Describing Image Focused in Cognitive and Visual Details for Visually

Impaired People: An Approach to Generating Inclusive Paragraphs

Daniel L. Fernandes

1 a

, Marcos H. F. Ribeiro

1 b

, Fabio R. Cerqueira

1,2 c

and Michel M. Silva

1 d

Department of Informatics, Universidade Federal de Vic¸osa - UFV, Vic¸osa, Brazil

Department of Production Engineering, Universidade Federal Fluminense - UFF, Petr

opolis, Brazil

Keywords:

Image Captioning, Dense Captioning, Neural Language Model, Visually Impaired, Assistive Technologies.

Abstract:

Several services for people with visual disabilities have emerged recently due to achievements in Assistive

Technologies and Artiﬁcial Intelligence areas. Despite the growth in assistive systems availability, there is

a lack of services that support speciﬁc tasks, such as understanding the image context presented in online

content, e.g., webinars. Image captioning techniques and their variants are limited as Assistive Technologies

as they do not match the needs of visually impaired people when generating speciﬁc descriptions. We propose

an approach for generating context of webinar images combining a dense captioning technique with a set

of ﬁlters, to ﬁt the captions in our domain, and a language model for the abstractive summary task. The

results demonstrated that we can produce descriptions with higher interpretability and focused on the relevant

information for that group of people by combining image analysis methods and neural language models.

1 INTRODUCTION

Recently, we have witnessed a boost in several ser-

vices for visually impaired people due to achieve-

ments in Assistive Technology and Artiﬁcial Intelli-

gence (Alhichri et al., 2019). However, the problems

faced by the impaired people are literally everywhere,

from arduous and complex challenges, such as going

to groceries, to daily tasks like recognizing the con-

text of TV news, online videos or webinars. In the last

couple of years, online content and videoconferencing

tools have been widely used to overcome the restric-

tions imposed by the social distance of the COVID-19

pandemic (Wanga et al., 2020). Nonetheless, there is

a lack of tools that allow visually impaired people to

understand the overall context of such content (Gurari

et al., 2020; Simons et al., 2020).

One of the services applied as an Assistive Tech-

nology is the Image Captioning techniques (Gurari

et al., 2020). Despite the remarkable results for the

automatically generated image caption, these tech-

niques are limited when applied to extract the image

context. Even with recent advances to improve the

https://orcid.org/0000-0002-6548-294X

https://orcid.org/0000-0003-4481-5781

https://orcid.org/0000-0003-1325-2592

https://orcid.org/0000-0002-2499-9619

quality of the captions, at the best, they compress all

the visual elements of an image into a single sentence,

resulting in a simple generic caption (Ng et al., 2020).

Since the goal of Image Captioning is to create a high-

level description for the image content, the cognitive

and visual details needed by visually impaired people

are disregarded (Dognin et al., 2020).

To address the drawback of Image Captioning

about enclosing all visual details in a single sentence,

Dense Captioning creates a descriptive sentence for

each meaningful image region (Johnson et al., 2016).

Nonetheless, such techniques fail to synthesize infor-

mation into coherently structured sentences due to the

overload caused by multiple disconnected sentences

to describe the whole image (Krause et al., 2017).

Thus, Dense Captioning is not suitable to the task of

extracting image context for impaired people since it

describes every visual detail of the image in a unstruc-

tured manner, not providing cognitive information.

Image Paragraph techniques address the de-

mand for generating connected and descriptive cap-

tions (Krause et al., 2017). The goal of these tech-

niques is to generate long, coherent and informative

descriptions about the whole visual content of an im-

age (Chatterjee and Schwing, 2018). Although being

capable of generating connected and informative sen-

tences, the usage of these techniques is limited when

creating image context for visually impaired people,

526

Fernandes, D., Ribeiro, M., Cerqueira, F. and Silva, M.

Describing Image Focused in Cognitive and Visual Details for Visually Impaired People: An Approach to Generating Inclusive Paragraphs.

DOI: 10.5220/0010845700003124

In Proceedings of the 17th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2022) - Volume 5: VISAPP, pages

526-534

ISBN: 978-989-758-555-5; ISSN: 2184-4321

because these techniques have generic application and

result in a long description to tell a story about the im-

age and all its elements. By creating a long and dense

paragraph that describes the whole image, the needs

of those with visual impairment are not matched.

The popularity of the social inclusion trend is no-

ticeable in social media, e.g., the Brazilian project

#ForBlindToSee (from the Portuguese, #PraCegoVer)

has reached trend topics in Twitter. This project pro-

vides a manual description for an image to be repro-

duced by audio tools for the visually impaired, and

also encourages people during videoconferences to

perform an oral description of the main characteris-

tics of their appearance and the environment where

they are located. The description helps the visually

impaired audience to better understand the context of

the reality of the person who is presenting. Although

this is a promising inclusion initiative, once the oral

descriptions are dependent on sighted people, it may

not be provided or may even be poorly descriptive.

