Keyframe and GAN-Based Data Augmentation for Face Anti-Spooﬁng

Jarred Orfao

and Dustin van der Haar

Academy of Computer Science and Software Engineering, University of Johannesburg,

Kingsway Avenue and University Rd, Auckland Park, South Africa

Keywords:

Face Anti-Spooﬁng, Generative Data Augmentation, Keyframe Selection.

Abstract:

As technology improves, criminals, ﬁnd new ways to gain unauthorised access. Accordingly, face spoof-

ing has become more prevalent in face recognition systems, requiring adequate presentation attack detection.

Traditional face anti-spooﬁng methods used human-engineered features, and due to their limited represen-

tation capacity, these features created a gap which deep learning has ﬁlled in recent years. However, these

deep learning methods still need further improvements, especially in the wild settings. In this work, we use

generative models as a data augmentation strategy to improve the face anti-spooﬁng performance of a vision

transformer. Moreover, we propose an unsupervised keyframe selection process to generate better candidate

samples for more efﬁcient training. Experiments show that our augmentation approaches improve the baseline

performance of the CASIA-FASD and achieve state-of-the-art performance on the Spoof in the Wild database

for protocols 2 and 3.

1 INTRODUCTION

Face recognition is a physical biometric modality that

has historically struggled with user acceptance due

to its non-contact nature (Jain et al., 2007). In re-

cent years, developments in technology and COVID-

19 protocols have enabled facial recognition to be-

come a more common method of user authentication

in public and private settings (Bischoff, 2021), in-

cluding workplaces, trains, and airports, using devices

such as computers and mobile phones. Although fa-

cial recognition has taken massive strides from its in-

ception, each component has inherent vulnerabilities.

The biometric sensor is the ﬁrst component of an au-

thentication system that a user interacts with, making

it the easiest to access and least expensive to attack.

Unlike other components, the system has no control

over the input that the sensor is exposed to, thereby

making it susceptible to presentation attacks, such as

face spooﬁng.

A face spooﬁng attack is when an attacker

presents a two-dimensional medium, such as a photo

or video, or a three-dimensional medium, such as a

mask, of an enrolled user (commonly referred to as

a victim), to the biometric sensor to gain illegal ac-

cess (Daniel and Anitha, 2018). As an authenticated

face is often the only hurdle to accessing physical and

https://orcid.org/0000-0003-1430-0488

https://orcid.org/0000-0002-5632-1220

digital assets, it is imperative that face spooﬁng is de-

tected.

In this study, we use deep learning (a Vision

Transformer) to detect two-dimensional face spooﬁng

attacks and generative models to enhance the results

further. To our knowledge, this paper is the ﬁrst work

using Generative Adversarial Networks (GANs) as a

data augmentation strategy for face anti-spooﬁng. We

summarise the main contributions of this paper as fol-

lows:

1. We show the effectiveness of GANs as a data

augmentation strategy for face anti-spooﬁng com-

pared to traditional augmentation approaches.

2. We propose an unsupervised keyframe selection

process for more effective candidate generation

and investigate the relationship between variabil-

ity and image ﬁdelity and its role in artefact de-

tection.

3. We explore when data augmentation should be

performed, the optimal data augmentation per-

centage and the number of frames to consider for

face anti-spooﬁng.

4. We benchmark our approach against the current

state-of-the-art face anti-spooﬁng approaches on

public datasets.

The rest of the paper is structured accordingly: We

begin with a discussion of face anti-spooﬁng and sim-

ilar work in Section 2, followed by an explanation of

Orfao, J. and van der Haar, D.

Keyframe and GAN-Based Data Augmentation for Face Anti-Spooﬁng.

DOI: 10.5220/0011648400003411

In Proceedings of the 12th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2023), pages 629-640

ISBN: 978-989-758-626-2; ISSN: 2184-4313

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

629

the proposed method in Section 3. In Section 4, we

describe the experiment setup, followed by the anal-

ysis of the results in Section 5 and a conclusion in

Section 6.

2 RELATED WORK

Face anti-spooﬁng has been an active research topic

for more than 15 years, with publications increasing

yearly (Yu et al., 2021). Despite researchers’ efforts,

face recognition systems are still vulnerable to sim-

ple, non-intrusive attack vectors. These attack vectors

prey on the biometric sensor and are categorised ac-

cordingly (Hernandez-Ortega et al., 2021):

1. A photo attack is when an attacker presents a

printed image of a victim to the biometric sensor.

2. A warped-photo attack is an extension of a photo

attack, implemented by manipulating the printed

image to simulate facial motion.

3. A cut-photo attack is an extension of a photo at-

tack, implemented by blinking behind eye holes

removed from the printed image.

4. A video replay attack is when an attacker uses a

device to replay a video containing a victim’s face

to the biometric sensor.

5. A 3D-mask attack is when an attacker wears a

3D mask, replicating a victim’s facial features, in

front of the biometric sensor.

6. A DeepFake attack occurs when an attacker uses

deep learning methods to replace a person’s face

in a video with a victim’s.

Thankfully, face anti-spooﬁng methods have ad-

vanced signiﬁcantly in recent years. Traditionally,

researchers achieved face anti-spooﬁng by using hu-

man vitality cues and handcrafted features. The vi-

tality cues include eye blink detection (Li, 2008),

face movement analysis (Bao et al., 2009) and gaze

tracking (Ali et al., 2013). However, these ap-

proaches are susceptible to cut-photo and video-

replay attacks, making them unreliable. In contrast,

handcrafted features such as Local Binary Patterns

(LBP) (Boulkenafet et al., 2016), Speeded-Up Ro-

bust Features (SURF) (Boulkenafet et al., 2017) and

Shearlets (van der Haar, 2019) have extracted ef-

fective spoof patterns in real-time with minimal re-

sources. However, handcrafted features require a

hands-on approach from feature engineers to select

the essential features from images, which becomes

more difﬁcult as the number of classiﬁcation classes

increase (Walsh et al., 2019). Moreover, each feature

requires handling multiple parameters, which all need

ﬁne-tuning.

