SLAE6: Secure and Lightweight Authenticated Encryption Scheme

for 6LoWPAN Networks

Fatma Foad Ashrif

1,2 a

, Elankovan A. Sundarajan

, Rami Ahmed

and Mohammad Kamrul Hasan

Faculty of Information Science & Technology, Universiti Kebangsaan Malaysia, 43600 Bangi, Selangor, Malaysia

Department of Computer Science, Sebha Universit, Ubari, Libya

College of Computer Information Technology, American University in the Emirates, 503000, Dubai, U.A.E.

Keywords: Internet of Things, Authenticated Encryption, Key Establishment, 6LoWPAN, Wireless Sensor Networks.

Abstract: The emergence of the Internet of things is highly related to the development of wireless sensor networks

(WSNs) and their evolving protocols, such as Internet Protocol version 6 (IPv6) over Low-Power Wireless

Personal Area Networks (6LoWPAN). Providing security within a sensor network, including achieving

authentication between WSN nodes, is critical. The node and the server create an encryption session key for

future communications. Therefore, developing a lightweight and efficient authentication and key

establishment (AKE) scheme is imperative. Symmetric cryptographic and public key-based AKE methods

have been developed to address these issues. Nevertheless, some known attacks and large communication and

computational overheads remain as problems for the developed solutions. This study proposes a secure

and lightweight authenticated encryption scheme for 6LoWPAN (SLAE6) that uses a lightweight hash

function and an authenticated encryption primitive, known as ACE, to enable the AKE process to occur

securely. SLAE6 is effective in dealing with computing and communication complexities while

simultaneously withstanding well-known attacks. First, SLAE6 validates the authenticity of information from

sensor networks (SNs) and then establishes a secret key between an SN and the server to guarantee security.

The proposed system is proven reliable on the basis of the Canetti–Krawczyk and Dolev–Yao threat models.

In addition, SLAE6 is logically demonstrated to be exact through Burrows–Abadi–Needham logic. Compared

with other schemes, SLAE6 is lightweight, efficient, and requires less bandwidth and shorter execution time.

1 INTRODUCTION

IPv6 addresses used by sensor nodes allow them to

transmit sensing information to other devices or to a

central location across the Internet through IPv6 over

Low-Power Wireless Personal Area Networks

(6LoWPAN) (Bagwari et al., 2022), which is meant

to support all the functions of IPv6 over LoWPAN,

including packet fragmentation, reassembly, and

encapsulation (Tanaka et al., 2019). 6LoWPAN

applications must provide privacy and security

because they transmit information via the Internet.

However, no security or privacy feature is built into

the basic 6LoWPAN design to prevent unauthorized

https://orcid.org/0000-0001-7711-7520

https://orcid.org/0000-0003-2711-0659

https://orcid.org/0000-0003-3913-6397

https://orcid.org/0000-0001-5511-0205

entities from obtaining information or unauthorized

users from gaining access to network resources

(Tanveer et al., 2020). Considering the resource

constraints and insufficiently organized network

architecture in 6LoWPAN, securing these networks

has become more challenging (Monika et al., 2022).

A 6LoWPAN designed for WSNs and IoT should

have inexpensive sensor nodes that require relatively

low power, resulting in low computation performance

(Wazirali et al., 2021). Moreover, sensitive areas

occasionally require nodes that cannot be regularly

powered, and thus, conserving energy while

maintaining security is essential (Ahmad et al.,

2021)(Wazirali & Ahmad, 2022).

Ashrif, F., Sundarajan, E., Ahmed, R. and Hasan, M.

SLAE6: Secure and Lightweight Authenticated Encryption Scheme for 6LoWPAN Networks.

DOI: 10.5220/0011632200003399

In Proceedings of the 12th International Conference on Sensor Networks (SENSORNETS 2023), pages 67-78

ISBN: 978-989-758-635-4; ISSN: 2184-4380

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

Furthermore, a secure connection layer requires

powerful hardware and consumes considerable

power (Ahmad et al., 2021). Lightweight

cryptography (LWC) algorithms offer an efficient

means of reducing computation complexity and

preserving security. An authentication scheme that is

lightweight and secure is an effective way to establish

scalable and reliable communication between IoT

devices (Amanlou et al., 2021). 6LoWPAN must

ensure authenticity, data integrity, freshness,

availability, and confidentiality. Confidentiality

ensures that data are transmitted securely between

authorized WSNs and servers. In 6LoWPAN,

authentication and key establishment (AKE) is a

mechanism for identifying a network’s security;

implementing a lightweight AKE mechanism is

imperative (Tanveer et al., 2021). AKE is crucial for

achieving reliable and secure communication in the

IoT or WSN. Given the computational complexity of

SNs, conventional AKE schemes, such as

blockchains and passwords, are unsuitable for

6LoWPAN devices. Compared with public-key

cryptography, less energy and computational

resources are consumed by symmetric-key

cryptography (Hasan et al., 2021). An authenticated

encryption with associative data (AEAD) scheme is

presented using a lightweight cryptography primitive

known as ACE (Aagaard et al., 2019). With an LWC-

based authenticated encryption (AE) scheme, data

encryption and authentication are performed

simultaneously. Therefore, we propose a secure and

lightweight AE scheme for 6LoWPAN (SLAE6) that

is secure and efficient by using AEAD mechanisms.

SLAE6 ensures anonymity, untraceability, and end-

to-end security from the SNs to the server. The

following contributions are highlighted in the current

study.

 An AKE scheme that provides end-to-end

security by using LWC-based lightweight

AEAD mechanisms, XOR operation, and hash

function (HF) is proposed.

 An informal analysis is conducted to

demonstrate the robustness of SLAE6 under

the threat models of Dolev–Yao (DY) and

Canetti–Krawczyk (CK). A formal analysis

based on Burrows–Abadi–Needham (BAN)

logic confirms MA.

 SLAE6 has less computation cost, bandwidth

requirements and execution time than other

related schemes.

The remainder of this paper is organized as

follows. Section 2 provides a presentation related to

the AKE scheme. Section 3 describes the adopted

system model. Section 4 explains our proposed

scheme in detail. Section 5 provides a security

analysis of the proposed SLAE6 and its comparison

with related schemes. Section 6 concludes the

paper. Table 1 summarizes the abbreviations used

throughout this paper.

Table 1: Abbreviation table.

Acron

ms Para

hrase

WSN Wireless Sensor Networ

IoT Internet of Things

6LoWPAN

IPv6 over Low-Power Wireless

Personal Area Networks

LWC Lightweight Cryptograph

AKE Authentication and Key Establishment

AEAD Authenticated Encryption with

Associative Data

MITM Man in the Middle

HF Hash Function

DoS Denial of Service

ECC Elli

tic-curve Cr

PKI Public Ke

Infrastructure

PUF Physical Unclonable Function

DY Dolev

–

Yao model

Canetti

–

Krawcz

k model

2 RELATED WORK

This section provides an overview of existing IoT

AKE schemes. Various security specifications for

6LoWPAN were discussed in Hennebert and Santos

(2014). The authors proposed a secure AKE scheme

(SAKES) by using public-key cryptography (Hussen

et al., 2013); however, this scheme is computationally

costly for devices with limited storage. Qiu and Ma

(2016) proposed an AKE scheme based on a hybrid

cryptography approach for 6LoWPAN that is

insecure against chosen plaintext, sinkhole, and node

capture attacks in accordance with Gao et al. (2020).

