SWaTEval: An Evaluation Framework for Stateful Web Application

Testing

Anne Borcherding

1,3 a

, Nikolay Penkov

1 b

, Mark Giraud

1 c

and J

urgen Beyerer

1,2,3

Fraunhofer Institute of Optronics, System Technologies and Image Exploitation IOSB, Karlsruhe, Germany

Vision and Fusion Laboratory (IES), Karlsruhe Institute of Technology (KIT), Karlsruhe, Germany

KASTEL Security Research Labs, Karlsruhe, Germany

Keywords:

Web Application Testing, Stateful Testing, Blackbox Testing, State Machine Inference, Fuzzing, Clustering.

Abstract:

Web applications are an easily accessible and valuable target for attackers. Therefore, web applications need

to be examined for vulnerabilities. Modern web applications usually behave in a stateful manner and hence

have an underlying state machine that determines their behavior based on the current state. To thoroughly test

a web application, it is necessary to consider all aspects of a web application, including its internal states. In

a blackbox setting, which we presuppose for this work, however, the internal state machine must be inferred

before it can be used for testing. For state machine inference it is necessary to choose a similarity measure

for web pages. Some approaches for automated blackbox stateful testing for web applications have already

been proposed. It is, however, unclear how these approaches perform in comparison. We therefore present

our evaluation framework for stateful web application testing, SWaTEval. In our evaluation, we show that

SWaTEval is able to reproduce evaluation results from literature, demonstrating that SWaTEval is suitable for

conducting meaningful evaluations. Further, we use SWaTEval to evaluate various approaches to similarity

measures for web pages, including a new method based on the euclidean distance that we propose in this

paper. These similarity measures are an important part of the automated state machine inference necessary for

stateful blackbox testing. We show that the choice of similarity measure has an impact on the performance of

the state machine inference regarding the number of correctly identiﬁed states, and that our newly proposed

similarity measure leads to the highest number of correctly identiﬁed states.

1 INTRODUCTION

With the widespread use of Web Applications (WAs),

it is necessary to expose and eliminate as many vul-

nerabilities in WAs as possible to ensure a minimal at-

tack surface. This applies to WAs such as web shops

as well as WAs provided by industrial devices for

monitoring and conﬁguration purposes. Especially

for these industrial settings, a thorough test for vul-

nerabilities is necessary, since a successful attack on

the WA can lead to a production stop or even physi-

cal harm (Pfrang et al., 2019). Stateful blackbox WA

testing is crucial to a thorough test. In blackbox tests,

information regarding the internals of the tested WA is

unavailable. Stateful refers to tests that take the inter-

nal state of the WA into consideration. This provides

https://orcid.org/0000-0002-8144-2382

https://orcid.org/0000-0002-5421-4253

https://orcid.org/0000-0002-2972-2758

the possibility to conduct tests in an efﬁcient and pur-

poseful way (Doup

e et al., 2012). As previously men-

tioned, however, a blackbox setting does not provide

explicit information about the internal state machine

of the WA. As a consequence, identifying the under-

lying state machine of the WA by different means is

inevitable in a blackbox setting.

Various approaches to automatic state machine in-

ference exist in the literature. For example, Raffelt

et al.(Raffelt et al., 2005) suggest a general automata

learning approach, while Doup

e et al.(Doup

e et al.,

2012) propose a method for a WA-speciﬁc state in-

ference. In general, the state machine of a WA is

learned by looking for changes in the behavior of the

WA when it is provided with different inputs. To iden-

tify changes in the behavior of the WA, we measure

the similarity between the web pages presented by a

WA with the help of a similarity measure. With this,

we can determine whether the internal state of the WA

has changed and what caused the state transition.

430

Borcherding, A., Penkov, N., Giraud, M. and Beyerer, J.

SWaTEval: An Evaluation Framework for Stateful Web Application Testing.

DOI: 10.5220/0011652200003405

In Proceedings of the 9th International Conference on Information Systems Security and Privacy (ICISSP 2023), pages 430-441

ISBN: 978-989-758-624-8; ISSN: 2184-4356

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

The aforementioned challenges can be solved with

a set of different approaches. To evaluate the ap-

proaches in an individual or a combined manner, a

modular framework is necessary. Moreover, an easily

understandable Evaluation Target is needed to deter-

mine the performance and impact of the approaches.

The contribution of our work to the domain of

Stateful Web Application Testing (SWAT) can be

summarized as follows:

• We design and implement a modular framework

(SWaTEval) to analyze different approaches for

the multitude of challenges of stateful WA testing

• We design and implement a manageable and state-

ful Evaluation Target

• We implement various detection approaches with

the help of various similarity measures and evalu-

ate them using SWaTEval

Our evaluation is twofold. On the one hand, we

perform a qualitative and quantitative evaluation of

SWaTEval itself. This includes reproducing of re-

sults presented by a large study in literature (Yandra-

pally et al., 2020). We show that the results produced

with SWaTEval are coherent with the results from this

study, suggesting that SWaTEval produces meaning-

ful results. On the other hand, we use SWaTEval to

perform a new evaluation regarding the choice of sim-

ilarity measure for stateful blackbox WA testing. We

show that the choice of similarity measure has an im-

pact on the state machine inference and that the sim-

ilarity measure based on the euclidean distance leads

to the best results.

2 BACKGROUND

State-awareness is generally needed to maximize test

coverage of a WA (Doup

e et al., 2012). Behind the re-

quirement to perform state-aware testing lies the fol-

lowing intuition: If a testing tool is unaware of the ex-

isting states, it might skip some of them while testing

and fail to reveal vulnerabilities in the missed states.

This is true for different meanings of the word state

in literature. Similar to Doup

e et al., we consider the

WA state as the underlying internal state. For exam-

ple, the WA’s internal state for an authenticated user

usually differs from that of a non-authenticated user.

In contrast, the general case of the WA showing differ-

ent pages to the user does not correspond to different

internal states. In the following, we will always refer

to the internal state of the WA when using state.

Additionally, we use the following terminology.

The target that should be testend and is used for our

evaluation is a WA in its full form and functionality.

We refer to it as Evaluation Target or simply target.

A WA consists of various web pages like a login page,

or a register page. Endpoints expose functionality

and allow communication with a WA. Generally, they

point to web pages of a WA.

Since a blackbox WA does not reveal information

about its internals directly, we need to infer the under-

lying state machine by communicating with the WA.

