A Critical Review on Concept Drift Monitoring Process for Class

Imbalance in Data Streams

Nouhaila Aasoum

, Ismail Jellouli and Souad Amjad

Computer Science and Systems Engineering Laboratory, Abdelmalek Essaadi University, Tetouan, Morocco

Keywords: Machine learning, online learning, concept drift, class imbalance, non-stationary environment.

Abstract: Machine learning techniques have participated in world evolution. They have accomplished worthy goals in

many areas such as banking, industry, cybersécurité, and many others. However, in most data analysis

applications, data comes in streams based on online learning scenarios. As streams emerge and change quickly

over time, it will be hard to store them in memory. Thus, the analysis has become a real challenge to mitigate

using traditional approaches. The change in data distribution degrades the accuracy performance of the trained

model and becomes inefficient. This phenomenon is called concept drift, where the model must adapt quickly

to these changes, including those in the environment, trends, or behaviour, to maintain their accuracy. Another

phenomenon commonly exists in real-world applications is a class imbalance, when data distribution changes

within classes. Thus, the model will favor the majority class and ignores the minority one. The problem

becomes more challenging when both of them co-exist. Therefore, a few studies addressed this research gap.

The objective is to detect concept drift with class imbalance for enhanced performance in a non-stationary

data environment. This study will focus on class imbalance handling techniques, and concept drift effects in

decreasing model performance, and some methods to detect concept drift while existing class imbalance issue.

1 INTRODUCTION

Learning from streaming data is an emerging topic

that has received much attention in the last decades.

In many machine learning applications, data is

generated instantly over time without storing it as

static data. Thus, we have to use a real-time dataset to

build a suitable online classifier that maintains its

performance in non-stationary environments.

The non-stationary environment is characterized

by newly emerged samples of data, representing the

minority portion of the entire dataset. The minority

class contains a few instances, while those instances

can be essential for the trained model.

However, this model focuses on the majority class

and ignores the minority one. Training from such

imbalanced streaming data is called online class

imbalance (S. Wang et al., 2013).

For example, figure 1 illustrates class imbalance

for spam email filtering, where the non-spam email

presents the majority class, while the spam email

shows the minority class from the entire dataset.

https://orcid.org/0000-0002-7283-6785

Another challenging problem is concept drift that

degrades the model accuracy and makes it unsuitable

because of the changes in the data distribution.

The model needs to adapt quickly to such changes

if any features or classes emerge in the data. The

concept drift becomes a severe issue when the

changes affect sample features and class numbers

simultaneously. Thus, it becomes hard to handle it.

When class imbalance and concept drift coincide,

the problem will be more challenging because one

issue can affect the treatment of the other, especially

in online scenarios.

2 CLASS IMBALANCE

MANAGED TECHNIQUES

The class imbalance issue has received much

attention recently. Many state-of-the-art propose

techniques in this research gap for both stationary and

non-stationary environments to handle it by focusing

404

Aasoum, N., Jellouli, I. and Amjad, S.

A Critical Review on Concept Drift Monitoring Process for Class Imbalance in Data Streams.

DOI: 10.5220/0010735500003101

In Proceedings of the 2nd International Conference on Big Data, Modelling and Machine Learning (BML 2021), pages 404-408

ISBN: 978-989-758-559-3

on data preprocessing, algorithmic, and ensemble

learning approaches.

2.1 Data Preprocessing Approaches

Resampling is a preprocessing technique that is used

before training the model in real-time.

The objective is to maintain the number of

instances for each category to benefit from the

ignored category distributions. It works

autonomously with the learning algorithm at the data

level (S. Wang et al., 2015). The principal used types

of resampling are oversampling and undersampling.

Oversampling-based Online Bagging (OOB) (S.

