Detection and Remediation of Malicious Actors for Studies Involving
Remote Data Collection
Bethany K. Bracken
, John Wolcott
, Isaac Potoczny-Jones
, Brittany A. Mosser
Isabell R. Griffith-Fillipo
and Patricia A. Arean
Charles River Analytics, 625 Mount Auburn St., Cambridge, MA, U.S.A.
Tozny, LLC, 411 NW Park Ave. Ste 400, Portland, OR 97209, U.S.A.
Department of Psychiatry & Behavioral Sciences, University of Washington,
1959 NE Pacific Street, Seattle, WA, 98195, U.S.A.
Keywords: Remote Data Collection, Malicious Actors, Bots, Bad Actors.
Abstract: Although most human subjects research requires data collection by contacting local participants who visit a
research site, some studies require increasingly large troves of data collected continuously during their typical
daily lives using sensors (e.g., fitness trackers) and ecological momentary assessments. Long-term,
continuous collection is becoming more feasible as smartphones become ubiquitous. To enable remote
collection of these rich data sets while ensuring privacy, we built a system to allow secure and fully human-
out-of-the-loop participant recruitment, screening, onboarding, data collection on smartphones, data
transmission to the cloud, data security in the cloud, and data access by analysis and modeling teams. Study
participants were paid for completion of daily ecological momentary assessments in keeping with standards
of research equipoise, fairness, and retention strategies. However, our study attracted “malicious actors” who
were pretending to be study participants, but were not, in order to receive payment. This opinion piece outlines
how we initially detected malicious actors, and the steps we took in order to prevent future malicious actors
from enrolling in the study. This opinion piece outlines several lessons learned that we think will be valuable
for future studies that recruit, enroll, and maintain study participants remotely.
Currently, most human-subjects data collection is
done by recruiting participants through fliers or
advertisements, and requiring that they visit the lab
over the course of the study. However, this is costly,
time-consuming, and results in decreasing subject
retention with each required visit. Moreover, data
collection in discrete time points only offers a small
window into participants’ lives and relies heavily on
participant recall between visits to complete
important behavioral and environmental data. Such
data collection is flawed and rife with assumptions
about data accuracy that may very well influence
research into disease phenotyping, prediction
analyses, and other important analyses (Areàn et al.,
2016). With the advent of personal digital technology
(e.g., fitness trackers, smartphone sensors), scientists
are now in the position to collect such information as
it happens in real time and with greater accuracy than
ever before. For example, there are is an increasing
number of studies to measure health outcomes over
the longer term.
Our project, titled Health and Injury Prediction
and Prevention Over Complex Reasoning and
Analytic Techniques Integrated on a Cellphone App
(HIPPOCRATIC App), requires just such a dataset.
The goal of this study is to develop algorithms that
enable continuous and real-time assessment of
individuals health by leveraging data that is
passively and unobtrusively captured by smartphone
sensors. While the potential medical outcomes are
positive, the potential privacy outcomes are negative
and invasive, so extraordinary care must be taken to
protect both the security and privacy of user data
throughout the data lifecycle.
To address this, we built a system to allow fully
human-out-of-the-loop management of participants
including participant recruitment, screening,
onboarding, data collection on smartphones, data
transmission to the cloud, data security in the cloud,
and data access by analysis and modeling teams
Bracken, B., Wolcott, J., Potoczny-Jones, I., Mosser, B., Griffith-Fillipo, I. and Arean, P.
Detection and Remediation of Malicious Actors for Studies Involving Remote Data Collection.
DOI: 10.5220/0010805500003123
In Proceedings of the 15th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2022) - Volume 5: HEALTHINF, pages 377-383
ISBN: 978-989-758-552-4; ISSN: 2184-4305
2022 by SCITEPRESS – Science and Technology Publications, Lda. All rights reserved
(Bracken et al., 2020). Our approach improves
privacy by allowing all stages of recruitment and
participation without human access to private or
Personally Identifying Information (PII). This
requires a human-in-the-loop process for payment
processing and support. Study participants were paid
in keeping with standards of research equipoise and
fairness. Providing incentive payments for
completing study activities is a common strategy
utilized by researchers to increase retention and
engagement with study procedures (Wurst et al.,
2020). Our Administration Dashboard allows for
anonymized information review of all information
required to address participants’ concerns including:
random unique user IDs (UUID's), surveys
completed, incoming messages, and the ability to
respond, all while preserving PII anonymity. This
includes information such as information on date and
amount of gift card delivery. However, since this is a
remote study where no human has direct contact with
any study participants, the study attracted “malicious
actors” who faked upload of data in order to access
payments. This is a common problem in research of
this nature; methods for identifying bots and
malicious actors are needed (Pozzar et al., 2020).
