Investigating the Performance of Optimization Techniques on Deep

Learning Models to Identify Dota2 Game Events

Matheus Prado Prandini Faria

, Etienne Silva Julia

, Henrique Coelho Fernandes

Marcelo Zanchetta do Nascimento

and Rita Maria Silva Julia

Computer Science Department, Federal University of Uberl

andia, Uberl

andia, Minas Gerais, Brazil

Keywords:

Deep Learning, Convolutional Neural Network, Genetic Algorithm, Bayesian Optimization, Video Games,

Game Events, Classiﬁcation, Dota2.

Abstract:

Game logs are an important part of the player experience analysis in literature. They describe the major actions

and events (related to the players or other elements) that affect the progress of a game. In most existing games

(especially popular commercial games like FIFA, Dota2 and Valorant), their access is typically restricted to the

game’s developers. Deep Learning (DL) approaches have been proposed to perform game event classiﬁcation

from videos. However, retrieving relevant information about these game events (normally associated with

actions performed by players) in real-time is still a challenge. Existing approaches require high computational

power that serves as an additional issue. In this sense, the present paper investigates a set of approaches that

aim to reduce the computational cost of DL-based models - more speciﬁcally, Convolutional Neural Networks

(CNN) based on Residual Nets architectures - through Genetic Algorithm and Bayesian Optimization. This

investigation is carried out in the context of Dota2 game event classiﬁcation. The comparative analysis showed

that the models obtained herein achieved a classiﬁcation performance as good as the models of the state-of-

the-art considering the Dota2 dataset, but with signiﬁcantly fewer parameters. Thus, this work can help in the

generation of optimized CNNs for real-time applications.

1 INTRODUCTION

Video games have become a critical part of the en-

tertainment industry, impacting the lives of billions of

people every day (Wijman, 2019). They exert wide

inﬂuence among the younger generation, whether for

the appealing side of their content or for the messages

and ideas they disseminate (Moosa et al., 2020). In

addition to being designed for fun and entertainment,

games can also be used in education, health and many

other areas. For example, to understand underlying

psychological and behavioral implications of the in-

teraction of players with this medium. This is because

video games provide extremely appropriate domains

for the occurrence of rich affective experiences mea-

surable through in-game behavior (Azadvar, 2021).

For this purpose, it is essential that developers

count on information that efﬁciently represents the

https://orcid.org/0000-0003-1468-9243

https://orcid.org/0000-0003-3750-4264

https://orcid.org/0000-0002-7078-9620

https://orcid.org/0000-0003-3537-0178

https://orcid.org/0000-0001-5181-5451

players’ experiences. This is generally achieved

through game logs, which register what the players

are doing and what is happening in the scenario. Ac-

cessing these logs traditionally requires access to the

game engine, that is, to the software-development en-

vironment used to make the game. This poses a chal-

lenge because game engines are usually inaccessible

due to the companies’ privacy concerns (Luo et al.,

2019a) and, even considering game platforms which

make available the game logs, it is not possible to

count on game information in situations in which it

must be retrieved from recorded games.

State-of-art works to derive approximated game

logs from gameplay videos rely on Deep Learning

(DL) approaches - more speciﬁcally, on Convolu-

tional Neural Network (CNN). These networks are

widely applied to video action recognition because

they present an excellent level of performance in tasks

involving visual data (He et al., 2016). For exam-

ple, (Xu et al., 2019) proposes an approach based on

CNNs and Recurrent Neural Networks (RNN) capa-

ble of encapsulating a lot of relevant functionalities

for online action detection into a single framework

(Temporal Recurrent Network), which conﬁrmed the

Faria, M., Julia, E., Fernandes, H., Zanchetta do Nascimento, M. and Julia, R.

Investigating the Performance of Optimization Techniques on Deep Learning Models to Identify Dota2 Game Events.

DOI: 10.5220/0011691800003417

In Proceedings of the 18th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2023) - Volume 4: VISAPP, pages

881-888

ISBN: 978-989-758-634-7; ISSN: 2184-4321

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

881

success of CNNs and RNNs in the task of extracting

actions from videos.

However, CNNs require a signiﬁcant amount of

computational resources considering the context of

real-time game analysis, such as online modeling the

behavior of players and identifying actions performed

in e-sport tournaments livestream (Luo et al., 2018).

