Revolutionary Direction of Secured Supercomputer Technologies

Development in Russia

Andrey S. Molyakov

Innstitute of IT and Сybersecurity, Russian State University for the Humanities, Moscow, Russia

Keywords: J7, J10, Project "Angara", BNW-network.

Abstract: The article describes a promising project for the development of secured strategic supercomputer "Angara",

which is a set of nodes of different types, united by several communication networks. The service nodes are

built on conventional superscalar microprocessors. Computing nodes are built on special multicore

multithread-stream microprocessors (microprocessors of the J series), are combined into modules in the form

of multi-socket boards, and can work on a logically single addressable memory (globally addressable

memory) formed by local memories of modules with computational nodes. There are two models of J series

microprocessors: the younger one is J7, the older one is J10. Further, the characteristics and principles of

operation of the younger model J7 are considered, and for the older model, only a list of fundamental

differences and general characteristics is given.

1 INTRODUCTION

SCSN "Angara" is a set of nodes of different types,

united by several communication networks, one of

which has a unique property of transmitting large

streams of short packets with high throughput. This

network is necessary to implement work with

globally addressable memory, hereinafter we will call

it the basic working network (BNW-network). The

nodes are connected to the basic working network and

can be computing and service (Molyakov, 2020).

Computing nodes are built on special multicore

multithread-stream microprocessors

(microprocessors of the J series), are combined into

modules in the form of multi-socket boards, and can

work on a logically single addressable memory

(globally addressable memory) formed by local

memories of modules with computational nodes.

There are two models of J-series microprocessors: the

younger one is J7, the older one is J10. Further, the

characteristics and principles of operation of the

younger model J7 are considered, for the older model

a list of fundamental differences and general

characteristics is given.

Service nodes are built on conventional

superscalar microprocessors, perform the functions of



https://orcid.org/0000-0003-4560-5911



input-output, user connection, interface with the

global network, and can also perform computations if

they are well localized and efficiently executed on

these nodes. Computing and service nodes are

connected to another network (RAS network), which

is a component of the reliability, availability, and

service subsystem. A detailed description of the

system-wide specification can be found in publication

(Mitrofanov, Slutskin and Eisymont, 2008).

2 METHODOLOGY

New architectural and technological approaches in

the field of creating "new generation"

supercomputers.

The J7 microprocessor is referred to as a

“multicore, multithread-stream microprocessor with

support for globally addressable memory operations”.

The term “globally addressable memory” in the name

of the microprocessor should be understood as

follows: in the J7 / J10 microprocessors, the virtual

memory is organized so that when it is accessed, it is

automatically recognized during the translation of the

address which node of the system should be accessed

and this call is made without user intervention. The J7

Molyakov, A.

Revolutionary Direction of Secured Supercomputer Technologies Development in Russia.

DOI: 10.5220/0010616500003170

In Proceedings of the International Scientiﬁc and Practical Conference on Computer and Information Security (INFSEC 2021), pages 5-11

ISBN: 978-989-758-531-9; ISSN: 2184-9862

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

microprocessor has two multi-threaded cores

(MTcore0 and MTcore1). Four command pipelines

are available in one multi-threaded core. Each of them

works with 16 threaded devices, each of which can

run one process (Semenov, 2010).

Several tasks can be executed simultaneously in

one microprocessor core. Each task is assigned one

protection domain, one of the kernel tasks is the

operating system. The user's task performed in the

microprocessor can be simultaneously executed in the

protection domains of its different cores; information

about the task's binding to the protection domains is

stored in a special table of the microprocessor.

The main idea behind hiding delays, i.e. ensuring

its insensitivity to these delays in terms of the

developed real performance, - ensuring a high rate of

execution of operations with memory and network.

This requires a special organization of the processor

and the applications running on it, a special

organization of a communication network, a special

organization of memory. All of these devices require

the ability to perform a large number of operations

simultaneously and high pipelining. The

computational model of the application is required to

be able to issue a large number of operations, which

is why multithreading is needed.