Wang et al., 2015) is a technique that increases the

minority class. Undersampling-based Online

Bagging (UOB) (S. Wang et al., 2015) is a technique

that decreases the majority class. While relatively,

each has significant shortcomings: (UOB) ignores

data from the majority class, whether this data is

necessary or not. (OOB) generates exact samples

from the minority class, which may produce

overfitting in the classifier (Ditzler & Polikar, 2010).

(Chawla et al., 2002) have proposed synthetic

Minority Oversampling Technique (SMOT). It is an

oversampling method that generates new samples

from the minority class, depending on the features of

the nearest neighbours. Thus, SMOT maintains the

accuracy of the minority class in classification tasks

compared to other approaches. There are different

used techniques like random oversampling and

random undersampling.

2.2 Algorithmic and Ensemble

Approaches

Ensemble approaches manage the issue of

imbalanced class differently. They focus on

increasing the accuracy of the minority category by

updating some training mechanisms.

(J. Wang et al., 2012), and (Ghazikhani et al.,

2013) proposed online cost-sensitive learning

methods CSOGD, RLSACP, respectively. They

misclassified the cost of the algorithm and made him

capable of favouring the minority class.

Additionally, there is an ensemble learning

approach based on multiple classifiers. It combines

the classification of various classifiers and trains them

individually. Bagging or bootstrap aggregating (Oza

& Russell, 2001) uses an ensemble-based approach

by combining multiple classifiers to improve the

model accuracy. In bagging, we can mitigate the

imbalance by generating more test data. Boosting is

another approach based on ensemble classifier, the

procedure in this method is different. In boosting, we

give much importance to the minority class. Where

taking a subset from the entire dataset

misclassifies the samples.

Generally, bagging reaches to reduce the model

variance while boosting reaches for improving the

model accuracy.

Figure 1: Imbalanced data in spam email filtering.

3 CONCEPT DRIFT TAXONOMY

Data comes from the same source distribution in

stationary environments, but in real-world

applications, data comes from different sources and

arises concept drift phenomenon when existing online

learning scenarios. This issue can directly affect the

accuracy of the trained model and decrease their

performance in classification or prediction results.

In principle, for supervised tasks, the model needs

inputs and outputs features from the data. However,

these features can change, or classes number can

increase over time. Thus, we have to separate

between virtual and real concept drift. The equation

below shows the Bayesian decision theory (Jameel et

al., 2020).

P(c/X) = P(c) P(X/c) / P(X)

)

Where posterior, prior, conditional, and feature-

based probabilities are P(c/X), P(c), P(X/c), and P(X),

respectively (Jameel et al., 2020). Real drift mentions

the P(c/X) changes that affect the probability of a

class label and given features. This change can

decrease the accuracy of the classifier and affects

decision boundaries. (Wares et al., 2019).

Alternatively, virtual drift refers to P(X) changes

only. In this state, the distribution has changed

without affecting the classifier's decision limits.

(Wares et al., 2019). For the Hybrid drift, the changes

A Critical Review on Concept Drift Monitoring Process for Class Imbalance in Data Streams

405

affect P(X) and P(c/X) simultaneously. Figure 2

shows the differences between drift types:

Figure 2: Concept drift types.

However, concept drift has a different configuration

pattern occurrence within the data streams over time.

Abrupt: When the change occurs suddenly, in

this case, another target can replace the main one.

Incremental: The changes are relatively, and

they may take a lot of time to compare.

Gradual: In this type, the change is replaced

progressively from an interest to another one and can

be tracked over a long time. The gradual drift is the

most challenging type to detect. For example, when a

sensor is becoming old and not providing correct

outputs in a suitable time. (Gözüaçık & Can, 2020).

Re-Occurring: This type of drift is concerned

with seasonal changes that can revert after a few

times. Moreover, this matter occurs when there is

demand for a particular thing or event during the year

or month. Figure 3 illustrates all configuration

patterns of concept drift.

Figure 3: Concept drift configuration patterns.