There are various approaches to learn a state machine

in a blackbox setting (e.g. (Raffelt et al., 2005; Doup

et al., 2012)). Most of them are based on the assump-

tion that a state transition is present if a request on

an Endpoint returns a response that is different from

previously observed responses to the same request on

the same Endpoint. We call a request-response pair

an Interaction with the WA.

In general, it is necessary to decide which End-

points of the WA should be tested. Similar Endpoints

have to be clustered properly and omitted. For this,

a method for clustering of similar Endpoints is nec-

essary. Lastly, the inferred state machine has to be

pruned by detecting similar states and merging them.

Summarized, the process of automatically learn-

ing the state machine of a WA in a blackbox setting

consists of the following challenges: (I) cluster sim-

ilar Endpoints, (II) detect a state change, and (III)

cluster similar states (Doup

e et al., 2012). Various

approaches can be used for each of these challenges,

which we discuss in more detail in Section 5.2. Es-

pecially, different approaches can be taken to de-

ﬁne the distance between two Endpoints or states (or

their similarity). To understand the impact of these

choices, an evaluation framework for SWAT is nec-

essary. This framework needs to focus on the state

detection capabilities and provide an Evaluation Tar-

get with manageable complexity. In this work, we

present SWaTEval, which aims to fulﬁll the need for

a general evaluation framework for SWAT.

3 RELATED WORK

Our work is located in the domain of SWAT while

also focussing on similarity measures for web pages.

The following paragraphs give an overview of related

work in these two areas.

Stateful Testing of Web Applications. SWAT is a

topic that has been around for some time and is, nev-

ertheless, still relevant. Doup

e et al. proposed a ﬁrst

approach to include the underlying state of the tested

WA into testing and fuzzing (Doup

e et al., 2012).

However, the authors chose a non-modular approach

for their implementation, and their approach has not

SWaTEval: An Evaluation Framework for Stateful Web Application Testing

431

yet been compared to other approaches that include

the underlying state. Since then, various approaches

for stateful WA testing and crawling have been pro-

posed, for which Hassanshahi et al. provide a recent

overview (Hassanshahi et al., 2022). Moreover, a re-

cent work proposes a framework for SWAT (Drakon-

akis et al., 2020), but it only focuses on a single part

of SWAT, namely authentication and authorization.

To our knowledge, there is no work besides ours that

aims to provide a modular framework to evaluate dif-

ferent aspects of the SWAT process.

Several intentionally vulnerable WAs and bench-

marks exist that can be used as evaluation targets

for the evaluation of WA testing. Some of the most

prominent ones are WackoPicko (Doup

e et al., 2010),

JuiceShop

, XVWA

, DVWA

, and OWASP Bench-

mark

. These evaluation targets mainly focus on the

vulnerabilities that a test might ﬁnd. Although the

discovery rate of these vulnerabilities can be used as

an overall performance metric, a more speciﬁc evalu-

ation target is necessary to understand the impact of

stateful testing methods on the test performance. For

this, it is particularly important that the state machine

of the target is known and manageable in size.

There are several works focusing on different as-

pects of WA testing that are orthogonal to our ap-

proach. Borcherding et al. present an approach to im-

prove the performance of WA fuzzers transparently by

injecting additional information to the fuzzer’s traf-

ﬁc using a proxy (Borcherding et al., 2020). We use

a similar approach to provide an interface for exist-

ing fuzzers in SWaTEval. Li et al. present an ap-

proach to test stateful web services based on a state

machine. They derive the state machine from a spec-

iﬁcation of the web service provided in the Web Ser-

vices Description Language (Li et al., 2018). In con-

trast, we build a state machine of the underlying WA

based on the blackbox HTTP communication with the

WA itself. Other approaches focus on stateful testing

of the network protocol implementation itself (Aich-

ernig et al., 2021; Pferscher and Aichernig, 2022).

In contrast, our work focuses on testing the interface

with which a user interacts directly. In contrast to

the blackbox testing used in this work, another ap-

proach to dynamic testing is to conduct gray-box test-

ing, which requires additional information about the

WA under test (Gauthier et al., 2021).

Similarity of Web Pages. As mentioned in Sec-

tion 1, it is essential to calculate the distance (or

https://github.com/juice-shop/juice-shop

https://github.com/s4n7h0/xvwa

https://github.com/digininja/DVWA

https://owasp.org/www-project-benchmark/

similarity) between two web pages when performing

SWAT. Since we focus our evaluation on similarity

measures, we give a short overview of related work

in this paragraph. Lin et al. propose a similarity

measure based on the similarity of links on the web

pages (Lin et al., 2006). Other works apply the Lev-

enshtein distance to calculate the distance between

two web pages (Popescu and Nicolae, 2014; Mesbah

et al., 2008). In contrast, Doup

e et al. use a distance

metric based on a preﬁx tree (Doup

e et al., 2012).

More recent works propose to measure the similar-

ity between web pages by using their content, such

as input ﬁelds (Lin et al., 2017), or buttons, anchors,

and images (Alidoosti et al., 2019). Yandrapally et al.

present an extensive study on the performance of dif-

ferent similarity measures based on various real world

WAs and nine open source WAs (Yandrapally et al.,

2020). Note that the understanding of state used by

Yandrapally et al. is different compared to ours. We

consider the internal state of the WA, similar to Doup

et al. (see Section 2). In contrast, Yandrapally et al.

consider the dynamic webpage of the WA as the state.

Nevertheless, the concepts of web page similarity de-

scribed by Yandrapally et al. can be directly trans-

ferred to our work, and we use the results of their ex-

tensive work for comparison purposes in Section 6.2.

Oliver et al. present a method for generation of

a locality-sensitive hash called Trend Micro Locality

Sensitive Hash (TLSH) (Oliver et al., 2013). When

calculating the TLSH of an input, small changes in the

input lead to small changes in the output hash. This

property is beneﬁcial since it provides a method to

represent data in a compressed way. Moreover, it al-

lows the calculation of meaningful distances between

data which is represented in this fashion. Oliver et al.

deﬁne a distance measure on TLSH which approxi-

mates the hamming distance. We choose TLSH and

the corresponding distance measure (TLSH Score) as

one of the possibilities to represent web pages and cal-

culate similarities (see section 5.2).

4 FUNDAMENTALS

As a basis for the following sections, we present our

research goals, our methodology, and the require-

ments we used for our approach in the following sub-

sections.

4.1 Research Statements

With our research, we aim to (I) design and imple-

ment an evaluation framework for SWAT and (II) con-

duct an evaluation and analysis of the different simi-

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

432

larity measures and thus also verify the usefulness of

SWaTEval regarding its evaluation capabilities. We

formulate the following two research questions.

