Using Infrastructure-Based Agents to Enhance Forensic Logging of

Third-Party Applications

Jennifer Bellizzi

1 a

, Mark Vella

1 b

, Christian Colombo

1 c

and Julio Hernandez-Castro

2 d

Department of Computer Science, University of Malta, Msida, Malta

School of Computing, Cornwallis South, University of Kent, Canterbury, U.K.

Keywords:

Enhanced Forensic Logging, Deeper Endpoint Visibility, Digital Forensics, Android Security.

Abstract:

Logs are the primary data source forensic analysts use to diagnose and investigate attacks on deployed ap-

plications. Since the default logs may not include all application events required during an investigation,

application-speciﬁc forensic logging agents are used to forensically enhance third-party applications post-

deployment and ensure that any critical events are logged. However, developing such application-speciﬁc

agents is impractical as this relies on application-speciﬁc knowledge requiring signiﬁcant code comprehen-

sion efforts. Furthermore, the resulting forensic logging agents are likely to break compatibility between ap-

plication versions and across applications; thus, requiring the time-consuming process of agent re-development

much more frequently. We propose a more practical approach to developing forensic logging agents that lever-

ages commonly-used underlying infrastructure, which is more stable across application versions and common

across different applications. We evaluate our approach in the context of enhanced logging of Android mes-

saging apps. Our results show that this approach can be used to develop logging agents that work across

multiple apps while preserving the accuracy of the logs generated, thus mitigating the challenges associated

with forensically enhancing third-party applications.

1 INTRODUCTION

Incident responders use logs to investigate attacks on

deployed applications. Investigators rely on applica-

tion logs to understand both the entry point of an at-

tack on an application and its ramiﬁcations; that is,

what damages have been inﬂicted and which data as-

sets are being targeted (Ma et al., 2015). However,

it is difﬁcult to know a priori where logs are needed

to ensure attack-related events are logged in the fu-

ture. Exhaustively recording all possible application

events is infeasible due to the resulting overheads. As

a result of these issues, applications can produce lots

of log entries, but rarely the relevant ones needed to

investigate an attack. Furthermore, existing logs may

be inaccessible, for instance, in a mobile investigation

involving an unrooted device.

Several tools, including GRR Rapid Response

https://orcid.org/0000-0003-1754-9473

https://orcid.org/0000-0002-6483-9054

https://orcid.org/0000-0002-2844-5728

https://orcid.org/0000-0002-6432-5328

https://github.com/google/grr

(Cohen et al., 2011) and Velociraptor IR

use client

device agents for end-point visibility purposes. These

agents are installed within third-party applications or

on devices as part of the forensic readiness stage to

aid in Incident Response. They collect ﬁles, applica-

tion and system logs, and outputs from live forensics

commands that harbour indicators of compromise to

feed them back to a central investigation node. Mak-

ing use of additional agents that are inserted inside

third-party application processes (for which access to

the source code is restricted) carries the potential to

enhance logging with deeper visibility. While opt-

ing for application-speciﬁc agents may seem the most

obvious solution to log application-related events, it

can be impractical. Such agents rely on application-

speciﬁc objects, resources and logic that may change

when newer versions are released. Therefore, not

only do application-speciﬁc agents require signiﬁ-

cant code comprehension effort for every application,

their reliance on application-speciﬁc logic means that

application-speciﬁc logging agents will likely break

compatibility across applications and versions.

https://github.com/Velocidex/velociraptor

Bellizzi, J., Vella, M., Colombo, C. and Hernandez-Castro, J.

Using Infrastructure-Based Agents to Enhance Forensic Logging of Third-Party Applications.

DOI: 10.5220/0011634700003405

In Proceedings of the 9th International Conference on Information Systems Security and Privacy (ICISSP 2023), pages 389-401

ISBN: 978-989-758-624-8; ISSN: 2184-4356

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

389

Repositories

State holders

Resources

UI Elements

Data Sources

App Logic

Application-speciﬁc logging agent Infrastructure-based logging agent

App A v1

Standard APIs

Native libraries

party development

libraries

Repositories

State holders

Resources

UI Elements

Data Sources

App Logic

App A v2

Repositories

State holders

Resources

UI Elements

Data Sources

App Logic

App B

Standard APIs

Native libraries

party development

libraries

Standard APIs

Native libraries

party development

libraries

Figure 1: Forensic logging agents leveraging application-

speciﬁc codebase versus agents leveraging common under-

lying infrastructure-interfacing code that is expected to be

more stable across versions (App A v1, v2) and applications

(App A, B). Different colour codes signify application-

speciﬁc codebases, whereas the same-coloured codebases

reﬂect common APIs across applications and versions.

This paper proposes a new approach to address

challenges that arise when relying on application-

speciﬁc logic to build post-deployment forensic log-

ging agents for third-party applications, for which ac-

cess to the source code is limited. Figure 1 presents

the main insight underpinning our proposed solution,

which aims to leverage common, widespread infras-

tructure across different application versions and ap-

plications altogether. While application-speciﬁc com-

ponents of an application may change when newer

versions are released (see App A v1 and v2 in Fig-

ure 1) and differ across different applications (see

App A and B in Figure 1), infrastructure-centric

components such as native libraries and APIs, are

more likely to remain compatible with other appli-

cations and versions. As a direct beneﬁt of our ap-

proach, code comprehension effort is signiﬁcantly

reduced since i) common underlying infrastructure

is publicly well-documented, ii) the focus is on a

subset of the code that interacts with infrastructure

code, and iii) the resulting agent has the potential to

work across versions and other applications that use

common underlying infrastructure. Furthermore, in-

frastructure logic is expected to be more stable and

backward-compatible, whereas application internals

may change between versions. Therefore, updates to

infrastructure-based agents will not be required as fre-

quently as application-speciﬁc agents that rely on ap-

plication internals which are constantly in ﬂux and out

of the logging agent developer’s control.

While this approach has several beneﬁts, an es-

sential requirement is that accuracy in logged events

is not diminished. Since infrastructure-based logging

agents focus on a reduced subset of the application

codebase, the control over application-speciﬁc log en-

try metadata that needs to be logged will also be re-

duced, which may impact the accuracy of the log en-

tries produced. With this in mind, we set out to eval-

uate our approach in the context of Android messag-

ing applications, a common target for attacks (Flubot,

2021; Amer Owaida, 2021; Jon Russell, 2012), and

make the following contributions:

• We verify the potential for infrastructure-centric

logging agents to be compatible across different

apps of the same category through AppBrain and

determine the stability of underlying infrastruc-

ture among selected application versions by per-

forming a static analysis of application versions

spread across ﬁve years.

• We produce a prototype logging agent based on

common infrastructure logic for Android messag-

ing applications that can operate on three different

applications and conduct a qualitative study to as-

sess the accuracy of the log entries produced.

