Self-Healing Misconﬁguration of Cloud-Based IoT Systems Using

Markov Decision Processes

Areeg Samir

and H

avard Dagenborg

Computer Science Department, The Arctic University of Norway, Tromsø. Norway

Keywords:

Markov Decision Process, Self-Healing, Recovery, Performance, Threat, Edge Computing, Cluster,

Containers, Medical Devices, Multi-Cluster.

Abstract:

Misconﬁguration of IoT devices and backend containerized-cluster systems can expose vulnerable areas at

the network level, potentially allowing attackers to penetrate the network and disrupt workload and the ﬂow

of data between system components. This paper describes a self-healing model based on a Markov decision

process that can recover the misconﬁguration and its impact on the workload and data ﬂow at the network

level. The results show that the proposed controller led to accurate results in performance and reliability.

1 INTRODUCTION

Misconﬁguration might emerge when essential se-

curity settings of in edge devices and system clus-

ters parameters are either not implemented or imple-

mented with errors such as leaving the default conﬁg-

uration settings unchanged, erroneous conﬁguration

changes, or other technical issues (Samir and Dagen-

borg, 2023) that impact the workload and data ﬂow

within and across systems. Multi-layered vulnera-

bilities can leave devices vulnerable and allow unau-

thorized access. Thus, the change in workload and

data ﬂows due to misconﬁguration might result in

poor quality assessment, ineffective resource utiliza-

tion, latency, high cost, and a decline in service qual-

ity.

Several works have looked at the management of

workload and information ﬂow (Moothedath et al.,

2020), (Kraus et al., 2021), (Nie et al., 2021b), (Nie

et al., 2021a), (Tang et al., 2018), (DCMS, 2018),

(Jin et al., 2022), (George and Thampi, 2019). How-

ever, more work is needed to recover the miscon-

ﬁguration of edge devices and containerized clusters

and to optimize the system’s performance and relia-

bility (Dass and Namin, 2021), (Mascellino, 2022),

(Rahman et al., 2023), (Wang et al., 2018).

In this paper, we proposed a self-healing con-

troller that ﬁxes the misconﬁguration of edge devices

and backend containerized services to mitigate its im-

https://orcid.org/0000-0003-4728-447X

https://orcid.org/0000-0002-1637-7262

pact on the workload and the data ﬂow. The pro-

posed controller is based on Markov Decision Pro-

cesses (MDPs), which have been shown useful for a

wide range of optimization problems via reinforce-

ment learning. We chose MDP to manage the un-

certainty of the system’s performance at a particular

time and to allow multiple components to select the

same actions to reduce the total number of actions re-

quired. Recovery occurs by replacing or reconﬁgur-

ing the edge devices and containers-based cluster set-

tings when they do not meet the performance evalua-

tion metrics (e.g., utilization, latency, response time,

network congestion, and throughput). The controller

applies the recovery based on the type of misconﬁgu-

ration (Samir and Dagenborg, 2023), considering the

selection of the optimal recovery policy.

The rest of the paper is organized as follows. Sec-

tion 2 discusses the misconﬁguration under cluster

and edge device levels in our system. Section 3 in-

troduces the self-healing controller and describes the

mechanism of ﬁnding the optimal recovery policy.

Section 4 evaluates the controller. Section 5 discusses

the related work. Section 6 concludes the paper and

presents the direction of future work.

2 OVERVIEW OF THE SYSTEM

MODEL

We consider IoT-enabled systems that consist of var-

ious edge devices that connect via the Internet (e.g.,

244

Samir, A. and Dagenborg, H.

Self-Healing Misconﬁguration of Cloud-Based IoT Systems Using Markov Decision Processes.

DOI: 10.5220/0011966700003488

In Proceedings of the 13th International Conference on Cloud Computing and Services Science (CLOSER 2023), pages 244-252

ISBN: 978-989-758-650-7; ISSN: 2184-5042

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

Figure 1: An example of a multi-cluster architecture for

edge-based fog computing.