Motivated to mitigate the accessibility barriers for

vision-impaired people, we combine the advantages

of the Dense Captioning techniques, task-speciﬁc

Machine Learning methods and language models pre-

trained on massive data. Our method consists in a

pipeline of computational techniques to automatically

generate suitable descriptions for this speciﬁc audi-

ence about the relevant speaker’s characteristics (e.g.,

physiognomic features, facial expressions) and their

surroundings (ABNT, 2016; Lewis, 2018).

2 RELATED WORK

Works on image description and text summariza-

tion have been extensively studied. We provide an

overview classifying them in the following topics.

Image Captioning. Image Captioning aims the

generation of descriptions for images and has at-

tracted the interest of researchers, connecting Com-

puter Vision and Natural Language Processing.

Several frameworks have been proposed for the

Image Captioning task based on deep encoder-

decoder architecture, in which an input image is en-

coded into an embedding and subsequently decoded

into a descriptive text sequence (Ng et al., 2020;

Vinyals et al., 2015). Attention Mechanisms and

their variations were implemented to incorporate vi-

sual context by selectively focusing on the speciﬁc

part of the image (Xu et al., 2015) and to decide when

to activate visual attention by means of adaptive at-

tention and visual sentinels (Lu et al., 2017).

Most recently, a novel framework for generating

coherent stories from a sequence of input images was

proposed by modulating the context vectors to capture

temporal relationship on the input image sequence

using bidirectional Long Short-Term Memory (bi-

LSTM) (Malakan et al., 2021). To maintain the im-

age speciﬁc relevance and context, image features and

context vectors from the bi-LSTM are projected into

a latent space and submitted to an Attention Mecha-

nism to learn the spatio-temporal relationships among

image and context. The encoder output is then mod-

ulated with the input word embedding to capture the

interaction between the inputs and their context using

Mogriﬁer-LSTM that generates relevant and contex-

tual descriptions of the images while maintaining the

overall story context.

Herdade et al. proposed a Transformer architec-

ture with an encoder block to incorporate information

about the spatial relationships between input objects

detected through geometric attention (Herdade et al.,

2019). Liu et al. also addressed the captioning prob-

lem using Transformers by replacing the CNN-based

encoder of the network by a Transformer encoder, re-

ducing the convolution operations (Liu et al., 2021).

Different approaches have been proposed to im-

prove the discriminative capacity of the generated

captions and attenuate the restrictions presented in

previously proposed methods. Despite the efforts,

most models still produce generic and similar cap-

tions (Ng et al., 2020).

Dense Captioning. Since region-based descrip-

tions tend to be more detailed than global descrip-

tions, the Dense Captioning task aims at generaliz-

ing the tasks of Object Detection and Image Cap-

tioning into a joint task by simultaneously locating

and describing salient regions of an image (Johnson

et al., 2016). Johnson et al. proposed a Fully Convolu-

tional Localization Network architecture, which sup-

ports end-to-end training and efﬁcient test-time per-

formance, composed of a CNN to process the input

image and a dense localization layer to predict a set

of regions of interest in the image. The descriptions

for each region is created by a LSTM with natural lan-

guage previously processed by a fully connected net-

work (Johnson et al., 2016). Additional approaches

improve Dense Captioning by using joint inference

and context fusion (Yang et al., 2017), and the visual

information about the target region and multi-scale

contextual cues (Yin et al., 2019).

Image Paragraphs. Image Paragraphs is a caption-

ing task that combines the strengths of Image Cap-

tioning and Dense Captioning, generating long, struc-

Describing Image Focused in Cognitive and Visual Details for Visually Impaired People: An Approach to Generating Inclusive Paragraphs

527

Image Analyzer

Grey beard hair on a

man. Man standing in

front of wall. Wall

behind the man is

green. Goatee on

man's mouth is not

smiling. A man

wearing sweater. His

sweater is black. His

hair is blonde. He has

short hair. Facial hair

under his lips.

Output paragraph

Context Generation

Summary

generation

Summary

cleaning

Quality

estimation

Text

concatenation

Dense captioning

generator

Filters and text

processing

External

classifiers

Sentence

generation

People

detection

Input image

Figure 1: Given a webinar image, its relevant information along with speaker attributes from pretained models are extracted

into textual descriptions. After a ﬁlter processing to ﬁt the person domain, all descriptions are aggregated into a single text.

We summarize the generated single text, and after a cleaning and ﬁltering process, the best quality paragraph is selected.

tured and coherent paragraphs that richly describe the

images (Krause et al., 2017). This approach was mo-

tivated by the lack of detail described in a single high-

level sentence of the Image Captioning techniques

and the absence of cohesion when describing whole

image due to the large amount of short independent

captions returned by Dense Captioning techniques.