RQ1: Can we reproduce the results of Yandrapally

et al. by using SWaTEval?

RQ2: How do the different approaches for page sim-

ilarity measurement inﬂuence the number of

correctly detected states?

RQ3: Which combination of similarity measures per-

forms better in terms of the number of correctly

detected states?

4.2 Methodology

To achieve our previously stated research goals, we

ﬁrst infer requirements from literature and formu-

late our requirements for a framework for the eval-

uation of SWAT. Afterwards, we design and imple-

ment a framework that meets these requirements. Fi-

nally, we evaluate our resulting framework qualita-

tively by using two different approaches. On the one

hand, we evaluate SWaTEval by using it to reproduce

the results of Yandrapally et al. (Yandrapally et al.,

2020). We thus show that SWaTEval is suited to pro-

duce meaningful results. On the other hand, we use

SWaTEval to evaluate different web page similarity

measures. We show thus that SWaTEval can success-

fully be used to conduct evaluations in the domain of

SWAT and that the similarity measure based on the

Euclidean distance performs best.

4.3 Requirements

As a basis for our design and implementation, we

gathered requirements for an evaluation framework

by investigating existing work. We used insights from

Doup

e et al. (Doup

e et al., 2012) and Hassanshahi

et al. (Hassanshahi et al., 2022) as well as our own

analysis of existing tools and frameworks. In the fol-

lowing, we present the resulting requirements for the

framework (FR) and the Evaluation Target (TR).

FR1 Modularity: The state machine inference and

testing approaches are modular and can easily

be modiﬁed or replaced.

FR2 Interaction: The crawling and fuzzing of the

framework can work in an interlaced fashion.

FR3 Traceability: All generated data can be traced

back and reproduced easily.

TR1 Similar Pages: The Evaluation Target has sim-

ilar (but not equivalent) web pages that should

be treated as the same web page.

Database Module

Fuzzer

Crawler 3

Detector

Worker

Figure 1: Overview of SWaTEval showing a modular ap-

proach regarding the Modules and the execution logic. The

Modules are run in the order given by the numbers.

TR2 Different Pages: The Evaluation Target has

web pages that are signiﬁcantly different and

should be treated as different web pages.

TR3 Statefulness: The Evaluation Target provides

the possibility to change its underlying state.

TR4 Complexity: The state machine is understand-

able and manageable by humans.

5 APPROACH

In this section, we present the approach and the

technical details for SWaTEval. First, we give an

overview of the framework and the used Modules. We

then present the various Modules of SWaTEval in fur-

ther detail. This includes a description of the new

similarity measure we present in this work. At last,

we describe the features and details of the Evaluation

Target.

5.1 SWaTEval

We applied the four principles of object-oriented pro-

gramming: encapsulation, abstraction, inheritance,

and polymorphism. The result is a compact frame-

work that avoids tight coupling, but allows compound

conﬁgurations with interchangeable Modules.

5.1.1 Overview

As shown in Figure 1,the Modules of SWaTEval are

divided into three categories: (I) Crawlers, which

are used for state selection and state traversal, (II)

Fuzzers, which are used for payload generation and

attack evaluation, and (III) Detectors, which are used

for pattern detection and information inference. All

Modules have access to a centralized database where

they can read and write data. This facilitates the inter-

action of the Modules and the sharing of information

between them. Especially, this allows the Crawlers

SWaTEval: An Evaluation Framework for Stateful Web Application Testing

433

Table 1: Implemented Modules of the different categories.

Name of Module Source

Basic Crawler (Doup

e et al., 2012)

Dummy Fuzzer New work

External Fuzzers (Borcherding et al., 2020)

Clustering Detector New work

and Fuzzers to interact with one another as suggested

by literature (Hassanshahi et al., 2022; Doup

e et al.,

2012). Further details on each module are available in

Sections 5.1.2 to 5.1.4.

Further, we encapsulate the execution logic of the

Modules in Workers. This creates the advantage that

the Modules can be dynamically spawned and run in

a distributed way, allowing SWaTEval to scale to for

bigger workloads.

In the following, we present the Modules we de-

signed and implemented. This includes approaches

from literature as well as our own approaches. Ta-

ble 1 shows an overview of the Modules as well as

their source.

5.1.2 Crawlers

The Crawlers’ goal is to walk through the WA and

ﬁnd new Endpoints. The information found by the

Crawlers is saved in the database and is later used

by the Detectors which generate the preliminary state

machine. This state machine is then used by the

Crawler again to decide which states to explore next.

Basic Crawler. This Crawler implements a simple

approach for crawling. It navigates the WA to the ﬁrst

available state that is not marked as explored, and vis-

its all available Endpoints in this state. To ensure

that the WA is always in the selected state, we re-

set the WA and navigate to the selected state before

each crawl iteration. While crawling, the Crawler

saves all generated data in the database. In the case

of the BasicCrawler, we assume that the WA can be

crawled thoroughly and assume convergence when all

detected states and Endpoints are visited, and no fur-

ther states and Endpoints are detected.

5.1.3 Fuzzers

The Fuzzers’ goal is to generate payloads to test the

WA and to analyze whether a vulnerability has been

found. In our setting, they are also used to trigger new

states of the WA by trying out different inputs. Simi-

lar to the Crawlers, the data generated by the Fuzzers

is also saved in the database. To differentiate between

the data generated by the Fuzzers and the Crawlers,

we ﬂag the data in the database accordingly.

Dummy Fuzzers. To validate our concept, we im-

plemented a dummy Fuzzers for the Evaluation Target

we used in our evaluation. They mock the functional-

ity of a real Fuzzer by detecting the current state of the

WA and executing requests that are known to cause

state transitions. In addition, they also send non-fuzzy

requests that will not trigger a state transition, mim-

icking the behavior of a real Fuzzer.

External Fuzzers. Since SWaTEval has the goal to

integrate different approaches for SWAT, we also pro-

vide an interface for external Fuzzers such as Wapiti

or Nikto

. This conﬁguration is based on the work

by Borcherding et al.(Borcherding et al., 2020). To

interact with the external Fuzzer, we implement a

Fuzzer-speciﬁc strategy that starts the external Fuzzer

and intercepts its trafﬁc using the MITM proxy

. This

allows us to inject state data in the requests of the ex-

ternal fuzzer such as cookies and headers, and simul-

taneously retrieve the responses of the WA.

