Evaluation of Persistence Methods Used by Malware on Microsoft

Windows Systems

elie Dieterich, Matthias Schopp, Lars Stiemert, Christoph Steininger and Daniela P

ohn

Universit

at der Bundeswehr M

unchen, Neubiberg, Germany

Keywords:

Malware, Persistence, Evaluation, Windows Security.

Abstract:

The usage of persistence methods has become common, as adversaries seek to remain undetected with their

malware on systems for longer periods. This raises the question of how effective frequently used persistence

methods are across different versions of the Microsoft Windows operating system. To answer this question, a

metric is developed by which persistence methods can be quantitatively evaluated and compared. The metric

is subsequently applied to eight persistence mechanisms across four different Microsoft Windows operating

systems. In our results, there is no difference in the performance of methods between operating systems and a

majority of mechanisms scored similarly overall. There is, however, a signiﬁcant decline in performance when

defensive mechanisms are enabled. The results emphasize the effectiveness of basic persistence methods of

Microsoft Windows operating systems.

1 INTRODUCTION

Malware persistence has become commonplace, from

backdoors to well-known ransomware such as Wan-

naCry. Thereby, adversaries receive persistent access

to computers. On the other hand, it becomes more

difﬁcult to detect and remove them. Other examples

of the importance of persistence are Advanced Per-

sistent Threats (APTs). APTs are cyber attacks on a

computer network that remain undetected for an ex-

tended period of time. They are often launched by

state-funded actors with the aim of sabotaging or spy-

ing on the conﬁdential data of companies or authori-

ties. With persistent malware becoming ubiquitous, it

is important to be able to gauge how dangerous a per-

sistence method is, in order to understand the threat

posed by speciﬁc methods. This can be achieved by

scoring persistence methods. Currently, most classi-

ﬁcations of persistence methods focus solely on simi-

larities between how persistence is achieved such as

with (MITRE, 2022) ATT&CK. ATT&CK summa-

rizes adversary techniques and tactics into an openly

available knowledge base with one category being

dedicated to persistence tactics. Here, methods are

categorized according to which medium is abused to

gain persistence.

In order to assess the danger emerging persistence

https://orcid.org/0000-0002-6373-3637

methods pose, a baseline is needed against which

newly established methods can be compared. Mi-

crosoft Windows is the most widely used desktop op-

erating system (OS) with a market share of 74.99%

as of November 2022 (StatCounter, 2022). In con-

sequence, we concentrate on Microsoft Windows OS

with the recent versions of Windows 10, Windows

11, Windows Server 2019, and Windows Server 2022.

Since defensive tools, such as anti-virus software, are

regularly updated to maintain their effectiveness, mal-

ware persistence methods may be rendered ineffec-

tive. As a result, it is important to consider whether

persistence methods are detected and/or prevented by

defensive software on a system. Consequently, we fo-

cus on the following research questions:

R1: How effective are common persistence methods

on recent Microsoft Windows OSs?

R2: To what extent do the built-in defenses of Win-

dows 11 and Windows Server 2022 protect against

persistence methods compared to their respective

predecessors?

The contribution of this paper is twofold: 1) we

present a systematic evaluation approach including a

metric, and 2) we present the results of a practical

evaluation of persistence methods on several different

Windows OSs.

The paper is organized as follows: Section 2 pro-

vides an overview of related work. Next, in Section 3,

552

Dieterich, A., Schopp, M., Stiemert, L., Steininger, C. and Pöhn, D.

Evaluation of Persistence Methods Used by Malware on Microsoft Windows Systems.

DOI: 10.5220/0011710200003405

In Proceedings of the 9th International Conference on Information Systems Security and Privacy (ICISSP 2023), pages 552-559

ISBN: 978-989-758-624-8; ISSN: 2184-4356

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

common persistence methods for Microsoft Windows

OSs are explained. The methodology of our research

is outlined in Section 4, while its application within

the practical evaluation is described in Section 5. The

results are summarized and discussed in Section 6.

Section 7 concludes the paper and provides an out-

look for future work.

2 RELATED WORK

While (MITRE, 2022; Hunkeler, 2022) describe com-

mon persistence methods, research approaches either

analyze persistence methods or propose ways to de-

tect them.