In this sense, (Luo et al., 2019a) proposed some

approaches based on transfer learning and network

pruning to build accessible CNN models - in terms

of hardware - with the goal of extracting sequence of

game events from gameplay videos in real-time with

little computational resources. These models showed

a considerable reduction in training time, inference

time and memory usage of the Graphics Processing

Unit in CNNs based on the ResNet152 architecture

(He et al., 2016), while maintaining an excellent event

classiﬁcation performance on the Dota2 game.

These approaches proposed by (Luo et al., 2019a)

rely on a model pre-trained on a large and high-

quality real-world dataset. Considering the domain

of games, this limits their application to the more re-

alistic ones. As highlighted in (Luo et al., 2018), real-

world datasets - as ImageNet (Deng et al., 2009) and

UCF (Soomro et al., 2012) - do not transfer their char-

acteristics well to games with a pixelated aesthetic

(that is, games with simplistic graphics) like Super

Mario and Mega man. Thus, an existing high-quality

dataset with pixelated aspects would be required to

apply such approaches to these games, which is not

always an easy task to be performed.

Motivated by such facts, in this paper the authors

extend the approaches proposed in (Luo et al., 2019a)

by investigating the design of optimized CNN archi-

tectures for game event classiﬁcation without the use

of transfer learning techniques. This work explores

two distinct methods - a Genetic Algorithm (GA)

based one and Bayesian Optimization (BO) - in a DL

optimization framework with the aim to minimize the

number of parameters (size of weights vector) and the

classiﬁcation error of the CNN architectures.

The next sections are structured as following: sec-

tion 2 resumes the background; section 3 describes

the CNN architecture optimization; section 4 presents

the experiments and results; ﬁnally, section 5 shows

the conclusions and the future works.

2 BACKGROUND

Among the existing approaches to derive approxi-

mated game logs from video games, those based on

deep learning stand out. In (Luo et al., 2018), the

authors proposed two possible solutions for the prob-

lem of classifying events in video games (using Su-

per Mario Bros as case study). They did so by pre-

senting two possible approaches, the ﬁrst one consist-

ing on training a popular CNN detection model with

a manually labeled game dataset. This approach re-

quires a large labeled dataset, and a lot of process-

ing power in order to train the network. The second

approach utilizes a Student-Teacher technique (Wong

and Gales, 2016) to lower the amount of training data,

and processing, needed. The results obtained with it,

by training and testing a network on different games

in the same style and genre, also were not satisfactory

for the author‘s goal. However, they managed to ob-

tain solid results when applying the Student-Teacher

method with a network pre-trained on the UCF dataset

to the game Skyrim, which, in addition to having re-

alistic graphics, also was tested with the same actions

depicted in the real-world data.

In neural networks projects (covering CNNs), one

of the most important tasks is the deﬁnition of their

architectures (for example, hyperparameters such as

the number of layers and the number of neurons in

each one). Thus, due to the huge number of possible

combinations (large search space), the task of deﬁn-

ing a good architecture manually is very costly. There

are architectures studied exhaustively for visual data

classiﬁcation tasks, among them MobileNet (Howard

et al., 2017) and ResNet (He et al., 2016) stand out

(each one of them has its peculiarities). However, as

most of them are very deep in terms of the number of

layers (and consequently with a very large number of

parameters), high-performance machines are needed

to guarantee success in real-time tasks.

In this sense, there exists some approaches to re-

duce training time, execution time and memory. Prun-

ing is one of the most popular methods to reduce

network complexity (in terms of number of layers

and, consequently, number of parameters) (Han et al.,

2016). Among the main algorithms proposed in this

context, ThiNet (meaning ”Thin Net”) stands out (Luo

et al., 2017). The goal of this algorithm is to prune

the unimportant ﬁlters (without changing the original

network structure) to simultaneously accelerate and

compress CNN models in both training and test stages

with minor performance (in this case, in classiﬁcation

problems) degradation. It allows transfer tasks such

as classiﬁcation of game events to run much faster (in

both training and inference time), especially on small

devices (low-performance machines).

In (Luo et al., 2019a), the ThiNet framework is

used to compress the pre-trained ResNet152 (decreas-

ing the inference time and the memory requirements)

through the ThiNet30 (it keeps 30% of its ﬁlters),

ThiNet50 (it keeps 50% of its ﬁlters) and ThiNet70 (it

VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications

882

keeps 70% of its ﬁlters) versions of ResNet152, which

prunes 70%, 50% and 30% of the ﬁlters respectively.

