Evaluating the Fork-Awareness of Coverage-Guided Fuzzers

Marcello Maugeri

1 a

, Cristian Daniele

2 b

, Giampaolo Bella

1 c

and Erik Poll

2 d

Department of Maths and Computer Science, University of Catania, Catania, Italy

Department of Digital Security, Radboud University, Nijmegen, The Netherlands

Keywords:

Fuzzing, Fork, Security Testing, Software Security.

Abstract:

Fuzz testing (or fuzzing) is an effective technique used to ﬁnd security vulnerabilities. It consists of feeding a

software under test with malformed inputs, waiting for a weird system behaviour (often a crash of the system).

Over the years, different approaches have been developed, and among the most popular lies the coverage-based

one. It relies on the instrumentation of the system to generate inputs able to cover as much code as possible.

The success of this approach is also due to its usability as fuzzing techniques research approaches that do

not require (or only partial require) human interactions. Despite the efforts, devising a fully-automated fuzzer

still seems to be a challenging task. Target systems may be very complex; they may integrate cryptographic

primitives, compute and verify check-sums and employ forks to enhance the system security, achieve better

performances or manage different connections at the same time. This paper introduces the fork-awareness

property to express the fuzzer ability to manage systems using forks. This property is leveraged to evaluate 14

of the most widely coverage-guided fuzzers and highlight how current fuzzers are ineffective against systems

using forks.

1 INTRODUCTION

In the last years, plenty of fuzzers have been devel-

oped to deal with sophisticated software and nowa-

days it is extremely common that network systems

employ forks to deal with different connections at the

same time. This leads to 1) the need to devise accurate

and ad-hoc fuzzers and 2) the need to evaluate these

fuzzer according to their ability to cope with such ad-

vanced systems.

Unfortunately, as pointed out in (Hazimeh et al.,

2020), it is not easy to benchmark all of them

since the fuzzers are very different from each other.

Metzman et al. faced this problem by devising

FuzzBench(Metzman et al., 2021), an open-source

service for the evaluations of stateless fuzzers. Later,

Natella and Pham presented ProFuzzBench(Natella

and Pham, 2021), which similarly to FuzzBench pro-

vides a service to evaluate stateful fuzzers.

Although FuzzBench includes a sample of real

word programs and ProFuzzBench includes differ-

ent network systems (i.e. systems that often employ

https://orcid.org/0000-0002-6585-5494

https://orcid.org/0000-0001-7435-4176

https://orcid.org/0000-0002-7615-8643

https://orcid.org/0000-0003-4635-187X

forks to deal with multiple connections(Tanenbaum,

2009)), they do not evaluate the ability of the fuzzers

to cope with programs that use forks. Despite forks

representing the only way to create a new process

(Tanenbaum, 2009), experimental results have shown

that current fuzzers cannot deal with forked processes.

The existing approach merely relies on code mod-

iﬁcations to remove the forks. Unfortunately, this ap-

proach goes against the willingness to reduce manual

work and improve automation during a fuzzing cam-

paign.(Boehme et al., 2021).

In this work, we explore and classify the limita-

tions current fuzzers exhibit in front of forking pro-

grams.

In summary, this paper:

1. devises a novel property capturing the ability of

fuzzers to deal with forks appropriately;

2. evaluates 14 coverage-guided fuzzers based on

this property;

3. proposes possible improvements to the current

state-of-the-art and future directions.

The paper is organised as follows. Section 2 describes

the relevant background, Section 3 presents our con-

tributions to knowledge, Section 4 shows the existing

approaches that try to cope with the fork problem and,

424

Maugeri, M., Daniele, C., Bella, G. and Poll, E.

Evaluating the Fork-Awareness of Coverage-Guided Fuzzers.

DOI: 10.5220/0011648600003405

In Proceedings of the 9th International Conference on Information Systems Security and Privacy (ICISSP 2023), pages 424-429

ISBN: 978-989-758-624-8; ISSN: 2184-4356

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

eventually, Section 5 discuss the results and propose

possible future directions.

2 BACKGROUND

2.1 Fuzz Testing

Fuzzing is an automated testing technique pioneered

by Miller et al.(Miller et al., 1990) in 1990 to test

UNIX utilities. As outlined in Figure 1, coverage-

guided fuzzing is composed at least of seed selection,

input generation and system execution.

