Hyperparameter Optimization in NLP Architectures

Noureddine Ettaik

, Ben Lahmar El Habib

Laboratory for Information Processing and Modeling, Hassan II University of Casablanca, Faculty of Sciences Ben M’sik,

BP 7955, Sidi Othman, Casablanca, Morocco

Keywords: Natural Language processing, Hyperparameter optimization, Survey

Abstract: Hyperparameter optimization (HPO) is an essential part of setting up efficient machine learning models

dealing with natural language processing (NLP) tasks, especially with the recent NLP breakthroughs. In this

paper, we explore the problem of HPO through a survey conducted on a selected number of academic

publications in NLP by studying the strategy used for the optimization of their hyperparameters and by

investigating their common traits. We then lay out some recommendations for good practice in NLP HPO.

1 INTRODUCTION

As data grows in size and complexity, algorithms

processing it are getting more complex, especially

when dealing with natural language processing NLP

tasks. A significant component of this complexity

stems from the optimization process of

hyperparameters.

Hyperparameter optimization is mainly done

manually (Hinton 2012) or by testing a predefined set

of hyperparameters in a grid (Pedregosa et al. 2011),

or by exploring the search space and randomly

selecting the optimal hyperparameters (Bergstra and

Bengio 2012). More sophisticated techniques have

made their appearance (Claesen and De Moor 2015)

and were applied to HPO like the Bayesian

optimization (Swersky, Snoek, and Adams 2013;

Zhang et al. 2016; Klein et al. 2017; Bergstra et al.

2015; Feurer et al. 2015), the evolutionary algorithms

(Young et al. 2015), heuristics inspired algorithms like

simulated annealing, particle swarm optimization (Ye

2017) and ant colony optimization (Costa and

Rodrigues 2018).

Deep learning models share a multitude of their

models’ hyperparameters, but when dealing with a

specific task like in NLP with specific architectures

like RNNs and LSTMs, or more recent transformer-

based ones, generalizations cannot be easily made,

and the optimization becomes more task-specific. In

this context, hyperparameters tend to behave

https://orcid.org/0000-0001-8523-1227

https://orcid.org/0000-0001-7098-4621

according to the task at hand and the probability of

generalization among models dealing with NLP is

higher in the same architecture.

In this paper, we inquire into the use of

hyperparameter optimization in natural language

processing by investigating a group of papers in the

domain, we try to spot the techniques used to optimize

these hyperparameters as well as the tools used to tune

them, we also try to find any pattern related to the most

important and useful hyperparameters and set them

apart from the less useful ones. We finally set a list of

recommendations regarding the use of

hyperparameter optimization in the context of NLP.

2 STUDIES OVERVIEW

The studies selected for this paper are a result of

research in academic databases based on an adapted

search equation, a study selection was applied on the

resulting papers (inclusion and exclusion criteria).

They are highly cited papers in the domain of NLP

dealing with hyperparameter optimization and

published in highly respected journals and

conferences in the domain of artificial intelligence.

We describe below the major highlights of HPO in

NLP displayed in each study.

In (Melis, Dyer, and Blunsom 2017), the focus is

on language modelling architectures like LSTMs,

RHN (Recurrent highway network) (Zilly et al. 2017)

466

Ettaik, N. and El Habib, B.

Hyperparameter Optimization in NLP Architectures.

DOI: 10.5220/0010736600003101

In Proceedings of the 2nd International Conference on Big Data, Modelling and Machine Learning (BML 2021), pages 466-470

ISBN: 978-989-758-559-3

and NAS (Neural architecture search) (Zoph and Le

2017), the HPO is performed on Google vizier

(Golovin et al. 2017), which is a black box

hyperparameter optimization tool. Based on the

results of this Automl tuner and the validation loss, the

authors plotted these results against each other, which

showed that 15 %to 25% of the hyperparameter space

is promising, a comparable grid search yielding the

same results, would have taken too much time and

trials as the authors stated.

In (Aghaebrahimian and Cieliebak 2019), an ad

hoc search was used to tune the hyperparameters of a

model over a limited budget for a text classification

task. Certain hyperparameters had an impact on the

model, while others had none.