4 APPROACHES TO DETECT

CONCEPT DRIFT WITH CLASS

IMBALANCE

A few detection methods have been submitted to

detect concept drift for class imbalance in online

scenarios through the existing studies.

(S. Wang et al., 2013) proposed Drift Detection

Method for Online Class Imbalance DDM-OCI is a

helpful technique for handling drift in the minority

class, based on tracking his recall. At the same time,

it is a more robust and suitable technique for

imbalanced data streams.

(H. Wang, 2015) proposed another method is the

Linear Four Rate (LFR). It is an improvement

approach for DDM-OCI. LFR is capable of detecting

drift with the best recall and few false alarms. Its

controls the four rates; precision and recall for both

the minority and the majority class.

This study (Mirza et al., 2015) proposed

Ensemble of Subset Online Sequential Extreme

Learning Machine (ESOS-ELM). It is an ensemble-

based technique that works for non-stationary

environments. In ESOS-ELM, a single classifier

processed a majority class instance, while multiple

classifiers process the minority class. In this case,

classifiers learned from balanced subsets of the

original dataset that is imbalanced.

Page-Hinkley (PH) (Brzezinski & Stefanowski,

2015) proposed drift detecting, especially for the

abrupt one, addressed for the binary imbalance issue

only. A recent drift detector submitted from

multiclass imbalanced data streams in this study

(Krawczyk, 2021), based on Restricted Boltzmann

Machine (RBM-IM) notify if any data is drifting. It is

capable of training itself dynamically and detects the

drift at a local and global level. RBM- IM can manage

the changes in minority class without being biased

towards the majority one.

CALMID is a comprehensive active learning

method using for multiclass imbalanced where

existing concept drift, proposed by (Liu et al., 2021).

It’s a recent approach based on an ensemble classifier.

CALMID considers the multiclass imbalance ratio as

unbiased. When the sensor reports any drift, a new

classifier will be generated and initialized by the

existing weighted at the initialization training (Liu et

al., 2021). Thus, it is a suitable approach when

concept drift and multiclass imbalance co-exist.

5 COMPARATIVE STUDY

This section presents a comparative study of different

detector approaches for imbalanced data streams in

various studies. The comparative analysis is based on

the effectiveness of detecting several types of drifts

with the imbalanced class issue.

BML 2021 - INTERNATIONAL CONFERENCE ON BIG DATA, MODELLING AND MACHINE LEARNING (BML’21)

406

Table 1: Comparison of concept drift detection approaches for imbalanced data streams.

Method

Class imbalance Multiclass Drift t

pe Ref

DDM-OCI

X X

Real drift

(S. Wang et

al., 2013)

LFR

X X

Real drift

(H. Wang,

2015)

X X

Real drift

(Brzezinsk &

Stefanowski,

2015)

ESOS-ELM



Real drift, Virtual

drif

(Mirza et al.,

2015)

RBM-IM

 

Real, Virtual and

brid drif

(Krawczyk,

2021)

CALMID

 

Real, Virtual and

brid drif

(Liu et al.,

2021)

6 CONCLUSION

This paper has discussed concept drift with class

imbalance for online learning, focusing on class

imbalance mitigating techniques. We can state that

class imbalance handling techniques are still not

applicable for concept drift detection through the

existing studies. Then we have talked about the most-

used methods for concept drift detection for

imbalanced data streams.

According to the literature, a few studies have

been proposed when both issues co-exist. In addition,

this is due to the difficulty that they arise in online

scenarios. The majority of proposed methods do not

cover all concept drift types (virtual drift, real drift,

and hybrid drift).

Thus, there is no one method for all in this

research gap. We can conclude that concept drift

detection approaches need to be more adaptive and

applicable with their different types, mainly when it

comes to online scenarios where data change by its

nature.