Memory and network latencies can be up to ten

times higher, the pace is not always able to withstand

the same operation per clock cycle, especially in the

communication network - the physical limitations of

the bandwidth of data transmission links between

nodes within the network effect. For these reasons, a

larger number of threaded devices are selected, up to

64-128 per MT core, which makes it possible to have

up to 512-1024 concurrent memory or network

accesses in one core. Commands of memory accesses

are used behind short vectors, for example, up to 8

64-bit words, which allows to further increase the

number of concurrent memory accesses and reduce

the overhead of organizing one memory access.

The term “streaming” is more applicable to the

architecture of the J10 microprocessors and can be

used in the sense of providing the ability to process

data streams using data flow graph models. Two

graph flow models are supported - static and dynamic

graphs. These models are used to provide more

parallelism and asynchrony, and static graphs are

used to reduce the number of memory accesses when

transferring data between nodes. A static graph node

appears along with the entire graph, functions for

some time, and then is deleted along with the graph.

A node of a dynamic graph can appear and be

destroyed during the operation of the graph. This

possibility is preserved and strengthened in the

Chinese version (Molyakov, 2019). For a node of a

dynamic graph, such a sequence of data arrival in an

arc can be violated, so the data comes with special

tags, by the coincidence of which they can find a pair

for themselves in the stream of another arc. The

operation may be normal if there is a pair for which

the operation can be performed. Such selection of

data corresponding to each other in the streams of arcs

requires the use of memory with associative access,

in this case, the associative address is a data tag. Such

memory is implemented in software. RPC commands

are actively used in the implementation of dynamic

graphs.

3 RESEARCH RESULTS

New principles of access security model based on

outbound command assembly and multi-domain

protection.

Given the development of vulnerability search

methods, the implementation of reactive information

protection methods should be considered, along with

preventive ones. Instead of the classical concept of

"localized task" for supercomputers (SC), one should

speak of parallel distributed stream structures

generated and processed at different levels of the

command pipeline hierarchy by processor devices

connected by high-speed networks.

Object access attributes and subject privileges,

connections between them are formalized as a set

(conjunction) of predicates. You can track interaction

and control access by a set of characteristic features

(markers), represented as tuples of boolean variables.

Information security is based on controlling

access to objects of management and guest operating

systems; these objects can be attributed to different

levels of protection. The traditional approach to

access control assumes the use of access attributes

(rights) in requests to these objects to perform some

operations on them. If the verification of such

attributes is successful, then access to the object at its

security level is allowed, then the requested operation

is performed on it. With this approach, it is

technically possible to intercept the request and use

its access rights in a surrogate request aimed at

malicious impact.

We propose a new mathematical model for

security. It is based on an 8-tier model (one level of

protection was added) and new logic for controlling

access to requests to perform actions with OS objects,

which is implemented by a hypervisor with an

appropriate organization, which additionally uses the

INFSEC 2021 - International Scientiﬁc and Practical Conference on Computer and Information Security

architectural capabilities of the proposed

supercomputer model extended by the author.

In the course of experimental studies, new

scientific results have been obtained that confirm the

effectiveness and minimal loss of performance of the

use of hardware virtualization technology in the form

of a multi-level "sandbox" for promising SCs in

comparison with the use of traditional superclusters.

Since it is possible to control the execution of requests

at the level of the components of the hypervisor and

the transactional memory controller and it is

impossible to control the operation of all equipment,

during the research, the maximum level of

functioning of the ISS agents was found - S8. With

this configuration, when the number of levels of the

hierarchy is N = 8, the execution of context-

dependent operations becomes quasi-deterministic

with a confidence level of approximately 0.9.