5G or WiFi) to backend clusters with nodes that con-

tain one or more services. For instance, in the health-

care industry, heart monitoring software might be de-

ployed to a container on a backend server, while medi-

cal sensors and mobile applications run on the edge to

collect health metrics from patients. Misconﬁguration

makes such systems and edge devices prone to several

attacks (e.g., distributed denial of service attacks, ran-

somware, security compliance breaches, privilege es-

calation attack) that facilitate further breaches, stress

the system clusters and devices, and degrade system

performance. A network gateway could provide the

starting point to launch malicious activities that affect

the system’s resources. In our medical example, see

Figure 1, the cluster contains a pool of nodes, pods,

and containers that provide resources for the health-

care system. The cluster includes the healthcare appli-

cation, which resides in the Docker Hub repository to

share and access containers’ images. The system in-

cludes services for its control, continuous integration,

and deployment. To conﬁgure Kubernetes, conﬁgu-

ration ﬁles are used to describe clusters, users, and

contexts. They are stored in version control before

being pushed to the cluster to simplify the conﬁgu-

ration change and aid cluster re-creation and restora-

tion. Misconﬁguration might occur at different levels;

at the edge device level, misconﬁguration (e.g., CVE-

2019-6538) could affect the scores of the heart rate

monitor (e.g., Medtronic device) that allows a nearby

attacker to change the settings of a patient’s cardiac

device by manipulating radio communications be-

tween it and control devices (inject, replay, modify,

and intercept the telemetry data to reprogram the car-

diac device). At the cluster level, misconﬁguration

(e.g., CVE-2019-5736, CVE-2022-0811) might occur

due to network rules, root/less privileged user access,

wrong pod label speciﬁcations, manual errors like ty-

pos, or forgetting to enforce network policies after

writing them. Hence, misconﬁgured might allow an

adversary to exploit container processes.

The controller in our system model aims to re-

cover such misconﬁguration and mitigate their impact

on workload (overloaded resources) and prevent se-

quences of abnormal data ﬂow paths. We focused on

the common misconﬁguration at Kubernetes, Azure,

and Docker Swarm (Samir and Dagenborg, 2023) re-

ported in 2022 and 2023 by CVE, the National In-

stitute of Standards and Technology (NIST) SP 800-

190, OWASP Container Security Veriﬁcation Stan-

dards, OWASP Kubernetes Security Testing Guide,

and OWASP A05:2021 – Security Misconﬁguration.

We adopt the Monitor, Analysis, Plan, Exe-

cute, and Knowledge (MAPE-K) architecture for self-

healing systems as shown in Figure 2. Our controller

consists of (1) Monitor that collects the performance

and the conﬁgurations of edge devices and cluster-

based nodes and containers; (2) Analysis that detects

misconﬁguration and identiﬁes its type to apply a suit-

able recovery action. The detection and identiﬁca-

tion are not the scopes of this paper; more details

in (Samir and Dagenborg, 2023); (3) Plan and Exe-

cute that selects the optimal recovery policy from a

set of recovery actions to heal the misconﬁguration

and its impact on workload considering the provision

of system resources. The recovery actions are stored

in the Knowledge storage to keep track of the number

of applied actions to the anomalous component. We

created pre-deﬁned misconﬁguration description pro-

ﬁles with common misconﬁguration types and stored

them in the knowledge storage to be used in the re-

covery process.

Figure 2: System model.

Self-Healing Misconﬁguration of Cloud-Based IoT Systems Using Markov Decision Processes

245

3 SELF-HEALING CONTROLLER

In this section, the self-healing controller is presented

that selects the optimal recovery policy with the most

proper recovery action(s) for the containers-based

cluster or edge device according to its status. The

following extends our previous controller (Samir and

Pahl, 2019), (Samir and Pahl, 2020) to detect and

identify the misconﬁguration at the edge device(s)

and containers-based cluster (Samir and Dagenborg,

2023).

3.1 Recovery Process Assumption

Our controller consists of the agent, which is a learner

or decision-maker, and the environment, which is ev-

erything surrounding the agent (system under obser-

vation). In our case, the agent represents the Recov-

ery phase and the environment reﬂects both the Kube

Nodes (nodes, container, services) and the patient’s

edge device. The controller, at the recovery phase,

chooses an action according to the misconﬁguration

types identiﬁed in (Samir and Dagenborg, 2023) and

observes the performance of the environment after ap-

plying the action as shown in Figure 3. Then, corre-

sponding to the applied action, the controller receives

a reward, which refers to the performance enhance-

ment for the observed monitoring metrics. If the ac-

tion is applied successfully, the controller marks the

component as recovered and keeps a proﬁle for the

applied actions in the knowledge to learn the opti-

mal action at each state in the environment and to en-

hance the recovery procedure in the future. Here, the

state refers to clusters, nodes, containers, services, or

edge devices. However, if the applied action didn’t

enhance the anomalous behavior of the misconﬁg-

ured state (e.g., network congestion), the controller

applies another action from the recovery actions list

deﬁned for that type of misconﬁgured state through

the Reconﬁguration Executor. For each type, The Ex-

ecutor follows a set of conﬁguration steps predeﬁned

and stored in the Knowledge storage. Based on the

applied actions, observations, and rewards obtained

from the applicable actions, the controller continu-

ously updates the recovery policy to ﬁnd an optimal

policy that maximizes the expected cumulative long-

term reward received during the recovery process.