A pioneering approach proposed a two-level hi-

erarchical RNN to decompose paragraphs into sen-

tences after separating the image into regions of in-

terest and aggregating the features of these regions in

semantically rich representation (Krause et al., 2017).

This approach was extended with an Attention Mech-

anism and a GAN that enables the coherence be-

tween sentences by focusing on dynamic salient re-

gions (Liang et al., 2017). An additional study uses

coherence vectors and Variational Auto-Encoder to

increase sentence consistency and paragraph diver-

sity (Chatterjee and Schwing, 2018).

Our approach diverges from the Image Paragraph.

Instead of unconstrained describing the whole image,

we focus on the relevant speaker’s attributes to pro-

vide a better understanding to the visually impaired.

Abstractive Text Summarization. This task aims

to rewrite a text into a shorter version, keeping the

meaning of the original content. Recent work on Ab-

stractive Text Summarization was applied in differ-

ent problems, such as highlighting news (Zhu et al.,

2021). Transformers pre-trained in massive datasets

achieved remarkable performance on many natural

language processing tasks (Raffel et al., 2020). In Ab-

stractive Text Summarization, we highlight the state-

of-the-art pre-trained models BART, T5, and PEGA-

SUS, with remarkable performance in both manipu-

lated use of lead bias (Zhu et al., 2021) and zero or

few-shot learning settings (Goodwin et al., 2020).

3 METHODOLOGY

Our approach takes an image as input and generates

a paragraph containing the image context for visu-

ally impaired people, regarding context-speciﬁc con-

straints. As depicted in Fig. 1, the method consists of

two phases: Image Analyzer and Context Generation.

3.1 Image Analyzer

We generate dense descriptions from the image, ﬁlter

the descriptions, extract high-level information from

the image, and aggregate all information into a single

text, as presented in the following pipeline.

People Detection. Our aim is to create an im-

age context by describing the relevant characteristics

about the speaker and their surroundings in the con-

text of webinars. Therefore, as a ﬁrst step, we apply a

people detector and count the number of people P in

the image. If P = 0, the process is stopped.

Dense Captioning Generator. Next, we use an au-

tomatic Dense Captioning approach to produce inde-

pendent and short sentence description for each mean-

ingful region of the image. Every created description

also has a conﬁdence value and a bounding box.

Filters and Text Processing. The Dense Caption-

ing produces a large number of captions per image,

VISAPP 2022 - 17th International Conference on Computer Vision Theory and Applications

528

which could result in similar descriptions or even out

of context. In this step, we ﬁlter out those captions.

Initially, we convert all captions to lower case, remove

punctuation and duplicated blank spaces, and apply a

tokenization method in the words. Then, to reduce the

amount of similar dense captions, we create a high-

dimensional vector representation for each sentence

using word embedding and calculate the cosine sim-

ilarity between all sentence representations. Dense

captions with cosine similarity greater than threshold

text sim

are discarded.

Next, we remove descriptions out of our context,

i.e., captions that are not associated with the speaker.

Linguistic annotation attributes are veriﬁed for each

token in the sentences. If no tokens related to nouns,

pronouns or nominal subjects are found, the sentence

is discarded. Then, a double check is performed over

the sentences that were kept after this second ﬁltering.

This is done using WordNet cognitive synonym sets

(synsets) (Miller, 1995), verifying whether the tokens

are associated to the concept person, being one of its

synonyms or hyponym (Krishna et al., 2017).

It is important to ﬁlter out short sentences since

they are more likely to have obvious details and to be

less informative for visually impaired people (ABNT,

2016; Lewis, 2018), for example, “a man has two

eyes”, “the man’s lips”, etc. We remove all sentences

shorter than the median length of the image captions.

On the set of kept sentences, we standardize the

subject/person in the captions using the most frequent

one, aiming to achieve better results in the text gener-

ator. At the end of this step, we have a set of semanti-

cally diverse captions, related to the concept of person

and the surroundings. Due to the ﬁltering process, the

kept sentences tend to be long enough to not contain

obvious or useless information.

External Classiﬁers. To add information regard-

ing relevant characteristics for vision-impaired peo-

ple, complementing the Dense Captioning results, we

apply people-focused learning models, such as age

detection and emotion recognition, and a scene clas-

siﬁcation model.

Due to the challenge of predicting the correct age

of a person, we aggregate the returned values by the

age group proposed by the World Health Organiza-

tion (Ahmad et al., 2001), i.e., Child, Young, Adult,

Middle-aged, and Elderly. Regarding emotion recog-

nition and scene classiﬁcation models, we use their

outputs in cases where the model conﬁdence is greater

than a threshold T

model con fidence

. To avoid inconsis-

tencies in the output, age and emotion models are only

applied if a single person is detected in the image.

Sentence Generation and Text Concatenation.