2 BACKGROUND

The use of log enhancement through application-

speciﬁc agents is not just a forensic visibility prob-

lem. Logs are the primary data source engineers, de-

velopers, and analysts use to diagnose issues in de-

ployed applications, such as performance issues, bugs

or even evidence of attacks (Toslali et al., 2021; Yuan

et al., 2012a; Yuan et al., 2012b; Zhao et al., 2017;

Mace et al., 2015). However, it is difﬁcult to know a

priori where logs are needed to help diagnose prob-

lems that may occur in the future. Post-deployment

log enhancement refers to logging third-party appli-

cation events after the application, for which access

to the source code is restricted, has been deployed

so that relevant events related to unforeseen issues

may be logged and analysed. This enhancement

is typically carried out through application-speciﬁc

agents that enhance application logging by relying

on application-speciﬁc logic. However, relying on

application-speciﬁc knowledge requires reverse engi-

neering applications, which introduces several chal-

lenges, including i) comprehending compiled code,

ii) bypassing any anti-tampering solutions present in

the application code and ﬁnally, iii) complying with

fair-use reverse engineering.

2.1 Log Collection for Forensic Analysis

Similar challenges apply to forensic log collection.

Cyberattack incidents increasingly use malware that

interacts with benign applications to hide their pres-

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

390

ence or escalate privileges, as well as carry out on-

device fraud (ThreatLandscape, 2022; Octo, 2022).

Log collection is crucial in a forensic investigation

to gather all possible evidence to reconstruct the at-

tack steps. Unfortunately, critical evidence is not al-

ways located in the collected logs, especially in cases

involving stealthy malware that hides malicious be-

haviours to minimise suspicion and prolong its life-

time, thus requiring late detection. Advanced persis-

tent threats (APTs) initiated by resourceful attackers

and ﬁleless malware operating in memory fall into

this category. Other advanced stealth techniques have

emerged through attack vectors that misuse the legiti-

mate actions of targeted benign applications for ﬁnan-

cial or personal data theft.

In the case of malicious interactions with pre-

installed, benign applications, entries in application

logs are crucial as they contain evidence of applica-

tion activities carried out seemingly by the benign

application that could reconstruct the attack steps in-

volving application misuse. Even if application logs

are available, the investigators are still at the mercy of

the application developers who control the contents of

the log entries. Typically production application logs

are used for diagnostic purposes, which may result in

log entries that do not produce the evidence required

in the case of application misuse. On the other hand,

it is infeasible to introduce exhaustive logging of all

possible application events by default, as this would

incur signiﬁcant overhead on all application users, in-

cluding those unaffected by a stealthy attack.

In this case, investigators require logging agents

installed inside third-party application processes. Yet,

the lack of collaboration with application developers

can complicate matters. Such agents would rely on

application-speciﬁc logic to log related events. Re-

lying on application-speciﬁc knowledge not only in-

troduces the previously-mentioned challenges associ-

ated with reverse engineering applications but also in-

troduces issues related to practicality.

2.2 JIT-MF: A Speciﬁc Case of

Post-Deployment Forensic Log

Enhancement on Android

Just-in-Time Memory Forensics (JIT-MF) (Bellizzi

et al., 2020; Bellizzi. et al., 2021; Bellizzi et al.,

2022) is a framework that enables live process mem-

ory forensics in a setting involving stealthy malware

that delegates their attack steps to benign applications.

JIT-MF was conceived to be adopted by incident re-

sponse tools for stock smartphones without breaking

any of their security controls. Rather, given that its

primary purpose is to aid device owners in recovering

from cyberattacks, it assumes the device owner’s col-

laboration. It tackles the problem of missing evidence

in application logs by enabling the enhancement of

Android apps with app-speciﬁc logging agents re-

ferred to as JIT − MF Drivers that timely dump ev-

idence from memory, using app instrumentation to

avoid device rooting. These non-intrusive agents are

installed within third-party applications to record ad-

ditional data from memory, as part of the forensic

readiness stage of incident response, without chang-

ing the application code beyond hooking. JIT-MF

Drivers have two main properties:Evidence objects

are identiﬁed as those application-speciﬁc objects

whose presence in memory implies the execution of

some speciﬁc app functionality, possibly a delegated

attack step. Trigger points deﬁne which application

instructions signify that Evidence objects are in mem-

ory, and hence when memory dumps should be trig-

gered. Therefore, trigger points are crucial to timely

dump evidence objects in memory.

JIT-MF Logs. Taking the case of a stealthy mes-

saging hijack attack as an example, attackers aim

to send messages through a victim’s benign mes-

saging app and immediately delete them to ensure

that the victim remains unaware of the malicious at-

tack step. To aid investigation efforts, benign mes-

saging apps can be enhanced with a JIT-MF driver

whose evidence object is deﬁned as the application-

speciﬁc MessageObject containing details of the mes-

sage sent, and trigger point can be deﬁned as any op-

eration handling the MessageObject. A sample of the

resulting JIT-MF log entries is shown in Listing 1,

whereby each entry consists of metadata derived from

the evidence object (in this case MessageObject) as

dumped from memory at a particular trigger point.

The application-speciﬁc MessageObject contains

the properties that populate a log entry with the neces-

sary information regarding an event. However, iden-

tifying this object in the ﬁrst place is challenging

since i) application developers may change the prop-

erties of this object or even the object name itself,

when newer versions of the application are released,

and ii) different messaging applications use different

MessageObjects with different properties.

On the other hand, identifying infrastructure-

centric evidence objects, for example, a String ob-

ject, is expected to be simpler and far less likely to

change when compared to an application-speciﬁc ob-

ject. However, log entry completeness becomes an

issue due to the level of information derivable from a

generic String object.

Using Infrastructure-Based Agents to Enhance Forensic Logging of Third-Party Applications

391

Listing 1: JIT-MF log entry sample generated while using WhatsApp, Telegram and Signal Android apps (Bellizzi et al.,

2022).

1 {"time": "1 66 24 82 71 2" , "event": "W ha ts ap p M es sa ge Se n t" , "trigger_point": " an dr oi d . d at ab as e . s ql ite . SQ Li te Da ta ba se " ,

"object": {"date": "" , "me ss a ge _i d" : "4 13 88 21D 2B F1 8 D8 44 7 20 CB BF5 06 7A 5 AD ," , "text": "N or ma l_ me ss age _1 " , "to_id":

"7 19 6@ s . w ha ts ap p . ne t ]" , "to_name": "" , "to_phone": "" , "from_id": "" , "from_name": "" , "from_phone": "" }}

2 {"time": "1 66 24 85 25 6" , "event": "T el egr am M es sa ge Pre sen t" , "trigger_point": "re cv" , "object": {"date": " 16 624 83 77 9" ,

"m e ss ag e_ id " : "23 28" , "text": "N o rm al _m es sa ge _1 " , "to_id": "5 18 12 66 731" , "to_name": "t ar g et _p ho n e ; ;; " , "to_phone":