3.2 Recovery Actions

The applied action could be one or more possible ac-

tions, denoted as a

, such as terminate, reconﬁgure,

redeploy, restart, or do nothing. Here, terminate is

represented as a

i=1

, which denotes that the system’s

Figure 3: Self-Healing Controller - Recovery Using MDP.

state (e.g., containers deployed services) will be ter-

minated if a container escapes vulnerability and al-

lows an attacker to obtain host root access, and the

recovery actions don’t heal the anomalous behavior.

The a

i=2

represents a combination of two actions,

reconﬁgure and redeploy, and it indicates that the

anomalous state will be reconﬁgured and redeployed.

In case the a

i=2

action didn’t heal the anomalous state,

another action, a

i=3

, will be applied to reconﬁgure

and restart the whole cluster. If the status of the state

cannot be obtained, do nothing action a

i=4

will be ap-

plied. The restart action a

i=0

is the default applicable

action to avoid trying multiple actions and to mini-

mize the time and cost of the recovery process.

3.3 Recovery States: Environment

For each misconﬁgured state, denoted as s, an action

from the action space A at time t where A contains

a set of actions available for the misconﬁgured state,

∈ A(s

). The misconﬁgured state s at a speciﬁc pe-

riod constitutes the controller’s input, which belongs

to a state space S that includes possible situations for

each misconﬁgured state: 1) the state is at the initial

status (misconﬁgured) s

Int

, 2) the state is successfully

recovered s

, 3) the state recovery failed s

, and 4)

the state is recovered s

. Hence, if the state is s

Int

then a recovery action from the A is applied. In case

the action is applied successfully, the state transits to

to indicate the success of recovery, and the state

is marked as recovered s

; otherwise, the state turns

to s

, and another action is applied. The controller

monitors the performance evaluation metrics after ap-

plying the action. Whenever the metrics are beyond

the dynamic threshold, the controller considers it a

recovered state; otherwise, a recovery process will be

continued until the misconﬁgured state is recovered.

For each applicable action on state s, the controller re-

ceives a reward r at time t, where r ⊂ R, and R is the

cumulative reward. The recovered state s

returns to

its optimal status at s

t+1

. The transition from one state

status to another, denoted as P

= P(s

i=2

) = 1,

and referred to the probability of transiting from state

CLOSER 2023 - 13th International Conference on Cloud Computing and Services Science

246

to state s

upon applying action a

i=2

and receiving

reward r

. If the state recovery failed s

, the proba-

bility of transition P

= P(s

Int

i=2

) = 0, and we

assign a constant failure rate CFR for the state un-

der recovery with an exponential failure distribution

as shown in (1) to measure the conditional probabil-

ity of failure per time unit.

(t)

= CFR × exp

−CFR(t+t

)

(1)

3.4 Recovery Rewards

The reward could be a positive value, which refers to

a successfully applied recovery action that enhanced

the observed metrics, or a negative value which refers

to an unsuccessfully applied recovery action that de-

clined the observed metrics. The value of the reward

is determined by measuring the performance for ev-

ery anomalous state based on the action applied at

each time slot. We obtained the number of rewards

for each anomalous state, as shown in (2).

= [r

t+1

| s

]

(2)

To optimize the controller rewards, we computed

the total amount of rewards, as shown in (3), received

by the controller at time t while performing action

i=2

to transits from state status (s

) to (s

R(t) = r(t + 1) + r(t + 2) + · · · + r(T )

(3)

For the recovery failed s

state status, the con-

troller applies recovery actions until the state is re-

covered and the controller transits to (s

). However,

if the s

can’t be recovered by the applicable actions,

the controller enters into a loop as it isn’t able to tran-

sit to (s

), and a self-transitions happens to the (s

)

with zero rewards. Thus, to avoid inﬁnity, we deﬁned

a discount factor DF to give immediate or future re-

wards according to the status of the s

state so that

the controller could exit the loop of the anomalous

state and ﬂag the state as not-recovered. The optimal

value for DF lies between 0.2 to 0.8 so that the sum

of the rewards received at time steps u over the future

is maximized according to a discount rate DF that de-

termines the value of future rewards as shown in (4).

R(t) =

T −t−1

∑

u=0

t+u+1

(4)

3.5 Appropriate Actions Selection

To select the proper recovery action for each state in

terms of the rewards, we expanded (4) so that the con-

troller follows a recovery policy π to take action a in

state s at time t, as shown in (5), with a probability

distribution over the actions taken for each state as

shown in (6).