1) Seeds Selection. The user must provide some

input messages (seeds) representative of some usual

inputs for the system.

2) Input Generation. The core of every fuzzer is

the generation of slightly malformed input messages

to forward to the software under test. A fuzzer is as

efﬁcient as the generated inputs are able to break the

system. According to the approach used to generate

the messages, the fuzzers may be classiﬁed into:

• dumb: generate random strings (as the ﬁrst fuzzer

(Miller et al., 1995) did);

• dumb mutational: blindly mutate seed messages

provided by the user;

• grammar-based: leverage the grammar of the sys-

tem to craft the input messages;

• smart mutational: (often called evolutionary) re-

quire a sample of inputs and leverage feedback

mechanisms to craft system-tailored messages.

An example of feedback mechanisms is the code

coverage feedback, explored in Section 2.2.

3) System Execution. Each execution of the fuzzer

involves three components:

• Bugs detector: it reports eventual bugs. The ma-

jority of the bugs detectors only report crashes,

however for many systems, also a weird deviation

from the happy ﬂow of the protocol may represent

signiﬁcant security issues;

• Hangs detector: it detects program execution

hangs;

• Code coverage detector: as further explained in

Section 2.2, the code coverage represents one of

the feedbacks the fuzzer leverages to improve the

quality of the input messages.

2.2 Coverage-Guided Fuzzing

Smart mutational fuzzers use feedback mechanisms

to steer the generation of the messages. Different

types of feedback mechanisms exist (Shahid et al.,

2011), and often different terms are used to express

the same idea. To avoid further noise, in this work

we use the term code coverage to express the lines of

code that are reached by a speciﬁc message.

Code coverage fuzzers need to recompile the code

with ad-hoc compilers (e.g. the AFL compiler) to in-

strument the code and obtain run-time information.

AFL (Zalewski, 2017), for example, instruments

the code to ﬁll a bitmap that represents the lines of

the code covered by the inputs.

Later, it uses this bitmap to assign a higher score

to messages able to explore previously unseen lines of

code.

Start

Seeds selection

Input

generation

System execution

Hangs

detector

Bugs

detector

Code

coverage

detector

Report

End

Figure 1: Coverage-guided fuzzing process.

2.3 Inter-Process Communication

Operating systems provide system calls to perform

different tasks (e.g. writing and reading ﬁles, access-

ing hardware services, creating and executing new

processes). On UNIX systems, new processes are cre-

ated by using the fork system call(Tanenbaum, 2009).

In short, the ﬁrst process, called parent process, gen-

Evaluating the Fork-Awareness of Coverage-Guided Fuzzers

425

erates a clone, called child process, that is an exact

copy of the parent process. After the fork, ﬁle de-

scriptors and registers are duplicated, thus a change

in one of the processes does not affect the other one.

Also, the parent and child process will follow sepa-

rate execution paths.

3 OUR CONTRIBUTION

This paper aims to understand how the state-of-the-

art coverage-guided fuzzers deal with software under

tests containing forks.

It was not obvious to come up with a way to com-

pare and contrast the various tools. We devised a

novel property, the fork awareness, that must be sat-

isﬁed when a fuzzer deals with forks effectively and

efﬁciently. As we shall see below, fork awareness

rests upon three aspects representing the ability to

deal with child processes.

Also, we evaluate the novel property over the

most widely used fuzzers from two benchmark frame-

works, reaching a total of 14 evaluated tools, 11

drawn from FuzzBench and 3 from ProFuzzBench.

3.1 Fork-Awareness

Abstractly, fork awareness insists that every fuzzer

should address the child process as the parent one.

During the system execution, the system monitor

should detect bugs or hangs regardless of their loca-

tion and the coverage should be measured also in the

child process. This is formalised through Deﬁnition 1.

Deﬁnition 1. A coverage-guided fuzzer is fork-aware

if it can detect bugs and hangs and measure coverage

in the same way for both the child and the parent’s

branch.

The three aspects in this deﬁnition are called:

[C.1] Child Bugs Detection: any anomaly is re-

ported also if it occurs in child processes;

[C.2] Child Hangs Detection: any inﬁnite hang is

reported also if it occurs in child processes;

[C.3] Child Code Coverage: code coverage is mea-

sured also for child processes.

