Design and Evaluation of Computational Thinking Tasks in the

<colette/> Project: Experiences Gained from Workshops with

Secondary and Grammar School Students in Austria, the

Netherlands, and Slovakia

Eva Schmidthaler

, Sylvia van Borkulo

, Martin Cápay

, Bjarnheiður Kristinsdóttir

Rebecca S. Stäter

, Tim Läufer

, Matthias Ludwig

, David Hornsby

, Jakob Skogø

and Zsolt Lavicza

School of Education/STEM Didactics, Johannes Kepler, University, Altenbergerstraße 69, Linz, Austria

Freudenthal Institute, Utrecht University, Princetonplein 5, Utrecht, The Netherlands

Department of Informatics, Constantine the Philosopher University in Nitra, Tr. A. Hlinku 1, Nitra, Slovakia

School of Education, University of Iceland, Stakkahlíð 105, Reykjavík, Iceland

Institute of Mathematics and Computer Science Education, Goethe University Frankfurt,

Robert-Mayer-Str. 6-8, Frankfurt (Main), Germany

Keywords: Computational Thinking, Augmented Reality, Block-Based Programming, Mobile Educational Application,

mAR, STEM Education.

Abstract: In recent years, numerous applications (apps) for mobile devices have been developed for STEM education,

but there is a lack of suitable educational apps that support teachers in promoting computational thinking (CT)

in mathematics and computer science (CS) lessons. In this position paper, two types of CT tasks, Building

Cubes and Draw-o-Bot, of the newly developed <colette/> app with augmented reality (AR) function, are

described, and preliminary results from four workshops that were held in total with 76 10-18-year-old

secondary and grammar school students in Austria (W1), the Netherlands (W2), and Slovakia (W3) are

discussed. The tasks and the mobile app itself were created as part of the <colette/>-project, an Erasmus+

project, in which seven institutions from five European countries are involved. Each type of task includes a

set of CT tasks related to the block-based programming (BBP) app. In the workshops, we set out to explore

how the participating secondary school students solved the CT tasks, whilst using <colette/>. The experiences

made in the workshops will be used to inform the further development of the application, and to prepare

teacher training to support the successful implementation of <colette/> as an educational tool in schools. The

first findings indicate that the participating students react positively to the app, can solve BBP tasks

successfully, and create loops to shorten their code. In the future, further task types will be implemented in

the app and researched.

1 INTRODUCTION

Recently, curricula in many European countries call

for the integration of computational thinking (CT)

skills into STEM subjects in compulsory education

(Bocconi et al., 2022). STEM teachers and students

can find a variety of mobile and web-based

educational applications (learning apps) freely

available on the Internet or in app stores, especially

for mathematics education. However, they will not

find many apps that combine mathematical topics and

CT, and both the development of such apps and the

research on them are still lacking in secondary school

(Lv et al., 2022). In the context of this paper, six core

CT skills can be identified: ‘abstraction, algorithmic

thinking, automation, decomposition, debugging, and

generalization’ (Bocconi et al., 2016, p.7). Each of the

introduced task types, currently mainly tasks that

implement block-based programming, addresses core

CT skills differently or directly (Csizmadia et al.,

2015; Bocconi et al., 2016). As a first step, apps with

visual block-based programming (BBP) languages

are introduced to novice students by their Computer

Science (CS) or STEM teachers. BBP tools, based on

Google Blockly (Blockly, 2022; Blockly Games,

2022), such as Scratch (Scratch, 2022), or Alice

Schmidthaler, E., van Borkulo, S., Cápay, M., Kristinsdóttir, B., Stäter, R., Läufer, T., Ludwig, M., Hornsby, D., Skogø, J. and Lavicza, Z.

Design and Evaluation of Computational Thinking Tasks in the <colette/> Project: Experiences Gained from Workshops with Secondary and Grammar School Students in Austria, the

Netherlands, and Slovakia.

DOI: 10.5220/0011974700003470

In Proceedings of the 15th International Conference on Computer Supported Education (CSEDU 2023) - Volume 1, pages 297-304

ISBN: 978-989-758-641-5; ISSN: 2184-5026

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

297

(Alice, 2020), allow novice students from an early

age to build things, test, experiment, and tinker with

CT topics. Furthermore, they assist in changing the

way students are learning and problem-solving

(Yamashita et al., 2017; Shih, 2017; Xu et al., 2019).