Chom Thungon et al. (2020) claimed that this scheme

cannot resist replay and man-in-the-middle (MITM)

attacks. However, although Gao et al. (2020)

addressed these security concerns, both schemes still

require considerable computing and communications.

In Chom Thungon et al. (2020), an authentication

scheme that utilizes lightweight keys and is optimized

for 6LoWPAN was proposed to authenticate

resource-constrained sensor devices that use HF and

XOR operations. However, their scheme cannot

detect some attacks, such as denial-of-service (DoS)

attacks. In Tanveer et al. (2020), the authors presented

an AKE scheme that uses HF, XOR operations, and

ASCON for 6LoWPAN. However, this scheme lacks

untraceability features. In Chom Thungon et al.

SENSORNETS 2023 - 12th International Conference on Sensor Networks

(2020) and Tanveer et al. (2020), BAN logic was used

to verify the security of the proposed scheme. Alshrif

et al. (2021) developed an AKE framework based on

a symmetric algorithm, HF, and XOR operations;

then, they proposed a lightweight encryption

technology scheme that enables energy efficiency and

secures WSN communication in 6LoWPAN. Ahmed

et al. (Ahmad et al., 2022) presented a secure and

cost-saving framework for low-cost 6LoWPAN

based on adaptive trust. Anonymity and

untraceability are not considered in many of these

protocols. Performing a public key infrastructure

(PKI)-based technique is computationally intensive.

Most elliptic-curve cryptography (ECC)-based

schemes utilize time-consuming bilinear pairing

operations. Nevertheless, ECC-based authentication

and key agreement cost lower than PKI-based

schemes. Even hardware-based solutions, such as

physical unclonable function (PUF) (Fragkos et al.,

2022), cannot be implemented in some environments,

such as underwater or climate monitoring.

Implementing robust security and privacy in a WSN

or IoT environment at lower communication and

computational costs remains challenging. In

consideration of this issue, we propose a 6LoWPAN-

compatible AKE scheme that uses an efficient and

secure AEAD called ACE, ephemerals, pseudo

identities, XOR, and hashing. This scheme requires

minimal execution time and bandwidth.

3 SYSTEM MODEL

The proposed scheme and network of SLAE6 and the

threat models are presented in this section.

3.1 Network Model

The SLAE6 network model is presented in Figure 1

to illustrate mutual AKE in 6LoWPAN. The proposed

protocol includes 6LoWPAN sensor nodes (6LNs),

6LoWPAN router (6LR), 6LoWPAN border router

(6LBR), and 6LoWPAN server (6LS). As shown in

Figure 1, the 6LNs gather data, while the 6LR

aggregates the sensor data before forwarding them to

the 6LBR, which delivers them to the 6LS. In addition,

the 6LR facilitates Internet connectivity within

domains via the 6LNs. The 6LR provides IPv6 cloud

interconnectivity with the 6LS. Communications

among the 6LR, 6LBR, and 6LS are assumed as

secure. In addition, the 6LNs, 6LR, and 6LBR are

assumed to reach the 6LS. In addition to registering

with the 6LS via a secure channel, the 6LR

communicates with the 6LNs via the neighbor

discovery (ND) protocol to exchange temporary

identities. The 6LR also registers itself with the 6LBR.

All 6LoWPAN devices access the 6LS global routing

prefix through the 6LBR. In addition, the 6LNs

generate IPv6 addresses by using IEEE extended

unique identifiers referred to as PAN IDs (Hui &

Thubert, 2011).

Figure 1: Network model of SLAE6 provides AKE-based

AEAD from the 6LNs to the 6LS, ensuring end-to-end

security in 6LoWPAN networks.

3.2 Adversary Model

In this subsection, we will assume a model of attacks

that may expose communication between both ends

of the devices. Thus, securing communications

between the 6LNs and 6LS is imperative. Hence, the

6LS must also be prevented from receiving data from

illegitimate 6LNs. To ensure the credibility of the

6LNs, we devise an AKE procedure that provides a

secret SK that can be used for future communication

after validating the authenticity of the 6LNs. The

procedure design of SLAE6 falls under the following

definitions.

Definition 1: As a result of the one-time pad

theorem, if a random value is XORed with a value,

then the resulting value will also be random.

Definition 2: To have a secure HF, h(.): (a) given

an input message K, generating h(K) of a fixed length

given an input message K of an arbitrary length is

possible; and (b) in the case of K, finding the value of

h(K') = h(K) is computationally impossible.

Definition 3: In the DY model (Dolev & Yao,

1983), adversary (

) can (a) have valid credentials but

be malicious; and (b) control the open communication

medium, and thus, alter, intercept, insert, or erase

messages sent over this medium.

Definition 4: In accordance with the CK model

(Sarr et al., 2010), adversary (

) can compromise

session-specific state information and DY model

capabilities. Moreover, secrets must not be disclosed

by compromising the secrecy of another party if they

compromise the security of a party. In addition to the

adversary’s capabilities under the DY and CK threat

SLAE6: Secure and Lightweight Authenticated Encryption Scheme for 6LoWPAN Networks

models,

can compromise the session state, secret

key, and session key (SK) by using session hijacking.

Therefore, short-term (temporal) and long-term

(permanent) secrets must be considered in generating

the SK between two entities.

3.3 ACE: An Authenticated Encryption

Algorithm

To resolve the problems mentioned in Section 2, the

AEAD algorithm is used. With AEAD, associated

data (AD), such as routing data, can be verified in

terms of validity and integrity. The AEAD scheme

has elicited considerable interest in cryptography due

to the National Institute of Standards and Technology

(NIST)-funded Competition for Authenticated

Encryption: Security, Applicability, and Robustness

(CAESAR) and the NIST-LWC competition for

standardizing lightweight AEAD schemes. A report

was published in October 2019 on the lightweight

cryptography standardization process of NIST (Turan

et al., 2021). In the current study, we use ACE, an

authenticated encryption and hash algorithm. It is one

of the algorithms selected from NIST’s first round of

lightweight cryptography competition. In ACE

encryption and decryption algorithms, the input

includes AD, key, and nonce, each of which is 128

bits. The output includes ciphertext, plaintext, and

authentication tags, as shown in Figure 2. Therefore,

dividing or truncating the output of SHA-256 into 128

bits is necessary to generate ACE’s input parameters

for encryption and decryption.

Figure 2: ACE architecture (Aagaard et al., 2019).

4 PROPOSED SCHEME

ACE is used as the encryption scheme by the 6LS and

6LNs after verifying the authenticity of the 6LNs in

SLAE6. We generate a unique output string by

combining SHA-256 with bitwise XOR operations

and SLAE6 secret parameters. SLAE6 has two

phases: registration and AKE for the static 6LNs. The

subsequent sections provide additional details about

each phase. As indicated in Table 2, the current study

uses the following phases.

4.1 Registration Phase

A registration phase is required before the 6LN can be

deployed. The state is loaded byte-wise with a 128-

bit nonce Ns = N

|| N

and 128-bit key Km = K

, and the remaining 8 bytes are set to zero. The

6LS performs the following operations to register the

6LNs.

Table 2: List of notations.

Notation Description

6LN, 6LR, 6LBR,

6LS

6LoWPAN sensor node, 6LoWPAN

router, 6LoWPAN border router,

and 6LoWPAN server, respectively

TID

6LN

, TID

6LR

Temporary identities of the 6LN and

6LR.