3.2 Example Challenges

We wrote three simple C programs to use as chal-

lenges for the fuzzers, namely to test whether the

fuzzers satisfy the aspects given above.

a) Bugs Detection Challenge:

1 if(fork()==0){ //Child process

2 raise(SIGSEGV); //Simulated crash

3 } else { //Parent process

4 wait(NULL); //Waiting child

5 //termination

6 }

The snippet sends a SIGSEGV signal to simulate

a bug in the child process. This signal is used to

report a segmentation fault, i.e. a memory access

violation, which is common in programs written

in low-level languages. The fuzzer must detect

this bug also after the parent’s termination.

b) Hangs Detection Challenge:

1 if(fork()==0){ //Child process

2 while(1){ ; } //Simulation of

3 //blocking code

4 }

The snippet simulates an inﬁnite loop in the child

process. The fuzzers must report processes still in

execution after the loop and must kill child pro-

cesses at the end of the fuzzing campaign, avoid-

ing pending process executions.

c) Code Coverage Challenge:

1 pid_t pid = fork();

2 if(pid==0){ //Child process

3 if(data %2 == 0){ do_something(); }

4 else { do_something(); }

5 if(data %3 == 0){ do_something(); }

6 else { do_something(); }

7 if(data %5 == 0){ do_something(); }

8 else { do_something(); }

9 if(data %7 == 0){ do_something(); }

10 else { do_something(); }

11 }

12 else { //Parent process

13 wait(NULL); //Waiting child

14 //termination

15 }

This snippet simulates a child with several branches.

A fuzzer must cover and consider every child’s

branches.

We run the 14 fuzzers over these challenges and

organised the results in Table 1. We noticed that none

of the fuzzers succeeded through all three challenges.

3.3 Testbed

We decided to analyse only the coverage-guided

fuzzers present in FuzzBench (Metzman et al., 2021)

and ProFuzzBench (Natella and Pham, 2021) even

though the property applies to every coverage-guided

fuzzer. All fuzzers were executed on an Ubuntu 20.04

server machine and all our source codes are freely

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

426

Table 1: Coverage guided fuzzers evaluation.

Fuzzer Based on Monitor technique

Bugs

Detection

(C1)

Hangs

Detection

(C2)

Code

coverage

(C3)

AFL(Zalewski, 2017) - POSIX signals × × X

AFL++(Fioraldi et al., 2020) AFL POSIX signals × × X

AFLFast(Bohme et al., 2017) AFL POSIX signals × × X

AFLSmart(Pham et al., 2021) AFL POSIX signals × × X

Eclipser(Choi et al., 2019) AFL POSIX signals × × X

FairFuzz(Lemieux and Sen, 2018) AFL POSIX signals × × X

laﬁntel(Besler and Frederic, 2016) AFL POSIX signals × × X

AFLnwe

AFL POSIX signals × × X

AFLNet(Pham et al., 2020) AFL POSIX signals × × X

MOpt-AFL(Lyu et al., 2019) AFL POSIX signals × × X

StateAFL(Natella, 2022)

- AFL

- AFLNet

POSIX signals × × X

LibFuzzer

- UBSAN

- ASAN

- MSAN

X × X

Entropic(Bohme et al., 2020) LibFuzzer

- UBSAN

- ASAN

- MSAN

X × X

Honggfuzz

- ptrace (Linux) X × X

available online

so that our experiments are fully re-

producible.

3.4 Fuzzers Evaluation

We run all selected fuzzers against our three example

challenges. Table 1 summarises our ﬁndings.

All the fuzzers based on AFL use POSIX signals

and a bitmap respectively to report bugs and keep

track of the code coverage.