"3 56 99 62 69 72 " , "from_id": " 16 79923 80 3" , "from_name": " co nt ac t _p ho ne ;; ;" , "from_phone": "3 5 67 92 47 1 96 " }}

3 {"time": "1 66 24 87 18 2" , "event": "S ig na l M es sa ge P res en t" , "trigger_point" : "o pen " , "object": {"date": "1 66 24 87 13 25 03 " ,

"m e ss ag e_ id " : "16 8" , "text": " No rm al _m es sa ge _1" , "to_id": "Re ci pi en t Id ::2 " , "to_name": "n ull " , "to_phone": "

+3 5 69 96 26 97 2 " , "from_id": " Re ci p ie nt Id :: 3" , "from_name": "nu ll" , "from_phone": " +3 56 79 24 7 19 6 " }}

Step 2: Identify

underlying APIs

Step 3: Determine

underlying infrastructure at

the most native level

Input

Step 4: Log Collection -

Identify and manipulate

events that need to be

recorded

Input

Step 5: Log Parsing - parse

application-speciﬁc elements

of the logs generated.

API

Native-level

infrastructure

Input

Log entries

Forensic

Enhancement

Technique

Output Output

Step 1: Identify key

application events

Input

Third-party

Application

Input

Third-party

Application

Key application

events

Output

Figure 2: Proposed process for creating and deploying infrastructure-based logging agents.

3 OVERVIEW

The main aim of this work is to present and eval-

uate a modiﬁed approach towards developing post-

deployment third-party application logging agents

that leverages the common subset of the applications’

codebase that interacts with commonly-used infras-

tructure. As shown in Figure 1, the underlying in-

frastructure is generally more stable and widespread

across different applications and versions, allowing

infrastructure-based logging agents to remain us-

able across different applications and versions (unlike

application-speciﬁc agents, which need to be devel-

oped anew). Figure 2 presents the process for cre-

ating infrastructure-based forensic logging agents as

part of this new proposed approach.

Step 1: The ﬁrst step in developing an

infrastructure-based logging agent requires that,

given a third-party application, a logging agent devel-

oper must ﬁrst identify the scope of the logging agent

by determining which key application events (core

application functionality) requires deeper visibility

and hence needs to be logged. In the case of stealthy

messaging attacks, for instance, key application

events constitute messaging events that an attacker

could hijack.

Step 2: Application developers use readily-

available infrastructure (such as services, libraries

and APIs) to develop key functionality commonly

carried out among applications. Given a third-party

application, the forensic logging agent developer

must determine the underlying APIs that the appli-

cation uses to perform the identiﬁed key application

event; for example, storage/database libraries that

persist events in the application’s local database.

Step 3: Applications using the same underlying in-

frastructure may use custom APIs at higher levels of

abstraction that better ﬁt the needs of a speciﬁc ap-

plication. However, at the native level, these APIs

typically use the same native libraries. Therefore the

logging agent developer must determine the underly-

ing infrastructure at the most native level, which is

expected to be consistent among application versions

and applications; for instance, the native sqlite.c

library.

Step 4: Given a forensic enhancement technique

and the underlying infrastructure identiﬁed, publicly

available documentation of the interface exposed by

the infrastructure can be used to determine which

infrastructure calls need to be logged to produce

log entries containing the identiﬁed key application

events. Since the focus is on infrastructure-based

events, this step involves analysing only a subset of

the application codebase that is typically publicly

well-documented and can be common for applications

that use the same underlying infrastructure.

Step 5: An infrastructure codebase is expected to

expose the same interface across the different applica-

tions in which it is used. However, applications may

make application-speciﬁc use of the interface and the

events that the infrastructure can carry out. There-

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

392

fore, it is expected that the ﬁnal step will be unique to

each application and will involve application-speciﬁc

parsing of the generated and collected log entries.

This means that an element of application reverse

engineering will be required to make sense of the

application-speciﬁc elements in the log entries, the

extent of which is difﬁcult to predict as it requires

a large-scale qualitative exploration of the solution.

However, we expect that the deﬁnition of the parser

will be similar for applications using the same under-

lying infrastructure. Since infrastructure code is more

stable and less likely to change, modiﬁcations to the

log parser between an application’s versions are ex-

pected to be minimal. While the parsing element may

need revising, the collection element remains func-

tional. Therefore, evidence is collected regardless of

whether or not a parser is readily available or a new

one needs to be developed.

4 EVALUATION

We evaluate our proposed approach of infrastructure-

based forensic logging agents in the context of An-

droid messaging apps and use JIT-MF, a forensic en-

hancement technique for third-party Android appli-

cations whose effectiveness has been demonstrated

in previous works (Bellizzi et al., 2020; Bellizzi.

et al., 2021; Bellizzi et al., 2022). We ﬁrst con-

duct a preliminary analysis to select a suitable infras-

tructure candidate used to carry out core functional-

ity in messaging apps. Then, we run experiments

to answer the following questions: Is common in-

frastructure usage prevalent across different versions

of a messaging app? (Q1) Can infrastructure-based

agents work across different Android messaging apps

while maintaining the same accuracy as application-

speciﬁc agents? (Q2)

4.1 Common Infrastructure Adoption

Our preliminary analysis aims to identify which

infrastructure is commonly-used among messaging

apps to ensure that an infrastructure-based agent can

function across app versions and on multiple apps.

Not only does this infrastructure need to be in use by

the app, but it also needs to be taking an active role

when critical events that need to be logged are taking

place. We consider the data provided by AppBrain

(AppBrain, 2022), a service that provides statistics on

the Android application’s ecosystem including library

adoption by different apps in different categories. In

this case, we focus speciﬁcally on Android messaging

apps, per the scope of this evaluation.

Methodology. AppBrain categorises libraries used

in Android applications by tags, depending on the

functionality provided by the library. As described in

step 2 of Figure 2, when developing an infrastructure-

based agent, the selected infrastructure must sup-

port core app functionality that is within the logging

agent’s scope and requires deeper visibility (Figure 2

step 1). Out of the 41 possible categories, we identify

Network and Database libraries as critical infrastruc-

tures used by messaging apps to support key messag-

ing events. Network functionality allows messages to

be sent and received over the network, and Storage

allows messages (both sent and received) to be stored

and retrieved on the devices where the app is installed.

Results. At the time of our analysis, AppBrain

statistics showed that the most widely used network

library was Retroﬁt

. In contrast, the most widely

used database infrastructure was Android Architec-

ture Components

, which at its most native level

(see Step 3 Figure 2) refers to storage management

through an SQLite Database

. AppBrain statistics

revealed that at the time, 86.62% of communication

(messaging) apps used Android Architecture Compo-

nents, while only 14.6% used Retroﬁt.