From the output produced by the external classiﬁers,

coherent sentences are created to include information

about age group, emotion, and scene in the set of ﬁl-

tered descriptions for the input image. The gener-

ated sentences follow the default structure: “there is

a/an <AGE> <NOUN>”, “there is a/an <NOUN>

who is <EMOTION>”, and “there is a/an <NOUN>

in the <SCENE>”, where AGE, EMOTION and

SCENE are the output of the learning methods, and

the <NOUN> is the frequent person-related noun

used to standardize the descriptions. Example of gen-

erated sentences, “there is a middle-aged woman”,

“there is a man who is sad”, and “there is a boy in the

ofﬁce”. These sentences are concatenated with the set

of previously ﬁltered captions into a single text.

3.2 Context Generation

In this phase, a neural linguist model is fed with the

output of the ﬁrst phase and generates coherent and

connected summary, which goes through a new clean-

ing process to create a quality image context.

Summary Generation. To create a human-like sen-

tence, i.e., a coherent and semantically connected

structure, we apply a neural language model to pro-

duce a summary from the concatenated descriptions

resulting from the previous phase. Five distinct sum-

maries are generated by the neural language model.

Summary Cleaning. One important step is to ver-

ify if the summary produced by the neural language

model achieves high similarity with the input text pro-

vided by the Image Analyzer phase. We assure the

similarity between the language model output and its

input, by ﬁltering out phrases inside the summary

when cosine similarity is less than threshold α. A

second threshold β is used as an upper limit to the

similarity values between pairs of sentences inside the

summary to remove duplicated sentences. In pairs of

sentences in which the similarity is greater than β, one

of them is removed to decrease redundancy. As a re-

sult, after the application of the two threshold-based

ﬁlters, we have summaries that are related to the input

with low probability of redundancy.

Quality Estimation. After generating and cleaning

the summaries, it is necessary to select one summary

returned by the neural language model. We model

the selection process to address the needs of vision-

impaired people in understanding an image context

by estimating the quality of paragraphs.

Describing Image Focused in Cognitive and Visual Details for Visually Impaired People: An Approach to Generating Inclusive Paragraphs

529

The most informative paragraphs usually present

linguistic characteristics, such as, multiple sentences

connected by conjunctions, use of complex linguistic

phenomena (e.g., co-references), and have a higher

frequency of verbs and pronouns (Krause et al.,

2017). Aiming to return the most informative sum-

mary, for each of the ﬁve ﬁltered summaries, we cal-

culate the frequency of the aforementioned linguistic

characteristics. Finally, the output of our proposed

approach is the summary with the higher frequency

of these characteristics.

4 EXPERIMENTS

Since there is no labeled dataset and evaluation met-

rics for the task of image context generation for visu-

ally impaired people, we adapted an existing dataset

and used general purpose metrics, as described in this

section.

Dataset. We used the Stanford Image-Paragraph

(SIP) dataset (Krause et al., 2017), widely applied for

visual Image Paragraph task. SIP is a subset of 19,551

images from the Visual Genome (VG) dataset (Kr-

ishna et al., 2017), with a single human-made para-

graph for each image. VG was used to access human

annotations of SIP images.

We selected only the images related to our domain

of interest, by analyzing their VG dense human anno-

tations. Only images with at least one dense caption

concerning to person were kept. To know whether

a dense caption is associated with a person, we used

WordNet synsets. To perform a double check about

the presence and relevance of people in the image,

we used a people detector, and ﬁlter out all images

in which no person were detected or the ones that do

not have a person bounding box with area greater than

50% of the image area. Our ﬁltered SIP dataset con-

sists of 2,147 images. Since the human annotations of

SIP could contain sentences beyond our context, we

ﬁltered out sentences that were not associated with a

person by means of linguistic feature analysis.

Implementation Details. For people detection and

dense captioning tasks, we used YOLOv3 (Redmon

and Farhadi, 2018) with minimum probability of 0.6,

and DenseCap (Johnson et al., 2016), respectively.

To reduce the amount of similar dense captions, we

adopted T

text sim

= 0.95. For age inference, emo-

tion recognition, and scene classiﬁcation tasks, we

used, respectively, Deep EXpectation (Rothe et al.,

2015), Emotion-detection (Goodfellow et al., 2013),

Table 1: Comparison between methods using standard met-

rics to measure similarity between texts. All values are re-

ported as percentage. B, Mt and Cr metrics stand for BLEU,

METEOR and CIDEr, respectively. Best values in bold.

Method B-1 B-2 B-3 B-4 Mt Cr

Concat 6.4 3.9 2.3 1.3 11.4 0.0

Concat-Filter 29.8 17.5 9.9 5.5 16.4 9.6

Ours 16.9 9.6 5.3 3.0 10.9 9.1

Ours-GT 22.3 12.1 6.6 3.7 12.5 15.3

and PlacesCNN (Zhou et al., 2017). For emotion and

scene models, we used T

model con f idence

= 0.6.