REFERENCES

Brzezinski, D., & Stefanowski, J. (2015). Prequential AUC

for classifier evaluation and drift detection in evolving

data streams. Lecture Notes in Artificial Intelligence

(Subseries of Lecture Notes in Computer Science),

8983, 87–101. https://doi.org/10.1007/978-3-319-

17876-9_6

Chawla, N. V., Bowyer, K. W., Hall, L. O., & Kegelmeyer,

W. P. (2002). SMOTE: Synthetic minority over-

sampling technique. Journal of Artificial Intelligence

Research, 16(February 2017), 321–357.

https://doi.org/10.1613/jair.953

Ditzler, G., & Polikar, R. (2010). An ensemble based

incremental learning framework for concept drift and

class imbalance. Proceedings of the International Joint

Conference on Neural Networks, August.

https://doi.org/10.1109/IJCNN.2010.5596764

Ghazikhani, A., Monsefi, R., & Sadoghi Yazdi, H. (2013).

Recursive least square perceptron model for non-

stationary and imbalanced data stream classification.

Evolving Systems, 4(2), 119–131.

https://doi.org/10.1007/s12530-013-9076-7

Gözüaçık, Ö., & Can, F. (2020). Concept learning using

one-class classifiers for implicit drift detection in

evolving data streams. Artificial Intelligence Review,

0123456789. https://doi.org/10.1007/s10462-020-

09939-x

Jameel, S. M., Hashmani, M. A., Alhussain, H., Rehman,

M., & Budiman, A. (2020). A critical review on adverse

effects of concept drift over machine learning

classification models. International Journal of

Advanced Computer Science and Applications, 11(1),

206–211.

https://doi.org/10.14569/ijacsa.2020.0110127

Krawczyk, B. (2021). Concept Drift Detection from Multi-

Class Imbalanced Data Streams. April.

Liu, W., Zhang, H., Ding, Z., Liu, Q., & Zhu, C. (2021). A

comprehensive active learning method for multiclass

imbalanced data streams with concept drift.

Knowledge-Based Systems, 215, 106778.

https://doi.org/10.1016/j.knosys.2021.106778

Mirza, B., Lin, Z., & Liu, N. (2015). Ensemble of subset

online sequential extreme learning machine for class

imbalance and concept drift. Neurocomputing, 149(Part

A), 316–329.

https://doi.org/10.1016/j.neucom.2014.03.075

Oza, N. C., & Russell, S. (2001). Experimental

comparisons of online and batch versions of bagging

and boosting. Proceedings of the Seventh ACM

SIGKDD International Conference on Knowledge

Discovery and Data Mining, 359–364.

A Critical Review on Concept Drift Monitoring Process for Class Imbalance in Data Streams

407

https://doi.org/10.1145/502512.502565

Wang, H. (2015). Concept Drift Detection for Streaming

Data t The three user defined parameters are the time

decaying.

Wang, J., Zhao, P., & Hoi, S. C. H. (2012). Cost-sensitive

online classification. Proceedings - IEEE International

Conference on Data Mining, ICDM, 1140–1145.

https://doi.org/10.1109/ICDM.2012.116

Wang, S., Minku, L. L., Ghezzi, D., Caltabiano, D., Tino,

P., & Yao, X. (2013). Concept drift detection for online

class imbalance learning. Proceedings of the

International Joint Conference on Neural Networks.

https://doi.org/10.1109/IJCNN.2013.6706768

Wang, S., Minku, L. L., & Yao, X. (2015). Resampling-

based ensemble methods for online class imbalance

learning. IEEE Transactions on Knowledge and Data

Engineering, 27(5), 1356–1368.

https://doi.org/10.1109/TKDE.2014.2345380

Wares, S., Isaacs, J., & Elyan, E. (2019). Data stream

mining: methods and challenges for handling concept

drift. SN Applied Sciences, 1(11), 1–19.

https://doi.org/10.1007/s42452-019-1433-0

BML 2021 - INTERNATIONAL CONFERENCE ON BIG DATA, MODELLING AND MACHINE LEARNING (BML’21)

408