(Gittins and Soltys, 2020) focus on persistence

techniques in well-known malware, such as Emotet,

TrickBot, and OceanLotus, and their identiﬁca-

tion through malware analysis. The authors show

that even complex malware often gains persistence

through well-known methods. (Barr-Smith et al., ) an-

alyze the Living-off-the-Land (LotL) technique with

several malware samples, showing that it is often used

at APTs. (Rana et al., 2021) examine various per-

sistence methods in Microsoft Windows OS. Even

though the authors analyze several methods, it stays

unclear which exact versions of Microsoft Windows

OS and test setup they use and how often the single

steps are repeated.

(Mankin, 2013) applies DIONE, an infrastructure

for rule-based disk input/output (I/O) monitoring and

analysis to detect if a persistence method is installed

and if the mechanism is successful. Thereby, the au-

thor demonstrates the effectiveness of classifying per-

sistence mechanisms according to their capabilities.

(Dubey, 2019) combines static and dynamic analy-

sis to identify malware persistence mechanisms. The

persistence methods are detected by identifying vari-

ous functions and ﬁles that were modiﬁed by the mal-

ware. The author concludes that a combination of

static, dynamic, advanced static, and advanced dy-

namic is most suitable for identifying malware per-

sistence techniques. In contrast, (Laurenza et al.,

2020) propose a group of one-class classiﬁers to de-

tect APT samples. Similarly, (Reischaga et al., 2020)

use heuristic, static, and dynamic analysis for detect-

ing, assessing, and measuring malware threats. To un-

derstand the impact of adversarial examples on mal-

ware detection, (Park and Yener, 2020) review practi-

cal attacks against malware classiﬁers.

Summary: The focus of the described related work

is on analyzing malware regarding their persistence

methods as well as understanding these mechanisms.

However, few approaches rate the effectiveness in

terms of the threat posed by different persistence tech-

niques and compare them to each other.

3 PERSISTENCE METHODS

This section explains a selected number of methods

to maintain persistence within a compromised sys-

tem. As the practical evaluation in Section 5 focuses

solely on current versions of the Microsoft Windows

OSs, only methods that operate on Windows are con-

sidered in the following. Furthermore, methods cov-

ered in this section have been commonly used by ad-

versaries in well-known malware, such as Mimikatz,

Agent Tesla, and BabyShark (MITRE, 2022). We ex-

clude pre-OS persistence methods such as bootkits

because these are more commonly used in APTs.

3.1 User Account

Abusing existing user accounts to gain initial access

to a system is a common tactic. In addition, this

method can be used for persistence. In the following,

we describe the three categories of valid accounts,

account manipulation, and account creation, which

work for both local and domain accounts.

Valid Account: If attackers obtain valid creden-

tials to an existing account, they are able to abuse

these to maintain their foothold within a system.

This is referred to as valid account persistence. In-

truders obtain account credentials through a wide

variety of tools and techniques, such as credential

leaks, social engineering, password cracking, and

key-loggers (Thomas et al., 2017). The persistence

gained through a valid account is not affected by

changes (updates, upgrades) to the OS. However, the

credentials can be altered and accounts can be deleted.

This locks the intruder out, although installed mal-

ware may remain active. Detecting the abuse of ac-

counts is challenging because it concerns identifying

unusual behavior. Indicators to identify account abuse

exist, for instance, logons outside of business hours

and one account logged into multiple machines simul-

taneously. Inactive accounts are especially vulnerable

to attacks, as there is no user present to identify ab-

normal activity on the account (CISA, 2022).

Account Manipulation: To prevent the loss of access

caused by the users changing their password, intrud-

ers may change the credentials themselves. This type

of approach is referred to as account manipulation.

However, it is not restricted to only password modiﬁ-

cation. Other tactics include any action by which an

intruder preserves access to a compromised account,

for example, by modifying permission groups or al-

Evaluation of Persistence Methods Used by Malware on Microsoft Windows Systems

553

lowing remote access to accounts. The drawback of

modifying user accounts lies in the higher probabil-

ity of detection as these actions are likely to show up

in the logs. Furthermore, a changed password on an

active account will be noticed by the user. The privi-

leges required for a speciﬁc type of modiﬁcation vary:

Changing an account’s password is possible with lim-

ited rights, however, modifying permission groups re-

quires administrator privileges.