5.1.4 Detectors

The Detectors compare the output of similar requests

before and after fuzzing to infer information on the

state machine. The intuition behind this decision is

the following. If a response to a request differs from

the responses that we received to the same request ear-

lier, a state change has likely happened between those

two requests. The detection approach presented be-

low is based on this assumption and uses it to infer

the state machine.

Clustering Detector. Our newly proposed ap-

proach is based on clustering. The clustering algo-

rithm uses Endpoints, Interactions, and States as in-

put, which we will denote as content in the following.

For this Detector type, the content is represented by

a locality sensitive hash. To measure the similarity

of two content entries, a distance score between their

respective hashes is calculated. The clustering algo-

rithm ﬁrst calculates this distance, and then clusters

the web pages accordingly. The detection of a new

cluster is interpreted as a relevant change in the con-

tent, which represents an anomaly. This anomaly can

indicate a state transition, a state collapsing, or the

existence of an unseen Endpoint. The whole method

https://wapiti-scanner.github.io/

https://github.com/sullo/nikto

https://mitmproxy.org/

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

434

is described in further detail in the next section (Sec-

tion 5.2).

5.2 Clustering Based Detection

This section provides deeper insight into the inner

workings of our clustering based Detectors. Our ap-

proach aims to achieve the same goals as the approach

presented by Doup

e et al.. Doup

e et al. represent a

web page as a page link vectors which incorporate in-

formation on the DOM path, anchors, forms, parame-

ters, and values (Doup

e et al., 2012). In contrast, we

create a latent representation of the data and apply di-

rect clustering methods on it. With these clustering

based methods, we aim to achieve a more adaptive

analysis that adjusts the clustering results to the newly

available data. We represent content generated in our

framework with the help of the locality sensitive hash

called TLSH (see Section 3). To be more speciﬁc, we

apply this hash to different parts of the available con-

tent as shown in the following.

5.2.1 Data Types

To represent the content of the WA and make use of it

during SWAT, we deﬁne three data types: Endpoint,

Interaction, and State. Each of these data types has

a hash attribute that contains the compact TLSH rep-

resentation of the contained data. Furthermore, we

deﬁne for our framework the data types Request and

Response to represent HTTP Requests and HTTP Re-

sponses, respectively.

Endpoints contain information about web ad-

dresses found while scanning a WA. They include

an address location, the parameters found in the URL

and the body, the HTTP method, the DOM location,

the corresponding state, and the source. Here, the

source is deﬁned as the Interaction that created a Re-

sponse which contained the corresponding Endpoint.

To calculate the hash of an Endpoint, we concatenate

its URL, parameters, state, and DOM location in a

string and apply TLSH to it.

Interactions represent the communication with

the WA and are put together from an Endpoint, and

the corresponding Request, Response, and State. To

calculate the hash of an Interaction, we ﬁrst parse the

body of its Response and extract links provided as an-

chors and forms. Then, we concatenate them with the

received response code, URL, and HTTP method, and

use the ﬁnal string to generate a TLSH.

States contain information about the Interaction

that caused the transition, and paths from other States

that lead to the corresponding State. The state hash

is calculated by concatenating the related Interaction

hashes in a String and using it to generate a TLSH.

5.2.2 Clustering Based Detectors

We orient the SWAT challenges, that the Detectors of

SWaTEval should solve, on the challenges identiﬁed

by Doup

e et al. (Doup

e et al., 2012). The Endpoint-

Detector has the goal to decide which Endpoints are to

be classiﬁed as identical in order to discard duplicated

Endpoints and such reduce the time needed for a test.

The StateChangeDetector aims to identify state tran-

sitions in order to build the state machine. Similar to

the EndpointDetector, the StateDetector helps reduc-

ing the testing time by deciding which states of the

identiﬁed state machine are considered equivalent and

can be merged. As has been mentioned, the Workers

execute the Modules in a sequential order. After a

Crawling or a Fuzzing step, the Detectors are run in

the following order: (I) EndpointDetector, (II) State-

ChangeDetector, (III) StateDetector. Each of the De-

tectors makes use of our clustering approach which

we will explain in more detail in Section 5.2.3.

EndpointDetector. The EndpointDetector decides

which Endpoints should be visited in the upcoming

crawling iterations, since not every newly found End-

point should be visited by the Crawler. Some End-

points lead to Interactions that contain similar infor-

mation even if the Endpoint addresses differ. Since

duplicate information does not contribute to the state

machine inference, we want to avoid interacting with

duplicate Endpoints. For example, WAs sometimes

provide dynamically generated links on webpages,

which point to the same URL with slightly different

parameters. Such is the case in WackoPicko, an inten-

tionally vulnerable WA (Doup

e et al., 2010). This WA

contains a calendar page that always generates a link

pointing to the same calendar page, but with the next

date selected. With this, it essentially creates a never

ending chain of Endpoints which will get a crawler

stuck in the corresponding state.

We solve this issue by calculating clusters of End-

point hashes. We consider Endpoints in the same

cluster to be the same. By labelling the Endpoints ac-

cordingly, the EndpointDetector helps the Crawler to

ﬁlter out identical Endpoints when selecting an End-

point for the next Interaction. Thereby, we ensure that

the subsequently visited Endpoints are considerably

different from any previously visited Endpoint and the

crawling procedure will eventually converge.

StateChangeDetector. The purpose of the State-

ChangeDetector is to detect state transitions. To

achieve this, it clusters all Interaction hashes gener-

ated when visiting an Endpoint and looks for outliers.

SWaTEval: An Evaluation Framework for Stateful Web Application Testing

435

As stated earlier, we assume that a state change

has occurred when the same Request results in a dif-

ferent Response than in previous Interactions. To de-

cide whether a Response is different from the ones

seen before, we apply our clustering approach again.

We calculate clusters using data from all Interactions

that have been carried out on the same Endpoint. If

the Interactions on the same Endpoint have more than

one cluster, we assume that a state change has hap-

pened. Based on this observation, we infer the state

machine as proposed by Doup

e et al. (Doup

e et al.,

2012), and a new state is created. As soon as the

Fuzzer creates a new Interaction, the StateChange-

Detector compares this Interaction with Interactions

having the same Endpoint and being created by the

Crawler. This ensures that the StateChangeDetector

can detect a state transition on time. As a result, it

ensures that future Interactions will be mapped to the

correct state.

StateDetector. An additional important step in the

state machine inference is the merging of similar

states (Doup

e et al., 2012). This pruning operation

is crucial, since duplicate States will slow down the

scanning process without adding new information.

The StateDetector runs after the StateChange-

Detector and identiﬁes states that appear equivalent.