(s,a,t) = [

T −t−1

∑

u=0

t+u+1

| S

= s, A

= a]

(5)

π(a|s) = ρ[A

= a|S

= s]

(6)

From (5) and (6), the controller selected action a

as a suitable recovery option for s

as the greater the

value of R

(s,a,t), the better a speciﬁc action for a

state is, as shown in Table 1.

Table 1: State Action Value.

Misconﬁgured Components s

Actions a

Values 0.3 0.8

From (5) and (6) given any state s and action a at

t, we computed the probability of each possible pair

of the next state s

and reward r as shown in (7). Here,

the controller responds at (t + 1) to transit to the next

state and reward. Given that we obtained: (1) the

reward for any state action pair as shown in (8), (2)

the state transition probabilities as shown in (9), and

the expected rewards for the state action, next state as

shown in (10).

p(s

,r|s, a) = Pr{R

t+1

= r,S

t+1

= s

= s, A

= a},

s ∈ S

,a ∈ A

(7)

r(s, a) = ε [R

t+1

= s, A

= a] =

∑

r∈R

∑

∈S

p(s

,r|s, a)

(8)

p(s

|s,a) = Pr{S

t+1

= s

= s, A

= a} =

∑

r∈R

p(s

,r|s, a)

(9)

r(s, s

,a) = ε [R

t+1

= s, A

= a, S

t+1

= s

] =

∑

r∈R

r ∗ p(s

,r|s, a)/p(s

|s,a)

(10)

For each state s

, we measured the average recov-

ery time ART , which refers to the mean time µ of

applying a speciﬁc action a

under a particular pol-

icy π knowing the monitored metric type MoM

{type}

(e.g., type: CPU, Memory, Network) that exists in the

performance function Per and belongs to the state s

as shown in (11). Hence, the performance of the re-

covery process for a speciﬁc state is the overall per-

formance for recovering a state s during the whole re-

covery process at time T with state probability matrix

P[s

Self-Healing Misconﬁguration of Cloud-Based IoT Systems Using Markov Decision Processes

247

ART =

∑

i=1

P[s

]

∑

j=1

t,a

× π(a

∀ MoM

{CPU}

∃ Per, ∈ s

(11)

3.6 Find the Optimal Recovery Policy

To ﬁnd the optimal recovery policy for each state con-

sidering the recovery actions, we considered the pol-

icy that achieves more rewards than other policies and

optimizes the performance over time as follows:

3.6.1 Policy Selection and Evaluation

We assumed that a policy denoted π is deﬁned to be

better than or equal to another policy denoted π

the value of state s under the policy π denoted υ

(s)

is the expected return for taking action a in state s and

is greater than or equal to π

for all states and actions

under that policy. We measured the expected return

from each state under a given policy by obtaining the

transition probabilities and the expected reward r for

applying action a in state s under a given policy π

and a discount factor value DF of the next state s

as shown in (12) and (13). Then, we obtained the

maximum return overall policies that can be achieved

at any state s by obtaining the optimal state value as

shown in (14) and the optimal state-action value as

shown in (15). A policy whose states and actions val-

ues are optimal is an optimal policy; we can ﬁnd that

by taking their maximum as shown in (16). These

steps are repeated for each state-action pair that be-

longs to the state space and action space under a se-

lected policy to evaluate the selection of the optimal

actions in a state to maximize Q

optimal

(s,a). The eval-

uation is stopped when the convergence between the

old and the new values is small.

(s) =

∑

π(a|s)

∑

p(s

,r|s, a)[r +DFυ

)]

(12)

(s,a) =

∑

p(s

,r|s, a)[r +DFυ

)]

(13)

optimal

(s) = max

(s),∀ s ∈ S

(14)

optimal

(s,a) = max

(s,a),∀ s ∈ S, ∀ a ∈ A

(15)

optimal

(s) = arg max

optimal

(s,a)

(16)

3.6.2 Policy Update

We update the optimal policy obtained from the pre-

vious steps to select the action a that maximizes the

future rewards if we take action a in state s and follow

policy π as shown in (17). The policy π

must be bet-

ter than the previous policy π

optimal

, which indicates

that π

improves the chances of getting more future

rewards starting from the state s as shown in (18). The

policy update stops when the policy stops improving,

as shown in (19), or when the optimal policy obtained

from the previous section π

optimal

(s) is better than the

(s), in such a case, we consider π

optimal

(s) is the

best policy that maximizes the future rewards for the

state action values.

