GroupGazer: A Tool to Compute the Gaze per Participant in Groups

with Integrated Calibration to Map the Gaze Online to a Screen or

Beamer Projection

Wolfgang Fuhl

1,∗

, Daniel Weber

and Shahram Eivazi

1,2

University T

ubingen, Sand 14, T

ubingen, Germany

FESTO, Ruiter Str. 82, Esslingen am Neckar, Germany

Keywords:

Eye Tracking, Gaze, Gaze Group, Calibration, Group Calibration, Gaze Mapping.

Abstract:

In this paper we present GroupGaze. It is a tool that can be used to calculate the gaze direction and the

gaze position of whole groups. GroupGazer calculates the gaze direction of every single person in the image

and allows to map these gaze vectors to a projection like a projector. In addition to the person-speciﬁc gaze

direction, the person afﬁliation of each gaze vector is stored based on the position in the image. Also, it

is possible to save the group attention after a calibration. The software is free to use and requires a simple

webcam as well as an NVIDIA GPU.

1 INTRODUCTION

Eye tracking is an important input modality and infor-

mation source in the modern world (Cognolato et al.,

2018). In the ﬁeld of human-machine interaction, the

gaze signal is used and further researched for inter-

action with robots (Willemse and Wykowska, 2019)

but also other technical devices (Wanluk et al., 2016).

This involves not only simple control but also collab-

oration in which a human communicates complex be-

havior to a robot or system (Palinko et al., 2016). In-

teraction with the eyes is also an interesting source

of information in the ﬁeld of computer games (Alkan

and Cagiltay, 2007). Eye interaction is many times

faster than mouse interaction, which could revolution-

ize the professional computer gaming ﬁeld (J

onsson,

2005). In the ﬁeld of virtual reality, gaze information

can be used to render only small areas of the scene

in high resolution, leading to a signiﬁcant reduction

in the resources consumption of the devices (Meng

et al., 2018). Another important area in which the

gaze signal plays an important role is driver obser-

vation. Here it is necessary to assess whether the

driver is able to control the vehicle or is too tired in

the case of autonomous driving to take over the vehi-

cle (Zandi et al., 2019). Of course, this also applies

to car rental companies, for which it is important to

know whether the driver is, for example, intoxicated

Corresponding author

or an unsafe driver (Maurage et al., 2020). In the

ﬁeld of medicine, research is also being conducted

into methods of self-diagnosis (Clark et al., 2019).

This involves, for example, the early detection of

Alzheimer’s disease (Crawford, 2015), strokes (Mat-

sumoto et al., 2011), as well as eye defects (Eide et al.,

2019) or autism (Boraston and Blakemore, 2007).

In the ﬁeld of safety, the eye signal also gains in-

creasingly more interest (Katsini et al., 2020; Fuhl

et al., 2021a). This is due to the fact that personal

behavior is reﬂected in the gaze signal, which can

be used to identify the person (Fuhl et al., 2021b).

Other information contained in the eye is the cog-

nitive load based on pupil dilation (Chauliac et al.,

2020), attention (Chita-Tegmark, 2016), procedural

strategies (Jenke et al., 2021) and many others. A

relatively new area in which the eye tracking signal

is used is behavioral research (Yang and Krajbich,

2021; Das et al., 2018). Here it is on the one hand

about extracting expert knowledge from the eye sig-

nal and passing this knowledge to trainees (Manning

et al., 2003; Hoghooghi et al., 2020). This concerns,

all areas in which the training is only possible with

expensive tools and training devices (Vijayan et al.,

2018). In the area of medicine the main interest is to

distill the expert knowledge better (Quen et al., 2021;

Manning et al., 2003). Another area of behavioral re-

search which is also the subject of this thesis is group

behavior (Hwang and Lee, 2020; Reichenberger et al.,

Fuhl, W., Weber, D. and Eivazi, S.

GroupGazer: A Tool to Compute the Gaze per Participant in Groups with Integrated Calibration to Map the Gaze Online to a Screen or Beamer Projection.

DOI: 10.5220/0011607000003417

In Proceedings of the 18th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2023) - Volume 2: HUCAPP, pages

109-116

ISBN: 978-989-758-634-7; ISSN: 2184-4321

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

109

Figure 1: Detection results of the proposed tool GroupGazer on a group photo. The image has a high resolution in the pdf

so you can zoom in to see everything. A larger version of the image with more people is in the supplementary material. The

image is taken from www.pexels.com.

2020; Kredel et al., 2017). Here there is research in

the area of teaching (Korbach et al., 2020; Schnei-

der et al., 2008; Jarodzka et al., 2020) but also in dy-

namic environments like sports (Oldham et al., 2021;

Du Toit et al., 2009; Reneker et al., 2020).

The current problems in the ﬁeld of behavioral re-

search for groups, is that there is no freely available

software for this. Therefore, research groups have to

resort to expensive solutions such as multiple worn

eye trackers. This creates further issues like the as-

signment of the important areas between the different

scene cameras. One way around this is to use virtual

reality together with eye tracking. However, this also

changes the behavior of the test persons and cannot be

carried out over longer periods of time with regard to

motion sickness. Alternatively to worn eye trackers,

there is also the possibility to use external cameras.