For the same task, we can see that the authors in

(Tellez et al. 2017), tackle the task of text

categorization in a supervised learning layout, the

process of optimization was carried out by first

performing a combination of a random search and a

hill-climbing algorithm, in other words, the RS spots

randomly some promising areas of the hyperparameter

space and then the hill-climbing algorithm is

initialized using those promising points by greedily

updating them till no improvement is possible.

The task of linguistic sequence tagging is

investigated in (Reimers and Gurevych 2017) using

deep LSTM-Networks, the study shows that

hyperparameters have different impacts on the model.

For example, the choice of embeddings and the

dropout mechanism have a considerable leverage on

the result. Also, the hyperparameters tend to influence

each other, which means if an initial search yielded an

excellent performance, the global optima might be

hidden down the line of further HP combinations.

In (Dernoncourt and Lee 2016), the task at hand is

based on dialog act classification, more precisely

assigning a dialog act to each utterance, and the model

is based on an ANN architecture. The

hyperparameters are optimized using Gaussian

process GP (a Bayesian optimization inspired

approach), which proved to be four times better than

the uninformed random search. That GP search result

is highly impacted by the initial random points.

The task at hand In (Wang et al. 2015) is

classification and question answering, and the

optimization of hyperparameters is done based on

Bayesian optimization but with a multi-stage approach

allowing for the HPO to take place in successive

stages in a sequential fashion while increasing the

amount of data being trained. The optimization starts

with a small amount of data being trained in the early

stages and keeps improving according to the

promising candidate hyperparameters, a full Bayesian

optimization is applied based on these candidates to

allow for a convergence based on a better prior

knowledge.

The transformer architecture with self-attention

introduced in (Vaswani et al. 2017) experimented on

machine translation, and the hyperparameters were set

after multiple experimentations on different values

(No mention of a particular technique of

optimization), especially the optimizer and its

parameters, the regularization (residual dropout,

attention drop out and label smoothing) and the

learning rate which underwent an increase according

to a formula with warmup step of 4000.

In (Devlin et al. 2019), another transformer-based

architecture paper with an outcome of a state of the art

pre-trained model (BERT), the tasks it tackles are

question answering and language understanding. For

this type of model, transfer learning can be applied

with minor hyperparameter tuning; in fact; the

optimization can take place using the majority of the

pre-trained model hyperparameter values and use a

recommended range of values for the remaining

hyperparameters (dropout, batch size, learning rate

and epochs) even with tasks different than the original

tasks of the model.

3 HYPERPARAMETERS

PATTERN IN NLP

In table 1, we lay down the pattern we detected in the

studies, which showcases the hyperparameter

optimization HPO used, and the NLP specified

task(s).

Table 1: HPO techniques in NLP and tasks by study.

Stud

Techni

ue NLP tas

(Dernoncourt

and Lee 2016)

Bayesian opt

by gaussian

rocess

Dialog act

classification

(Caselles-Dupré

et al. 2018)

Manual

Natural Language

Processing tasks

and

Recommendation

tasks (word to

vec: embeddin

)

(Tellez et al.

2017)

Random

Search then

Hill-Climbing

Text

classification

(topic and

polarity

classification,

spam detection,

user profiling and

authorship

attribution

)

Hyperparameter Optimization in NLP Architectures

467

(Wang et al.

2015)

Multi-stage

Bayesian

optimization

Sentiment

classification and

QA tasks

(Aghaebrahimian

and Cieliebak

2019)

Ad hoc grid

Multi-label text

classification task

(Reimers and

Gurevych 2017)

NA Linguistic

sequence tagging

(POS, Chunking,

NER, Entity

Recognition, and

Event

Detection

)

(Devlin et al.

2019)

NA Question

Answering;

natural language

understanding

(Vaswani et al.

2017)

HP set with

expertise and

optimization

with a

formula (for

)

Machine

translation

4 HPO STRATEGIES

The strategy of hyperparameter optimization adopted

depends on the task at hand, the available resources

and the dataset complexity. The Bayesian

optimization proves to be efficient but is very

expensive; thus performing a multi-stage BO can

yield better and faster results (Wang et al., 2015). Its

variant; the gaussian process; proves to be faster than

random search in dialog act classification

(Dernoncourt & Lee, 2016), when using simple

heuristics may not find optimal hyperparameters well.