(s) = arg max

(s,a)

(17)

(s,π

(s)) = max

(s,a) ≥

(s,π

optimal

(s)) = υ

(s)

(18)

(s,π

(s)) = max

(s,a) =

(s,π

optimal

(s)) = υ

(s)

(19)

4 EVALUATION

In this section, a brief discussion is stated for the re-

covery evaluation.

4.1 Environment Setup

To evaluate the effectiveness of the proposed con-

troller, our setup consisted of four nodes. Three

main nodes (i.e., VM instances). One node is for

the heart rate monitor; one is for correctly conﬁg-

ured containers-based clusters, and one is for the con-

troller. The fourth node is for the misconﬁguration

scenarios. For each node, we deployed a set of con-

tainers and services. Each node is equipped with Lin-

uxOS (Ubuntu 18.10 version), one VCPU, and 2GB

VRAM. A K8s cluster running on VMs consisting

of one master node and three worker nodes was de-

ployed using Kubeadm, running K8s version 1.19.2.

We created 30 namespaces, each with 4 microservices

(pods) used for performance measurements, and as-

signed the same number of network policies. The

number of created policies was 900, which were or-

dered, managed, and evaluated using Calico, Open

Policy Agent, and Styra DAS, respectively. We veri-

ﬁed the ability of the controller using a long time-span

dataset (from 1 July 2021 to 1 November 2022). The

model was trained for all-day and daytime-only on the

collected data.

CLOSER 2023 - 13th International Conference on Cloud Computing and Services Science

248

4.2 Data Collection and System

Monitoring

Agents are installed to collect data about CPU, Mem-

ory, Network, ﬁlesystem changes, information ﬂow

(i.e., no. of ﬂows issued to component), patient health

information, device operation status, the device id,

and service status from the system components. The

agents exposed log ﬁles of system components to the

storage to be used in the analysis. The agent adds

a data interval function to determine the time inter-

val at which the data collected belongs. The agent

clears outliers from the collected data and monitors

them using selected resource performance monitoring

tools. The agent is conﬁgured to connect to the sys-

tem automatically with valid credentials for authen-

tication. Edge devices with similar functionality are

grouped and allocated to a respective group (pool of

heart monitor edge devices).

We used the Datadog tool to obtain a live data

stream for the running components and to capture the

request-response tuples and associated metadata. The

captured data were streamed out of the cluster to be

analyzed further. Prometheus is used to group the col-

lected data (latency, throughput, bandwidth, throttling

congestion, errors, number of requests, and resource

utilization) and to store them in a time series database

using Timescale-DB. We used the Logman command

in Kubernetes and Docker to trace remote procedure

call (RPC) events to forward container logs as event

tracing in the window. We used NNM iSPI Per-

formance to collect data about the information ﬂow

from the system under observation (e.g., device id,

device type, max/mean/min size of the packet sent,

total packets, max/mean/min amount of time of active

ﬂow, duration of ﬂow). The conﬁguration ﬁles of the

components are stored in the GitOps version control

to simplify the rollback of conﬁguration change. We

wrote our conﬁguration ﬁles using YAML. We man-

aged the conﬁgurations, deployments, and dependen-

cies using kubectl and Skaffold.

The datasets were extracted from the monitoring

tools and log ﬁles, and they were in a variety of sizes.

The dataset used to train the model was divided into a

70% training set and 30% testing set.

4.3 Misconﬁguration Scenarios

We trained our model on one of the identiﬁed

misconﬁguration types in (Samir and Dagenborg,

2023), which is the unauthenticated connection that

happens because the pod was incorrectly conﬁg-

ured with parameters made true for privileged and

hostPID. Moreover, some misconﬁguration types

(e.g., CVE-2019-5736, CVE-2022-0811, CVE-2019-

6538, CVE-2021-21284, CVE-2019-9946, and CVE-

2020-10749) that allow privilege escalation was con-

sidered during the performance evaluation. We chose

these types as they allow root access to the host,

and they resulted in a sudden increase at the cluster

level in request latency and the request rate falling,

which caused excessive consumption of resource us-

age (CPU, memory, network). Furthermore, some

of these types of misconﬁguration might lead to im-

proper access occurring at the edge level (e.g., CVE-

2019-6538) due to no encryption to secure the com-

munication protocol, and the protocol lacks authenti-

cation for legitimate devices.

4.4 The Recovery Assessment

This section focuses on evaluating the controller by

measuring the reliability of recovery, deployment, and

performance of the controller.

