Absolute-ROMP: Absolute Multi-Person 3D Mesh Prediction from a

Single Image

Bilal Abdulrahman

1 a

and Zhigang Zhu

2 b

The CUNY Graduate Center, New York, NY 10016, U.S.A.

The CUNY City College and Graduate Center, New York, NY 10031, U.S.A.

Keywords:

Machine Learning, Computer Vision, 3D reconstruction, Camera Calibration, Mesh Regression, Pose

Prediction, Human Mesh Regression.

Abstract:

Recovering multi-person 3D poses and shapes with absolute scales from a single RGB image is a challenging

task due to the inherent depth and scale ambiguity from a single view. Current works on 3D pose and shape

estimation tend to mainly focus on the estimation of the 3D joint locations relative to the root joint , usually

deﬁned as the one closest to the shape centroid, in case of humans deﬁned as the pelvis joint. In this paper, we

build upon an existing multi-person 3D mesh predictor network, ROMP, to create Absolute-ROMP. By adding

absolute root joint localization in the camera coordinate frame, we are able to estimate multi-person 3D poses

and shapes with absolute scales from a single RGB image. Such a single-shot approach allows the system to

better learn and reason about the inter-person depth relationship, thus improving multi-person 3D estimation.

In addition to this end to end network, we also train a CNN and transformer hybrid network, called TransFocal,

to predict the focal length of the image’s camera. Absolute-ROMP estimates the 3D mesh coordinates of all

persons in the image and their root joint locations normalized by the focal point. We then use TransFocal

to obtain focal length and get absolute depth information of all joints in the camera coordinate frame. We

evaluate Absolute-ROMP on the root joint localization and root-relative 3D pose estimation tasks on publicly

available multi-person 3D pose datasets. We evaluate TransFocal on dataset created from the Pano360 dataset

and both are applicable to in-the-wild images and videos, due to real time performance.

1 INTRODUCTION

3D Human pose and shape estimation is one of the

most active ﬁelds of research within the current land-

scape of computer vision and AI thanks to its many

applications in robotics (Du and Zhang, 2014; Zim-

mermann et al., 2018), activity recognition (Lo Presti

and La Cascia, 2016; Carbonera Luvizon et al., 2017),

graphics (Boulic et al., 1997; Aitpayev and Gaber,

2020) and human-object interaction detection (Fang

et al., 2018; Qi et al., 2018; Li et al., 2020b; Li et al.,

2020c). Current works on 3D pose and shape estima-

tion tend to mainly focus on the estimation of the 3D

joint locations relative to the root joint, usually de-

ﬁned as the one closest to the shape centroid.In case

of humans, deﬁned as the pelvis joint. Due to the in-

herent depth and scale ambiguity of a single view, it

is quite a challenge to accurately recover multi-person

3D pose and shape with absolute scales from a single

https://orcid.org/0000-0002-1164-1976

https://orcid.org/0000-0002-9990-1137

RGB image. Addressing this ambiguity requires as-

sessing cues in the image as a whole, such as scene

layouts, body dimensions, and inter-person relation-

ships. This paper aims to address the problem of es-

timating absolute 3D pose and shape of multiple peo-

ple simultaneously from a single RGB image. Com-

pared to the 3D pose and shape estimation problem

that focuses on recovering the root-relative pose, the

task addressed here additionally needs to recover the

3D translation of each person in the camera coordi-

nate system (or sometimes called camera coordinate

frame).

Estimating the absolute 3D location of each per-

son in an image is essential for understanding human-

to-human interactions (Figure 3). Since multi-person

activities take place in cluttered scenes, inherent depth

ambiguity and occlusions make it challenging to es-

timate the absolute positions of multiple individuals.

We argue that body dimensions alone paint a vague

picture of absolute depth. Robust estimation of global

positions requires information cues over the entire im-

age, such as geometric cues, human body sizes in

Abdulrahman, B. and Zhu, Z.

Absolute-ROMP: Absolute Multi-Person 3D Mesh Prediction from a Single Image.

DOI: 10.5220/0011629500003417

In Proceedings of the 18th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2023) - Volume 5: VISAPP, pages

69-79

ISBN: 978-989-758-634-7; ISSN: 2184-4321

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

the image, any occlusions which might affect the per-

ceived sizes, layout of the entire scene etc.

Most existing methods for absolute multi-person

3D pose estimation extend the single-person approach

with an added step to recover the absolute position

of each detected person individually. They either use

another neural network to regress the 3D translation

of the person from the cropped image (Moon et al.,

2019) or compute it based on the prior knowledge

about the body size (Dabral et al., 2019), which ig-

nores the global context of the whole image. While

others employ complicated architecture with exten-

sive steps, drastically slowing down inference (Lin

and Lee, 2020).

In this paper, we build upon ROMP (Sun et al.,

2020), a light weight, accurate end to end multi-

person 3D mesh prediction network, by adding in

absolute root joint depth estimation and localization

head while maintaining its end to end and light weight

nature. We call the revised network Absolute-ROMP.

We adopt the same end to end pipeline for the task

of multi-person absolute 3D mesh estimation. By

leveraging depth cues from the entire scene and prior

knowledge of the typical size of the human pose and

body joints, we can estimate the depth of a person in

a monocular image with considerably high accuracy.

The target depths are discretized into a preset number

of bins, in order to limit the range of predictions and

thus improve the prediction performance. The range

of these bins is chosen after taking prediction error

mitigation and reasonable distance estimation in con-

sideration. We employ a soft-argmax operation on the

bins for improved accuracy as compared to exact bin

locations and for faster convergence during training

without losing precision to direct numerical regres-

sion.

We also train a CNN and a vision transformer

hybrid network to predict the vertical ﬁeld of view of

the image, which is used to estimate the focal length.