Threats to Validity. AppBrain is closed-source;

however, it provides insight into how it derives in-

formation regarding Android apps on Google Play-

Store. It analyses all Android apps on Google Play

and performs some analysis on the package ﬁle of

the app (APK). Statistics regarding development tools

and libraries usage are obtained by matching package

names inside the apps “with known package names

from development tools. Therefore, these statistics

reﬂect whether the code of a certain library is present

in an app.” (AppBrain, 2022). While this does not

guarantee that a particular application actively uses a

library, “it still gives a good idea of the market share

and what is the list of the top Android development

tools.” (AppBrain, 2022).

4.2 Prevalence Across App Versions

Through the results shown in the previous section we

determine that storage libraries, speciﬁcally managed

through SQLite, are the most commonly-used storage

library and surpass the usage of network libraries in

https://square.github.io/retroﬁt/

https://www.appbrain.com/stats/libraries

https://developer.android.com/training/data-storage/sq

lite

Using Infrastructure-Based Agents to Enhance Forensic Logging of Third-Party Applications

393

messaging apps by 68.02%. JIT-MF has been pre-

viously evaluated (Bellizzi et al., 2022) using app-

speciﬁc drivers (logging agents) for WhatsApp, Tele-

gram and Signal, and we therefore use statistics pro-

vided by AppBrain to assert that this underlying in-

frastructure is present in the latest version of each of

these apps.

AppBrain does not provide statistics on the pre-

vious versions of Android applications. Therefore,

we use a quantitative static analysis approach within

a qualitative set of applications (comprising of What-

sApp, Telegram and Signal) to assess the longevity of

an SQLite infrastructure-based forensic logging agent

across application versions, thus answering Q1.

Methodology. We answer this question in two

parts. First, we assess the prevalence of SQLite

library usage across the previous Telegram, What-

sApp and Signal versions by statically checking for

the presence of code that uses this library. Sec-

ond, we compare the frequency of releases between

the SQLite library and each of the apps to indicate

the stability that infrastructure-based agents relying

on public-facing infrastructure codebase can provide

compared with application-speciﬁc logging agents re-

lying on an application-speciﬁc codebase.

Previous versions of each app were obtained from

August 2017 every six months up until August 2022

(10 past versions per app, 30 apps in total), using

APKCombo

, a repository for apps and their previ-

ous versions. Versions of the apps dating more than

six months prior could not be installed successfully

due to limitations and restrictions presented by each

app. Telegram was the only exception which allowed

versions from six-month prior to be run. Due to this

limitation, we conduct a static check to assert SQLite

library usage in the decompiled sources of an app’s

version. This check is carried out based on a signature

that encapsulates how a library can be used in an An-

droid app. To use a library, Android apps can either:

i) Call Android’s API wrapper or ii) Use a custom

implementation that interfaces with the infrastructure

using JNI by including a shared object in the APK.

The search aims to (1) ﬁnd smali code in decom-

piled code that calls functions from the SQLite An-

droid package or (2) ﬁnd the SQLite shared object in

the application library folder of the decompiled app.

If the search is successful, the search returns the par-

ent folder name; that is, the app version folder.

https://apkcombo.com/

Listing 2: Signature for checking the presence of SQLite

usage in an Android app package (APK).

1 grep -Priq --include *. smali "

La ndro id / dat aba se / s qlit e .*; - > "

$ap p_ver sion / smal i */ |

2 grep -riq sq lite $a pp_ve rsion / lib

Results. Table 1 shows the results obtained when

the signature in Listing 2 is used to check for SQLite

usage within the decompiled application versions ob-

tained. These results show that bindings with the

common underlying SQLite infrastructure are present

across all apps and previous versions from the last ﬁve

years, even if the interfacing method has changed.

Therefore, selecting an infrastructure-based logging

agent based on SQLite in the case of WhatsApp, Tele-

gram and Signal is likely to remain compatible with

upcoming versions of the apps.

Table 2 shows the frequency by which newer

versions of the apps and SQLite are released.

Application-speciﬁc logging agents for WhatsApp,

Telegram and Signal are based on application code-

bases that are updated on average every 6 - 15 days. A

compatibility test would therefore be required accord-

ingly to ensure that application-speciﬁc logic within

the agent was not altered in the update. On the other

hand, updates to the SQLite library are not only much

less frequent but also optional and hence not necessar-

ily reﬂected in the apps that use them. Furthermore,

in the case of SQLite, stable interfaces are maintained

indeﬁnitely in a backward-compatible way

, which

means that the agent relying on an older version of

SQLite will not remain compatible, even if the infras-

tructure is updated.

Threats to Validity. We rely on a static signature

that follows logic on how apps interact with the un-

derlying infrastructure. However, this does not guar-

antee that the developer is using the code, as there

is also the possibility that the code or libraries found

reﬂect dead or legacy code, which cannot be distin-

guished statically.

4.3 Android Messaging Case Study

We conduct a qualitative case study to evaluate

whether or not infrastructure-based agents can work

across applications while maintaining the same level

of accuracy in the logs produced as application-

speciﬁc agents, and thereby answering Q2. Therefore,

https://www.sqlite.org/capi3ref.html

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

394

Table 1: The table shows whether or not the SQLite usage signature was matched in different versions of Signal, Telegram

and WhatsApp, since 2017.

Release Date App version

Found SQLite function calls in

decompiled smali code (1)

Found shared object in library

folder (2)

23-08-2017 Signal v.4.9.9 3 7

28-02-2018 Signal v.4.16.9 3 3

06-08-2018 Signal v.4.24.8 3 3

09-02-2019 Signal v.4.33.5 3 3

09-08-2019 Signal v.4.45.2 3 3

12-02-2020 Signal v.4.55.8 3 3

20-08-2020 Signal v.4.69.4 3 3

18-02-2021 Signal v.5.4.6 3 3

20-08-2021 Signal v.5.21.5 3 3

18-02-2022 Signal v.5.32.7 3 3

05-08-2017 Telegram v.4.2.2 7 3

19-02-2018 Telegram v.4.8.4 7 3

30-08-2018 Telegram v.4.9.1 7 3

09-02-2019 Telegram v.5.3.1 7 3

24-08-2019 Telegram v.5.10.0 7 3

16-02-2020 Telegram v.5.15.0 7 3

16-08-2020 Telegram v.7.0.0 7 3

18-02-2021 Telegram v.7.4.2 7 3

07-08-2021 Telegram v.7.9.3 7 3

14-02-2022 Telegram v.8.5.2 7 3

11-08-2017 WhatsApp v.2.17.296 3 3

09-02-2018 WhatsApp v.2.18.46 3 3

18-08-2018 WhatsApp v.2.18.248 3 3

08-02-2019 WhatsApp v.2.19.34 3 3

07-08-2019 WhatsApp v.2.19.216 3 3

13-02-2020 WhatsApp v.2.20.22 3 3

05-08-2020 WhatsApp v.2.20.196.16 3 7

06-02-2021 WhatsApp v.2.21.3.13 3 7

09-08-2021 WhatsApp v.2.21.17.1 3 7

17-02-2022 WhatsApp v.2.22.4.75 3 7

Table 2: The frequency of Signal, Telegram, WhatsApp and SQLite library version releases, since 2017.