When dealing with multilabel text classification

tasks, the degree of impact of the HP is not the same,

and some have no impact at all on the model; for

example in (Aghaebrahimian & Cieliebak, 2019;

Reimers & Gurevych, 2017), the combination of

glove embedding type, Sigmoid for last layer, bi GRU

deep architecture, Nadam as optimizer, pooling with

both max and average concatenated, normalization

for Gradient control and dropout set to variational

proved to be the optimal set of HP for the task.

In tasks related to linguistic sequence tagging, the

combination of the optimizer Nadam with a gradient

normalization threshold of 1, a variational dropout,

recurrent units of LSTM layer and a CRF classifier

(Reimers & Gurevych, 2017). Relying on full Automl

search may be counterproductive as an HPO strategy

since it could be greedy. A simple combination with

a manual approach (Melis et al., 2017), for example,

a plot between promising hyperparameters and

validation loss could produce optimal results.

For machine translation tasks, and under a

transformer architecture (Vaswani et al., 2017)

recommend choosing specific hyperparameter

values, namely Adam as optimizer, a learning rate

that is variant according to the warm-up steps, which

start at 4000, a residual dropout rate of 0.1 and a label

smoothing of 0.1. in the same transformer

environment but with a bidirectional variant and a

different task based on Question Answering and

natural language understanding (Devlin et al., 2019)

recommend setting dropout probability to 0.1, batch

size to16 or 32, learning rate (Adam) to 5e-5, 3e-5 or

2e-5 and epochs to 2, 3 or 4.

5 ANALYSIS AND DISCUSSION

NLP tasks are becoming more and more demanding,

and the need for optimization grows more important

than ever. Meanwhile, hyperparameter optimization

algorithms and techniques have recently proven to be

very efficient, especially with the rise of automated

machine learning applications, and if used efficiently,

could improve the state-of-the-art models and bypass

the budget and time constraints.

Not all hyperparameters have the same impact on

the models, and the nature of NLP tasks favours

parameters like the word embeddings type, the

dropout rate and the optimizer, which are more

impactful than others, thus making the tuning of the

latter useless in most cases.

HPO is becoming as compulsory as choosing the

model itself for NLP tasks. Researchers and

practitioners alike should invest more time and effort

to optimize their models using the available

techniques.

A combination of automatic HPO based mostly on

a sophisticated approach like the Bayesian technique

coupled with a rule of thumb like a plot comparison

between the initial HPO and the loss, a warm start, or

an early stopping is the most efficient since a

complete search is always greedy in resources.

The availability of pre-trained models like BERT

(Devlin et al., 2019), ELMO (Peters et al., 2018) and

others allows for a minimal hyperparameter

optimization that doesn’t involve a huge search space

and can be applied across a wide array of NLP tasks.

Applying different HPO techniques on NLP

models may be time-consuming or expensive for

some tasks, especially with big datasets, but their use

proves to be effective when the sweet spot of optimal

values is reached, especially with the use of pre-

BML 2021 - INTERNATIONAL CONFERENCE ON BIG DATA, MODELLING AND MACHINE LEARNING (BML’21)

468

trained models since they are highly effective in the

field of NLP, and the tasks in the domain are recurrent

and repetitive and deal with a homogenous entity

which is language. Meaning that the hyperparameters

that are optimal in a big model will very likely yield

the same results in smaller tasks with the same nature.

6 CONCLUSIONS

This paper provides an insight into good practices in

hyperparameter optimization in natural language

processing related tasks. We found out that there are

common traits in the optimization process of

hyperparameters and that some particular HPO

techniques work well with certain tasks. Also, the

values reported in this paper from certain studies can

be reproduced in similar tasks. The recent

developments in transformer architectures, have

paved the way for optimal models down the line by

means of transfer learning, which benefits ultimately

the hyperparameter optimization in NLP.

REFERENCES

Moore, R., Lopes, J., 1999. Paper templates. In

TEMPLATE’06, 1st International Conference on

Template Production. SCITEPRESS.

Smith, J., 1998. The book, The publishing company.

London, 2

edition.

Aghaebrahimian, Ahmad, and Mark Cieliebak. 2019.

“Hyperparameter Tuning for Deep Learning in Natural

Language Processing,” 7.

Bergstra, James, and Yoshua Bengio. 2012. “Random

Search for Hyper-Parameter Optimization,” 25.