With the predicted focal length we can estimate

absolute distance in camera coordinates without the

need for camera intrinsic parameters. Our model uses

embeddings from ResNet (He et al., 2015), which

are then converted to tokens to be fed into the vision

transformer (Dosovitskiy et al., 2020a). The added

attention from the transformer gives our network an

edge over previous work (Kocabas et al., 2021c).

Our contributions in this work are:

• We propose an absolute depth estimation head for

the ROMP network using a combination loss.

• We design and train TransFocal, a network to pre-

dict focal length of the image thus negating the

requirement of intrinsic parameters.

• Quantitative and qualitative results show that our

approach outperforms or has competitive perfor-

mance to the state-of-the-art on multiple bench-

mark datasets under various evaluation metrics.

This paper is organizes as the follows. Section 2

discusses related work. Section 3 describes the pro-

posed Absolute-ROMP, including the absolute depth

map head and the focal length estimation network:

TransFocal. Section 4 provides some key imple-

mentation details in network architectures and train-

ing/testing settings. Section 5 presents experimental

results and ablation studies. Section 6 provides a few

concluding remarks.

2 RELATED WORK

2.1 Single-Person 3D Mesh Regression

Parametric human body models allow complex 3D

human mesh vertices to be encoded into low dimen-

sional parameter vectors. These have been widely

adopted since they allow regression of 3D meshes

from images, such as the Skinned Multi-Person Lin-

ear Model (SMPL) (Loper et al., 2015). Various weak

supervision techniques have lead to reasonable accu-

racy for single-person 3D mesh regression with vari-

ous techniques, such as those using semantic segmen-

tation (Xu et al., 2019), geometric prior (Kanazawa

et al., 2017), motion analysis (Kanazawa et al., 2018;

Kocabas et al., 2019) and 2D pose (Choi et al., 2020).

The work in (Kocabas et al., 2021a) uses a part-guided

attention mechanism to overcome occlusions by ex-

ploiting information about the visibility of individual

body parts while leveraging information from neigh-

boring body-parts to predict occluded parts. Whereas

(Kocabas et al., 2021c) uses predicted camera calibra-

tion parameters to aid in the regression of the body

mesh parameters.

2.2 Multi-Person 3D Pose Estimation

For multi-person 3D pose estimation, (Mehta et al.,

2017) proposes occlusion-robust pose-maps and ex-

ploits the body part association to avoid bounding box

prediction. In (Benzine et al., 2021), an anchor-based

one-stage model is proposed, which relies on a huge

number of pre-deﬁned anchor predictions and the pos-

itive anchor selection. To handle person-person oc-

clusion, (Zhen et al., 2020) proposes a system that

ﬁrst regresses a set of 2.5D representations of body

parts and then reconstructs the 3D absolute poses

based on these 2.5D representations with a depth-

aware part association algorithm. Both (Rogez et al.,

VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications

2019) and (Moon et al., 2019) employ a top-down de-

sign, which estimates the target via regression from

anchor-based feature proposals.

2.3 Multi-Person 3D Mesh Estimation

(Jiang et al., 2020) proposes a network for Coherent

Reconstruction of Multiple Humans (CRMH). Built

on Faster-RCNN (Ren et al., 2015), they use the RoI-

aligned feature of each person to predict the SMPL

parameters. (Zanﬁr et al., 2018b) estimates the 3D

mesh of each person from its intermediate 3D pose es-

timation. (Zanﬁr et al., 2018a) further employs multi-

ple scene constraints to optimize the multi-person 3D

mesh results. All these methods follow a multi-stage

design. The complex multi-step process requires a

repeated feature extraction, which is computationally

expensive. The ROMP (Sun et al., 2020), which our

proposed model is based on, learns an explicit pixel-

level representation with a holistic view, which im-

proves accuracy in multi-person in-the-wild scenes.

2.4 Monocular Absolute Depth

Estimation

Depth estimation from a single view suffers from

inherent ambiguity. Nevertheless, several methods

make remarkable advances in recent years (Li and

Snavely, 2018; Lee and Kim, 2019). (Li et al.,

2019) employs the use of mannequin challenge to ob-

tain a dataset for depth estimation by employing the

frozen poses and moving camera of the mannequin

challenge. They generate training data using multi-

view stereo reconstruction and adopt a data-driven

approach to recover a dense depth map. However,

such a depth map lacks scale consistency and can-

not reﬂect the real depth. (Zhen et al., 2020) pro-

poses a system that ﬁrst regresses a set of 2.5D rep-

resentations of body parts and then reconstructs the

3D absolute poses based on these 2.5D representa-

tions with a depth-aware part association algorithm.

(Lin and Lee, 2020) estimates the 2D human pose

with heatmaps of the joints. Then these heatmaps

are used as attention masks for pooling features from

image regions corresponding to the target person. A

skeleton-based Graph Neural Network (GNN) is used

to predict the depth of each joint. (Li et al., 2020a)

uses an integrated model to estimate human bounding

boxes, human depths, and root-relative 3D poses si-

multaneously, with a coarse-to-ﬁne architecture. All

these methods either employ multi-step prediction or

use large networks which slow down the inference.

Our method is able to estimate depth and regress 3D

mesh of multiple people in real time with high ac-

curacy while also regressing the shape parameters of

individuals.

2.5 Focal Length Estimation

Recent works such as (Hold-Geoffroy et al., 2017;

Kendall et al., 2015; Workman et al., 2016; Work-

man et al., 2015; Zhu et al., 2020) estimate camera

parameters from a single image. To estimate camera

rotations and ﬁelds of view, these methods train a neu-

ral network to leverage geometric cues in the image.