We used a T5 model (Raffel et al., 2020) (Hug-

gingface T5-base implementation) ﬁne-tuned on the

News Summary dataset for abstractive summarization

task and with beam search widths in the range of 2-6.

To keep sentences relevant and unique, we deﬁned α

and β equal to 0.7 and 0.5, respectively.

Competitors. We compared our approach with two

competitors, Concat, that creates a paragraph by con-

catenating all DenseCap outputs, and Concat-Filter,

that concatenates only the DenseCap outputs associ-

ated with a person, as described in Section 3.1. The

proposed method is mentioned as Ours hereinafter,

and a variant is referred as Ours-GT. This variant

uses the human-annotated dense captions of the VG

database instead of using DenseCap for creating the

dense captions for the images, and it is used as an

upper-bound comparison for our method.

Evaluation Metrics. The performance of the meth-

ods was measured through the metrics: BLEU-{1, 2,

3, 4}, METEOR and CIDEr, commonly used on para-

graph generation and image captioning tasks.

5 RESULTS AND DISCUSSION

We start our experimental evaluation analyzing Tab. 1,

which shows the values of the metrics for each

Table 2: Language statistics about the average and standard

deviation in the number of characters, words, and sentences

in the paragraphs generated by each method.

Method Characters Words Sentences

Concat 2,108 ± 311 428 ± 58 89 ± 12

Concat-Filter 294 ± 116 62 ± 23 12 ± 5

Ours 109 ± 42 22 ± 8 3 ± 1

Ours-GT 139 ± 54 26 ± 10 3 ± 1

Humans 225 ± 110 45 ± 22 4 ± 2

VISAPP 2022 - 17th International Conference on Computer Vision Theory and Applications

530

Table 3: Comparing Ours with the ﬁltered Concat-Filter to match the number of sentences written by humans. Lines bellow

the dashed show the metrics when the ﬁltering is smoothed. All values are reported as percentage, and best ones are in bold.

Method BLEU-1 BLEU-2 BLEU-3 BLEU-4 METEOR CIDEr

Concat-Filter-25% 7.4 4.0 2.1 1.1 8.2 4.7

Ours 16.9 9.6 5.3 3.0 10.9 9.1

Concat-Filter-30% 11.3 6.1 3.2 1.7 9.2 6.2

Concat-Filter-35% 16.0 8.7 4.6 2.4 10.4 8.1

Concat-Filter-40% 19.4 10.6 5.6 3.0 11.0 9.0

Concat-Filter-45% 22.6 12.4 6.6 3.6 11.7 9.9

Table 4: Statistics of paragraph linguistic features for Nouns

(N), Verbs (V), Adjectives (A), Pronouns (P), Coordinating

Conjunction (CC), and Vocabulary Size (VS). All values are

reported as percentage, except for VS. Values in bold are the

closest to the human values.

Method N V A P CC VS

Concat 30.3 3.3 14.3 0.0 1.9 876

Concat-Filter 32.6 8.6 8.4 0.1 0.5 418

Ours 30.3 10.6 9.9 1.6 1.5 642

Humans 25.4 10.0 9.8 5.9 3.1 3,623

method. The Concat approach presented the worst

performance due to the excess of independent pro-

duced captions, demonstrating its inability to pro-

duce coherent sentences (Krause et al., 2017). When

comparing with Concat, Ours achieved better perfor-

mance in most metrics. The descriptions generated

by the Concat-Filter method produced higher scores

when compared with our approach. However, it is

worth to note that Ours and Concat-Filter presented

close values considering the CIDEr metric. Unlike

the metrics BLEU (Papineni et al., 2002) and ME-

TEOR (Banerjee and Lavie, 2005) that are intended

for the Machine Translation task, CIDEr was speciﬁ-

cally designed to evaluate image captioning methods

based on human consensus (Vedantam et al., 2015).

Furthermore, the CIDEr value of the Concat-Filter

is smaller than the value of Ours-GT, which demon-

strates the potential of our method in the upper-bound

scenario.

Tab. 2 presents language statistics, demonstrat-

ing that Concat-Filter generates medium-length para-

graphs, considering the number of characters, and av-

erage number of words closer to paragraphs described

by humans. However, its paragraphs have almost

three times the number of sentences of human para-

graphs. This wide range of information contained

in the output explains the higher values achieved in

BLEU-{1,2,3,4} and METEOR, since these metrics

are directly related to the amount of words present in

the sentences.

To further demonstrate that the good results

achieved by Concat-Filter was due to the greater num-

ber of words, we randomly removed the sentences

from the paragraphs of Concat-Filter. The average

number of sentences were closer to paragraphs de-

scribed by human when 75% of the sentences were re-

moved. Then, we ran the metrics again and the values

for Concat-Filter dropped substantially, as demon-

strated in Tab. 3. Considering 25% of the sentences,

Ours overcome the results in all metrics. Concat-

Filter only achieves comparable performance with

Ours when it is kept at least 40% of the total para-

graph sentences. This is a higher amount compared

to the average of sentences present in paragraphs cre-

ated by humans and our approach (Tab. 2).