6LN

, ID

6LS

Secret real identities of the 6LN and

6LS.

, O

SP1

Secret authentication parameters.

(Tag

6LN

,Tag′

6LN

(Tag

, Tag

6LS

)

Tag generated authentication

parameters for the 6LN and 6LS.

T1, T2, T3

Timestamps for 6LN, 6LBR, and

6LS, respectively.

, Tr

Maximum transmission delay limit

and received time of messages.

(Si,Si′′′),(Si′,Si′′)

Initialization states for the 6LN and

6LS.

6LN

, RN1, RN2,

R1, R2

The key and random numbers of the

6LN are used in the AKE process.

MAC

6LN

,MAC

6LS

MAC addresses of the 6LN and 6LS.

Verification of the temporary

identities of messages.

A, B

A and B are connected to represent

the message’s plain text (PT).

CT Cipher text of the message.

(), E

() Decryption and encryption of CT by

using the initialization state Si.

H(.), ||, ⊕ HF, concatenation, and bitwise

XOR, respectively.

Picks up of the 6LS real identity ID

6LS

, and it is

random number R

6LS

, such that we can compute the

master key (Km) by calculating Km = H(ID

6LS

||R

6LS

Km is divided into 64 bits by the 6LS, namely, K

and K

. K

6LS

= K

⊕ K

is computed, where K

6LS

is a temporary key for the 6LS. A nonce Ns of 128 is

generated. The 6LS divides Ns into two 64-bit chunks:

and N

. A unique ID

6LN

, K

6LN

, is selected, and the

temporary identity (TID

6LN

) of 64 bits for the 6LN is

computed. TID

6LN

= ID

6LN

⊕ K

6LN

⊕ K

6LS

SENSORNETS 2023 - 12th International Conference on Sensor Networks

Subsequently, the 6LS computes its temporal secret

component by computing T

=H(Km||K

6LN

||ID

6LS

)

and calculating O

= O

⊕ O

where O

, O

, and O

are 64-bit chunks

divided into four equal parts of O

. To load the state,

a 128-bit nonce Ns = N

||N

, a 128-bit key Km=

||K

, and the remaining 8 bytes are set to zero.

Then, Load_AE(Ns||Km). Finally, the 6LS stores

6LN-related secret information, i.e., {ID

6LS

, O

, K

6LN

6LS

, MAC

6LN

} into its database and {ID

6LS

, O

, K

6LN

TID

6LN

, MAC

6LS

} in 6LN’s memory by utilizing a

secure channel. Secure channels are also used by the

6LS to store TID

6LN

in the 6LR memory.

4.2 Initialization State

This phase is dedicated to initializing ACE’s state Si,

which is composed of 320 bits and called the

initialization state Si. The 6LN, which is a random

number R1 of 64 bits, is generated and computes

6LN

=(R1||TID

6LN

), where M

6LN

is an initialization for

the 6LN. The size of Si is 320 bits (load−AE(Ns||Km)

= 256 bits + M

6LN

= 64 bits), which is used during the

initialization phase as input to the encryption

algorithm. Thereafter, the state is absorbed once the

permutation ACE is applied to the two key blocks.

The following are the initialization steps:

 Si ← ACE (load-AE(Ns||Km)),

 Si ← ACE (K

⊕

6LN

 Si ← ACE (K

⊕

6LN

4.3 Associative Data Generation

To generate AD, we perform the following

operations:

The 6LN computes P

=H(R1||MAC

6LN

). Then, it

divides P

into two, namely, P

HC1

and P

HC2

, with

each containing 128 bits. The 6LN calculates AD =

HC1

⊕

HC2

. AD is 128 bits in size. To preserve the

integrity of the associative data, the encryption

algorithm uses AD as one of the input in the

associative data processing phase.

4.4 AKE Phase

In this phase, the 6LN enables anonymous AKE with

the 6LS by using the 6LR and 6LBR as intermediate

nodes. The 6LN and 6LS can exchange data securely

once a secret key is established. The authentication

process involves four messages exchanged by

SLAE6. The details about the messages exchanged in

SLAE6 are provided as follows.

Step 1: The 6LN generates 46 bits random number

RN1 and 32 bits timestamp T1 for computing A=ID

6LN

⊕RN1⊕O

and B= ID

6LN

⊕RN1, where A and B are

64 bits. The 6LN and 6LS use Si as input to the ACE

encryption algorithm. AD is computed in the

associative data generation processing. When (A||B)

is processed at the plaintext level, it produces the

ciphertext (CT)=E

{AD, (A||B)} and Tag

6LN

, (which

is generated automatically by ACE. That tag is

extracted from the same byte positions used when the

key is loaded. Consequently, CT ensures that

plaintext (A||B) is confidential. On the receiving end,

Tag

6LN

ensures the integrity and authenticity of the

ciphertext CT. The Tag

6LN

function is similar to the

message authentication code (MAC). The 6LN

calculates D=TID

6LN

⊕TID

6LR

, where TID

6LR

is the

temporary identity of the 6LR. After these operations,

the 6LN constructs a message Mgs

:(T

6LN

||D || (CT

||Tag

6LN

)||R1) that is sent to the 6LR for further

processing.

Step 2: Upon receiving Msg

from the 6LN, the

6LR extracts D and computes TID

=D ⊕TID

6LN

. The

6LR compares TID

with the stored TID

6LR

in its

memory. As long as TID

and TID

6LR

have the same

contents, 6LR adds its TID

6LR

with the received Msg

to generate the new message Msg

:(TID

6LR

|| Msg

)

and forwards it to the 6LBR. Otherwise, the message

is sent back to the 6LN if the 6LR aborts the AKE

process.

Step 3: The 6LBR receives Msg

from the 6LR

and checks the existence of TID

6LR

in its database.

The AKE process is aborted if the 6LBR cannot find

TID

6LR

in the list, and the unverified TID

6LR

is added

to the block list. By contrast, upon successfully

verifying the TID

6LR

for Msg

, the 6LBR selects a time

stamp T2 and computes S

6LBR

= K

6LBR

⊕ TID

6LR

where TID

6LBR

is the temporary identity of the 6LBR,

and K

6LBR

is the pre-shared key between the 6LBR

and 6LS. In the next step, the 6LBR generates

Msg

:(TID

6LBR

||T2||Msg

||S

6LBR

) and forwards it to

the 6LS to be processed further.

Step 4: Upon receiving Msg

from the 6LBR, the

6LS retrieves 6LBR-related secret information by

utilizing TID

6LBR

. Moreover, the 6LS checks T2

validity by checking that Msg

is received within the

allowance maximum transmission delay (T

) by

calculating Tr−T2

≤

, where Tr represents the

received timestamp for Msg

. To verify the integrity

of Msg

, the 6LS derives S

6LBR

'= K

6LBR

⊕ TID

6LR

. If

6LBR

' and the received S

6LBR

do not match, then the

6LBR is added to the suspicious device list. After

verifying the integrity of Msg

, the 6LS extracts Msg

from Msg

and checks its freshness by confirming

whether Tr−T1

≤

. the 6LS rejects Msg

if the

condition is not met. A valid TID

6LR

is also checked

in the current list of 6LR devices by the 6LS. If the

verification of TID

6LR

is successful, then the 6LS

SLAE6: Secure and Lightweight Authenticated Encryption Scheme for 6LoWPAN Networks

extracts D from Msg

, derives TID

6LN

by computing

TID

6LR

⊕ D, and verifies if TID

6LN

exists in its

database. The 6LS retrieves ID

6LN

, K

6LS

, K

6LN

, and O

information after verifying TID

6LN

in its database.