Our study involved recruiting participants through
social media (e.g., Facebook and Google
advertisements). Participants visited a landing page
that described the study and what participation
entailed. Participants then completed an enrollment
questionnaire. If participants were eligible to
participate, they proceeded to read the consent form,
take a short quiz to ensure they understood consent
content, and then electronically sign the form. They
were then sent a link to download our smartphone
app. The smartphone app collected data from the
smartphone sensors (e.g., accelerometer/gyroscope),
but did not access any other app data (e.g., visits to
social media sites or texts). The app also delivered a
baseline survey asking general questions such as
demographics, habits of smartphone use, and daily
routine information, as well as shorter, twice-daily
surveys asking questions about health (e.g., diagnosis
with cold or flu), activity (e.g., sleeping patterns), and
mood. Participation lasted up to 12 weeks, and
participants were paid based on how many surveys
they completed. Total potential payment for
participants was $90 (in US dollars), with payment
amount for the baseline and final (the longer surveys)
being the largest, and the remaining payments split
across the remaining surveys (twice daily for 12
weeks), increasing gradually throughout the 12
Data collection successfully kicked off with
recruiting starting March 15
, 2020 and subject
onboarding beginning immediately after that. By the
end of April, we saw over 3,000 subjects onboarded
(driven in part by positive press coverage) and over
60,000 surveys uploaded as well as the smartphone
sensor data for the participants. In May, 2020 we
continued to monitor the platform usage as the study
progressed through the first sixteen weeks of data
collection including the completion of the 12 week
study by some participants. In July, 2020, we started
to observe a significant increase in study participant
enrollment that was inconsistent with recruitment
activity. We were excited about the numbers, but we
also noticed some red flags that led to more
investigation. The analysis eventually led to the
conclusion that fraudulent participants were
attempting to game the study to illegitimately obtain
Amazon gift card incentives from the program.
Note that no systems were breached and no
data was exposed. Malicious actor activity was
limited to automation of fake users in order to
receive payments. In addition, throughout the
process, we remained in close communication with
the University of Washington’s (UW’s) Institutional
Review Board (IRB) about the fraudulent actors and
the team’s work to respond to that situation. Once
observed, we analyzed the traffic and behavior, put
models in place to help identify the malicious actors
with increasing confidence, and deployed initial
mitigation strategies. Over the course of the
remainder of the study, we refined the rules used to
detect and block these fraudulent users as well as to
refine the enrollment and payment processes.
3.1 Malicious Actor Detection
Our first indication that we had attracted malicious
actors was that although we were not running new ads
to drive recruitment and there was no additional press
coverage, the daily enrollment numbers were rising
rapidly from 50’s per day into the 100’s per day
without an explanation. Figure 1 shows registration
events from May 1
through the end of July 2020. The
large spike around May 15
was expected due to the
HEALTHINF 2022 - 15th International Conference on Health Informatics
app team having to redeploy an update to the iOS app.
The unexpected ramp in registration activity started
to become apparent in late June.
Figure 1: Registration events from May 1st to June 30th
Second, the number of registered devices (users)
that was being reported in our data tracking portal for
experimenters (which reflected data directly from the
smartphone apps) was much higher than what we
were seeing in our data storage platform, TozStore,
(which reflected true data upload metrics) by as
much as 3x. This indicated that many of these surveys
were faked. Malicious actors were calling endpoints
on the data tracking portal to indicate that a survey
was uploaded, however no survey was actually
Third, we started to see a large increase in the
number of recent Android users, which was far too
high in comparison to iOS users (initially a ratio of
2:1). Throughout the course of the study these
numbers should track relatively closely, with the ratio
of iOS to Android devices sold within the country in
which participants are recruited. Figure 2 shows iOS
vs. Android registration count divergence from the
start of data collection. Figure 3 shows iOS vs.
Android registration count divergence focusing on
June and July.
Figure 2: Number of Android and iOS devices registered
from start of data collection.
Figure 3: Number of Android and iOS devices registered in
June and July of 2020.
Fourth, our baseline survey collected city
information, which was a freeform field in the
demographics section of the questionnaire. We
analyzed this data and saw an inordinate number of
participants reporting "Los Angeles" and “Brooklyn”
as the city. This led to additional analysis of baseline
survey metadata showing scripted responses that
were repetitive and not representative of the expected
demographics. Further analysis again found that in
most cases, malicious actors did NOT upload daily
surveys, which gave us confidence that most of the
data collected was from legitimate study participants.
