Vulnerability Dataset on Android Source Code (LVDAndro) to Develop AI-Based Code Vulnerability Detection Models

661

(Simonin, 2023), AndroZoo (Allix et al., 2016), and

some well-known malware repositories (Senanayake

et al., 2021). Python scripts were used to download

APKs and their source code from GitHub reposito-

ries. An experiment was also carried out to investigate

whether source code from reverse-engineered APKs

could be used to generate the dataset instead of rely-

ing on the original source code. This was due to the

lack of open-source APKs and the high availability of

closed-source APKs. Figure 2 illustrates the sources

of the downloaded apps in the current version of the

dataset, which will be increased in future versions.

Figure 2: Source of downloaded apps.

3.2 Scanning APKs for Vulnerabilities

(Data Labelling)

LVDAndro was developed to leverage ML to iden-

tify source code vulnerabilities in real-time. To create

robust and effective machine learning models, a di-

verse dataset of APKs and source ﬁles was necessary.

To achieve this, various scanning methods were em-

ployed as the second step in dataset generation, which

involved scanning both the APKs and source ﬁles for

vulnerabilities. This enabled the ML models to be

trained on a comprehensive range of vulnerabilities.

The LVDAndro dataset was developed using the

code analysis approach in the static analysis method

by scanning APKs and Android project ﬁles (which

include source code and ﬁle structure). Vulnerability

scanning tools such as MobSF and Qark were used

for this purpose. During the scanning process, these

tools could identify the vulnerable lines of code and

the corresponding CWE-IDs. The idea was that by

using the resulting dataset to train machine learning

models, the models would be able to learn from the

capabilities of both scanners and perform better than

either tool alone in terms of detection. A Python script

was developed to automate the scanning process, and

all applications were scanned using this script.

To analyse an APK or Android project using

MobSF, it needs to be set up as a server, and several

API requests can be made, including upload, scan,

and download. When an APK or project is uploaded,

MobSF decompiles it using tools such as JADX,

dex2-jar, JD-GUI. The decompiled source code or

project ﬁles are then scanned for vulnerabilities. Af-

ter the scan is complete, the results are stored in a

local database, which is mapped to a generated hash

value. The results are retrieved as a JSON object and

passed to the automation Python script using the hash

value. The JSON object contains details of the upload

ﬁles, including vulnerability status, manifest analysis

details, code analysis details, and associated ﬁles. A

separate Python script is then used to extract the nec-

essary details and the source code lines of both vul-

nerable and non-vulnerable codes labelled by MobSF.

To perform analysis with Qark, it is needed to run

Qark as a shell script, because it does not offer APIs

like MobSF does. APK of the project source ﬁle di-

rectory should be passed as parameters when running

the Qark. When an APK is passed, Qark decompiles

it using tools such as Fernﬂower, Procyon, and CFR,

and then scans it to identify vulnerable lines of code.

If a ﬁle is submitted, it is directly scanned. After iden-

tifying the vulnerable code lines, a Python script la-

bels and stores them, along with a description from

the scanner, vulnerability type, and severity level.

Python scripts were created to scan APKs and

source ﬁles, utilising a uniﬁed approach that inte-

grates the functionalities of MobSF and Qark. These

scripts employ techniques for scanning and identify-

ing any potential vulnerabilities in the application or

source code, and the results are tagged with CWE IDs

to provide relevant information.

3.3 Generating Processed Dataset

(Preprocessing)

During this stage, various preprocessing steps were

carried out. First, user-deﬁned string values were re-

placed with user str, since typical user-deﬁned string

values do not make a signiﬁcant impact for vulnera-

bilities (Hanif and Maffeis, 2022). However, string

values that included IP addresses and encryption al-

gorithms like AES, SHA-1, and MD5 were not re-

placed since they may cause for vulnerabilities such

as CWE-200 and CWE-327, which involve exposing

sensitive information to unauthorised parties and us-

ing insecure cryptographic algorithms. Next, all com-

ments were replaced with //user comment since the

language compilers ignore comments. Finally, dupli-

cates were removed based on the processed code and

the vulnerability status.

SECRYPT 2023 - 20th International Conference on Security and Cryptography

662

4 RESULTING DATASET

A sequence of datasets was created when generating

the LVDAndro dataset. This section discusses the

characteristics of these resulting datasets.