Using R1 and TID

6LN

, the 6LS generates M

6LN

from

Msg

. Moreover, the 6LS determines AD by using R1

from Msg

and the stored MAC

6LN

in the 6LS’s

database by computing P

'=H(R1||MAC

6LN

). Hence,

AD'=P

HC1

'⊕P

HC2

'. In addition, the 6LS performs the

decryption operation Dsi′{(AD', CT)}. As the

decryption algorithm extracts the plaintext

information, Tag

is first generated. When ACE

processes AD and the ciphertext, the authentication

Tag

is generated automatically. When Tag

6LN

received with Msg

, the 6LS checks the condition

Tag

6LN

=Tag

. Inverse-free authentication schemes

generate the same authentication tag during

encryption and decryption if AD and the ciphertext

are not modified. Nonetheless, if the communicated

message is modified, then the generated

authentication tag differs, resulting in the proposed

AKE failing to authenticate. A successful decryption

reveals the plaintext information if the condition

holds. Otherwise, the AKE process is aborted if this

scenario occurs. When CT is decrypted, A and B are

revealed as plaintext. The 6LS selects ID

6LN

and

computes the ID

6LN

⊕ B operation to determine RN1

for calculating O

' =ID

6LN

⊕ RN1⊕ A. In addition,

the 6LS checks if O

' to ensure the legitimacy

of the 6LN. AKE is aborted if the condition does not

hold. The 6LS registers the 6LN as a legitimate

device. Upon verifying the validity of the 6LN, the

6LS selects the 32-bit timestamp T3 and 64 bits

random numbers RN2, R2, and RN. Then, T''=H(Km||

||ID

6LS

) is derived and a new security parameter

SP1

is calculated by computing

SP1

=T''

⊕T''

. The 6LS calculates

B1=RN⊕K

6LS

, A1=B1⊕RN1, and M

6LS

'=H(R2||A1).

To generate Si', the 6LS generates nonce Ns" and

calculates Si''=load-AE(Ns||Km). Subsequently, the

6LS calculates AD by computing P

=H(R1||MAC

6LN

), AD1=P

⊕P

''. To ensure

future secure communication, the 6LS computes an

SK by computing SK=H(ID

6LN

||B1||O

SP1

||RN1||RN2).

Furthermore, during the initialization phase, Si" is

considered by the encryption algorithm, AD′′ during

the AD processing phase, and (O

SP1

||RN2) while

processing plaintext information to generate

{CT1}=E

"{AD′′,(O

SP1

||RN2)} and Tag

6LS

Moreover, the 6LS constructs the message

Msg

:(T3||A1||(CT1||Tag

6LS

)||R2) and forwards it to

the 6LBR. Then, the 6LBR and 6LR forward Msg

the 6LN. Lastly, the 6LS saves the parameters {ID

6LN

, O

SP1

, K

6LS

} in its memory.

Step 5: Upon obtaining Msg

, the 6LN verifies the

freshness of timestamp T3 by checking whether

Tr−T3

≤

, where Tr represents the period in which

Msg

has been received and T

represents the

maximum allowed time. Significantly, the 6LN

rejects Msg

if T3 exceeds the maximum time

allowed. The 6LN obtains R2 and A1 from Msg

and

computes M

6LS

''=H(R2||A1). M

6LS

also calculates

B1=RN1⊕A1, Ns'''=H(O

||TID

6LR

) and Si'''=(load-

AE(Ns||Km)'''|| M

6LS

'''). Subsequently, the 6LN

calculates AD by computing P

'' =H(R1||MAC

6LN

AD1= P

'''

⊕ P

'''. As the input to the decryption

algorithm, Si" receives an associative data processing

phase of Si, and CT1 receives a ciphertext processing

phase of CT. The decryption operation is performed

on DSi'"{AD'", CT1} to generate Tag

6LN

". In the final

step, the 6LN checks whether Tag

6LN

=Tag

6LS

. As long

as the condition is met by decrypting the message, the

plaintext is revealed, i.e., (O

SP1

||RN2). Then, the 6LN

computes SK by computing SK=H(ID

6LN

||B1||

SP1

||RN1||RN2) to secure future communications

with the 6LS. Finally, the 6LN stores the parameters

{ID

6LN

, O

SP1

, TID

6LN

, K

6LN

} in its memory.

5 COMPARATIVE AND

SECURITY ANALYSES

This this section has two parts. The first provide

security analysis, and the second provides

performance evaluation.

5.1 Security Analysis

SLAE6 is analyzed in two phases in this section. The

first phase describes SLAE6’s capabilities and

characteristics against malicious attacks. The second

phase incorporates BAN logic to demonstrate the

logical correctness of the SLAE6 scheme.

5.1.1 Informal Security Analysis

Throughout this subsection, the robustness of this

protocol is demonstrated under all DY and CK

assumptions, as discussed in the threat models. The

DY and CK models assume that network

communication occurs over unsecured channels, and

none of the communicating entities can be trusted. On

the basis of the adversarial properties found in

Definitions 3 and 4, the proposed protocol was

evaluated against replay, impersonation, MIMT, and

DoS attacks, except for the ephemeral-secret-leakage

(ESL) attack, which was evaluated only under CK.

Furthermore, SLAE6 ensures MA, perfect forward

secrecy, untraceability, and anonymity. The

following theorems are used to achieve this

objective:-

SENSORNETS 2023 - 12th International Conference on Sensor Networks

Theorem 1: SLAE6 ensures MA.

Proof: Each participant authenticates the other by

using a public channel during the AKE phase. To

confirm the authenticity of the 6LN, the 6LS checks if

the device’s ID is in its memory and confirms that

Tag

=Tag

6LN

. To ensure the authenticity of the 6LS,

the 6LN verifies the condition Tag

6LN

=Tag

6LS

Consequently, the 6LS and 6LN reach MA with the

help of 6LR and 6LBR in SLAE6.

Theorem 2: SLAE6 ensures forward/backward

secrecy (F/B S).

Proof: An SK for an AKE session can be determined

by computing the value

SK=H(ID

6LN

||B1||O

SP1

||RN1||RN2) for every AKE

session. New parameters, such as B1, O

SP1

, RN1, and

RN, are incorporated into the new AKE process. An

adversary (

) cannot compromise the future SK if the

current SK is compromised. Consequently,

adversaries cannot construct past or future SKs in our

scheme.

Theorem 3: SLAE6 ensures untraceability and

anonymity.