In this paper, two types of tasks from the new visual

programming app, <colette/> are introduced

(‘Computational Thinking Learning Environment for

Teachers in Europe’) (Colette-project, 2022; Milicic

et. al, 2021). The <colette/> project consists of seven

European partner institutions coming from five

different countries: Austria, Germany, the

Netherlands, Slovakia, and France. The main scope

of the project is to implement the ‘bring-your-own-

device’ approach to teach CT in pre-existing school

subjects, such as mathematics and CS, and moreover,

to train teachers to do so. The project outcomes range

from an authoring tool for teachers (the web portal)

to a mobile app with augmented reality (AR)

function, intended for students to work on the CT

tasks. In the mobile app, students can work on the

given tasks, see hints, and get their solutions checked

automatically; furthermore, they can view their self-

coded structures (Fig.1). Throughout the employment

of mobile devices (e.g., tablets, smartphones) and an

AR-marker (Fig.1), students can see their coded

figure embedded into reality. This feature gives the

possibility to interact with the figure, i.e. the students

can observe their objects from any perspective. By

using BBP, the students can solve mathematical and

CS tasks without any text-based codes. The proposed

block-based programming language of <colette/> has

many advantages, which have already been examined

and discussed in several studies. Many factors

contribute to making BBP easy, including the natural

language description of blocks and drag-and-drop

composition interactions (Weintrop & Wilensky,

2015). Furthermore, it is beneficial that the difficulty

in understanding and memorizing a particular order

of the BBP commands by novice students is

decreased. Thus, further (syntax) errors in students’

codes are reduced, and the learning curve gets more

gradual. Another advantage is that teachers can save

time when correcting students’ errors (Yamashita

et.al., 2017; Shih, 2017; Xu et. al., 2019).

With Blockly, students can drag-and-drop

programming blocks from a predefined range onto the

<colette/> app canvas (checkerboard), and further

connect the visual programming blocks with each

other. Moreover, they can be modified with input

parameters (e.g., coordinates) to adjust the desired

programming object (e.g., gate, pyramid, movement

of a robot) (Xu et al., 2019; Blockly, 2022; Blockly

Games, 2022). According to Lin and Weintrop

(2021), many BBP environments have been

developed, examined, and published but aren't yet

publicly accessible. Within the <colette/> project,

three different types of BBP CT tasks are already

implemented in the app, and five are in preparation.

In this paper workshops and findings with two of the

implemented ones, Building Cubes and Draw-o-Bot

are presented.

Figure 1: Student BBP solution of a task (left). To view the

result, the student must point their camera toward the

marker (center) for viewing the result in AR (right).

1.1 Building Cubes and Draw-o-Bot

Building Cubes encompasses a set of tasks that ask

students to build a certain structure in a coordinate

system. As previously mentioned, it makes use of

BBP (Blockly, 2022; Blockly Games, 2022). This

code is used to place unit cubes on a checkerboard

using x, y, and z coordinates. When the code is

executed, the resulting structure made of unit cubes is

shown in AR using the device's camera and a given

marker (Fig.1). The tasks invite students to work on

algorithmic thinking (AT); debug, decompose

problems, and think about coding principles, such as

making code efficient, testing, and creating general

solutions. Simple coding blocks to create one cube at

a specific location are provided along with more

advanced programming structures, such as loops and

conditional statements. The concepts involved in the

Building Cubes tasks were the coordinate system in

three dimensions, and spatial orientation and

visualization as part of spatial skills (McGee, 1979).

The second task type Draw-o-Bot includes a set of

CT tasks that ask students to program a virtual robot

to draw a certain pre-described pattern. Like Building

Cubes, BBP is used to create commands for the robot,

therefore the same already mentioned CT skills are

targeted. The difference between these two task types

is that no AR function is provided. Instead, when the

code is executed, the resulting ‘command’ is shown

on the screen of the user’s device. The utilization of

educational robots (ER) is becoming more common

in schools nowadays because ER have the

opportunity to encourage the usage of new

technologies (Benitti, 2012; González et al., 2019;

Pou et al., 2022). Within Draw-o-Bot, the students

CSEDU 2023 - 15th International Conference on Computer Supported Education

298

must program a virtual ER. The following commands

can be set: ‘set the color (of the pen) up/down’, ‘move

x step(s) forward’, and ‘turn 90 degrees left/right’.

With these commands, the students can program the

robot, for example, to draw a street sign pattern on a

piece of paper (Fig.2). In the future, an addition is

planned where an ER will draw the shape of the

desired object virtually and drawing angles of the

desired size (currently only 90°) will be possible.