In this case, the researchers have to implement their

technical solutions independently, which often leads

to dependencies on other working groups and is also

an expensive undertaking due to the image processing

cameras which are usually used.

In this paper, we present software that allows any-

one to use a simple webcam for gaze estimation of

groups and calibration each subject in parallel. By

doing so, we hope to enable anyone to conduct behav-

ioral group research. Our contributions to the state of

the art are:

1. A tool to record the gaze of groups and calibrate

each individual in parallel.

2. The tool has no specialized hardware require-

ments and only needs an NVIDIA GPU with at

least 4 GB memory (We used a 1050 ti with 4

GB).

3. Stores the gaze per person as well as the average

gaze location of the group.

2 RELATED WORK

Since our software is the combination of several re-

search ﬁelds, we have divided the related work into

three categories. The ﬁrst category is face recogni-

tion, the second category is appearance based gaze

estimation, and the third category is gaze based group

behavior research.

2.1 Face Detection

Face recognition in arbitrary environments is still a

very challenging ﬁeld of research. Here, an arbitrarily

large image is given, and all faces must be detected.

This often involves occlusions, different head posi-

tions, changes in lighting conditions, and of course

the faces in the image have different resolutions. The

ﬁrst very successful approach was presented by Viola

and Jones (Viola and Jones, 2004). This is based on

hair features and trained using AdaBoost. The next

major step was achieved with deformable part models

(DPM) (Yan et al., 2014). Compared to feature-based

approaches, DPM is much more robust but requires

signiﬁcantly more computational effort. With the ad-

vent of deep neural networks, however, the state of

the art was again signiﬁcantly improved (Bai et al.,

2018; Jiang and Learned-Miller, 2017; Li et al., 2019;

Zhang et al., 2020). The ﬁrst extension of neural

networks was the combination of face detection with

face matching (Zhang and Zhang, 2014; Zhang et al.,

2016). Current methods for face detection follow two

directions. The ﬁrst direction is the multistage ap-

proach, which is based on a region proposal neural

network followed by validation of the proposed faces.

The most notable representatives of this direction of

development are RCNN (Girshick et al., 2014), al-

most RCNN (Girshick, 2015), and faster RCNN (Ren

et al., 2015). The second direction of development

is direct methods such as single shot multibox detec-

tor (SSD) (Liu et al., 2016) or you only look once

(YOLO) (Redmon et al., 2016). For YOLO, there are

HUCAPP 2023 - 7th International Conference on Human Computer Interaction Theory and Applications

110

already multiple versions, which consume even less

resources at approximately the same detection rate.

The advantage of the direct approaches, is the faster

execution and the smaller resource consumption. The

multilayer methods, on the other hand, provide a bet-

ter detection rate and fewer misclassiﬁcations.

2.2 Appearance Based Gaze Estimation

Here, the entire facial image or eye area of a per-

son is used to directly determine the gaze vector via

a neural network. The ﬁrst work in this area is from

1994 (Baluja and Pomerleau, 1994) and was extended

in (Tan et al., 2002) by linear projection functions.

These methods require very expensive calibration,

since the neural network was trained for each person

individually with many training examples. The ﬁrst

extensions to reduce the effort in calibration were a

Gaussian process regression (Williams et al., 2006),

saliency maps (Sugano et al., 2012), and optimal se-

lection using a linear regression (Lu et al., 2014).

While all of these methods advanced the state of the

art, the appearance based approach still had many lim-

itations, such as a ﬁxed head position and per-person

calibration. With deep neural networks and the advent

of big data, this has changed signiﬁcantly. In (Zhang

et al., 2015) the ﬁrst successful approach was pre-

sented, which realized appearance based gaze estima-

tion with deep neural networks. The ﬁrst extensions

used, in addition to eye images, the subjects’ faces,

which resulted in a signiﬁcant improvement (Krafka

et al., 2016; Kellnhofer et al., 2019). For extreme

head positions and strongly deviating gaze angles to

the head orientation, an asymmetric regression was

presented (Cheng et al., 2020).

2.3 Gaze Based Group Behavior

Research

In this section, we would like to mention and brieﬂy

explain only some works from this area, since our

software is made for this purpose but does not per-

form a behavior research study.

The ﬁrst area in behavioral research which can

also be applied to groups is mind wandering (Hutt

et al., 2017; Hutt et al., 2019). Mind wandering is a

shift in attention to task-unrelated thoughts. This is an

interesting effect for teaching since it negatively inﬂu-

ences the learning performance of students (Robert-

son et al., 1997; Smallwood et al., 2008; Hutt et al.,

2019). Mind wandering itself is a special form of dis-

engagement and has to be separated from boredom

or off-task behaviors (Cocea and Weibelzahl, 2010;

Mills et al., 2014; Hutt et al., 2019). Another inter-

Figure 2: The workﬂow of our approach. We ﬁrst detect

the faces and compute the gaze vector using an appearance

based approach. Each person is calibrated using mouse

clicks on a projection in parallel. The ﬁtted polynomials

are afterwards used to map the gaze to the projection.