(Workman et al., 2015) uses an AlexNet backbone to

regress the horizontal ﬁeld of view. Except (Workman

et al., 2015), these methods discretize the continuous

space of rotation into bins, casting the problem as a

classiﬁcation task and applying cross entropy (Work-

man et al., 2016) or KL-divergence (Hold-Geoffroy

et al., 2017; Zhu et al., 2020) losses. (Kocabas et al.,

2021c) also uses a binning technique. It trains a neu-

ral network with a bespoke-biased loss on a new col-

lected dataset (Kocabas et al., 2021c) . However none

of these methods take advantage of the latest architec-

ture innovation in the vision space, i.e., transformer

networks (Dosovitskiy et al., 2020a). (Lee et al.,

2021) takes both an image and line segments as in-

put and regresses the camera parameters based on the

transformer encode-decoder architecture. The line

segments, extracted from the input image using the

LSD algorithm (Grompone von Gioi et al., 2010), are

also mapped to geometric tokens. However, the sub-

sequent transformer decoder aggregates both seman-

tic and geometric tokens along with the queries for the

camera parameters. In contrast, our model only em-

ploys vision transformer to encode the features from

a single image and a simple MLP layer is used for de-

coding, thus an integration of a vision transformer and

a CNN hybrid network with a combination of losses

during supervision.

3 METHODOLOGY

Absolute-ROMP is an extension of the ROMP net-

work (Sun et al., 2020), which regresses meshes

in a one-stage fashion for multiple 3D people (thus

termed ROMP). We will brieﬂy explain the working

of our Absolute-ROMP and, therefore by extension,

of ROMP before going into details about our addition.

Figure 1 shows overall system diagram. Absolute-

ROMP employs a multi-head design with a HRNeT-

32 backbone(Wang et al., 2019) and 4 head networks:

Body Center Map, Camera Map, SMPL Map and

Root Depth Map. Details of the backbone will be

described in Section 4. Given a RGB image as in-

Absolute-ROMP: Absolute Multi-Person 3D Mesh Prediction from a Single Image

Figure 1: Overview of how the system works. Absolute-ROMP predicts the mesh parameters and depth. The focal length is

predicted by TransFocal which are then used to get the complete absolute 3D coordinates.

put, it outputs a body center heatmap, camera param-

eters, SMPL parameters and an absolute depth map in

the camera coordinate frame. The resolution for each

map is 64×64 In the body center heatmap, Absolute-

ROMP predicts the probability of each position being

a human body center. Each body center is represented

as a Gaussian distribution in the body center heatmap.

At each position of the camera map, SMPL map and

absolute depth map, it predicts the absolute depth of

the root joint s

( deﬁned as the pelvis joint), cam-

era parameters (t

,s) ( a weak-perspective camera

model with translations in the x and y directions and a

scale), and SMPL parameters (22×6 pose parameters

and 10 shape parameters) of the person that takes the

position as the center respectively.

During inference, we sample the 3D body mesh

parameter results from the SMPL parameter map at

the 2D body center locations parsed from the body

center heatmap. We put the sampled parameters into

the SMPL model to generate the 3D body meshes. we

employ a weak-perspective camera model to project

3D body joints back to the 2D joints on the im-

age plane. The reason for not employing perspective

transform from the absolute coordinates for back pro-

jection is because the root depth map only predicts

the absolute depth parameter s

, not translation in the

x or y direction. This is done in order to preserve real

time inference, but it is not sufﬁcient for a perspec-

tive projection back to the image. Weak-perspective

camera model allows orthogonal back-projection of

the 3D pose to 2D on the image, facilitating training

the model with in-the-wild 2D pose datasets. This

helps with robustness and generalization and also al-

lows for more accurate position estimates than the

body center heatmap, as the body center heatmap has

limited resolution compared to the image. We will

provide more details on heatmap resolution in the next

section. We employ the estimated focal length from

TransFocal, the projected 2D pose and the predicted

absolute depth of the root joint to get the absolute x

and y coordinates of the root joint. Finally, using the

3D pose prediction from the SMPL mesh parameters,

we infer the absolute location of each of the remain-

ing joints.

3.1 Absolute Depth Map Head

From the original ROMP network (Sun et al., 2020),

we maintain an output map size n ×H ×W , where n

is the number of channels and H = W = 64, assum-

ing that each location of the absolute depth map is the

center of a human body, we estimate absolute depth

of its corresponding root joint. Instead of directly re-

gressing the numerical value of depth, we employ a

binning technique in the log depth space. The bin-

ning resolution is set to 120. The range is chosen after

taking prediction error mitigation and reasonable dis-

tance estimation based on all available data into con-

sideration. Since different focal lengths of the camera

affect the scales of a target person in the image, it is

unrealistic to estimate the absolute depth from images

taken by any arbitrary camera. 3D human datasets

with absolute depth information have minimal varia-

tion in focal lengths (most datasets use the same cam-

era for all images in each said dataset). This makes

it challenging for the model to learn this variable and

therefore can overﬁt on the focal lengths of the train-

ing datasets. The same person will have different

dimensions in the images with cameras with differ-

ent focal lengths. Therefore, the predicted depth is

normalized(divided) by the focal length. The focal

length is estimated by training another network Trans-

VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications

Focal, which we will detail in the next subsection.

We employ a soft-argmax operation on the bins

for improved accuracy as compared to exact bin lo-

cations. Exact bins can only give integer outputs and

therefore have limited precision. Whereas soft bins

can output any number between bin indices depend-

ing on what number between 0 and 1 is the output of

that bin. Therefore, there is minimal precision loss

if any. This allows the actual prediction to be a ra-

tio of the bins improving granularity and accuracy of

the model. The bin index for the log depth space is

computed as follows:

d) =

log

d −logS

logE −log S

(N −1) (1)

where b(

d) is the bin index of the normalized depth

N is the total number of bins and [S , E] is the range of

the bins. We can state this style of binning depth map

as a collection of 1D heatmaps.There are 64×64 pre-

dictions for each image. Therefore, we have a 64×64

collection of 1D heatmaps. The predicted bin values

B are converted back to normalized depth as follows:

d = exp[

∑

N−1

i=0

N −1

(logE −log S) + logS] (2)

Similar to (Lin and Lee, 2020), the losses added to

supervise depth learning are cross-entropy loss on the

estimated bins B and L1 loss on the bin index b as

follows:

bins

= −

N−1

∑

i=0

logB

pred

(3)

= |b

−b

pred

| (4)

To calculate L

bins

we have to generate ground truth

bins. First, we compute bin index using equation 1.