Codebase Average Release time (in days) over the last 5 years

WhatsApp 6.324

Telegram 14.917

Signal 7.319

SQLite 39.48

Releases here reﬂect changes in the library source code. These up-

dates do not necessarily imply changes in the API and are not manda-

tory for applications that use it.

the case study involved two Google Pixel 3XL emula-

tors running Android 10 (API 29). Telegram v.8.8.5,

Whatsapp v.2.22.17.70 and Signal v.5.44.4 were in-

stalled on both emulators. JIT-MF was used as a

forensic enhancement tool that equips these apps on

one of the emulators (Device A) with a logging agent

(JIT-MF Driver).

Methodology. Existing JIT-MF drivers from pre-

vious research

that cater for messaging hijacks on

Telegram, WhatsApp and Signal are used and a new

https://gitlab.com/mobfor/jitmf experiments resourc

SQLite infrastructure-based driver

is developed that

can be used with all three apps. The applications

are equipped with their respective application-speciﬁc

JIT-MF driver and the same SQLite infrastructure-

based driver. AndroidViewClient was used to simu-

late normal messaging trafﬁc, whereby 20 messages

were sent, and 20 messages were received by De-

vice A. Each message was formulated as follows:

Normal Message < #msgnumber >.

The log entries produced by the drivers are ex-

pected to include any messages sent and received by

the enhanced app. Therefore, to evaluate whether an

https://gitlab.com/bellj/infrastructure based agents

Using Infrastructure-Based Agents to Enhance Forensic Logging of Third-Party Applications

395

Step 2: Identify

underlying APIs

Step 3: Determine

underlying infrastructure at

the most native level

Input

Step 4: Log Collection -

Identify and manipulate

events that need to be

recorded

Input

Step 5: Log Parsing - parse

application-speciﬁc elements

of the logs generated.

SQLite

sqlite.c

Input

INSERT INTO

TABLE_NAME (v1,v2…)

JIT-MF

Output Output

Step 1: Identify key

application events

Input

Telegram,

Whatsapp, Signal

Input

Telegram,

Whatsapp, Signal

Message Send

Output

Figure 3: Process for creating and deploying SQLite infrastructure-based logging agents for Telegram, WhatsApp and Signal,

using SQLite as infrastructure and JIT-MF as the forensic enhancement tool.

SQLite infrastructure-based driver can maintain the

same level of accuracy in its log entries as application-

speciﬁc drivers, we compare these log entries to those

produced by application-speciﬁc drivers.

Logging Agent Development. JIT-MF drivers are

the logging agents used in JIT-MF. We created a

new SQLite infrastructure-based JIT-MF driver as

an infrastructure-based logging agent aimed at being

able to enhance all three apps. Following the steps

shown in Figure 2, the SQLite infrastructure-based

driver was developed, as shown in Figure 3. We iden-

tify message send events as the key application event

that the SQLite infrastructure-based agent needs to

log. Log entries produced through JIT-MF are in-

voked at trigger points containing evidence objects.

In the case of an SQLite infrastructure-based JIT-MF

driver, trigger points were deﬁned as the functions ex-

posed by the sqlite C interface

and evidence ob-

jects comprise of a parameter within these functions

that contains the SQL statements executed.

Log Collection. The publicly available documen-

tation for SQLite indicates that prepared state-

ments allow applications to execute all SQL state-

ments. Furthermore, the second parameter of

any prepared statement contains the SQL query

to be executed. Subsequent bind functions

(BIND INT,BIND TEXT,BIND BLOB) are used to pop-

ulate the parameterised values of the query, depend-

ing on a query ID

. Therefore log entries produced

by SQLite infrastructure-based logging agent should

consist of SQL statements that were executed to pop-

ulate messages in the messaging app local database.

Log Parsing. An ofﬂine component was required

to parse the log entries produced. While the SQLite

infrastructure-based JIT-MF driver was the same for

all three apps, the log entries produced contained

https://www.sqlite.org/c3ref/funclist.html

https://www.sqlite.org/c3ref/stmt.html

application-speciﬁc knowledge that required unique

parsing logic per app. For instance, not all apps inter-

nals use the same SQL statements to populate their re-

spective local databases. However, SQLite databases

include a schema that describes the tables within a

database. This means that the developed parser could

use this information to carve out the necessary por-

tions from the log entries accordingly.

Listing 3 shows three unparsed log entries gener-

ated by an SQLite infrastructure-based driver, while

sending messages from WhatsApp, Telegram and

Signal, respectively. Each entry comprises of an

INSERT | REPLACE statement, signifying a new mes-

sage that will be inserted in the local database.

Application-speciﬁc parsers were developed which

could: i) identify the names of the message table

unique to each app (message ftsv2, messages v2

and sms), and ii) map the appropriate ﬁeld val-

ues with the key application event metadata; for in-

stance, the second ﬁeld value of a REPLACE INTO

messages v2 table generated when using Telegram

reﬂects the time at which a message was sent. The

respective parsed log entries are shown in Listing 4.

Results. Publicly-available documentation allowed

the development of an SQLite infrastructure-based

logging agent without requiring application-speciﬁc

code reversing. The same SQLite infrastructure-

based JIT-MF driver was effective on all three apps;

however, as expected, ofﬂine application-speciﬁc log

parsing was required per app.

We compare the parsed output generated by the

SQLite infrastructure-based logging agent with that

produced by the application-based agents. The

ﬁnal column in Table 3 shows that the SQLite

infrastructure-based agent was able to produce the

same number of log entries containing the same text

metadata, as each of the application-speciﬁc drivers.

While text metadata in log entries generated by the

SQLite infrastructure-based logging agent (Listing 4)

and application-based agents (Listing 1) is the same,

closer inspection of the two sample log entry outputs

generated, shows some difference in the other key

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

396

Listing 3: Unparsed log entries generated by infrastructure-based agent for WhatsApp (1), Telegram (2) and Signal (3)

respectively.