The best model generated by the mentioned work was

ThiNet30. Its goal was to perform CNN optimization

for the classiﬁcation of Dota2 game events. Beside

this, recent works aim to build optimized architectures

for visual task using evolutionary techniques, high-

lighting (Faria et al., 2020) for image classiﬁcation in

FIFA (soccer simulation game). The mentioned work

proposes the Minimum Convolutional Neural Net-

work obtained by Genetic Algorithm (MCNN-GA)

method that evolves a population of CNN architec-

tures through genetic algorithm aiming to ﬁnd the one

with the best trade-off between performance classiﬁ-

cation and network accuracy.

As shown in Table 1, the present paper inves-

tigates new approaches to the Dota2 game event

classiﬁcation/identiﬁcation task (MCNN-GA and BO)

and compares with the state-of-art work (Luo et al.,

2019a), which generated ThiNet30 as the best model.

The new methods explored here do not require pre-

trained models to perform parameter optimization

(unlike ThiNet which is run on a pre-trained model).

Furthermore, the present work adds BO to the ana-

lyzed methods, which has a different nature of evolu-

tion of the MCNN-GA evaluated solutions.

3 DL OPTIMIZATION

FRAMEWORK

This section presents the framework investigated

herein to optimize DL models which identify game

events in gameplay footage. Such architecture is com-

posed of the following modules: Preprocessing Mod-

ule and Architecture Compression Methods, as shown

in Figure 1 and described in the sequence. The frame-

work receives as input a dataset of game events from

gameplay videos and aims to generate an optimized

model (in terms of classiﬁcation performance and

neural network size) for such a dataset.

3.1 Capturing Frames from the

Gameplay Footage

The required training data samples for this paper are

extracted from Dota2 gameplay videos sourced from

the main related work (Luo et al., 2019b). The sam-

ples that make up the dataset consists of individual

frames containing a single active game event (that is,

frames devoid of events or otherwise containing mul-

tiple events are discarded). 10 three second gameplay

clips were collected of each event at 30 frames per

second (FPS), which lead to a total of 9000 frames.

These data are then pre-processed (subsection 3.2) in

order to generate the dataset necessary to the execu-

tion of the experiments.

3.2 Frame Pre-Processing

The individual frames are submitted to a pre-

processing that consists on the following two phases

(following (Luo et al., 2019b)): 1) every frame is

resized from its original size to 224×224 pixels,

maintaining the RGB color channels; 2) every re-

sized frame is submitted to a pixel-wise normalization

(where the values range in the interval [0,1]).

3.3 Game Events

The dataset is composed of examples related to a

set of the following 10 game events: using Black

King Bar, using Eul’s Scepter of Divinity, using

a Glyph, Ending the game, Roshan ﬁght, using

Shiva’s Guard, activating a Shrine, team ﬁght,

teleport, and tower destruction. They will be not

described in detail here, but the authors of (Luo et al.,

2019a) ensure ”they are a mix of important events in-

volving multiple characters and individual characters

employing powerful items or abilities”. In addition,

the visual effects difference between such selected

events is highlighted, which is an important factor in

the success of CNN images classiﬁcation/recognition

approaches. It is important to note that this dataset it

completely balanced (that is, there are the same num-

ber of examples of each class/game event), which fa-

cilitates the learning process of CNN models.

3.4 Architecture Compression

Approaches

This section presents the implementation of both op-

timization approaches (MCNN-GA and BO) used in

the Architecture Compression module. Basically, it is

responsible for choosing an optimized CNN based on

the classiﬁcation performance over the input dataset

evaluating a population of individuals, which corre-

spond to solutions. The individuals and their evalua-

tion (ﬁtness) are described in the sequence. Next, the

details of MCNN-GA and BO are presented.

3.4.1 Individuals

The individuals correspond to CNN architectures. In

this work, such architectures are composed of a maxi-

mum of ten blocks (as justiﬁed in (Faria et al., 2020))

of the following types: Skip and Pooling. The Skip

Investigating the Performance of Optimization Techniques on Deep Learning Models to Identify Dota2 Game Events

883

Table 1: Parallel between the main related works and the present approach.