Proof: Consider the scenario in which messages have

been eavesdropped by an adversary (

), Msg

and

Msg

, where Msg

:(T1||D ||(CT||Tag

6LN

)||R1) and

Msg

:(TID

6LR

||(M

sg1

)). Furthermore, D=TID

6LN

⊕TID

6LR

and (CT, Tag

6LN

)=E

{AD,(A||B)}. By using

captured messages exchanged over insecure

channels, the attacker attempts to derive the 6LS’s

6LS

and the 6LN’s ID

6LN

. When transacting with

authentication messages, the 6LN uses temporary

identity TID

6LN

, calculated as TID

6LN

⊕K

6LN

⊕K

6LS

, where all the parameters are

secret to the 6LS and 6LN. Therefore,

experiences

difficulty generating TID

6LN

without these

parameters. In addition,

cannot distinguish

messages from different participants by including the

random number R1 and timestamp T1 in

messages. The 6LN in SLAE6 selects fresh random

numbers in every new session. The 6LN performs

different computations to generate fresh random

numbers, such as A=ID

6LN

⊕RN1⊕O

and

B=ID

6LN

⊕RN1. (A||B) is used in plaintext processing

and produces ciphertext. Hence, for every new

session, Si, CT, and Tag

6LN

are different because fresh

random numbers are used in SLAE6. Furthermore, a

new T1 of the 6LN is created after a session is

completed, increasing the untraceability of messages.

Consequently, SLAE6 provides anonymity and

untraceability.

Theorem 4: SLAE6 is resistant to replay attacks.

Proof: An adversary (

) is assumed to have

intercepted messages Msg

, Msg

, and Msg

exchanged between the 6LN and 6LS. In the

subsequent step, these messages take some time to

reach their recipients after they are archived.

Nevertheless, Msg

incorporates timestamp T1, Msg

incorporates timestamp T2, and Msg

incorporates

timestamp T3. As soon as the 6LS receives Msg

, it

confirms whether |Tr−T2| and |Tr−T1| are less than or

equal to T

. Similarly, when Msg

is received, the

6LN checks whether |Tr−T3| is equal to

. Moreover, the random numbers RN1, RN2, R1,

and R2 provide freshness to the messages. When the

freshness tests fail for these messages, both sessions

are terminated. Therefore, SLAE6 is protected

against replay attacks.

Theorem 5: SLAE6 is protected against DoS attacks.

Proof: By spoofing IP addresses, IP spoofing attacks

send large data packets over networks to launch a

DoS attack. In SLAE6, a DoS attack requires an

adversary (

) to calculate the following: compute

(AD), M

6LN

=(R1||TID

6LN

), Si=(load_AE(Ns||Km)

||M

6LN

), and (CT,Tag

6LN

)=E

{AD,(A||B)} to check

the condition Tag

=Tag

6LN

. The condition

Tag

=Tag

6LN

will not hold because it requires

parameters that are secret to the 6LN and 6LS,

namely, ID

6LN

, O

, and K

6LN

. Hence, SLAE6 is

protected against DoS attacks.

Theorem 6: SLAE6 is protected against

impersonation threats.

Proof: In this attack, an adversary (

) attempts to

mask as a legitimate 6LN or 6LS. It requires the

construction of a valid acknowledgment message,

Msg

and

Msg

. An impersonation attack can be

prevented by considering the following cases.

6LN impersonation attack:

must produce a valid

message Msg

:(T1||D||(CT||Tag

6LN

)||R1) on behalf of

the 6LN to execute an impersonation attack.

can

easily generate a timestamp. Therefore, to generate

the other parameters of a valid Msg

must know the

secret credentials, which include D and CT. The 6LN

knows only a few parameters. Therefore, SLAE6 is

resistant to 6LN impersonation.

6LS impersonation attack: The primary objective

of this attack is to fool the 6LS into believing that

Msg

and Msg

are from the 6LN by concocting

Msg

:(ID

6LBR

||T2 ||Msg

||S

6LBR

) on behalf of the 6LS.

The timestamps can be generated easily by

. Only the

6LS and 6LN know the secret parameters, including

6LN

, CT, and TID

6LN

, which enable

to generate the

remaining Msg

. Creating a valid Msg

without these

secret credentials is impossible, and thus, SLAE6 is

immune to 6LS impersonation attacks.

Theorem 7: SLAE6 is robust against MITM attacks.

Proof: This attack is designed to intercept and modify

messages Msg

, Msg

, and Msg

Then,

SLAE6: Secure and Lightweight Authenticated Encryption Scheme for 6LoWPAN Networks

unsuspecting recipients receive these messages.

Assume that an adversary (

) captures all messages

transmitted by Msg

, Msg

, and Msg

as the

6LN communicates with the 6LS. For example,

suppose

forges Msg

for the 6LS to believe that it is

authentic.

must guess the real identity of the 6LN,

which is impossible. Therefore,

cannot generate a

false message Msg

. All other transmitted messages

are subject to the same condition. Clearly, SLAE6 is

protected against MITM attacks.

Theorem 8: SLAE6 is resistant to ESL attacks.

Proof: ESL attacks under the CK adversary model

assume that leaks session-dependent ephemeral

values, such that adversary (

) cannot decode session

keys and long-term secrets. SLAE6 establishes a

secure communication key between the 6LN and 6LS

during the AKE process. Several ephemeral terms,

such as RN1 and RN2, and long terms, such as ID

6LN

are incorporated into the established SK. Even if A

compromises RN1 and RN2, A still needs long-term

TID

6LN

to break SK's security SK=H (ID

6LN

|| B1|| O

SP1

|| RN1|| RN2). SK's security cannot be compromised

unless

knows what valid long and ephemeral terms

are required. As a result, the proposed SLAE6 can

withstand an ESL attack.

5.1.2 Ban Logic Analysis

An AKE process of SLAE6 is formally tested using

BAN logic (Burrows et al., 1990) and determining

whether participant agreements are trustworthy. To

assess SLAE6’s MA properties, BAN logic is

used. BAN logic is described using the notations in

Table 3, which describe how different inference rules

are drawn. In Table 4, several logical rules for

determining the goal of a proposed scheme are

presented. SLAE6 makes the following assumptions

as a starting point for investigating our scheme’s

AKE properties.

Table 3: BAN logic notations.

Feature Description

|≡ B

elieves

∼

A once said B.

⊲

A controls B.

𝑨

𝒌

↔

E and R share the key with k.

𝒌

⇔

k is a secret parameter known only by E and R.

(

)

is fresh.

{

}

is encrypted by k.

(

)

is combined with secret S.



A receives B.

𝑨

𝑹

If A is true, then R is also true.

Goals: BAN logic in SLAE6 is based largely on

establishing an SK with each principal. As defined in

Table 5, SLAE6 seeks to achieve the following goals

for MA.

Table 4: BAN logic inference rules.

Notation Description

Message Meaning

Rule (MMR)

𝐴| ≡𝐴



↔ 𝑅, 𝐴⊲{𝐵}



𝐴 | ≡𝑅∼𝐵

Jurisdiction Rule (JR)

𝐴 | ≡𝑅



𝐵, 𝐴 | ≡𝑅| ≡𝐵

𝐴 | ≡ 𝐵

Belief Rule (BR)

𝐴 | ≡ (𝐵, 𝑅)

𝐴| ≡ 𝐵

Nonce Verification

Rule (NVR)

𝐴| ≡ #(𝑅), 𝐴 | ≡𝑅∼𝐵

𝐴 | ≡ 𝐵

Freshness Rule (FR)

𝐴 | ≡ #(𝑅)

𝐴| ≡ #(𝑅, 𝐵)

Table 5: Security goals.