Bergstra, James, Brent Komer, Chris Eliasmith, Dan

Yamins, and David D Cox. 2015. “Hyperopt: A Python

Library for Model Selection and Hyperparameter

Optimization.” Computational Science & Discovery 8

(1): 014008. https://doi.org/10.1088/1749-

4699/8/1/014008.

Caselles-Dupré, Hugo, Florian Lesaint, and Jimena Royo-

Letelier. 2018. “Word2Vec Applied to

Recommendation: Hyperparameters Matter.”

ArXiv:1804.04212 [Cs, Stat], August.

http://arxiv.org/abs/1804.04212.

Claesen, Marc, and Bart De Moor. 2015. “Hyperparameter

Search in Machine Learning.” ArXiv:1502.02127 [Cs,

Stat], April. http://arxiv.org/abs/1502.02127.

Costa, Victor O., and Cesar R. Rodrigues. 2018.

“Hierarchical Ant Colony for Simultaneous Classifier

Selection and Hyperparameter Optimization.” In 2018

IEEE Congress on Evolutionary Computation (CEC),

1–8. Rio de Janeiro: IEEE.

https://doi.org/10.1109/CEC.2018.8477834.

Dernoncourt, Franck, and Ji Young Lee. 2016. “Optimizing

Neural Network Hyperparameters with Gaussian

Processes for Dialog Act Classification.” In 2016 IEEE

Spoken Language Technology Workshop (SLT), 406–

13. San Diego, CA: IEEE.

https://doi.org/10.1109/SLT.2016.7846296.

Devlin, Jacob, Ming-Wei Chang, Kenton Lee, and Kristina

Toutanova. 2019. “BERT: Pre-Training of Deep

Bidirectional Transformers for Language

Understanding.” ArXiv:1810.04805 [Cs], May.

http://arxiv.org/abs/1810.04805.

Feurer, Matthias, Aaron Klein, Katharina Eggensperger,

Jost Tobias Springenberg, Manuel Blum, and Frank

Hutter. 2015. “Efﬁcient and Robust Automated

Machine Learning,” 9.

Golovin, Daniel, Benjamin Solnik, Subhodeep Moitra,

Greg Kochanski, John Karro, and D. Sculley. 2017.

“Google Vizier: A Service for Black-Box

Optimization.” In Proceedings of the 23rd ACM

SIGKDD International Conference on Knowledge

Discovery and Data Mining - KDD ’17, 1487–95.

Halifax, NS, Canada: ACM Press.

https://doi.org/10.1145/3097983.3098043.

Hinton, Geoffrey E. 2012. “A Practical Guide to Training

Restricted Boltzmann Machines.” In Neural Networks:

Tricks of the Trade, edited by Grégoire Montavon,

Geneviève B. Orr, and Klaus-Robert Müller, 7700:599–

619. Lecture Notes in Computer Science. Berlin,

Heidelberg: Springer Berlin Heidelberg.

https://doi.org/10.1007/978-3-642-35289-8_32.

Klein, Aaron, Stefan Falkner, Simon Bartels, Philipp

Hennig, and Frank Hutter. 2017. “Fast Bayesian

Hyperparameter Optimization on Large Datasets.”

Electronic Journal of Statistics 11 (2): 4945–68.

https://doi.org/10.1214/17-EJS1335SI.

Komninos, Alexandros, and Suresh Manandhar. 2016.

“Dependency Based Embeddings for Sentence

Classification Tasks.” In Proceedings of the 2016

Conference of the North American Chapter of the

Association for Computational Linguistics: Human

Language Technologies, 1490–1500. San Diego,

California: Association for Computational Linguistics.

https://doi.org/10.18653/v1/N16-1175.

Melis, Gábor, Chris Dyer, and Phil Blunsom. 2017. “On the

State of the Art of Evaluation in Neural Language

Models.” ArXiv:1707.05589 [Cs], November.

http://arxiv.org/abs/1707.05589.

Pedregosa, Fabian, Gael Varoquaux, Alexandre Gramfort,

Vincent Michel, Bertrand Thirion, Olivier Grisel,

Mathieu Blondel, et al. 2011. “Scikit-Learn: Machine

Learning in Python.” MACHINE LEARNING IN

PYTHON, 6.