The procedure to generate the ﬁnal bins from the in-

dex is then laid out in the pseudo code of Algorithm

Algorithm 1: Generate Ground truth Bins.

1: N ← Number of Bins

2: b(

d) ← Bin index

3: Arange(x) ← list of integers from 0 to x

4: ABS(x) ← Absolute value of x

5: Clip(x,y, z) ←Clip each value of x between (y,z)

6: GTBins = 1 − Clip(ABS(Arange(N) −

d)), 0, 1)

The ﬁnal loss is as follows:

(5)

abs

= λ

pose

+ λ

shape

+ λ

j3d

+ λ

pa j3d

+ λ

p j2d

+ λ

prior

+ λ

bins

+ λ

where λ

represents the weight associated with the

loss, L

pose

is the L2 loss of the pose parameters in

the 3 × 3 rotation matrix format, L

shape

is the L2 loss

of the shape parameters, L

j3d

is the L2 loss of the

3D joints, L

pa j3d

is the L2 loss of the 3D joints after

Procrustes alignment, L

p j2d

is the L2 loss of the pro-

jected 2D joints, and L

prior

is the Mixture Gaussian

prior loss of the SMPL parameters adopted in (Loper

et al., 2015). please refer to (Sun et al., 2020) for fur-

ther detail on these losses.

3.2 Focal Length Estimation

To estimate the focal length, we train a CNN and

transformer hybrid network TransFocal. When it

comes to images, convolutional neural networks by

design have a stronger inductive bias compared to

transformer networks (Bai et al., 2021). This results

in them being able to learn to embeddings relatively

quickly from a smaller subset of data. However, when

trained on enough data, the vision transformer is able

to outperform similar state-of-the-art CNN models

(Dosovitskiy et al., 2020a). The transformer’s self at-

tention like architecture results in it having better gen-

eralization properties (Bai et al., 2021). It has been

shown that combining CNN embeddings with the vi-

sion transformer results in the hybrid system perform-

ing better than larger and deeper vision transformer,

with less than half the computational ﬁne-tuning cost

(Dosovitskiy et al., 2020b). Thus combining the ben-

eﬁts of both architectures we are able to train on lesser

data and get improved accuracy.

Since focal length in pixels has an unbounded

range and it changes whenever one resizes images, we

estimate vertical ﬁeld of view (vfov) v in radians and

convert it to focal length f

via:

0.5h

tan(0.5v)

(6)

where h is the image height in pixels. We follow (Zhu

et al., 2020) and (Kocabas et al., 2021c) to assume

zero camera yaw and the effective focal length values

in both directions are the same, i.e., f

= f

= f .

TransFocal takes the complete image as input to

predict vfov which is the same for all subjects in the

image of a video sequence. This means that inference

has to only be performed once in order to get absolute

coordinates for each frame of a video sequence. The

full image contains rich cues that can facilitate trans-

former self attention. Vanishing points and geometric

lines help the network semantically reason the vertical

ﬁeld of view. Similar to our absolute depth map head

and (Kocabas et al., 2021c), we discretize the space

of vfov v into B bins, converting the regression prob-

lem into a classiﬁcation problem. Also similar to our

Absolute-ROMP: Absolute Multi-Person 3D Mesh Prediction from a Single Image

depth map head, we aggregate the predicted probabil-

ity mass using a softargmax operation. For the losses,

we found in our testing that combining cross entropy

loss L

(with a smaller weight) with softargmax-

biased-L2 loss (Kocabas et al., 2021c) L

agmax

im-

proves model convergence. The ﬁnal loss L

f oc

= λ

agmax

+ λ

(7)

4 IMPLEMENTATION DETAILS

In the following, we will list the implementation de-

tails of both the absolute depth map head, Absolute-

ROMP, and the focal length estimation network,

TransFocal, in terms of network architecture, training

setting details, training datasets, and evaluation met-

rics.

4.1 Absolute-ROMP

Network Architecture. We employ HRNet-32 (Wang

et al., 2019) as the backbone for Absolute-ROMP.

We also maintain CoordConv (Liu et al., 2018) from

ROMP to enhance the spatial information. Therefore,

the backbone feature is the combination of a coordi-

nate index map and output feature embeddings from

HRNET-32. This feature set is then used as input to

the four heads for complete end to end prediction. The

architecture of absolute depth map is similar to the

other map heads. The only difference being the out-

put of the ﬁnal 1×1 convolutional layer, with a size of

120×64×64: As stated earlier the binning resolution

is set to 120 and the map size is 64×64. For details on

the architecture of the map heads please refer to (Sun

et al., 2020).

Setting Details. The input images are resized to 512

× 512, by keeping the same aspect ratio and padding

with zeros. The size of the backbone feature is H

= 128. The maximum number of detection is N

= 64. The learning rate used is 5e-5. The batch size

is set to 26. We adopt the Adam optimizer (Kingma

and Ba, 2014) for training, and train the model until

performance plateaus on validation set.

Training Datasets. The basic training datasets

we used in the experiments include three 3D pose

datasets: (Human3.6M (Ionescu et al., 2014), MPI-

INF-3DHP (Mehta et al., 2016), MuCo-3DHP (Mehta

et al., 2016)) and four in-the-wild 2D pose datasets

(MS COCO (Lin et al., 2014), MPII (Andriluka et al.,

2014), LSP (Johnson and Everingham, 2010), Crowd-

pose (Li et al., 2018)). We also use the pseudo 3D

annotations from (Kolotouros et al., 2019) and the

pseudo 3D labels of 2D pose datasets provided by

(Joo et al., 2020). For evaluation on a 3D pose dataset

3DPW (von Marcard et al., 2018), we use the train set

for ﬁne tuning.