2 METHODOLOGY

The <colette/> app is still in its development stage,

and only three out of eight planned task types are

implemented yet. Therefore, the already implemented

task types and designed exercises must be tested, to

be able to successfully introduce and implement the

app as an educational tool in European schools. In the

following, after the purpose of this study has been

presented, the individual workshops, their procedure,

and the data collection and processing are discussed.

Afterward, the findings, broken down by country, are

described.

2.1 Research Aim & Experimental

Design

In an aim to test Building Cubes and Draw-o-Bot, and

present the experiences gained from the test

workshops, four lectures, based on discovery learning

methodology (de Jong & van Joolingen, 1998) were

held in Austria (W1), the Netherlands (2xW2), and

Slovakia (W3). Stratified sampling, with 76 10-18-

year-old secondary and grammar school students in

total, was used. The students were observed based on

the participant observation methodology (Musante &

DeWalt, 2010). The instructors documented the

students’ progress and their final task solutions during

and after the observation. At the end of each

workshop, the students were asked to answer an app

evaluation questionnaire (15min) to evaluate

<colette/> regarding their perception of CT and the

tasks in W1 (four open-ended questions), and its app

design in W2-3 (ten Likert scale and three open-

ended questions based on the Technology Acceptance

Model) (Davis, 1985).

The final student codes were evaluated manually,

quantitative data was analyzed using descriptive

statistics, and qualitative data were evaluated using

descriptive statistics (Vetter, 2017); Qualitative data

(e.g., participants’ perceptions of <colette/>) were

processed and shown as a summary content analysis

(Mayring, 2010).

2.2 Workshop Austria (W1)

In W1, held at the Johannes Kepler University (JKU)

in Linz, Austria, three Draw-o-Bot exercises were

tested. W1 (100min) began with a short introduction

to CT. After this, students received a link to a

<colette/> test environment for the tasks, a

worksheet, and a short explanation of block-based

programming. Afterward, the students had time to

work on the tasks and experiment with the test

environment. The tasks tested were designed by the

authors and intended to gradually familiarise students

with BBP. The students, paired into groups within all

exercises, had to program a code for the commands,

so the robot drew a square (Task 1), a traffic sign

(Task 2), and the first letter of the student’s name

(Task 3). Once the code was done, one group member

took the role of the ‘Instructor’, who read out loud the

commands shown on the screen of the mobile device.

Another group member took the role of the ‘Robot’,

using a pen to draw according to the instructor's

guidance on a piece of paper, checking if the desired

object (e.g., a road sign) would appear. All

participants had the opportunity to revise their codes

at any time. After the first task, students swapped

roles. Further, students were encouraged to find a way

to shorten their code, e.g., using loops. After the

coding exercise, the students had to answer the

questionnaire (15min):

(1) What is ‘CT’ to you?

(2) Did you like/dislike the tasks?

(3) Did you have any issues with the app during

your tasks?

(4) Which CT aspects are included in the tasks?

2.2.1 Sample & Data Processing (W1)

Nine students, aged 10–13 years, participated in W1

(female=1; male=8). The students were all part of a

course for gifted students (COOL Lab Talents Club,

2022), meaning that they had all shown an increased

aptitude for learning and understanding new

concepts. Three male students that had been to

previous Scratch workshops already had a reasonable

understanding of BBP, as well as loops. The students

split themselves independently into three groups of

two, and one group of three. The group of three had

two students with prior knowledge of coding, leaving

the last of the three students with prior knowledge in

a two-person group. The remaining groups had no

members with prior knowledge of coding. For data

collection, screenshots of final codes on the students’

devices, and the drawn objects on the paper at the end

of W1 were collected. The authors analyzed the

Design and Evaluation of Computational Thinking Tasks in the <colette/> Project: Experiences Gained from Workshops with Secondary

and Grammar School Students in Austria, the Netherlands, and Slovakia

299

pictures and codes after W1. Furthermore, the

answers to the questionnaire were collected and

processed using an Excel Sheet.

2.3 Workshops Netherlands (W2)

Two workshops were organized by Utrecht

University (UU) in the Netherlands in different

settings, to test four Building Cubes tasks, developed

and designed for <colette/> by the authors. The first

setting (120min) was an online session with the theme

‘Architect in the virtual world’. The second setting

(75min) was an on-site workshop at Utrecht

University. In both workshops, the students were first

introduced to the topic and BBP app and then worked

either alone or in pairs (30–60min). The tasks

gradually introduced the app and its components. For

the BBP activity, the mobile app was used. The app

provided both simple and straightforward

programming blocks to create single-unit cubes at

selected coordinates on a checkerboard and more

advanced repeat blocks and variables. This way,

students could create structures (e.g., buildings) made

from unit cubes. To see and check their results, the

students pointed their devices’ cameras to an AR

marker to view the cube building in ARand turn it

around (Fig.1). After the programming exercise, the

students filled in a questionnaire (15min) about their

perception of the tool based on the Technology

Acceptance Model (Davis, 1985):

(1) It was easy to understand the instructions.