Peters, Matthew E., Mark Neumann, Mohit Iyyer, Matt

Gardner, Christopher Clark, Kenton Lee, and Luke

Zettlemoyer. 2018. “Deep Contextualized Word

Representations.” ArXiv:1802.05365 [Cs], March.

http://arxiv.org/abs/1802.05365.

Reimers, Nils, and Iryna Gurevych. 2017. “Optimal

Hyperparameters for Deep LSTM-Networks for

Hyperparameter Optimization in NLP Architectures

469

Sequence Labeling Tasks.” ArXiv:1707.06799 [Cs],

August. http://arxiv.org/abs/1707.06799.

Rijn, J. N. van, and F. Hutter. 2018. “Hyperparameter

Importance Across Datasets.” Proceedings of the 24th

ACM SIGKDD International Conference on

Knowledge Discovery & Data Mining - KDD ’18,

2367–76. https://doi.org/10.1145/3219819.3220058.

Swersky, Kevin, Jasper Snoek, and Ryan P Adams. 2013.

“Multi-Task Bayesian Optimization,” 9.

Tellez, Eric S., Daniela Moctezuma, Sabino Miranda-

Jímenez, and Mario Graff. 2017. “An Automated Text

Categorization Framework Based on Hyperparameter

Optimization.” ArXiv:1704.01975 [Cs, Stat],

September. http://arxiv.org/abs/1704.01975.

Vaswani, Ashish, Noam Shazeer, Niki Parmar, Jakob

Uszkoreit, Llion Jones, Aidan N. Gomez, Lukasz

Kaiser, and Illia Polosukhin. 2017. “Attention Is All

You Need.” ArXiv:1706.03762 [Cs], December.

http://arxiv.org/abs/1706.03762.

Wang, Lidan, Minwei Feng, Bowen Zhou, Bing Xiang, and

Sridhar Mahadevan. 2015. “Efficient Hyper-Parameter

Optimization for NLP Applications.” In Proceedings of

the 2015 Conference on Empirical Methods in Natural

Language Processing, 2112–17. Lisbon, Portugal:

Association for Computational Linguistics.

https://doi.org/10.18653/v1/D15-1253.

Wistuba, Martin, Nicolas Schilling, and Lars Schmidt-

Thieme. 2015. “Learning Data Set Similarities for

Hyperparameter Optimization Initializations.” In

Metasel@ Pkdd/Ecml, 15–26.

Ye, Fei. 2017. “Particle Swarm Optimization-Based

Automatic Parameter Selection for Deep Neural

Networks and Its Applications in Large-Scale and

High-Dimensional Data.” Edited by Wen-Bo Du.

PLOS ONE 12 (12): e0188746.

https://doi.org/10.1371/journal.pone.0188746.

Young, Steven R., Derek C. Rose, Thomas P. Karnowski,

Seung-Hwan Lim, and Robert M. Patton. 2015.

“Optimizing Deep Learning Hyper-Parameters through

an Evolutionary Algorithm.” In Proceedings of the

Workshop on Machine Learning in High-Performance

Computing Environments - MLHPC ’15, 1–5. Austin,

Texas: ACM Press.

https://doi.org/10.1145/2834892.2834896.

Zhang, Yuyu, Mohammad Taha Bahadori, Hang Su, and

Jimeng Sun. 2016. “FLASH: Fast Bayesian

Optimization for Data Analytic Pipelines.” In

Proceedings of the 22nd ACM SIGKDD International

Conference on Knowledge Discovery and Data Mining

- KDD ’16, 2065–74. San Francisco, California, USA:

ACM Press. https://doi.org/10.1145/2939672.2939829.

Zilly, Julian Georg, Rupesh Kumar Srivastava, Jan

Koutník, and Jürgen Schmidhuber. 2017. “Recurrent

Highway Networks.” ArXiv:1607.03474 [Cs], July.

http://arxiv.org/abs/1607.03474.

Zoph, Barret, and Quoc V. Le. 2017. “Neural Architecture

Search with Reinforcement Learning.”

ArXiv:1611.01578 [Cs], February.

http://arxiv.org/abs/1611.01578.

BML 2021 - INTERNATIONAL CONFERENCE ON BIG DATA, MODELLING AND MACHINE LEARNING (BML’21)

470