We can see in Tab. 4 that Ours achieved results

closer to the human annotated output for most of the

linguistic features. The results presented in this sec-

tion demonstrate that paragraphs generated by our ap-

proach are more suitable for people with visual im-

pairments, since their resulting linguistic features are

more similar to the ones described by humans, and

mainly, the ﬁnal output is shorter. As discussed and

presented in Section 5.1, the length is crucial to better

understand the image context.

5.1 Qualitative Analysis

Fig. 2 depicts input images and their context para-

graphs generated by the methods compared in this

study. Concat-Filter returned text descriptions with

simple structure, containing numerous and obvious

details in general. These observations corroborate

with the data presented in Tab. 4, which show the low

amount of pronouns and coordinating conjunctions.

In contrast, even using a language model that is not

speciﬁc to the Image Paragraph task, Ours and Ours-

GT generate better paragraphs in terms of linguistic

elements, using commas and coordinating conjunc-

tions, which smooth phrase transitions.

In Fig. 2 column 3, we can note some ﬂaws in the

generated context paragraphs. The main reason is the

error propagated by the models used in the pipeline,

including DenseCap. Despite that, the results are still

intelligible and contribute to the image interpretabil-

Describing Image Focused in Cognitive and Visual Details for Visually Impaired People: An Approach to Generating Inclusive Paragraphs

531

A man is sitting down. He has

short hair and wear eye glasses.

He is holding a remote control

in his hand while posing for his

picture. You can see he is sitting

in a living roo m inside a home.

A man wearing a black shirt. Man with

black hair. A man holding a phone. A

man sitting on a couch. A black and

white wii remote. The man has glasses.

The hand of a man. The man has a

beard. Man with a beard. The man has

short hair. A picture of a woman. The

man is wearing a tie. The ear of a man.

The hair of a woman. White wall

behind the woman.

Man wearing a black shirt. A

man sitting on a couch. The

man has glasses. He has short

hair. He is wearing a white

shirt. He is wearing a tie. White

wall behind the man.

The man is dressed in a black

sweater and is sitting by a black

chair. He is wearing glasses

with a frame made of plastic.

The scene shows flowers

beneath the lamp behind the

man.

Ground-Truth (SIP dataset) Concat-Filter

Ours

Ours-GT

A woman is dressed in a short

light pink dress and holding a

brown teddy bear with a dark

pink bow. The woman is

looking off to the left she h as

blond hair and a plaid bow in

her hair. Her makeup is done.

She is in a roo m.

Girl holding t eddy bear. A woman is in

a pink dress. The woman has brown

hair. Wall behind the woman. Girl with

long hair. The girl is wearing a pink

shirt. The woman is wearing a skirt.

Pink shirt on a woman. The woman is

wearing glasses. White wall behind the

man. A woman wearing a black shirt.

The arm of a girl. A blue and white box.

A white shirt on a man. A woman

wearing a hat. The head of a woman. A

wall behind the man. The man is

wearing a brown shirt .

Woman holding teddy bear. A

white wall behind her. A

woman wearing black hat, a

white shirt and a brown shirt.

Blond woman holding a stuffed

teddy bear in her left hand. She

is wearing a pink dress and has

multicolored hair. The buttons

are on the woman's dress.

A middle aged man with gray

hair is looking straight ahead.

He is dressed in a black suit

gold tie gray colored shirt.

Man with glasses. Man has short hair.

The man has a beard. The collar of a

man. Man wearing a black suit. The

nose of a man. The man has glasses.

White shirt on man. The man is wearing

glasses. The man is smiling. A man in a

white shirt.The hair of a man.

A man in a discotheque has

short hair. He has a beard. A

man wearing a white shirt.

Grey haired man with d ark eyes

in a discotheque. A pink purple

and green colorful screen

behind a man's head. Old man

wearing dress shirt and tie.

Brown and gray hair on his

head. Man in front of a

darkened background.

Figure 2: Examples of paragraphs generated by the compared methods, except for Concat.

Concat-Filter

Ours

Ours-GT

A mature woman with short red

hair that is graying is speaking on

the telephone. She has a surprised

look on her face as she listens to

the caller. She is sitting in a chair

in a brightly lit office. She's

wearing glasses and a yellow

sweatshirt. Around her neck is a

lanyard that has many colorful

and exotic looking pins attached

to it.

A woman wearing a tie. A woman with

brown hair. White shirt on man. Man

holding a cell phone. A white shirt on a

man. The man is wearing a black watch.