The StateDetector allows only the earliest state to per-

sist and labels the identical ones as duplicates. This

ensures that the duplicate states are ﬁltered out in the

following crawling steps.

Again, we use the clustering approach to solve this

challenge and calculate the clusters of states. If multi-

ple States are considered to be in the same cluster, we

assume that these states are duplicates. By labeling

them as duplicates, we allow only the initial distinct

state to persist. Additionally, we ensure that no pre-

vious state graph paths are broken by appending the

paths of the duplicate states to the persisted state. We

also transfer the Interactions and Endpoints of the du-

plicate states accordingly.

5.2.3 Clustering

For the Detectors, we apply clustering on TLSH

hashes to ﬁnd patterns in the content. In the following,

we describe an issue coming from the requirements of

TLSH as well as our solution of augmenting the input

data with padding. Afterwards, we describe how we

preprocess the hashes for our clustering algorithms.

Padding. By design, the TLSH algorithm requires

a minimum input of 50 bytes to generate a hash. To

fulﬁl this requirement, we use a random but ﬁxed

padding for the inputs to the TLSH algorithm. How-

ever, augmenting the TLSH input data with random

data might dilute the information of the actual data

and make the clustering result less reliable. Also,

the concrete choice of the padding may inﬂuence the

clustering results. We acknowledge the impact of our

padding choice during our evaluation (Section 6).

Preprocessing. We propose the following two ways

to preprocess the TLSH hashes in order to use them

as an input for the clustering algorithms:

Integer Representation. Since the TLSH algo-

rithm always results in a hash with 72 characters, we

can interpret the hash as a feature vector in R

. Each

entry of the vector is converted from a character to an

Integer by using its ASCII representation. With this,

we receive a numerical representation of the TLSH

hash which can be used for clustering.

Text-based Distance. The second approach is to di-

rectly apply a text distance on the hashes and create

a distance matrix, which then can be used as an input

for the clustering algorithm. In this case, we use the

TLSH Score proposed by the authors of TLSH, and

apply it pairwise on the content hashes to create the

distance matrix. The TLSH Score approximates the

Hamming distance and is calculated as the distance

of every two bits. Additionally, the score punishes

large differences with higher distance values (Oliver

et al., 2013).

Clustering Algorithm. We choose DBSCAN as the

algorithm for the clustering since it ﬁts the properties

of our clustering task (Ester et al., 1996). It is not de-

pendent on the cluster shape and count, it is capable

of detecting densely positioned clusters, and robust to

noise and outliers. DBSCAN has two input parame-

ters that need to be chosen. ε deﬁnes the maximal dis-

tance between two samples in a neighbourhood, and

minPts determines the minimal number of neighbours

for a core point sample. We set the minPts parame-

ter to 1, since each Endpoint, Interaction, or state can

be a cluster on its own. This is in line with Schu-

bert et al., who state that minPts should be chosen

based on domain knowledge (Schubert et al., 2017).

ε, however, is optimized with the help of the Silhou-

ette Score (Shahapure and Nicholas, 2020) every time

we run the clustering procedure.

5.2.4 Evaluation Target

Complementary to SWaTEval, we created an Evalua-

tion Target, which is used to evaluate the performance

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

436

of the Modules. Similar to Doup

e et al. we imple-

mented a server-side rendered WA, meaning that the

DOM elements for each request are generated in the

back end and sent in the response each time (Doup

et al., 2012). Based on the requirements deﬁned in

Section 4.3, we integrated the following use cases in

the Evaluation Target.

User Login. The Evaluation Target supports login

functionality including a normal user and an admin.

Chained Links. The Evaluation Target includes an

Endpoint that takes a number as input parameter and

contains a link that points to the same page with an in-

cremented number. This mimics the previously men-

tioned case of a Crawler getting stuck in a feedback

loop of links (see Section 5.2). This challenges the

EndpointDetector, which should detect the Endpoints

generated after the ﬁrst visit as duplicates.

Pages with Links and Content. The Evaluation

Target includes pages that can have links or content

which can be dynamically generated or constant. All

four possible combinations exist and can be used to

evaluate the StateChangeDetector and the Endpoint-

Detector.

State Machine. Furthermore, the Evaluation Target

includes additional states which are accessible only

when a proper keyword is given (see Figure 2). The

state machine can be used to test the features of a

StateChangeDetector or a Fuzzer. The state machine

also includes a state transition that resets the state ma-

chine to the initial state. This state transition creates a

challenge for the StateChangeDetector, as the State-

ChangeDetector has to merge the new state and the

initial one. Failing to do so will replicate the state

machine indeﬁnitely.

6 EVALUATION

Our goal in evaluating SWaTEval is to verﬁy the func-

tionality of the implemented Modules and their inter-

operability. To achieve this, we aim to ensure that

the requirements deﬁned in Section 4.3 are fulﬁlled.

Moreover, we evaluate different similarity measures

and examine the performance of multiple framework

conﬁgurations. We conduct our experiments on a ma-

chine with 128GB of RAM and the following CPU:

Intel(R) Xeon(R) E5-1650 v3 @ 3.50GHz. Note that

the used hardware exceeds the needs of SWaTEval.

Initial

State 2.2 State 2.1

State 3.2State 3.1 State 3.3 State 3.4

Special

state2 1

state2 2

state3 1

state3 2 state3 3

state3 3

special

initial

Figure 2: State machine of the Evaluation Target. Keywords

needed to access a new state are presented in italic.

6.1 Qualitative Evaluation

As the ﬁrst step of our evaluation, we analyze how

SWaTEval fulﬁlls the requirements for a framework

enabling SWAT evaluations as stated in Section 4.3.

Dividing the framework into Modules with the

same base functionality and encapsulating their indi-

vidual policy allows us to hide complexity and cre-

ate abstract workﬂows. By doing so, we ensure that

SWaTEval covers FR1 Modularity.

Interaction between the Modules of SWaTEval

(FR2 Interaction) is achieved by establishing the

database as a core point of information exchange. The

Modules are run in a sequential order, and they exe-

cute their logic only if the conditions speciﬁed in their

policy match the current state of the framework. For

example, a Fuzzer will only generate a fuzzing re-

quest if the Crawler and the Detectors have marked

the current state as fully explored. In order to sat-

isfy FR1 Modularity, we implement the policy of each

Module separately, which allows us to avoid tight

coupling and still have interoperating Modules.