Account Creation: Lastly, persistence can be

achieved by adding new accounts to a compromised

system. While the persistence is similar to the cate-

gories described before, this tactic offers beneﬁts in

terms of detection since the account has no additional

users. Therefore, there is no other user, who might

recognize unusual activity on the account. However,

creating a new account will show up in the logs and

requires administrator privileges.

3.2 Scheduled Task/Job

Persistence achieved by abusing built-in functions for

scheduling tasks falls into the category of scheduled

task/job persistence. On Windows, this type of per-

sistence is often achieved through the Windows Task

Scheduler (WTS). The tasks performed by WTS run

in background sessions. Triggers determine when a

task with its actions, i. e., items or jobs, is to be ex-

ecuted. The security context in which a task is run

is deﬁned by principals. Settings are used to deter-

mine how a task is to be run with respect to condi-

tions external to the task. Registration information

contains administrative information that is gathered

when a task is created. The data component is sup-

plied by the author and contains additional documen-

tation about the task (Microsoft, 2021).

The WTS can be abused for persistence through

the creation of tasks with the schtasks utility resp.

graphical user interface (GUI) that regularly execute

malicious code. Tasks can only be created by ad-

ministrators but executed with any privileges. Reg-

ular user activity does not interfere with the comple-

tion of tasks. Furthermore, as tasks are designed to

be automatically executable during boot-up, sched-

uled tasks have no difﬁculty surviving system reboots.

When updating or upgrading a Windows OS, all data

will be transferred. However, it is not uncommon

for data to be lost during the procedure, possibly af-

fecting the scheduled task (Potter and Nieh, 2005).

Scheduled task persistence can be detected by mon-

itoring for newly created scheduled tasks. Further-

more, changed entries related to scheduled tasks in

%systemroot%\System32\Tasks may also indicate

a malicious presence.

3.3 System Process

In Windows, system-level processes are referred to as

Windows Services and are typically used to perform

background system functions. Services can be de-

ﬁned by creating an application that is subsequently

installed as a service using InstallUtil.exe and

edited with the Service Control Manager. For this

type of persistence, the malware will often install it-

self as a service. The persistence is similar to the

scheduled task persistence because services are also

system processes that are executed, for example, at

boot-up or logon. Creating services requires admin-

istrator privileges, however, they are executed under

system privileges. Consequently, this technique can

be used for privilege escalation. Abuse of Windows

services can be detected by monitoring the creation

and modiﬁcation of Windows services resp. monitor-

ing changes in the service registry entries and unusual

processes.

3.4 Boot or Logon Auto-Start Execution

When an adversary automatically runs a program at

boot or logon by conﬁguring system settings, it is re-

ferred to as boot or logon auto-start execution. There

are many mechanisms in OSs intended for execut-

ing programs at boot or logon, including the Win-

dows registry and particular directories from which

programs are automatically run. Due to the fact that

auto-start programs often run with elevated privileges,

they may also be used for privilege escalation.

Shortcut Modiﬁcation: Creating and modifying

shortcuts resp. shell links, which are used to run a

program during system boot or user login, can be

abused to gain persistence. Shortcuts can either be

added, modiﬁed, or entirely replaced within the Win-

dows startup folder, which is executed during user lo-

gon. Shortcuts can persist through anything up to and

including updates and upgrades. The required as well

as the effective privileges for this technique vary, de-

pending on the way it is applied. Detection of shortcut

persistence is accomplished by monitoring for newly

created or modiﬁed .lnk ﬁles.

Registry Run Keys/Startup: The Windows registry

is a system-deﬁned database in which conﬁguration

data is stored by applications and system components.

Its structure is hierarchical and resembles a tree for-

mat, in which each node is a key and each key can

contain both subkeys and data entries in the form of

values. Two registry run keys are created by default,

which can be abused to register malware. The reg-

istry is a built-in system feature and, therefore, main-

tains its foothold but does not survive a re-installation.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

554

Monitoring the creation and modiﬁcation of keys in

the registry is one way to detect this method.