No. Goals

Goal 1

|≡ 6L

|≡(6L









)

Goal 2

|≡6L









Goal 3

|≡ 6L

|≡ (6L







)

Goal 4







Idealized Forms: Messages Msg

, Msg

, and

Msg

sent by SLAE6 are transmitted on a public

channel. Given their idealized form, these messages

allow us to omit messages that do not provide the

properties of BAN logic. Table 6 presents an

idealized exchange of messages provided by SLAE6.

Table 6: Idealized message exchanges.

No.

6LN → 6LS: (T1, {O

𝑅𝑁1}) ID

6LN

)

6LS → 6LN: (T1, B1, {O

SP1

, RN2, (6LS







6LN)}

6LN

)

Assumptions: At the end of registration, each

principal is supposed to have an SK. After completing

the registration process, the pseudo identities appear

to be authentic and are random numbers. The

entitlement components are also believed to be

controlled by a legal principle, and SLAE6’s BAN

logic considers these assumptions in Table 7.

SENSORNETS 2023 - 12th International Conference on Sensor Networks

Table 7: Preliminary state assumptions.

No. Goals

A1 6L

|≡ #(T1), #(T3)

A2 6L

≡ #

(

)

, #

(

)

A3 6L

≡ ID

6LN

A4 6L

≡ O

A5 6L

|≡ ID

6LN

A6 6L

|≡ O

|≡ 6LS







⎯



|≡ 6LS







⎯



≡ #

(

)

A10 6L

≡ #

(

)

A11

|≡ 6L

⇒ (6L







⎯



)

A12

|≡ 6L

⇒ (6L







)

A13

|≡ 6L

⇒ (6L









)

A14

|≡ 6LS









A15

|≡ 6LS









BAN Logic Proof: To analyze SLAE6’s BAN logic,

the following steps are taken.

Step 1: From A7, A8, and F1 and by applying MMR,

the following can be obtained:

𝑆1=

6𝐿𝑆 | ≡



6𝐿𝑆







⎯



6𝐿𝑁



,6𝐿𝑆 ⊲

(

𝑇



{

𝑂



, 𝑅𝑁1

}

)

𝐼𝐷



6𝐿𝑆

≡ 6𝐿𝑁 ∼

(

𝑇



{

𝑂



, 𝑅𝑁1

}

)

𝐼𝐷



)

Step 2: S2 can be elicited by applying FR while using

A2 and F1.

𝑆2=

6𝐿𝑆 | ≡ #(𝑇



)

6𝐿𝑆| ≡ #(𝑇



{

𝑂



, 𝑅𝑁1

}

)

Step 3: S3 can be elicited by applying NVR by using

S2 and S1.

S3 =

6𝐿𝑆| ≡ #(𝑇



{

𝑂



, 𝑅𝑁1

}

), 6𝐿𝑆

≡ 6𝐿𝑁

, 𝐴∗

6𝐿𝑆

≡ 6𝐿𝑁

≡ (𝑇



{

𝑂



, 𝑅𝑁1

}

)

A* =∼ (𝑇



{

𝑂



, 𝑅𝑁1

}

)

Step 4: S4 can elicit Goal 1 by applying BR.

𝑆4=

6𝐿𝑆 | ≡ 6𝐿𝑁| ≡ (𝑇



{

𝑂



, 𝑅𝑁1

}

)

6𝐿𝑆

≡ 6𝐿𝑁

≡ (6𝐿𝑁









6𝐿𝑆))

Step 5: Goal 2 can be achieved using A13, S4, and

JR.

𝑆5=

6𝐿𝑆

≡ 6𝐿𝑁





6𝐿𝑁









6𝐿𝑆



6𝐿𝑆 | ∗𝐴

6𝐿𝑆 | ≡ (6𝐿𝑁









6𝐿𝑆)

*A= ≡ 6𝐿𝑁| ≡ (6𝐿𝑁









6𝐿𝑆)

Step 6: S6 can be elicited by applying MMR by using

F2 and A11.

𝑆6=

6𝐿𝑆 | ≡ (6𝐿𝑁







⎯



6𝐿𝑆), 𝐴∗

6𝐿𝑆 | ≡ 6𝐿𝑁| ∼ (𝑇3, 𝐵1, {𝑂



, 𝑅𝑁1, (6𝐿𝑁







⎯



6𝐿𝑆})𝐼𝐷



)

𝐴∗=6𝐿𝑆 ⊲ ((𝑇3, 𝐵1, {𝑂



, 𝑅𝑁1, (6𝐿𝑁







⎯



6𝐿𝑆})𝐼𝐷



)

Step 7: S7 can be elicited by applying FR by using A1

and F2.

𝑆7=

6𝐿𝑆 | ≡ #(𝑇3)

6𝐿𝑆| ≡ #(𝐵1, {𝑂



, 𝑅𝑁1(6𝐿𝑁



↔ 6𝐿𝑆))

Step 8: S8 can be elicited by applying NVR by using

S6 and S7.

𝑆8=

6𝐿𝑁 | ≡ #(𝑇3, 𝐵1, {𝑂



, 𝑅𝑁1, (6𝐿𝑁



↔ 6𝐿𝑆), 𝐴∗

6𝐿𝑁 | ≡ 6𝐿𝑁| ∼ (𝑇3, 𝐵1, {𝑂



, 𝑅𝑁1, (6𝐿𝑁







⎯



6𝐿𝑆})

𝐴∗=(6𝐿𝑁







⎯



6𝐿𝑆)}), 6𝐿𝑁| ≡ 6𝐿𝑆|

∼ (𝑇3, 𝐵1, {𝑂



, 𝑅𝑁1, (6𝐿







⎯



6𝐿𝑆)})

Step 9: S9 obtains Goal 3 by employing BR by using

S8.

𝑆9=

6𝐿𝑁 | ≡ 6𝐿𝑆(𝑇3, 𝐵1, {𝑂



, 𝑅𝑁1, (6𝐿𝑁



↔ 6𝐿𝑆)}

6𝐿𝑁

≡ 6𝐿𝑆

≡ (6𝐿𝑁



↔ 6𝐿𝑆)

Step 10: S10 can elicit Goal 4 by applying JR by using

A12.

𝑆10 =

6𝐿𝑁 | ≡

6𝐿𝑁





6𝐿𝑁



↔ 6𝐿𝑆



, 𝐴∗

6𝐿𝑁| ≡ (6𝐿𝑁



↔ 6𝐿𝑆))

A*=6𝐿𝑁

≡ 6𝐿𝑆

≡ (𝑇3, 𝐵1, {𝑂



, 𝑅𝑁1, (6𝐿𝑁



↔ 6𝐿𝑆)}

As a result of Goals 1–4, we demonstrate that

SLAE6 provides secure MA for the 6LN and

6LS. The MA properties of SLAE6 are assessed

using BAN logic.

5.2 Performance Evaluation

The performance of an authentication protocol is

evaluated by measuring its security features,

computation cost, execution time and bandwidth

requirements. SLAE6 is evaluated using the two

metrics. We compare SLAE6 with the schemes

in (Hussen et al., 2013), (Qiu & Ma, 2016), and

(Tanveer et al., 2020).

5.2.1 Security Feature

The results in Table 8 indicate that SLAE6 is the only

system that is capable of providing all security

features. With the SLAE6 scheme, for example,

sensor nodes can be protected from traceability

attacks, which other authentication schemes do not

SLAE6: Secure and Lightweight Authenticated Encryption Scheme for 6LoWPAN Networks

support. In addition, SLAE6 provides security under

the CK model.