In contrast, deep learning approaches discover de-

scriptive patterns independently with minimal human

intervention. Convolutional Neural Network (CNN)

architectures have been successful with face anti-

spooﬁng but require a large amount of data to train

models sufﬁciently and are prone to overﬁtting. To

avoid overﬁtting a dataset during training, researchers

use regularisation methods, such as dropout, espe-

cially when training a model with no prior knowl-

edge (Ur Rehman et al., 2017). Another strategy that

has achieved success is using a pre-trained model and

ﬁne-tuning selected layers (Nagpal and Dubey, 2019),

(George and Marcel, 2021). This approach allows

a model to apply the features learned from a large

dataset to a similar task with a smaller dataset. Some

researchers have been successful in training CNNs

with auxiliary information. Using this approach, (Liu

et al., 2018) achieved competitive results by fusing the

depth map of the last frame with the corresponding

remote photoplethysmography signal acquired over a

sequence of frames to determine the ﬁnal spoof score.

However, their approach requires multiple frames,

which limits its applicability.

Recently, researchers have achieved state-of-the-

art performance by using a hybrid approach of hand-

crafted features with deep learning. Wu et al. (2021)

created a DropBlock layer, which randomly discards

a part of the feature map to learn location-independent

features. Furthermore, their method acts as a data

augmentation strategy because the blocked regions

can represent occlusions, thus increasing the training

samples and reducing the risk of overﬁtting. Sim-

ilarly, inspired by how LBPs describe local rela-

tions, Yu et al. (2020) created a Central Difference

Convolution layer. This layer has the same sampling

step as a traditional convolutional layer but prefers

to aggregate the centre-oriented gradient of the sam-

pled values during the aggregation step. In doing so,

they obtain intensity-level semantic information and

gradient-level detailed messages, which they prove

are essential for face anti-spooﬁng.

The above analysis shows that hybrid approaches

reap the beneﬁts of traditional and deep learning

methods. Furthermore, approaches such as Wu et al.

(2021) also act as a data augmentation strategy. To

fairly evaluate the effectiveness of our data augmen-

tation strategy, we will ﬁne-tune a vision transformer

similar to George and Marcel (2021), which we will

discuss in the next section.

ICPRAM 2023 - 12th International Conference on Pattern Recognition Applications and Methods

630

3 PROPOSED METHOD

This paper proposes a transfer learning approach to

face anti-spooﬁng using a pre-trained Vision Trans-

former (ViT) model. Furthermore, we use generative

data augmentation to optimise this model by synthe-

sising candidate samples using StyleGAN3 models.

In the following sections, we will discuss the different

stages of the training pipeline, illustrated in Figure 1.

3.1 Preprocessing

We preprocessed each video to avoid background and

dataset bias. First, we employed the MTCNN algo-

rithm (Zhang et al., 2016) for face detection. Next,

we rotated the detected region (to align the eye centres

horizontally), scaled the region (to minimise the back-

ground), and cropped the region to produce a square

patch containing the subject’s eyebrows and mouth.

Although it is possible to scale the detected region

to remove the background altogether, the crop patch

does not have eyebrows or a mouth. Since these facial

features are essential for portraying emotion, we de-

cided to include slightly more background to ensure

they are both present in the cropped patch.

3.2 Data Augmentation

We followed a generative data augmentation approach

by synthesising new training images rather than ap-

plying an afﬁne transformation to existing images.

We trained a StyleGAN3 model for each attack vec-

tor and used these models to generate new candidate

samples. We also performed data augmentation using

traditional methods to compare it against our genera-

tive approach.



× P

100% − P



÷ N

(1)

In equation (1), N

is the number of images gener-

ated for each attack vector; N

is the number of sam-

ples present in the training protocol; N

is the number

of attack vectors present in the training protocol, and

P is the desired data augmentation percentage. Using

equation 1, we calculated the number of images nec-

essary to achieve the desired data augmentation per-

centage for each attack vector.

3.3 Model Training

Vision transformers have received much attention

in recent years (Han et al., 2022). Initially, re-

searchers used transformers for natural language pro-

cessing (Vaswani et al., 2017), but their success in

this ﬁeld caught the attention of computer vision

researchers. Kolesnikov et al. (2021) harnessed the

power of transformers for computer vision tasks by

making minor alterations. Instead of providing tokens

to a transformer as input, they divided an image into

patches and used the patch embeddings. In doing so,

they created what is now known as a Vision Trans-

former (ViT). Vision transformers have achieved re-

markable results in image classiﬁcation tasks (Krish-

nan and Krishnan, 2021).

We followed a similar approach to George and

Marcel (2021), who achieved state-of-the-art results

in face anti-spooﬁng using their ViT. Moreover, we

regard face anti-spooﬁng as a binary classiﬁcation

problem in which a sample is either bona ﬁde or a

spoof. For clarity, we deﬁne a bona ﬁde sample as

a genuine sample directly acquired from an individ-

ual. Furthermore, we deﬁne a spoof sample as a fabri-

cated sample of an individual captured indirectly from

a presented medium. Lastly, we employ a static face

anti-spooﬁng approach by analysing each frame inde-

pendently.

4 EXPERIMENT SETUP

4.1 Datasets

There are a variety of publicly available datasets

for face anti-spooﬁng. To evaluate the effectiveness

of our approach, we used the CASIA Face Anti-

Spooﬁng Database (CASIA-FASD) and Spoof in the

Wild (SiW) Database.

CASIA-FASD (Zhang et al., 2012). In 2012, ﬁfty

subjects participated in producing 600 videos cap-

tured in natural scenes with no artiﬁcial environment

uniﬁcation. These researchers recorded each sub-

ject normally (N) and created cut-photo (C), warped-

photo (W) and video-replay (R) attacks using a low

(1), medium (2) and high-resolution (HR) camera.

For clarity, we denote A as the attack vector and B

as the resolution in A B. For example, W HR corre-

sponds to a warped-photo attack sample captured with

a high-resolution camera.

This dataset contains seven protocols for training

and evaluating a model’s performance. Protocols 1 to

3 correspond to training and testing using only low,

medium, and high-resolution videos. Similarly, pro-

tocols 4 to 6 correspond to training and testing us-

ing only warped, cut-photo and video-replay attack

videos. Lastly, protocol 7 uses all the videos for train-

ing and testing.

Keyframe and GAN-Based Data Augmentation for Face Anti-Spooﬁng

631

Inference

Original Training

Dataset

Preprocessing

Data Augmentation

Model Training Trained Model

Traditional

Candidates

GAN3

Candidates

KFGAN3

Candidates

Augmentation

ViTT

ViTGAN3

ViTKFGAN3

ViT

Aack Vectors

Traditional

Candidates

Traditional

Augmentation

(Original Dataset)

Horizontal Flips,

Rotations,

Magniﬁcation

KFGAN3

Candidates

Generative

Augmentation

(Keyframe Dataset)

StyleGAN3-R

Aack Vectors

Keyframe

Dataset

GAN3

Candidates

Generative

Augmentation

(Original Dataset)

StyleGAN3-R

Aack Vectors

Original

Dataset

Data Synthesis

3 4

Figure 1: The stages of the proposed training pipeline.