(2) It took a long time to learn to use the app.

(3) The app is difficult to use.

(4) The app is clear.

(5) The app is fun to use.

(6) The app easily does what I want.

(7) I would like to use the app in school.

(8) I would like to use the app outside of school.

(9) The app has apparent faults. If so, please

explain why.

(10) Did you have experience with programming

before this workshop? If yes, describe your

experience.

(11) Do you have tips/tops for us?

2.3.1 Sample & Data Processing (W2)

In the online workshop, a group of 27 girls, aged 13–

14 years, participated. From this group, nine girls and

their parents consented in participating in the

research. In the on-site workshop a group of 26 girls,

aged 14–15 years, participated, 15 of whom filled in

the questionnaire. Both groups (W2) were part of a

program for girls with a special interest in STEM topics

in the Utrecht region in the Netherlands. Many of the

students had prior experience with programming. The

collected data were the responses to the questionnaire

from 24 students about their perception of the app. For

33 students, the logged data of the app was used to

analyze the successful tasks’ completions.

2.4 Workshop Slovakia (W3)

W3 was held at Constantine the Philosopher

University in Nitra, Slovakia, during the ordinary

informatics lectures at grammar school Gymnázium

Golianova 68 in Nitra. The students were supervised

by one instructor in the same four tasks used in W2

(Building Cubes). During the lesson (Duration=45

min), students were divided into groups, given tablet

PC and QR codes linking to the given task, and

explained the AR environment and marker. A follow-

up exercise involved students experimenting with the

<colette/> environment.

2.4.1 Sample & Data Processing (W3)

In W3, 32 grammar school students, aged 14–18

years (female=27; male=5), participated. Most

students worked in pairs; the rest worked alone. 88%

had previous experience with coding mostly in text-

based languages (e.g., Python and Scratch); and two

students had experience with C# and C++. Three

participants had no prior knowledge, even though

programming is mandatory in Slovakia. The students

completed the same questionnaire and tasks as in W2.

Some students were required to fill out the

questionnaires after the class due to lack of time.

Therefore, only 25 answers (female=20; male=5)

were collected.

3 RESULTS

3.1 Results Workshop Austria (W1)

While some groups used the ‘cardinal’ up, down, left,

and right blocks to create the square in the first task,

others immediately utilized the ‘turn-and-walk’

approach, with one group using the loop functions.

This approach of using 90-degree turns was later

spoken about by the students as being the better

solution. According to the participants, this approach

was helpful as it led them to use loops ‘easier’ or in a

‘faster’ way. It is worth noting that some discussions

arose among the students using the ‘go left’ and ‘go

right’-blocks, as it was not clear to them if the robot

was turning or walking sideways. In the second task

CSEDU 2023 - 15th International Conference on Computer Supported Education

300

(Fig. 2) of drawing the pattern of a pharmacy road

sign, all groups used the ‘turn-and-walk’-approach,

and all groups tried to solve the task using loops from

the beginning. Only after failing repeatedly and being

told to try and do only one part of the drawing by the

instructors, did a group try to solve the task without

using loops. Instructors did not notice a major

difference between students who had previous BBP

knowledge and those who did not. Only one group

had time to start working on the third task of drawing

the first letter of their name. However, this group did

not have time to refine their code and receive

satisfying results. In their first attempts, they tested

out using a loop within another loop. After a final

group discussion, it was clear to all students that

shortening the code was practical/helpful, and even

though other solutions were possible, the students

independently viewed the solutions that used loops as

being more ‘correct’ than others, without any

additional help from the instructors. All students

successfully completed the first two tasks.

Unfortunately, no app log data (e.g., number of trials

per task) was available. In participants’ answers (n=9)

to the questionnaire, the majority of the students

explained that to them, CT is to ‘think like a robot and

follow commands’. During W1, it appeared to

instructors that the participants had no major

problems with the test environment of the <colette/>

app and task design. In response to the question of

whether there were any issues, and whether they liked

the tasks, all students stated that they had ‘no issues’,

and ‘liked the tasks’. One group stated that they

thought that the ‘exercise was very interesting’. Some

students noted that they found the questionnaire itself,

and the mix of German and English languages in the

app and on the worksheets ‘a little bit annoying’.