FR3 Traceability aims to make the inﬂuence and

behavior of the different Modules and their interlaced

functionality visible. By separating the generated data

from the Modules, we allow for a centralized analysis

of the current state of SWaTEval. In addition, this al-

lows for manual data editing during runtime, enabling

experiments with edge cases and a deeper analysis of

the Modules’ behavior. To trace the various instances

of states, Endpoints, and Interactions, each instance is

identiﬁed by its hash. The database contains all rele-

vant information on the behavior of the Modules and

as such the content of the database can be stored and

used for documentation or analysis purposes. With

this, SWaTEval fulﬁlls FR3 Traceability.

The Evaluation Target incorporates different web

SWaTEval: An Evaluation Framework for Stateful Web Application Testing

437

pages (see Section 5.2.4 for details). First, it in-

cludes web pages with similar content which should

be classiﬁed as the same web page (TR1 Similar

pages). This holds, for example, for /views/const-

content/const-links/random-page. Besides, our Eval-

uation Target includes pages with different content,

such as views/dynamic-content/const-links/random-

page (TR2 Different pages). Moreover, it implements

the possibility to change the underlying state of the

WA by (I) a user login, and (II) the artiﬁcial state ma-

chine controlled by different keywords, as shown in

Figure 2 (TR3 Statefulness). The state machine has

eight states and the transitions of the states can be re-

traced easily. With this, our Evaluation Target fulﬁlls

the requirements TR1 - TR4.

6.2 Quantitative Evaluation

The goal of our quantitative evaluation is to ana-

lyze whether SWaTEval can be used to reproduce re-

sults from literature. We compare the results regard-

ing similarity measures based on our Evaluation Tar-

get with results from Yandrapally et al. (Yandrapally

et al., 2020). Note that Yandrapally et al. use a dif-

ferent terminology for the state of a WA, as each indi-

vidual web page is considered a state. This deﬁnition

maps to our understanding of an Endpoint. As a re-

sult, the evaluation of similarity measures for states

by Yandrapally et al. can be compared to our evalua-

tion of similarity measures for Endpoints.

We run various experiments for our comparison of

the similarity measures. First, we obtain the baseline

data by applying the similarity measures provided by

us (Section 5.2.3) and Yandrapally et al. to the tar-

gets given by Yandrapally et al.. Second, we apply the

same similarity measures to our Evaluation Target. As

a result, we obtain insights on the performance of dif-

ferent similarity measures for the large study of Yan-

drapally et al. as well as on our Evaluation Target.

Figure 3 shows the comparison of the accuracy of

similarity measures calculated on the targets used by

Yandrapally et al. and our Evaluation Target. The

x-axis presents the similarity measures and the data

representation they are based on. The y-axis displays

the achieved accuracy values of the different similar-

ity measures (see Section 5.2.3). Since the data by

Yandrapally et al. consists of more diverse WAs, it

is expected that the similarity measures show overall

less accuracy. Our results support this expectation.

Except for the differences in absolute values, our

results show the same trends and relative results for

the similarity measures. The TLSH Score results in

the lowest accuracy, while Levenshtein distance on

DOM data scores second best. The highest accu-

Euclidean TLSH Score Levenshtein

0.2

0.4

0.6

0.8

0.83

0.54

0.69

0.99

0.86

0.89

Similarity Measures

Accuracy

Duplicate Detection Accuracy

Yandrapally et al. Our Evaluation Target

Figure 3: Duplicate detection accuracy of various similarity

measures based on data by Yandrapally et al. and our Eval-

uation Target. The relative performance of the similarity

measures is the same.

racy is achieved by our proposed method using Eu-

clidean distance and the integer vector representation

of TLSH. The results show that the performance is

maximized both on the data from Yandrapally et al.

and from our Evaluation Target.

Our evaluation shows that our artiﬁcial Evalua-

tion Target leads to similar results as the study con-

ducted by Yandrapally et al.. Therefore, the conclu-

sion can be drawn that our Evaluation Target success-

fully incorporates the relevant features of real-world

WAs. With respect to RQ1, our results suggest that

our Evaluation Target achieves similar results to those

presented in literature.

6.3 Similarity Measures

In contrast to the evaluations presented in the previ-

ous subsections, which aim to evaluate SWaTEval it-

self, this subsection presents an evaluation of various

similarity measures by using SWaTEval. Neverthe-

less, this evaluation also shows that SWaTEval can

successfully be used for evaluations of different ap-

proaches for SWAT. The goal of this evaluation is to

analyze the inﬂuence of the choice of similarity mea-

sure on the results of the state machine inference.

Table 2 shows the similarity measures we consid-

ered for the Detectors in our Evaluation. For each of

the Detectors, we choose either Euclidean or Leven-

shtein as similarity measure (see Section 5.2.3), and

use them to calculate the distance between content

entries represented as TLSH. For the StateChange-

Detector, we additionally evaluate calculating the

Levenshtein distance of the body of the Responses.

Thus, we end up with 2 · 2 · 3 = 12 conﬁgurations

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

438

Table 2: Similarity measures used for the evaluation.

ID Representation Sim-Measure

TLSH Score TLSH as String TLSH Score

Euclidean TLSH as Integers Euclidean

Levenshtein Response Body Levenshtein

Euclidean TLSH Score Levenshtein

StateChangeDetector

Correctly identiﬁed states

Average Number of Correctly Identiﬁed States

StateDet: Euclidean | EpDet: Euclidean

StateDet: Euclidean | EpDet: TLSH Score

StateDet: TLSH Score | EpDet: Euclidean

StateDet: TLSH Score | EpDet: TLSH Score

Figure 4: Means average number of correctly identi-

ﬁed states for the different Detector conﬁgurations for the

StateChangeDetector, the StateDetector (StateDet), and the

EndpointDetector (EpDet). The euclidean similarity mea-

surement leads to higher numbers.

which we run 20 times each. This repeated execu-

tion accounts for one additional parameter which is

the padding for the TLSH which might affect the per-

formance of our Modules (see Section 5.2.3).

For each of the conﬁguration combinations, we

analyzed the count of correctly identiﬁed states, the

count of Endpoints, and the count of Interactions.

Figure 4 shows the count of correctly identiﬁed states,

which is the most important metric to measure the

performance of the conﬁgurations. The conﬁgura-

tions for the StateChangeDetector are shown on the

x-axis. The bars correspond to the different combi-

nations for StateDetector and EndpointDetector, and

the error bars show the standard deviation calculated

on the data from the 20 runs of each conﬁguration.

The correct number of states in the state machine is

marked with the dashed black horizontal line.