4.1 Different Datasets

The LVDAndro datasets were produced by scan-

ning real-world Android applications. Dataset 01

was compiled by including all the popular open-

source APKs and their related Android projects in

FossDroid, leading to a total of 511 Apps. An-

other dataset, named Dataset 02, was composed

of 5,503 open-source APKs and their associated

projects, scanned from all the listed apps in FossDroid

across 17 different categories such as Internet, Sys-

tems, Games, and Multimedia. Furthermore, Dataset

03 was formed by scanning 15,021 APKs from Foss-

Droid, AndroVul, and Android malware repositories.

This dataset includes scanned source code from both

open-source and closed-source applications, consist-

ing of 23 different CWE ID labels. If AI models need

to be developed based on the types of apps, the three

variations of datasets can be used. However, if there

is no such requirement, Dataset 3 can be used to per-

form an extensive analysis and build more accurate

models since it contains a large number of labelled

source code examples. A summary of the LVDAndro

datasets is provided in Table 1.

After processing Dataset 01 and Dataset 02, nine

sub-datasets were created. These sub-datasets were

generated using three different scanning approaches:

MobSF scanner, Qark scanner, and the proposed com-

bined scanner, to compare their effectiveness. Within

each method, three sub-datasets were generated using

only APKs, only Android projects, and both APKs

and Android projects. Dataset 03, which was gen-

erated using only APKs and the combined approach,

produced one dataset.

Figure 3 displays the distribution of vulnerable

and non-vulnerable code samples across the datasets

in LVDAndro. Observing the data, it is evident that

the count of non-vulnerable source code samples is

generally greater than the vulnerable source code

sample count. Since the datasets were created using

actual applications, it is possible that they contain a

signiﬁcant proportion of non-vulnerable code.

4.2 Statistics of Datasets

Table 2 presents the ﬁelds included in the LVDAn-

dro dataset. While the processed code, vulnerability

status, and CWE-IDs are necessary for detecting vul-

Figure 3: Vulnerable and non-vulnerable code samples dis-

tribution in each dataset (in APK Combined Approach).

nerabilities, other ﬁelds can also provide additional

information for prediction.

Table 3 classiﬁes the CWE-IDs based on their

likelihood of exploitation, and Figure 4 shows the

distribution of CWE-IDs in LVDAndro Dataset 03.

CWE-532 has a large number of code examples, as

it is common to write information to log ﬁles for de-

bugging purposes. However, these logs may also con-

tain sensitive information, which can be accidentally

written by the developer. CWE-312 also has a signif-

icant number of code examples, as many developers

tend to write sensitive information in cleartext. Most

of the other CWE categories have an even distribution

of code examples, whereas categories like CWE-299,

CWE-502, and CWE-599 have fewer examples due

to their complexity and difﬁculty in ﬁnding relevant

instances in the context of Android source code.

Figure 4: CWE-ID distribution in dataset 03.

Figure 5 depicts the distribution of CWE-IDs in

Dataset 03 based on their CWE likelihood of exploita-

tion values. As the dataset consists of 95% vulnerable

code examples for both high and medium exploitable

CWE-IDs, it is expected to be highly effective in de-

tecting vulnerabilities.

5 DATASET USAGE

This section outlines the proof-of-concept concerning

utilising LVDAndro to train machine learning models,

Labelled Vulnerability Dataset on Android Source Code (LVDAndro) to Develop AI-Based Code Vulnerability Detection Models

663

Table 1: Summary of the LVDAndro datasets.

Dataset Created

Date

No. of Code

Samples

No. of

Vulnerable

Codes

No. of Non

Vulnerable

Codes

Vul : Non-

vul Ratio

No. of

CWE-IDs

Description

Created using 511 open-source apps.

Dataset

Mar-2022 1,020,134 765,101 255,034 1:3 22 9 sub-datasets - scanned with MobSF, Qark

and Combined scanners (3 by scanning only

APKs, 3 by scanning only source ﬁles, 3 by

scanning both APKs and source ﬁles).

Created using 5,503 open-source apps.

Dataset

Jun-2022 14,228,925 10,529,405 3,699,521 7:9 23 9 sub-datasets - scanned with MobSF, Qark

and Combined scanners (3 by scanning only

APKs, 3 by scanning only source ﬁles, 3 by

scanning both APKs and source ﬁles).

Created using 15,021 apps.

Dataset

Dec-2022 21,289,029 14,689,432 6,599,597 9:11 23 1 dataset - scanned with combined scanner us-

ing both open-source and closed-source apps

from various sources

Table 2: Fields in LVDAndro.