esting social behavior is gaze following (Aung et al.,

2018). This gaze following is a form of commu-

nication and socializing. In some scenarios it has

to be done only for a single person (Judd et al.,

2009; Fathi et al., 2012) but in modern research entire

scenes with multiple persons are evaluated and ana-

lyzed (Aung et al., 2018; Mukherjee and Robertson,

2015; Marin-Jimenez et al., 2014; Recasens et al.,

2017; Recasens, 2016). Nowadays, psychologists use

behavior observation methods in classrooms as well

as direct behavior ratings (Woolverton and Pollastri,

2021). While both methods are valid and also used

by teachers themselves, they are limited in effective-

ness due to the attentional limits of the human ob-

servers as well as their induced biases (McIntyre and

Foulsham, 2018). Modern research focuses on es-

tablishing intelligent classroom technologies with eye

tracking and voice recording (Woolverton and Pol-

lastri, 2021; McIntyre and Foulsham, 2018). Those

methods have their limitations due to the data se-

curity but deliver more insights and allow reducing

the induced bias by humans (Woolverton and Pollas-

tri, 2021; McIntyre and Foulsham, 2018; McParland

et al., 2021).

3 METHOD

Figure 2 shows the workﬂow of our approach.

GroupGazer ﬁrst opens a video stream on an avail-

able camera. Afterwards, all faces in the image

are detected. If not all desired faces are detected,

GroupGazer offers an upscaling factor, which can be

set by the user. This upscaling factor resizes the in-

put image to allow the face detection to detect even

very small faces in the image. After the face detec-

tion, all detected faces are extracted from the image

and resized to 100× 100 pixels in a gray scale image.

These images are grouped together to form a batch

which is given to the gaze vector estimation DNN.

GroupGazer: A Tool to Compute the Gaze per Participant in Groups with Integrated Calibration to Map the Gaze Online to a Screen or

Beamer Projection

111

Table 1: Shows the architecture of our face detection deep

neural network. The architecture is copied from dlib (King,

2009) and uses the max margin (King, 2015) training pro-

cedure. We modiﬁed the model in terms of tensor normal-

ization (Fuhl, 2021b) and gradient centralization (Fuhl and

Kasneci, 2021) as well as convolution size and depth.

Level Gaze estimator

Input RGB image any resolution

1 Pyramid layer with six stages

2 5 × 5 Conv, dep 8, 2 × 2 down, BN, ReLu, TN

3 3 × 3 Conv, dep 8, 2 × 2 down, BN, ReLu, TN

4 3 × 3 Conv, dep 8, 2 × 2 down, BN, ReLu, TN

5 5 × 5 Conv, dep 16, BN, ReLu, TN

6 3 × 3 Conv, dep 16, BN, ReLu, TN

7 3 × 3 Conv, dep 16, BN, ReLu, TN

8 7 × 7 Conv, dep 1

Table 2: Shows the architecture of our gaze estimation deep

neural network. It has the structure of a ResNet-34 (He

et al., 2016) and uses the leaky maximum propagation

blocks (Fuhl, 2021a), tensor normalization (Fuhl, 2021b),

as well as the weight and gradient centralization (Fuhl and

Kasneci, 2021).

Level Gaze estimator

Input Gray scale image 100 × 100

1 5 × 5 Conv, dep 32

2 ReLu with tensor normalization

3 2 × 2 Max pooling

4 3 Max blocks, 2 × 2 d, 3 × 3 C, dep 64, BN

5 ReLu with tensor norm

6 3 Max blocks, 2 × 2 d, 3 × 3 C, dep 128, BN

7 ReLu with tensor norm

8 3 Max blocks, 2 × 2 d, 3 × 3 C, dep 256, BN

9 ReLu with tensor norm

10 Fully connected, 512 outputs

11 ReLu

12 Fully, 7 (3,7 for validation))

The batch size can also be set by the user. This ﬁxed

batch size allows GroupGazer to have a static runtime

and if there are fewer faces in the image, the rest of

the batch is ﬁlled with black images. GroupGazer can

be used with a 1050 ti graphics card for up to 40 faces

in real time, which is also dependent on the input res-

olution to the face detection DNN. For newer GPUs

more faces can be set by the user as well as larger

input image resolutions for the face detection. The

gaze estimation DNN processes the entire batch and

computes a starting position (First two values), an ac-

curacy of the starting position (Third value), the gaze

vector (Forth to sixth value), as well as an accuracy

of the gaze vector (Seventh value). With this infor-

mation, each face has a gaze vector and an estimated

accuracy. With the gaze vector and the starting posi-

tion, a polynomial is used to map the gaze vector to

a projection or monitor. The degree of the polyno-

mial can be speciﬁed by the user, and the calibration

procedure works as follows. The teacher or adviser

tells the students to look at his mouse cursor posi-

tion. On a left mouse click, all gaze vectors which

are seen as valid and accurate are stored together with

the click location. This is repeated multiple times.