Approach (Luo et al., 2019a) (Faria et al., 2020) Present paper

CNN Architecture ResNet ResNet ResNet

Pre-trained Weights Yes No No

Optimization Method ThiNet MCNN-GA BO and MCNN-GA

Experiments Application Dota2 FIFA Dota2

Figure 1: General architecture of the optimization framework.

block, inspired by residual blocks, is composed of two

convolutional layers and a skip connection. This con-

nection is responsible for connecting the input X of

the ﬁrst convolutional layer (referred to as conv1) to

the output of the second convolutional layer (conv2).

If the spatial sizes of the input of conv1 and the out-

put of conv2 are different, a third convolutional layer

(conv3) is applied to the input X in order to obtain the

same spatial size as the output of conv2.

Table 2 presents the conﬁguration used in the im-

plementation of the Skip block. Note that the Filter

Size, Stride and Padding hyperparameters are repre-

sented by constant values, while Number of Filters is

the only one taken into account in the optimization

process (F1 and F2). F1 represents the number of ﬁl-

ters of the ﬁrst convolutional layer, while F2 corre-

sponds to the number of ﬁlters of the second and third

(when needed) convolutional layers. In the case of the

present work, they can assume the following values:

8, 16, 32 or 64.

Table 2: Skip block hyperparameters conﬁguration.

Number of Filters Filter Size Stride Padding

conv1 F1 3x3 1x1 same

conv2 F2 3x3 1x1 same

conv3 F2 1x1 1x1 same

The Pooling block is composed of one pooling

layer. It has the Filter Size and Stride hyperparam-

eters values equal to 2x2. Thus, the only hyperparam-

eter taken into account in the optimization process is

the pooling operation type, which can be max pooling

or average pooling.

All the constant values of the aforementioned hy-

perparameters were retrieved from (Faria et al., 2020).

3.4.2 Fitness Function

The ﬁtness function indicates how well an individual

(representing a solution candidate) is able to solve the

optimization problem. In the case of this work, the

evaluation of this function is based on the combina-

tion of the classiﬁcation performance (in terms of the

model error) and the architecture size (in terms of the

number of parameters or vector of weights).

In this way, the CNN architecture of an individ-

ual is generated from its respective list of blocks (skip

or pooling). Throughout this generating process, the

batch normalization layer followed by the ReLu ac-

tivation function is added to the output of each con-

volutional layer in the skip blocks. After all blocks

are decoded, a fully connected - representing the out-

put layer implemented with the softmax classiﬁer - is

added to the end of such an architecture. The number

of neurons in the output layer is determined by the

number of game events of the given dataset.

With the CNN model generated, the data is di-

vided into training and testing sets using the hold-

out method in a way that the examples from the input

dataset are distributed in the same proportion in each

of these sets. It is initialized with random parame-

ters (weight vectors), trained with the training data

for ten epochs (considering the Categorical Cross En-

tropy loss function), and evaluated with the test data.

The evaluation of an individual corresponds to a lin-

ear combination between two terms deﬁned by Equa-

tion 1, FT

and FT

. The former represents the ﬁt-

ness relative to the number of parameters of the CNN

model while the latter corresponds to its classiﬁcation

performance (concerning the test examples). Thus, F

(ﬁtness function) is a minimization problem with re-

spect to the aforementioned terms.

F = min(FT

+ FT

) (1)

VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications

884

Fitness Term (FT

): it represents the evaluation of

the CNN architecture in terms of its size (i.e. the

number of parameters or size of the weight vec-

tor). The largest model that can be generated in

the case of this work is composed of a total of

3,474,500 parameters, since in the worst case the

architecture will have 10 skip blocks with values

of F1 and F2 equal to 64 (the largest value among

those deﬁned for the number of ﬁlters). Thus, the

smaller the size of the model, the better the evalu-

ation of FT

. Importantly, this value is normalized

in the range [0,1].

Fitness Term (FT

): it corresponds to the perfor-

mance of the CNN architecture in terms of its

classiﬁcation error. After the CNN model is

trained with the training data, its error based on

the Categorical Cross Entropy loss function over

the test data is calculated, FT

. Thus, it can be

stated that this term will have a good value when

the test error is low, that is, when the architecture

is robust in handling data from the given dataset.

The value of FT

is also normalized in the range

[0,1] just like FT

3.4.3 Minimum CNN-GA (MCNN-GA)

Basically, the MCNN-GA tries to ﬁnd the best CNN

architecture to classify an image classiﬁcation data set

through an evolutionary process consisting of the fol-

lowing steps: 1) Initialization of an arbitrary popula-

tion; 2) Evaluation of individuals’ ﬁtness; 3) Genera-

tion of the offspring; 4) Environmental selection.