Field Name Description

Index Auto-generated identiﬁer

Code Original source code line

Pprocessed code Source code line after preprocessing

Vulnerability status Vulnerable(1) or Non-vulnerable(0)

Category Category of the vulnerability

Severity Severity of the vulnerability

Type Type of the vulnerability

Pattern Pattern of the vulnerable code

Description Description of the vulnerability

CWE ID CWE-ID of the vulnerability

CWE Desc Description of the vulnerable class

CVSS Common vulnerability scoring system

OWSAP Mobile Open web application security project for

mobile apps details

OWSAP MASVS OWASP Mobile application security veri-

ﬁcation standard

Reference CWE reference URL for the vulnerability

Figure 5: CWE distribution based on the likelihood of ex-

ploit.

for detecting vulnerabilities in Android source code.

It shows that by training AutoML model on the LV-

DAndro dataset, it is possible to accurately detect and

classify different types of vulnerabilities in Android

source code.

Table 3: Available CWE-IDs in LVDAndro.

CWE ID Likelihood

of Exploit

CWE Description

CWE-79 High Improper Neutralisation of Input During

Web Page Generation (’Cross-site Script-

ing’)

CWE-89 High Improper Neutralisation of Special Ele-

ments used in an SQL Command (’SQL In-

jection’)

CWE-200 High Exposure of Sensitive Information to an

Unauthorised Actor

CWE-250 Medium Execution with Unnecessary Privileges

CWE-276 Medium Incorrect Default Permissions

CWE-295 High Improper Certiﬁcate Validation

CWE-297 High Improper Validation of Certiﬁcate with

Host Mismatch

CWE-299 Medium Improper Check for Certiﬁcate Revocation

CWE-312 Medium Cleartext Storage of Sensitive Information

CWE-327 High Use of a Broken or Risky Cryptographic

Algorithm

CWE-330 High Use of Insufﬁciently Random Values

CWE-502 Medium Deserialisation of Untrusted Data

CWE-532 Medium Insertion of Sensitive Information into Log

File

CWE-599 High Missing Validation of OpenSSL Certiﬁcate

CWE-649 High Reliance on Obfuscation or Encryption of

Security-Relevant Inputs without Integrity

Checking

CWE-676 High Use of Potentially Dangerous Function

CWE-749 Low Exposed Dangerous Method or Function

CWE-919 Medium Weaknesses in Mobile Applications

CWE-921 Medium Storage of Sensitive Data in a Mechanism

without Access Control

CWE-925 Medium Improper Veriﬁcation of Intent by Broad-

cast Receiver

CWE-926 High Improper Export of Android Application

Components

CWE-927 High Use of Implicit Intent for Sensitive Com-

munication

CWE-939 High Improper Authorisation in Handler for

Custom URL Scheme

SECRYPT 2023 - 20th International Conference on Security and Cryptography

664

5.1 Training AutoML Models

In this section, the performance of AutoML models

trained on LVDAndro datasets for detecting vulnera-

ble code lines (binary classiﬁcation), and for detecting

CWE-IDs (multi-class classiﬁcation), are compared.

To handle the data imbalance issue, the data were re-

sampled, and the dataset was split into an 80:20 ratio

for training and testing. The resulting performance

metrics are presented in Table 4 and Table 5 for bi-

nary and multi-class classiﬁcation, respectively, and

are categorised by dataset.

Table 4: Performance comparison of AutoML models in

binary classiﬁcation.

Sub dataset Name Binary Classiﬁcation

Accuracy F1-Score Top Classiﬁer

Dataset 01

APKs Qark 91% 0.90 RF

Source Qark 91% 0.90 RF

All Qark 91% 0.90 MLP

APKs MobSF 91% 0.90 RF

Source MobSF 91% 0.90 SVC

All MobSF 91% 0.90 MLP

APKs Combined 92% 0.91 MLP

Source Combined 92% 0.90 MLP

All Combined 92% 0.90 MLP

Dataset 02

APKs Combined 93% 0.92 RF

Source Combined 93% 0.91 RF

All Combined 93% 0.91 RF

Dataset 03

APKs Combined 94% 0.94 RF

According to Table 4 and Table 5, it can be ob-

served that the combined approach yielded better re-

sults when using APKs, source ﬁles, and both for

models in Dataset 01. As a result, only the com-

bined approach was used to train AutoML models in

Dataset 02. When training with Dataset 02, it was

discovered that the APKs combined approach outper-

formed the other source combined and all combined

Table 5: Performance comparison of AutoML models in

multi-class classiﬁcation.