In classical processors with the von Neumann

architecture, data and program codes are shared,

which prevents the effective restriction of one object's

access to the address space and data of another. They

also do not implement multilayer protection

mechanisms against attacks when executing system

calls in a multi-level context of nested guest and

control operating systems. Tagged architecture on the

example of MCST Elbrus processor does not support

hardware virtualization technology. However, the

lack of support for hardware virtualization makes

such architectural solutions highly specialized and

does not support the emulation of various hardware

and support for widely used hypervisors. Some

features of the hardware virtualization technology

also speed up the operation of virtual machines and

increase the level of security. Hardware-assisted

virtualization and multi-layered protection can reduce

the overhead of creating an isolated runtime

environment. In any operating system, when the

kernel code is paired with hardware at the physical

level, forbidden states appear - a zero tuple of data,

which the processor prohibits accessing even

programs in the zero protection ring. Only the

processor module can perform active task context

switching in protected mode since when shadow

copying the data of the executable code, the

programmer cannot get direct access to the

information. This requires the implementation of a

tiered query processing hierarchy.

This approach did not apply to previous

generation microprocessors due to poor performance.

The introduction of additional levels of privileges and

levels of protection greatly slowed down the system

as a whole (Molyakov, 2019). The high performance

of supercomputers, on the contrary, makes it possible

to quickly analyze descriptor tables and calculate

hash values of processes. They are distinguished by

self-diagnostics, multi-level protection, binding each

thread device to a specific domain, programming

using non-functional, non-procedural languages -

chains of calculations in the form of selectors,

substitutions on the right, left of functional

calculations, multi-level parallelization of algorithms,

etc.).

When the boot program is executed, the threading

device operates in a special privilege mode -

IPL_LEVEL. Physical addressing when accessing

instruction memory and data memory is used in this

mode, then the virtual infrastructure manager and

host OSs with hypervisor support are loaded. In this

case, the KERNEL_LEVEL level is used for the

kernel modules and the SUPERVISOR_LEVEL level

for the equipment manager. At the final stage, the

guest OS is launched at the USER_LEVEL level.

The only "stumbling block" in multicore

multiprocessor systems is the problem of efficient

implementation of the on-chip network and working

with memory. The multicore microprocessors used in

computational nodes have become a necessary

measure to ensure the growth of their peak

performance, and it is caused by the termination of

the direct influence of Moore's law on the growth of

processor cores performance. Multicore has given

rise to the problem of efficient implementation of the

on-chip network and exacerbated the problems of

working with memory. Possible solutions include the

use of multi-threaded and streaming architectures in

processor cores.

The multithreading organization allows multiple

threads of instructions to be executed concurrently,

which makes it possible to increase the multitude of

executable instructions and increase the flow of

concurrent memory operations. The streaming

architecture assumes the use of the decision fields of

elementary processors in the form of static graphs of

data streams. This makes it possible to reduce the

total number of memory accesses since, in the

decisive field, data is transferred from one fast

resource to another without accessing memory

(Molyakov, 2019).

The author proposes a method for reconfiguring

the runtime environment, taking into account the

requirements of mobility and ensuring the specific

performance characteristics of the program for the

safe expansion of the functionality of the system or

application.

Only hardware support for sharded stacks can

reduce compiler complexity and runtime overhead. In

any operating system, when the kernel code is paired

Revolutionary Direction of Secured Supercomputer Technologies Development in Russia

with hardware at the physical level, forbidden states

appear - a zero tuple of data, which the processor

prohibits accessing even programs in the zero

protection ring.

Only the processor module can perform active

task context switching in protected mode since when

shadow copying the data of the executable code, the

programmer cannot get direct access to the

information. These collisions are resolved by a new

approach - marker scanning, which uses generative

tables (Molyakov, 2016).

In addition to coding the address separation of

memory protection rings, the OS of different classes

implements a strongly typed interface for interfacing

with the processor's hardware core and managing the

context of binary code execution, taking into account

the compilation and assembly profile - the use of

system object markers.

The command processing pipeline is as follows.

After fetching and issuing by any threading device a

command to access the memory, the command enters

the LSU functional block for executing memory

access commands. The executive memory address

prepared in the LSU is then transmitted to the MMU,

in which the virtual address is translated into a

physical address or a global virtual address.