Evaluation Benchmarks and Metrics. We evaluate

our model on the Human3.6M (Ionescu et al., 2014),

Mupots (Mehta et al., 2017) and 3DPW (von Mar-

card et al., 2018). To evaluate the 3D pose accuracy,

we employ mean per joint position error (MPJPE)

(Joo et al., 2015) and Procrustes-aligned MPJPE (PM-

PJPE). For root depth estimation we employ MRPE

(Moon et al., 2019) and PCK

abs

(Moon et al., 2019).

MPJPE is the average Euclidean distance between

the location of real-life joints on human bodies and

the location of predicted joints on 3D pose after trans-

lating the root joint (‘pelvis’) of estimated bodies

to the groundtruth root. Procrustes-aligned MPJPE

(PMPJPE) uses procrustes alignment (Luo and Han-

cock, 1999) (PA) to solve for translation, scale and

rotation between the estimated bodies and the ground

truth and thus mostly focuses on the pose error. Mean

root position error(MRPE) is the mean of the eu-

clidean distance between the estimated coordinates of

the predicted absolute root and ground truth absolute

root. The 3D percentage of correct absolute keypoints

(3DPCK

abs

) treats a joint’s absolute prediction as cor-

rect if it lies within a 15cm from the ground truth joint

location.

4.2 TransFocal

Network Architecture. The architecture is shown in

Figure 2. Similar to (Yang et al., 2021), we use

ResNet (He et al., 2015) as the CNN backbone. Then

learnable patch embeddings are applied to patches ex-

tracted from the ResNet output.Each patch embed-

ding’s kernel size is equal to the patch size, which

means that the input sequence is obtained by simply

ﬂattening the spatial dimensions of the ResNet fea-

tures and projecting to the Transformer dimension.

Since the image is not converted into patches directly,

the original physical meaning of positional embed-

dings is missing. Therefore they are not used when

mapping the patches into a latent embedding space l

using a linear projection.

We also show the overview of the transformer en-

coder architecture in Figure 2, to help with the expla-

nation stated below. The input of the ﬁrst Transformer

layer z

is calculated as follow:

= l

E; l

E....; l

E (8)

where z

is mapped into a latent n-dimensional em-

bedding space using a trainable linear projection layer

and E is the patch embedding projection. These

patches are then fed into the vision transformer

VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications

Figure 2: TransFocal Architecture. The image is input into a ResNet backbone to create embeddings which are then projected

into latent embedding space and used as input for the vision transformer. The output from the transformer’s many layers is

then decoded using a fully connected layer.

speciﬁcally the VIT-B16 (Dosovitskiy et al., 2020a)

variant. There are L Transformer layers which consist

of multi-headed self-attention (MSA) and multi-layer

perceptron (MLP) blocks. At each transformer layer

ℓ, the input of the self-attention block is a triplet of Q

(query), K (key), and V (value), which are computed

from the output of the previous layer by matrix mul-

tiplication with learnable parameters of weight ma-

trices. The self-attention in the attention head AH is

calculated as:

AH = so ftmax(

Q ×K

√

)V (9)

where d is the dimension of self-attention block.

MSA means the attention head will be calculated

m times by independent weight matrices. The ﬁnal

MSA(z

ℓ−1

) is deﬁned as:

MSA(z

ℓ−1

) = z

ℓ−1

+ concat(AH

;AH

;· · · ; AH

) ×W

(10)

The output of MSA is then transformed by an MLP

block with residual skip connection as the layer out-

put as:

= MLP(Norm(MSA(z

ℓ−1

))) + MSA(z

ℓ−1

) (11)

where Norm means the layer normalization operator.

Finally we use a fully connected layer to decode the

output of the vision transformer.

Setting Details. The TransFocal model is trained with

images of varied resolutions. The learning rate used is

1e-4. The weight decay is set to 1e-2. The batch size

is set to 4. We adopt the Adam optimizer (Kingma

and Ba, 2014) for training. We train the model until

performance plateaus on validation set.

Training and Evaluation Datasets. A dataset is

created using the Pano360 dataset (Kocabas et al.,

2021c). Pano360 consists of real panoramas taken

from ﬂickr (Flickr, 2022) and synthetic panoramas.

Due to a portion of ﬂickr images being inaccessible,

we were unable to recreate the complete dataset. The

dataset is split for training and evaluation purposes.

The code for creating the dataset is available at (Ko-

cabas et al., 2021b). Note that as the image generation

parameters are randomized, it is difﬁcult to recreate

exact the same dataset.

5 EXPERIMENTS AND RESULTS

Here we report some performance comparison on

multiple datasets and a ablation study in using the

Absolute-ROMP.

5.1 Performance Comparison

The root joint localization results on Human3.6M

dataset are shown in Table 1. The baselines reported

in the ﬁrst 3 rows follow a two-stage approach (Moon

et al., 2019), where 2D pose and 3D pose are es-

timated separately, and an optimization process is

adopted to obtain the global root joint location that

minimizes the re-projection error. The baseline “w/o

limb joints” refers to optimization using only head

Table 1: MRPE

results comparison with state-of-the-art on

the Human3.6M dataset.

Methods MRPE

Baseline 261.9

Baseline w/o limb joints 220.2

Baseline with RANSAC 207.1

RootNet (Moon et al., 2019) 108.1

HDNET (Lin and Lee, 2020) 69.9

Ours 68

Absolute-ROMP: Absolute Multi-Person 3D Mesh Prediction from a Single Image

(a) (b) (c)

Figure 3: Absolute-ROMP is able to correctly position two people hugging: (a). Original image. (b). ROMP mesh positioning

using camera parameters (Sun et al., 2020). (c). Absolute-ROMP mesh positioning using absolute depth prediction.

and body trunk joints. The baseline “with RANSAC”

refers to randomly sampling the set of joints used for

optimization with RANSAC. The baseline results are

taken from the ﬁgures reported in (Moon et al., 2019).