Afterwards, for each user, the polynomial is ﬁtted in

the least squares sense. With those polynomials, the

mapping and therefore the gaze location is computed

for each user. The reidentiﬁcation of users is done by

the smallest euclidean distance to the last detections,

and the new position is not allowed to leaf the last

face detection bounding box. This is a simple proce-

dure but saves a lot of computational resources since

no additional network has to be used. In addition, it is

much more robust since ﬁne-tuning a Network online

usually needs multiple examples to deliver reliable re-

sults, even if we use the hypersphere approach (Xie

et al., 2019) or siam networks (Abdelpakey and She-

hata, 2019).

The used model architectures can be seen in Ta-

ble 1 and 2. Our face detection model is similar

to the model from dlib (King, 2009) we only made

some slight changes which improve the accuracy of

the model and only impact the runtime slightly. For

gaze estimation we used the architecture of a ResNet-

34 (He et al., 2016) since it has a good accuracy and is

resource saving in contrast to the other networks. We

modiﬁed the ResNet-34 architecture only by adding

some novel normalization (Fuhl, 2021b; Fuhl and

Kasneci, 2021), the landmark validation loss (Fuhl

and Kasneci, 2019), as well as leaky maximum prop-

agations instead of the residual connections (Fuhl,

2021a).

4 EVALUATION

Gaze360 (Kellnhofer et al., 2019) is a huge data set

with 3D gaze annotations recorded using multiple

cameras covering 360 degree. The recordings were

conducted indoor and outdoor with 238 subjects. The

dataset contains large head variations as well as dis-

tances of the subjects to the camera. We only used

approximately 80,000 images of this data set since

the data set contains also human heads from behind

as well as some partially covered heads which we re-

moved from our data for training and evaluation. The

train and test split was done by randomly selecting

20% for testing and 80% for training.

DLIB (King, 2009) data set contains images of

various resolutions. Each image can have multiple

faces which are annotated with bounding boxes. In

HUCAPP 2023 - 7th International Conference on Human Computer Interaction Theory and Applications

112

Table 3: Face detection results on DLIB data set (King, 2009) with percition and recall. We compare our model to other

approaches in therms of detection percentage as well as runtime in milliseconds (ms) for one hundred images in average.

OoM means out of memory exception.

Method Percision Recall Runtime GPU (ms)

1920 × 1280 300 × 300

Proposed 0,99 0,89 67 3

dlib (King, 2009) 0,99 0,88 175 8

Res-34 & Faster-RCNN (Ren et al., 2015) 0,99 0,91 OoM 22 & 1

Yolov5s (Redmon et al., 2016) 0,99 0,89 OoM 10

Table 4: Appearance based gaze estimation results on the Gaze360 (Kellnhofer et al., 2019) dataset. We compared our model

to other approaches and evaluated the gaze start estimation in average euclidean distance in pixel as well as the gaze vector

estimation in degree. Time is measured for one face image as average over one thousand.

Method Gaze start Gaze vector Runtime GPU (ms)

Proposed 0,6 0,2 3

ResNet-34 (He et al., 2016) 0,9 0,5 8

ResNet-50 (He et al., 2016) 0,5 0,2 12

MobileNet (Howard et al., 2017) 1,8 1,6 7

MobileNetv2 (Sandler et al., 2018) 1,7 1,6 7

total the data set contains 7213 images and 11480 an-

notated faces. We made a random 50% to 50% split

and used the ﬁrst half for training and the second half

for evaluation (One image more for training due to the

uneven number). The images in the dataset are taken

from other public data sets and annotated by the au-

thors of (King, 2009).

Table 5: Accuracy of the proposed tool for different dis-

tances to the camera. The results are the average accu-

racy over three subjects on a TV screen with a diagonal of

108cm.

Distance subjects 1m 2m 3m 4m 5m 6m

Average Error 4cm 5cm 8cm 12cm 15cm 19cm

In Table 3 and 4 our models are compared with

other approaches. For face detection (Table 3), it can

be seen that we have chosen a tradeoff between de-

tection rate and runtime. The recognition rate of our

approach can be further increased via the upscaling

factor. However, this also increases the computation

time, which also increases the runtime per image. For

Yolo this is not possible, because the memory usage

for images larger than 300 becomes too large. For the

backbone of the faster-RCNN, the memory consump-

tion is also too high for a large resolution. Which is

also the main reason why we decided against YOLO

and the faster-RCNN. In addition, both the faster-

RCNN with backbone and the YOLO need a ﬁxed

input resolution with which they have to be trained.

For our fully convolutional approach inspired by the

dlib architecture, this is not necessary.

For the gaze direction determination, you can

clearly see that our net runs signiﬁcantly faster than

the other nets. This is due to the fact that our lay-

ers use less depth than, for example, ResNet-34. The

MobileNets cannot show their advantage on the GPU,

since they cause cache conﬂicts here, whereby parts

of the code are executed serialized. On a CPU, Mo-

bileNet would be signiﬁcantly faster than our net, but

with about 160 ms per face too slow for a real-time

evaluation. In terms of results, ResNet-50 is the most

accurate, closely followed by our network. In addi-

tion to accuracy, if we consider runtime on a GPU,

our network is clearly ahead, which is why we chose

our architecture.