4 METHODOLOGY

In this section, we describe the used methodology

with the evaluation procedure (Section 4.1), methods

(Section 4.2), applied metric (Section 4.3), and limi-

tations (Section 4.4).

4.1 Evaluation Procedure

The evaluation consists of the followings steps:

1. Creation & Required Permissions: The method

establishes its foothold and its required permis-

sions are determined. As accounts can be given

a variety of different privileges, labeling them as

either user or administrator is difﬁcult. In order

to simplify the designation, the default rights ac-

counts assigned on creation are not manipulated

during the evaluation. Required permissions are

determined by trying to execute a given method,

ﬁrst with a user and then with an administrator ac-

count. After this step, the method should be ready

to establish its persistence at the next reboot or lo-

gon.

2. Afﬁrmation & Effective Permissions: In this

step, it is determined whether a method has

established its persistence. The method may ﬁrst

need to be triggered by, for example, logon, in

order to execute. Hence, determining whether a

method has gained persistence varies depending

on the mechanism. During this step, the effective

permissions will be reviewed by determining the

privileges a method uses to run itself.

3. Persistence: To determine the depth of persis-

tence we perform an action for each level of

persistence (User action: log off and on; re-

boot: restart; update: installing an OS update;

re-installation: re-installing the OS) and review

whether the method has maintained its foothold.

4. Detection: First, we observe anti-virus while exe-

cuting a method. If the software triggers an alert

or prevents the mechanism from executing, the

method is considered detected. Then, we focus

on monitoring. The logs are searched and the fol-

lowing are checked for new/modiﬁed entries: list

of all accounts, list of scheduled tasks, entries in

the two registry run keys, and both startup fold-

ers. Pre-OS changes are detected by monitoring

for changes made on pre-OS boot mechanisms.

5. Reliability: The reliability is reviewed by repeat-

edly triggering the method to produce a reliable

statement. For a reliable setting, logon/logoff-

triggered methods are executed 50 times and

reboot-triggered methods ten times.

4.2 Methods

Since we execute each method on different OSs, we

deﬁne the following standardized approach for each:

Valid Accounts: Logon to user/admin account.

Account Manipulation: Password modiﬁcation.

Account Creation: Create a new account and ele-

vate privileges.

Scheduled Task: Create a task.

Windows Services: Create a new service.

Shortcut Modiﬁcation: Create a shortcut inside the

current user resp. common startup folder.

Registry Run Keys: Add entries to the two registry

run keys.

4.3 Metric

The metric consists of the aspects of persistence,

permissions, detection, and reliability. The points

given to the different methods and categories are

in accordance with the difﬁculty, desired outcome,

and (MITRE, 2022).

Persistence: The methods are sorted into categories

(user action, reboot, update, re-installation) based on

what system changes they can withstand. User actions

summarize everything a user might do on a daily ba-

sis. User actions are the most common of all actions

to occur. Consequently, persistence methods that can-

not maintain their foothold through these are the least

useful. Points are awarded in descending order of fre-

quency of occurrence. Re-installation (RI) of the OS

is the least likely to occur in comparison to updates

(UD), reboots (RB), and user actions (UA). Follow-

ing, it is assigned 4 points, as shown in Table 1. If

a method fulﬁlls the requirements of multiple cate-

gories, it is to be placed in the highest.

Table 1: Valuation of persistence.

Persistence UA RB UD RI

Value 1 2 3 4

Permissions: Accounts can be categorized as the

user, administrator, and system. For simplicity, we

combine administrator and system. Administrator ac-

counts have higher permissions than user accounts:

Evaluation of Persistence Methods Used by Malware on Microsoft Windows Systems

555

full control of the ﬁles, directories, services, and other

resources on the local computer. Furthermore, they

are capable of managing accounts, rights, and permis-

sions. Users, on the other hand, are much more re-

stricted in their rights. Overall, the lower the required

permission is, the better for the attacker. Whereas for

effective permission the opposite is true. As a result,

the best case scenario is user → admin, and the worst

case is admin → user. The distribution of points is

accordingly and shown in Table 2.

Table 2: Valuation of required and effective permissions.