Sub dataset Name Multi-class Classiﬁcation

Accuracy F1-Score Top Classiﬁer

Dataset 01

APKs Qark 91% 0.82 RF

Source Qark 91% 0.81 RF

All Qark 91% 0.81 RF

APKs MobSF 91% 0.84 RF

Source MobSF 91% 0.83 RF

All MobSF 91% 0.83 RF

APKs Combined 92% 0.88 RF

Source Combined 92% 0.84 RF

All Combined 92% 0.86 RF

Dataset 02

APKs Combined 93% 0.91 RF

Source Combined 93% 0.85 RF

All Combined 93% 0.87 RF

Dataset 03

APKs Combined 94% 0.93 MLP

approaches. Therefore, only APKs were used for

scanning in Dataset 03. Furthermore, using multiple

sources to download APKs could potentially reduce

bias and impact the overall performance. Increasing

the dataset size resulted in a continuous improvement

in F1-Scores for both binary and multi-class classi-

ﬁcations. Minimising false positives and false nega-

tives is crucial to enhance the efﬁciency of any ML-

based solution, with minimising false negatives being

more critical in this problem. To accomplish this, sev-

eral measures, such as improving data quality during

preprocessing and training, were taken to reduce both

types of false alarms.

5.2 AutoML Model Comparison

An API was developed to detect vulnerable code

lines, and the associated CWE-ID using an AutoML

model trained on LVDAndro dataset. The API re-

quires source code lines as input, and in this experi-

ment, it was tested on a set of 3,312 source code lines

(unseen data) comprising both vulnerable examples

from the CWE repository and non-vulnerable exam-

ples from real applications. Subsequently, an APK

was created by incorporating the same set of 3,312

source code lines, and the APK was scanned using

MobSF and Qark Scanners. The accuracies of the

three approaches are reported in Table 6.

Table 6: Accuracy comparison of proposed ML model with

MobSF and Qark.

Approach Accuracy

MobSF 91%

Qark 89%

Proposed Approach 94%

The detection techniques of MobSF and Qark rely

on signatures, which are known for producing a high

number of false negatives, while maintaining accu-

racy in terms of true positives. To overcome this

limitation, the proposed ML-based technique trained

on LVDAndro can be applied, as it has learned from

the strengths of both scanners to make it more ro-

bust. With an accuracy of 94%, the proposed ML

model could accurately predict the vulnerability as-

sociated with tested code. This test was performed

using unseen source code, demonstrating that the

proposed method can detect vulnerabilities in new

APKs with high accuracy, conﬁrming the hypothe-

sis (PoC). By incorporating additional scanners into

the pipeline and expanding the dataset with regular

updates that include data related to novel vulnerabil-

ities, the proposed method’s accuracy can be further

improved. Additionally, the size and quality of the

labelled dataset can also be increased.

Labelled Vulnerability Dataset on Android Source Code (LVDAndro) to Develop AI-Based Code Vulnerability Detection Models

665

6 CONCLUSION AND FUTURE

WORKS

When developing Android mobile applications, it is

essential to adopt security-focused practices, from

early stages, during the overall development cycle,

and it is important to receive valuable automated tool

support. One way to support app developers, in

identifying source code vulnerabilities, is by apply-

ing AI methods. This study presents a dataset called

LVDAndro, which contains over 20 million distinct

source code samples, labelled based on CWE-IDs, for

identifying Android source code vulnerabilities. The

dataset can be used to train machine learning mod-

els to predict vulnerabilities, achieving 94% accuracy

in binary and multi-class classiﬁcation, with 0.94 and

0.93 F1-Scores, respectively. The dataset is available

on GitHub and ongoing efforts are underway to ex-

pand it and increase sample sizes for deeper learning

models. The addition of more scanners can further

increase the model’s accuracy. Adopting security-

focused practices and receiving automated tool sup-

port is important for developing secure Android apps.

REFERENCES

Allix, K., Bissyand

e, T. F., Klein, J., and Le Traon, Y.

(2016). Androzoo: Collecting millions of android

apps for the research community. In Proceedings of

the 13th International Conference on Mining Software

Repositories, MSR ’16, page 468–471, New York,

NY, USA. ACM.

Bagheri, H., Kang, E., Malek, S., and Jackson, D. (2018). A

formal approach for detection of security ﬂaws in the

android permission system. Formal Aspects of Com-

puting, 30(5):525–544.