5 CONCLUSION

In this paper, we have presented GroupGazer. This is

a software that allows to determine the gaze direction

of groups per person. This gaze determination is done

online on a conventional computer with an NVIDIA

GPU. GroupGazer allows each person in the group

to be calibrated in parallel so that the individual gaze

vectors can be mapped to a projection, such as that of

a projector or large monitor. The software is intended

to support behavioral research and thus make it possi-

ble to easily record the gaze positions of groups.

ACKNOWLEDGEMENTS

Daniel Weber is funded by the Deutsche Forschungs-

gemeinschaft (DFG, German Research Foundation)

under Germany’s Excellence Strategy – EXC number

2064/1 – Project number 390727645

GroupGazer: A Tool to Compute the Gaze per Participant in Groups with Integrated Calibration to Map the Gaze Online to a Screen or

Beamer Projection

113

REFERENCES

Abdelpakey, M. H. and Shehata, M. S. (2019). Dp-siam:

Dynamic policy siamese network for robust object

tracking. IEEE Transactions on Image Processing,

29:1479–1492.

Alkan, S. and Cagiltay, K. (2007). Studying computer game

learning experience through eye tracking. British

Journal of Educational Technology, 38(3):538–542.

Aung, A. M., Ramakrishnan, A., and Whitehill, J. R.

(2018). Who are they looking at? automatic eye gaze

following for classroom observation video analysis.

International Educational Data Mining Society.

Bai, Y., Zhang, Y., Ding, M., and Ghanem, B. (2018). Find-

ing tiny faces in the wild with generative adversarial

network. In Proceedings of the IEEE conference on

computer vision and pattern recognition, pages 21–

30.

Baluja, S. and Pomerleau, D. (1994). Non-intrusive gaze

tracking using artiﬁcial neural networks. Technical

report, CARNEGIE-MELLON UNIV PITTSBURGH

PA DEPT OF COMPUTER SCIENCE.

Boraston, Z. and Blakemore, S.-J. (2007). The application

of eye-tracking technology in the study of autism. The

Journal of physiology, 581(3):893–898.

Chauliac, M., Catrysse, L., Gijbels, D., and Donche, V.

(2020). It is all in the” surv-eye”: Can eye track-

ing data shed light on the internal consistency in self-

report questionnaires on cognitive processing strate-

gies?. Frontline Learning Research, 8(3):26–39.

Cheng, Y., Zhang, X., Lu, F., and Sato, Y. (2020). Gaze esti-

mation by exploring two-eye asymmetry. IEEE Trans-

actions on Image Processing, 29:5259–5272.

Chita-Tegmark, M. (2016). Social attention in asd: A re-

view and meta-analysis of eye-tracking studies. Re-

search in developmental disabilities, 48:79–93.

Clark, R., Blundell, J., Dunn, M. J., Erichsen, J. T., Giar-

dini, M. E., Gottlob, I., Harris, C., Lee, H., Mcilreavy,

L., Olson, A., et al. (2019). The potential and value

of objective eye tracking in the ophthalmology clinic.

Eye, 33(8):1200–1202.

Cocea, M. and Weibelzahl, S. (2010). Disengagement de-

tection in online learning: Validation studies and per-

spectives. IEEE transactions on learning technolo-

gies, 4(2):114–124.

Cognolato, M., Atzori, M., and M

uller, H. (2018). Head-

mounted eye gaze tracking devices: An overview of

modern devices and recent advances. Journal of re-

habilitation and assistive technologies engineering,

5:2055668318773991.

Crawford, T. J. (2015). The disengagement of visual at-

tention in alzheimer’s disease: a longitudinal eye-

tracking study. Frontiers in aging neuroscience,

7:118.

Das, M., Ester, P., and Kaczmirek, L. (2018). Social and

behavioral research and the internet: Advances in ap-

plied methods and research strategies. Routledge.

Du Toit, P. J., Kruger, P. E., Chamane, N., Campher, J.,

and Crafford, D. (2009). Sport vision assessment in

soccer players and sport science. African Journal for

Physical Health Education, Recreation and Dance,

15(4):594–604.

Eide, M. G., Watanabe, R., Heldal, I., Helgesen, C.,

Geitung, A., and Soleim, H. (2019). Detecting oculo-

motor problems using eye tracking: Comparing eyex

and tx300. In 2019 10th IEEE International Con-

ference on Cognitive Infocommunications (CogInfo-

Com), pages 381–388. IEEE.

Fathi, A., Hodgins, J. K., and Rehg, J. M. (2012). Social

interactions: A ﬁrst-person perspective. In 2012 IEEE

Conference on Computer Vision and Pattern Recogni-

tion, pages 1226–1233. IEEE.

Fuhl, W. (2021a). Maximum and leaky maximum propaga-

tion. arXiv preprint arXiv:2105.10277.

Fuhl, W. (2021b). Tensor normalization and full distribution

training. arXiv preprint arXiv:2109.02345.