Req. vs Ef. User Admin

User 2 3

Admin 1 2

Detection: All mechanisms that are detected by pre-

installed antivirus software such as the Windows De-

fender are contained in the category of Antivirus

(AV). Monitoring (MO) is a wide category including

all checks system administrators regularly perform,

such as monitoring logs and important ﬁles. Meth-

ods that can only be detected by performing integrity

checks on pre-OS boot mechanisms are assigned to

Pre-OS (PO). All methods that cannot be assigned to

any of the previous categories are counted as Not Vi-

able (NV). Since the detection through antivirus soft-

ware requires the least effort, it should be avoided by

adversaries at all costs and, therefore, is assigned the

lowest score. Pre-OS, on the other hand, requires no-

ticeably more effort because these methods cannot be

detected by host software-based defenses. The exact

allocation of points can be found in Table 3.

Table 3: Valuation of detection.

Detection AV MO PO NV

Value 1 2 3 4

Reliability: Reliability is rated by the percentage of

successful executions. Success is when a persistence

mechanism has successfully gained persistence with-

out any undesirable side effects. If a method is ex-

ecuted ten times, a probability below 50% indicates

that fewer than ﬁve attempts are successful. This is

undesirable (0 points), as a crash may alert the sys-

tem administrator and renders the system unavailable

to the adversary. In contrast, a probability of 96–

100% gives an adversary a likely chance of success (4

points). Table 4 provides an overview of the points.

Table 4: Valuation of reliability.

Reliability <50% ≥50% >75% >95%

Value 0 1 2 3

Final Score: In the ﬁnal step, we combine the in-

dividual properties. For the sake of readability, a

denotes the points achieved in Persistence, b in Per-

mission, c in Detection, and d in Reliability. Con-

sidering that detection, permission, and reliability are

secondary goals, persistence is multiplied by three to

achieve a weighting of the primary goal. The ﬁnal

result P of a method is calculated as follows:

P = 3 · a + b + c + d (1)

The maximum score that can be achieved is 22. A

higher score indicates that a method is able to main-

tain its persistence for a longer period of time, com-

pared to methods with a lower score.

4.4 Limitations

As described, we concentrate on the most often used

methods. Nevertheless, further persistence methods

exist and can be analyzed in future work. For the prac-

tical evaluation, a simple malware with bind-shell cre-

ated by MSFvenom is used. More advanced malware,

such as those utilized by APTs, can use more sophis-

ticated methods, such as OS and application patching

or supply-chain attacks. Hence, the results may differ.

This may be evaluated in future work. In addition,

we focus on recent Windows OS. Future versions of

Windows and other OSs may result in different scores

resp. require other methods.

5 PRACTICAL EVALUATION

This section describes the practical evaluation, ﬁrst

without and then with Windows Defender software.

5.1 Setup of the Evaluation

As indicated in Section 4.4, we generate the exe-

cutable using MSFvenom. Whether the executable

is runnable is detected through netstat by verifying

the port is open. bind.exe is the malware being exe-

cuted. It needs to be placed on the system before es-

tablishing persistence. For the evaluation, we will as-

sume that the ﬁle is already on the system. The persis-

tence is evaluated by the corresponding means. The

account permissions are determined with net user

<username>. The list of all accounts is retrieved

utilizing control.exe. The task scheduler helps to

identify scheduled tasks. Registry entries are seen by

viewing the registry editor and ﬁles by the ﬁle ex-

plorer. To determine the reliability of logon/off, we

force the system into a loop of logoffs and logons.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

556

For the practical evaluation, we use virtual ma-

chines (VMs) on VMware Workstation 16 Pro 1. Be-

tween each method, the VM is reset to a base snap-

shot. All VMs have their network connection set to

Network Address Translation (NAT), which means

they share the IP address of the host system. For each

OS, the ﬁrst evaluation is without any defensive soft-

ware, in contrast to the second and last evaluations.

The defensive mechanisms include all security fea-

tures that come preinstalled with each Windows OS.

Furthermore, automatic updates are deactivated. The

two accounts User and Admin are created on this sys-

tem and the bind.exe is located in C:\.