Fifth, we saw unusual IP traffic. Because it is very
typical for services on the Internet to see traffic from
a variety of IP addresses all over the world, and for
some of that traffic to be large-scale automated bot
traffic, the traffic itself did not raise any red flags.
However, once we started the deeper analysis we
determined much of the initial malicious actor traffic
that was gaming the platform were concentrated in a
small number of IP ranges in non-US countries that
the study was not advertised in. These IP ranges were
displaying automation-like behavior like repeated
and fast endpoint access.
Our conclusion was that due to the nature of bad-
actor activity, the large majority of actual survey
and sensor data was by legitimate study
participants. Furthermore, we were confident that
we would be able to identify and remove the bad data.
Once the malicious-actor activity was identified,
our first concern was in halting payments to these
actors while continuing to pay the legitimate study
participants acting in good faith. We paused
payments and implemented a new capability to allow
applying an exclusion list when we ran our payment
algorithm to pay participants. Once the exclusion list
was available, we ran a catch-up payments cycle
without paying the malicious actors in the exclusion
Detection and Remediation of Malicious Actors for Studies Involving Remote Data Collection
The first pass of the identification effort was
focused on identifying unique payees in order to
avoid sending incentives payments to malicious
actors. This effort also provided an initial means to
identify data that could be distinguished from the
legitimate study participants’ data that the data
analytics teams could use for their analysis.
We reviewed and tested many approaches to
detect malicious actors. We looked at baseline survey
content, time-in-study and related behavior, existence
of surveys and sensor data, registration email
domains and formats, types of sensors uploaded, etc.
The strongest indicators of malicious actors were in
cross-referencing TozStore metadata and the
smartphone app and payment data. As mentioned
above, the data for this included all users of the
system from the start of data collection; though note
that this did not rely on the use of PII, i.e., no email
addresses, location data, etc. were used. Future work
could leverage a no-human-in-the-loop, secure
compute approach to review raw GPS sensor data
from the devices. This raw GPS data was encrypted
and stored in TozStore, but due to its sensitive nature
in terms of identifying information, this sensor type
was not authorized for access by humans.
From the above efforts, an exclusion ruleset was
developed per analysis and observed vs. expected
study participation. See Exclusion Ruleset in Table 1.
We also performed basic baseline survey analysis,
though this was limited since it used information only
available in the most recent surveys (e.g., city), but
this turned out to be a good sanity check for future
approaches to identify malicious actors based on
survey responses as the small subset we identified
were also flagged by the detection rules. False
positives (not paying) are easy to correct whereas
false negatives (paying malicious actors) are not. We
paid participants using this exclusion list and then
worked at refining our ruleset to rule-in some false
positives (legitimate study participants). It should be
noted we concluded that there were likely multiple
malicious actors involved, or the same malicious
actors using multiple approaches. We did see clear
patterns of behavior from the majority of the
identified malicious actors, but there were some
behaviors unique to a smaller set of users appearing
to try to game the study.
We developed a spreadsheet model to easily apply
rules to flag users as “malicious actors.” The model
allowed for turning rules on and off to create a final
exclusion list. The rules we applied to begin payments
to participants again are shown in Table 1.
Table 1: Rules first applied.
Rule Description Notes
Reused devices detected
with repeated use of the
same UUID.
Assume fraudulent
behavior based on reusing
devices; may include some
valid users if include 2x
times (difference = 140 if
screen > 3 devices)
No baseline survey
uploaded (smartphone app
vs data storage database
Mismatch): Malicious
actor if smartphone app
received confirmation of
baseline survey
completion, but the
baseline survey is not
Indication that malicious
actors are quickly “re-
paving” devices to try
again (the user’s app
indicates the survey was
completed, but the
malicious actor started
over with a new
install/registration before
the survey was uploaded)
Long delay before
registration: Malicious
actor if user signs up
after a longer than
normal period of time
Assume they're caching
No registration date:
Malicious actor is
assumed if user is not
Likely caching registration
Table 2 shows rules that were considered, but for
which we concluded that more analysis was needed
to refine and qualify them further to increase
confidence that they were accurate.
Table 2: Rules initially considered, but not applied.