SiW (Liu et al., 2018). In 2018, 165 subjects partic-

ipated in producing 4 478 videos, each with a differ-

ent distance, pose, illumination and expression. This

dataset contains high-resolution normal (N), photo

(P) and video-replay (R) attack videos. The re-

searchers captured the normal videos using two light-

ing variations: no lighting variation (NLV) and dif-

ferent lighting variation (ELV). To create the photo

attacks, they captured low-resolution (LR) and high-

resolution (HR) images of each subject, which they

then printed on glossy and matte paper. Lastly, the

video-replay attacks utilised a Samsung Galaxy S8

(SGS8), an iPhone 7 Plus (IP7P), iPad Pro 2017

(IPP2017) and an ASUS MB168B laptop screen

(ASUS) to display the bona ﬁde videos.

This dataset contains three protocols to evaluate a

model’s performance. Protocol 1 evaluates the gener-

alisation capabilities by only training on the ﬁrst 60

frames of the training set videos with mainly frontal

view faces and testing on all the frames of the test

set videos. Since we cannot guarantee that a gen-

erated image will be within the ﬁrst 60 frames, we

will not perform this protocol. Protocol 2 evaluates

the generalisation capability on cross-mediums of the

same spoof type. This protocol follows a leave-one-

out (LOO) strategy, repeated for all mediums: using

three replay-attack mediums for training and leaving

the remaining medium for testing. Lastly, protocol

3 evaluates a model’s performance on unknown pre-

sentation attacks. This protocol is similar to proto-

col 2, using attack vectors rather than spoof medi-

ums. For clarity in later sections, we denote LOO X

as the group left out for training and used exclusively

for testing, where X is a video-replay spoof medium

(ASUS, IP7P, IPP2017 or SGS8) in protocol two and

an attack vector (P or R) in protocol three.

Since protocols 2 and 3 utilise various training

combinations, it is essential to use the mean and stan-

dard deviation of the combinations when reporting

metrics. For comparability with other work, we used

the videos of subjects 90 for training and 75 for test-

ing. Figures 2 and 3 display a sample frame from

each video captured for subjects 75 and 90, respec-

tively. We display the sample type (ST) and medium

(M) for each sample in both ﬁgures.

Although CASIA-FASD is an older and smaller

dataset compared to other face anti-spooﬁng datasets,

we selected it because it contains cut-photo attacks

ICPRAM 2023 - 12th International Conference on Pattern Recognition Applications and Methods

632

Figure 2: The middle frame of each video for subject 75

from the SiW database, where ST and M correspond to the

sample type and medium.

Figure 3: The middle frame of each video for subject 90

from the SiW database, where ST and M correspond to the

sample type and medium.

and low-resolution videos. Furthermore, we selected

SiW for its variation in the subjects’ distance, pose,

illumination and expression.

4.2 Dataset Augmentation

A traditional approach to data augmentation involves

applying random transformations to an image, such

as varying brightness, rotating, or cropping (P

erez-

Cabo et al., 2019). However, some of these trans-

formations could adversely affect the sample’s label

due to the nature of the problem environment (Shorten

and Khoshgoftaar, 2019). For instance, in some

video-replay attack samples, the LCD screen back-

light makes them appear brighter than the correspond-

ing bona ﬁde sample, as shown in Figures 2 and 3.

Thus, altering the brightness of the spoof samples

may lead to an unclear decision boundary due to label

contradictions. Hence, when using the traditional data

augmentation approach, we only use random horizon-

tal ﬂips, rotations (within 15°), and magniﬁcations

(within 20%).

In contrast to traditional data augmentation,

GANs can create new samples that match the char-

acteristics of an image domain while maintaining the

label given to the original samples. We selected the

StyleGAN3 architecture for the generative data aug-

mentation approach. StyleGAN3 improved the im-

age synthesis by linking details to depicted object sur-

faces rather than absolute coordinates (Karras et al.,

2021). Additionally, it inherits the enhanced training

stabilisation from StyleGAN2 (Karras et al., 2020),

enabling it to achieve good results on smaller datasets.

Thus, StyleGAN3 can synthesise high-ﬁdelity images

with limited data, making it state-of-the-art in image

generation.

We chose the alias-free rotation equivariant archi-

tecture (StyleGAN3-R) and trained each model using

the associated training conﬁguration for 2 GPUs with

a 256 by 256-pixel resolution for 5000 kimg, where

kimg is the number of thousand images from the train-

ing set. We selected the model with the lowest Frechet

Inception Distance (FID) (Heusel et al., 2017) to gen-

erate the candidate samples. We used ordered seeds

from 1 to N

and a truncation psi value of 1 (for max-

imum variation).

For clariﬁcation, we synthesised images for each

attack vector separately, with each image labelled as

a spoof. Although it is possible to generate images

using bona ﬁde samples, labelling them as such could

introduce a DeepFake attack vulnerability. Figure 4

illustrates the synthesised images for each SiW attack

vector using each data augmentation approach.

4.3 Face Anti-Spooﬁng

Training a ViT from beginning to end is very

resource-intensive, requiring adequate hardware and

a large dataset. Fortunately, researchers developed a

technique to alleviate this burden known as transfer

learning (Li and Lee, 2021). Transfer learning en-

ables us to use the knowledge learned by a model for

one task and apply it to another. Following (George

and Marcel, 2021), we used a pre-trained ImageNet

ViT-B/32 model and ﬁne-tuned the output to meet

our needs. We resized the input images to 224 by

224 pixels and replaced the last layer with a two-

Keyframe and GAN-Based Data Augmentation for Face Anti-Spooﬁng

633

Original Traditional Generative

ASUSIP7PIPP2017SGS8P

Figure 4: The synthesised images for each SiW attack vec-

tor. The columns and rows correspond to the sample sets

and attack vectors.

node dense layer with a SoftMax activation. We froze

all the layers before the ﬁnal layer and trained the

model using binary cross-entropy loss, optimised with

Adam (Kingma and Ba, 2014) at a learning rate of

1e−4. Using early stopping (with a patience value of

15), we trained each model for 70 epochs and restored

the version with the lowest validation loss before test-

ing.