Fuhl, W., Bozkir, E., and Kasneci, E. (2021a). Reinforce-

ment learning for the privacy preservation and manip-

ulation of eye tracking data. In Proceedings of IEEE

International Joint Conference on Neural Networks.

Fuhl, W. and Kasneci, E. (2019). Learning to validate the

quality of detected landmarks. In International Con-

ference on Machine Vision, ICMV.

Fuhl, W. and Kasneci, E. (2021). Weight and gradient cen-

tralization in deep neural networks. In Proceedings of

IEEE International Joint Conference on Neural Net-

works.

Fuhl, W., Sanamrad, N., and Kasneci, E. (2021b). The

gaze and mouse signal as additional source for user

ﬁngerprints in browser applications. arXiv preprint

arXiv:2101.03793.

Girshick, R. (2015). Fast r-cnn. In Proceedings of the IEEE

international conference on computer vision, pages

1440–1448.

Girshick, R., Donahue, J., Darrell, T., and Malik, J. (2014).

Rich feature hierarchies for accurate object detec-

tion and semantic segmentation. In Proceedings of

the IEEE conference on computer vision and pattern

recognition, pages 580–587.

He, K., Zhang, X., Ren, S., and Sun, J. (2016). Deep resid-

ual learning for image recognition. In Proceedings of

the IEEE conference on computer vision and pattern

recognition, pages 770–778.

Hoghooghi, S., Popovic, V., and Swann, L. (2020). Novice

to expert real-time knowledge transition in the context

of x-ray airport security. In Proceedings of DRS 2020

International Conference: Synergy. Vol. 4. Design Re-

search Society (UK).

Howard, A. G., Zhu, M., Chen, B., Kalenichenko, D.,

Wang, W., Weyand, T., Andreetto, M., and Adam,

H. (2017). Mobilenets: Efﬁcient convolutional neu-

ral networks for mobile vision applications. arXiv

preprint arXiv:1704.04861.

Hutt, S., Krasich, K., Mills, C., Bosch, N., White, S.,

Brockmole, J. R., and D’Mello, S. K. (2019). Au-

tomated gaze-based mind wandering detection during

computerized learning in classrooms. User Modeling

and User-Adapted Interaction, 29(4):821–867.

Hutt, S., Mills, C., Bosch, N., Krasich, K., Brockmole, J.,

and D’mello, S. (2017). ” out of the fr-eye-ing pan”

HUCAPP 2023 - 7th International Conference on Human Computer Interaction Theory and Applications

114

towards gaze-based models of attention during learn-

ing with technology in the classroom. In Proceedings

of the 25th Conference on User Modeling, Adaptation

and Personalization, pages 94–103.

Hwang, Y. M. and Lee, K. C. (2020). An eye-tracking

paradigm to explore the effect of online consumers’

emotion on their visual behaviour between desktop

screen and mobile screen. Behaviour & Information

Technology, pages 1–12.

Jarodzka, H., Skuballa, I., and Gruber, H. (2020). Eye-

tracking in educational practice: Investigating visual

perception underlying teaching and learning in the

classroom. Educational Psychology Review, pages 1–

10.

Jenke, L., Bansak, K., Hainmueller, J., and Hangartner, D.

(2021). Using eye-tracking to understand decision-

making in conjoint experiments. Political Analysis,

29(1):75–101.

Jiang, H. and Learned-Miller, E. (2017). Face detection

with the faster r-cnn. In 2017 12th IEEE international

conference on automatic face & gesture recognition

(FG 2017), pages 650–657. IEEE.

onsson, E. (2005). If looks could kill–an evaluation of eye

tracking in computer games. Unpublished Master’s

Thesis, Royal Institute of Technology (KTH), Stock-

holm, Sweden.

Judd, T., Ehinger, K., Durand, F., and Torralba, A. (2009).

Learning to predict where humans look. In 2009

IEEE 12th international conference on computer vi-

sion, pages 2106–2113. IEEE.

Katsini, C., Abdrabou, Y., Raptis, G. E., Khamis, M., and

Alt, F. (2020). The role of eye gaze in security and

privacy applications: Survey and future hci research

directions. In Proceedings of the 2020 CHI Confer-

ence on Human Factors in Computing Systems, pages

1–21.

Kellnhofer, P., Recasens, A., Stent, S., Matusik, W., and

Torralba, A. (2019). Gaze360: Physically uncon-

strained gaze estimation in the wild. In Proceedings of

the IEEE/CVF International Conference on Computer

Vision, pages 6912–6921.

King, D. E. (2009). Dlib-ml: A machine learning toolkit.

The Journal of Machine Learning Research, 10:1755–

1758.

King, D. E. (2015). Max-margin object detection. arXiv

preprint arXiv:1502.00046.

Korbach, A., Ginns, P., Br

unken, R., and Park, B. (2020).

Should learners use their hands for learning? results

from an eye-tracking study. Journal of Computer As-

sisted Learning, 36(1):102–113.

Krafka, K., Khosla, A., Kellnhofer, P., Kannan, H., Bhan-

darkar, S., Matusik, W., and Torralba, A. (2016). Eye

tracking for everyone. In Proceedings of the IEEE

conference on computer vision and pattern recogni-

tion, pages 2176–2184.