Figure 2: Example Solution of the Task ‘Draw a Road Sign’

from Austrian Students in W1 (n=9).

3.2 Results Workshops Netherlands

(W2)

Overall, most of the girls managed to use BBP to

create the target building and complete the exercises.

Furthermore, from the app log data, it appeared that

19 of 33 students (57.6%) used the more advanced

programming count block in one or more of their

solutions and that 12 used it successfully (Table 1).

During the sessions, it appeared that the assignments

worked differently for the different age groups. The

concept of a variable seemed to be a difficult concept

for the younger students. Although they succeeded in

solving the tasks, they tended to avoid using the

repeat block and variables, even if it would give a

more efficient solution. The 14–15-year-olds picked

up the concept of variables more easily. BBP

concepts (e.g., repeat block and variables) were used

more often and with greater success by the older ones.

When learning and using BBP concepts and

coordinate parameters, the students seemed to profit

from the instant feedback given by the AR

visualization, as it made the meaning of the code. For

example, one student discovered how entering the

coordinate parameters in the programming block led

to placing the cube at the desired location. BBP with

the parameters for each coordinate was at first an

abstract concept with numbers and after seeing the

result in AR, students made the link between the

numbers in the programming block indicating the

coordinates and the location of the cube in space.

From the questionnaire data (n=24) and observations,

it appeared that almost half of the students agreed or

strongly agreed that the app is fun to use (46%), and

the tasks’ instructions were simple to understand

(46%). Further, the app was easy to learn (65%), not

difficult to use (65%), clear (46%), and worked the

way the students wanted it to (38%). 35% would like

to continue using the application at school, and 27%

would use it outside of school. It was not always clear

to the participants how to utilize <colette/> to perform

the task. According to the questionnaire, students

were asked if the app had any clear faults and, if so,

what faults: Students mentioned that users could

easily lose their code, ‘if you reload your phone, the

code is gone’; it was unclear how the count block

worked; problems with using variables ‘sometimes

some variables didn’t work’. In most cases, the

technology worked well, but on a few phones, the AR

view didn't work properly, so students used laptops

with webcams or collaborated with another student on

a working phone. The small size of a smartphone

screen was sometimes experienced as too limiting. In

W2 the time was a bit short for younger students but

sufficient for the older ones.

Table 1: Successful Completion of Tasks (in%) and

Number of Trials per Task of the Students W2 (n=33).

Tasks

Successful

completion (%)

Participating

students (f)

The average number

of trials (SD)

Task 1 53.3% 30 2.33 (1.94)

Task 2 75% 20 3.33 (2.69)

Task 3 71.4% 14 5.36 (6.00)

Task 4 n.a. (free mode) 9 5.67 (2.55)

Design and Evaluation of Computational Thinking Tasks in the <colette/> Project: Experiences Gained from Workshops with Secondary

and Grammar School Students in Austria, the Netherlands, and Slovakia

301

3.2 Results Workshop Slovakia (W3)

According to the instructor, 75% of the students were

able to finish all three tasks, and six students or

student pairs were able to continue their work to

create their own structures (e.g., heart, tree, fish,

sandwiches, buildings with elevators and a model of

the Slovak Radio Building), as shown in Fig.3.

The biggest problem was a technical issue: the

<colette/> test environment refused to run the AR

mode. After changing the tablets to tablet PCs, the

issue was resolved, and the students could easily

employ the <colette/> environment. The most

common problem that students encountered was

putting the correct positioning of the variable as an

argument in a loop (e.g., coordinates in the correct

place of the BBP). Instead of using a loop, some

students happily used a simple sequence of blocks.

Their argument was that the output building was the

same as the desired one. In some cases, students

found it challenging to debug hidden argument

mistakes when more overlapping blocks were placed

in the same position. The instructor noted that longer

codes should be cut into smaller parts and organised

also horizontally, which should help students during

their debugging process. As in W2, when learning

and using the BBP concepts and coordinate

parameters, the students seemed to profit from the

instant feedback provided by the AR visualizations.

The instructor observed that some students just tried

the loop with coordinates, rather than experimenting

with the app’s BBP commands. According to

students’ answers (n=25) (agreed or strongly

agreed), the tasks’ instructions were simple to

understand (76%), <colette/> was easy to learn

(88%), not difficult (92%), clear (88%) and fun to use

(76%). The app worked the way students wanted

(72%), and they would like to continue using the

application at school (76%), but only 40% wanted to

use it in their leisure time. Some students stated that

they would have preferred clearer task instructions,

but liked the provided hints, and that they were able

to be creative. The AR function surprised most of the

students in a positive way: ‘It also showed our

progress even if we did something incorrectly’.