We also compare with the state-of-the-art ap-

proaches (Moon et al., 2019; Lin and Lee, 2020). In

(Moon et al., 2019) a multi-stage approach is used

while in (Lin and Lee, 2020) a graph convolution net-

work model is used. Our model is able to outperform

the SOTA while maintaining inference in real time.

Our system runs at ∼ 23 fps on a Nvidia Tesla V100

GPU. Our root joint localization head achieves a 68

mm accuracy.

We also showcase the performance of Absolute-

ROMP on the MUPOTS dataset in Table 2. Our

model has comparable performance to the SOTA. We

also compare MJPJPE and PMPJPE performance in

Table 3 which does not make use of the absolute depth

as joints are evaluated after root alignment. Even with

added depth map prediction, we are able to main-

tain comparable performance with the SOTA. We also

show qualitative comparison with ROMP in Figure 3

which highlights the importance of absolute global

coordinates. Thanks to absolute depth information

while positioning the meshes, we improve the loca-

tion accuracy therefore correctly placing people hug-

ging each other.

Table 2: Results on the MuPoTS-3D dataset.

Methods PCK

abs

Moon et al. (Moon et al., 2019) 31.9

HDNET (Lin and Lee, 2020) 35.2

SMAP (Zhen et al., 2020) 35.4

Ours 35.28

Table 3: Comparisons to the state-of-the-art methods on

3DPW.

Methods MPJPE PMPJPE

YOLO + VIBE (Kocabas et al., 2019) 82.9 51.9

ROMP(HRNET-32) (Sun et al., 2020) 76.7 47.3

Absolute-ROMP(HRNET-32) 84 50.5

Finally, in Table 4 we show case TransFocal per-

formance against a SOTA approach CamCalib (Ko-

cabas et al., 2021c). Our model is trained on a

dataset created from partially available images of the

Pano360 dataset, while we compare the performance

with a model provided by the author (Kocabas et al.,

2021c) pretrained on dataset created from complete

Pano360 dataset. We evaluate on a portion of the

dataset unseen by our model. As can be seen our

model is able to outperform CamCalib by up to 40%.

Table 4: vfov error results comparison with state-of-the-art

on dataset created from Pano360 dataset.

Methods vfov diff(degrees)

CamCalib (Kocabas et al., 2021c) 26.35

TransFocal 15.59

5.2 Ablation Study

We show the improvement in performance when we

use a combination loss instead of just employing the

Softargmax-biased-L2 loss when training TransFocal.

We report mean error after training for 1 epoch while

using Softargmax-biased-L2 loss alone and with cross

entropy loss in Table 5. The cross entropy loss acts as

a guide for the gradient descent direction when the

model is starting out thus adding to the speed of con-

vergence of the model .

Table 5: vfov error comparison after 1 epoch with different

losses for supervision.

Methods vfov diff

softargmax-biased-L2 15.8

softargmax-biased-L2+cross entropy 15.6

6 CONCLUSION

We build upon an end to end one-stage network

ROMP for monocular multi-person 3D mesh regres-

sion, by adding in absolute distance prediction to cre-

VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications

ate our Absolute-ROMP. In order to eliminate the

need for intrinsic parameters of the camera, we also

design and train a focal length prediction network

called TransFocal, which is a CNN+Transformer hy-

brid model. We evaluate our models on industry stan-

dard benchmarks. Absolute-ROMP shows competi-

tive performance while maintaining real time perfor-

mance, while TransFocal is able to outperform the

state-of-the-art.

Future work could incorporate the absolute cam-

era parameters eliminating the need for predicting the

depth separately. This would require the use of ac-

curate absolute multi-person 3D datasets in a variety

of scenarios, such as the synthetic dataset AGORA

(Patel et al., 2021). In addition, real-time clothes and

texture prediction would be especially beneﬁcial for

VR and AR applications.

ACKNOWLEDGEMENTS

The work is supported by AFOSR Dynamic Data

Driven Applications Systems (Award #FA9550-21-

1-0082). The work is also supported in part

by NSF via the Partnerships for Innovation Pro-

gram (Award #1827505) and the CISE-MSI Pro-

gram (Award #1737533), and ODNI via the Intelli-

gence Community Center for Academic Excellence

(IC CAE) at Rutgers University (Awards #HHM402-

19-1-0003 and #HHM402-18-1-0007).

REFERENCES

Aitpayev, K. and Gaber, J. (2020). Creation of 3d human

avatar using kinect. In Asian Transactions on Funda-

mentals of Electronics, Communication & Multime-

dia.

Andriluka, M., Pishchulin, L., Gehler, P., and Schiele, B.

(2014). 2d human pose estimation: New benchmark

and state of the art analysis. In 2014 IEEE Conference

on Computer Vision and Pattern Recognition, pages

3686–3693.

Bai, Y., Mei, J., Yuille, A., and Xie, C. (2021). Are trans-

formers more robust than CNNs? In Beygelzimer, A.,

Dauphin, Y., Liang, P., and Vaughan, J. W., editors,

Advances in Neural Information Processing Systems.

Benzine, A., Chabot, F., Luvison, B., Pham, Q. C., and

Achrd, C. (2021). Pandanet : Anchor-based single-

shot multi-person 3d pose estimation. arXiv.

Boulic, R., B

echeiraz, P., Emering, L., and Thalmann, D.

(1997). Integration of motion control techniques for

virtual human and avatar real-time animation. pages

111–118.

Carbonera Luvizon, D., Tabia, H., and Picard, D. (2017).

Learning features combination for human action

recognition from skeleton sequences. Pattern Recog-

nition Letters, 99:13–20. User Proﬁling and Behavior

Adaptation for Human-Robot Interaction.