Rule Description Notes / Why They Were
Not Applied
Baseline completed
quickly (suspect data):
Malicious actor if
completion time for SID1
is < 2 min (should take 5-
10 minutes)
The results are suspect due
to very short or very long
durations in the metadata
even for automation; more
analysis is required
Participation duration
check #1 - any uploads:
Malicious actor if user
doesn't participate in the
study for more than a N
days (sans if recent
Applying this rule will
include real people who
just dropped after a short
period; “N” is
parameterized; default=7
HEALTHINF 2022 - 15th International Conference on Health Informatics
Table 2: Rules initially considered, but not applied (cont.).
Rule Description Notes / Why They Were
Not Applied
Participation duration
check #2 - surveys (similar
to above): Malicious actor
if user submits surveys
for less than N days (sans
if recent registration)
Applying this rule will
include real people who
just dropped after a short
period; “N” is
parameterized; default=7
Participation duration
check #3 - sensor data:
Malicious actor if user
loads sensor data for less
than N days (sans if
recent registration)
Data is incomplete; also,
users could initially turn
off sensor collection while
still submitting surveys &
parameterized; default=7
3.2 Malicious Actor Remediation
Once we identified malicious actors, we paused study
recruitment for 45 days while we integrated several
mitigation strategies. We then re-started the study, but
continued to integrate additional strategies as the
study progressed. Our mitigation strategies were as
First, the initial mitigations we deployed were
designed based on the initial red flags we saw that
alerted us to the malicious actors. We (1) paused
incentive payments, (2) modified the enrollment
website to pause enrollments, (3) disabled the
backend registration endpoints as we saw some
malicious actors were bypassing the website to call
the end-point directly, and (4) blocked access to all
connections from the suspicious IPs outside the
regions we advertised in.
Second, we made changes to the smartphone app
to mitigate automation of the survey fulfillment and
other gaming, including (1) updating the app to detect
rooted devices, geo location, and device emulation;
(2) detecting and blocking previously used Device
IDs, and (3) invalidating unused registration codes.
Third, we made several changes to our payment
process including modifying the secure payments
processing software to receive an exclusion list of
malicious actors to not pay. We performed dry runs
to test payment totals with and without the list of rules
initially applied (see Table 1).
Fourth, we made several modifications to our
study methods (with an university IRB and
government Human Research Protection Office
(HRPO)-approved modification in place) to prevent
future malicious actors from enrolling. (1) We first
deployed a CAPTCHA mechanism within the landing
and consent webpages to improve automated
fraudulent activity deterrence. (2) Participants were
required to provide certain information (e.g., zip
code, state, height, weight) and allow collection of
passive data from accelerometer and gyroscope
sensors. These requirements limited the ability of
malicious actors to create numerous accounts using a
single mobile device and provided more data to
inform other mitigation efforts. (3) We modified the
payment cycles to run approximately on a monthly
basis rather than weekly. This allowed us the time to
run an analysis step prior to payments processing in
order to refine the exclusion ruleset and update the
exclusion list, and to give malicious actors less time
to detect our methods and adapt. The exclusion list
generation spreadsheet also provides a list of
malicious actors that we have leveraged to separate
out the good study data from malicious actor data so
that we can share them as completely different data
sets with the data analysis teams. (4) We also reverted
to relying on the data in our primary database
(TozStore) rather than the data tracking portal
connected to the smartphone app as the source of truth
for completed surveys when calculating the payment
As expected, attempts by fraudulent participants
to game the study continued, but the mitigations
slowed them down. We monitored the effectiveness
of our combined remediation efforts as recruitment
and registration efforts ramped up. We continually
monitored registration logs as well as CAPTCHA
challenge failures. Unexpected rates of either
registration or CAPTCHA challenge failures are an
indication of malicious actor activity. The
CAPTCHA is a deterrence, but it is a statistics game,
so we expected some malicious actors to adapt and
use means to bypass the challenge (e.g., humans vs.
bots). The alerts were deployed to prompt analysis
and expansion of the IP/VPN blocklist. This is an
effective means to slow down fraudulent registrations
while the malicious actors spin up new VPNs.
We implemented an Access Control List (ACL)
mechanism using a static list of CIDR blocks (IP
address ranges) that are known to originate outside
the country of interest (in our case, outside of the
United States). This approach allows for adding
access for specific countries if the program wants to
expand outside the US (e.g., Canada, Australia, New
Zealand, etc.). We noticed that within a few hours of
enacting IP address blocks, the malicious actor traffic
transitioned to VPNs in the US. This ACL mechanism
was then also used to block all VPNs. We
investigated methods and services for automated
detection of VPNs, but as we find additional
malicious actor IP addresses and VPNs, new ones
could be easily added to the list.