1 INSERT INTO me ss ag e_ f ts v2 (f ts _ji d , doci d , con ten t , f ts _n am e sp ac e ) VALUES (0 b,null, n or ma l_ mes sa ge _1 ,0 b)

2 REPLACE INTO me ss ag es _v 2 VALUES(23 28 , 1 67 99 23 803 , 2, 0, 16 62 48 37 79 , n8 \ " QY [! d \ " QY [! dC } c N or ma l _m es s ag e_ 1 , 0 , 0 ,

18 446 74 40 73 70 955 20 00 , NULL, 0, 0, 0, und ef in ed , 0, 0 , 0, un de fi ned )

3 INSERT INTO s ms ( t hre ad _i d , su bs cr ip ti on _i d , a ddr ess , pro toc ol , e xp ires_ in , ser ve r_ gu id , d at e_s en t , body ,date,read, type ,

un id en ti fi ed , d at e_ se rve r , r ep ly _pa th _p re se nt , se rv ic e_ ce nt er , a dd re s s_ de vic e_ id ) VALUES ( 3 , 184 46. .. 0 ,3 , 313 37 ,0 , d5 00 3

b3d -c e8e -4 1 cf - ba67 -1 cf 592 fa 81 c2 ,1 66 24 85 982439 , No rm al _me ss ag e_ 1

A§ , 16 62485 98 31 60 ,0 ,1 04 85 78 0 , 1 , 166 24 859 74 012 ,1 , GCM , 1)

Listing 4: JIT-MF log entry sample generated while using WhatsApp, Telegram and Signal, produced through an SQLite

infrastructure-based logging agent.

1 {"time": "1 66 24 81 63 6" , "event": "W ha tsA pp M es sa ge S ent" , " tr i gg er _p o in t ( s) " : "s ql i te 3_ c le ar_ bi n di ng s |s ql i te 3_ p re pa r e_ v2 |

sq li te 3_f in al iz e" , "object": {"date": "" , " me ss ag e _i d" : "" ,"text": "no rm al _m es sa ge _1 " , "to_id": "" , "to_name": "" ,

"to_phone": "" , "from_id": "" , "from_name": "" , "from_phone": "" }}

2 {"time": "1 66 24 83 78 9" , "event": "M es sa ge Se nt" , "tr ig ge r _p oi nt (s ) ": " sq l it e3 _ cl ea r _b in d in gs|sq lit e3 _p r ep ar e _v 2|

sq li te 3_f in al iz e" , "object": { "m es s ag e_ num be r" : " 232 8" , "date": " 16 62483 77 9" , "text": " No rm a l_ me ssa ge _1 " , "t yp e" :

"r ec eiv ed " , "to_id": " 51 81 266 73 1" , "to_name": " ta rg et _ ph on e ; ;; " , "to_phone": "356 99 62 69 72 " , "from_id": "1679 92 38 03 "

, "from_name": "co nt ac t _p ho ne ;; ;" , "from_phone": "3 567 92 47 196 " }}

3 {"time": "1 66 24 85 98 3" , "event": "M es sa ge Se nt" , "tr ig ge r _p oi nt (s ) ": " sq l it e3 _ cl ea r _b in d in gs|sq lit e3 _p r ep ar e _v 2|

sq li te 3_f in al iz e" , "object": {"date": "1 66 24 85 98 31 60 " , "text": "N or ma l_ me ssa ge _1 " , "t yp e" : "r ec ei ved " , , "to_id":

"_" , "to_name": "t ar ge t_ ph on e" , "to_phone": " +3 56 99 6 26 97 2 " , "from_id": "3 " , "from_name": "c on ta ct _p ho ne " ,

"from_phone": " +3 56 79 24 719 6 " }}

Table 3: The table shows the maximum lines of code (LoC) that need to be analysed to develop an application-speciﬁc agent

and an SQLite infrastructure-based agent, along with the percentage of log entries retrieved by an SQLite infrastructure-based

agent, when compared with log entries generated using an application-speciﬁc agent.

Application

Maximum LoC analysed for

application-speciﬁc agent

Maximum LoC analysed for

SQLite infrastructure-based

agent

% of log entries retrieved by

SQLite infrastructure-based

agent

WhatsApp 1,515,334 395,076 100

Telegram 1,025,467

100

Signal 1,552,171

100

The same SQLite codebase is used to develop an SQLite infrastructure-based agent for all three apps. Therefore the lines

of code is analysed only once.

application event metadata generated. Application

event metadata generated by SQLite infrastructure-

based logging agent translates roughly to the same

metadata obtained by the application-based agents in

the case of Telegram and Signal. With WhatsApp,

however, application event log entries are missing the

recipient value. Unlike Telegram and Signal, What-

sApp is closed-source. Therefore, parsing the gen-

erated logs was not as straightforward and possibly

required further in-depth reverse engineering efforts

to fully parse metadata within SQLite infrastructure-

based log entries. That said, given that the log entries

generated by the agent contain all the app events in-

volving interactions with the database, additional re-

verse engineering effort can be carried out ofﬂine at a

later stage to parse the generated logs.

In the case of application-speciﬁc JIT-MF drivers,

evidence objects are identiﬁed and deﬁned within a

driver based on knowledge of the application code-

base, which calls for a reverse engineering process.

We use lines of code (LoC) as a metric to high-

light the reverse engineering effort that needs to

be made when developing application-speciﬁc and

SQLite infrastructure-based logging agents. The sec-

ond and third columns of Table 3 show the maximum

LoC that need to be analysed using both approaches

(application-speciﬁc and SQLite infrastructure-based

logging agent) to select the relevant evidence object

and thus develop a logging agent for each app. In the

case of the application-speciﬁc logging agents, LoC

for each app reﬂects the lines of code in the respec-

tive decompiled java source ﬁles. For the SQLite

infrastructure-based agent, the LoC reﬂects the lines

of code in sqlite source and header ﬁles. Since

the same SQLite infrastructure-based agent was used

for the three apps, the LoC value for the SQLite

infrastructure-based agent is only considered once.

Therefore, the codebase that needs to be reversed to

develop an SQLite logging agent is much smaller than

each of the applications’ codebases and only needs

to be reversed once since it is common for all three

apps. The LoC values in the table portray the worst-

case scenario, as reverse engineering efforts can be

reduced further in the case of application-speciﬁc

agents by using keyword searches (e.g. Message) –

assuming an unobfuscated codebase – to narrow the

search for the evidence object to a couple of classes.

With infrastructure-based agents, public documenta-

Using Infrastructure-Based Agents to Enhance Forensic Logging of Third-Party Applications

397

tion of the infrastructure’s interface can outline key

exposed methods without going through the infras-

tructure codebase.

Threats to Validity. JIT-MF aims to ensure min-

imal forensic readiness by repackaging apps rather

than requiring the device to be rooted. While minimal

forensic readiness is a core property of JIT-MF, it falls

outside this experiment’s scope, as our aim is to assess

the accuracy of a JIT-MF driver based on infrastruc-

ture rather than application-speciﬁc logic. Therefore,

a rooted emulator was used to carry out the experi-

ment, which enabled ease of automation and results-

gathering, and drivers could be embedded directly on

the device without app repackaging. While repackag-

ing should not compromise the results obtained, this

merits threats to validity as the results obtained as-

sume that the driver can be installed.