The graph in Figure 4 shows three main ﬁndings:

(I) The euclidean similarity measure leads to the high-

est number of correctly identiﬁed states, (II) the usage

of TLSH increases the variance of the results, and (III)

the choice of the similarity measure for the Endpoint-

Detector is the choice which has the lowest impact on

the number of correctly identiﬁed states.

The ﬁrst ﬁnding can especially be seen for the Eu-

clidean StateChangeDetector (bars on the left), and

for the Euclidean StateDetector (plain bars). Overall

best results are achieved by the conﬁguration where

all three Detectors use the Euclidean similarity mea-

sure. Especially, the Euclidean distance is better

suited as a similarity measure than the TLSH Score

developed speciﬁcally for TLSH. This ﬁnding is in-

teresting since literature shows that distance measures

based on the Manhattan distance are better suited for

data with higher dimensions than the Euclidean dis-

tance (Aggarwal et al., 2001). In our case of 72 di-

mensions, one would assume that the TLSH Score,

which approximates the Hamming distance, would

behave similar to the Manhattan distance and such

perform better than the Euclidean approach. A pos-

sible explanation might be the different nature of the

data. Aggarwal et al. use synthetic data drawn from

a normal distribution as well as data taken from the

UCI machine learning repository. In contrast, we use

TLSH as input for the distance measure and the clus-

tering. We believe that an analysis of the classiﬁca-

tion performance on various types of data would be

an interesting starting point for future work, but we

consider it to be out of scope for this paper.

The second ﬁnding is that the use of TLSH in-

creases the variance of the results. This can be seen

especially in comparison to the Levenshtein State-

ChangeDetector (bars on the right) which is not us-

ing TLSH. The observation that the usage of TLSH

leads to a higher variance is expected since it is af-

fected by the padding mentioned before. Note that

the Euclidean distance measure is inﬂuenced by the

padding as well, since it also operates on the TLSH.

This shows that the choice of padding indeed has an

inﬂuence on the identiﬁed states.

The third ﬁnding concerns the impact of the

choice of similarity measure. As a measurement for

the impact, we choose to analyze the difference be-

tween the minimum and maximum values of cor-

rectly identiﬁed states from the different conﬁgura-

tions. This impact can already be seen in Figure 4.

We show these values in Table 3 in a more compact

form. For the StateDetector, for example, this table

shows the maximum difference of the mean numbers

of correctly identiﬁed states for all conﬁgurations for

which the StateDetector is using Levenshtein and Eu-

clidean, respectively. Based on this measurement, the

choice of the distance measure for the StateChange-

Detector and the StateDetector is more important than

the one for the EndpointDetector. This insight is also

reﬂected by the data depicted in Figure 4, where a

change in the EndpointDetector still leads to simi-

SWaTEval: An Evaluation Framework for Stateful Web Application Testing

439

Table 3: Impact of the choice regarding similarity measures

for the different Detectors. The choice for the Endpoint-

Detector has the lowest impact.

Detector Detection impact

StateChangeDetector 2.30

StateDetector 2.46

EndpointDetector 0.08

lar results, when the plain bars, and respectively the

patterned bars, are compared. For a deeper analy-

sis, we also evaluated the number of detected End-

points and the performed Interactions with the WA.

These numbers highly correlate to the number of cor-

rectly detected states. In regard to RQ3, we can state

that applying different distance measurements in the

presented approaches do inﬂuence the performance of

the StateChangeDetector and StateDetector, but only

have a small impact on the EndpointDetector.

6.4 Summary

Our evaluation had two objectives. On the one hand,

we showed that SWaTEval fulﬁlls the requirements

for a SWAT framework (see Section 4.3). In addi-

tion, we showed that SWaTEval is able to reproduce

results by a study from literature by reproducing the

results by Yandrapally et al.. On the other hand, we

used SWaTEval to evaluate various similarity mea-

sures used for SWAT. We showed that the choice

of similarity measures for StateChangeDetector and

StateDetector indeed has an impact on the state ma-

chine inference and that, for our data, the euclidean

similarity measure lead to the best results.

7 FUTURE WORK

We created SWaTEval with the goal to create a foun-

dation and initial building block for future SWAT re-

search. On the one hand, SWaTEval is suited to

evaluate the impact of various choices for the state

detection. First, one could evaluate the impact of

the chosen state detection algorithm. E.g., Vaan-

drager et al. proposed a new approach to automated

automata learning which could be evaluated regard-

ing its suitability for WA automata learning by us-

ing SWaTEval (Vaandrager et al., 2022). Second,

one could approach the question of how much the

quality of the inferred state machine inﬂuences the

performance of the fuzzer. Third, the feature selec-

tion for the representation of Endpoints, Interactions,

and States could be evaluated and tuned. On the

other hand, additional approaches for Detectors could

be implemented and analyzed. A possible approach

would be to base new detectors on the anomaly detec-

tion capabilities of autoencoders such as presented by

Mirsky et al. (Mirsky et al., 2018). In addition, other

challenges of stateful fuzzing can be evaluated using

SWaTEval, such as the challenge of deciding which

state to focus on during the next fuzzing phase (Liu

et al., 2022).

The current scope of SWaTEval are server-side

rendered WAs. Even though this is still the standard

in industrial contexts, many of the modern WAs ap-

ply a client-based approach. In the future, SWaTEval

could be extended with Detectors and an appropriate

Evaluation Target for client-side WAs.

8 CONCLUSIONS

In this work, we present SWaTEval, a novel evalu-

ation framework for Stateful Web Application Test-

ing. It consists of modular implementations for De-

tectors, Crawlers, and Fuzzers, and an Evaluation Tar-

get. In our evaluation, we show that (I) the Evalu-

ation Target is a suitable substitute for an evaluation

of various real-world WAs, and that (II) SWaTEval

is suitable to conduct evaluations. By further using

SWaTEval for an evaluation of similarity measures,

we show that the choice of similarity measures has

an impact on the state machine inference, and that,

for our data, our euclidean similarity measure leads

to the highest number of correctly identiﬁed states.

This insight is invaluable for the design and imple-

mentation of future SWAT tools. Regarding the limi-

tations of SWaTEval, we would like to highlight two

points. First, our Evaluation Target currently only in-

cludes HTML web pages and as such does not cover

JavaScript based content. Second, SWaTEval cur-

rently focuses on server-side rendered WAs and does

not support, for example, Progressive Web Applica-

tions. Both points represent possible enhancements of

SWaTEval that should be addressed in future work.