Table 8: Comparison of security features.

YES: security feature is supported/No: security feature is

not supported.

5.2.2 Computational Complexity

This section compares the computation costs of

SLAE6 with those of related authentication schemes,

namely, (Hussen et al., 2013), (Qiu & Ma, 2016), and

(Tanveer et al., 2020). This feature is calculated for

all authentication schemes on the basis of the

operations performed within each authentication

entity. Cryptographic functions are executed by

authentication nodes on the basis of the number of

cryptographic functions that they have executed. This

feature is used in all authentication schemes to

facilitate computations. Denote the time cost T

ACE

, T

AES

, T

ASCON

, T

EXP

, T

ECC

, and T

ECC/SV

to represent

execution time for ACE, SHA-256, AES, ASCON,

modular exponentiation, ECC key generation, and

ECC signature generation/verification, respectively.

Table 7 provides the computation cost in each

authentication entity and the total computation cost of

each authentication scheme. In accordance with

Table 9, SLAE6 consumes less computational

overhead than other existing schemes (Hussen et al.,

2013), (Qiu & Ma, 2016), (Tanveer et al., 2020). The

SLAE6 scheme argues that it is lightweight because

it uses only symmetric encryption/decryption, XOR,

and one-way HFs, which exhibit less computational

complexity. Compared with existing authentication

methods (Hussen et al., 2013), (Qiu & Ma, 2016),

which use asymmetric encryption/decryption

functions that are highly expensive,

the proposed SLAE6 scheme takes nine HFs

overhead during AKA phases, while the scheme of

(Tanveer et al., 2020) takes 13 HFs.

5.2.3 Execution Time

Table 9 compares the execution times of the proposed

protocols. We calculate execution time on the basis of

the assumptions presented by Tanveer et al. (Tanveer

et al., 2022) (Tanveer et al., 2020). T

ACE

≈ 0.0411 ms,

≈ 0.0311 ms, T

AES

≈ 0.125 ms, T

ASCON

≈ 0.065 ms,

EXP

≈ 19.16 ms, T

ECC

≈ 5.50, and T

≈ 5.20 ms.

Consequently, during the AKE phase, 4T

ACE

+ 9T

≈

0.5159 ms, the total cryptographic complexity is

executed in SLAE6. Accordingly, for the protocols in

(Hussen et al., 2013), (Qiu & Ma, 2016), and

(Tanveer et al., 2020), the computation overheads are

58.6044, 17.2494, and 0.6643 ms, respectively, as

illustrated in Table 9 and Figure 3. Therefore, the

protocols in (Hussen et al., 2013) have a longer

execution time of 58.6044 ms, followed by the

protocols in (Qiu & Ma, 2016) and (Tanveer et al.,

2020). Consequently, SLAE6 requires less execution

time with 0.5159 ms.

Table 9: Comparison of the computational complexity and

execution time.

Schemes

Computational Cost Total Time

(Hussen et al.,

2013)

+8T

AES

+4T

SHA_256

58.6044 ms

(Qiu & Ma,

2016)

AES

+4T

SHA_256

ppk

+ T

17.2494 ms

(Tanveer et al.,

2020)

ASCON

+13T

SHA_256

0.6643 ms

SLAE6 4T

ACE

+ 9T

0.5159 ms

Figure 3: Comparison of execution time.

5.2.4 Bandwidth Requirements

This section estimates the bandwidth requirement for

the AKE phase on the basis of the sizes of Msg

and

Msg

. It takes 256 bits for HF (SHA-256); 64 bits for

a random number, identity, temerity identity, and

secret parameters; 32 bits for timestamp; 160 bits for

ECC; and 128 bits for ACE encryption and

decryption. These messages are sized on the basis of

Features

(Hussen et

al., 2013)

(Qiu & Ma,

2016)

(Tanveer et

al., 2020)

SLAE6

Replay attac

YES YES YES YES

ESL NO YES YES YES

untraceability NO NO NO YES

Anon

mit

NO YES YES YES

F/B S NO YES YES YES

ersonation attac

YES YES YES YES

DoS attac

YES YES YES YES

MITM attac

YES YES YES YES

MA YES YES YES YES

CK model NO NO NO YES

SENSORNETS 2023 - 12th International Conference on Sensor Networks

Table 8, which shows the sizes of the output from

various cryptographic operations. On the basis of

these messages, we can derive their sizes.

Sensor

nodes must minimize their transmitted message size

to reduce their energy consumption. Notably, the

6LBR, 6LS, and 6LR are energy-efficient devices.

Therefore, power consumption outside 6LoWPAN is

not considered in the SLAE6 model, because it

focuses only on power consumption of wirelessly

connected constrained devices. Various bandwidth

requirements between the 6LN and 6LR are presented

in Table 10 and shown in Figure 4. This table shows

that the scheme in (Hussen et al., 2013) requires a

maximum bandwidth of 2864 bits. This scheme is

followed by the schemes in (Qiu & Ma, 2016) and

(Tanveer et al., 2020). By contrast, SLAE6 requires

only 850 bits of bandwidth.

Table 10: Bandwidth requirements.

Exchanged

messages

6LN 6LR 6LR 6LN Total

messages

(Hussen et al.,

2013

)

688 bits

2176 bits 2864 bits

(Qiu & Ma,

2016)

672 bits 784 bits 1456 bits

(Tanveer et al.,

2020)

496 bits 528 bits 1024 bits

SLAE6

425 bits 425 bits 850 bits

Figure 4: Comparison of bandwidth requirement.

6 CONCLUSIONS AND FUTURE

WORK

Conventional ECC, PKI, signature, and identity-

based AKE schemes generate high communication

and computation overheads that are inappropriate for

limited-resource 6LoWPAN devices. Therefore, we

proposed the SLAE6 device AKE scheme in the

current study. This scheme, which is based on the

ACE cryptographic mechanism via LWC, is efficient

and secure. MA is performed in SLAE6, and a secure

connection is established between SNs and the server

for encrypted communication. This process ensured

secure communication and prevented an attacker

from obtaining transmitted information. Hence,

energy consumption and cost minimization are

achieved while ensuring information security. BAN

logic analysis proves that SLAE6 is logically

complete. In addition, SLAE6 is proven robust

against known attacks by using informal security

analysis based on the DY and CK models. We present

a verifiable security and privacy provisioning

protocol designed to address some of these issues in

the current study. SLAE6 exhibits less computation

complexity and effectively reduces execution time by

22% and requirement bandwidths by 16% compared

with (Tanveer et al., 2020). Consequently, this

protocol has been demonstrated to be efficient in

terms of bandwidth usage and execution time. It is

computationally inexpensive and suited for SNs with

limited resources in IoT or WSN. In the future, this

protocol needs to be formally verified. Then, it will

be applied to a test bed experiment.

ACKNOWLEDGMENT

This research was supported by the research grant of

the Universiti Kebangsaan Malaysia under FRGS

grant: FRGS/1/2022/ICT11/UKM/02/2.

REFERENCES

Aagaard, M., Altawy, R., Gong, G., Mandal, K., Rohit, R.,

& Lab, S. (2019). ACE: An Authenticated Encryption

and Hash Algorithm Submission to the NIST LWC

Competition. https://uwaterloo.ca/communications-

security-lab/lwc/ace

Ahmad, R., Sundarajan, E. A., & Abu-Ain, T. (2021).