The man is wearing glasses. Man has

glasses. The hair of a man. A man with a

beard. The woman is holding a white

umbrella. The arm of a man. White wall

behind the woman. Hair on the womans

head. The man has a beard. The ear of a

man. The man is wearing a necklace .

A man with brown hair. A man

holding a cell phone. A white

shirt on a man. The man is

wearing glasses and a black

watch. He is wearing a

necklace.

A black cell phone in the

woman's hand. Blonde and gray

hair on the woman's head. Pins

attached to her lanyard. Glasses

covering the woman's eyes. A

clock on the wall behind the

woman.

A red headed man in thin wire

rimmed glasses is sitting in front

of a window overlooking a river

with a woman. The man is

wearing a brown raglan sleeved

top and the woman is wearing a

white camisole under a light blue

sheer top. The woman is wearing

her hair in a ponytail in the back

of her head. The woman is

holding a frisbee reading cheese

shop wow. There is a white and

red pole on the right of the man.

A woman with a dark hair. Man with

short hair. A red and white cup. Man has

a beard. Man wearing a blue shirt. The

man has glass es. The wo man is smiling.

The woman is wearing a necklace. The

man is wearing a tie. The collar of a

man. The hair of a man. A woman with

a beard. Red writing on the b ack of a

man. The ear of a man. A man wearing

a hat. A blue strap on the womans

shoulder. A man in the water. A woman

in a white shirt.

Man in a white shirt, wearing

a black shirt and wearing a

necklace. He has short hair.

Red writing on the back of a

man. A blue strap on his

shoulder. A man in a dark

hair.

Picture shows a middle-aged

woman and a woman smiling

together. Picture shows a

woman combing with a

ponytail. Picture shows a

woman holding a red lid.

Ground-Truth (SIP dataset)

Figure 3: Examples of paragraphs generated with different failure cases. Sentences and words in red are ﬂawed cases.

ity for visual-impaired people. Due to the ﬂexibility

of our approach, errors can be reduced by replacing

models by similar ones with higher accuracy. One ex-

ample is Ours-GT, in which DenseCap was replaced

by human annotations and the results are better in

all metrics and qualitative analysis, demonstrating the

potential of our method.

Fig. 3 illustrates failure cases generated by the

methods. In the ﬁrst line, a woman is present in the

image and the output of Ours described her as a man,

which can be justiﬁed since the noun man is more fre-

quent in the DenseCap output than woman, as can be

seen in the Concat-Filter column. This mistake was

not made by Ours-GT, since this approach does not

use DenseCap outputs. However, changing the se-

mantics of subjects is less relevant than mentioning

two different people in an image that presents only

one, as seen in the Concat-Filter result. In line 2, all

methods generate wrong outputs for the image con-

taining two people. A possible reason is the summa-

rization model struggling with captions referring to

different people in an image. In this case, we saw fea-

VISAPP 2022 - 17th International Conference on Computer Vision Theory and Applications

532

tures from one person described as related to another.

Nonetheless, other examples with two or more people

in our evaluation were described coherently.

As limitations of our approach, we can list the re-

striction to a static image, the error propagation from

the models used, the possibility of amplifying the er-

ror by standardizing the most frequent subject, mix-

ing descriptions from people when the image contains

more than one person, and the vanishing of descrip-

tions during the summarization process. The latter

can be observed in Fig. 2 line 1, in which none of the

characteristics age, emotion or scene were mentioned

in the summary.

The lack of an annotated dataset for the problem

of describing images for vision-impaired people im-

pacts our experimental evaluation. When using the

SIP dataset, even ﬁltering the captions to keep only

the phrases mentioning people, most of the Ground-

Truth descriptions are generic. Since our approach

includes ﬁne details about the speaker, such as age,

emotion, and scene, Ours can present low scores, be-

cause the reference annotation does not contain such

information. In this case, we added relevant and extra

information that negatively affects the metrics.

6 CONCLUSIONS

In this paper, we proposed an approach for generat-

ing context of webinar images for visually-impaired

people. Current methods are limited as assistive tech-

nologies since they tend to compress all the visual el-

ements of an image into a single caption with rough

details, or create multiple disconnected phrases to de-

scribe every single region of the image, which does

not match the needs of vision-impaired people. Our

approach combines Dense Captioning, as well as a set

of ﬁlters to ﬁt descriptions in our domain, with a lan-

guage model for generating descriptive paragraphs fo-

cused on cognitive and visual details for visually im-

paired people. We evaluated and discussed with dif-

ferent metrics on the SIP dataset adapted to the prob-

lem. Experimentally, we demonstrated that a social

inclusion method to improve the life of impaired peo-

ple can be developed by combining existent methods

for image analyze with neural linguistic models.

As a future work, given the ﬂexibility of our ap-

proach, we intend to replace and add more pretrained

models to increase the accuracy and improve the qual-

ity of the generated context paragraphs. We also aim

to create a new dataset designed to suit the image de-

scription problem for vision-impaired people.