One of our main goals for SWaTEval is that it will

be useful for future evaluations in the domain of State-

ful Web Application Testing. Hence, we published

the source code of SWaTEval

. SWaTEval thus pro-

vides a solid basis for future enhancements, imple-

mentations, and evaluations.

https://github.com/SWaTEval

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

440

ACKNOWLEDGEMENTS

This work was supported by funding from the topic

Engineering Secure Systems of the Helmholtz Asso-

ciation (HGF).

REFERENCES

Aggarwal, C. C., Hinneburg, A., and Keim, D. A. (2001).

On the surprising behavior of distance metrics in high

dimensional space. In International conference on

database theory, pages 420–434. Springer.

Aichernig, B. K., Mu

skardin, E., and Pferscher, A. (2021).

Learning-based fuzzing of iot message brokers. In

2021 14th IEEE Conference on Software Testing, Ver-

iﬁcation and Validation (ICST), pages 47–58. IEEE.

Alidoosti, M., Nowroozi, A., and Nickabadi, A. (2019). Bl-

prom: A black-box approach for detecting business-

layer processes in the web applications. Journal of

Computing and Security, 6(2):65–80.

Borcherding, A., Pfrang, S., Haas, C., Weiche, A., and Bey-

erer, J. (2020). Helper-in-the-middle: Supporting web

application scanners targeting industrial control sys-

tems. In 17th International Joint Conference on e-

Business and Telecommunications, pages 27–38.

Doup

e, A., Cavedon, L., Kruegel, C., and Vigna, G. (2012).

Enemy of the state: A state-aware black-box web vul-

nerability scanner. In 21st USENIX Security Sympo-

sium (USENIX Security 12), pages 523–538.

Doup

e, A., Cova, M., and Vigna, G. (2010). Why johnny

can’t pentest: An analysis of black-box web vulner-

ability scanners. In International Conference on De-

tection of Intrusions and Malware, and Vulnerability

Assessment, pages 111–131. Springer.

Drakonakis, K., Ioannidis, S., and Polakis, J. (2020). The

cookie hunter: Automated black-box auditing for web

authentication and authorization ﬂaws. In 2020 ACM

SIGSAC Conference on Computer and Communica-

tions Security, pages 1953–1970.

Ester, M., Kriegel, H.-P., Sander, J., Xu, X., et al. (1996).

A density-based algorithm for discovering clusters in

large spatial databases with noise. In The Second In-

ternational Conference on Knowledge Discovery and

Data Mining, pages 226–231.

Gauthier, F., Hassanshahi, B., Selwyn-Smith, B., Mai, T. N.,

Schl

uter, M., and Williams, M. (2021). Backrest: A

model-based feedback-driven greybox fuzzer for web

applications. arXiv preprint arXiv:2108.08455.

Hassanshahi, B., Lee, H., and Krishnan, P. (2022). Gelato:

Feedback-driven and guided security analysis of

client-side web applications. In 2022 IEEE Inter-

national Conference on Software Analysis, Evolution

and Reengineering (SANER), pages 618–629. IEEE.

Li, Y., Sun, Z.-G., and Jiang, T.-T. (2018). An automated

test suite generating approach for stateful web ser-

vices. In International Conference on Software Anal-

ysis, Testing, and Evolution, pages 185–201. Springer.

Lin, J.-W., Wang, F., and Chu, P. (2017). Using se-

mantic similarity in crawling-based web application

testing. In 2017 IEEE International Conference on

Software Testing, Veriﬁcation and Validation (ICST),

pages 138–148. IEEE.

Lin, Z., King, I., and Lyu, M. R. (2006). Pagesim: A novel

link-based similarity measure for the world wide web.

In 2006 IEEE/WIC/ACM International Conference on

Web Intelligence (WI 2006 Main Conference Proceed-

ings)(WI’06), pages 687–693. IEEE.

Liu, D., Pham, V.-T., Ernst, G., Murray, T., and Rubin-

stein, B. I. (2022). State selection algorithms and their

impact on the performance of stateful network proto-

col fuzzing. In 2022 IEEE International Conference

on Software Analysis, Evolution and Reengineering

(SANER), pages 720–730. IEEE.

Mesbah, A., Bozdag, E., and Van Deursen, A. (2008).

Crawling ajax by inferring user interface state

changes. In 2008 Eighth International Conference on

Web Engineering, pages 122–134. IEEE.

Mirsky, Y., Doitshman, T., Elovici, Y., and Shabtai, A.

(2018). Kitsune: an ensemble of autoencoders for on-

line network intrusion detection. In Network and Dis-

tributed Systems Security (NDSS) Symposium 2018.

Oliver, J., Cheng, C., and Chen, Y. (2013). Tlsh–a locality

sensitive hash. In 2013 Fourth Cybercrime and Trust-

worthy Computing Workshop, pages 7–13. IEEE.

Pferscher, A. and Aichernig, B. K. (2022). Stateful black-

box fuzzing of bluetooth devices using automata

learning. In NASA Formal Methods Symposium, pages

373–392. Springer.

Pfrang, S., Borcherding, A., Meier, D., and Beyerer, J.

(2019). Automated security testing for web applica-

tions on industrial automation and control systems. at-

Automatisierungstechnik, 67(5):383–401.

Popescu, D. A. and Nicolae, D. (2014). Determining the

similarity of two web applications using the edit dis-

tance. In International workshop soft computing ap-

plications, pages 681–690. Springer.

Raffelt, H., Steffen, B., and Berg, T. (2005). Learnlib: A

library for automata learning and experimentation. In

10th international workshop on Formal methods for

industrial critical systems, pages 62–71.

Schubert, E., Sander, J., Ester, M., Kriegel, H. P., and Xu,

X. (2017). Dbscan revisited, revisited: why and how

you should (still) use dbscan. ACM Transactions on

Database Systems (TODS), 42(3):1–21.

Shahapure, K. R. and Nicholas, C. (2020). Cluster qual-

ity analysis using silhouette score. In 2020 IEEE 7th

International Conference on Data Science and Ad-

vanced Analytics (DSAA), pages 747–748. IEEE.

Vaandrager, F., Garhewal, B., Rot, J., and Wißmann, T.

(2022). A new approach for active automata learning

based on apartness. In International Conference on

Tools and Algorithms for the Construction and Analy-

sis of Systems, pages 223–243. Springer.

Yandrapally, R., Stocco, A., and Mesbah, A. (2020). Near-

duplicate detection in web app model inference. In

ACM/IEEE 42nd international conference on software

engineering, pages 186–197.

SWaTEval: An Evaluation Framework for Stateful Web Application Testing

441