Bagheri, H., Sadeghi, A., Garcia, J., and Malek, S. (2015).

Covert: Compositional analysis of android inter-app

permission leakage. IEEE transactions on Software

Engineering, 41(9):866–886.

Calzavara, S., Grishchenko, I., and Maffei, M. (2016).

Horndroid: Practical and sound static analysis of an-

droid applications by smt solving. In 2016 IEEE Euro-

pean Symposium on Security and Privacy (EuroS&P),

pages 47–62, Saarbruecken, Germany. IEEE.

Challande, A., David, R., and Renault, G. (2022). Build-

ing a commit-level dataset of real-world vulnerabili-

ties. In Proceedings of the Twelfth ACM Conference

on Data and Application Security and Privacy, CO-

DASPY ’22, page 101–106, New York, USA. ACM.

Gajrani, J., Tripathi, M., Laxmi, V., Somani, G., Zemmari,

A., and Gaur, M. S. (2020). Vulvet: Vetting of vulner-

abilities in android apps to thwart exploitation. Digital

Threats: Research and Practice, 1(2):1–25.

Ghaffarian, S. M. and Shahriari, H. R. (2017). Software

vulnerability analysis and discovery using machine-

learning and data-mining techniques: A survey. ACM

Comput. Surv., 50(4).

Goa

er, O. L. (2020). Enforcing green code with android

lint. In Proceedings of the 35th IEEE/ACM Interna-

tional Conference on Automated Software Engineer-

ing Workshops, ASE ’20, page 85–90, New York, NY,

USA. ACM.

Hanif, H. and Maffeis, S. (2022). Vulberta: Simpliﬁed

source code pre-training for vulnerability detection. In

2022 International Joint Conference on Neural Net-

works (IJCNN), pages 1–8.

Mitra, J. and Ranganath, V.-P. (2017). Ghera: A repository

of android app vulnerability benchmarks. In Proceed-

ings of the 13th International Conference on Predic-

tive Models and Data Analytics in Software Engineer-

ing, PROMISE, page 43–52, New York, NY, USA.

ACM.

Namrud, Z., Kpodjedo, S., and Talhi, C. (2019). Androvul:

A repository for android security vulnerabilities. In

Proceedings of the 29th Annual International Confer-

ence on Computer Science and Software Engineering,

CASCON ’19, page 64–71, USA. IBM Corp.

Qin, J., Zhang, H., Guo, J., Wang, S., Wen, Q., and Shi,

Y. (2020). Vulnerability detection on android apps–

inspired by case study on vulnerability related with

web functions. IEEE Access, 8:106437–106451.

Senanayake, J., Kalutarage, H., and Al-Kadri, M. O.

(2021). Android mobile malware detection using ma-

chine learning: A systematic review. Electronics,

10(13):1606.

Senanayake, J., Kalutarage, H., Al-Kadri, M. O., Petrovski,

A., and Piras, L. (2022). Developing secured android

applications by mitigating code vulnerabilities with

machine learning. In Proceedings of the 2022 ACM

on Asia Conference on Computer and Communica-

tions Security, ASIA CCS ’22, page 1255–1257, New

York, NY, USA. ACM.

Senanayake, J., Kalutarage, H., Al-Kadri, M. O., Petrovski,

A., and Piras, L. (2023). Android source code vulner-

ability detection: A systematic literature review. ACM

Comput. Surv., 55(9).

Shezan, F. H., Afroze, S. F., and Iqbal, A. (2017). Vulner-

ability detection in recent android apps: An empiri-

cal study. In 2017 International Conference on Net-

working, Systems and Security (NSysS), pages 55–63,

Dhaka, Bangladesh. IEEE.

Simonin, D. (2023). Fossdroid. https://fossdroid.com/. Ac-

cessed: 2023-01-02.

Souppaya, M., Scarfone, K., and Dodson, D. (2021). Secure

software development framework: Mitigating the risk

of software vulnerabilities. Technical report, NIST.

Statcounter (2023). Mobile operating system mar-

ket share worldwide. https://gs.statcounter.com/

os-market-share/mobile/worldwide/. Accessed:

2023-01-02.

Statista (2023). Average number of new an-

droid app releases via google play per month.

https://www.statista.com/statistics/1020956/

android-app-releases-worldwide/. Accessed:

2023-02-02.

SECRYPT 2023 - 20th International Conference on Security and Cryptography

666