The ﬁrst two steps were previously explained in

subsections 3.4.1 and 3.4.2 respectively. The third

step is performed using binary tournament (Miller

et al., 1995) to select parent individuals and apply-

ing the one-point crossover operation (Srinivas and

Patnaik, 1994) over each pair of selected parents to

generate the offspring. Then, these children can be

mutated through the following operations: 1) Adding

a Skip block randomly; 2) Adding a Pooling block

randomly; 3) Removing a block randomly; 4) Mod-

ifying a block conﬁguration (hyperparameters) ran-

domly. The children are also limited to the number

of ten blocks (excluding the output layer) in order

to maintain the algorithm consistency. Finally, the

fourth step is carried out by combining the binary

tournament and an elitist strategy. The best individ-

ual is automatically placed in the next population and

the others are selected through binary tournament.

3.4.4 Bayesian Optimization (BO)

BO tries to ﬁnd the best CNN architecture to clas-

sify an image classiﬁcation data set through a method

known as surrogate optimization, that is, it models

an approximation of the objective function (which is

usually completely unknown) based on the following

steps: 1) Sampling of random individuals; 2) Train-

ing a gaussian process; 3) Computing an acquisition

function; 4) Generating a new solution (individual).

The ﬁrst step was previously explained in subsec-

tions 3.4.1 and 3.4.2. It generates 10 random individ-

uals (with arbitrary architectures) and performs their

evaluation creating some observations of the objec-

tive function (in this case, this function maps the pa-

rameter set x ﬁtness relationship). From this, the sec-

ond step involves building and training a probabilistic

surrogate model of the objective function (typically a

Gaussian Process). The idea behind it is that the more

points (individuals) that are generated, the better the

approximation of the surrogate model with the objec-

tive function. The third step is performed computing

the acquisition function, which drives the proposition

of new potential points to test, in an exploration and

exploitation trade-off. This work used the Expected

Improvement based method, which is one of the most

widely used acquisition functions for BO (Mockus

and Mockus, 1991). Finally, the fourth step corre-

sponds to generating and evaluating the best potential

point found from the acquisition function. This entire

process is carried out until N individuals are evalu-

ated (it should be noted that at some point this method

can reach convergence, that is, it always generates the

same point/individual to be evaluated).

4 EXPERIMENTS AND RESULTS

The experiments performed here are primarily aimed

at validating the use of MCNN-GA and BO methods

(Architecture Compression Methods) in the process of

automatically building optimized CNN architectures

and comparing, in the context of Dota2 game events,

with the ThiNet technique used by (Luo et al., 2019a).

Thus, in a ﬁrst step, an evaluation and comparison

is performed between the two methods explored here

(Experiment 1). Then, another comparative analysis

is performed on the method with the best results ob-

tained in the ﬁrst experiment with respect to the best

state-of-the-art method, ThiNet (Experiment 2). The

parameters used to validate such comparisons are the

classiﬁcation performance, memory and time. The

independent-samples t-test (t-test) (Coleman, 2009) is

used to verify if there is a superiority in terms of per-

formance between the different methods compared.

In this sense, subsection 4.1 describes all the ex-

perimental conﬁgurations used in this work, subsec-

tion 4.2 brieﬂy comments the evaluative parameters.

Investigating the Performance of Optimization Techniques on Deep Learning Models to Identify Dota2 Game Events

885

Finally, subsections 4.3 and 4.4 present the results of

the Experiment 1 and Experiment 2 respectively.

4.1 General Experimental

Conﬁgurations

The experimental conﬁgurations used in this paper

(and also retrieved from (Luo et al., 2019b)), are de-

scribed below:

• Size of Input Images: 224x224x3.

• Input Data Normalization: pixel-wise pixel nor-

malization (that is, the pixel values are in the

range between zero and one).

• Number of Training Epochs: 10 (the best epoch

in terms of validation loss represents the ﬁnal

model parameters/weights).

• Optimizer: Adam.

• Learning Rate: 0.001.

• Loss Function: Cross-Entropy.

• Output Activation: Softmax.

• Split Method: Holdout (80% of training data and

20% of test data). It is noteworthy here that the

game events are evenly distributed between the

two sets (that is, 80% of examples of each class

is related to training data and 20% to test data).