Figure 3: The Slovak Radio Building in Real Life (left; Ledl,

2017) and Student’s Solution of its Model (W3).

4 DISCUSSION & LIMITATIONS

In this study, two BBP task types in the educational

application <colette/> were presented based on

individual student workshops (W1-3), to improve or

acquire CS and CT skills, in the secondary area, as

shown in similar research with BBP applications

before (Saritepeci & Yildiz-Durak, 2017). Based on

the students’ final codes, approaches, loop utilization,

and completed exercises, it can be assumed that

<colette/> has the possibility to promote coding

skills, CT (e.g., problem-solving, abstraction, AT),

and can create situations that instructors can use to

introduce CT concepts (e.g., variables and loops). It

cannot be expected that the concept of variables is

picked up and used automatically by students.

However, by students ‘hitting the wall’ of getting into

trouble with code when not using variables, a much

more fertile ground for students to be willing to learn

about variables is created. The concept of variables

will always benefit from being introduced to students

in connection with their existing app experiences.

Thus, the introduction of variables becomes the

answer to a problem that students already

encountered. Limiting factors in this study are on the

one hand its small and imbalanced sample, and on the

other hand, the missing log data (e.g., the average

number of trials) of W1 and W3, due to technical

problems. Only screenshots of the final students’

solutions and additional notes could be taken during

W1 and W3. Hence, from the W1-3 findings, no

generalization can be drawn, but a positive trend

regarding <colette/>, student engagement, and

enjoyment with CT tasks can be noted. Parts of this

assumption were already explored in similar studies

with digital technologies or apps, where a positive

influence on participants’ CT skills (Papadakis,

2022), engagement, and enjoyment during (STEM)

lessons was researched (Attard & Holmes, 2020;

Willacy, 2017; Drigas & Pappas, 2015). It remains to

investigate why some students’ uncertainties and

issues (e.g., variables did not work) appeared during

the workshops, and if it was due to the instructors, the

students, the app, the course of the workshops, and/or

the task design itself. Firstly, in the next workshops,

the instructor should not evaluate the solutions in any

way, and let the participants work completely

independently without interfering and influencing

them (e.g., example solutions, many explanations).

Secondly, it is not necessary for students to know

what the term ‘computational thinking’ means. After

using the app, most of the students in W1 thought CT

meant ‘thinking like a robot’. Therefore, the course

and questionnaire of the Draw-o-bot were changed

CSEDU 2023 - 15th International Conference on Computer Supported Education

302

(adapted and aligned to the Building Cubes

workshop). In the future, more time for the tasks and

final group discussions will be provided. In W1 and

W3, the time provided was too short (e.g., no time to

start some tasks). In addition, the perception of the

Building Cubes appeared different in W2-3: The

questionnaire data showed that the younger students

(W2) perceived the app as more difficult and less fun

than the older users (W3). This might be explained by

the fact that the app and the tasks were more

challenging for the younger ones. Also, within the

Building Cubes workshops (W2-3), some students

had technical issues (e.g., test environment, AR

function, variables), especially in W3. Therefore,

some still existing bugs need to be fixed, and the AR

view must be improved to work properly.

Overlapping blocks formed another hurdle in W2-3.

Perhaps the blocks should be colored differently (a

feature that students suggested), marked more clearly

with thicker outlines, or additional hints could be

added for students to detect and fix their errors more

quickly. This functionality might make it easier to

create variable tasks. It should also be mentioned that

the students interpreted some commands (in W1: ‘go

left’ and ‘go right’-blocks) differently from their

intended meaning, thus creating different solutions

(e.g., W1: ‘turn and walk’: unclear if ER was turning

and/or walking). The approach of giving little or no

assistance so that the participants create codes

themselves and shorten them might be helpful, as the

students rated the codes with loops as ‘better’ in W1.

This might be explained by some biased reactions of

the instructors (e.g., encouragement, a celebration of

a specific approach). Basically, it was not mandatory

to use loops in W1, as it was in W2-3. Nevertheless,

in W2-3 some students were satisfied with using a

simple sequence of blocks instead of using loops. In

the future, it will be necessary to consider what types

of tasks will include mandatory loops because it can

only gradually become more convenient to use loops

as the tasks gain more complexity.