Choi, H., Moon, G., and Lee, K. M. (2020). Pose2mesh:

Graph convolutional network for 3d human pose and

mesh recovery from a 2d human pose.

Dabral, R., Gundavarapu, N. B., Mitra, R., Sharma, A., Ra-

makrishnan, G., and Jain, A. (2019). Multi-person 3d

human pose estimation from monocular images.

Dosovitskiy, A., Beyer, L., Kolesnikov, A., Weissenborn,

D., Zhai, X., Unterthiner, T., Dehghani, M., Minderer,

M., Heigold, G., Gelly, S., Uszkoreit, J., and Houlsby,

N. (2020a). An image is worth 16x16 words: Trans-

formers for image recognition at scale.

Dosovitskiy, A., Beyer, L., Kolesnikov, A., Weissenborn,

D., Zhai, X., Unterthiner, T., Dehghani, M., Min-

derer, M., Heigold, G., Gelly, S., Uszkoreit, J., and

Houlsby, N. (2020b). vision transformer github repos-

itory. GitHub repository.

Du, G. and Zhang, P. (2014). Markerless human–robot in-

terface for dual robot manipulators using kinect sen-

sor. Robotics and Computer-Integrated Manufactur-

ing, 30(2):150–159.

Fang, H.-S., Cao, J., Tai, Y.-W., and Lu, C. (2018). Pairwise

body-part attention for recognizing human-object in-

teractions.

Flickr (2022). Yahoo. https://www.ﬂickr.com/.

Grompone von Gioi, R., Jakubowicz, J., Morel, J.-M., and

Randall, G. (2010). Lsd: A fast line segment de-

tector with a false detection control. IEEE Transac-

tions on Pattern Analysis and Machine Intelligence,

32(4):722–732.

He, K., Zhang, X., Ren, S., and Sun, J. (2015). Deep resid-

ual learning for image recognition.

Hold-Geoffroy, Y., Sunkavalli, K., Eisenmann, J., Fisher,

M., Gambaretto, E., Hadap, S., and Lalonde, J.-F.

(2017). A perceptual measure for deep single image

camera calibration.

Ionescu, C., Papava, D., Olaru, V., and Sminchisescu, C.

(2014). Human3.6m: Large scale datasets and pre-

dictive methods for 3d human sensing in natural envi-

ronments. IEEE Transactions on Pattern Analysis and

Machine Intelligence, 36(7):1325–1339.

Jiang, W., Kolotouros, N., Pavlakos, G., Zhou, X., and

Daniilidis, K. (2020). Coherent reconstruction of mul-

tiple humans from a single image.

Johnson, S. and Everingham, M. (2010). Clustered pose

and nonlinear appearance models for human pose

estimation. In Proceedings of the British Machine

Vision Conference, pages 12.1–12.11. BMVA Press.

doi:10.5244/C.24.12.

Joo, H., Liu, H., Tan, L., Gui, L., Nabbe, B., Matthews,

I., Kanade, T., Nobuhara, S., and Sheikh, Y. (2015).

Panoptic studio: A massively multiview system for

social motion capture. In 2015 IEEE International

Conference on Computer Vision (ICCV), pages 3334–

3342.

Joo, H., Neverova, N., and Vedaldi, A. (2020). Exemplar

ﬁne-tuning for 3d human model ﬁtting towards in-the-

wild 3d human pose estimation.

Absolute-ROMP: Absolute Multi-Person 3D Mesh Prediction from a Single Image

Kanazawa, A., Black, M. J., Jacobs, D. W., and Malik,

J. (2017). End-to-end recovery of human shape and

pose.

Kanazawa, A., Zhang, J. Y., Felsen, P., and Malik, J. (2018).

Learning 3d human dynamics from video.

Kendall, A., Grimes, M., and Cipolla, R. (2015). Posenet: A

convolutional network for real-time 6-dof camera re-

localization. In 2015 IEEE International Conference

on Computer Vision (ICCV), pages 2938–2946.

Kingma, D. P. and Ba, J. (2014). Adam: A method for

stochastic optimization.

Kocabas, M., Athanasiou, N., and Black, M. J. (2019).

Vibe: Video inference for human body pose and shape

estimation.

Kocabas, M., Huang, C.-H. P., Hilliges, O., and Black, M. J.

(2021a). Pare: Part attention regressor for 3d human

body estimation.

Kocabas, M., Huang, C.-H. P., Tesch, J., M

uller, L.,

Hilliges, O., and Black, M. J. (2021b). Spec github

repository. GitHub repository.

Kocabas, M., Huang, C.-H. P., Tesch, J., M

uller, L.,

Hilliges, O., and Black, M. J. (2021c). Spec: Seeing

people in the wild with an estimated camera.

Kolotouros, N., Pavlakos, G., Black, M. J., and Daniilidis,

K. (2019). Learning to reconstruct 3d human pose and

shape via model-ﬁtting in the loop.

Lee, J., Go, H., Lee, H., Cho, S., Sung, M., and Kim, J.

(2021). Ctrl-c: Camera calibration transformer with

line-classiﬁcation.

Lee, J.-H. and Kim, C.-S. (2019). Monocular depth estima-

tion using relative depth maps. pages 9721–9730.

Li, J., Wang, C., Liu, W., Qian, C., and Lu, C. (2020a).

Hmor: Hierarchical multi-person ordinal relations for

monocular multi-person 3d pose estimation.

Li, J., Wang, C., Zhu, H., Mao, Y., Fang, H.-S., and Lu,

C. (2018). Crowdpose: Efﬁcient crowded scenes pose

estimation and a new benchmark.

Li, Y.-L., Liu, X., Lu, H., Wang, S., Liu, J., Li, J., and Lu,

C. (2020b). Detailed 2d-3d joint representation for

human-object interaction.

Li, Y.-L., Xu, L., Liu, X., Huang, X., Xu, Y., Wang, S.,

Fang, H.-S., Ma, Z., Chen, M., and Lu, C. (2020c).