If it is necessary to access the memory of a remote

node, which is automatically determined in the

MMU, a hardware-generated system short message

packet with a memory access command is transmitted

through the MSU network message control unit, the

on-chip network, the network interface with the

communication network.

When moving through the network, some packets

can deviate from the path prescribed by the routing

table, thus bypassing all kinds of "traffic jams" that

they can independently detect. After such a rejection,

the packet, under certain conditions, can return to a

guaranteed deadlock-free movement over the

network.

Globally addressable memory provides not only

additional programming convenience, which, as

experts expect, should affect the productivity of

parallel programming by about 10 times. An increase

in the efficiency of parallel programs is also expected,

since two-way interaction models of the “send-

receive” type, as a rule, by long messages, are

replaced by one-way interactions using short

messages. The reality of achieving greater efficiency

with such a transition to a new memory model and

organization of computations has already been

proven in many experiments (Gorbunov, and

Eisymont, 2010).

The J7 / J10 microprocessors also use a special

apparatus of tag bits and bits for controlling the

execution of memory accesses, which are available

both directly in memory cells and pointers to them.

The programs can use physical and virtual

addressing. Controlling the issuance of physical or

virtual addresses when accessing memory is

performed by setting a special bit in the thread state

word. Physical addressing is allowed only in

privileged kernel and boot modes. The memory of

commands and data is addressed according to

different schemes. Only data addressing is discussed

below.

4 PRACTICAL RESULTS OF

RESEARCH ON MODELING

STANDS. PROTOTYPES OF

CALCULATORS

General characteristics of the J7 microprocessor:

 There are two multi-threaded cores with 64

threaded devices in each and the ability to work

in each core with four program and data

protection domains;

 each thread device can execute software

threads of the same type, and each such thread

has access to only 32 64-bit general-purpose

registers, 32 64-bit registers for storing

floating-point numbers, 8 one-bit feature

registers, 8 registers for storing control transfer

addresses, a set of system registers and tables

available only at the system software or

hardware level;

 general registers and registers for storing

floating-point numbers are implemented as

single-level register memory, registers are used

only for temporary storage of data;

 a set of commands contains about 160

commands, processed data - 64-bit signed and

unsigned integers, 64-bit and 32-bit floating-

point numbers;

 The organization of virtual memory is

segment-page, three-level, work with shared

memory distributed over many computing

nodes (address distribution is cyclic and block-

cyclic) is provided, its volume can reach 8 PB

(8 * 1015) on a separate task, and in one

computing node - up to 256 GB, memory cells

are equipped with tag bits to synchronize calls

to these cells;

 the number of concurrently executed memory

access operations - 1024;

INFSEC 2021 - International Scientiﬁc and Practical Conference on Computer and Information Security

 The multi-threaded core contains four fixed-

point addition, subtraction and multiplication

units (FXU), two integer dividers (DIV), two

floating-point units (FPU), and one memory

(LSU), the level of parallelization of

commands is 4 commands, but from different

thread devices, all operations are performed on

scalar data, only operations from commands

selected from the executed threads fall on

functional devices,

 peak performance of one J-7 microprocessor

operating at a frequency of 500 MHz - about 4

Gflops for 64-bit numbers;

 the number of computational nodes in a

supercomputer built on a J-7 microprocessor is

up to 32 thousand nodes, i.e. the peak

performance of such a supercomputer will be

256 teraflops;

 high real performance at the level of 50-60%

should be achieved due to the following basic

architectural properties of the microprocessor:

tolerance to delays in performing operations

with memory and communication network due

to its multithreading using threads of the same

type;

 the ability to localize not only data but also

computations, the use of computation models

over distributed shared memory.