5 CONCLUSIONS & OUTLOOK

The experiences made in four workshops will be used

for further improvement of the application (e.g.,

issues with AR, time management), and to prepare

teacher training courses for the implementation of

<colette/> as an educational tool teaching CT in

secondary education. Findings after testing and

evaluating the app indicate that the participants

reacted positively to <colette, the majority were able

to solve BBP tasks successfully and create loops to

shorten their code. Furthermore, it can be assumed

that <colette/> increased the enjoyment of the

participants in this study and has the possibility to

promote CT skills (e.g., debugging, problem-solving,

abstraction, AT). According to the participants, most

of the students had no issues with the task instructions

and the app was easy to use. Therefore, it can be

assumed that <colette/> is a useful educational tool to

teach CT, spatial representation, and BBP. Moreover,

W1-3 and tasks were re-evaluated and adapted for

future workshops, especially regarding time

management and using loops. In addition to the

currently implemented CT task types, more are

planned to be incorporated. Future research,

including a larger sampling of students and teachers,

and an in-depth analysis of the user data, will focus

on the individual types of tasks, and embedding

<colette/> into European schools.

ACKNOWLEDGMENTS

The project is (partially) funded by the Erasmus+

grant program (2020-1-DE03-KA201-077363) of the

European Union. Neither the PAD nor the European

Commission, are responsible for the content nor

liable for any losses or damage resulting from the

utilization of these resources.

REFERENCES

Alice. (2020). Alice – Tell Stories. Build Games. Learn to

Program. https://www.alice.org/ 16.11.2022

Aydeniz, M. (2018). Integrating Computational Thinking in

School Curriculum. In: Khine, M. (eds) Computational

Thinking in the STEM Disciplines. Springer. Cham.

10.1007/978-3-319-93566-9_13

Attard, C., Holmes, K. (2020). “It gives you that sense of

hope”: An exploration of technology use to mediate

student engagement with mathematics, Heliyon, 6(1).

https://doi.org/10.1016/j.heliyon.2019.e02945.

Benitti, F.B.V. (2012). Exploring the Educational Potential

of Robotics in Schools: A Systematic Review.

Computer Education. 58(1). 978–988. https://doi.org/

10.1016/j.compedu.2011.10.006

Blockly, (2022). Introduction to Blockly. Google

Developers.https://developers.google.com/blockly/gui

des/overview 12.11.2022

Blockly Games, 2022. About Blockly Games

https://blockly-games.appspot.com 12.11.2022

Bocconi, S., Chioccariello, A., Dettori, G., Ferrari, A.,

Engelhardt, K. (2016). Developing computational

thinking in compulsory education – Implications for

policy and practice. 10.2791/792158

Design and Evaluation of Computational Thinking Tasks in the <colette/> Project: Experiences Gained from Workshops with Secondary

and Grammar School Students in Austria, the Netherlands, and Slovakia

303

Bocconi, S., Chioccariello, A., Kampylis, P., Dagienė, V.,

Wastiau, P., Engelhardt, K., Earp, J., Horvath, M.A.,

Jasutė, E., Malagoli, C., Masiulionytė-Dagienė, V. and

Stupurienė, G. (2022). Reviewing Computational

Thinking in Compulsory Education, Inamorato dos

Santos, A., Cachia, R., Giannoutsou, N. and Punie, Y.

editor(s), Publications Office of the European Union,

Luxembourg. 10.2760/126955

Colette-Project. (2022). Computational Thinking Learning

Environment for Teachers in Europe https://colette-

project.eu 14.11.2022

COOL Lab Talents Club. (2022). https://www.cool-

lab.net/clubs 13.12.2022

Csizmadia, A., Curzon, P., Dorling, M., Humphreys, S.,

Ng, T., Selby, C. and Woollard, J. (2015).

Computational thinking - a guide for teachers.

Swindon. Computing at School. 1-8.

https://eprints.soton.ac.uk/424545/

Davis, F. D. (1985). A technology acceptance model for

empirically testing new end-user information systems:

Theory and results (Doctoral dissertation,

Massachusetts Institute of Technology).

Drigas, A., Pappas, M. (2015). A Review of Mobile

Learning Applications for Mathematics. International

Journal of Interactive Mobile Technologies (iJIM),

9(3), 18–23. https://doi.org/10.3991/ijim.v9i3.4420

González, E.; De La Pena, A.; Cortés, F.; Molano, D.;

Baron, B.; Gualteros, N.; Páez, J.; Parra, C. Robotic

Theater: An Architecture for Competency Based

Learning. In Proc. Adv. Intell. Syst. Comput. 126–137

[Google Scholar]

Jong, T. de, Joolingen, W.R. van. (1998). Scientific

discovery learning with computer simulations of

conceptual domains. Review of Educational Research,

68, 179-202.