4.4.1 Reliability Evaluation

We used Mean Time to Recovery (MTTR) to eval-

uate the average time the recovery process takes to

recover a component after observing a failure on the

monitored metrics. The failure refers to a component

that cannot meet its expected performance metrics. A

higher MTTR indicates the existence of inefﬁciencies

within the recovery process or the component itself.

We conducted two scenarios. The ﬁrst one corre-

sponds to the selection of the optimal policy. The

second relates to selecting a random policy, where

the agent randomly selects one or more actions with

uniform distribution. For each scenario, we aimed

to assess the average time that the recovery process

took to recover a container and an edge device. In

the ﬁrst scenario, the MTTR for the edge device was

20 s, and the MTTR to recover the container was ap-

proximately 43 s with a grace period of 80 s (default

30 s in Kubernetes) for service image size (110 MB)

with service image number 30. For the second sce-

nario, the MTTR for the edge device was 53 s, and

the MTTR to recover the container was roughly 71

seconds under the same settings. We noticed that the

container and the edge device function normally af-

ter that interval in both scenarios regarding the as-

signed rewards. The result of the ﬁrst scenario led

to a signiﬁcantly short recovery time as the average

achieved rewards through the optimal policy were re-

markably higher than the random policy. Moreover,

for some actions, such as reconﬁguring and redeploy-

ing action, the more rewards are assigned during the

recovery process, the average time decreases as the

detection time was short, demonstrating a signiﬁcant

Self-Healing Misconﬁguration of Cloud-Based IoT Systems Using Markov Decision Processes

249

difference in the controller performance. However, to

recover from failure efﬁciently, the average recovery

time increased when the failure rate increased.

4.4.2 Deployment and Performance Evaluation

We veriﬁed if the captured variation in performance

was due to a misconﬁguration within the clusters and

edge devices. Hence, spearman’s rank correlation co-

efﬁcient is used to estimate the correlation between

valid conﬁgurations and normal system performance

based on observing monitored metrics as the correct

system behavior (more details, see (Samir and Pahl,

2019)). The decrease in the correlation degree tells

that the observed degradation is not due to misconﬁg-

uration; otherwise, it refers to its existence. The gen-

eral observation indicated a higher number of notice-

able correlations between the misconﬁguration and

the performance indicators. The highest correlation

was 0.82, and the lowest correlation was 0.34.

The conﬁguration settings were checked against

the benchmarks for misconﬁgurations during the de-

ployment of a component (edge devices, containers,

edge gateway, and clusters). The controller iterated

all the security policies and guidelines (Azure, CIS

Docker, and Kubernetes Benchmarks). In case of a

mismatch between the settings and the requirements

of secure deployment in one or more component(s),

the controller reevaluates the deployment of the im-

pacted component, applies the required reconﬁgura-

tion, and redeploys the component. Otherwise, the

component settings are secure as per security guide-

lines, and the controller proceeds with the deploy-

ment. The controller checked the misconﬁguration,

which needs to be addressed in components as a ﬂag.

Hence, we measured the average redeployment time

for the component after observing anomalous behav-

ior until the successful recovery of a component. The

container redeployment average time was 210 sec-

onds, with no observing overheads associated with

Kubernetes and Docker Swarm. For the edge de-

vice, the average redeployment time required to send

a redeployment request and to receive a response to

the corresponding edge gateway successfully was 185

seconds for the redeployment package with 110 MB.

For the edge gateway, the average redeployment time

was 95 seconds. Over multiple runs, the average rede-

ployment time was reduced by 15∼30%, and the per-

formance improved by 20% depending on the content

and structure of the container’s image and the avail-

able network bandwidth. In this sense, the platform

had a signiﬁcant impact on the redeployment time.

Moreover, the results show that the average

amount of resource consumption (CPU, memory, net-

work), with no misconﬁguration, was approximately

the same, with respective values varying around

30%∼60% (normal behavior). Resource consump-

tion due to misconﬁguration increased and was over

98% (overloaded resources), demonstrating the im-

pact of improper conﬁguration on the system re-

sources. The recovered misconﬁguration impacted

the saturated resource as the values of the monitored

resources varied around 38.4%∼64.6% (normal be-

havior). The controller performance was almost the

same, with a minor recovery time deviation of around

100 seconds for some failure types, like container

privileged access and wrong pod label. The devia-

tion returned to the correlation with the failure in the

system. Hence, we used the sequence of failures oc-

curring during the recovery process to reﬂect the type

of failure, which represents the failures that share the

same observations corresponding to a unique fault. If

the container privileged access and wrong pod label

sequence of failures occurred, we focus on the con-

tainer privileged access failure to represent its failure

type and relate it to its fault, which is Privilege Ac-

cess Escalation Management. We choose the initial

failure that occurred as it is representative enough of

the observations to which it belongs, which allows us

to save the recovery time without trying many recov-

ery actions.