We determined the optimal data augmenta-

tion percentage by performing a hyperparameter

search (Liaw et al., 2018) for the following augmen-

tation percentages: 5, 10, 20, and 30. Using a strati-

ﬁed 3-fold cross-validation (Rodr

ıguez and Lozano,

2007) approach, we split the training dataset into

80% for training and 20% for validation, each with

a batch size of 32. We repeated each trial twice

and averaged the following ISO/IEC

30107-3

(ISO/IEC,

2017) metrics to compare our approach with simi-

lar work: Bonaﬁde Presentation Classiﬁcation Error

Rate (BPCER), Attack Presentation Classiﬁcation Er-

ror Rate (APCER) and Average Classiﬁcation Error

Rate (ACER). BPCER is the proportion of bona ﬁde

samples incorrectly classiﬁed as an attack. Similarly,

APCER is the proportion of attack samples incor-

rectly classiﬁed as bona ﬁde. Finally, ACER is the

mean of APCER and BPCER. Additionally, we re-

port the Equal Error Rate (ERR) for comparisons with

older face anti-spooﬁng approaches, which in the con-

text of biometric anti-spooﬁng, is the point where the

APCER and BPCER are equal (Ben Mabrouk and Za-

grouba, 2018).

4.4 Keyframe Selection

Hardly any movement in a one-second video can re-

sult in 24 near-duplicate frames. We investigated

these near-duplicate frames’ effect on the ViT train-

ing. To do this, we employed the following three-

stage unsupervised keyframe selection process.

Stage 1: Feature Extraction. We extracted fea-

tures from the preprocessed frames using a ResNet-50

backbone, pre-trained on the VGGFace2 dataset. This

large facial recognition dataset contains 9131 subjects

of various ages, ethnicities and professions in various

poses and illumination (Cao et al., 2018), making it

suitable for our task.

Stage 2: Feature Clustering. We clustered the ex-

tracted features using Lloyd’s K-Means clustering al-

gorithm. To do so, we used the Facebook AI Simi-

larity Search (FAISS) (Johnson et al., 2019) library,

which harnesses the power of GPUs and is currently

the fastest implementation of Lloyd’s K-Means clus-

tering algorithm. We conducted a hyperparameter

search to ﬁnd the K that maximises the Silhouette

Score (Shahapure and Nicholas, 2020) to determine

the optimal K.

Stage 3: Keyframe Selection. For each category,

we calculated the mean optimal K. For CASIA-

FASD, we used the attack vectors as the categories;

for Spoof in the Wild, we used the medium names

associated with each session. We again clustered

the extracted features; however, we used the corre-

sponding categorical mean optimal K to obtain the

cluster centroids. Finally, we used vector quantisa-

tion to determine the features closest to these cen-

troids and selected the corresponding images as the

keyframes. Figures 5 and 6 illustrate the ﬁnal result

of the keyframe selection process.

Table 1 shows the ablation study for selecting the

optimal K for CASIA-FASD. Looking at this table,

we can see that the standard deviation is greater than

the mean, implying that the optimal Ks are moder-

ately dispersed. The dispersion occurs between the

and 100

percentiles values. If we look at the

ICPRAM 2023 - 12th International Conference on Pattern Recognition Applications and Methods

634

Figure 5: The original frames for subject 18, video 1 in the

CASIA-FASD test release.

Figure 6: The keyframes for subject 18, video 1 in the

CASIA-FASD test release.

percentile, the values are close to the mean ex-

cept for the medium resolution warped-photo attack

category (W 2). Thus, using the categorical-mean op-

timal K is better than the individual-video optimal K

due to outlier videos. Figure 7 depicts the Keyframe

reduction effect on CASIA-FASD. The unsupervised

keyframe reduction process reduced the 110 882

frames in the original dataset to 7850 keyframes, re-

sulting in a 1412% frame reduction.

Figure 7: The number of original frames (blue) vs the num-

ber of keyframes (red) for each video in the CASIA-FASD

ordered by video frame count.

To avoid confusion, we introduce notations to dis-

tinguish the Vision Transformer models using their

corresponding data augmentation approach. We be-

gin by representing the baseline model, trained on

Table 1: The mean, std. deviation and ﬁve-number-

summary for the optimal K of each attack vector in CASIA-

FASD.

Five-Number-Summary

Attack Vector Mean Min 25

Max

N 1 14.2 ± 15 2 2 5 23.3 42

N 2 9.6 ± 16.8 2 2 2.5 4.3 54

N HR 12.3 ± 20.2 2 2 3 5.3 68

C 1 2.2 ± 0.2 2 2 2 2 3

C 2 2.2 ± 0.5 2 2 2 2 4

C HR 3.1 ± 4.2 2 2 2 2 21

W 1 32.8 ± 21.4 2 20.3 31.5 49.5 73

W 2 17.4 ± 30.9 2 2 3 4.5 95

W HR 20.7 ± 28.5 2 2.8 4.5 39.8 101

R 1 14.1 ± 20.8 2 2 2.5 18.3 63

R 2 10.8 ± 13 2 2 2 21.3 40

R HR 18.2 ± 29.5 2 2 2.5 14.5 85

Figure 8: The average metrics of the traditional (ViTT) and

generative (ViTGAN3 and ViTKFGAN3) data augmenta-

tion models performed before (B) and after (A) the valida-

tion split for SiW protocols 2 and 3, using data augmenta-

tion percentages: 5, 10, 20 and 30.

the original dataset with no data augmentation as

ViT. Next, we represent a ViT model optimised using

the traditional data augmentation approach as ViTT.

Since our generative data augmentation approach uses

StyleGAN3-R models, we represent a ViT model op-

timised with this approach as ViTGAN3. We intro-

duce KFGAN3 as a keyframe generative data aug-

mentation approach, in which we train the Style-

GAN3 models using only the keyframes. Thus, we

represent a ViT model optimised with the keyframe

generative data augmentation approach as ViTKF-

GAN3.

5 RESULTS

We conducted an ablation study using SiW protocols

1 and 2 to determine when to perform data augmen-

tation, the optimal data augmentation percentage, and

the optimal number of frames to detect face spooﬁng.

Keyframe and GAN-Based Data Augmentation for Face Anti-Spooﬁng

635

Table 2: The performance of the baseline (ViT), traditional data augmentation (ViTT) and generative data augmentation

(ViTGAN3, ViTKFGAN3) models for SiW protocols 2 and 3, in terms of ACER (%) for the image-based and video-based

classiﬁcation approaches, using a window size of 5, 7, 10, and 15.