• Number of Examples - Dota2 Dataset: 9.000

(7.200 training data examples and 1.800 test data

examples).

Since the technique for splitting the data is simple

holdout, 10 runs were performed for each method to

allow evaluation of statistical tests on the results in all

experiments. In each run of each method, exactly the

same examples were used in the training and test sets

(i.e., using the same random seed value for splitting

the data), which means the performance comparison

is independent of the potential issue of data distribu-

tion, as done in (Luo et al., 2019a). Finally, the exper-

iments were executed in an architecture composed by

a machine with a Tesla K80 GPU and 16 GB RAM

4.2 Evaluative Parameters

The parameters used to evaluate and compare all the

methods investigated in this work are presented in the

sequence.

• Accuracy: classiﬁcation performance parameter

that represents the rate of correct inferences of the

https://github.com/matheusprandini/

dota2-cnn-optimization

model (CNN architecture) over the total number

of examples in the test set.

• Loss: classiﬁcation performance parameter that

corresponds to the model error based on the value

of the loss function (in this case, Categorical

Cross Entropy) in the test set.

• Size: memory parameter that measures the size

of the model in terms of its number of parameters

(weight vector dimension).

• Inference Time: parameter that represents the

time (in seconds) it takes for the trained model to

make predictions for all examples in the test set.

• Execution Time: parameter that represents the

time (in minutes) that the method takes to gen-

erate the CNN model.

• Fitness: corresponds to the evaluation value of

the best individual (CNN model) found (used only

in the MCNN-GA and BO methods).

4.3 Experiment 1 - Comparing

MCNN-GA and BO Methods

Performance

The intention of this experiment was to validate and

compare the performance of MCNN-GA and BO on

the construction of optimized CNN models. The ex-

ecution parameters for the MCNN-GA are shown in

Table 3: population size equal to 10; number of gen-

erations equal to 10; probability of an individual per-

forming the crossover operation equal to 0.8; and,

probability of an individual performing the mutation

operation equal to 0.2. This means that a maximum

of 220 individuals will be evaluated (20 initial indi-

viduals plus 20 offspring individuals in each of 10

generations). Then, to maintain the fairness of this

comparative analysis, the BO method was also set up

to evaluate a maximum of 220 individuals.

Table 3: MCNN-GA Execution Parameters.

Population Size 10

Number of Generations 10

Individual Crossover Rate 0,8

Individual Mutation Rate 0,2

Table 4 summarizes the mean value of the eval-

uative parameters for best individuals found through

these two approaches over 10 runs. They indicate su-

perior performance of MCNN-GA over BO overall. In

terms of classiﬁcation, the former obtained a mean

accuracy rate and a mean loss value, respectively,

of 0.3% higher and 0.07 lower than the latter. Re-

garding the mean CNN network size, the evolution-

VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications

886

ary method generated lighter architectures by approx-

imately 57%. Hence, this was reﬂected in the differ-

ence in the ﬁtness value. There was no difference in

the inference time, but the MCNN-GA execution time

was, on average, 2.5 hours longer than the BO. A t-test

with a signiﬁcance level (α = 0.05) was conducted to

validate the performance comparison.

Table 4: BO and MCNN-GA comparison results (mean

value).

Accuracy Loss Size

Inference

Time

Execution

Time

Fitness

BO 99.05 0.169 80994.0 5.4 481.0 0.01445

MCNN-GA 99.35 0.099 35026.0 5.4 637.0 0.00864

The t-test computes the following main values: t-

statistic value (t-value) and p-value. The former in-

dicates the actual t-test result and the direction of the

difference (if any). The latter represents the signiﬁ-

cance value of the test. In this manner, the following

was created: BO holds the same level of perfor-

mance as MCNN-GA.

As Table 5 states, the BO and MCNN-GA meth-

ods performed equally well only for the inference

time parameter. In terms of the classiﬁcation qual-

ity parameters (accuracy and loss) and size of the

generated model, a superiority of MCNN-GA can be

noted. While BO had a signiﬁcantly lower execu-

tion time. The authors believe that the faster con-

vergence of the solutions generated by BO is because

it evaluates a smaller number of individuals to ﬁnd

an optimized CNN for the input dataset than MCNN-

GA. However, since BO generates a single solution

at a time, it analyzes a smaller diversity than MCNN-

GA which keeps several points scattered in the search

space. This indicates that although the MCNN-GA

method takes longer (which is its main limitation) to

return an optimized solution, it generates lighter neu-

ral networks with higher classiﬁcation efﬁciency than

BO with a 95% conﬁdence interval for the mean dif-

ference. Therefore, it is concluded that MCNN-GA

outperformed BO in Dota2 dataset.