5.2 Evaluation of Windows OSs

With the described methodology, we evaluate the fol-

lowing Windows OSs:

• Windows 10 Pro version 21H2 with KB4023057

and KB5013624 being the latest updates;

• Windows 11 Pro version 21H2 with KB5013943

and KB5013628 being the latest updates;

• Windows Server 2019 Standard Evaluation ver-

sion 1809, OS-build 17763.253;

• Windows Server 2022 Standard Evaluation ver-

sion 21H2, OS-build 20348.169.

The main difference is the stricter password policy for

Windows Server. This though does not affect the im-

plementation. All four OSs produce the same results.

As consequence, we describe the practical evaluation

for all four OS in the following.

Valid Accounts. For valid accounts, no previous ac-

cess to the system is required and the gained permis-

sions depend on the compromised account. In conse-

quence, we will differentiate between two scenarios:

in the ﬁrst, we compromise a user account, and, in the

second, we gain access to an account with admin priv-

ileges. Access to both accounts remains unchanged

up to and including Update. However, a Re-install

will cause the accounts to be removed. Log-on events

are logged by default with the event ID 4624. There-

fore, both scenarios are detected through Monitoring.

The reliability of this method is dependent on the re-

liability of the OS. The reliability of Windows 10 is

adequate, thereby both scenarios achieve 100% relia-

bility. Table 5 provides an overview of the score for

each scenario.

Account Manipulation. Changing the password of

an account does not require elevated privileges and

does not change the permissions of the account. For

Table 5: Results of Valid Accounts.

Account Type PS PM DE RE Score

User 3 2 2 3 16

Admin 3 3 2 3 17

persistence, we encounter an unusual case, since the

owner of the account would be locked out of their

account, thereby making it impossible to complete

User Action while further maintaining the persis-

tence of the adversary. Nonetheless, we will rate the

persistence with 0 points because the owner of the

account would likely initiate countermeasures such

as an account deactivation or password reset, effec-

tively undoing the adversaries’ persistence. Pass-

word changes are logged through entries with event

ID 4723, thereby being detected by monitoring. The

reliability depends on the OS the same way it was in

Valid Accounts. The full score can be seen in Table 6.

Table 6: Results of Account Manipulation.

PS PM DE RE Score

Manipulation 0 2 2 3 7

Account Creation. Creating an account is only suc-

cessful with admin rights. Nonetheless, these also

enable us to elevate the privileges of the new ac-

count, thereby achieving effective administrator per-

missions. As in Valid Accounts the persistence and

reliability are based on the basic functionality of an

account, therefore achieving the same results. Ac-

count creation can be detected through the log entries

with the event ID 4720. The full score can be seen in

Table 7.

Table 7: Results of Account Creation.

PS PM DE RE Score

Creation 3 2 2 3 16

Scheduled Task. We are required to have adminis-

trator rights in order to create a scheduled task. How-

ever, the tasks can be executed with elevated privi-

leges. A task will maintain its persistence up to and

including updates but will lose its persistence after a

re-installation. All scheduled tasks show up in the

Task Scheduler and can, consequently, be detected

through monitoring. The task maintained its persis-

tence with 100% reliability. The full score can be seen

in Table 8.

Table 8: Results of Scheduled Task.

PS PM DE RE Score

Task 3 2 2 3 16

Evaluation of Persistence Methods Used by Malware on Microsoft Windows Systems

557

Windows Services. Installing a new service re-

quires administrator privileges and the service is ex-

ecuted using the local system account, thereby main-

taining its permissions. Persistence is maintained up

to and including updates, a re-install will also remove

services installed by the user. All installed services

can be seen in the Services application and are, there-

fore, detectable by monitoring. The service main-

tained its persistence successfully throughout all ten

reboots. Table 9 provides an overview of the score.

Table 9: Results of Windows Services.

PS PM DE RE Score

Services 3 2 2 3 16

Shortcut Modiﬁcation. There are two different

start-up folders into which we can place our short-

cut, the current user and the common startup folder.

In consequence, we will be differentiating between

these two scenarios. We are able to place a shortcut

in the current user startup folder with user privileges

and into the common folder with administrator rights.