Model Aug. (%)

Protocol 2 Protocol 3

Image 5 7 10 15 Image 5 7 10 15

ViT (Baseline) 0 3.51 0 0 0 0 8.92 2.83 1.49 1.19 0

ViTT (Before)

5 4.08 0.78 0.26 0.26 0 8.79 2.08 2.08 1.19 0.3

10 3.4 0 0 0 0 8.45 2.9 2.9 2.01 0.3

20 4.28 0.26 0.26 0.26 0.26 8.48 2.98 2.68 1.49 0

30 4.02 0.26 0.26 0 0 8.06 2.98 2.98 2.38 0.3

ViTT (After)

5 3.39 0 0 0 0 9.08 3.13 2.53 1.93 1.34

10 3.5 0 0 0 0 7.96 1.79 1.79 1.49 1.04

20 3.66 0 0 0 0 7.94 3.27 2.68 1.19 0.3

30 3.8 0.26 0.26 0.26 0 7.62 2.68 2.68 1.79 0.3

ViTGAN3 (Before)

5 3.89 0 0 0 0 9.12 2.68 2.38 2.08 1.79

10 3.43 0 0 0 0 11.4 5.21 5.21 4.02 4.32

20 3.04 0.52 0.52 0 0 11.34 3.57 3.57 2.68 2.68

30 3.42 0 0 0 0 12.01 5.51 5.51 4.61 5.21

ViTGAN3 (After)

5 3.94 1.04 1.04 1.04 0.52 9.13 2.38 2.08 1.79 0.89

10 3.29 0.26 0.26 0.26 0.26 11.98 5.36 5.36 4.46 4.46

20 3.88 0.78 0.26 0.52 0.26 11.25 5.95 5.65 4.76 3.87

30 3.38 0 0 0 0 11.39 8.78 8.78 8.18 7.59

ViTKFGAN3 (Before)

5 4.43 1.3 1.3 0.78 0.52 9.67 3.87 3.87 3.27 2.68

10 4.17 0.52 0.52 0.52 0.52 8.13 3.13 3.13 1.93 1.04

20 3.42 0 0 0 0 8.57 2.08 2.83 2.83 2.23

30 4.03 0 0 0 0 7.73 2.08 1.49 0.595 0

ViTKFGAN3 (After)

5 3.97 0.26 0.52 0 0 7.37 1.93 2.53 1.34 1.93

10 3.47 0 0 0 0 9.33 2.9 2.31 2.01 2.23

20 3.64 0 0 0 0 7.38 1.64 1.64 1.64 1.04

30 3.74 0 0 0 0 8.34 1.79 1.19 0.595 0

Data Augmentation Before or After the Valida-

tion Split. As illustrated in Figure 8, the generative

data augmentation approach (GAN3) performed bet-

ter for both protocols and achieved its lowest ACER

before the validation split. In contrast, the tradi-

tional data augmentation approach performed better

and achieved its lowest ACER after the split. Inter-

estingly, the keyframe generative data augmentation

(KFGAN3) performed better before the split for pro-

tocol two and after the split for protocol 3. Tables 5

and 6 conﬁrm these results on the CASIA-FASD,

except for the ViTGAN3 ACER, which performed

slightly better after the split.

The Optimal Data Augmentation Percentage

(DAP). As shown in Figure 8, the GAN3 approach

works best with a DAP of 20% and 0% for protocols 2

and 3, respectively. Similarly, the KFGAN3 approach

works best with a DAP of 20% and 5% for protocols

2 and 3, respectively. Lastly, the traditional approach

works best with a DAP of 5% and 30% for protocols

2 and 3, respectively. Tables 5 and 6 conﬁrm that

beyond 30%, we encounter diminishing returns.

Image-Based Classiﬁcation Versus Video-Based

Classiﬁcation. One advantage of using a static

analysis approach to face anti-spooﬁng is that it can

be incorporated into image-based and video-based

recognition systems. Accordingly, we investigated

the effectiveness of our approach in each scenario by

using image-based and video-based classiﬁcation. We

treated each video frame as a separate presentation

attempt for image-based classiﬁcation and classiﬁed

them independently. For video-based classiﬁcation,

we treated each video as a separate presentation at-

tempt by aggregating the predictions from the ﬁrst ‘n’

frames and using the majority vote as the ﬁnal label.

When n is even, the vote favours the spoof label. The

study results are shown in Table 2.

Starting with the image-based classiﬁcation

method, we found that the GAN3 approach performed

the best in SiW protocol 2 but the worst in protocol

3. In contrast, the KFGAN3 approach performed the

best in protocol 3 but the worst in protocol 2. Upon in-

vestigation, we observed that the FID of the KFGAN3

models was much larger than the GAN3 models, as

shown in Table 4. Since FID is a measure of similar-

ity between the generated and original samples, there

is more variability in the training set using KFGAN3

ICPRAM 2023 - 12th International Conference on Pattern Recognition Applications and Methods

636

Table 3: The performance of the models trained with the traditional (ViTT) and generative data augmentation (ViTGAN3 and

ViTKFGAN3) approaches, compared to similar work models on protocols 2 and 3 of SiW. We denote ‘-B’ and ‘-A’ as our

models trained with data augmentation before and after the validation split, respectively. As a reminder, we did not perform

protocol one since we could not guarantee that the generated image would appear within the ﬁrst 60 frames.

Model Classiﬁcation Approach Metric (%)