4.4 Experiment 2 - Comparing

MCNN-GA and ThiNet30 Methods

Performance

The ﬁrst experiment proved the performance superi-

ority of the models generated from MCNN-GA against

BO. Then, in this second experiment, the best method

investigated in the latter experiment (MCNN-GA) is

confronted with the best method (ThiNet30) obtained

in the state-of-art considering the Dota2 dataset. It is

important to highlight that ThiNet30 is implemented

an trained as described in (Luo et al., 2019a).

Table 6 shows the mean results of these methods

through 10 runs (the results of MCNN-GA were trans-

posed from Table 4). They indicate a slight classi-

ﬁcation performance superiority of MCNN-GA over

ThiNet30 (0.25% for accuracy and 0.014 for loss).

Regarding the mean CNN network size, the evolu-

tionary method generated lighter architectures by ap-

proximately 95%. In terms of inference time, MCNN-

GA also had a 1.1 seconds advantage over ThiNet30.

The execution time and ﬁtness parameters were not

computed since the ThiNet method does not involve

generating different architectures to obtain the opti-

mal model (it only applies the reduction of the num-

ber of ﬁlters in the original convolutional layers of

ResNet152 as previously explained in section 2).

An independent-samples t-test with a signiﬁcance

level (α = 0.05) was conducted to validate this com-

parative analysis as shown in Table 7. The null hy-

pothesis (H

) stated that MCNN-GA holds the same

level of performance as ThiNet30.

The positive accuracy t-value (1.983) and nega-

tive loss t-value (-1.199) suggest a slight superiority

of MCNN-GA over ThiNet30 in terms of classiﬁcation

performance. However, since the p-value of accu-

racy and loss are 0.062 and 0.245, respectively (values

greater than the α = 0.05 designated for the statistical

test), the null hypothesis cannot be rejected. Thus,

both methods are considered to have the same qual-

ity in the task of classiﬁcation/identiﬁcation of game

events (with respect to the Dota2 dataset).

Regarding the network size and inference time,

MCNN-GA generated signiﬁcantly better results than

ThiNet30 (since the p-value for both parameters are

smaller than α with a 95% conﬁdence interval). So,

it is concluded that despite presenting the same clas-

siﬁcation performance, the former brings the advan-

tage of generating much lighter networks with faster

data inference time than the latter. These results indi-

cate that the best models generated by MCNN-GA are

more suitable considering a real-time setting. This

is because the depth of the models (number of lay-

ers) generated by this method is smaller than that

of ThiNet30 (and consequently ResNet152), which

speeds up the prediction phase.

5 CONCLUSION AND FUTURE

WORKS

This work investigated two different approaches (one

based on genetic algorithm and the other based on

bayesian optimization) in order to generate CNNs op-

timized in terms of classiﬁcation performance and

network size without the need to rely on pre-trained

Investigating the Performance of Optimization Techniques on Deep Learning Models to Identify Dota2 Game Events

887

Table 5: T-test applied to the results between methods BO and MCNN-GA.

Accuracy Loss Size

Inference

Time

Execution

Time

Fitness

t-value p-value t-value p-value t-value p-value t-value p-value t-value p-value t-value p-value

-3.125 0.006 3.048 0.007 4.455 0.0003 0.0 1.0 -3.966 0.001 5.596 0.00003

Table 6: MCNN-GA and ThiNet30 comparison results

(mean value).

Method Accuracy Loss Size Inference Time

MCNN-GA 99.35 0.099 35026.0 5.4

ThiNet30 99.10 0.113 6700576 6.5

Table 7: T-test applied to the results between methods

MCNN-GA and ThiNet30.

Accuracy Loss Size

Inference

Time

t-value p-value t-value p-value t-value p-value t-value p-value

1.983 0.062 -1.199 0.245 -9968.12 0 -5.312 0.00004

networks. The case study used to validate the analysis

was the Dota2 game event dataset. The results showed

that MCNN-GA generated CNNs which achieved a

classiﬁcation performance as good as the best model

produced in (Luo et al., 2019a) (ThiNet30), but with

signiﬁcantly fewer parameters (resulting in models

with less memory usage). It means that MCNN-GA

have a great potential to generate highly efﬁcient and

suitable models for real-time applications (which can

be transferable to domains beyond games), which

helps in hardware accessibility for complex tasks.