Kredel, R., Vater, C., Klostermann, A., and Hossner, E.-

J. (2017). Eye-tracking technology and the dynamics

of natural gaze behavior in sports: A systematic re-

view of 40 years of research. Frontiers in psychology,

8:1845.

Li, Z., Tang, X., Han, J., Liu, J., and He, R. (2019). Pyra-

midbox++: high performance detector for ﬁnding tiny

face. arXiv preprint arXiv:1904.00386.

Liu, W., Anguelov, D., Erhan, D., Szegedy, C., Reed, S.,

Fu, C.-Y., and Berg, A. C. (2016). Ssd: Single shot

multibox detector. In European conference on com-

puter vision, pages 21–37. Springer.

Lu, F., Sugano, Y., Okabe, T., and Sato, Y. (2014). Adap-

tive linear regression for appearance-based gaze esti-

mation. IEEE transactions on pattern analysis and

machine intelligence, 36(10):2033–2046.

Manning, D., Ethell, S. C., and Crawford, T. (2003). Eye-

tracking afroc study of the inﬂuence of experience

and training on chest x-ray interpretation. In Medi-

cal Imaging 2003: Image Perception, Observer Per-

formance, and Technology Assessment, volume 5034,

pages 257–266. International Society for Optics and

Photonics.

Marin-Jimenez, M. J., Zisserman, A., Eichner, M., and Fer-

rari, V. (2014). Detecting people looking at each other

in videos. International Journal of Computer Vision,

106(3):282–296.

Matsumoto, H., Terao, Y., Yugeta, A., Fukuda, H., Emoto,

M., Furubayashi, T., Okano, T., Hanajima, R., and

Ugawa, Y. (2011). Where do neurologists look when

viewing brain ct images? an eye-tracking study in-

volving stroke cases. PloS one, 6(12):e28928.

Maurage, P., Masson, N., Bollen, Z., and D’Hondt, F.

(2020). Eye tracking correlates of acute alcohol con-

sumption: A systematic and critical review. Neuro-

science & Biobehavioral Reviews, 108:400–422.

McIntyre, N. A. and Foulsham, T. (2018). Scanpath anal-

ysis of expertise and culture in teacher gaze in real-

world classrooms. Instructional Science, 46(3):435–

455.

McParland, A., Gallagher, S., and Keenan, M. (2021).

Investigating gaze behaviour of children diagnosed

with autism spectrum disorders in a classroom set-

ting. Journal of Autism and Developmental Disorders,

pages 1–16.

Meng, X., Du, R., Zwicker, M., and Varshney, A. (2018).

Kernel foveated rendering. Proceedings of the ACM

on Computer Graphics and Interactive Techniques,

1(1):1–20.

Mills, C., Bosch, N., Graesser, A., and D’Mello, S. (2014).

To quit or not to quit: predicting future behavioral dis-

engagement from reading patterns. In International

Conference on Intelligent Tutoring Systems, pages 19–

28. Springer.

Mukherjee, S. S. and Robertson, N. M. (2015). Deep head

pose: Gaze-direction estimation in multimodal video.

IEEE Transactions on Multimedia, 17(11):2094–

2107.

Oldham, J. R., Master, C. L., Walker, G. A., Meehan III,

W. P., and Howell, D. R. (2021). The association be-

tween baseline eye tracking performance and concus-

sion assessments in high school football players. Op-

tometry and Vision Science, 98(7):826–832.

Palinko, O., Rea, F., Sandini, G., and Sciutti, A. (2016).

Robot reading human gaze: Why eye tracking is bet-

GroupGazer: A Tool to Compute the Gaze per Participant in Groups with Integrated Calibration to Map the Gaze Online to a Screen or

Beamer Projection

115

ter than head tracking for human-robot collaboration.

In 2016 IEEE/RSJ International Conference on Intel-

ligent Robots and Systems (IROS), pages 5048–5054.

IEEE.

Quen, M. T. Z., Mountstephens, J., Teh, Y. G., and Teo, J.

(2021). Medical image interpretation training with a

low-cost eye tracking and feedback system: A prelim-

inary study. Healthcare Technology Letters.

Recasens, A., Vondrick, C., Khosla, A., and Torralba, A.

(2017). Following gaze in video. In Proceedings of the

IEEE International Conference on Computer Vision,

pages 1435–1443.

Recasens, A. R. C. (2016). Where are they looking? PhD

thesis, Massachusetts Institute of Technology.

Redmon, J., Divvala, S., Girshick, R., and Farhadi, A.

(2016). You only look once: Uniﬁed, real-time object

detection. In Proceedings of the IEEE conference on

computer vision and pattern recognition, pages 779–

788.

Reichenberger, J., Pfaller, M., and M

uhlberger, A. (2020).

Gaze behavior in social fear conditioning: An eye-

tracking study in virtual reality. Frontiers in psychol-

ogy, 11:35.

Ren, S., He, K., Girshick, R., and Sun, J. (2015). Faster

r-cnn: Towards real-time object detection with region

proposal networks. Advances in neural information

processing systems, 28:91–99.