In the end, we found that some anomalous behav-

ior in the test set, such as CVE-2022-0811, is not cov-

ered by the training set, which might impact accuracy.

The result stated that the controller performed better

with the increase in the training dataset size. More-

over, we measured the average rate of successfully

recovered components to the total number of mis-

conﬁgurations in all anomalous components. After

multiple runs, the average rate was around 97.66%,

which means that the recovery could not handle a

small number of misconﬁgurations, though the un-

handled anomalous behavior decreased dramatically

with more training data.

5 RELATED WORK

This section explores the recovery of misconﬁgura-

tion in literature.

Various frameworks for managing workload and

information ﬂow in Edge/Fog environments have

been developed; however, they provided limited

scope for integrating different policies to manage the

conﬁgurations of medical edge devices and clusters

dynamically. In particular, existing frameworks have

paid limited attention to the critical role of efﬁcient

recovery management (Mascellino, 2022), (Nie et al.,

2021b), (Nie et al., 2021a), (Tang et al., 2018), (Taft,

CLOSER 2023 - 13th International Conference on Cloud Computing and Services Science

250

2022), (Fairwinds, 2023), (Pelletier, 2020), (Alspach,

2022), (Dass and Namin, 2021).

In Pranata et al. (2020), the relationship between

the service behavior and the value of some perfor-

mance metrics is identiﬁed to discover the miscon-

ﬁguration of cloud services using principal compo-

nent analysis. In Dur

an and Sala

un (2016), a protocol

that reconﬁgures cloud applications is presented. It

focuses on reconﬁguring a set of interconnected com-

ponent failures hosted on remote VMs. In Chiba et al.

(2019), a performance-centric conﬁguration frame-

work for containers on Kubernetes is proposed. The

framework gives uniﬁed key-value data, including

conﬁgurations and metrics, to analysis plugins by pro-

viding a built engine for processing deﬁned rules in

analysis plugins. In Assuncao and Cunha (2013), a

dynamic reconﬁgurable workﬂow framework is pro-

vided to manage failures of unavailable resources and

variations in service quality. The framework recov-

ers from failures in long-running workﬂow either by

human intervention or a predeﬁned task. In Vaquero

et al. (2012) provides an architecture to control the

behavior of the applications deployed in the cloud by

using a set of deﬁned rules. The rules are deﬁned to

create and conﬁgure the VMs. The architecture en-

ables the re-deﬁnition of policies at the service and

VM levels to describe their behavior.

Our work is similar to the ideas presented above.

However, the presented controller extended the work

in (Samir and Pahl, 2020), (Samir and Pahl, 2019) by

mapping the observed performance degradation (fail-

ure) on performance metrics to its hidden abnormal

ﬂow of information (fault) and misconﬁguration type

(error) to analyze the misconﬁguration and its conse-

quence of threat within IoT edge devices and a cluster

of containers running on cluster nodes; more details

see (Samir and Dagenborg, 2023). Based on the map-

ping, the controller that is presented in this paper re-

covers the misconﬁguration by selecting the optimal

recovery policy with optimum actions to optimize the

performance and the reliability of the system under

observation.

6 CONCLUSIONS AND FUTURE

WORK

Securing workloads and information ﬂow in

containers-based clusters Kubernetes and edge

medical devices is an important part of overall

system security. This paper presented a self-healing

controller that recovers the misconﬁguration of

edge medical devices and container-based cluster

systems using Markov Decision Processes (MDPs).

The proposed controller optimizes the recovery

process by selecting the optimal recovery policy with

optimum actions to maximize the performance of

observed metrics. The results show that the proposed

controller is able to recover the misconﬁguration with

more than 97%, which demonstrates the suitability of

the solution.

The aim of this paper was to introduce the recov-

ery part of the controller architecture with its key pro-

cessing steps. In the future, we will expand the recov-

ery mechanism and carry out further experiments to

fully conﬁrm these given conclusions.

ACKNOWLEDGMENT

This research was funded in part by The Research

Council of Norway under grant number 263248.

REFERENCES

Alspach, K. (2022). Major vulnerability found in open

source dev tool for kubernetes.

Assuncao, L. and Cunha, J. C. (2013). Dynamic workﬂow

reconﬁgurations for recovering from faulty cloud ser-

vices. volume 1, pages 88–95. IEEE Computer Soci-

ety.