As shown in the Table 1, while the bitmaps are

able to keep track of the child’s code coverage, bugs

triggered in the child’s processes are not detected

since AFL catches signals from the main process

only, as pointed out in the documentation

. The only

fuzzers able to detect bugs in the child process are

LibFuzzer

, Entropic(Bohme et al., 2020) and Hong-

fuzz

, as discussed in more detail below:

• LibFuzzer

and Entropic(Bohme et al., 2020) em-

ploy a set of sanitizers

to report bugs. These

mechanisms make the fuzzers able to ﬁnd the

https://github.com/marcellomaugeri/forks-break-aﬂ

https://github.com/google/AFL/blob/master/

README.md

https://llvm.org/docs/LibFuzzer.html

https://honggfuzz.dev/

https://llvm.org/docs/LibFuzzer.html

AddressSanitizer, UndeﬁnedBehaviorSanitizer and

MemorySanitizer

bug in Challenge 1 and measure the different

code paths in Challenge 3, thereby satisfying chal-

lenges C.1 and C.3, as seen above. Unfortunately,

challenge C.2 is not satisﬁed since the fuzzer can-

not detect hangs in the child process.

• Honggfuzz supports different software/hardware

feedback mechanisms and a low-level interface to

monitor targets. When executed on Linux ma-

chines, Honggfuzz uses the ptrace system call to

manage processes. This mechanism allows the

fuzzer to capture a wide range of signals. As

shown in Table 1, the use of ptrace (along with

the SanitizerCoverage) allows the fuzzer to detect

bugs and to consider coverage also in the child

process. Unfortunately, neither this mechanism is

able to detect hangs in the child process.

In summary, while all selected fuzzers detect the code

coverage (C3), none detect hangs (C2) and only a few

detect bugs (C1) in the child process. The evaluation

underlines that:

• Loops detection challenge is the most difﬁcult be-

cause fuzzers do not wait for all the child pro-

cesses but only for the main one;

• Code coverage challenge is the easiest because

the instrumentation allows measuring coverage

from the execution, regardless of the process in-

volved;

• Bug detection challenge depends on the technique

Evaluating the Fork-Awareness of Coverage-Guided Fuzzers

427

used to observe bugs, as well as the use of sanitis-

ers.

We interpret this general outcome as a clear call for

future research and developments.

4 EXISTING SOLUTIONS

Nowadays the only solutions to fuzz programs that

use forks are manually modifying the code or break-

ing the multi-process nature of the system (by em-

ploying tools like defork

) in order to get rid of the

forks.

Unfortunately, making modiﬁcations to the code,

as pointed out in the AFLNet documentation

, to

remove all the forks is a challenging and error-prone

task and break the multi-process nature of the system

often leads to weird system behaviours. The only so-

lution, therefore, remains to modify the fuzzers.

5 CONCLUSIONS

This paper analyses the fork awareness of the

coverage-guided fuzzers using three different aspects.

The analysis conducted on 14 well-known fuzzers

highlights that while is it clear how important is to

handle multi-process programs, the majority of the

fuzzers overlook the problem. 11 of 14 fuzzers are

not able to detect bugs in the child process. The intu-

ition behind these outcomes is related to the way these

fuzzers detect bugs. All the AFL-derived fuzzers use

signals (SIGSEGV, SIGABRT, etc) to detect bugs and

this mechanism misses bugs in child processes. We

noticed that dealing with forks is not the only problem

and other issues may be related to the IPC scheduling.

For example, the IPC may inﬂuence the success of

the fuzzing process since some bugs may be triggered

only after a speciﬁc process schedule and only after

access to a particular cell of memory. We believe this

paper represents a ﬁrst step towards the devising of

fuzzers aware of the eventual multiprocess nature of

the software. The ﬁrst step to achieve this goal might

be the implementation of a loop detector at an early

stage, e.g. by leveraging a dynamic library to keep

track of all process identiﬁers of forked processes. To

summarise, this work not only provides the ﬁrst con-

crete way to evaluate the fuzzers according to their

fork awareness but sheds light for the ﬁrst time on a

https://github.com/zardus/preeny/blob/master/src/

defork.c

https://github.com/aﬂnet/aﬂnet

class of problems that have been ignored until now,

showing interesting future directions.

REFERENCES

Besler and Frederic (2016). Circumventing fuzzing road-

blocks with compiler transformations. https://laﬁntel.

wordpress.com.

Boehme, M., Cadar, C., and Roychoudhury, A. (2021).

Fuzzing: Challenges and reﬂections. IEEE Softw.,

38(3):79–86.