Protocol

2 3

Auxiliary (Liu et al., 2018) Video-based

APCER 0.57 ± 0.69 8.31 ± 3.81

BPCER 0.57 ± 0.69 8.31 ± 3.80

ACER 0.57 ± 0.69 8.31 ± 3.81

CDCN (Yu et al., 2020) Image-based

APCER 0.00 ± 0.00 1.67 ± 0.11

BPCER 0.13 ± 0.09 1.76 ± 0.12

ACER 0.06 ± 0.04 1.71 ± 0.11

CDCN++ (Yu et al., 2020) Image-based

APCER 0.00 ± 0.00 1.97 ± 0.33

BPCER 0.09 ± 0.1 1.77 ± 0.1

ACER 0.04 ± 0.05 1.90 ± 0.15

FAS-SGTD (Wang et al., 2020) Video-based

APCER 0.00 ± 0.00 2.63 ± 3.72

BPCER 0.04 ± 0.08 2.92 ± 3.42

ACER 0.02 ± 0.04 2.78 ± 3.57

FasTCo (Xu et al., 2021) Video-based

APCER 0.02 ± 0.02 2.73 ± 0.91

BPCER 0.00 ± 0.00 1.28 ± 0.21

ACER 0.01 ± 0.01 2.00 ± 0.56

PatchNet (Wang et al., 2022) Image-based

APCER 0.00 ± 0.00 3.06 ± 1.10

BPCER 0.00 ± 0.00 1.83 ± 0.83

ACER 0.00 ± 0.00 2.45 ± 0.45

ViTGAN3-B (20%) Image-based

APCER 5.31 ± 5.86 20.59 ± 18.63

BPCER 0.78 ± 0.78 2.08 ± 4.49

ACER 3.04 ± 2.91 11.34 ± 8.57

ViTKFGAN3-A (5%) Image-based

APCER 5.51 ± 5.88 13.79 ± 11.62

BPCER 2.42 ± 2.77 0.95 ± 0.84

ACER 3.97 ± 2.62 7.37 ± 5.45

ViTKFGAN3-A (30%) Video-based

APCER 0.00 ± 0.00 1.19 ± 2.78

BPCER 0.00 ± 0.00 0.00 ± 0.00

Window size of 10 ACER 0.00 ± 0.00 0.595 ± 1.39

ViTKFGAN3-A (30%) Video-based

APCER 0.00 ± 0.00 0.00 ± 0.00

BPCER 0.00 ± 0.00 0.00 ± 0.00

Window size of 15 ACER 0.00 ± 0.00 0.00 ± 0.00

Table 4: The FID for the StyleGAN3 models trained using

the original frames (GAN3) and keyframes (KFGAN3) for

each attack vector in SiW.

Attack Vector FID

Model ASUS IP7P IPP2017 SGS8 P

GAN3 25.33 18.18 34.76 35.14 26.47

KFGAN3 54.66 57.91 99.41 82.98 66.38

than GAN3-generated candidates. Furthermore, per-

forming the data augmentation after the split can in-

crease the variability of the training set. The high

variability seems beneﬁcial for unseen presentation

attacks (protocol 3), and the low variability appears

beneﬁcial for unseen spoof mediums of the same type

(protocol 2).

Regarding the optimal frame window, we found

no need for data augmentation for protocol 2 when

using frame sizes 5, 7, 10 and 15. Moreover, we

found that the baseline, traditional, and KFGAN3 ap-

proaches achieved state-of-the-art performance across

both protocols using a frame size of 15. Despite this

remarkable performance, we found that the KFGAN3

approach achieves comparable performance with less

processing time, using a window size of 10. As the

window size increases, the image-based classiﬁcation

trend emerges with reduced error values. As for the

CASIA-FASD, we found that the KFGAN3 approach

performed the best for image and video-based classi-

ﬁcation when using a window size of 7. Even though

the other approaches achieved the same ACER and

EER values using the same window size, the KF-

GAN3 approach achieved the lowest values simulta-

neously. Thus, the optimal window size for video-

based classiﬁcation lies between the ﬁrst 7 (CASIA-

FASD) and 15 frames (SiW). From this study, we sus-

pect that the ﬁrst few video frames can effectively re-

veal whether a presentation is genuine or a spoof.

Tables 3 and 7 benchmark our approach against

similar research. Although our independent frame ap-

proach improved the baseline model’s performance,

more was needed to compete with the state-of-the-

Keyframe and GAN-Based Data Augmentation for Face Anti-Spooﬁng

637

Table 5: The performance of the baseline (ViT), traditional

data augmentation (ViTT) and generative data augmenta-

tion (ViTGAN3, ViTKFGAN3) models for CASIA-FASD

protocol 7 in terms of EER (%) for the image-based and

video-based (window size of 7) classiﬁcation approaches.

Model Aug. (%)

EER (%)

Image Video

ViT (Baseline) 0 1.75 2.01

ViTT (Before)

5 1.96 2.18

10 2 1.83

20 2.12 2.36

30 2.18 2.36

ViTT (After)

5 1.89 1.65

10 1.96 1.82

20 2.13 2

30 2.21 1.82

ViTGAN3 (Before)

5 1.77 1.65

10 1.72 1.47

20 1.75 1.71

30 1.81 1.29

ViTGAN3 (After)

5 1.72 1.53

10 1.8 1.83

20 1.83 1.65

30 1.87 1.83

ViTKFGAN3 (Before)

5 1.71 1.83

10 1.71 1.29

20 1.73 1.47

30 1.85 1.65

ViTKFGAN3 (After)

5 1.78 1.83

10 1.82 1.83

20 1.86 2.01

30 1.9 2.01

art image-based classiﬁcation methods. However, our

video-based classiﬁcation approach achieved top per-

formance across both SiW protocols. Although the

baseline and traditional approaches obtained the same

results as the KFGAN3 approach using a window size

of 15, we decided the KFGAN3 approach was the best

when considering its performance on CASIA-FASD.

Upon investigating our suspicion of the ﬁrst few

frames’ effectiveness, we found that (Xu et al., 2021)

also encountered this phenomenon and hypothesised

large motions and illumination changes to be the

cause. Unlike (Xu et al., 2021), who developed

a module to estimate uncertainty for a sequence of

frames, we found improved performance using a ma-

jority vote on the ﬁrst ﬁfteen frames.

6 CONCLUSION

In this work, we optimised the performance of a vi-

sion transformer using generative and traditional data

augmentation approaches. We trained a StyleGAN3

model for each attack vector and used these models

to generate candidate samples. We extended this ap-

Table 6: The performance of the baseline (ViT), traditional

data augmentation (ViTT) and generative data augmenta-

tion (ViTGAN3, ViTKFGAN3) models for CASIA-FASD

protocol 7 in terms of ACER (%) for the image-based and

video-based (window size of 7) classiﬁcation approaches.

Model Aug. (%)

ACER (%)

Image Video

ViT (Baseline) 0 1.42 1.42

ViTT (Before)

5 1.39 1.45

10 1.38 1.27

20 1.38 1.39

30 1.41 1.45

ViTT (After)

5 1.37 1.11

10 1.39 1.17

20 1.41 1.2

30 1.42 1.2

ViTGAN3 (Before)

5 1.37 1.2

10 1.36 1.11

20 1.41 1.36

30 1.42 1.14

ViTGAN3 (After)

5 1.36 1.11

10 1.35 1.27

20 1.35 1.23

30 1.36 1.3

ViTKFGAN3 (Before)

5 1.42 1.3

10 1.36 1.11

20 1.34 1.14

30 1.38 1.23

ViTKFGAN3 (After)

5 1.36 1.27

10 1.36 1.2

20 1.35 1.36

30 1.34 1.3

Table 7: The performance of the models trained with the

traditional (ViTT) and generative data augmentation (ViT-

GAN3 and ViTKFGAN3) compared to similar work models

using CASIA-FASD protocol 7. We denote ‘-B’ and ‘-A’ as

our models trained with data augmentation before and af-

ter the validation split. Moreover, ‘I’ and ‘V’ correspond

to image-based and video-based classiﬁcation approaches,

with ‘W-N’ denoting the ﬁrst N frames.