Both scenarios are unaffected by user action, reboots,

and updates. However, a reinstall will cause the con-

tents of both startup folders to be deleted. Further-

more, both scenarios are detectable through monitor-

ing because the shortcuts are visible within the folder.

Both scenarios achieved 100% reliability. The full

score can be seen in Table 10.

Table 10: Results of Shortcut Modiﬁcation.

Shortcut PS PM DE RE Score

Current User 3 2 2 3 16

Common 3 2 2 3 16

Registry Run Keys. As with Shortcut Modiﬁca-

tion, there are two different registry run keys, one spe-

ciﬁc to the current user and one common key. In con-

sequence, we will again be considering two scenarios.

Similar to shortcut modiﬁcation, the current user key

can be modiﬁed using user privileges and the common

key requires admin rights. Persistence is maintained

through user actions, reboots, and updates. Nonethe-

less, a re-install will cause a loss of persistence. Both

scenarios are detectable through the Registry Editor

and the execution of entries to both keys was 100%

reliable. An overview of the scores for both scenarios

can be seen in Table 11.

Table 11: Results of Registry Run Keys.

Key PS PM DE RE Score

HKCU 3 2 2 3 16

HKLM 3 2 2 3 16

5.3 Windows Defensive Software

On each OS, the defensive mechanisms are set up in

the same way. Without needing to start any scan,

Windows Defender identiﬁes bind.exe as malware

across all four systems. Windows Defender ﬂags the

ﬁle as malware and prevents nearly all interaction

(moving, copying, executing) with it. Shortcuts of the

ﬁle can be created. However, their functionality is

limited because the ﬁle cannot be executed. Further-

more, the ﬁle was often automatically deleted from

the OS after a short time frame. This reaction was

caused, as no defense evasion was used such as ob-

fuscation. In addition, MSFvenom is commonly used

by adversaries and is hence known by Windows De-

fender. The methods valid account, account manip-

ulation, and account creation remain unaffected by

Windows Defender since they do not use bind.exe.

All other methods (task, service, shortcut, registry)

were unable to establish persistence because they rely

on the use of bind.exe.

6 RESULTS

When comparing each method’s performance on dif-

ferent Windows OSs, no differences can be found.

This does not come as a surprise, as all methods are

core features of the Windows OS. However, a signif-

icant difference is found when comparing the perfor-

mance of each method on an unprotected versus pro-

tected version of the OS. All methods, except for the

three based on abusing accounts, were fully disabled,

since they were not capable of establishing any persis-

tence. This shows that Windows Defender is not ca-

pable of discerning normal account use and the abuse

of an account.

Most methods performed similarly. Out of ten,

eight scored equally in all aspects (16 points). Ac-

count manipulation performed signiﬁcantly worse

with seven points because even though it technically

maintains persistence, it can practically be removed.

Valid accounts for administrators performed slightly

better with 17 points since it enables privilege escala-

tion.

The similarities in each method’s persistence and

reliability likely stem from the fact that each is a sys-

tem feature speciﬁcally designed to persist on an ac-

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

558

tively used system. Hence, they should function in a

reliable way as important OS processes are often exe-

cuted through these. Since privilege escalation is not

a goal of persistence, it was to be anticipated that only

a few methods would achieve this. This may explain

why we see no method that scores at least one point

in permission. The detection results were also to be

expected because we did not try to actively hide our

actions. More advanced malware will try to hide its

activities, in order to stay undetected from Windows

Defender among others.

In consequence, the metric provides a simple mea-

sure to compare different OS versions and methods

used by adversaries. It can be applied to more ad-

vanced methods used by APTs. The results may guide

future improvements in detection methods by defen-

sive mechanisms.

7 CONCLUSION AND OUTLOOK

The ability to assess the effectiveness of methods

compared to each other enables the understanding

of the threat each method poses to IT infrastruc-

ture. Therefore, based on related work, we explained

common persistence methods for Windows OS. Then

we described our methodology with the workﬂow

and metric for evaluating persistence methods. This

methodology was applied on Windows 10, Windows

11, Windows Server 2019, and Windows Server 2022

using a bind-shell executable as exemplary malware.