General characteristics of the J10 microprocessor:

 the presence of up to 8 multi-threaded cores,

each of which contains 128 or 256 threaded

devices and provides 16 protection domains;

 each thread device can execute software

threads that differ in the type of computations

performed (light, medium and heavy

computational models);

 the number of general and floating-point

registers used by one thread device can vary

depending on the type of thread being executed

from 16 to 64;

 register memory of general registers and

floating-point registers is implemented as two-

level cacheable register files of large size,

which provides greater efficiency in the use of

crystal area and power consumption;

 general and floating-point registers can be used

not only for the temporary storage of data but

also as input / output ports for ultra-fast inter-

thread interactions;

 a set of commands contains about 300

commands, processed data - 32-bit and 64-bit

signed and unsigned integers, 32-bit and 64-bit

floating-point numbers, bit matrices up to 64 ×

64;

 the organization of virtual memory is the same

as in J-7;

 the number of concurrently executed

commands of memory access and inter-thread

interactions through register input / output

ports - up to 16384;

 in multi-threaded cores there are blocks of

functional devices FXU and FPU operating in

asynchronous and synchronous mode. When

working in synchronous mode, FXU and FPU

can synchronously perform SIMD operations

on short vectors: 8 simultaneous operations on

32-bit numbers, 4 operations on 64-bit

numbers. Operations on the FXU and FPU can

come from commands from executable threads,

as well as directly from the function block for

receiving / issuing system messages. The peak

performance of a single J-10 microprocessor

with eight cores and operating at 1 GHz is

about 64 Gflops for 64-bit numbers. The multi-

threaded core additionally introduces

specialized devices for performing operations

on bit matrices and a device for cryptographic

algorithms and modular arithmetic;

 the number of computational nodes in a

supercomputer built on a J-10 microprocessor

is up to 32 thousand. The peak performance is

thus 2 Pflops for 64-bit numbers;



high performance up to 70-90% should be

achieved due to the following basic

architectural properties: processor tolerance to

delays in performing operations with memory

and communication network due to

multithreading with threads of different types

of Spatio-temporal localization of memory

accesses; localization of data near

computational processes and computations

near data; the use of computational models of

programs over distributed shared memory; a

sharp reduction in the number of memory

accesses and granularity of parallelization

required for the execution of tasks due to the

use of stream models of computations with

static graphs supported by the hardware in the

J-10; a sharp increase in thread parallelism due

to the use of hardware and firmware supported

in the J-10 stream models of computations with

dynamic graphs.

5 CONCLUSION

The most advanced work in Russia is the work of the

"public level" class associated with the development

Revolutionary Direction of Secured Supercomputer Technologies Development in Russia

of the MVS-express network, which uses the PCI-

express interface and PLX communication chips.

There are already two installations where this

approach is used - K100 (Keldysh Institute of Applied

Mathematics of the Russian Academy of Sciences)

and St. Petersburg State Polytechnic University.

Improvement of hardware and software MVS-

express continues, and techniques for effective

parallel programming of applied tasks are also being

developed. Similar works have been started at JSC

"NITSEVT", but they are focused on using the

HyperTransport interface. Also, NITSEVT is

working on a “moderate level” class of GAS / PGAS

implementation - an N-torus network router is being

implemented and it is planned to be strengthened with

multi-threaded cores (Eisymont, 2010). Work is

underway to create a VLSI router, which is currently

implemented as a prototype on an FPGA.

We should also mention the work of the

“moderate level” class of the GAS / PGAS

implementation, carried out by the staff of the

Ailamazyan Institute of Applied Problems of the

Russian Academy of Sciences and the RSK SKIF

company in the SKIF-Aurora project. This work is in

many respects similar to the implementation of

FPGA-based routers carried out at JSC "NITSEVT",

in which the main developers were former employees

of this organization. Work of this type is also carried

out by the T-Platforms Group via the Extоall network,

and its version of the microprocessor is being

developed, but there is no information about these

developments (Gorbunov, Elizarov and Eisymont,

2011).