Model Approach EER (%)

DoG (Zhang et al., 2012) I 17.00

LBP (Boulkenafet et al., 2016) I 3.20

Deep LBP (Li et al., 2017a) I 2.30

Hybrid CNN (Li et al., 2017b) I 2.2

Attention CNN (Chen et al., 2020) V 3.145

Dropblock (Wu et al., 2021) I 1.12

ViTKFGAN3-B (10%) I 1.71

ViTKFGAN3-B W-7 (10%) V 1.29

proach by training the StyleGAN3 models using only

keyframes rather than all the training samples. We im-

plemented the traditional data augmentation approach

using random rotations, horizontal ﬂips and magniﬁ-

cations.

We found that the samples generated using

keyframes increased the variability among the train-

ICPRAM 2023 - 12th International Conference on Pattern Recognition Applications and Methods

638

ing and validation sets, whereas the samples gener-

ated using all the frames increased the similarity. We

found high variability beneﬁcial for unknown presen-

tation attack detection and high similarity beneﬁcial

for unknown presentation attacks of the same kind.

We explored face anti-spooﬁng performance using

image-based and video-based classiﬁcation methods.

We found the ﬁrst few frames more effective for de-

tecting face spooﬁng attacks than using each frame

independently. The keyframe data augmentation ap-

proach using the ﬁrst 15 frames achieved the top per-

formance for Spoof in the Wild protocols 2 and 3.

The SiW and CASIA-FASD results proved

keyframe data augmentation to be the most effective

approach. Furthermore, we suspect augmenting train-

ing sets with generated spoof images can make deep

learning models more robust against DeepFake at-

tacks. We will investigate this in future work, along

with more advanced GAN image generation tech-

niques.

ACKNOWLEDGEMENTS

The support and resources from the South African

Lengau cluster at the Centre for High-Performance

Computing (CHPC) are gratefully acknowledged.

REFERENCES

Ali, A., Deravi, F., and Hoque, S. (2013). Directional

sensitivity of gaze-collinearity features in liveness de-

tection. In 2013 Fourth International Conference on

Emerging Security Technologies, pages 8–11.

Bao, W., Li, H., Li, N., and Jiang, W. (2009). A liveness

detection method for face recognition based on optical

ﬂow ﬁeld. In 2009 International Conference on Image

Analysis and Signal Processing, pages 233–236.

Ben Mabrouk, A. and Zagrouba, E. (2018). Abnormal be-

havior recognition for intelligent video surveillance

systems: A review. Expert Systems with Applications,

91:480–491.

Bischoff, P. (2021). Facial recognition technology (frt): 100

countries analyzed - comparitech.

Boulkenafet, Z., Komulainen, J., and Hadid, A. (2016).

Face spooﬁng detection using colour texture analysis.

IEEE Transactions on Information Forensics and Se-

curity, 11(8):1818–1830.

Boulkenafet, Z., Komulainen, J., and Hadid, A. (2017).

Face antispooﬁng using speeded-up robust features

and ﬁsher vector encoding. IEEE Signal Processing

Letters, 24(2):141–145.

Cao, Q., Shen, L., Xie, W., Parkhi, O. M., and Zisserman,

A. (2018). Vggface2: A dataset for recognising faces

across pose and age. In 2018 13th IEEE International

Conference on Automatic Face & Gesture Recognition

(FG 2018), pages 67–74.

Chen, H., Hu, G., Lei, Z., Chen, Y., Robertson, N. M., and

Li, S. Z. (2020). Attention-based two-stream convo-

lutional networks for face spooﬁng detection. IEEE

Transactions on Information Forensics and Security,

15:578–593.

Daniel, N. and Anitha, A. (2018). A study on recent trends

in face spooﬁng detection techniques. In 2018 3rd

International Conference on Inventive Computation

Technologies (ICICT), pages 583–586.

George, A. and Marcel, S. (2021). On the effectiveness of

vision transformers for zero-shot face anti-spooﬁng.

In 2021 IEEE International Joint Conference on Bio-

metrics (IJCB), pages 1–8.

Han, K., Wang, Y., Chen, H., Chen, X., Guo, J., Liu, Z.,

Tang, Y., Xiao, A., Xu, C., Xu, Y., Yang, Z., Zhang, Y.,

and Tao, D. (2022). A survey on vision transformer.

IEEE Transactions on Pattern Analysis and Machine

Intelligence, pages 1–1.

Hernandez-Ortega, J., Fierrez, J., Morales, A., and Galbally,

J. (2021). Introduction to presentation attack detection

in face biometrics and recent advances.

Heusel, M., Ramsauer, H., Unterthiner, T., Nessler, B., and

Hochreiter, S. (2017). Gans trained by a two time-

scale update rule converge to a local nash equilibrium.

ISO/IEC (2017). International Organization for Standard-

ization. Information technology - Biometric presenta-

tion attack detection - Part 3: Testing and reporting.

Technical Report ISO/IEC FDIS 30107-3:2017(E),

Geneva, CH.

Jain, A. K., Flynn, P., and Ross, A. A. (2007). Handbook of

biometrics. Springer Science & Business Media.

Johnson, J., Douze, M., and J

egou, H. (2019). Billion-scale

similarity search with GPUs. IEEE Transactions on

Big Data, 7(3):535–547.

Karras, T., Aittala, M., Hellsten, J., Laine, S., Lehtinen, J.,

and Aila, T. (2020). Training generative adversarial

networks with limited data. In Proc. NeurIPS.

Karras, T., Aittala, M., Laine, S., H

ark

onen, E., Hellsten, J.,

Lehtinen, J., and Aila, T. (2021). Alias-free generative

adversarial networks. In Proc. NeurIPS.

Kingma, D. P. and Ba, J. (2014). Adam: A method for

stochastic optimization.