ACKNOWLEDGEMENTS

The authors thank CAPES, FAPEMIG and CNPq for

funding different parts of this work, and the Google

Cloud Platform for the awarded credits.

REFERENCES

ABNT (2016). Accessibility in communication: Audio de-

scription - NBR 16452. ABNT.

Ahmad, O. B. et al. (2001). Age standardization of rates: a

new who standard. WHO, 9(10).

Alhichri, H. et al. (2019). Helping the visually impaired

see via image multi-labeling based on squeezenet cnn.

Appl. Sci., 9(21):4656.

Banerjee, S. and Lavie, A. (2005). Meteor: An automatic

metric for mt evaluation with improved correlation

with human judgments. In ACLW.

Chatterjee, M. and Schwing, A. G. (2018). Diverse and co-

herent paragraph generation from images. In ECCV.

Dognin, P. et al. (2020). Image captioning as an assistive

technology: Lessons learned from vizwiz 2020 chal-

lenge. arXiv preprint.

Goodfellow, I. J. et al. (2013). Challenges in representation

learning: A report on three machine learning contests.

In ICONIP, pages 117–124. Springer.

Goodwin, T. R. et al. (2020). Flight of the pegasus? com-

paring transformers on few-shot and zero-shot multi-

document abstractive summarization. In COLING,

volume 2020, page 5640. NIH Public Access.

Gurari, D. et al. (2020). Captioning images taken by people

who are blind. In ECCV, pages 417–434. Springer.

Herdade, S. et al. (2019). Image captioning: Transforming

objects into words. In NeurIPS.

Johnson, J. et al. (2016). Densecap: Fully convolutional

localization networks for dense captioning. In CVPR.

Krause, J. et al. (2017). A hierarchical approach for gener-

ating descriptive image paragraphs. In CVPR.

Krishna, R. et al. (2017). Visual genome: Connecting lan-

guage and vision using crowdsourced dense image an-

notations. Int. J. Comput. Vision, 123(1):32–73.

Lewis, V. (2018). How to write alt text and image descrip-

tions for the visually impaired. Perkins S for the Blind.

Liang, X. et al. (2017). Recurrent topic-transition gan for

visual paragraph generation. In ICCV.

Liu, W. et al. (2021). Cptr: Full transformer network for

image captioning. arXiv preprint, abs/2101.10804.

Lu, J. et al. (2017). Knowing when to look: Adaptive at-

tention via a visual sentinel for image captioning. In

CVPR, pages 375–383.

Malakan, Z. M. et al. (2021). Contextualise, attend, mod-

ulate and tell: Visual storytelling. In VISIGRAPP (5:

VISAPP), pages 196–205.

Miller, G. A. (1995). Wordnet: a lexical database for en-

glish. Comms. of the ACM, 38(11):39–41.

Ng, E. G. et al. (2020). Understanding guided image cap-

tioning performance across domains. arXiv preprint.

Describing Image Focused in Cognitive and Visual Details for Visually Impaired People: An Approach to Generating Inclusive Paragraphs

533

Papineni, K. et al. (2002). Bleu: a method for automatic

evaluation of machine translation. In Proc. of the 40th

annual meeting of the ACL, pages 311–318.

Raffel, C. et al. (2020). Exploring the limits of transfer

learning with a uniﬁed text-to-text transformer. JMLR,

21(140):1–67.

Redmon, J. and Farhadi, A. (2018). Yolov3: An incremental

improvement. arXiv preprint.

Rothe, R. et al. (2015). Dex: Deep expectation of apparent

age from a single image. In ICCV, pages 10–15.

Simons, R. N. et al. (2020). “i hope this is helpful”: Under-

standing crowdworkers’ challenges and motivations

for an image description task. ACM HCI.

Vedantam, R. et al. (2015). Cider: Consensus-based image

description evaluation. In CVPR, pages 4566–4575.

Vinyals, O. et al. (2015). Show and tell: A neural image

caption generator. In CVPR, pages 3156–3164.

Wanga, H. et al. (2020). Social distancing: Role of smart-

phone during coronavirus (covid–19) pandemic era.

IJCSMC, 9(5):181–188.

Xu, K. et al. (2015). Show, attend and tell: Neural im-

age caption generation with visual attention. In ICML,

pages 2048–2057. PMLR.

Yang, L. et al. (2017). Dense captioning with joint inference

and visual context. In CVPR, pages 2193–2202.

Yin, G. et al. (2019). Context and attribute grounded dense

captioning. In CVPR, pages 6241–6250.

Zhou, B. et al. (2017). Places: A 10 million image database

for scene recognition. TPAMI.

Zhu, C. et al. (2021). Leveraging lead bias for zero-shot

abstractive news summarization. In ACM SIGIR.

VISAPP 2022 - 17th International Conference on Computer Vision Theory and Applications

534