Chiba, T., Nakazawa, R., Horii, H., Suneja, S., and See-

lam, S. (2019). Confadvisor: A performance-centric

conﬁguration tuning framework for containers on ku-

bernetes. pages 168–178.

Dass, S. and Namin, A. S. (2021). Reinforcement learn-

ing for generating secure conﬁgurations. Electronics

2021, Vol. 10, Page 2392, 10:2392.

DCMS (2018). Mapping of iot security recommendations,

guidance and standards to the uk’s code of practice for

consumer iot security.

Dur

an, F. and Sala

un, G. (2016). Robust and reliable recon-

ﬁguration of cloud applications. Journal of Systems

and Software, 122:1339–1351.

Fairwinds (2023). Kubernetes benchmark report security,

cost, and reliability workload results.

George, G. and Thampi, S. M. (2019). Vulnerability-based

risk assessment and mitigation strategies for edge de-

vices in the internet of things. Pervasive and Mobile

Computing, 59.

Jin, X., Katsis, C., Sang, F., Sun, J., Kundu, A., and Kom-

pella, R. (2022). Edge security: Challenges and is-

sues. pages 1–21.

Kraus, S., Schiavone, F., Pluzhnikova, A., and Invernizzi,

A. C. (2021). Digital transformation in healthcare:

Analyzing the current state-of-research. Journal of

Business Research, 123:557–567.

Mascellino, A. (2022). Nearly one million exposed miscon-

ﬁgured kubernetes instances could cause breaches.

Self-Healing Misconﬁguration of Cloud-Based IoT Systems Using Markov Decision Processes

251

Moothedath, S., Sahabandu, D., Allen, J., Clark, A., Bush-

nell, L., Lee, W., and Poovendran, R. (2020). Dy-

namic information ﬂow tracking for detection of ad-

vanced persistent threats: A stochastic game ap-

proach. arXiv:2006.12327.

Nie, L., Ning, Z., Obaidat, M. S., Sadoun, B., Wang, H., Li,

S., Guo, L., and Wang, G. (2021a). A reinforcement

learning-based network trafﬁc prediction mechanism

in intelligent internet of things. IEEE Transactions on

Industrial Informatics, 17:2169–2180.

Nie, L., Sun, W., Wang, S., Ning, Z., Rodrigues, J. J., Wu,

Y., and Li, S. (2021b). Intrusion detection in green in-

ternet of things: A deep deterministic policy gradient-

based algorithm. IEEE Transactions on Green Com-

munications and Networking, 5:778–788.

Pelletier, J. (2020). Common kubernetes misconﬁguration

vulnerabilities.

Pranata, A. A., Barais, O., Bourcier, J., and Noirie, L.

(2020). Misconﬁguration discovery with principal

component analysis for cloud-native services. pages

269–278. Institute of Electrical and Electronics Engi-

neers Inc.

Rahman, A., Shamim, S. I., Bose, D. B., and Pandita, R.

(2023). Security misconﬁgurations in open source ku-

bernetes manifests: An empirical study. ACM Trans-

actions on Software Engineering and Methodology.

Samir, A. and Dagenborg, H. (2023). A self-conﬁguration

controller to detect, identify, and recover misconﬁg-

uration at iot edge devices and containerized cluster

system. pages 765–773.

Samir, A. and Pahl, C. (2019). A controller architecture

for anomaly detection, root cause analysis and self-

adaptation for cluster architectures. pages 75–83.

Samir, A. and Pahl, C. (2020). Autoscaling recovery ac-

tions for container-based clusters. Concurrency and

Computation: Practice and Experience, 33:1–13.

Taft, D. K. (2022). Armo: Misconﬁguration is number 1

kubernetes security risk.

Tang, F., Fadlullah, Z. M., Mao, B., and Kato, N. (2018). An

intelligent trafﬁc load prediction-based adaptive chan-

nel assignment algorithm in sdn-iot: A deep learning

approach. IEEE Internet of Things Journal, 5:5141–

5154.

Vaquero, L. M., Mor

an, D., Gal

an, F., and Alcaraz-Calero,

J. M. (2012). Towards runtime reconﬁguration of ap-

plication control policies in the cloud. Journal of Net-

work and Systems Management, 20:489–512.

Wang, S., Li, C., Hoffmann, H., Lu, S., Sentosa, W., and

Kistijantoro, A. I. (2018). Understanding and auto-

adjusting performance-sensitive conﬁgurations. vol-

ume 53, pages 154–168. Association for Computing

Machinery.

CLOSER 2023 - 13th International Conference on Cloud Computing and Services Science

252