Kolesnikov, A., Dosovitskiy, A., Weissenborn, D., Heigold,

G., Uszkoreit, J., Beyer, L., Minderer, M., Dehghani,

M., Houlsby, N., Gelly, S., Unterthiner, T., and Zhai,

X. (2021). An image is worth 16x16 words: Trans-

formers for image recognition at scale.

Krishnan, K. S. and Krishnan, K. S. (2021). Vision trans-

former based covid-19 detection using chest x-rays. In

2021 6th International Conference on Signal Process-

ing, Computing and Control (ISPCC), pages 644–648.

Li, J.-W. (2008). Eye blink detection based on multiple

gabor response waves. In 2008 International Con-

ference on Machine Learning and Cybernetics, vol-

ume 5, pages 2852–2856.

Li, L., Feng, X., Jiang, X., Xia, Z., and Hadid, A. (2017a).

Face anti-spooﬁng via deep local binary patterns. In

Keyframe and GAN-Based Data Augmentation for Face Anti-Spooﬁng

639

2017 IEEE International Conference on Image Pro-

cessing (ICIP), pages 101–105.

Li, L., Xia, Z., Li, L., Jiang, X., Feng, X., and Roli, F.

(2017b). Face anti-spooﬁng via hybrid convolutional

neural network. In 2017 International Conference on

the Frontiers and Advances in Data Science (FADS),

pages 120–124.

Li, T.-W. and Lee, G.-C. (2021). Performance analysis of

ﬁne-tune transferred deep learning. In 2021 IEEE 3rd

Eurasia Conference on IOT, Communication and En-

gineering (ECICE), pages 315–319.

Liaw, R., Liang, E., Nishihara, R., Moritz, P., Gonzalez,

J. E., and Stoica, I. (2018). Tune: A research platform

for distributed model selection and training. arXiv

preprint arXiv:1807.05118.

Liu, Y., Jourabloo, A., and Liu, X. (2018). Learning deep

models for face anti-spooﬁng: Binary or auxiliary su-

pervision. In 2018 IEEE/CVF Conference on Com-

puter Vision and Pattern Recognition, pages 389–398.

Nagpal, C. and Dubey, S. R. (2019). A performance eval-

uation of convolutional neural networks for face anti

spooﬁng. In 2019 International Joint Conference on

Neural Networks (IJCNN), pages 1–8.

erez-Cabo, D., Jim

enez-Cabello, D., Costa-Pazo, A., and

opez-Sastre, R. J. (2019). Deep anomaly detection

for generalized face anti-spooﬁng. In 2019 IEEE/CVF

Conference on Computer Vision and Pattern Recogni-

tion Workshops (CVPRW), pages 1591–1600.

Rodr

ıguez, J. and Lozano, J. (2007). Repeated stratiﬁed k-

fold cross-validation on supervised classiﬁcation with

naive bayes classiﬁer: An empirical analysis.

Shahapure, K. R. and Nicholas, C. (2020). Cluster qual-

ity analysis using silhouette score. In 2020 IEEE 7th

International Conference on Data Science and Ad-

vanced Analytics (DSAA), pages 747–748.

Shorten, C. and Khoshgoftaar, T. (2019). A survey on image

data augmentation for deep learning. Journal of Big

Data, 6.

Ur Rehman, Y. A., Po, L. M., and Liu, M. (2017). Deep

learning for face anti-spooﬁng: An end-to-end ap-

proach. In 2017 Signal Processing: Algorithms, Ar-

chitectures, Arrangements, and Applications (SPA),

pages 195–200.

van der Haar, D. T. (2019). Face antispooﬁng using shear-

lets: An empirical study. SAIEE Africa Research Jour-

nal, 110(2):94–103.

Vaswani, A., Shazeer, N., Parmar, N., Uszkoreit, J., Jones,

L., Gomez, A. N., Kaiser, L. u., and Polosukhin,

I. (2017). Attention is all you need. In Guyon,

I., Luxburg, U. V., Bengio, S., Wallach, H., Fer-

gus, R., Vishwanathan, S., and Garnett, R., editors,

Advances in Neural Information Processing Systems,

volume 30. Curran Associates, Inc.

Walsh, J., O’ Mahony, N., Campbell, S., Carvalho, A., Kr-

palkova, L., Velasco-Hernandez, G., Harapanahalli,

S., and Riordan, D. (2019). Deep learning vs. tradi-

tional computer vision.

Wang, C.-Y., Lu, Y.-D., Yang, S.-T., and Lai, S.-H. (2022).

Patchnet: A simple face anti-spooﬁng framework via

ﬁne-grained patch recognition. In 2022 IEEE/CVF

Conference on Computer Vision and Pattern Recog-

nition (CVPR), pages 20249–20258.

Wang, Z., Yu, Z., Zhao, C., Zhu, X., Qin, Y., Zhou, Q.,

Zhou, F., and Lei, Z. (2020). Deep spatial gradient

and temporal depth learning for face anti-spooﬁng. In

2020 IEEE/CVF Conference on Computer Vision and

Pattern Recognition (CVPR), pages 5041–5050.

Wu, G., Zhou, Z., and Guo, Z. (2021). A robust method with

dropblock for face anti-spooﬁng. In 2021 Interna-

tional Joint Conference on Neural Networks (IJCNN),

pages 1–8.

Xu, X., Xiong, Y., and Xia, W. (2021). On improving tem-

poral consistency for online face liveness detection

system. In 2021 IEEE/CVF International Conference

on Computer Vision Workshops (ICCVW), pages 824–

833.

Yu, Z., Qin, Y., Li, X., Zhao, C., Lei, Z., and Zhao, G.

(2021). Deep learning for face anti-spooﬁng: A sur-

vey.

Yu, Z., Zhao, C., Wang, Z., Qin, Y., Su, Z., Li, X., Zhou,

F., and Zhao, G. (2020). Searching central difference

convolutional networks for face anti-spooﬁng. In 2020

IEEE/CVF Conference on Computer Vision and Pat-

tern Recognition (CVPR), pages 5294–5304.

Zhang, K., Zhang, Z., Li, Z., and Qiao, Y. (2016). Joint

face detection and alignment using multitask cascaded

convolutional networks. IEEE Signal Processing Let-

ters, 23(10):1499–1503.

Zhang, Z., Yan, J., Liu, S., Lei, Z., Yi, D., and Li, S. Z.

(2012). A face antispooﬁng database with diverse at-

tacks. In 2012 5th IAPR International Conference on

Biometrics (ICB), pages 26–31.

ICPRAM 2023 - 12th International Conference on Pattern Recognition Applications and Methods

640