The results of the SCS "Angara" project, which

has been carried out for more than 7 years, became

the basis for Chinese work on the strategic

supercomputer ST-2 in 2009 for the global

information system of China's military intelligence.

The TSMC factory has now produced prototypes of a

12-core mass multi-threaded microprocessor using 45

nm technology, which is a Chinese modified version

of the Russian J7 microprocessor project for the

Angara SCSN. The microprocessor was improved in

some characteristics: computational capabilities were

enhanced by introducing SIMD operations on short

vectors and GPU elements such as synchronously

executed threads in addition to asynchronous threads

from J7.

Work in this direction in China is being carried

out at NUDT, the National University of China's

Defense Technologies. They have serious prospects

for creating a supercomputer with an exascale

performance level not only for building information

systems, but also for solving scientific and technical

problems with a high level of real productivity, i.e.

not with peak, but real performance in exaflops.

Based on the existing domestic schemes for the

implementation of the multi-threaded core J7 / J10, it

is necessary to design the architecture and

microarchitecture of this core, taking into account the

Chinese experience of revision and American work,

to carry out improvements and acceptance testing on

fragments of special tasks of interest from different

departments with the aim of subsequent introduction

into industrial operation.

REFERENCES

Molyakov, A.S. (2020). Based on Reconfiguring the

Supercomputers Runtime Environment New Security

Methods. Advances in Science Technology and

Engineering Systems Journal, 5(3): 291-298.

Molyakov, A.S. (2020). Main Scientific and Technological

Problems in the Field of Architectural Solutions for

Supercomputers. Computer and Information Science,

13(3). DOI: 10.5539/cis.v13n3p89

Semenov, A.S. Development and research of the

architecture of globally addressable memory of a

multithread-streaming supercomputer. Dissertation for

the degree of candidate of technical sciences. Specialty

05.13.15 - Computing machines, complexes and

computer networks. Moscow 2010, 224 pages.

Molyakov, A.S. (2019). China Net: Military and Special

Supercomputer Centers. Journal of Electrical and

Electronic Engineering, 7(4): 95-100.

– DOI: 10.11648/j.jeee.20190704.12

Molyakov, A.S. (2019). Age of Great Chinese Dragon:

Supercomputer Centers and High Performance

Computing. Journal of Electrical and Electronic

Engineering, 7(4): 87-94.

– DOI: 10.11648/j.jeee.20190704.11

Molyakov, A.S. (2019). New Multilevel Architecture of

Secured Supercomputers. Current Trends in Computer

Sciences & Applications, 1(3).

DOI:10.32474/CTCSA.2019.01.000112.

Molyakov, A.S. (2019). Supercomputer and new generation

operating systems. Information security: yesterday,

today, tomorrow. International scientific and practical

conference: collection of articles of the Russian State

Humanitarian University. – Moscow, pages 196 – 200.

Molyakov, A. S. (2016). A Prototype Computer with Non-

von Neumann Architecture Based on Strategic

Domestic J7 Microprocessor. Automatic Control and

Computer Sciences, 50(8): 682 -686.

Molyakov, A. S. (2016). Token Scanning as a New

Scientific Approach in the Creation of Protected

Systems: A New Generation OS MICROTEK.

Automatic Control and Computer Sciences, 50(8): 687-

692.

Gorbunov, V. and Eisymont, L. (2010). Exascale Barrier:

Problems and Solutions. Open Systems, 6: 12-15.

INFSEC 2021 - International Scientiﬁc and Practical Conference on Computer and Information Security

Eisymont, L. (2010). DARPA UHPC - the road to exaflops.

Open Systems, 12. http://www.osp.ru/

Gorbunov, V., Elizarov, G. and Eisymont, L. (2011). HPC:

regional news. Open Systems, 2: 12-16.

Mitrofanov, V., Slutskin, A. and Eisymont, L. (2008).

Supercomputer technology for strategic missions.

ELECTRONICS: NTB, 7: 66-79.

Revolutionary Direction of Secured Supercomputer Technologies Development in Russia