As future works, the authors intend: to investi-

gate the performance of the approaches studied here

for different types of games (simpler 2D games like

Super Mario Bros and more realistic 3D games like

Skyrim); to publish the framework investigated here

for the community’s use; and, ﬁnally, to use such ap-

proaches to build real-time mechanisms that can help

people with cognitive difﬁculties.

REFERENCES

Azadvar, A. (2021). Predictive psychological player proﬁl-

ing.

Coleman, A. M. (2009). A dictionary of psychology / An-

drew M. Colman. Oxford University Press Oxford ;

New York, 3rd ed. edition.

Deng, J., Dong, W., Socher, R., Li, L.-J., Li, K., and Fei-Fei,

L. (2009). Imagenet: A large-scale hierarchical image

database. In 2009 IEEE conference on computer vi-

sion and pattern recognition, pages 248–255.

Faria, M. P. P., Julia, R. M. S., and Tomaz, L. B. P.

(2020). Improving ﬁfa player agents decision-making

architectures based on convolutional neural networks

through evolutionary techniques. In Cerri, R. and

Prati, R. C., editors, Intelligent Systems, pages 371–

386, Cham. Springer International Publishing.

Han, S., Mao, H., and Dally, W. J. (2016). Deep compres-

sion: Compressing deep neural network with pruning,

trained quantization and huffman coding. In 4th Inter-

national Conference on Learning Representations.

He, K., Zhang, X., Ren, S., and Sun, J. (2016). Deep resid-

ual learning for image recognition. In Proceedings of

the IEEE Conference on Computer Vision and Pattern

Recognition (CVPR).

Howard, A. G., Zhu, M., Chen, B., Kalenichenko, D.,

Wang, W., Weyand, T., Andreetto, M., and Adam,

H. (2017). Mobilenets: Efﬁcient convolutional neu-

ral networks for mobile vision applications.

Luo, J.-H., Wu, J., and Lin, W. (2017). Thinet: A ﬁlter level

pruning method for deep neural network compression.

In 2017 IEEE International Conference on Computer

Vision (ICCV), pages 5068–5076.

Luo, Z., Guzdial, M., Liao, N., and Riedl, M. (2018). Player

experience extraction from gameplay video. CoRR,

abs/1809.06201.

Luo, Z., Guzdial, M., and Riedl, M. (2019a). Making cnns

for video parsing accessible. CoRR, abs/1906.11877.

Luo, Z., Guzdial, M., and Riedl, M. (2019b). Making

cnns for video parsing accessible: Event extraction

from dota2 gameplay video using transfer, zero-shot,

and network pruning. In Proceedings of the 14th In-

ternational Conference on the Foundations of Digital

Games, FDG ’19, New York, NY, USA. Association

for Computing Machinery.

Miller, B. L., Miller, B. L., Goldberg, D. E., and Gold-

berg, D. E. (1995). Genetic algorithms, tournament

selection, and the effects of noise. Complex Systems,

9:193–212.

Mockus, J. B. and Mockus, L. J. (1991). Bayesian ap-

proach to global optimization and application to mul-

tiobjective and constrained problems. J. Optim. The-

ory Appl., 70(1):157–172.

Moosa, A. M., Al-Maadeed, N., Saleh, M., Al-Maadeed,

S. A., and Aljaam, J. M. (2020). Designing a mobile

serious game for raising awareness of diabetic chil-

dren. IEEE Access, 8:222876–222889.

Soomro, K., Zamir, A., and Shah, M. (2012). Ucf101: A

dataset of 101 human actions classes from videos in

the wild. CoRR.

Srinivas, M. and Patnaik, L. M. (1994). Genetic algorithms:

a survey. Computer, 27:17–26.

Wijman, T. (2019). The global games market will generate

$152.1 billion in 2019 as the u.s. overtakes china as

the biggest market.

Wong, J. and Gales, M. (2016). Sequence student-teacher

training of deep neural networks. pages 2761–2765.

Xu, M., Gao, M., Chen, Y.-T., Davis, L. S., and Crandall,

D. J. (2019). Temporal recurrent networks for online

action detection.

VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications

888