Pastanet: Toward human activity knowledge engine.

Li, Z., Dekel, T., Cole, F., Tucker, R., Snavely, N., Liu, C.,

and Freeman, W. T. (2019). Learning the depths of

moving people by watching frozen people.

Li, Z. and Snavely, N. (2018). Megadepth: Learning single-

view depth prediction from internet photos.

Lin, J. and Lee, G. H. (2020). Hdnet: Human depth estima-

tion for multi-person camera-space localization.

Lin, T.-Y., Maire, M., Belongie, S., Bourdev, L., Girshick,

R., Hays, J., Perona, P., Ramanan, D., Zitnick, C. L.,

and Doll

ar, P. (2014). Microsoft coco: Common ob-

jects in context.

Liu, R., Lehman, J., Molino, P., Such, F. P., Frank, E.,

Sergeev, A., and Yosinski, J. (2018). An intriguing

failing of convolutional neural networks and the co-

ordconv solution.

Lo Presti, L. and La Cascia, M. (2016). 3d skeleton-based

human action classiﬁcation: A survey. Pattern Recog-

nition, 53:130–147.

Loper, M., Mahmood, N., Romero, J., Pons-Moll, G., and

Black, M. (2015). Smpl: a skinned multi-person linear

model. volume 34.

Luo, B. and Hancock (1999). Feature matching with pro-

crustes alignment and graph editing. In Image Pro-

cessing And Its Applications, 1999. Seventh Interna-

tional Conference on (Conf. Publ. No. 465), volume 1,

pages 72–76 vol.1.

Mehta, D., Rhodin, H., Casas, D., Fua, P., Sotnychenko,

O., Xu, W., and Theobalt, C. (2016). Monocular 3d

human pose estimation in the wild using improved cnn

supervision.

Mehta, D., Sotnychenko, O., Mueller, F., Xu, W., Sridhar,

S., Pons-Moll, G., and Theobalt, C. (2017). Single-

shot multi-person 3d pose estimation from monocular

rgb.

Moon, G., Chang, J. Y., and Lee, K. M. (2019). Cam-

era distance-aware top-down approach for 3d multi-

person pose estimation from a single rgb image.

Patel, P., Huang, C.-H. P., Tesch, J., Hoffmann, D. T., Tri-

pathi, S., and Black, M. J. (2021). AGORA: Avatars in

geography optimized for regression analysis. In Pro-

ceedings IEEE/CVF Conf. on Computer Vision and

Pattern Recognition (CVPR).

Qi, S., Wang, W., Jia, B., Shen, J., and Zhu, S.-C. (2018).

Learning human-object interactions by graph parsing

neural networks.

Ren, S., He, K., Girshick, R., and Sun, J. (2015). Faster

r-cnn: Towards real-time object detection with region

proposal networks.

Rogez, G., Weinzaepfel, P., and Schmid, C. (2019). LCR-

net++: Multi-person 2d and 3d pose detection in nat-

ural images. IEEE Transactions on Pattern Analysis

and Machine Intelligence, pages 1–1.

Sun, Y., Bao, Q., Liu, W., Fu, Y., Black, M. J., and Mei, T.

(2020). Monocular, one-stage, regression of multiple

3d people.

von Marcard, T., Henschel, R., Black, M., Rosenhahn, B.,

and Pons-Moll, G. (2018). Recovering accurate 3d hu-

man pose in the wild using imus and a moving camera.

In European Conference on Computer Vision (ECCV).

Wang, J., Sun, K., Cheng, T., Jiang, B., Deng, C., Zhao,

Y., Liu, D., Mu, Y., Tan, M., Wang, X., Liu, W., and

Xiao, B. (2019). Deep high-resolution representation

learning for visual recognition.

Workman, S., Greenwell, C., Zhai, M., Baltenberger, R.,

and Jacobs, N. (2015). Deepfocal: A method for direct

focal length estimation. In 2015 IEEE International

Conference on Image Processing (ICIP), pages 1369–

1373.

Workman, S., Zhai, M., and Jacobs, N. (2016). Horizon

lines in the wild.

Xu, Y., Zhu, S.-C., and Tung, T. (2019). Denserac: Joint

3d pose and shape estimation by dense render-and-

compare.

VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications

Yang, G., Tang, H., Ding, M., Sebe, N., and Ricci, E.

(2021). Transformer-based attention networks for

continuous pixel-wise prediction.

Zanﬁr, A., Marinoiu, E., and Sminchisescu, C. (2018a).

Monocular 3d pose and shape estimation of multiple

people in natural scenes: The importance of multi-

ple scene constraints. In 2018 IEEE/CVF Conference

on Computer Vision and Pattern Recognition, pages

2148–2157.

Zanﬁr, A., Marinoiu, E., Zanﬁr, M., Popa, A.-I., and Smin-

chisescu, C. (2018b). Deep network for the inte-

grated 3d sensing of multiple people in natural im-

ages. In Bengio, S., Wallach, H., Larochelle, H.,

Grauman, K., Cesa-Bianchi, N., and Garnett, R., edi-

tors, Advances in Neural Information Processing Sys-

tems, volume 31. Curran Associates, Inc.

Zhen, J., Fang, Q., Sun, J., Liu, W., Jiang, W., Bao, H.,

and Zhou, X. (2020). Smap: Single-shot multi-person

absolute 3d pose estimation.

Zhu, R., Yang, X., Hold-Geoffroy, Y., Perazzi, F., Eisen-

mann, J., Sunkavalli, K., and Chandraker, M. (2020).

Single view metrology in the wild.

Zimmermann, C., Welschehold, T., Dornhege, C., Burgard,

W., and Brox, T. (2018). 3d human pose estimation in

rgbd images for robotic task learning.

Absolute-ROMP: Absolute Multi-Person 3D Mesh Prediction from a Single Image