The evaluation was performed without and with de-

fensive mechanisms activated. The results of the eval-

uation conclude that most methods performed very

similarly, likely due to the fact that each mechanism

abused a feature integral to the Microsoft Windows

OS. The majority of methods are capable of reliably

establishing persistence which could withstand up-

dates of the OS. Enabling Windows’ built-in defen-

sive mechanisms resulted in a signiﬁcant decline in

the performance of persistence methods. This points

to the effectiveness of current protection measures

against commonly used persistence methods.

In the next step, more complex and real-world

malware – with obfuscation methods – will be applied

and analyzed for the distribution of applied methods.

Last but not least, we plan to evaluate more as well as

combinations of methods.

REFERENCES

Barr-Smith, F., Ugarte-Pedrero, X., Graziano, M., Spolaor,

R., and Martinovic, I. Survivalism: Systematic Anal-

ysis of Windows Malware Living-Off-The-Land. In

2021 IEEE Symposium on Security and Privacy (SP),

pages 1557–1574. IEEE.

CISA (2022). Alert (AA22-074A). https://www.cisa.gov/

uscert/ncas/alerts/aa22-074a. Accessed 17.11.2022.

Dubey, L. (2019). Identifying The Malware Persistence us-

ing Advance Static And Advance Dynamic Method.

International Journal of Scientiﬁc & Technology Re-

search, 8.

Gittins, Z. and Soltys, M. (2020). Malware Persistence

Mechanisms. In 24th International Conference on

Knowledge-Based and Intelligent Information & En-

gineering Systems, pages 88–97. Elsevier.

Hunkeler, A. (2022). Collection of malware persis-

tence information. https://github.com/Karneades/

malware-persistence. Accessed 17.11.2022.

Laurenza, G., Lazzeretti, R., and Mazzotti, L. (2020). Mal-

ware Triage for Early Identiﬁcation of Advanced Per-

sistent Threat Activities. Digital Threats, 1(3).

Mankin, J. L. (2013). Classiﬁcation of malware persistence

mechanisms using low-artifact disk instrumentation.

PhD thesis, Northeastern University Boston, MA.

Microsoft (2021). Task Scheduler for developers.

https://learn.microsoft.com/en-us/windows/win32/

taskschd/task-scheduler-start-page. Accessed

17.11.2022.

MITRE (2022). MITRE ATT&ACK. https://attack.mitre.

org. Accessed 17.11.2022.

Park, D. and Yener, B. (2020). A Survey on Practical Adver-

sarial Examples for Malware Classiﬁers. In Reversing

and Offensive-Oriented Trends Symposium (ROOTS),

pages 23–35, New York, NY, USA. Association for

Computing Machinery.

Potter, S. and Nieh, J. (2005). Reducing Downtime Due

to System Maintenance and Upgrades. In 19th Large

Installation System Administration Conference (LISA

05). USENIX Association.

Rana, M. U., Ali Shah, M., and Ellahi, O. (2021). Malware

Persistence and Obfuscation: An Analysis on Con-

cealed Strategies. In 2021 26th International Confer-

ence on Automation and Computing (ICAC), number

Portsmouth, United Kingdom, pages 1–6. IEEE.

Reischaga, Lim, C., and Kotualubun, Y. S. (2020). Un-

covering Malware Traits Using Hybrid Analysis. In

Proceedings of the International Conference on Engi-

neering and Information Technology for Sustainable

Industry (ICONETSI), New York, NY, USA. Associa-

tion for Computing Machinery.

StatCounter (2022). Desktop Operating System Market

Share Worldwide – Sept 2021 - Sept 2022. https://gs.

statcounter.com/os-market-share/desktop/worldwide.

Accessed 17.11.2022.

Thomas, K., Li, F., Zand, A., Barrett, J., Ranieri, J., In-

vernizzi, L., Markov, Y., Comanescu, O., Eranti, V.,

Moscicki, A., Margolis, D., Paxson, V., and Bursztein,

E. (2017). Data Breaches, Phishing, or Malware?

Understanding the Risks of Stolen Credentials. In

Proceedings of the 2017 ACM SIGSAC Conference

on Computer and Communications Security (CCS),

pages 1421–1434. Association for Computing Ma-

chinery.

Evaluation of Persistence Methods Used by Malware on Microsoft Windows Systems

559