Detection and Remediation of Malicious Actors for Studies Involving Remote Data Collection
There were several cases in which our exclusion rules
mis-characterized a legitimate study participant as a
malicious actor. For example, one exclusion rule
triggered when no smartphone data were uploaded to
the database, although survey data was uploaded.
However, there were instances in which the
smartphone app malfunctioned and did not upload
sensor data for legitimate study participants.
One function of the human-out-of-the-loop
participant handling approach that we developed, but
that is outside the scope of this paper (Bracken et al.,
2020) is a portal through which experimenter teams
can communicate with participants. The experimenter
sees only the random ID assigned to the participant,
but the participant receives communication within the
study application’s chat feature and/or emails through
the email address they signed up for the study with
(mapping between the two occurs in the cloud out of
reach of the human experimenters). Through this
portal using anonymous communication and case-by-
case analysis of user participant activity information,
we identified many of the mis-labelled participants
who we then re-characterized as good participants
after email exchanges. Catch up runs of incentive
payments were performed for these users and their
data was reclassified as good for use by analysis
We built a system to allow fully human-out-of-the-
loop management of patients including patient
recruitment, screening, onboarding, data collection
on smartphones, data transmission to the cloud, data
security in the cloud, and data access by analysis and
modeling teams. However, since no human has direct
contact with any study participants, the study
attracted “malicious actors” who faked upload of data
in order to access payments. We identified and put
into place mechanisms to block malicious actors. As
expected, attempts by fraudulent participants to game
the study continued, but the mitigations slowed them
However, we believe that this work to identify and
prevent malicious actors has had several positive
results. First, the lessons learned here can result in
improvement of future remotely conducted studies by
integrating these malicious actor mitigation strategies
from study initiation.
Second, it improved the study outlined here. It
caused us to closely monitor study data, which has led
to higher confidence results. It has improved dataset
quality for the data analysis teams, and reduced the
burden of dataset cleanup. The process has identified
data integrity and upload issues that otherwise would
have been missed until late in the data collection
process. These would not have been found until data
analysis teams were deeper into their analysis. In
addition, malicious actor identification and early
analysis of profiles has led to improved quality
assurance of the smartphone app used in the study.
In future studies, we will also explore integration
of additional strategies not used in this study. We can
use data that was deemed too sensitive for humans to
access (e.g., email addresses, IP addresses, GPS
location) to identify potential malicious actors. This
can be done without humans accessing the data as we
have now developed a tool for humans to apply
analysis techniques to data that may be identifiable
that is stored in the cloud, then pull down the results
of the analysis that are not identifiable. For example,
a researcher can write code that will access and search
for matching IP addresses, then only see the randomly
assigned participant IDs that have matching IP
This material is based upon work supported by United
States Air Force and DARPA under Contract No.
FA8750-18-C-0056 entitled Health and Injury
Prediction and Prevention Over Complex Reasoning
and Analytic Techniques Integrated on a Cellphone
App (HIPPOCRATIC App). The views, opinions
and/or findings expressed are those of the author and
should not be interpreted as representing the official
views or policies of the DoD or the U.S. Government.
Bracken, B.K., Potoczny-Jones, I., Wolcott, J., Raffaele, E.,
Woodward, L., Gogoel, C., Kiourtis, N., Schulte, B.,
Arean, P.A., and Farry, M. Development of Human-
Out-of-the-Loop Participant Recruitment, Data
Collection, Data Handling, and Participant
Management System. Proceedings of the Annual
International Human Factors and Ergonomics Society,
October 5-10, 2020.
Pozzar, R., Hammer, M. J., Underhill-Blazey, M., Wright,
A. A., Tulsky, J. A., Hong, F., Gundersen, D. A., &
Berry, D. L. (2020). Threats of bots and other bad actors
to data quality following research participant
HEALTHINF 2022 - 15th International Conference on Health Informatics
recruitment through social media: Cross-sectional
questionnaire. Journal of Medical Internet Research,
22(10), e23021.
Wurst, R., Maliezefski, A., Ramsenthaler, C., Brame, J., &
Fuchs, R. (2020). Effects of Incentives on Adherence to
a Web-Based Intervention Promoting Physical
Activity: Naturalistic Study. Journal of Medical
Internet Research, 22(7), e18338.
Detection and Remediation of Malicious Actors for Studies Involving Remote Data Collection