5 DISCUSSION

While infrastructure-based forensic logging agents

can signiﬁcantly reduce the code comprehension ef-

fort required, selecting the proper infrastructure upon

which a forensic logging agent is developed is crit-

ical to the agent’s ability to produce the necessary

evidence. SQLite, the storage management infras-

tructure employed by Android Architecture Compo-

nents, was selected for our experiments. This infras-

tructure persists data from memory to a database on

the user’s phone. While our qualitative case study

demonstrated the success of an SQLite infrastructure-

based agent on three Android messaging apps, we ex-

pect that similar storage infrastructure usage is com-

monplace among the most popular apps, regardless of

their category. Applications maintain their state by

persisting essential app data and events to storage (ei-

ther on the device or to cloud storage). Thus, appli-

cations are bound to use storage infrastructures that

handle key application events even beyond messag-

ing, potentially allowing such an infrastructure-based

agent to be reused among multiple apps.

We assess the potential effectiveness of using

an infrastructure-based approach to generate log-

ging agents for Android apps at a larger scale by

performing coverage analysis on the most down-

loaded Android apps from Google Playstore (550

apps in total, 44 of which fall in the messaging cat-

egory). Using statistics from AppBrain (AppBrain

API, 2022), Figure 4 shows that, potentially, develop-

ing two storage-related infrastructure-based logging

agents would be enough to forensically enhance a

large majority (94.7%) of the most popular apps. At

No agent

Android Architec-

ture Components

Firebase

GreenDAO

OrmLite

Realm

DBFlow

ActiveAndroid

SugarORM

MongoDB

100

Available logging agents

% of apps covered

All apps

Messaging apps

Figure 4: The number of storage infrastructure-based agents

needed to forensically enhance a % of apps from the most

downloaded 550 apps on Google PlayStore.

the same time, a single storage-related infrastructure-

based logging agent could enhance 93.2% of messag-

ing apps. This means a signiﬁcantly small number of

apps (5-7%) would require further code comprehen-

sion effort to develop the relevant logging agents.

Considerations & Limitations. Our coverage

analysis indicates that storage-related infrastructure-

based agents could signiﬁcantly decrease the effort

required when developing forensic logging agents for

third-party apps by requiring fewer agents to enhance

more apps successfully. This analysis, however, is

based on statistics derived from AppBrain; thus,

any limitations regarding how these statistics are

generated can impact the results of our analysis.

While results from our case study show that less

application-speciﬁc reverse engineering is required

to develop an effective storage-related infrastructure-

based agent, application-speciﬁc parsing is still nec-

essary, to a lesser extent. Application evidence in

memory is typically transformed (see Listing 3) when

persisted to storage, regardless of the application cat-

egory, requiring some form of application-speciﬁc

parsing (see Listing 4). While the type of transfor-

mation is speciﬁc to the application and evidence, our

case study showed that: i) this transformation is typ-

ically lossless (i.e. all the event metadata is retained

in log entries) and structure-related, requiring some

form of deserialisation; ii) the necessary steps to carve

out all the metadata about key application events can

quickly be determined upon observation.

This may not always be the case. Application de-

velopers may opt to transform evidence in memory

so they can no longer be easily parsed, for instance,

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

398

by persisting encrypted or compressed data to a lo-

cal database. However, this may not be practical as

is the case in the context of Android, for instance.

File-based encryption (FBE) (Google, 2022) is en-

abled by default on devices running Android 10 or

higher. Therefore, encrypting application data would

lead to slower performance without any additional se-

curity beneﬁt beyond the default.

6 RELATED WORK

Forensic Logging. Tracing system-level depen-

dence is a popular technique for anomaly detection

in desktop, server and mobile environments (New-

some and Song, 2005; King et al., 2005; King and

Chen, 2003; Ammann et al., 2002; Yuan et al., 2017).

Such techniques are typically used to record events

(e.g. system calls, API calls) during execution so that

causal dependencies between system subjects (e.g.

process) and system objects (e.g., network socket or

ﬁle) can be identiﬁed to detect malicious behaviour.

Ultimately, traces of function/API calls comprise logs

that serve an ulterior speciﬁc purpose, such as mal-

ware detection. In this work, we show that applica-

tion events logged at the level of function/API trac-

ing intended to provide deeper visibility are not infe-

rior to enhanced forensic logging that beneﬁts from

application-speciﬁc logic knowledge.

Similarly to tools like BEEP (Lee et al., 2013),

ProTracer (Ma et al., 2016), and WinLog (Ma et al.,

2015), an infrastructure-based forensic logging agent,

as proposed in this paper, calls for a proactive ap-

proach to forensically enhance application binaries

for attack reconstruction. However, rather than rely-

ing solely on system and memory level dependencies,

infrastructure-based agents may also rely on library

and API calls. Calls to these dependencies are less

complex to reverse engineer and can obtain semanti-

cally richer traces of logs obtained from lower-level

dependencies (e.g. system calls).

Logging agents deployed by forensic enhance-

ment tools complement tracing techniques by obtain-

ing richer traces through custom tracing third-party

applications. The logging entries (traces) generated

can be used alongside other sources of evidence for

analysis by endpoint visibility tools such as GRR

Rapid Response and Velociraptor IR, provided that an

appropriate parser is created for the traces.

Dynamic Instrumentation as an Enabler for Log-

ging Agents. Instrumentation is not always neces-

sary for log enhancement (Ma et al., 2015). However,

in the case of logging agents for third-party applica-

tions it is the primary enabler (Toslali et al., 2021;

Bellizzi et al., 2022). While the approach introduced

in this paper was evaluated using an enhancement

technique that leverages instrumentation, the main

aim of our work involved developing logging agents

that require less reverse engineering effort while mit-

igating the accuracy risks in the logs generated.

Android Forensic Enhancement. In the context of

Android, DroidForensics (Yuan et al., 2017) enables

multi-layer logging events on Android from differ-

ent layers, while CopperDroid (Tam et al., 2015) pro-

poses system-call logging. Rather than utilising a log-

ging agent to log events of interest, these solutions re-

quire modiﬁcations to the underlying Android system.

While this means that application reverse engineering

and agents breaking compatibility are no longer an is-

sue, users must signiﬁcantly modify their devices.

Our work builds on previous research that intro-

duces the JIT-MF framework (Bellizzi et al., 2020;

Bellizzi et al., 2022; Bellizzi. et al., 2021), a foren-

sic enhancement technique for Android that uses

application-speciﬁc logging agents (drivers) to dump

evidence from memory to aid investigations regard-

ing benign application misuse. The cornerstone of

the framework is a JIT-MF driver having application-

speciﬁc properties related to the application-speciﬁc

trigger points and objects that need to be dumped

from memory. Previous work evaluated the impact

black-box (non-application-speciﬁc) trigger points

would have on the object (evidence) dumped (Bel-

lizzi et al., 2020); however, the object itself was

application-speciﬁc. Experiment results from this

paper show that JIT-MF drivers should follow an

infrastructure-centric approach, which reduces appli-

cation reverse engineering effort by forgoing the need

to work with application-speciﬁc objects and thus in-

creasing the driver’s stability across applications and

versions.