Ledl, T. (2017). Upside down Pyramid, Bratislava.

https://commons.wikimedia.org/wiki/File:Upside_dow

n_Pyramid,_Bratislava_02.jpg 17.1.2023

Lv, L., Zhong, B., Liu, X. (2022). A literature review on the

empirical studies of the integration of mathematics and

computational thinking. Educ Inf Technol.

https://doi.org/10.1007/s10639-022-11518-2

Lin, Y., David Weintrop, D. (2021). The landscape of

Block-based programming: Characteristics of block-

based environments and how they support the transition

to text-based programming. Journal of Comp.

Languages. 67(1) 10.1016/j.cola.2021.101075

Mayring, Ph. (2010). Qualitative Inhaltsanalyse.

Grundformen und Techniken.11. Weinheim: Beltz.

McGee, M. G. (1979). Human spatial abilities:

Psychometric studies and environmental, genetic,

hormonal, and neurological influences. Psychological

Bulletin, 86(5), 889–918. https://doi.org/10.1037/0033-

2909.86.5.889

Milicic, G., van Borkulo, S.P., Medova, J., Wetzel, S.,

Ludwig, M. (2021). Design and Development of a

Learning Environment for Computational Thinking:

The Erasmus+ COLETTE Project. Proceedings of the

Conference EduLearn 2021. 1(1). 7376-7383. DOI:

10.21125/edulearn.2021.1495

Musante, K., DeWalt, B. (2010). Participant Observation:

A Guide for Fieldworkers. AltaMira Press

.https://books.google.at/books?id=ymJJUkR7s3UC

Papadakis, S. (2022). Can Preschoolers Learn

Computational Thinking and Coding Skills with

ScratchJr? A Systematic Literature Review.

International Journal of Educational Reform.

https://doi.org/10.1177/10567879221076077

Pou, A.V., Canaleta, X., Fonseca, D. (2022) Computational

Thinking and Educational Robotics Integrated into

Project-Based Learning. Sensor. 22. 3746.

https://doi.org/10.3390/s22103746

Saritepeci, M., Yildiz-Durak, H. (2017). Analyzing the

Eﬀect of Block and Robotic Coding Activities on

Computational Thinking in Programming Education. In

book: Educational Research and Practice. Chapter: 49.

Publisher: St. Kliment Ohridski University Press.

https://www.researchgate.net/publication/316890358_

Analyzing_the_Effect_of_Block_and_Robotic_Codin

g_Activities_on_Computational_Thinking_in_Progra

mming_Education 12.11.2022

Scratch. (2022). Scratch - Imagine, Program, Share.

https://scratch.mit.edu/ 26.11.2022

Shih, W.C. (2017). Mining Learners' Behavioral Sequential

Patterns in a Blockly Visual Programming Educational

Game. In International Conference on Industrial

Engineering, Management Science and Application

(ICIMSA). 1-2. 10.1109/ICIMSA.2017.7985594

Vetter, T.R. (2017). Descriptive Statistics: Reporting the

Answers to the 5 Basic Questions of Who, What, Why,

When, Where, and a Sixth, So What? Anesth Analg.

125(5). 1797-180 10.1213/ANE.0000000000002471

Yamashita, S., Tsunoda, M., Yokogawa, T. (2017). Visual

Programming Language for Model Checkers Based on

Google Blockly. In Felderer, M., Méndez Fernández,

D., Turhan, B., Kalinowski, M., Sarro, F., Winkler, D.

(Eds.), Product-Focused Software Process

Improvement. PROFES. Lecture Notes in Computer

Science, 10611. 597–601. Springe. Cham.

https://doi.org/10.1007/978-3-319-69926-4_49

Weintrop, D., & Wilensky, U. (2015). To block or not to

block, that is the question: students' perceptions of

blocks-based programming. Proceedings of the 14th

International Conference on Interaction Design and

Children. 10.1145/2771839.2771860

Willacy, H., Calder, N. (2017). Making Mathematics

Learning More Engaging for Students in Health

Schools through the Use of Apps. Education Sciences,

7(2), 48. https://doi.org/10.3390/educsci7020048

Xu, Z., Ritzhaupt, A.D., Tian, F., Umapathy, K. (2019).

Block-based versus text-based programming

environments on novice student learning outcomes: a

meta-analysis study, Computer Science Education,

29(2-3), 177-204. 10.1080/08993408.2019.1565233

CSEDU 2023 - 15th International Conference on Computer Supported Education

304