Analysis the Effect of Dynamic Clustering and

Lightweight Symmetric Encryption Approaches on

Network Lifetime in WSNs. Iceei2021, 1–28.

Ahmad, R., Wazirali, R., Abu-Ain, T., & Almohamad, T.

A. (2022). Adaptive Trust-Based Framework for

Securing and Reducing Cost in Low-Cost 6LoWPAN

Wireless Sensor Networks. Applied Sciences, 12(17),

8605. https://doi.org/10.3390/app12178605

Ahmad, R., Wazirali, R., Bsoul, Q., Abu-Ain, T., & Abu-

Ain, W. (2021). Feature-selection and mutual-

clustering approaches to improve dos detection and

maintain wsns’ lifetime. Sensors, 21(14).

https://doi.org/10.3390/s21144821

Alshrif, F. F., Sundararajan, E. A., & Ahmad, R. (2021).

New Framework for Authentication and key

SLAE6: Secure and Lightweight Authenticated Encryption Scheme for 6LoWPAN Networks

Establishment to Secure 6LoWPAN Networks.

Iceei2021, 1–6.

Amanlou, S., Hasan, M. K., & Bakar, K. A. A. (2021).

Lightweight and secure authentication scheme for IoT

network based on publish–subscribe fog computing

model. Computer Networks, 199. https://doi.org/

10.1016/j.comnet.2021.108465

Bagwari, A., Bagwari, J., Anand, T., Chaurasia, B. K.,

Gangwar, R. P. S., & Hasan, M. K. (2022). The Role of

IoT in Smart Technologies. In 5G and Beyond (pp. 57–

66). Chapman and Hall/CRC. https://doi.org/10.

1201/9781003045809-6

Burrows, M., Abadi, M., & Needham, R. (1990). Logic of

authentication. ACM Transactions on Computer

Systems, 8(1), 18–36. https://doi.org/10.1145/77

648.77649

Chom Thungon, L., Ahmed, N., Chandra Sahana, S., &

Hussain, M. I. (2020). A lightweight authentication and

key exchange mechanism for IPv6 over low-power

wireless personal area networks-based Internet of

things. Transactions on Emerging Telecommunications

Technologies, 1–18. https://doi.org/10.1002/ett.4033

Dolev, D., & Yao, A. C. (1983). On the Security of Public

Key Protocols. IEEE Transactions on Information

Theory, 29(2), 198–208. https://doi.org/10.1109/

TIT.1983.1056650

Fragkos, G., Minwalla, C., Tsiropoulou, E. E., &

Plusquellic, J. (2022). Enhancing Privacy in PUF-Cash

through Multiple Trusted Third Parties and

Reinforcement Learning. ACM Journal on Emerging

Technologies in Computing Systems, 18(1).

https://doi.org/10.1145/3441139

Gao, L., Zhang, L., Feng, L., & Ma, M. (2020). An Efficient

Secure Authentication and Key Establishment Scheme

for M2M Communication in 6LoWPAN in Unattended

Scenarios. Wireless Personal Communications, 115(2),

1603–1621.https://doi.org/10.1007/s11277-020-07645-z

Hasan, M. K., Shafiq, M., Islam, S., Pandey, B., Baker El-

Ebiary, Y. A., Nafi, N. S., Ciro Rodriguez, R., &

Vargas, D. E. (2021). Lightweight Cryptographic

Algorithms for Guessing Attack Protection in Complex

Internet of Things Applications. Complexity, 2021.

https://doi.org/10.1155/2021/5540296

Hennebert, C., & Santos, J. Dos. (2014). Security protocols

and privacy issues into 6LoWPAN stack: A synthesis.

IEEE Internet of Things Journal, 1(5), 384–398.

https://doi.org/10.1109/JIOT.2014.2359538

Hui, J., & Pascal, T. (2011, August 20). Compression

Format for IPv6 Datagrams over IEEE 802.15.4-Based

Networks. 2011. https://www.hjp.at/doc/rfc/rfc6282.

html

Hussen, H. R., Tizazu, G. A., Ting, M., Lee, T., Choi, Y.,

& Kim, K.-H. (2013). SAKES: Secure authentication

and key establishment scheme for M2M

communication in the IP-based wireless sensor network

(6L0WPAN). In 2013 Fifth International Conference

on Ubiquitous and Future Networks (ICUFN). IEEE.,

246–251. https://doi.org/https://doi.org/10.1109/ICUF

N.2013.6614820

Monika, M., Smita, A., Rakhi, A., Sanjivani, D., Sachi, N.

M., & Suneeta, S. (2022). A Proposed Framework to

Achieve CIA in IoT Networks. International

Conference on Artificial Intelligence and Sustainable

Engineering, 19–30.

Qiu, Y., & Ma, M. (2016). A Mutual Authentication and

Key Establishment Scheme for M2M Communication

in 6LoWPAN Networks. IEEE Transactions on

Industrial Informatics, 12(6), 2074–2085. https://

doi.org/10.1109/TII.2016.2604681

Sarr, A. P., Elbaz-Vincent, P., & Bajard, J.-C. (2010). A

New Security Model for Authenticated Key

Agreement. International Conference on Security and

Cryptography for Networks, 219–234. https://doi

.org/10.1007/978-3-642-15317-4_15

Tanaka, Y., Minet, P., & Watteyne, T. (2019). 6LoWPAN

Fragment Forwarding. IEEE Communications

Standards Magazine, 3(1), 35–39. https://doi.

org/10.1109/MCOMSTD.2019.1800029

Tanveer, M., Abbas, G., Abbas, Z. H., Bilal, M.,

Mukherjee, A., & Kwak, K. S. (2021). LAKE-6SH:

Lightweight User Authenticated Key Exchange for

6LoWPAN-based Smart Homes. IEEE Internet of

Things Journal, 14(8), 1–14. https://doi.org/10.

1109/jiot.2021.3085595

Tanveer, M., Abbas, G., Abbas, Z. H., Waqas, M.,

Muhammad, F., & Kim, S. (2020). S6AE: Securing

6lowpan using authenticated encryption scheme.

Sensors (Switzerland), 20(9), 1–23. https://doi.org/

10.3390/s20092707

Tanveer, M., Khan, A. U., Nguyen, T., Ahmad, M., &

Abdei-Latif, A. (2022). Towards A Secure and

Computational Framework for Internet of Drones

Enabled Aerial Computing. IEEE Transactions on

Network Science and Engineering. https://doi.org/

10.1109/TNSE.2022.3151843

Turan, M., McKay, K., Chang, D., Calik, C., Bassham, L.,

Kang, J., & Kelsey, J. (2021). Status Report on the

Second Round of the NIST Lightweight Cryptography

Standardization Process. https://doi.org/10.6028

/NIST.IR.8369

Wazirali, R., & Ahmad, R. (2022). Machine learning

approaches to detect DoS and their effect on WSNs

lifetime. Computers, Materials and Continua, 70(3),

4921–4946. https://doi.org/10.32604/cmc.2022.020044

Wazirali, R., Ahmad, R., Al-Amayreh, A., Al-Madi, M., &

Khalifeh, A. (2021). Secure watermarking schemes and

their approaches in the iot technology: An overview.

Electronics (Switzerland), 10(14). https://doi.org/1

0.3390/electronics10141744

SENSORNETS 2023 - 12th International Conference on Sensor Networks