Reneker, J. C., Pannell, W. C., Babl, R. M., Zhang, Y.,

Lirette, S. T., Adah, F., and Reneker, M. R. (2020).

Virtual immersive sensorimotor training (vist) in col-

legiate soccer athletes: A quasi-experimental study.

Heliyon, 6(7):e04527.

Robertson, I. H., Manly, T., Andrade, J., Baddeley, B. T.,

and Yiend, J. (1997). Oops!’: performance cor-

relates of everyday attentional failures in traumatic

brain injured and normal subjects. Neuropsychologia,

35(6):747–758.

Sandler, M., Howard, A., Zhu, M., Zhmoginov, A., and

Chen, L.-C. (2018). Mobilenetv2: Inverted residu-

als and linear bottlenecks. In Proceedings of the IEEE

conference on computer vision and pattern recogni-

tion, pages 4510–4520.

Schneider, M., Heine, A., Thaler, V., Torbeyns, J.,

De Smedt, B., Verschaffel, L., Jacobs, A. M., and

Stern, E. (2008). A validation of eye movements as

a measure of elementary school children’s developing

number sense. Cognitive Development, 23(3):409–

422.

Smallwood, J., McSpadden, M., and Schooler, J. W. (2008).

When attention matters: The curious incident of the

wandering mind. Memory & Cognition, 36(6):1144–

1150.

Sugano, Y., Matsushita, Y., and Sato, Y. (2012).

Appearance-based gaze estimation using visual

saliency. IEEE transactions on pattern analysis and

machine intelligence, 35(2):329–341.

Tan, K.-H., Kriegman, D. J., and Ahuja, N. (2002).

Appearance-based eye gaze estimation. In Sixth

IEEE Workshop on Applications of Computer Vision,

2002.(WACV 2002). Proceedings., pages 191–195.

IEEE.

Vijayan, K. K., Mork, O. J., and Hansen, I. E. (2018). Eye

tracker as a tool for engineering education. Universal

Journal of Educational Research, 6(11):2647–2655.

Viola, P. and Jones, M. J. (2004). Robust real-time face

detection. International journal of computer vision,

57(2):137–154.

Wanluk, N., Visitsattapongse, S., Juhong, A., and Pintavi-

rooj, C. (2016). Smart wheelchair based on eye track-

ing. In 2016 9th Biomedical Engineering Interna-

tional Conference (BMEiCON), pages 1–4. IEEE.

Willemse, C. and Wykowska, A. (2019). In natural inter-

action with embodied robots, we prefer it when they

follow our gaze: a gaze-contingent mobile eyetrack-

ing study. Philosophical Transactions of the Royal

Society B, 374(1771):20180036.

Williams, O., Blake, A., and Cipolla, R. (2006). Sparse

and semi-supervised visual mapping with the sˆ 3gp.

In 2006 IEEE Computer Society Conference on Com-

puter Vision and Pattern Recognition (CVPR’06), vol-

ume 1, pages 230–237. IEEE.

Woolverton, G. A. and Pollastri, A. R. (2021). An ex-

ploration and critical examination of how “intelligent

classroom technologies” can improve speciﬁc uses of

direct student behavior observation methods. Educa-

tional Measurement: Issues and Practice.

Xie, R., Chen, Y., Wo, Y., and Wang, Q. (2019). A deep,

information-theoretic framework for robust biometric

recognition. arXiv preprint arXiv:1902.08785.

Yan, J., Lei, Z., Wen, L., and Li, S. Z. (2014). The fastest

deformable part model for object detection. In Pro-

ceedings of the IEEE Conference on Computer Vision

and Pattern Recognition, pages 2497–2504.

Yang, X. and Krajbich, I. (2021). Webcam-based online

eye-tracking for behavioral research. Judgment and

Decision Making, 16(6):1486.

Zandi, A. S., Quddus, A., Prest, L., and Comeau, F. J.

(2019). Non-intrusive detection of drowsy driving

based on eye tracking data. Transportation research

record, 2673(6):247–257.

Zhang, C. and Zhang, Z. (2014). Improving multiview face

detection with multi-task deep convolutional neural

networks. In IEEE Winter Conference on Applications

of Computer Vision, pages 1036–1041. IEEE.

Zhang, K., Zhang, Z., Li, Z., and Qiao, Y. (2016). Joint

face detection and alignment using multitask cascaded

convolutional networks. IEEE Signal Processing Let-

ters, 23(10):1499–1503.

Zhang, X., Sugano, Y., Fritz, M., and Bulling, A. (2015).

Appearance-based gaze estimation in the wild. In Pro-

ceedings of the IEEE conference on computer vision

and pattern recognition, pages 4511–4520.

Zhang, Z., Shen, W., Qiao, S., Wang, Y., Wang, B., and

Yuille, A. (2020). Robust face detection via learn-

ing small faces on hard images. In Proceedings of

the IEEE/CVF Winter Conference on Applications of

Computer Vision, pages 1361–1370.

HUCAPP 2023 - 7th International Conference on Human Computer Interaction Theory and Applications

116