7 CONCLUSION

This paper presents a new approach to developing

post-deployment forensic logging agents, deployed

during the forensic readiness stage of incident re-

sponse, for third-party applications whose access to

the source code is limited. This approach leverages

interfaces to widely deployed infrastructure to min-

imise the reverse engineering efforts required to de-

velop such agents, thereby increasing compatibility

across applications and versions.

Our experiments have shown that SQLite can

be leveraged in the context of Android messaging

Using Infrastructure-Based Agents to Enhance Forensic Logging of Third-Party Applications

399

apps to develop infrastructure-based logging agents

that remain prevalent across app versions and func-

tional across three different applications. In doing

so, we considerably reduce the reverse engineering

effort while increasing compatibility across applica-

tions and their versions.

Coverage analysis based on data from AppBrain

also shows that potentially, using this approach, 95%

of most downloaded apps on Google Playstore can

be forensically enhanced using at most two storage-

related infrastructure-based forensic logging agents.

This signiﬁcantly reduces the number of agents that

need to be developed and the individual apps that

would need to be reverse-engineered. This result

bodes well for JIT-MF and any other forensic logging

enhancement technique aiming to provide deeper

visibility through a third-party application-speciﬁc

forensic logging agent.

ACKNOWLEDGEMENTS

This work is supported by the DETECTIF (Digi-

tal Evidence Targeting covErt Cyberattacks through

Timely Information Forensics) project. DETECTIF

is funded by the Malta Council for Science and Tech-

nology (MCST) under the FUSION R&I: Research

Excellence Programme, Grant Agreement No. REP-

2022-007.

REFERENCES

Amer Owaida (2021). Wormable android malware spreads

via whatsapp messages. https://www.welivesecurity.c

om/2021/01/26/wormable-android-malware-spreads

-whatsapp-messages. Accessed: 9.11.2021.

Ammann, P., Jajodia, S., and Liu, P. (2002). Recovery from

malicious transactions. IEEE transactions on knowl-

edge and data engineering, 14(5):1167–1185.

AppBrain (2022). Appbrain: Monetize, advertise and ana-

lyze android apps. https://www.appbrain.com/stats/l

ibraries. Accessed: 23.08.2022.

AppBrain API (2022). https://api.appbrain.com/v2/info/b

rowse. Accessed: 20.10.2022.

Bellizzi, J., Vella, M., Colombo, C., and Hernandez-Castro,

J. (2020). Real-time triggering of android memory

dumps for stealthy attack investigation. In NordSec,

pages 20–36.

Bellizzi., J., Vella., M., Colombo., C., and Hernandez-

Castro., J. (2021). Responding to living-off-the-land

tactics using just-in-time memory forensics (jit-mf)

for android. In SECRYPT, pages 356–369.

Bellizzi, J., Vella, M., Colombo, C., and Hernandez-Castro,

J. (2022). Responding to targeted stealthy attacks on

android using timely-captured memory dumps. IEEE

Access, 10:35172–35218.

Cohen, M. I., Bilby, D., and Caronni, G. (2011). Distributed

forensics and incident response in the enterprise. dig-

ital investigation, 8:S101–S110.

Flubot (2021). Flubot malware – all you need to know & to

act now. https://www.threatmark.com/flubot-bankin

g-malware/. Accessed: 6.03.2021.

Google (2022). File-based encryption. https://source.and

roid.com/security/encryption/file-based Accessed:

22.10.2022.

Jon Russell (2012). Stealth sms payment malware iden-

tiﬁed in chinese android app stores, 500,000 devices

infected. https://thenextweb.com/news/stealth-sms-

payment-malware-identiﬁed-chinese-app-stores-500

000-android-devices-infected. Accessed: 2.10.2022.

King, S. T. and Chen, P. M. (2003). Backtracking intrusions.

In ACM SOSP, pages 223–236.

King, S. T., Mao, Z. M., Lucchetti, D. G., and Chen, P. M.

(2005). Enriching intrusion alerts through multi-host

causality. In NDSS.

Lee, K. H., Zhang, X., and Xu, D. (2013). High accuracy at-

tack provenance via binary-based execution partition.

In NDSS, volume 16.

Ma, S., Lee, K. H., Kim, C. H., Rhee, J., Zhang, X., and Xu,

D. (2015). Accurate, low cost and instrumentation-

free security audit logging for windows. In ACSAC,

pages 401–410.

Ma, S., Zhang, X., Xu, D., et al. (2016). Protracer: Towards

practical provenance tracing by alternating between

logging and tainting. In NDSS, volume 2, page 4.

Mace, J., Roelke, R., and Fonseca, R. (2015). Pivot tracing:

Dynamic causal monitoring for distributed systems. In

Proceedings of the 25th Symposium on Operating Sys-

tems Principles, pages 378–393.

Newsome, J. and Song, D. X. (2005). Dynamic taint anal-

ysis for automatic detection, analysis, and signature-

generation of exploits on commodity software. In

NDSS, volume 5, pages 3–4.

Octo (2022). Look out for octo’s tentacles! a new on-device

fraud android banking trojan with a rich legacy. https:

//threatfabric.com/blogs/octo-new-odf-banking-troj

an.html. Accessed: 16.08.2022.

Tam, K., Fattori, A., Khan, S., and Cavallaro, L. (2015).

Copperdroid: Automatic reconstruction of android

malware behaviors. In NDSS Symposium 2015, pages

1–15.

ThreatLandscape (2022). 2022 mobile threat landscape up-

date. https://www.threatfabric.com/blogs/h1-2022-m

obile-threat-landscape.html. Accessed: 6.03.2021.

Toslali, M., Ates, E., Ellis, A., Zhang, Z., Huye, D., Liu,

L., Puterman, S., Coskun, A. K., and Sambasivan,

R. R. (2021). Automating instrumentation choices for

performance problems in distributed applications with

VAIF. In ACM SoCC, pages 61–75.

Yuan, D., Park, S., Huang, P., Liu, Y., Lee, M. M., Tang, X.,

Zhou, Y., and Savage, S. (2012a). Be conservative:

Enhancing failure diagnosis with proactive logging. In

USENIX OSDI, pages 293–306.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

400

Yuan, D., Zheng, J., Park, S., Zhou, Y., and Savage, S.

(2012b). Improving software diagnosability via log

enhancement. ACM TOCS, 30(1):1–28.

Yuan, X., Setayeshfar, O., Yan, H., Panage, P., Wei, X., and

Lee, K. H. (2017). Droidforensics: Accurate recon-

struction of android attacks via multi-layer forensic

logging. In ACM ASIACCS, pages 666–677.

Zhao, X., Rodrigues, K., Luo, Y., Stumm, M., Yuan, D.,

and Zhou, Y. (2017). Log20: Fully automated optimal

placement of log printing statements under speciﬁed

overhead threshold. In ACM SOSP, pages 565–581.

Using Infrastructure-Based Agents to Enhance Forensic Logging of Third-Party Applications

401