Bohme, M., Manes, V. J., and Cha, S. K. (2020). Boosting

fuzzer efﬁciency: An information theoretic perspec-

tive. In Proceedings of the 28th ACM Joint Meeting on

European Software Engineering Conference and Sym-

posium on the Foundations of Software Engineering,

pages 678–689.

Bohme, M., Pham, V.-T., and Roychoudhury, A.

(2017). Coverage-based greybox fuzzing as markov

chain. IEEE Transactions on Software Engineering,

45(5):489–506.

Choi, J., Jang, J., Han, C., and Cha, S. K. (2019). Grey-box

concolic testing on binary code. In 2019 IEEE/ACM

41st International Conference on Software Engineer-

ing (ICSE), pages 736–747. IEEE.

Fioraldi, A., Maier, D., Eißfeldt, H., and Heuse, M. (2020).

Aﬂ++: Combining incremental steps of fuzzing re-

search. In 14th USENIX Workshop on Offensive Tech-

nologies (WOOT 20).

Hazimeh, A., Herrera, A., and Payer, M. (2020). Magma:

A ground-truth fuzzing benchmark. Proceedings of

the ACM on Measurement and Analysis of Computing

Systems, 4(3):1–29.

Lemieux, C. and Sen, K. (2018). Fairfuzz: A targeted muta-

tion strategy for increasing greybox fuzz testing cov-

erage. In Proceedings of the 33rd ACM/IEEE Interna-

tional Conference on Automated Software Engineer-

ing, pages 475–485.

Lyu, C., Ji, S., Zhang, C., Li, Y., Lee, W.-H., Song, Y.,

and Beyah, R. (2019). {MOPT}: Optimized muta-

tion scheduling for fuzzers. In 28th USENIX Security

Symposium (USENIX Security 19), pages 1949–1966.

Metzman, J., Szekeres, L., Maurice Romain Simon,

L., Trevelin Sprabery, R., and Arya, A. (2021).

FuzzBench: An Open Fuzzer Benchmarking Platform

and Service. In Proceedings of the 29th ACM Joint

Meeting on European Software Engineering Confer-

ence and Symposium on the Foundations of Soft-

ware Engineering, ESEC/FSE 2021, pages 1393–

1403, New York, NY, USA. Association for Comput-

ing Machinery.

Miller, B. P., Fredriksen, L., and So, B. (1990). An empiri-

cal study of the reliability of unix utilities. Communi-

cations of the ACM, 33(12):32–44.

Miller, B. P., Koski, D., Lee, C. P., Maganty, V., Murthy, R.,

Natarajan, A., and Steidl, J. (1995). Fuzz revisited: A

re-examination of the reliability of unix utilities and

services. Technical report, University of Wisconsin-

Madison Department of Computer Sciences.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

428

Natella, R. (2022). Stateaﬂ: Greybox fuzzing for state-

ful network servers. Empirical Software Engineering,

27(7):191.

Natella, R. and Pham, V. T. (2021). Profuzzbench: A bench-

mark for stateful protocol fuzzing. In ISSTA 2021 -

Proceedings of the 30th ACM SIGSOFT International

Symposium on Software Testing and Analysis, pages

662–665. Association for Computing Machinery, Inc.

Pham, V.-T., B

ohme, M., Santosa, A. E., C

aciulescu,

A. R., and Roychoudhury, A. (2021). Smart greybox

fuzzing. IEEE Transactions on Software Engineering,

47(9):1980–1997.

Pham, V.-T., Bohme, M., and Roychoudhury, A. (2020).

Aﬂnet: a greybox fuzzer for network protocols. In

2020 IEEE 13th International Conference on Software

Testing, Validation and Veriﬁcation (ICST), pages

460–465. IEEE.

Shahid, M., Ibrahim, S., and Mahrin, M. N. (2011). A study

on test coverage in software testing. Advanced Infor-

matics School (AIS), Universiti Teknologi Malaysia,

International Campus, Jalan Semarak, Kuala Lumpur,

Malaysia.

Tanenbaum, A. (2009). Modern operating systems. Pearson

Education, Inc.,.

Zalewski, M. (2017). American fuzzy lop. https://lcamtuf.

coredump.cx/aﬂ/.

Evaluating the Fork-Awareness of Coverage-Guided Fuzzers

429
